I Figures and illustrations in this User Manual are provided for reference Transportation to and from the Service Center is the responsibility of
only and may differ from actual product appearance. Product design and the purchaser. Conditions covered are limited only to manufacturing
specifications may be changed withoat notice, defects in material or workmanstqip, and only those encountered
Important Warranty Information Regarding
Television Format Viewing
=_ See tile warranty card for more information oil warranty
terms.
Wide screen format LED Displays (16:9, the aspect ratio ofthe
screen width to height) are primarily designed to view wide screen
format full-motion video. The images displayed on them should
primarily be in the wide screen 16:9 ratio format, or expanded to
fill the screen ifyour model offers this feature and the images are
constantly moving. Displaying stationary graphics and images on
screen, such as the dark sidebars on non- expanded standard
format television video and programming, should be limited to no
more than 5% of the total television viewing per week. Additionally,
viewing other stationary images and text such as stock market
reports, video game displays, station loges, web sites or computer
graphics and patterns, should be limited as described above for
all televisions. Displaying stationary images that exceed the above
guidelines can cause uneven aging of LED Displays that leave
subtle, but permanent burned-in ghost images in the LED picture.
To avoid this, vary the programming and images, and primarily
display full screen moving images, not stationary patterns or dark
bars. On LED models that offer picture sizing features, use these
controls to view different formats as a full screen picture. Be careful
in the selection and duration of television formats you use for
viewing. Uneven LED aging as a result of format selection and use,
as well as burned-in images, are not covered by your Samsung
limited warranty.
- SAMSUNG ELECTRONICS NORTH AMERICAN LIMITED
WARRANTY STATEMENT
Subject to the requirements, conditions, exclusions and limitations
of the original Limited Warranty supplied with Samsung Electronics
(SAMSUNG) products, and the requirements, conditions, exclusions
and limitations contained herein, SAMSUNG will additionally
provide Warranty Repair Service in the United States on SAMSUNG
products purchased in Canada, and in Canada on SAMSUNG
products purchased in the United States, for the warranty period
originally specified, and to the Original Purchaser only.
The above described warranty repairs must be performed by a
SAMSUNG Authorized Service (}enter. Along with this Statement,
the Original Limited Warranty Statement and a dated Billof Sale
as Proof of Purchase must be presented to the Service (}enter.
BN68 05829L-00
innormal use of the product. Excluded, but not limited to, are
any originally specified provisions for, in-home or on-site services,
minimum or maximum repair times, exchanges or replacements,
accessories, options, upgrades, or consumables.
Forthe location of a SAMSUNG Authorized Service Center, please
call toIHree:
-- In the United States :1-800-SAMSUNG (1-800-726-7864
-- In Canada : 1-800-SAMSUNG
Still image warning
Avoid displaying still images (such as jpeg picture files)or still
image elements (such as TV channel loges, TV shows or movies
in panorama or 4:3 format, stock or news scroll bars, etc.) on the
screen. The constant display of still pictures can cause ghosting or
image burn-in (image retention) on the LED screen, which will affect
image quality.To reduce the risk of this effect, please follow the
recommendations below:
- Avoid displaying the same TV channel for long periods.
- Always try to display any image in fullscreen mode. Use the TV's
Picture Options menu to select the optimal screen size.
- Reduce brightness and contrast values to the minimum required
to achieve the desired picture quality. Values that exceed the
minimum may speed up the burn-in process.
- Frequently use all TV features designed to reduce image retention
and screen burn-in. Refer to proper user manual section for
details.
Contact SAMSUNG WORLD WIDE
If you haveanyquestionsor comments_e!atingto Samsungproducts, i
pleasecontacttheSAMSUNGcustomercarecenter.
Samsung Electronics Samsung Electronics
Canada Inc. 2050 Derry America, Inc. 85
Road West, Mississauga, Challenger Road
Ontario L5N OB9 Canada Ridgefield Park, NJ 07660
<,
1-800-oAMSUNG (726-7864)
vww,Lsamsung.com/ca/
support (English)
vwwv.samsung.com/cafr/ support
support (French)
Your TV has two kinds of menus, the Main menu and the various
Tools menus. The Main menu gives you access to most or all of
the menu options available on your TV.The Tools menus display
a selected number of frequently used menu options that change
depending on the screen you are viewing.
The Main menu hasseven primary categories:
" Picture o Input
" Sound o Application
" Channel o Support
- Setup
To view the Main menu, press the MENU button on your remote. To
view a Tools menu, press the TOOLS button onyour remote.
'_' The menu options that appear in the Main menu depend
on the Source you have selected. For example, if you have
selected the HDMI source, the Channel category will not
appear. To see the Channel category, you must first select TV
in the Source List.
The Menu options are presented below, arranged by Main menu
categories. A Tools button symbol (_['_ll) next to an option
name indicates the option is also available in one of the Tools
menus.
Mode
Select your preferred picture mode.
'_' When your TV is connected to a PC, you can only select
Entertain and Standard.
[] Dynamic: Brightens the screen. Suitable for a bright room.
[] Standard: Suitable for a normal.
[] Movie: Darkens the screen, making it less glary. Suitable for
watching movies in a darkened room.
[] Entertain: Sharpens the picture. Suitable for games.
_ Only available when the TV is connected to a PC.
Backlight / Contrast / Brightness / Sharpness /
Color / Tint (G/R)
[] Backlight: Adjusts the brightness ofthe screen by adjusting the
brightness of the individual pixeIs.
[] Contrast: Increases or decreases the contrast between dark and
light areas of the picture.
[] Brightness: Adjusts the brightness of the screen. Not as
effective as BacHight.
[] Sharpness: Sharpens or dulls the edges of objects.
[] Color: Adjusts the color saturation. The higher the Color setting,
the more intense the color. Low settings remove color and the
picture becomes black, white and gray.
[] Tint (G/R): Adjusts the amount of green and red in the picture.
As you increase the amount of green, the amount of red
decreases and vice versa.
'_' When the TV is connected to a PC, you can only make
changes to Backlight, Contrast, Brightness, and
Sharpness.
Picture Options
=_ When the TV is connected to a PC, you can only make
changes to ttqeColor Tone, Size and HDMI Black Level.
[] Color Tone (Cool / Standard / Warm): Cool makes the picture
bluer (cooler). Warm 1 and Warm 2 make the picture redder
(warmer).
[] Size: Set ttqesize and aspect ratio of the picture on the screen.
Your cable box or satellite receiver may have its own set of
screen sizes as well. However, we highly recommend you use
ttqeTVs 16:9 mode most of the time.
=z The menu is deactivated, when ttqeH. 264 (1080p) DTV is
being played.
16:9: Sets the picture to the 16:9 wide screen format.
Zoom1 : Provides moderate magnification of the picture. Sides,
top, and bottom are cut off.
Zoom2: Provides larger magnification of the picture. Sides, top,
and bottom are cut off.
Wide Fit: Enlarges ttqeaspect ratio of the picture so the picture
fits the entire screen.
4:3: Sets ttqepicture to the old, 4:3 format and puts black or gray
borders on the right and left of the picture.
=z Do not watctq your TV in ttqe4:3 format for a long time.
Traces of borders displayed on the left, right and center of
the screen may cause image retention (screen bum) wtqictq
is not covered by the warranty.
Screen Fit: Displays the full image without any cut-off when
your TV is inputting HDMI (720p/1080i/1080p) or Component
(1080i/1080p) HD signals.
=z HD (High Definition) has a 16:9 aspect ratio and 1080i/1080p
(1920x1080) or 720p (1280x720) resolution.
=z You can adjust and store settings for eactq external device you
have connected to an input on the TV. Picture Sizes available
by hqputSource are listed below:
16:9, Zoom1,
ATV,AV,Component (480i,480p) Zoom2, 4:3
DTV(1080i),Component (1080i, 1080p),HDMI 16:9, Wide Fit,
(720p, 1080i, 1080p) 4:3, Screen Fit
[] Digital Clean View (Off / Low / Medium / High / Auto) :If the
broadcast signal received by your TV is weak, you can activate
ttqe Digital Clean View feature to reduce any static and ghosting
ttqat may appear on the screen.
=z When the signal is weak, try all ttqeDigital Clean View
options until the TV displays ttqebest picture.
[] HDMI Black Level (Normal / Low) : For HDMI signals, select
ttqe black level to adjust ttqescreen depth. Low make blacks look
darker.
=z Available only in HDMI mode (RGB signals).
[] Film Mode (Off / Auto) : Sets the TV to automatically sense and
process film signals from all sources and adjusts the picture for
optimum quality.
=z Available in ATV, DTV (interlace), AV, COMPONENT (480i /
1080i) and HDMI (480i / 1080i).
[] Motion Lighting (Off/On): Reduce power consumption by
brigtltness control adapted motion.
=z Available in Standard mode only.
Picture Reset
[] Picture Reset (Reset Picture Mode/Cancel): Resets ttqe
picture settings to their factory defaults.
Mode
[] Standard: Selects the normal sound mode.
[] Music: Emphasizes music over voices.
[] Movie: Provides the best sound for movies.
[] Clear Voice: Emphasizes voices over other sounds.
Equalizer
Available in Standard sound mode only.
[] Balance L/R: Adjusts the balance between the right and left
speaker.
[] 100Hz / 300Hz / 1KHz / 3KHz / 10KHz (Bandwidth
Adjustment): Adjusts the loudness of specific bandwidth
frequencies.
[] Reset: Resets the equalizer to itsdefault settings.
DTS TruSurround
Available in Standard sound mode only.
DTSTruSurround is a patented DTS technology that solves
the problem of playing 5.1 multichannel content over two
speakers. TruSurround delivers a compelling, virtual surround
sound experience through any two-speaker playback system,
including internaltelevision speakers. It isfully compatible with all
multichannel formats.
Preferred Language
Digital channels only.
DigitaI-TV broadcasts can transmit many audio tracks
simultaneously (for example, simultaneous translations of a program
into foreign languages).
'_' You can only select a language from among the ones being
broadcast.
Multi-Track Sound (MTS)
Analog channels only.
[] Mono: Select for channels that are broadcasting in mono or if
you are having difficulty receiving a stereo signal.
[] Stereo: Select for channels that are broadcasting in stereo.
[] SAP: Select to listen to the Separate Audio Program, which is
usually a foreign-language translation.
'_' Depending on the program being broadcast, you can listen to
Mono, Stereo or SAP
Auto Volume
Automatically adjusts the volume levelwtqenyou ctqangevideo
sources or content so the level remains the same.
SPDIF Output
The SPDIF (Sony Philips Digital InterFace) outputs an
uncompressed digital audio signal when you connect the digital
audio jack on the back of the TV to a digital audio injack on a
receiver or home theater.
[] Audio Format (PCM/Dolby Digital): You can select the Digital
Audio output (SPDIF) format. The available Digital Audio output
format may differ depending on the input source.
'_' By connecting the TV to a receiver or home theater with
Dolby Digital and 5.1ch speakers and selecting Dolby
Digital, you can maximize your interactive3D sound
experience.
[] Audio Delay: Lets you correct timing mismatches between the
audio track and the video when you are watching the TV and
listening to digital audio output from the TV through an external
device such as an AV receiver. When you select Audio Delay, a
slider appears. Use the left and right arrow buttons to adjust the
slider. Press ENTER _ when done (0ms _ 250ms).
Speaker Select
A sound echo may occur due to a difference in decoding speed
between the main speaker and the audio receiver. Inthis case, set
the TV to External Speaker.
'_' When Speaker Select is set to External Speaker, the
volume and MUTE buttons will not operate and the sound
settings will be limited.
'_' When Speaker Select is set to External Speaker.
* TV Speaker: Off, External Speaker: On
'_' When Speaker Select is set to TV Speaker.
* TV Speaker: On, External Speaker: On
'_' If there is no video signal, both speakers will be mute.
Visual Impaired
Digital channels only.
Adds verbal description to the main audio to help the visually
impaired.
Sound Reset
[] Reset All: Resets all sound settings to ttqefactory defaults.
_3Memorizing Channels
When you first set upyour TV using Plug & Play, the TV
memorized the channels that were available over the air or through
your cable system and added them to the Channel List. The
Antenna and Auto program functions described below let you
re-run the channel memorization function without having to re-run
the Plug & Play procedure.
Antenna (Air/ Cable)
Before your television can memorize the available channels, you
must select your TV's signal source, Air (using an antenna) or
Cable. Select Menu >Channel > Antenna > Air or Cable. After
you have selected the signal source, go on to the Auto Program
function.
'_' Selecting the signal source using the Antenna function also
determines the signal source the TV is tuned to. For example,
ifyou receive your TV signal over the air, and you select
Cable, you will see only snow. You must select Air to see a
picture.
Auto Program
The Auto Program function memorizes all ctqannels that are
available over the air or through your cable system and adds them
to the Channel List.
To start Auto Program, follow these steps:
1. Push MENUrrrl _ Channel _ Auto Program _ ENTER_
on your remote. The Antenna Source screen appears.
2. On the Antenna Source screen, select the source of your TV
signal.
Air
Ifyour TV is connected to an antenna choose Air, and ttqen press
ENTER _. The TV will automatically start memorizing channels.
Cable
Ifyour TV is connected to a cable outlet, ctqoose Cable, and then
press ENTERS. Go to Step 3.
Auto
If you choose Auto, and then press ENTERS, the TV will
automatically select the correct Antenna source. Go to
Step 3.
3. On the Cable Type screen, use the _/I_/A/T buttons to select
the type of digital and analog cable systems you have: STD, HRC,
or IRC. Most systems are STD (Standard). When done, select
Start, and then press ENTER _. The TV will start memorizing
channels.
=z Channel memorization can take up to 45 minutes, depending
on your cable system.
=z Memorized ctqannels are added to ttqeAdded Channels
list. These are ttqe channels you will see wtqen you usettqe
Channel buttons on your remote.
Clear Scrambled Channel
This function filters out scrambled cilannels after Auto Program is
completed. This process may take up to 20_30 minutes.
=z Press the ENTER _ button to stop the Clear Scrambled
Channel.
=z This function is only available in Cable mode.
C3Managing Channels
Channel List
See your list of Added channels, Favorite channels, or channels
you've scheduled for viewing. Add or delete Favorite channels, add
or delete channels from the Added Channels list, schedule channels
or programs for viewing. Watch a channel by selecting the channel
in the All Channels, Added Channels, or Favorite screen, pressing
the A / T buttons, and then pressing the ENTER_ button.
Channel List Screens icons are listed on the left side. Select an
icon using the A/T buttons to view each list.
[] _ All Channels: Shows allcurrently available channels including
those you deleted from the Added Channels
list,
[] _ Added Channels: Shows allAdded Channels. These are the
channels that appear when you press the CH LIST button.
[] _ Favorite: Shows allfavorite channels.
[] (_ Programmed: Shows all ctqannels and programs currently
scheduled using Timer Viewing.
'_' Remote control buttons active on the Channel List screen.
* Green (Zoom): Enlarges or shrinks a channel number.
* Yellow (Select): Move the cursor to a channel. Press the Yellow
button to select the channel. A _ mark appears. Repeat to select
additional channels. Then, open the Tools menu and apply a
function to the channels you selected.
* _r3 (Tools): Displays the Channel List Tools menu. (The Tools
menus may differ depending on the situation.)
Display Icons Used in the Channel List Screens
.,z
v
6)
A selected channel.
A Favorite channel.
A reserved program.
A program currently being broadcast.
_3The Channel List Tools Menu
The Channel List Tools menu contains most of the functions you
can use on the All Channel, Added Channels, and Favorite List
screens, [b view, select a list screen, select a channel, and then
press the TOOLS button,
[] Add / Delete: Delete a channel from or add a channel to the
Added Channels list.
To delete channels from the Added Channels list, follow these steps:
1. Select one or more channels in the Added Channels list using
the &/_ buttons and the Yellow Select button on your remote.
2. Press the TOOLS button on your remote. The Tools menu
appears.
3. Select Delete in the Tools menu, and then press the ENTER
button.
To add channels to the Added Channels list,follow these steps:
1. Select one or more channels in the All Channels list using the
A/_' buttons and the Yellow Select button onyour remote.
2. Press the TOOLS button on your remote. The Tools menu
appears.
3. Select Add inthe Tools menu, and then press the ENTER
button.
'_' All deleted channels will be shown on the All Channels list.
You add channels back to the Added Channels list on the
All Channels list.
'_' A gray-colored channel indicates the channel has been
deleted from the Added Channels list.
'_' The Add menu option only appears for deleted channels.
[] Add to Favorite/Delete from Favorite: Lets you add channels to
and delete channels from your Favorites list.
To add channels to the Favorites list, follow these steps:
1. Select one or more channels in the All Channels list using the
A/T buttons and the Yellow Select button on your remote.
2. Press the TOOLS button on your remote. The Tools menu
appears.
3. Select Add to Favorite in the Tools menu, and then press the
ENTER_ button.
-t-
© 2014 Samsung Electronics Co., Ltd. All rights reserved.
-2- -3- -4-
To delete channels from the Favorites list,follow these steps:
1. Select one or more channels in the Favorite Channels list
using the A/T buttons and the Yellow Select button on your
remote.
2. Press the TOOLS button on your remote. The Tools menu
appears.
3. Select Delete from Favorite in the Tools menu, and then
press the ENTER _ button.
[] Timer Viewing: You can schedule a channel to be displayed
automatically at a set time, even when you are watching another
channel. You must set the current time first in the Time > Clock
function to use Time Viewing.
To schedule a channel, follow these steps:
1. Select a channel in the Added Channels list using the A/_
buttons and the Yellow Select button on your remote.
2. Press the TOOLS button on your remote. The Tools menu
appears.
3. Select Time Viewing in the Tools menu, and then press the
ENTER _ button. The Time Viewing screen appears.
4. Use the _/1_ buttons to move from entry field to entry field
and the &/_ buttons to change the entries. Where numbers
are displayed, you can also enter numbers directly using the
number keypad on your remote.
'_' If you select Everyday or Every Week, the date you
select in the Date field becomes the start date for your
scheduled viewing. For Everyday, the TV will turn on
every day, at the time you selected, starting from that
date. For Everyweek, the TV will turn on every week,
on the same day of the week as the start date you
selected, at the time you selected, from that day on. If
you select Once, the TV will turn on once, on the date
and time you selected.
5. Press the ENTER _ button on your remote when done.
_' Only Added Channels can be scheduled.
_' Scheduled programs and channels are displayed inthe
Programmed List.
'_' When you select a digital channel, press the !_ button to
view the digital program list. Ifyou highlight a program in
the list, and then press the ENTERS(Schedule) button,
you set Timer Viewing for that program directly.
[] Channel Name Edit: Analog channels only. Lets you assign a
name of up to five characters to an analog channel. For example,
Hist, Food, Golf, etc. This makes it easier to find and select a
channel.
[] Select All: Select all the channels in the displayed channel list.
[] Deselect All: Deselect all the selected displayed channels.
'_' You can only select Deselect All when one or more
channels are selected.
[] Auto Program: See Auto Program under Memorizing Channels.
-5-
@_Programmed List (on the Channel List Screen)
The Programmed list displays the channels and programs you
have scheduled for viewing using the Time Viewing function. You
can view, modify, or delete a show you have scheduled using the
functions on the Programmed List screen Tools menu.
Programmed List Screen Tools Menu
[] Change Info: Change the scheduling informationfor a show or
channel you have scheduled.
To change the information,follow these steps:
1. Select the Programmed List icon on the left side of the
Channel List screen, and then press the ENTER_ button.
2. On the Programmed List screen, select the show or channel
entry you want to change, and then press the TOOLS button.
The Tools Menu appears.
3. Select Change Info, and then press the ENTER _ button.
The Time Viewing screen appears.
4. Use the _/!_ buttons to move from entry field to entry field
and the A/V buttons to change the entries. Where numbers
are displayed, you can also enter numbers directly using the
number keypad on your remote.
5. Press the ENTER _ button when done.
[] Cancel Schedules: Cancel a show or channel you have
scheduled.
To cancel a scheduled show or channel, follow these steps:
1. Select the Programmed List icon on the left side of the
Channel List screen, and then press the ENTER_ button.
2. On the Programmed List screen, select the show or channel
entry you want to cancel, and then press the TOOLS button.
The Tools Menu appears.
3. Select Cancel Schedules, and then press the ENTER
button. The Cancel Schedule screen appears.
4. Select OK, and then press the ENTER _ button.
[] Information: Display the informationfor a show or channel you
have scheduled. You can also change the schedule Information.
1. Select the Programmed List icon on the left side of the
Channel List screen, and then press the ENTER_ button.
2. On the Programmed List screen, select the show or channel
entry you want information for, and then press the TOOLS
button. The Tools Menu appears.
3. Select Information, and then press the ENTER _ button.
The Time Viewing Information screen appears.
4. Select Change Info and press the ENTER_ button to
change information, or select Close and press the ENTER
button to close the Information screen.
[] Select All / Deselect All: You can select or deselect all channels
in the channel list.
_3 Other Channel Menu Functions
Channel Mode (Added Channels/Favorite
Channels)
Lets you select the channel list displayed when you press the
ACHV (Channel) button on your remote. For example, if you
select Favorite Channels, you will only see Favorite channels when
you press the ACHV button.
Fine Tune
Analog channels only.
Ifthe reception isclear,you do not have to fine tune the channel,
as this isdone automatically during the search and store
operation. If the signal is weak or distorted, fine tune the channel
manually.
'_' Select the channel, and then select Fine Tune.
'_' Fine tuned channels that have been saved are marked with
an asterisk "*"on the right-hand side of the channel number
in the channel banner.
'_' To reset fine-tuning, select the channel, select Fine Tune, and
then select Reset on the Fine Tune screen.
Plug & Play
Lets you re-run the Plug & Play initial setup procedure. For
instructions, see your Quick Start Guide.
Language
Set the menu language.
'_' Choose between English, Espahol, and Francais.
_3 Setting the Time
Time
'_' The time you set will appear when you press the INFO
button.
[] Clock: Set the clock so you can use the various timer features
of the TV.
'_' If you disconnect the power cord, you have to set the
clock again.
To set the clock, follow these steps:
1. Select Setup >Time > Clock.
2. Press ENTER _ and select Auto or Manual, and then press
ENTER _ again.
if you selected Auto:
The TV will automatically download the correct time from a
digital channel.
- Select Time Zone, and then press the ENTER _ button.
Use the_,/_' buttons to select your Time Zone, and then
press ENTER _.
- Select DST (Daylight Savings Time), and then press
ENTER _. Select On ifyou want to turn the DST
adjustment on and off manually. Select Off to turn off the
DST adjustment. Select Auto ifyou want the TV to adjust
to DST automatically. Press ENTER_ when done.
_' DST and Time Zone function are only available when
the Clock Mode is set to Auto.
if you selected Manual:
The Clock Set screen appears. Use the &/T buttons to
change the values in each field or use the number buttons to
enter the values directly. Use the ,_/_ buttons to move from
field to field. When done with all the fields, press ENTER _.
'_ Available only when Clock Mode is set to Manual.
[] Sleep Timer
Automatically shuts off the TV after a preset period of time. (30,
60, 90, 120, 150 and 180 minutes).
'_' To cancel the Sleep Timer, select Off.
Timer 1 / Timer 2 / Timer 3
Turns the TV on and off automatically at times and days you
select. You can set three different on/off timer settings.
'_' You must set the clock first.
[] On Time / Off Time: Set the hour, minute, am/pm, and
ActivatdlnactNate fields for the On Time and Off Time. Use the
_/!_ buttons to move from field to field. Use the A/T buttons
to change the values in each field. To activate the timer with
the setting you have chosen, set the Activate/Inactivate field to
Activate.
[] Volume: Set the desired loudness.
[] Contents: To select what will be turned on when the timer
setting is activated. Youcan set the TV to turn on a specific
channel or play back contents such as photo or audio files.
Use the ,_/_ buttons to move to move to the Contents field,
and then press the ENTER _ button. The Contents screen
appears. Use the _/!_ buttons to move from field to field. Use
the &/_ buttons to change the values in each field.
- TV/USB: Select TV or USB. The USB device must be
connected to your TV before you can select USB.
- Antenna: Displays the current antenna source, Air or Cable.
- Channel: Ifyou have selected TV, select the desired channel.
- Music/Photo: If you have selected USB, follow these steps to
select a folder containing MP3 (Music) or JPEG (Photo) files on
the USB device:
_' The maximum displayed number of files, including sub
folders, in one folder of USB storage device is 2000.
'_' The media may not be playing smoothly when using the
device lower than USB 2.0.
1. Use the ,_/_ buttons to move to the field under Music
or the field under Photo, and then press the ENTER
button. The TV displays a single folder (the Root folder)
and the type or name of the device.
2. Press the ENTER _ button. A list of folders on the device
appears.
'_' If there are no folders on your device, press the
Yellow select button to select the Root folder, and
then press the RETURN button. The Timer screen
re-appears.
3. Use the A/T buttons to highlight a folder that contains
music or photos, and then press the Yellow select button
to select the folder.
4. Press the RETURN button. The Timer screen re-appears.
[] Repeat: Select Once, Everyday, Mon-Fri, Men-Sat,
Sat-Sun or Manual. Ifyou select Manual, you can select the
days you want to activate the timer by using the _1/!_ buttons
to highlight the day, and then pressing the ENTER _ button.
To unselect a day, highlight it, and then press the ENTER _
button.
When you finished making allyour selections on the Timer screen,
press either the ENTER _ or RETURN button.
-6-
_3 Other Features
Program Rating Lock
The Program Rating Lock feature lets you block programs
you've determined are inappropriate for your children based on
the program's ratings. To access the Program Rating Lock
feature and make any changes, you must enter a PIN (personal
identification number). Towatch a blocked program, you must also
enter the same PIN.
'_' Program Rating Lock is not available in HDMI or
Component mode.
'_' The default PIN number of a new TV set is "0-0-0-O". You can
set your own PIN using the Change PIN function.
How It Works
When you access the Program Rating Lock Menu functions for
the first time, the PIN input screen appears. Enter 0-0-0-0. The PIN
screen closes and the Program Rating Lock Menu appears. Every
time you access the Program Rating Lock functions, the PIN
screen will appear and you must enter a PIN.
When the Rating Lock screen appears, select Program Rating
Lock, and then press ENTER _. Select On, and then press the
ENTER _ key again. Depending on what type of programs or
movies you want to block, select one of the options on the screen,
and then press the ENTER _ button. The options are listed below:
[] TV Parental Guidelines: You can block TV programs based
on their ratings. This function allows you to control what your
children are watching.
[] MPAA Rating: You can block movies based on their MPAA
ratings. The Motion Picture Association of America (MPAA) has
implemented a rating system that provides parents or guardians
with advanced information on which films are appropriate for
children.
[] Canadian English: You can block TV programs based on their
Anglophone Canadian ratings.
[] Canadian French: You can block TV programs based on their
French Canadian ratings.
[] Downloadable U.S. Rating: Parental restriction information can
be used while watching DW channels.
Locking/Blocking Programs or Movies
You lock or block programs and/or movies in essentially the same
way for each option. Each option displays a grid or table. All the
tables have ratings listed on the left. The TV Parental Guidelines
option also has kinds of content listed across the top: ALL: Lock all
TV ratings. / FV: Fantasy violence / V: Violence / S: Sexual situation
/ L: Adult Language / D: Sexually Suggestive Dialog.
To IocWblock movies or shows with certain ratings and/or kinds of
content, click the square next to the rating and/or under the kind of
content. A lock appears. To unlock/unblock, click the square again.
When you click a low rating, all the ratings above it will also display
locks. You can also Allow All or Lock All. When done, press the
RETURN button on your remote.
[] Change PIN: The Change PIN screen will appear. Choose any
4 digits for your PIN and enter them in Enter New PIN fields.
Re-enter the same 4 digits in Confirm New PiN fields. When the
Change PIN screen disappears, press the OK button. The TV
has memorized your new PIN.
'_' If you forget the PIN, press the remote-control buttons in
the following sequence, which resets the pin to "0-0-0-0" :
POWER (off) _ MUTE _ 8 _ 2 _ 4 _ POWER (on)
-7-
Game Mode (On/Off)
When you connect a game console such as a PlayStation TM
or Xbox TM to your TV,you can enjoy a more realistic gaming
experience by turning on the Game Mode function.
'_' Precautions and limitations for game mode:
° Before you disconnect the game console and connect another
external device, set Game Mode to Off in the setup menu.
° Ifyou display the TV menu in Game Mode, the screen shakes
slightly.
'_' Game Mode is not available when the input source is set to
TV.
'_' After connecting the game console, set Game Mode to On.
You may notice slightly reduced picture quality.
Caption
(On-Screen Text Dialogue)
[] Caption: You can switch the caption function on or off. If
captions are not available, they will not be displayed on the
screen.
'_' The Caption feature does not work inComponent or
HDMI mode.
[] Caption Mode: Youcan select the desired caption mode.
Default / CCl -CC4 / Text1 -Text4: (analog channels only) The
Analog Caption function operates in either analog TV channel
mode or when a signal is supplied from an external device to the
TV. (Depending on the broadcasting signal, the Analog Caption
function may or may not work with digital channels.)
Default / Service1 -Service6 / CCl -CC4 / Text1 -Text4:
(Digital channels only)The Digital Captions function works with
digital channels.
'_' Service1-6 may not be available in digital caption mode
depending on the broadcast.
[] Digital Caption Options: (Digital channels only)
Size: Options include Default, Small, Standard and Large. The
default is Standard.
Font Style: Options include Default and Styles 0 to 7. The
default is Style 0.
Foreground Color: Options include Default, White, Black, Red,
Green, Blue, Yellow, Magenta and Cyan. You can change the
color of the letters. The default isWhite.
Background Color: Options include Default, White, Black, Red,
Green, Blue, Yellow, Magenta and Cyan. You can change the
background color of the captions. The default is Black.
Foreground Opacity: This adjusts the opacity of text. Options
include Default, Transparent, Translucent, Solid and Flashing.
Background Opacity: This adjusts the opacity of the caption
background. Options include Default, Transparent, Translucent,
Solid and Flashing.
Return to Default: This option sets each Size, Font Style,
Foreground Color, Background Color, Foreground Opacity and
Background Opacity to its default.
'_' Digital Caption Options are available only when you can
select Default and Service1 - Service6 in Caption Mode.
'_' The Foreground and Background cannot be set to the
same color.
Boot Logo
Enable/disable displaying the logo wt_ilethe TV starts up.
Eco Solution
[] Energy Saving (Off / Low / Medium / High / Picture Off) :
This adjust the brightness of the TV in order to reduce power
consumption. Ifyou select Picture Off, the screen isturned
off, but the sound remains on. Press any button except volume
button to turn on the screen.
[] Eco Sensor (Off / On): Toenhance your power savings; the
picture settings will automatically adapt to the light inthe room.
'_' If you adjust the Backlight, the Eco Sensor will be set to Off.
Min. Backlight: When Eco Sensor is On, the minimum screen
brightness can be adjusted manually.
'_' If Eco Sensor is On, the display brightness may change
(become slightly darker in most cases) depending on the
surrounding light intensity.
[] No Signal Power Off (Off / 15 min. / 30 min. / 60 min.): Sets
how quickly the TV switches to standby mode, if no picture is
being received.
_ Disabled when the PC isin power saving mode.
[] Auto Power Off (Off / On): The TV will be automatically turned
off when no user operation is received for 4 hours.
Auto Protection Time
[] Auto Protection Time (Off / 2 hours / 4 hours / 8 hours / 10
hours): Ifthe screen remains idlewith a still image for a certain
period of time you define, the screen saver is activated to prevent
the formation of ghost images on the screen.
_nosis
[] Picture Test: Use to check for picture problems. If the problem
appears inthe test picture, select Yes and follow the directions
on the screen.
[] Sound Test: Use the built-in melody sound to check for sound
problems. If the problem occurs during the test, select Yes and
follow the directions on the screen.
[] Signal Strength: (Digital channels only) An HD channeFs
reception quality is either perfect or the channels are unavailable.
Adjust your antenna to increasesignal strength.
[] Reset: Reset all settings to the factory defaults.
'_ The PIN input screen appears before the setup screen.
'_' Enter your 4-digit PIN. Change the PIN using the Change
PIN option.
Software Upgrade
Software Upgrade can be performed by downloading the latest
firmware from samsung.com to a USB memory device.
HD Connection Guide
Refer to this information when connecting external devices to ttqe
TV.
Contact Samsung
View this informationwhen your TV does not work properly or
when you want to upgrade the software. You can find information
regarding our call centers and how to download products and
software.
Enjoy photos, music and/or movie files saved on a r----q
USB Mass Storage Class (MS(}) device.
_3Connecting a USB Device
1. Turn on your TV.
2. Connect a USB device containing photo, music, and/or movie
files to the USB jack on the back of the TV. A pop up window
appears.
3. Press the MED_A,P button on your remote. The Media Play
menu appears.
_3Using the Media Play Menu
To open Media Play in the Menu, follow these steps:
1. Press the MENU button. Then, press ttqe _ or _ button to
select Application on the left, and ttqen press ttqe ENTER
button.
2. Press the • or • button to select Media Play (USB), and then
press the ENTER _ button.
3. Press the _ or I_ button to select an icon(Videos, Music,
Photos, Settings), and then press the ENTER _ button.
Media Play might not work properly with unlicensed
multimedia files.
_' Need-to-Know List before using Media Play (USB)
° The file system supports FAT16, FAT32 and NTFS.
° Certain types of USB Digital camera and audio devices may not
be compatible with this TV.
° Media Play only supports USB Mass Storage Class (MSC)
devices. MSC is a Mass Storage Class Bulk-Only Transport
device. Examples of MSC are Thumb drives and Flash Card
Readers. Devices should be connected directly to the TV's USB
pelt. USB HDD ia not suppolted.
° Before connecting your device to the TV, please back up your
files to prevent them from damage or loss of data. SAMSUNG is
not responsible for any data file damage or data loss.
° A USB device that requires high power (more than 0.hA) may not
be supported.
° Do not disconnect the USB device while it is loading.
° The higher the resolution of the image, the longer it takes to
display on the screen.
° The maximum supported JPEG resolution is 15360 x 8640 pixels.
° If a file is corrupted or the TV does not support the file type, the
"Not Supported File Format" message appears.
° The TV cannot play MP3 files with DRM that have been
downloaded from a for-pay site. Digital Rights Management
(DRM) is a technology that supports the creation, distribution,
and management of digital content in an integrated and
comprehensive way, including protecting the rights and interests
of content providers, preventing illegal copying of contents, and
managing billing and settlements.
-8-
[UH4005-ZA]BN68-05829L_00EN(}.indb 1 2014-06-25 _]_3:15:44
Loading ...
