CM172020MUK Rev2
* Register online for your 2 year guarantee. See back of this instruction book for details (UK and Ireland customers only).
Esp
resso Coffee M
ac
h
in
e
Please read and keep these instructions for future use
www.facebook.com/morphyrichardsuk
@loveyourmorphy
www.morphyrichards.co.uk/blog
For competitions, product hints and tips
and more join us at
CM172020MUK Rev2.qxp_Layout 1 02/12/2020 13:49 Page 1
2
Health and Safety
Location
• Always locate your appliance away from the edge of the
worktop.
• Ensure that the appliance is used on a firm, flat surface.
• Do not use the appliance outdoors or near water.
• WARNING: Do not place the appliance onto a metal tray
or metal surface whilst in use.
Mains cable
• Do not let the mains cable hang over the edge of the
worktop where a child could reach it.
• Do not let the mains cable run across an open space e.g.
between a low socket and a table.
• Do not let the mains cable run across a cooker or other
hot area which might damage the cable.
• The mains cable should reach from the socket to the
base unit without straining the connections.
Personal safety
• WARNING: To protect against fire, electric shock and
personal injury do not immerse cord, plug and appliance
in water or any other liquid.
• Unplug from the outlet before cleaning.
• Allow to cool before putting on or taking off parts and
before cleaning.
• Do not move the Coffee Maker while switched on.
Other safety considerations
• The use of attachments or tools not recommended or
sold by Morphy Richards, may cause fire, electric shock
or injury.
• Do not use the appliance for any use other than its
intended purpose.
• Do not place the appliance on or near a hot gas or
electric burner or in a heated oven.
• WARNING: The appliance must not be immersed for
cleaning.
• CAUTION: To prevent damage to the appliance, do not
use alkaline cleaning agents when cleaning. Use a soft
cloth and detergent.
Electrical requirements
Should the fuse in the mains plug require changing, replace
it with a fuse of the same rating as originally fitted.
WARNING: This appliance must be earthed.
The use of any electrical appliance requires the following common sense safety rules.
Please read these instructions carefully before using the product.
• WARNING: This appliance incorporates a heating element
which is subject to residual heat after use.
• WARNING: Misuse of the appliance could cause personal injury.
• CAUTION: To prevent damage to the appliance, do not use alkaline
cleaning agents when cleaning, use a soft cloth and mild detergent.
• This appliance can be used by children aged from 8 years and
above if they have been given supervision or instruction
concerning the use of the appliance in a safe way and if they
understand the hazards involved. Cleaning and user maintenance
shall not be made by children unless they are older than 8 and
supervised. Keep the appliance and its cord out of the reach of
children aged less than 8 years.
• For care and cleaning, refer to page 10.
• If the mains cable is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified person in order
to avoid a hazard.
• Appliances can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved.
• Children shall not play with the appliance.
• This appliance is intended to be used in household and similar
applications such as: farm houses, by clients in hotels, motels and
other residential type environments, and bed and breakfast type
environments. It is not suitable for use in staff kitchen areas in
shops, offices and other working environments.
CM172020MUK Rev2.qxp_Layout 1 02/12/2020 13:49 Page 2
3
Health and safety .................................................................
Product Overview / Features ..............................................
Before First Use ...................................................................
Preheating (Optional) ...........................................................
Re-filling the Water Tank ......................................................
Using Your Coffee Maker .....................................................
Using The Steam Wand ........................................................
Notes On Using The Steam Wand ......................................
Usage Warning .....................................................................
Altering Dispense Amounts ................................................
Tip ..........................................................................................
Standby Mode ......................................................................
Emptying The Drip Tray ........................................................
Adding Hot Water .................................................................
Cleaning Your Espresso Coffee Machine ...........................
Descaling ..............................................................................
Making Coffee ......................................................................
Troubleshooting ...................................................................
Contact Us ............................................................................
Guarantee .............................................................................
Contents
2
4
5
6
6
7
8
9
9
9
9
9
9
9
10
10
10
11
11
12
CM172020MUK Rev2.qxp_Layout 1 02/12/2020 13:49 Page 3
4
Features
(1) Steam Button
(2) Two Cup Button
(3) One Cup Button
(4) On/Standby Button
(5) Espresso Cups Holder
(6) Steam Control Dial
(7) Water Tank Lid
(8) Water Tank
(9) Filter Holder Lock Position
(10) Brewing Head
(11) Removable Drip Tray Grid
(12) Steam Wand
(13) Steam Wand Grip Tab
(14) Steam Wand Sleeve
(15) Removable Drip Tray
(16) Drip Tray Full Indicator
(17) Tamp Spoon
(18) E.S.E. Pod Filter
(19) Smaller One Cup Filter
(for single shot use)
(20) Larger Two Cup Filter
(for double shot use)
(21) Filter Holder
(22) Filter Holder Clip
Product Overview
18
19
20
21
1 32 4
5 6 8
7
9
16
17
12
14
1310
11
15
22
CM172020MUK Rev2.qxp_Layout 1 02/12/2020 13:49 Page 4
5
2
Without placing any Filters
(18/19/20)
into the
Filter Holder
(21)
, place the Filter Holder into the
Brewing Head
(10) and turn until at a right angle
to the Main Unit to lock into position securely.
1
Ensure the Water Tank
(8)
is filled up to the MAX line.
Assemble the Espresso Coffee Machine as above,
ensuring the Removable Drip Tray
(15)
is in place.
3
Before First Use
IMPORTANT: I
t is important that prior to using the coffee maker for the first time that water is
f
lushed through the system and it is primed for making coffee.
N
OTE: You may hear a pumping sound when water is passing through the system for the first time.
T
his is normal and is caused by the air escaping from the system. The noise will cease after around
20 seconds.
5
Priming the Coffee Machine
4
Following action no.4, wait for the
Two Cup and One
Cup Buttons
(2/3)
to illuminate solidly. Then place a
receptacle, capable of holding 150ml, on the Drip
Tray Grid
(11) and press the Two Cup Button (2).
6
Water will pass through the system into the
receptacle, which then must be emptied. Repeat a
further 3 times, the coffee machine is now primed
for making coffee.
Ensure the Steam Control Dial (6) is in the off
position and press the On/Standby Button
(4).
The Two Cup and One Cup Buttons
(2/3) will
pulse as the unit is heating up
.
When the Two Cup and One Cup Buttons (2/3)
illuminate solidly, place the Steam Wand (12) into
a mug or jug and slowly turn the Steam Control
Dial
(6) until water dispenses, keep the Dial open
for at least 30 seconds and close the Dial. Take
care performing this process as the hot water will
pulse into the receptacle, and it may emit steam.
Dispose of the water and repeat the process a
further two times.
CM172020MUK Rev2.qxp_Layout 1 02/12/2020 13:49 Page 5
6
1
4
Preheating (Optional)
F
or a hot Espresso, we recommend preheating the appliance before following the instructions on the
f
ollowing page. Preheating ensures the Filter Holder and cup are warm enough to enhance the coffee flavour.
6
5
2
3
Place the Coffee Filter (18/19/20) into the Filter
Holder (21) without coffee in the Filter. Place the
Filter Holder into the Brewing Head (10) and turn
until at a right angle to the Main Unit to lock into
position securely.
Fill the Water Tank
(8)
up to the MAX line.
Assemble the Espresso Coffee Machine as above,
ensuring the Removable Drip Tray
(15)
is in place.
When the Two Cup and One Cup Buttons (2/3)
illuminate solidly, place your cup(s) on the Drip
Tray Grid (11). Press either the One or Two Cup
Button to dispense set amount, approximately
50ml for one cup and 100ml for two.
Empty the water from your Espresso cup.
Next, follow steps 2 onwards under ‘Using Your
Coffee Maker’ on the following page, using your
preheated Espresso cup.
Remove the warmed Filter Holder
(21), ready for
use (see steps 2 and 3 under ‘Using Your Coffee
Maker’ on the following page).
Plug the Espresso Coffee Machine in and press
the On/Standby Button
(4). The button will
illuminate and remain on until the coffee machine
is switched off again. The Two Cup and One Cup
Buttons (2/3) will pulse.
Re-filling the water tank
If the Water Tank (8) runs dry, after re-filling it
may require two or more presses of the Two Cup
and/or One Cup Buttons (2/3) for water to flow
through the system to make an espresso.
CM172020MUK Rev2.qxp_Layout 1 02/12/2020 13:49 Page 6
7
3
Place the Filter Holder into the Brewing Head
(10) and turn until at a right angle to the Main
Unit to lock into position securely.
2
1
F
ill the Water Tank
(
8)
u
p to the MAX line.
Assemble the Espresso Coffee Machine as above.
Your Espresso C
offee Machine
uses ground
coffee or Easy Serving Espresso (E.S.E.)
pods and comes with three suitable Filters.
The smaller one cup Filter
(19) is for single
shot use and the larger two cup Filter (20) is
for double shot use. Use the E.S.E. Pod Filter
(18) when using E.S.E. pods - a compact
coffee pod with a paper filter covering.
7
Allow the grinds/pod to cool. Empty the coffee
grinds/ESE pod, using the Filter Holder Clip
(22)
to
keep the Filter in place. Remove the Filter and clean.
6
You may press and hold the One or Two cup Button
to continue dispensing until the button is released.
See ‘Altering Dispense Amounts’ page 9, for details.
5
When the Two and One Cup Buttons (2/3) illuminate
solidly, place your cup(s) on the Drip Tray. Press
either the One or Two Cup Button to dispense set
amount, approximately 50ml for one cup and 100ml
for two. If no further drinks are required turn off the
machine with the standby button.
Using Your Coffee Maker
Place the Espresso Filter into the Filter Holder (21).
Fill the Filter with fine espresso ground coffee to just
below the top rim and compact it down with the
Tamp Spoon
(17)
. Alternatively insert the E.S.E. pod.
4
P
lug the Espresso Coffee Machine in and press
the On/Standby button (4). The button will
illuminate and remain on until the coffee machine
is switched off again or automatically goes into
standby after 30 minutes. The Two and One Cup
Buttons (2/3) will pulse.
If the coffee machine is switched off by the user by pressing the On/Standby button (4) or if it
automatically goes into standby mode, after 30 minutes without use the machine requires one
press of the On/Standby button to exit standby and a second press to start pre-heating for
another coffee, the Two Cup and One Cup Buttons (2/3) will pulse.
CM172020MUK Rev2.qxp_Layout 1 02/12/2020 13:49 Page 7
8
4
1
0mm
Place the Steam Wand (12) into the milk, slowly
turn the Steam Control Dial
(6) until steam is
dispensed. Adjust to your liking.
3
100ml -200ml
Pour 100-200ml of chilled milk into a jug.
2
P
ress the Steam Button
(
1)
,
wait for the button
to illuminate solidly after pulsing.
1
F
ill and fit the Water Tank
(
8)
.
Ensure the Steam
Control Dial
(6) is in the off position. Press the
On/Standby Button
(4).
6
Press the Steam Button (1) to exit the steam
function. Serve the frothy milk. Press the
On/Standby Button
(4) to turn off the unit.
5
10mm
Whe
n e
no
ug
h f
ro
th ha
s
be
e
n produce
d, turn the
Ste
a
m
Co
ntro
l Di
a
l
(
6)
to
OF
F.
U
si
ng
T
he
S
t
e
a
m
W
a
nd
7
Allow the steam wand to cool before cleaning. To
clean, remove the Steam Wand Sleeve
(14) and use
a wet cloth to clean the Wand and Sleeve.
8
Use a pin to clean the nozzle head and air holes
in the Sleeve.
If another coffee is required after frothing milk, see ‘Notes on Using the Steam Wand’ on Page 9
for instructions on how to cool the machine.
IMPORTANT:
The Steam wand must be cleaned after every use.
CM172020MUK Rev2.qxp_Layout 1 02/12/2020 13:49 Page 8
9
I
f the unit is switched on with the Steam
Control Dial
(6)
on, all buttons will flash. The
S
team Control Dial must be turned to the off
p
osition.
I
f you want to make another coffee after using
steam, ensure the Steam Control Dial
(6) is in its
off state and the Two Cup and One Cup Buttons
(
2/3)
a
re pulsing, the unit is cooling down. The
buttons will illuminate solidly when it’s back down
to temperature and ready to make coffee again.
This can be accelerated by turning the Steam
Control Dial to on, water will pump through and
cool. Ensure there is a receptacle under the
Steam Wand
(12)
.
ENSURE THE FILTER HOLDER (21) IS LOCKED
INTO POSITION CORRECTLY AT A RIGHT
ANGLE TO THE MAIN UNIT AND SECURELY
LOCATED IN THE BREWING HEAD (10)
BEFORE USE.
WHEN FROTHING MILK, ENSURE THE STEAM
CONTROL DIAL
(6) IS OFF BEFORE REMOVING
THE STEAM WAND (12) FROM THE MILK.
When dispensing coffee, (see ‘Using Your Coffee
Maker’, step 5, page 7) you may press and hold
the Two Cup or One Cup Button
(2/3) to continue
dispensing coffee until the button is released. The
machine will store dispensed volumes up to a 60
second maximum limit. If you dispense for longer
than 60 seconds, it will dispense the volume but
not store it in the program. For subsequent use,
one press will dispense the programmed amount
for that button.
Factory dispense settings can be restored by
pressing the One Cup Button
(3) and Steam
Button (1) together for 3 seconds, until you hear
a beep.
NOTE: Both the Two Cup and One Cup Buttons
(2/3) can be programmed.
After using the Steam Wand
(12), the water in the
boiling chamber will be too hot to brew coffee
without burning the grinds. The water will be the
correct temperature when the Two Cup and One
Cup Buttons
(2/3) illuminate solidly. The Two Cup
and One Cup Buttons will not function until they
are illuminated solidly.
Your Espresso Coffee Machine will automatically
s
witch off 30 minutes after brewing coffee.
To reactivate the coffee maker, press the
On/Standby Button (4) once to exit standby and a
s
econd time to start pre-heating for further use.
W
hen the water in the Removable Drip Tray
(
15)
i
s
full, the Drip Tray Full Indicator
(16) will be visible.
1. Remove the Drip Tray from the appliance and
empty.
2. Clean the Drip Tray Grid (11) and Drip Tray with a
damp cloth before replacing.
The best method to make a long drink is to press
and hold the Two Cup or One Cup Button (2/3).
NOTE: If this time is below 60 seconds the
volume will be stored, see 'Altering Dispense
Amounts'.
In addition, hot water can be dispensed from the
Steam Wand
(12).
Ensure the Steam Control Dial
(6) is in the closed
position. Turn the unit on, and place a cup or
vessel under the Steam Wand (12). Ensure the
Steam Button (1) is off, and the Two Cup and One
Cup Buttons (2/3) are illuminated solidly. Open
the Steam Control Dial, and hot water will flow
through the Steam Wand.
Take care performing this process as the hot
water will 'pulse' into the cup.
USAGE WARNING
Altering
D
isp
ense
Am
o
unts
Notes on Using the
Steam Wand
Tip
S
t
a
nd
b
y
M
o
d
e
Em
p
ty
ing
T
he
D
rip
T
r
ay
Ad
d
ing
H
o
t W
ater
CM172020MUK Rev2.qxp_Layout 1 02/12/2020 13:49 Page 9
10
1
Disconnect the appliance from the mains supply.
2
M
ake sure the appliance has completely cooled
down.
3
S
imply wipe the Steam Wand
(
12)
a
nd exterior
w
ith a clean, damp cloth.
U
se a pin to clean the nozzle head and air holes
i
n the Sleeve.
Do not use any abrasives or metal scourers as
this will damage the finish on the unit.
4
The Filter Holder (21) and Water Tank (8) should
be washed after each use by rinsing them under
water. To assist in keeping the Filter Holder clean,
we recommend you periodically run the machine
with the Filter Holder in place, without coffee,
using water only.
Should the holes in the Filter become blocked
with coffee grinds, use a fine bristled brush to
help clean.
When your coffee maker is not being used, we
recommend that you do not leave the Filter
Holder attached to the machine as this will
reduce the life of the gasket.
5
Remove the Drip Tray Grid (11) and Drip Tray (15)
from the appliance and remove any spilt coffee
and water. Then, clean them with a damp cloth or
a damp sponge.
6
You must clean the Steam Wand (12) and Sleeve
(14) immediately after each use, after it has
cooled down. Place the Steam Wand in a jug or
mug and use the steam setting to clear any
remaining milk out of the Wand and Sleeve.
Remove the Steam Wand Sleeve, place under
warm running water to remove excess milk. If
the Steam Wand becomes blocked, use a small
pin to clean more thoroughly.
WARNING: Steam from the Steam Wand is
extremely hot and can scald.
IMPORTANT: Never wash your coffee machine
accessories in a dishwasher.
1
Disconnect the appliance from the mains supply.
2
Make sure the appliance has cooled down
completely.
3
Remove the Water Tank (8) and Drip Tray (15) from
the machine.
4
F
ill the Water Tank with dissolved descaler
solution (as per the manufacturers instructions),
up to the max level marked on the side of the tank.
5
R
e-fit the Water Tank and Drip Tray to the
machine.
6
P
lace an empty container under the Brewing
Head
(10) to gather the descaled hot boiled water.
7
Connect the appliance to the mains supply.
8
P
ress the On/Standby Button
(
4)
a
nd wait for the
Two Cup and One Cup Buttons
(2/3) to illuminate
s
olidly.
9
Place the Steam Wand (12) into a mug or jug and
slowly turn the Steam Control Dial (6) until water
dispenses.
10
Keep dispensing to fill the mug or jug, then empty
when full.
11
Repeat the process until the Water Tank (8) is
empty.
12
Immediately refill the Water Tank with clean water
and repeat the process to flush the system.
Your Espresso Coffee Machine allows you to
create a variety of coffee drinks helping you to
create the coffee shop experience in your own
home. The diagrams on this page are a simple
guide showing you the percentage of ingredients
that make up each of the drink types. Please refer
to the instructions in this booklet on how to
create the perfect espresso and frothy milk.
Making Coffee
Des
cali
ng
Cleaning Your Espresso
Coffee Machine
Espresso
Espresso
Espresso
Hot Milk
Flat White
Espresso
Whipped Cream
Espresso con Panna
Espresso
Hot Milk
Milk Froth
Cappuccino
Espresso
Water
Americano
Espresso
Milk Froth
Espresso Macchiato
Espresso
Hot Milk
Milk Froth
Caffé Latte
Espresso
Chocolate Syrup
Hot Milk
Whipped Cream
Caffé Mocha
CM172020MUK Rev2.qxp_Layout 1 02/12/2020 13:49 Page 10
Helpline
If you are having a problem with your appliance,
please call our Helpline, as we are more likely to
be able to help than the store you purchased the
item from.
Please have the product name, model number
and serial number to hand when you call to help
us deal with your enquiry quicker.
UK Helpline: 0344 871 0944
IRE Helpline: 1800 409 119
Spares: 0344 873 0710
Talk To Us
If you have any questions or comments, or want
some great tips or recipe ideas to help you get
the most out of your products, join us online:
Blog: www.morphyrichards.co.uk/blog
Facebook: www.facebook.com/morphyrichardsuk
Twitter: @loveyourmorphy
Website: www.morphyrichards.com
11
• Water is dispensing from
t
he Steam Wand
(
12)
• Steam Control Dial (6) is
o
pen
• Rotate the Steam Control
D
ial
(
6)
s
o it is closed
Troubleshooting
Problem Reason Solution
• The coffee temperature is
t
oo cold
• Heater block is not hot
e
nough before dispensing
• Conduct a preheating
p
rocess, see ‘Preheating
(Optional)’ on page 6
• The coffee grinds are wet
after use
• Coffee is not compact
enough
• Tamp the coffee before
inserting
• Espresso is weak • Wrong coffee type • Always use espresso coffee
grinds
• Milk is not frothing • Air and steam are not
getting into the milk
• Use a pin to clean the
Steam Wand nozzle and air
holes in the Sleeve (14)
• Coffee is too strong or weak • Wrong volume of coffee •
Use the correct coffee Filter:
1 person -
Smaller One Cup Filter (19)
2 person -
Larger Two Cup Filter (20)
• What is E.S.E, and where
can I find them?
• Easy Serving Espresso,
coffee within a teabag
• They are available online
and in some supermarkets
Contact us
CM172020MUK Rev2.qxp_Layout 1 02/12/2020 13:49 Page 11
CM172020MUK Rev2 12/20
The After Sales Division
Morphy Richards Ltd
Mexborough, South Yorkshire,
England, S64 8AJ
Helplines (office hours)
UK 0344 871 0944
Spare Parts 0344 873 0710
Republic of Ireland 1800 409 119
www.morphyrichards.com
Your standard one year guarantee is extended for an
a
dditional 12 months when you register the product within
2
8 days of purchase with Morphy Richards. If you do not
register the product with Morphy Richards within 28 days,
your product is guaranteed for 1 year. To validate your 2
year guarantee register with us online at
w
ww.morphyrichards.co.uk
Or call our customer registration line
U
K
0
344 871 0242
IRE 1800 409 119
N
.B. Each qualifying product needs to be registered with
Morphy Richards individually.
Please note that the 2 year guarantee is only available in
the UK and Ireland. Please refer to the one year guarantee
for more information.
It is important to retain the retailer’s receipt as proof of
purchase. Staple your receipt to this back cover for future
reference.
Please quote the following information if the product
develops a fault. These numbers can be found on the base
of the product.
Model no.
Serial no.
All Morphy Richards products are individually tested before
leaving the factory. In the unlikely event of any appliance
proving to be faulty within 28 days of purchase, it should
be returned to the place of purchase for it to be replaced.
If the fault develops after 28 days and within 12 months of
original purchase, you should contact the Helpline number
quoting Model number and Serial number on the product,
or write to Morphy Richards at the address shown.
You may be asked to return a copy of proof of purchase.
Subject to the exclusions set out below (see Exclusions),
the faulty appliance will then be repaired or replaced as
appropriate and dispatched usually within 7 working days
of receipt.
If, for any reason, this item is replaced or repaired during
the 1 year guarantee period, the guarantee on the new
item will be calculated from original purchase date.
Therefore it is vital to retain your original till receipt or
invoice to indicate the date of initial purchase.
To qualify for the 1 year guarantee, the appliance must
have been used according to the instructions supplied.
For example, crumb trays should have been emptied
regularly.
Morphy Richards shall not be liable to replace or repair the
goods under the terms of the guarantee where:
1 T
he fault has been caused or is attributable to accidental
u
se, misuse, negligent use or used contrary to the
manufacturer’s recommendations or where the fault has
b
een caused by power surges or damage caused in transit.
2 The appliance has been used on a voltage supply other
than that stamped on the products.
3 R
epairs have been attempted by persons other than our
service staff (or authorised dealer).
4 The appliance has been used for hire purposes or non
domestic use.
5 T
he appliance is second hand.
6 Morphy Richards reserves the right not to carry out any
type of servicing under the guarantee at its discretion.
7 P
lastic filters for all Morphy Richards kettles and coffee
makers are not covered by the guarantee.
8 Batteries and damage from leakage are not covered by
the guarantee.
• This guarantee does not confer any rights other than those
expressly set out above and does not cover any claims for
consequential loss or damage. This guarantee is offered
as an additional benefit and does not affect your statutory
rights as a consumer. Morphy Richards products are
intended for household use only. See usage limitations
within the location safety instructions.
Morphy Richards has a policy of continuous improvement
in product quality and design. The company, therefore
reserves the right to change the specification of
its models at any time.
For electrical products sold within the
European Community. At the end of the
electrical products useful life, it should not be
disposed of with household waste.
Please recycle where facilities exist. Check with
your Local Authority or retailer for
recycling advice in your country
Exclusions
Registering your 2 year
guarantee
Your 1 year guarantee
Disclaimer
IF YOU ARE HAVING A PROBLEM
WITH ONE OF OUR PRODUCTS,
CALL OUR HELPLINE:
UK: 0344 871 0944
EIRE: 1800 409 119
SPARES: 0344 873 0710
CM172020MUK Rev2.qxp_Layout 1 02/12/2020 13:49 Page 12
