Figuresandillustrationsinthis UserManualareprovidedforreference Transportation to and from the Service Center is the responsibility of
onlyandmaydifferfromactualproductappearance.Productdesignand tile purchaser. Conditions covered are limited only to manufacturing
spedficationsmaybe changedwithoutnotice, defects in material or workmanship, and only those encountered
Important Warranty Information Regarding
Television Format Viewing
'_ See tile warranty card for more information oil warranty
terms.
Wide screen format LED Displays (16:9, the aspect ratio of the
screen width to height) are primarily designed to vies! wide screen
format full-motion video. The images displayed on them should
primarily be in the wide screen 16:9 ratio format, or expanded to
fill the screen ifyour model offers this feature and the images are
constantly moving. Displaying stationary graphics and images on
screen, such as the dark sidebars on non- expanded standard
format television video and programming, should be limited to no
more than 5% of the total television viewing per week. Additionally,
viewing other stationary images and text such as stock market
reports, video game displays, station Iogos, web sites or computer
graphics and patterns, should be limited as described above for
alltelevisions. Displaying stationary images that exceed the above
guidelines can cause uneven aging of LED Displays that leave
subtle, but permanent burned-in ghost images in the LED picture.
To avoid this, vary the programming and images, and primarily
display full screen moving images, not stationary patterns or dark
bars. On LED models that offer picture sizing features, use these
controls to vies! different formats as a full screen picture. Be careful
in the selection and duration of television formats you use for
viewing. Uneven LED aging as a result of format selection and use,
as well as burned-in images, are not covered by your Samsung
limited warranty.
- SAMSUNG ELECTRONICS NORTH AMERICAN LIMITED
WARRANTY STATEMENT
Subject to the requirements, conditions, exclusions and limitations
of the original Limited Warranty supplied with Samsung Electronics
(SAMSUNG) products, and the requirements, conditions, exclusions
and limitations contained herein, SAMSUNG will additionally
provide Warranty Repair Service in the United States on SAMSUNG
products purchased in Canada, and in Canada on SAMSUNG
products purchased in the United States, for the warranty period
originally specified, and to the Original Purchaser only.
The above described warranty repairs must be performed by a
SAMSUNG Authorized Service Center. Along with this Statement,
the Original Limited Warranty Statement and a dated Bill of Sale
as Proof of Purchase must be presented to the Service Center.
in normal use of the product. Excluded, but not limited to, are
any originally specified provisions for, in-home or on-site services
minimum or maximum repair times, exchanges or replacements,
accessories, options, upgrades, or consumables.
For the location of a SAMSUNG Authorized Service Center, please
call toll-free:
-- In the United States : 1-800-SAMSUNG (1-800-726-7864)
-- In Canada : 1-800-SAMSUNG
Still image warning
Avoid displaying still images (such as jpeg picture flies) or still
image elements (such as TV channel Iogos, TV shows or movies
in panorama or 4:3 format, stock or news scroll bars, etc.) on the
screen. The constant display of still pictures can cause ghosting or
image bum-in (image retention) on the LED screen, which will affect
image quality. To reduce the risk of this effect, please follow the
recommendations below:
- Avoid displaying the same TV channel for long periods.
- Always try to display any image in full screen mode. Use the TV's
Picture Options menu to select the optimal screen size.
- Reduce brightness and contrast values to the minimum required
to achieve the desired picture quality. Values that exceed the
minimum may speed up the bum-in process.
- Frequently use allTV features designed to reduce image retention
and screen bum-in. Refer to proper user manual section for
details.
w-.-. ....... . ......... =--.--= ..... ----.= ..... i
€ontact SAMSUNG WORLDWIDE i
If you have any questions or comments relating to Samsung products, II
please contact the SAMSUNG customer care center, iI
Samsung Electlonics
Canada Inc., Customer
Service 55 Standish Cour[
Mississauga, Ontario LSR
Samsung Electronics
America, Inc
85 Challenger Road
Ridgefleld Park, NJ
1 800 SAMSUNG(726 7864)
www samsung.com/ca
(English)
www samsung.com/ca tr
(F/ench)
www,samsung.com/us
IIIIIIIIIIIIIIIIIIIIIIIIIII
BN68 04499A 02
(4:)2012 Samsung Electronics Co., Ltd. All rigMs reserved.
To add channels to the Added Channels list, follow these steps:
1. Select one or more channels in the All Channels list using the
A/T buttons and the Yellow Select button on your remote.
2. Press the TOOLS button on your remote. The Tools menu
appears.
3. Select Add in the Tools menu, and then press the ENTER
button.
'_' All deleted channels will be shown on the All Channels list.
You add channels back to the Added Channels list on the
All Channels list.
'_' A gray-colored channel indicates the channel has been
deleted from the Added Channels list.
'_' The Add menu option only appears for deleted channels.
[] Add to Favorite/Delete from Favorite: Lets you add channels
to and delete channels from your Favorites list.
To add channels to the Favorites list, follow these steps:
'_' Ifyou select Everyday or Every Week, the date you
select in the Date field becomes the start date for your
scheduled viewing. For Everyday, the TV will turn on
every day, at the time you selected, starting from that
date. For Everyweek, the TV will turn on every week,
on the same day of the week as the start date you
selected, at the time you selected, from that day on. If
you select Once, the TV will turn on once, on the date
and time you selected.
5. Press the ENTER _ button on your remote when done.
_' Only Added Channels can be scheduled.
_' Scheduled programs and channels are displayed in the
Programmed List.
'_' When you select a digital channel, press the _. button to
view the digital program list. If you highlight a program in
the list, and then press the ENTERS(Schedule) button,
you set Timer Viewing for that program directly.
1. Select one or more ctqannels in the All Channels list using the [] Select All: Select all the ctqannels in the displayed ctqannel list.
A/T buttons and the Yellow Select button on your remote.
2. Press the TOOLS button on your remote. The Tools menu
appears.
3. Select Add to Favorite in the Tools menu, and then press the
ENTER _ button.
To delete channels from the Favorites list, follow these steps:
1. Select one or more channels in the Favorite Channels list
using the A/_" buttons and the Yellow Select button on your
remote.
2. Press the TOOLS button on your remote. The Tools menu
appears.
3. Select Delete from Favorite in the Tools menu, and then
press the ENTER _ button.
[] Timer Viewing: You can schedule a channel to be displayed
automatically at a set time, even when you are watching another
channel. You must set the current time first in the Time > Clock
function to use Time Viewing.
To schedule a channel, follow these steps:
1. Select a channel in the Added Channels list using the A/T
buttons and the Yellow Select button on your remote.
2. Press the TOOLS button on your remote. The Tools menu
appears.
3. Select Time Viewing in the Tools menu, and then press the
ENTER_ button. The Time Viewing screen appears.
4. Use the _/_- buttons to move from entry field to entry field
and the A/_' buttons to change the entries. Where numbers
are displayed, you can also enter numbers directly using the
number keypad on your remote.
[] Deselect All: Deselect allthe selected displayed channels.
'_' You can only select Deseleet All when one or more
channels are selected.
[] Channel Name Edit: Analog channels only. Lets you assign a
name of up to five characters to an analog channel. For example,
Hist, Food, Golf, etc. This makes iteasier to find and select a
channel.
[] Auto Program: See Auto Program under Memorizing Channels.
Programmed List (on the Channel List Screen)
The Programmed list displays the channels and programs you
have scheduled for viewing using the Time Viewing function. You
can view, modify, or delete a show you have scheduled using the
functions on the Programmed List screen Tools menu.
Programmed List Screen Tools Menu
[] Change Info: Change the scheduling information for a show or
channel you have scheduled.
Tochange the information, follow these steps:
1. Select the Programmed List icon on the left side of the
Channel List screen, and then press the ENTER _ button.
2. On the Programmed List screen, select the show or channel
entry you want to change, and then press the TOOLS button.
The Tools Menu appears.
3. Select Change Info, and then press the ENTER_ button.
The Time Viewing screen appears.
4. Use the _1i/_-buttons to move from entry field to entry field
and the A/_' buttons to change the entries. Where numbers
are displayed, you can also enter numbers directly using the
number keypad on your remote.
5. Press the ENTER _ button when done.
[] Cancel Schedules: Cancel a show or channel you have
scheduled.
Tocancel a scheduled show or channel, follow these steps:
1. Select the Programmed List icon on the left side of the
Channel List screen, and then press the ENTER _ button.
2. On the Programmed List screen, select the show or channel
entry you want to cancel, and then press the TOOLS button.
The Tools Menu appears.
3. Select Cancel Schedules, and then press the ENTER_
button. The Cancel Schedule screen appears.
4. Select OK, and then press the ENTER _ button.
_5_
Your TV has two kinds of menus, the Main menu and the various
Tools menus. The Main menu gives you access to most or all of
the menu options available on your T_ The Tools menus display
a selected number of frequently used menu options that change
depending on the screen you are viewing. A Tools menu symbol
(_']) in the lower right side of the screen indicates that a Tools menu
is available.
The Main menu has seven primary categories:
" Picture " Input
" Sound " Application
" Channel - Support
- Setup
To vies! the Main menu, press the MENU button on your remote. To
view a Tools menu, press the TOOLS button on your remote.
'_' The menu options that appear in the Main menu depend
on the Source you have selected. For example, ifyou have
selected the HDMI source, the Channel category will not
appear. To see the Channel category, you must first select TV
in the Source List.
The Menu options are presented below, arranged by Main menu
categories. A Tools button symbol (EI_I_I) next to an option
name indicates the option is also available in one of the Tools
menus.
Mode
Select your preferred picture mode.
'_' When your TV is connected to a PC, you can only select
Entertain and Standard.
[] Dynamic: Brightens the screen. Suitable for a bright room.
[] Standard: Suitable for a normal.
[] Movie: Darkens the screen, making it less glary. Suitable for
watching movies in a darkened room.
[] Entertain: Sharpens the picture. Suitable for games.
_ Only available when the TV is connected to a PC.
Backlight / Contrast / Brightness / Sharpness /
Color / Tint (G/R)
[] Backlight: Adjusts the brightness of the screen by adjusting the
brightness of the individual pixels.
[] Contrast: Increases or decreases the contrast between dark and
light areas of the picture.
[] Brightness: Adjusts the brightness of the screen. Not as
effective as Backlight.
[] Sharpness: Sharpens or dulls the edges of objects.
[] Color: Adiusts the color saturation, The higher the Color setting,
the more intense the color. Los! settings remove color and the
picture becomes black, white and gray.
[] Tint: Adjusts the amount of green and red in the picture. As you
increase the amount of green, the amount of red decreases and
vice versa.
'_' When the TV is connected to a PC, you can only make
changes to Backlight, Contrast, Brightness, and
Sharpness.
_2_
[] Information: Display the information for a show or channel you
have scheduled. You can also change the schedule Information.
1. Select the Programmed List icon on the Idt side of the
Channel List screen, and then press the ENTER _ button.
2. On the Programmed List screen, select the show or channel
entry you want information for, and then press the TOOLS
button. The Tools Menu appears.
3. Select Information, and then press the ENTER_ button.
The Time Viewing Information screen appears.
4. Select Change Info and press the ENTER _ button
to change information, or select Close and press the
ENTER _ button to close the Information screen.
[] Select All / Deselect All: You can select or deselect all
channels in the channel list.
_3Other Channel Menu Functions
Channel Mode (Added Channels/Favorite
Channels)
Lets you select the channel list displayed when you press the
ACHV (Channel) button on your remote. For example, ifyou
select Favorite Channels, you will only see Favorite channels when
you press the ACHV button.
Fine Tune
Analog channels only.
If the reception is clear, you do not have to fine tune the channel,
as this is done automatically during the search and store
operation. Ifthe signal isweak or distorted, fine tune the channel
manually.
'_' Select the channel, and then select Fine Tune.
'_' Fine tuned channels that have been saved are marked with
an asterisk "*" on the right-hand side of the channel number
in the channel banner.
'_' To reset fine-tuning, select the channel, select Fine Tune, and
then select Reset on the Fine Tune screen.
Plug & Play
Lets you re-run the Plug & Play initial setup procedure. For
instructions, see your Quick Start Guide.
Language
Set the menu language.
_' Choose between English, Espa6ol, and Francais.
_3Setting the Time
Time
'_' The time you set will appear when you press the INFO
button.
[] Clock: Set the clock so you can use the various timer features
of the T_
'_' If you disconnect the power cord, you have to set the
clock again.
_6_
Advanced Settings
Available in Standard and Movie mode only.
Compared to previous models, new Samsung TVs offer a more
precise picture with more precise controls.
'_' When your TV is connected to a PC, you can only make
changes to Gamma and White Balance.
[] Color Space (Auto / Native): Auto automatically matches the
range of colors available to create pictures to the color range of
the video source. Native provides a color range wider than the
color range of the video source.
[] White Balance: Adjusts the color temperature of the picture so
that white objects look white (instead of, for example, slightly
pink or slightly yellow) and the overall color of the picture looks
natural.
R-Offset / G-Offset / B-Offset: Adjusts each color's (red,
green, blue) darkness.
R-Gain / G-Gain / B-Gain: Adjusts each color's (red, green,
blue) brightness.
Reset: Resets the White Balance to it's default settings.
[] Gamma: Adjusts the primary color intensity.
[] Dynamic Contrast (Off / Low / Medium / High): Adjusts the
screen contrast.
[] Black Tone (Off / Dark / Darker / Darkest): Selects the black
level to adjust the screen depth. Darker settings make blacks
look darker.
[] Flesh Tone: Adjusts the amount of red in skin tones.
[] Motion Lighting (Off / On): When on, the TV automatically
adjusts the brightness of the screen in response to the
brightness of the room. Inbright light, the screen brightens. In
dim light, the screen dims.
_' Available in Standard mode only.
Picture Options
'_' When the TV isconnected to a PC, you can only make
changes to the Color Tone, Size and HDMI Black Level.
[] Color Tone (Cool / Standard / Warm1 / Warm2): Cool makes
the picture bluer (cooler). Warm 1 and Warm 2 make the picture
redder (warmer).
'_' Warm1 and Warm2 are deactivated when the picture
mode is set to Dynamic.
[] Size: Set the size and aspect ratio of the picture on the screen.
Your cable box or satellite receiver may have its own set of
screen sizes as well. However, we highly recommend you use
the TVs 16:9 mode most of the time.
16:9: Sets the picture to the 16:9 wide screen format.
Zoom1 : Provides moderate magnification of the picture. Sides,
top, and bottom are cut off.
Zoom2: Provides larger magnification of the picture. Sides, top,
and bottom are cut off.
Wide Fit: Enlarges the aspect ratio of the picture so the picture
fits the entire screen.
4:3: Sets the picture to the old, 4:3 format and puts black or gray
borders on the right and left of the picture.
'_' Do not watch your TV in the 4:3 format for a long time.
Traces of borders displayed on the left, right and center of
the screen may cause image retention (screen burn) which
is not covered by the warranty.
Screen Fit: Displays the full image without any cut-off when
your TV is inputting HDMI (720p / 1080i / 1080p) or Component
(1080i/1080p) HD signals.
_' HD (High Definition) has a 16:9 aspect ratio and 1080i/1080p
(1920x1080) or 720p (1280x720) resolution.
_' You can adjust and store settings for each external device you
have connected to an input on the TV. Picture Sizes available
by Input Source are listed below:
To set the clock, follow these steps:
1. Select Setup >Time > Clock.
2. Press ENTER_ and select Auto or Manual, and then press
ENTER _ again.
If you selected Auto:
The TV will automatically download the correct time from a
digital channel.
- Select Time Zone, and then press the ENTER _ button.
Use theA/_" buttons to select your Time Zone, and then
press ENTER _.
- Select DST (Daylight Savings Time), and then press
ENTER _. Select On ifyou want to turn the DST
adjustment on and off manually. Select Off to turn off the
DST adjustment. Select Auto ifyou want the TV to adjust
to DST automatically. Press ENTER_ when done.
_' DST and Time Zone function are only available when
the Clock Mode is set to Auto.
If you selected Manual:
The Clock Set screen appears. Use the A/_" buttons to
change the values in each field or use the number buttons to
enter the values directly. Use the _/_- buttons to move from
field to field. When done with allthe fields, press ENTER _.
'_' Available only when Clock Mode is set to Manual.
[] Sleep Timer
Automatically shuts off the TV after a preset period of time. (30,
60, 90, 120, 150 and 180 minutes).
'_' To cancel the Sleep Timer, select Off.
Timer 1 / Timer 2 / Timer 3
Turns the TV on and off automatically at times and days you
select. You can set three different on/off timer settings.
'_' You must set the clock first.
[] On Time / Off Time: Set the hour, minute, am/pm, and
Activate/Inactivate fields for the On Time and Off Time. Use the
_1i/_ buttons to move from field to field. Use the A/_" buttons
to change the values in each field. Toactivate the timer with
the setting you have chosen, set the Activate/Inactivate field to
Activate.
[] Volume: Set the desired loudness.
[] Contents: Toselect what will be turned on when the timer
setting is activated. You can set the TV to turn on a specific
channel or play back contents such as photo or audio files.
Use the _1i/_-buttons to move to move to the Contents field,
and then press the ENTER _ button. The Contents screen
appears. Use the _1i/_ buttons to move from field to field. Use
the _/_r buttons to change the values in each field.
- TV/USB: Select "IV or USB. The USB device must be
connected to your TV before you can select USB.
- Antenna: Displays the current antenna source, Air or Cable.
- Channel: Ifyou have selected TV, select the desired channel.
- Music/Photo: Ifyou have selected USB, folios! these steps to
select a folder containing MP3 (Music) or JPEG (Photo) files on
the USB device:
_' The maximum displayed number of files, including sub
folders, in one folder of USB storage device is 2000.
'_' The media may not be playing smoothly when using the
device lower than USB 2.0.
1. Use the _/_. buttons to move to the field under Music
or the field under Photo, and then press the ENTER
button. The TV displays a single folder (the Root folder)
and the type or name of the device.
A VAVComponent/ 0, 1'
DTV(1080i, 1080p), Component (1080i, 1080p), 16:9, Wide Fit,
HDMI (720p, 1080i, 1080p) 4:3, Screen F t
[] Digital Noise Filter (Off / Low / Medium / High / Auto) : Ifthe
broadcast signal received by your TV is weak, you can activate
the Digital Noise Filter feature to reduce any static and ghosting
that may appear on the screen.
'_' When the signal isweak, try all the Digital Noise Filter
options until the TV displays the best picture.
[] HDMI Black Level (Normal / Low) : For HDMI signals, select
the black level to adjust the screen depth. Los! make blacks look
darker.
_' Available only in HDMI mode (RGB signals).
[] Film Mode (Off / Auto) : Sets the TV to automatically sense and
process film signals from all sources and adjusts the picture for
optimum quality.
_' Available in ATV, DTV (interlace), AV, COMPONENT (480i /
1080i) and HDMI (480i/1080i).
[] LED Motion Plus (Off/On): Removes drag from fast scenes
with a lot of movement to provide a clear picture.
Picture Reset
[] Picture Reset (Reset Picture Mode/Cancel): Resets tile
picture settings to their factory defaults.
Mode
[] Standard: Selects the normal sound mode.
[] Music: Emphasizes music over voices.
[] Movie: Provides the best sound for movies.
[] Clear Voice: Emphasizes voices over other sounds.
[] Amplify: Increase the intensity of high-frequency sounds to allow
a better listening experience for the hearing impaired.
Equalizer
Available inStandard sound mode only.
[] Balance L/R: Adjusts the balance between the right and left
speaker.
[] 100Hz / 300Hz / 1KHz / 3KHz / 10KHz (Bandwidth
Adjustment): Adjusts the loudness of specific bandwidth
frequencies.
[] Reset: Resets the equalizer to itsdefault settings.
SRS TruSurround HD (On/Off)
Available inStandard sound mode only.
SRS TruSurround HD is a patented SRS technology that solves
the problem of playing 5.1 multichannel content through two
speakers. TruSurround delivers a compelling, virtual surround
sound experience through any two-speaker playback system,
including internal television speakers. It isfully compatible with all
multichannel formats.
Preferred Language
Digital channels only.
DigitaI-TV broadcasts can transmit many audio tracks
simultaneously (for example, simultaneous translations of a program
into foreign languages).
'_' You can only select a language from among the ones being
broadcast.
_3_
Multi-Track Sound (MTS)
Analog channels only.
[] Mono: Select for ctqannels that are broadcasting in mono or if
you are having difficulty receiving a stereo signal.
[] Stereo: Select for ctqannels that are broadcasting in stereo.
[] SAP: Select to listen to the Separate Audio Program, wtqich is
usually a foreign-language translation.
'_' Depending on the program being broadcast, you can listen to
Mono, Stereo or SAP.
Auto Volume
Because each station has its own broadcasting conditions, the
volume may fluctuate each time you change the channel. This
feature automatically adjusts the volume of a channel by lowering
the sound output when the modulation signal is high or by raising
the sound output when the modulation signal is low.
SPDIF Output
The SPDIF (Sony Philips Digital InterFace) outputs an
uncompressed digital audio signal when you connect the digital
audio jack on the back of the TV to a digital audio in jack on a
receiver or home theater.
[] Audio Format (POM/Dolby Digital): You can select the Digital
Audio output (SPDIF)format. The available Digital Audio output
format may differ depending on the input source.
_. By connecting the TV to a receiver or home theater with
Dolby Digital and 5.1ch speakers and selecting Dolby
Digital, you can maximize your interactive 3D sound
experience.
[] Audio Delay: Lets you correct timing mismatches between the
audio track and the video when you are watching the TV and
listening to digital audio output from the TV through an external
device such as an AV receiver. When you select Audio Delay, a
slider appears. Use the left and right arrow buttons to adjust the
slider. Press ENTER _ when done (0ms _ 250ms).
Speaker Settings
[] Speaker Select (External Speaker / TV Speaker)
If you are listening to the sound track of a broadcast or movie
through an external receiver, you may hear a sound echo caused
by the difference in decoding speed between the -[V's speakers
and the speakers attached to your audio receiver. If this occurs,
set the TV to External Speaker.
'_' When you set Speaker Select to External Speaker, the
TV's speakers are turned off. You will hear sound through
the external speakers only. When you set Speaker Select
to TV Speaker both the TV's speakers and the external
speakers are on. You will hear sound through both.
'_' When Speaker Select is set to External Speaker, the
VOLUME and MUTE buttons will not operate and the
sound settings will be limited.
'_' If there is no video signal, both the TV's speakers and the
external speakers will be mute.
Sound Reset
[] Reset All: Resets all sound settings to the factory defaults.
2. Press the ENTER_ button. A list of folders on the device
appears.
'_' If there are no folders on your device, press the
Yellow select button to select the Root folder, and
then press the RETURN button. The Timer screen
re-appears.
3. Use the &/T buttons to highlight a folder that contains
music or photos, and then press the Yellow select button
to select the folder.
4. Press the RETURN button. The Timer screen re-appears.
[] Repeat: Select Once, Everyday, Mon~Fri, Mort~Sat, Sat-Sun
or Manual. Ifyou select Manual, you can select the days you
want to activate the timer by using the _1i/_-buttons to highlight
the day, and then pressing the ENTER _ button. To unselect a
day, highlight it, and then press the ENTER_ button.
When you finished making allyour selections on the Timer screen,
press either the ENTER _ or RETURN button.
_3Other Features
Program Rating Lock
The Program Rating Lock feature lets you block programs
you've determined are inappropriatefor your children based on
the program's ratings. To access the Program Rating Lock
feature and make any changes, you must enter a PIN (personal
identification number). To watch a blocked program, you must also
enter the same PIN.
'_' Program Rating Lock is not available in HDMI or
Component mode.
'_' The default PIN number of a new TV set is "0-0-0-0". You can
set your own PIN using the Change PIN function.
How It Works
Wtqen you access ttqeProgram Rating Lock Menu functions for
the first time, the PIN input screen appears. Enter 0-0-0-0. The PIN
Locking/Blocking Programs or Movies
You lock or block programs and/or movies in essentially the same
way for each option. Each option displays a grid or table. All the
tables have ratings listed on the left. The TV Parental Guidelines
option also has kinds of content listed across the top: ALL: Lock all
TV ratings. / FV: Fantasy violence / V: Violence / S: Sexual situation
/ L: Adult Language / D: Sexually Suggestive Dialog.
ToIocWblock movies or shows with certain ratings and/or kinds of
content, click the square next to the rating and/or under the kind of
content. A lock appears. TounlocWunblock, click the square again.
When you click a low rating, allthe ratings above itwill also display
locks. You can also Allow All or Lock All. When done, press the
RETURN button on your remote.
[] Change PIN: The Change PIN screen will appear. Choose any
4 digits for your PIN and enter them in Enter New PIN fields.
Re-enter the same 4 digits in Confirm New PIN fields. When the
Change PIN screen disappears, press the OK button. The TV
has memorized your new PIN.
'_' If you forget the PIN, press the remote-control buttons in
the following sequence, which resets the pin to "0-0-0-0" :
POWER (off) _ MUTE _ 8 _ 2 _ 4 _ POWER (on)
Game Mode (On/Off)
When you connect a game console such as a PlayStation TM
or Xbox TM to your T_, you can enjoy a more realistic gaming
experience by turning on the Game Mode function.
'_' Precautions and limitations for game mode:
* Before you disconnect the game console and connect another
external device, set Game Mode to Off in the setup menu.
* Ifyou display the TV menu in Game Mode, the screen shakes
slightly.
'_' Game Mode is not available when the input source is set to
TV.
'_' After connecting the game console, set Game Mode to On.
You may notice slightly reduced picture quality.
screen closes and ttqeProgram Rating Lock Menu appears. Every Caption
time you access the Program Rating Lock functions, the PIN
screen will appear and you must enter a PIN.
When the Rating Lock screen appears, select Program Rating
Lock, and then press ENTER _. Select On, and then press the
ENTER _ key again. Depending on what type of programs or
movies you want to block, select one of the options on the screen,
and then press the ENTER _ button. The options are listed below:
[] TV Parental Guidelines: You can block TV programs based
on their ratings. This function allows you to control what your
children are watching.
[] MPAA Rating: You can block movies based on their MPAA
ratings. The Motion Picture Association of America (MPAA)has
implemented a rating system that provides parents or guardians
with advanced information on which films are appropriate for
children.
[] Canadian English: You can block TV programs based on their
Anglophone Canadian ratings.
[] Canadian French: You can block TV programs based on their
French Canadian ratings.
[] Downloadable U.S. Rating: Parental restriction information can
be used while watching DTV channels.
(On-Screen Text Dialogue)
[] Caption: You can switch the caption function on or off. If
captions are not available, they will not be displayed on the
screen.
'_' The Caption feature does not work in Component or
HDMI mode.
[] Caption Mode: You can select the desired caption mode.
Default / OO1~004 / Text1 ~Text4: (analog channels only) The
Analog Caption function operates in either analog TV channel
mode or when a signal is supplied from an external device to the
TV. (Depending on the broadcasting signal, the Analog Caption
function may or may not work with digital channels.)
Default / Service1 ~Service6 / OO1~004 / Text1 ~Text4:
(Digital channels only) The Digital Captions function works with
digital channels.
'_' Service1~6 may not be available in digital caption mode
depending on the broadcast.
[] Digital Caption Options: (Digital channels only)
Size: Options include Default, Small, Standard and Large. The
default is Standard.
Font Style: Options include Default and Styles 0 to 7. The
default is Style 0.
Foreground Color: Options include Default, White, Black, Red,
Green, Blue, Yellow, Magenta and Cyan. You can change the
color of the letters. The default is White.
_7_
_3 Memorizing Channels
When you first set up your TV using Plug & Play, the TV memorized
the channels that were available over the air or through your cable
system and added them to the Channel List. The Antenna and
Auto program functions described below let you re-run the channel
memorization function without having to re-run the Plug & Play
procedure.
Antenna (Air/ Cable)
Before your television can memorize the available channels, you
must select your TV's signal source, Air (using an antenna) or Cable.
Select Menu >Channel > Antenna > Air or Cable. After you have
selected the signal source, go on to the Auto Program function.
'_' Selecting the signal source using the Antenna function also
determines the signal source the TV is tuned to. For example,
ifyou receive your TV signal over the air, and you select Cable,
you will see only snow. You must select Air to see a picture.
Auto Program
The Auto Program function memorizes allchannels that are
available over the air or through your cable system and adds them to
the Channel List.
Tostart Auto Program, follow these steps:
1. Push MENUiTrl _ Channel _ Auto Program _ ENTER_ on
your remote. The Antenna Source screen appears.
2. On the Antenna Source screen, select ttqesource of your TV
signal.
Air
If your TV is connected to an antenna ctqooseAir, and then press
ENTER _. The TV will automatically start memorizing ctqannels.
Cable
If your TV is connected to a cable outlet, choose Cable, and then
press ENTER _. Go to Step 3.
Auto
If you choose Auto, and then press ENTER _, the TV will
automatically select the correct Antenna source. Go to
Step 3,
3. On the Cable Type screen, use the _Ii/_-/A/T buttons to select
the type of digital and analog cable systems you have: STD, HRC,
or IRC. Most systems are STD (Standard). When done, select
Start, and then press ENTER _. The TV will start memorizing
channels.
'_' Channel memorization can take up to 45 minutes, depending
on your cable system.
'_' Memorized channels are added to the Added Channels
list. These are the channels you will see when you use the
Channel buttons on your remote.
Clear Scrambled Channel
This function filters out scrambled channels after Auto Program is
completed. This process may take up to 20_30 minutes.
'_' Press the ENTER_ button to stop the Clear Scrambled
Channel.
'_' This function is only available in Cable mode.
Background Color: Options include Default, White, Black, Red,
Green, Blue, Yellow, Magenta and Cyan. You can change the
background color of the captions. The default is Black.
Foreground Opacity: This adjusts the opacity of text. Options
include Default, Transparent, Translucent, Solid and Flashing.
Background Opacity: This adjusts the opacity of the caption
background. Options include Default, Transparent, Translucent,
Solid and Flashing.
Return to Default: This option sets each Size, Font Style,
Foreground Color, Background Color, Foreground Opacity and
Background Opacity to its default.
'_' Digital Caption Options are available only when you can
select Default and Service1 ~ Service6 in Caption Mode.
'_' The Foreground and Background cannot be set to the
same color.
Melody
Set so that a melody plays when the TV is turned on or off.
'_' The Melody does not play:
° When no sound isoutput from the TV because the MUTE
button has been pressed.
° When no sound isoutput from the TV because the volume has
been reduced to minimum with the VOL .- button.
° When the TV is turned off by Sleep Timer function.
Auto Protection Time
[] Auto Protection Time (Off / 2 hours / 4 hours / 8 hours / 10
hours): If the screen remains idle with a still image for a certain
period of time you define, the screen saver is activated to prevent
the formation of ghost images on the screen.
Eco Solution
[] Energy Saving (Off / Low / Medium / High / Picture Off) :
This adjust the brightness of the TV in order to reduce power
consumption. If you select Picture Off, the screen is turned
off, but the sound remains on. Press any button except volume
button to turn on the screen.
[] Eco Sensor (Off / On)To enhance your
power savings; the picture settings will automatically adapt to the
light in the room.
'_' If you adjust the Backlight, the Eco Sensor will be set to
Off.
Min. Backlight: When Eco Sensor is On, the minimum screen
brightness can be adjusted manually.
'_' If Eco Sensor is On, the display brightness may change
(become slightly darker in most cases) depending on the
surrounding light intensity.
[] No Signal Power Off (Off / 15 rain. / 30 min. / 60 min.): Sets
how quickly the TV switches to standby mode, if no picture is
being received.
'_' Disabled when the PC is in power saving mode.
[] Auto Power Off (Off / On): The TV will be automatically turned
off when no user operation is received for 4 hours.
_4_
_3Managing Channels
Channel List
See your list of Added channels, Favorite channels, or channels
you've scheduled for viewing. Add or delete Favorite channels, add
or delete channels from the Added Channels list, schedule channels
or programs for viewing. Watch a channel by selecting the channel
in the All Channels, Added Channels, or Favorite screen, pressing
the A / T buttons, and then pressing the ENTER_ button.
Channel List Screens icons are listed on the left side. Select an
icon using the _/T buttons to view each list.
[] _ All Channels: Shows all currently available channels including
those you deleted from the Added Channels
list.
[] _ Added Channels: Shows all Added Channels. These are the
channels that appear when you press the CH button.
[] _ Favorite: Shows allfavorite channels.
[] _ Programmed: Shows all channels and programs currently
scheduled using Timer Viewing.
'_' Remote control buttons active on the Channel List screen.
° Green (Zoom): Enlarges or shrinks a channel number.
° Yellow (Select): Move the cursor to a channel. Press the Yellow
button to select the channel. A -,/ mark appears. Repeat to select
additional channels. Then, open the Tools menu and apply a
function to the channels you selected.
o r] (Tools): Displays the Channel List Tools menu. (The Tools
menus may differ depending on the situation.)
Display Icons Used in the Channel List Screens
_3The Channe_ List Tools Menu
The Channel List [bols menu contains most of the functioRS you
can use on the All Channel, Added Channels, and Favorite List
screens. '[b view, select a list screen, select a channel, and then
press the TOOLS button.
[] Add / Delete: Delete a channel from or add a channel to the
Added Channels list.
To delete channels from ttqeAdded Channels list, follow these steps:
1. Select one or more channels in the Added Channels list using
ttqe _/_' buttons and the Yellow Select button on your remote.
2. Press the TOOLS button on your remote. The Tools menu
appears.
3. Select Delete in the Tools menu, and ttqen press ttqe ENTER
button.
Self Diagnosis
[] Picture Test: Use to check for picture problems. Ifthe problem
appears in the test picture, select Yes and follow the directions
on the screen.
[] Sound Test: Use the built-in melody sound to check for sound
problems. If the problem occurs during the test, select Yes and
follow the directions on the screen.
[] Signal Strength: (Digital channels only)An HD channel's
reception quality iseither perfect or the channels are unavailable.
Adjust your antenna to increase signal strength.
[] Reset: Reset allsettings to the factory defaults.
'_ The PIN input screen appears before the setup screen.
'_' Enter your 4-digit PIN. Change the PIN using the Change
PIN option.
Software Upgrade
Software Upgrade can be performed by downloading the latest
firmware from samsung.com to a USB memory device.
HD Connection Guide
Refer to this informationwhen connecting external devices to the
TV.
Contact Samsung
Vies! this informationwhen your TV does not work properly or
when you want to upgrade the software. You can find information
regarding our call centers and how to download products and
software.
Enjoy ptqotos, music and/or movie files saved on a
USB Mass Storage Class (MSC) device.
_3Connecting a USB Device
1. Turn on your TV.
2. Connect a USB device containing photo, music, and/or movie
files to the USB jack on the back of the TV.A pop up window
appears.
3. Press the MED_A.P button on your remote. The Media Play
menu appears.
_3Using the Media Play Menu
To open Media Play in the Menu, follow these steps:
1. Press the MENU button. Then, press the A or _' button to
select Application on the left, and then press the ENTER
button.
2. Press the A or T button to select Media Play (USB), and then
press the ENTER _ button.
3. Press the _ or _- button to select an icon (Videos, Music,
Photos, Settings), and then press the ENTER _ button.
=_ Media Play might not work properly witt_ unlicensed
multimedia files.
'_' Need-to-Know List before using Media Play (USB)
° The filesystem supports FAT16,FAT32and NTFS.
° Certain types of USB Digital camera and audio devices may not
be compatible with this TV.
° Media Play only supports USB Mass Storage Class (MSC)
devices. MSC isa Mass Storage Class Bulk-Only Transport
device. Examples of MSC are Thumb drives and Flash Card
Readers. Devices should be connected directly to the TV's USB
port. USB HDDis not supported.
Loading ...
