BLF346
BLF346
EN OPERATOR MANUAL
ES MANUAL DEL OPERADOR
BLOWER
SOPLADOR
1 Description.................................... 4
1.1 Purpose...................................................... 4
1.2 Overview.................................................... 4
2 Important safety instructions......... 4
3 Battery-operated power tools........ 4
4 Child Safety................................... 5
5 Save these instructions................. 5
6 Symbols on the product.................5
7 Risk levels..................................... 6
8 Environmentally safe battery
disposal......................................... 6
9 Installation..................................... 6
9.1 Unpack the machine...................................6
9.2 Install the tube............................................ 6
9.3 Install the battery pack............................... 7
9.4 Remove the battery pack........................... 7
10 Operation.......................................7
10.1 Start the machine....................................... 7
10.2 Stop the machine....................................... 7
10.3 Cruise control lever.................................... 7
10.4 Turbo button............................................... 7
10.5 Operation tips............................................. 7
11 Maintenance..................................7
11.1 Clean the machine..................................... 7
12 Transportation and storage........... 8
12.1 Move the machine...................................... 8
12.2 Store the machine...................................... 8
13 Troubleshooting.............................8
14 Technical data............................... 8
15 Limited warranty............................ 8
16 Exploded view............................... 9
3
English
EN
1 DESCRIPTION
1.1 PURPOSE
The machine is used to propel air out of a tube to move
unwanted materials such as leaves in the yard. Some
machines also suck in leaves and small twigs through a
vacuum, and shred them into a bag.
1.2 OVERVIEW
Figure 1 - 4.
1
Trigger
2
Turbo button
3
Cruise control lever
4
Tube release button
5
Tube
6
Nozzle
7
Lock button
8
Slot
9
Battery release
button
2 IMPORTANT SAFETY
INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING (THIS
POWER TOOL)
WARNING
Read and understand all instructions before using this
product. Failure to follow all instructions listed below
may result in electric shock, fire, and/or serious
personal injury. When using an electrical appliance,
basic precautions should always be followed, including
the following:
• Do not use on wet surfaces.
• Do not charge the unit outdoors.
• For household use.
• Do not allow to be used as a toy. Close attention is
necessary when used by or near children.
• Use only as described in this manual. Use only
manufacturer’s recommended attachments.
• If appliance is not working as it should, has been
dropped, damaged, left outdoors, or dropped into
water, return it to a service center.
• Do not handle appliance with wet hands.
• Do not put any object into openings. Do not use with
any opening blocked; keep free of dust, lint, hair,
and anything that may reduce air flow.
• Keep hair, loose clothing, fingers and all body parts
away from openings and moving parts.
• Use extra care when cleaning on stairs.
• Do not operate power tools in an explosive
atmosphere, such as in the presence of flammable
liquids, gases, or dust. Power tools create sparks
that may ignite the dust or fumes.
• Store indoors. Do not expose to rain or water. Avoid
direct sunshine.
• Never allow children to operate the equipment.
Never allow adults to operate the equipment without
proper instruction.
• Wear heavy long pants, boots, and gloves. Avoid
loose garments or jewellery that could get caught in
moving parts of the machine or its motor.
• Do not force tool. Use the correct tool for your
application. The correct tool will do the job better
and safer at the rate for which it is designed.
• Do not leave appliance when not in use and before
servicing.
• Do not operate the equipment while barefoot or
when wearing sandals or similar lightweight
footwear. Wear protective footwear that will protect
your feet and improve your footing on slippery
surfaces.
• Keep firm footing and balance. Do not overreach.
Overreaching can result in loss of balance.
• Do not use the tool if the switch does not turn it on
or off. Any tool that cannot be controlled with the
switch is dangerous, and must be repaired.
• Do not operate this unit when you are tired, ill, or
under the influence of alcohol, drugs, or medication.
• Do not operate in poor lighting.
• Do not pull or carry by cord, use cord as a handle,
close a door on cord, or pull cord around sharp
edges or corners. Do not run appliance over cord.
Keep cord away from heated surfaces.
• Do not use to pick up flammable or combustible
liquids, such as gasoline, or use in areas where they
may be present
• Do not pick up anything that is burning or smoking,
such as cigarettes, matches, or hot ashes.
• Do not use without dust bag and/or filters in place (if
applicable).
• Check the work area before each use. Remove all
objects such as rocks, broken glass, nails, wire, or
string which can be thrown or become entangled in
the machine.
• Use only identical manufacturer’s replacement parts
and accessories. Use of any other parts may create
a hazard or cause product damage.
3 BATTERY-OPERATED POWER
TOOLS
• Do not use battery-operated appliance in rain.
• Turn off all controls before removing the battery.
• Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used
with another battery pack.
• Use only the charger supplied by the manufacturer
to recharge.
• Use appliances only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
4
English
EN
• Prevent unintentional starting. Ensure the switch is
in the off-position before connecting to battery pack,
picking up or carrying the appliance. Carry the
power tool with your finger on the switch or energize
power tool that have the switch on invites accidents.
• Disconnect the battery pack from the power tool
before making any adjustments, changing
accessories, or storing the power tool. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
• When battery pack is not in use, keep it away from
other metal objects like paper clips, coins, keys,
nails, screws or other small metal objects that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
burns or a fire.
• Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or
burns.
• Do not incinerate the appliance even if it is severely
damaged. The batteries can explode in a fire.
• Do not use a battery pack or appliance that is
damaged or modified. Damaged or modified
batteries may exhibit unpredictable behavior
resulting in fire, explosion or risk of injury.
• Do not expose a battery pack or appliance to fire or
excessive temperature. Exposure to fire or
temperature above 265°F (130°C) may cause an
explosion.
• Have servicing performed by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the product is
maintained.
• Don't modify or attempt to repair the appliance or
the battery pack (as applicable) except as indicated
in the instructions for use and care.
• Follow all charging instructions and do not charge
the battery pack or appliance outside of the
temperature range specified in the instructions.
Charging improperly or at temperatures outside of
the specified range may damage the battery and
increase the risk of fire.
4 CHILD SAFETY
Tragic accidents can occur if the operator is not aware
of the presence of children.
• Keep children out of the working area and under the
watchful care of a responsible adult.
• Do not allow children under the age of 14 to operate
this machine. Children who are 14 years of age and
older must read and understand the operating
instructions and safety rules in this manual and must
be trained and supervised by a parent.
• Stay alert, and turn the machine off if a child or any
other person enters the working area.
• Use extreme care when approaching blind corners,
doorways, shrubs, trees, or other objects that may
obscure your view of a child who may run into the
path of the machine.
5 SAVE THESE
INSTRUCTIONS
6 SYMBOLS ON THE PRODUCT
Some of the following symbols may be used on this tool.
Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate
the tool better and safer.
Symbol Explanation
V Voltage
A Current
W Power
min Time
/min
Revolutions, strokes, surface speed,
orbits etc., per minute
Direct current
Read and understand all instructions
before operating the product, and fol-
low all warnings and safety instruc-
tions.
Precautions that involve your safety.
Wear ear protection when operating
this equipment.
Always wear eye protection with side
shields marked to comply with ANSI
Z87.1 when operating this equipment.
Do not expose the product to rain or
moist conditions.
Keep all bystanders at least 15 m
away.
Do not touch the fan when you oper-
ate this machine.
Failure to keep loose clothing from
being drawn into air intake could re-
sult in personal injury.
5
English
EN
Symbol Explanation
Failure to keep long hair away from
the air inlet could result in personal
injury.
Rotating impeller blades can cause
severe injury.
7 RISK LEVELS
The following signal words and meanings are intended
to explain the levels of risk associated with this product.
SYM-
BOL
SIGNAL MEANING
DANGER Indicates an imminently
hazardous situation,which,
if not avoided, will result in
death or serious injury.
WARNING Indicates a potentially haz-
ardous situation,which, if
not avoided, could result in
death or serious injury.
CAUTION Indicates a potentially haz-
ardous situation, which, if
not avoided, may result in
minor or moderate injury.
CAUTION (Without Safety Alert Sym-
bol) Indicates a situation
that may result in property
damage.
8 ENVIRONMENTALLY SAFE
BATTERY DISPOSAL
The toxic and corrosive materials below are in the
batteries used in this machine: Lithium-Ion, a toxic
material.
WARNING
Discard all toxic materials in a specified manner to
prevent contamination of the environment. Before
discarding damaged or worn out Li-ion battery, contact
your local waste disposal agency, or the local
Environmental Protection Agency for information and
specific instructions. Take the batteries to a local
recycling and/or disposal center, certified for lithium-
ion disposal.
WARNING
If the battery pack cracks or breaks, with or without
leaks, do not recharge it and do not use. Discard it
and replace with a new battery pack. DO NOT TRY
TO REPAIR IT! To prevent injury and risk of fire,
explosion, or electric shock, and to avoid damage to
the environment:
• Cover the terminals of the battery with heavy-duty
adhesive tape.
• DO NOT try to remove or destroy any of the
battery pack components.
• DO NOT try to open the battery pack.
• If a leak develops, the released electrolytes are
corrosive and toxic. DO NOT get the solution in the
eyes or on skin, and do not swallow it.
• DO NOT put these batteries in your regular
household trash.
• DO NOT incinerate.
• DO NOT put them where they will become part of
any waste landfill or municipal solid waste stream.
• Take them to a certified recycling or disposal
center.
9 INSTALLATION
9.1 UNPACK THE MACHINE
WARNING
Make sure that you correctly assemble the machine
before use.
WARNING
• If the parts have damage, do not use the machine.
• If you do not have all the parts, do not operate the
machine.
• If the parts are damaged or missing, speak to the
service center.
1. Open the package.
2. Read the documentation in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and package in compliance with
local regulations.
9.2 INSTALL THE TUBE
Figure 2.
1. Move the tube until the lock button engages into the
slot.
2. Connect the nozzle to the tube until the latch on the
tube engages into the opening on the nozzle.
6
English
EN
TIP
You can use the nozzle to increase airflow in tight
areas.
9.3 INSTALL THE BATTERY PACK
Figure 3.
WARNING
• If the battery pack or charger is damaged, replace
the battery pack or the charger.
• Stop the machine and wait until the engine stops
before you install or remove the battery pack.
• Read, know, and do the instructions in the battery
and charger manual.
1. Align the lift ribs on the battery pack with the
grooves in the battery compartment.
2. Push the battery pack into the battery compartment
until the battery pack locks into place.
3. When you hear a click, the battery pack is installed.
9.4 REMOVE THE BATTERY PACK
Figure 3.
1. Push and hold the battery release button.
2. Remove the battery pack from the machine.
10 OPERATION
WARNING
Make sure the blower tube is in position before
operation.
10.1 START THE MACHINE
Figure 4.
1. Pull the trigger to start the machine.
2. Pull the trigger fully to increase the speed.
3. Release the trigger to decrease the speed.
10.2 STOP THE MACHINE
Figure 4.
1. Release the trigger to stop the machine.
NOTE
Wait until the engine stops after you stop the machine.
10.3 CRUISE CONTROL LEVER
Figure 4.
1. Pull the cruise control lever clockwise to increase
the speed. This will lock the speed at the desired
setting.
2. Push the cruise control lever counter clockwise to
decrease the speed.
NOTE
If you decrease the speed all the way, the unit will stop
and it is necessary to do the first step again.
10.4 TURBO BUTTON
Figure 4.
1. Push the turbo button, the machine is at the highest
speed.
2. Release the turbo button, the machine is at the
normal speed.
10.5 OPERATION TIPS
• Blow around the outer edge of the unwanted
materials to prevent the unwanted materials from
scattering.
• Use rakes and brooms to clear the unwanted
material before you blow.
• Make the surfaces wet before you clear the
unwanted material in dusty conditions.
• Look out for children, pets, open windows, and
cleaned cars during operation.
• Clean the machine.
• Discard the unwanted material when you complete
work.
11 MAINTENANCE
CAUTION
Do not let brake fluids, gasoline, petroleum-based
materials touch the plastic parts. Chemicals can cause
damage to the plastic, and make the plastic
unserviceable.
CAUTION
Do not use strong solvents or detergents on the plastic
housing or components.
WARNING
Remove the battery pack from the machine before
maintenance.
11.1 CLEAN THE MACHINE
CAUTION
The machine must be dry. Humidity can cause risks of
electrical shocks.
• Clear the unwanted material out of the air vent with
a vacuum cleaner.
7
English
EN
• Do not spray the air vent or put the air vent in
solvents.
• Clean the housing and the plastic components with
a moist and soft cloth.
1
2 TRANSPORTATION AND
STORAGE
WARNING
Remove the battery pack from the machine before
tranportation and storage.
12.1 MOVE THE MACHINE
• Only hold the machine with the handgrip.
• Remove the blower tube when you move the
machine on a vehicle.
1
2.2 STORE THE MACHINE
• Clean the machine before storage.
• Make sure that the motor is not hot when you store
the machine.
• Make sure that the machine does not have loose or
damaged parts. If it is necessary, do these steps/
instructions:
• Replace the damaged parts.
• Tighten the bolts.
• Speak to a person of an approved service
center.
• Store the machine in a dry area.
• Make sure that children cannot come near the
machine.
1
3 TROUBLESHOOTING
PROBLEM POSSIBLE
CAUSE
SOLUTION
The motor does
not start when
you pull the trig-
ger.
The battery pack
is not installed
tightly.
Make sure that
you tighlty install
the battery pack
in the machine.
The battery pack
is out of power.
Charge the bat-
tery pack.
The machine
does not start.
The power switch
is defective.
Replace the de-
fective parts by
an approved
service center.
The motor is de-
fective.
The PCB board is
defective.
PROBLEM POSSIBLE
CAUSE
SOLUTION
The air does not
flow through the
tube when you
start the ma-
chine.
The air inlet or
tube outlet has a
blockage.
Remove the
blockage.
14 TECHNICAL DATA
Voltage 40 V
Air volume 450 CFM
Air speed 125 MPH
Weight (without
battery pack)
1.9 kg (4.2 lbs.)
Battery model BAF722 and other BAF series
Charger model CAF series or 29842 charger
The recommended ambient temperature range:
Item Temperature
Blower storage tempera-
ture range
-4°F (-20°C) - 158°F
(70°C)
Blower operation tempera-
ture range
-4°F (-20°C) - 104°F
(40°C)
Battery charging tempera-
ture range
39°F (4°C) - 104°F (40°C)
Charger operation temper-
ature range
39°F (4°C) - 113°F (45°C)
Battery storage tempera-
ture range
1 year: 32°F (0°C) - 73°F
(23°C)
3 months: 32°F (0°C) -
113°F (45°C)
1 months: 32°F (0°C) -
140°F (60°C)
Battery discharging tem-
perature range
6.8°F (-14°C) - 113°F
(45°C)
15 LIMITED WARRANTY
Greenworks hereby warranties this product, to the
original purchaser with proof of purchase, for a period of
three (3) years against defects in materials, parts or
8
English
EN
YEAR
AÑOS
LIMITED WARRANTY
GARANTÍA
LIMITADA
3
workmanship. Greenworks , at its own discretion will
repair or replace any and all parts found to be defective,
through normal use, free of charge to the customer.
This warranty is valid only for units which have been
used for personal use that have not been hired or
rented for industrial/commercial use, and that have
been maintained in accordance with the instructions in
the owners’ manual supplied with the product from new.
I
TEMS NOT COVERED BY WARRANTY:
1. Any part that has become inoperative due to
misuse, commercial use, abuse, neglect, accident,
improper maintenance, or alteration; or
2. The unit, if it has not been operated and/or
maintained in accordance with the owner's manual;
or
3. Normal wear, except as noted below;
4. Routine maintenance items such as lubricants,
blade sharpening;
5. Normal deterioration of the exterior finish due to use
or exposure.
H
ELPLINE:
Warranty service is available by calling our toll-free
helpline, at 1-888-909-6757.
1
6 EXPLODED VIEW
1
2
3
4
No. Part No. Qty Description
1 311093502 1 Cruise control assembly
2 311053510 1 Blower assembly
3 311043510 1 Tube
4 311063513 1 Nozzle
9
English
EN
TRANSPORTATION CHARGES:
Transportation charges for the movement of any power
equipment unit or attachment are the responsibility of the
purchaser. It is the purchaser’s responsibility to pay
transportation charges for any part submitted for replacement
under this warranty unless such return is requested in writing
by Greenworks.
USA ADDRESS:
Greenworks Tools
P.O. Box 1238
Mooresville, NC 28115
