Version 1.0
Samsung Electronics
page 1 of 13
User manual of WCA720M
1. Introduction
WCA720M is a Wi-Fi module compliant with IEEE802.11 a.b.g.n.ac MAC/baseband/radio applications. The
core chipset is from Mediatek, part number MT7668.
2. Hardware Architecture:
2.1 Main Chipset Information
Item Vendor Part Number
IEEE802.11 a.b.g.n.ac
mac/baseband/radio
Mediatek MT7668
2.2 Absolute Maximum Ratings
Symbol Parameter Rating Unit
Temp Operating -10 to 70 ℃
TSTG Storage Temperature -30 to 85 ℃
