Please read and keep these
instructions for future use
CM172023MUK A3 Rev1
Contact us
If you are having a problem with your appliance or just need advice, contact
us at Morphy Richards. Please have the product name, model number and
serial number to hand, this will help us to deal with your enquiry quicker.
www.morphyrichards.com/en-gb/support/contact-us
www.morphyrichards.com
Espresso Machine
With milk frother
Product Overview
Before First Use
Priming the Coffee Machine
Remove all packaging. Wash the water tank (2), milk tank (7), porta-filter (5), 1 cup (11) & 2 cup (12)
filters and tamping spoon (13) in warm soapy water. Rinse and dry thoroughly. Remove any labels
from the product
IMPORTANT: Prior to first use it is important that water is flushed through the system and the
machine is primed for making coffee.
NOTE: You may hear a pumping sound when water is passing through the system for the first
time. This is normal and is caused by the air escaping from the system. The noise will cease after
around 20 seconds.
To prime the unit run a cappuccino cycle with water only by following the steps below:
1
2
Fill water tank (2) to the “Max” level, replace
the lid (3), remove the red plug from the
underneath of the tank and re-attach to the
machine.
Fill the milk tank (7) with water to the “Max”
level, replace the lid (8) and attach to the
machine.
Select one of the filters (11 or 12) and place
it in the porta-filter (5). Place the porta-filter
into the brew head (4) ensuring it is properly
locked and place a cup under it.
The six control panel lights will start to flash.
When the lights become solid, press the
cappuccino button (14) twice. Once this
process is completed, the six control panels
will become solid. Your machine has been
primed and is ready to use.
Make sure the tip of the frothed milk
dispensing tube is inside the cup. Plug the
machine into an appropriate socket. Turn the
on/off switch (1) to “I” .
3
4
Espresso
Cappuccino
Latte
5
U
P
T
O
2
Y
E
A
R
G
U
A
R
A
N
T
E
E
W
I
T
H
R
E
G
I
S
T
R
A
T
I
O
N
O
N
L
I
N
E
•
1 On/off switch
2 Water Tank
3 Water Tank Lid
4 Brew Head
5 Porta-filter
6 Control Panel
7 Milk Tank
8 Milk Tank Lid
9 Milk Frother Nozzle
10 Milk Frother Control
Knob
11 1 Cup Filter
12 2 Cup Filter
13 Tamping Spoon
14 Removeable drip tray and
grid
15 Drip Tray Stand
16 Cup Storage
17 1 cup espresso and
manual dispense light
18 2 cup espresso and
manual dispense light
19 Espresso 1 and 2 Cup and
manual dispensing select
button
20 Small cup cappuccino
and milk foam light
21 Large cup cappuccino
and milk foam light
22 Cappuccino Small &
Large Cup Select Button
23 Small cup latte and
cleaning light
24 Large cup latte and
cleaning light
25 Latte Small & Large
Cup Select and cleaning
button
Health and safety
• WARNING: This appliance incorporates a heating element which is subject to residual
heat after use.
• WARNING: Misuse of the appliance could cause personal injury.
• CAUTION: To prevent damage to the appliance, do not use alkaline cleaning agents
when cleaning, use a soft cloth and mild detergent.
• This appliance can be used by children aged from 8 years and above if they have been
given supervision or instruction concerning the use of the appliance in a safe way and
if they understand the hazards involved. Cleaning and user maintenance shall not be
made by children unless they are older than 8 and supervised. Keep the appliance and
its cord out of the reach of children aged less than 8 years.
• For care and cleaning, refer to the relevant sections in these instructions.
• If the mains cable is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified person in order to avoid a hazard.
• Appliances can be used by persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards involved.
• Children shall not play with the appliance.
• This appliance is intended to be used in household and similar applications such as: farm
houses, by clients in hotels, motels and other residential type environments, and bed
and breakfast type environments. It is not suitable for use in staff kitchen areas in shops,
offices and other working environments in order to avoid a hazard.
• This product is not suitable for use in altitudes above 2000m.
• This appliance incorporates an earth connection for functional purposes only.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
• CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cut-
out, this appliance must not be supplied through an external switching device, such as a
timer, or connected to a circuit that is regularly switched on and off by the utility.
• The coffee-maker shall not be placed in a cabinet when in use.
• The Milk frother Nozzle becomes very hot during use & this may cause burn in case of
contact, therefore avoid any direct contact with Nozzle.
The use of any electrical appliance requires the following common sense safety rules. Please read these instructions carefully before using the product.
• WARNING: Do not place the appliance onto a metal tray or metal surface whilst in use.
Mains cable
• Do not let the mains cable hang over the edge of the worktop where a child could
reach it.
• Do not let the mains cable run across an open space e.g. between a low socket and
a table
• Do not let the mains cable run across a cooker or other hot area which might damage
the cable.
• The mains cable should reach from the socket to the base unit without straining the
connections.
Personal safety
• WARNING: To protect against fire, electric shock and personal injury do not immerse
cord, plug and appliance in water or any other liquid.
• Unplug from the outlet before cleaning.
• Allow to cool before putting on or taking off parts and before cleaning.
• Do not move the Coffee Maker while switched on.
• The use of attachments or tools not recommended or sold by Morphy Richards, may
cause fire, electric shock or injury.
• Do not use the appliance for any use other than its intended purpose.
• Do not place the appliance on or near a hot gas or electric burner or in a heated oven.
• WARNING: The appliance must not be immersed for cleaning.
• CAUTION: To prevent damage to the appliance, do not use alkaline cleaning agents
when cleaning. Use a soft cloth and detergent.
Electrical requirements
Should the fuse in the mains plug require changing, replace it with a fuse of the same rating as
originally fitted.
WARNING: This appliance must be earthed.
Exclusions
Other safety considerations
Morphy Richards shall not be liable to replace or repair the goods under the terms of the
guarantee where:
1 The fault has been caused or is attributable to accidental use, misuse, negligent use or
used contrary to the manufacturer’s recommendations or where the fault has been caused
by power surges or damage caused in transit.
2 The appliance has been used on a voltage supply other than that stamped on the products.
3 Repairs have been attempted by persons other than our service staff (or authorised
dealer).
4 The appliance has been used for hire purposes or non domestic use.
5 The appliance is second hand.
6 Morphy Richards reserves the right not to carry out any type of servicing under the
guarantee at its discretion.
7 Plastic filters for all Morphy Richards kettles and coffee makers are not covered by the
guarantee.
8 Batteries and damage from leakage are not covered by the guarantee.
9 This guarantee does not confer any rights other than those expressly set out above and
does not cover any claims for consequential loss or damage. This guarantee is offered
as an additional benefit and does not affect your statutory rights as a consumer. Morphy
Richards products are intended for household use only. See usage limitations within the
location safety instructions.
Location
• Always locate your appliance away from the edge of the worktop.
• Ensure that the appliance is used on a firm, flat surface.
• Do not use the appliance outdoors or near water.
Espresso
Cappuccino
Latte
1
4
5
13
12
15
11
14
16
6
18
17
19
25
22
20
23
21
24
2
7
9
10
3
8
