English
Table of Contents
Quick Guide ........................................................................................................................................2-3
Important Safety Instructions ..............................................................................................................4-5
Installation and General Instructions ..................................................................................................5-6
Feature Diagram....................................................................................................................................7
Control Panel .........................................................................................................................................8
Cooking Modes......................................................................................................................................9
Cookware and Utensil Chart................................................................................................................10
Clock Setting .......................................................................................................................................11
Child Safety Lock Setting ....................................................................................................................11
Micro Power Setting ............................................................................................................................12
Turbo Defrost Setting ..........................................................................................................................13
Grill Setting ..........................................................................................................................................14
Combination Setting ............................................................................................................................15
To Cook Using the Quick 30 Function .................................................................................................16
Using the Add Time Function...............................................................................................................16
Auto Cook Setting — To Use Beverage ..............................................................................................17
Sensor Cook Setting.......................................................................................................................18-19
Auto Cook Setting — Others ..........................................................................................................20-22
Timer Setting (Kitchen Timer/Standing Time/Delay Start) ...................................................................23
3-Stage Setting ....................................................................................................................................24
Microwaves and How They Work ........................................................................................................25
Food Characteristics............................................................................................................................25
Cooking Techniques .......................................................................................................................26-28
Defrosting Chart ..................................................................................................................................29
Reheating Chart ..................................................................................................................................30
Cooking Chart......................................................................................................................................31
Before Requesting Service ..................................................................................................................32
Care of your Microwave Oven .............................................................................................................33
Technical Specifications ......................................................................................................................33
© Panasonic Appliances Microwave Oven (Shanghai) Co., Ltd. 2018
- Eng-2 -
- Eng-3 -
English
After plugging in, “ ” will appears in the display window, then you can start to operate.
Feature How to Operate
To Set Clock
(
page 11)
Press twice.
Set Time of day. Press once.
To Set / Cancel Child
Safety Lock
(
page 11)
To Set:
Press 3 times.
To Cancel:
Press 3 times.
To Cook / Reheat /
Defrost by Micro Power
and Time Setting
(
page 12)
Select power. Set the cooking time. Press.
To Use Turbo Defrost
Pad
(
page 13)
Press. Select the weight of food. Press.
or
To Cook using
Grill Pad
(
page 14)
Select power. Set the cooking time. Press.
To Cook using
Combination Pad
( page 15)
Select power. Set the cooking time. Press.
To Cook using Quick 30
Pad
(
page 16)
Press.Press to set the
desired cooking time.
Quick Guide
- Eng-2 -
- Eng-3 -
English
Feature How to Operate
To Use the Add Time
Function
(
page 16)
After cooking,
press this pad.
Add Time by pressing
the Time pads.
Press.
To Cook using Sensor
Cook pad
(
page 18)
Press. Press to select
the desired menu
number.
To Cook using
Auto Cook Pads
(
page 20)
Press to select the
desired menu number.
Press.
eg:
Set the weight.
To Use as a
Kitchen Timer
(
page 23)
Press. Set the kitchen time. Press.
To Set
Standing Time
(
page 23)
Press. Set the standing time. Press.
Set the desired
cooking program.
To Set
Delay Start
(
page 23)
Press. Set the delay time. Press.
Set the desired
cooking program.
Quick Guide (continued)
- Eng-4 -
- Eng-5 -
English
Precautions to be taken when
using Microwave Ovens for
Heating Foodstuffs
Inspection for Damage:
A microwave oven should only be used if an
inspection confirms all of the following conditions:
1. The grille is not damaged or broken.
2. The door fits squarely and securely and opens
and closes smoothly.
3. The door hinges are in good condition.
4. The metal plates of a metal seal on the door are
neither buckled nor deformed.
5. The door seals are neither covered with food nor
have large burn marks.
Precautions:
Microwave radiation from microwave ovens can
cause harmful effects if the following precautions are
not taken:
1. Never tamper with or deactivate the interlocking
devices on the door.
2. Never poke an object, particularly a metal object,
through a grille or between the door and the oven
while the oven is operating.
3. Never place saucepans, unopened cans or other
heavy metal objects in the oven.
4. Do not let other metallic articles, e.g. fast food foil
containers, touch the side of the oven.
5. Clean the oven cavity, the door and the seals with
water and a mild detergent at regular intervals.
Never use any form of abrasive cleaner that may
scratch or scour surfaces around the door.
6. Always use the oven with the trays or cookware
recommended by the manufacturer.
7. Never operate the oven without a load (i.e. an
absorbing material such as food or water) in the
oven cavity unless specifically allowed in the
manufacturer’s literature.
8. For horizontally hinged doors, never rest heavy
objects such as food containers on the door while
it is open.
9. Do not place sealed containers in the microwave
oven. Baby bottles fitted with a screw cap or a
teat are considered to be sealed containers.
10. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
11. Children should be supervised to ensure that they
do not play with the appliance.
12. It is hazardous for anyone other than a competent
person to carry out any service or repair operation
that involves the removal of a cover which gives
protection against exposure to microwave energy.
13. The surfaces are liable to get hot during use.
Earthing Instructions
This microwave oven must be earthed. In the event
of an electrical short circuit, earthing reduces the risk
of electric shock by providing an escape wire for the
electric current. This microwave oven is equipped
with an earthing plug. The plug must be plugged into
an outlet that is properly installed and earthed.
WARNING—Improper use of the earthing plug can
result in electric shock.
Fan Motor Operation after Cooking
After using this oven the fan may rotate to cool the electric
components. This is perfectly normal, and you can take
out the food from the oven while the fan operates.
Important Instructions
WARNING—To reduce the risk of burns, electric shock,
fire, injury to persons or excessive microwave energy:
1. Read all instructions before using microwave oven.
2. Some products such as whole eggs and sealed
containers - (for example, closed glass jars and
sealed baby bottles with teat) may explode and
should not be heated in microwave oven.
3. Use this microwave oven only for its intended use
as described in this manual.
4. As with any appliance, close supervision is
necessary when used by children.
5. Do not operate this microwave oven, if it is not
working properly, or if it has been damaged or
dropped.
6. Do not store or use this appliance outdoors.
7. Do not immerse cord or plug in water.
8. Keep cord away from heated surfaces.
9. Do not let cord hang over edge of table or counter.
10. To reduce the risk of fire in the oven cavity:
(a) Do not overcook food. Carefully attend
microwave oven if paper, plastic, or other
combustible materials are placed inside the
oven to facilitate cooking.
(b) Remove wire twist-ties from bags before
placing bag in oven.
(c) If materials inside the oven should ignite, keep
oven door closed, turn oven off at the wall
switch, or shut off power at the fuse or circuit
breaker panel.
(d) Never leave microwave unattended while
cooking or reheating.
11. Do not remove outer panel from oven.
12. Appliances are not intended to be operated by
means of an external timer or separate remote-
control system.
13. Failure to maintain the oven in a clean condition
could lead to deterioration of the surface that
could adversely affect the life of the appliance
and possibly result in a hazardous situation.
Circuits
Your microwave ovens should be operated on
a separate circuit from other appliances. The
voltage used must be the same as specified on this
microwave oven. Failure to do this may cause the
power board fuse to blow, and/or food to cook slower.
Do not insert higher value fuse in the power board.
Important Safety Instructions
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
- Eng-4 -
- Eng-5 -
English
Practical Hints:
1. For initial use of GRILL and COMBINATION, if
you see white smoke arise, it is not malfunction.
2. The oven has two grill heaters situated in the top of
the oven. After using the GRILL and COMBINATION
functions, the ceiling will be very hot.
3. Accessible parts may become hot during use.
Young children should be kept away.
4. Before using GRILL and COMBINATION function
for the first time operate the oven without food and
accessories (including glass tray and roller ring) on
Grill 1 for 5 minutes. This will allow the oil that is
used for rust protection to be burned off. This is the
only time that the oven is operated empty.
Caution: All inside surfaces of the oven will be hot.
5. Exterior oven surfaces, including air vents on
the cabinet and the oven door will get hot during
GRILL and COMBINATION. Use care when
opening or closing door and when inserting or
removing food and accessories.
Caution! Hot surfaces
Important Safety Instructions (continued)
General Use
1. In order to maintain high quality, do not operate
the oven when empty. The microwave energy
will reflect continuously throughout the oven if
no food or water is present to absorb energy.
This can lead to damage to the microwave oven
including arcing within the oven cavity.
2. If smoke is observed, press the Stop/Reset Pad
and leave door closed order to stifle any flames.
Disconnect the power cord, or shut off power at
the fuse or circuit breaker panel.
3. If smoke is observed, switch off or unplug the
appliance and keep the door closed in order to
stifle any flames.
4. The microwave oven is intended for heating food
and beverages. Drying of food or clothing and
heating of warming pads, slippers, sponges,
damp cloth and similar may lead to risk of injury,
ignition or fire.
5. Do not use recycled paper products, as they may
contain impurities which may cause sparks and/or
fires when used.
6. Do not use newspapers or paper bags for cooking.
7. Do not hit or strike control panel. Damage to
controls may occur.
8. POT HOLDERS may be needed as heat from
food is transferred to the cooking container and
from the container to the glass tray. The glass
tray can be very hot after removing the cooking
container from the oven.
9. Do not store flammable materials next to, on top
of, or in the oven. It could be a fire hazard.
10. Do not cook food directly on glass tray unless
indicated in recipes. (Food should be placed in a
suitable cooking utensil.)
WARNING
(a) The door seals and door seal areas should be cleaned with a damp cloth. The appliance should
be inspected for damage to the door seals and door seal areas and if these areas are damaged
the appliance should not be operated until it has been repaired by a service technician trained
by the manufacturer.
(b) If the door or door seals are damaged, the oven must not be operated until it has been repaired
by a competent person.
(c) It is hazardous for anyone other than a competent person to carry out any service or repair
operation that involves the removal of a cover which gives protection against exposure to
microwave energy.
(d) If the supply cord of this appliance is damaged, it must be replaced by the manufacturer or its
service agent or a similarly qualified person in order to avoid a hazard.
(e) Before use, the user should check that whether the utensils are suitable for use in microwave ovens.
(f) Liquids and other foods must not be heated in sealed containers since they are liable to
explode, at the same time it should avoid the boiling liquids splash.
(g) Only allow children to use the oven without supervision when adequate instructions have been
given so that the child is able to use the oven in a safe way and understands the hazards of
improper use.
(h) When the appliance is operated in the grill or combination modes, children should only use the
oven under adult supervision due to the temperatures generated.
(I) Care should be taken not to displace the glass tray when removing containers from the appliance.
Installation and General Instructions
- Eng-6 -
- Eng-7 -
English
Installation and General Instructions
(continued)
11. DO NOT use this oven to heat chemicals or other
non-food products. DO NOT clean this oven with
any product that is labeled as containing corrosive
chemicals. The heating of corrosive chemicals in
this oven may cause microwave radiation leaks.
12. If glass tray is hot, allow to cool before cleaning or
placing in water.
13. When using the COMBINATION mode, never
place any aluminum or metal container directly
on the wire rack. Always insert a heat-proof,
grass plate or dish between the wire rack and the
aluminum container. This will prevent sparking
that may damage the oven.
14. During cooking, some steam will condense inside
and/or on the oven door. This is normal and safe.
Steam will disappear after the oven is cool down.
15. Metallic containers for food and beverages are
not allowed during microwave cooking.
16. It is recommended not to use the Wire Rack when
cooking in the MICROWAVE mode only.
17. Only use utensils that are suitable for use in
microwave ovens.
Placement of Oven
This oven is intended for Counter-top use only. It is
not intended for built-in use or use inside a cupboard.
1. The oven must be placed on a flat, stable surface.
It shall not be placed in a cabinet. For correct
operation, the oven must have sufficient air flow.
Allow 15 cm of space on the top of the oven,
10 cm at back and 5 cm on both sides. If one side
of the oven is placed flush to a wall, the other side
or top must not be blocked. Do not remove feet.
5 cm
15 cm
10 cm
OPEN
Counter-top
(a) Do not block air vents. If they are blocked
during operation, the oven may overheat. If
the oven overheats, a thermal safety device
will turn the oven off. The oven will remain
inoperable until it has cooled.
(b) Do not place oven near a hot or damp surface
such as a gas stove, electric range or sink etc.
(c) Do not operate oven when room humidity is
too high.
2. This oven was manufactured for household use only.
3. If the oven is designed for installation into a wall
cabinet, use the proper trim kit available from a
local Panasonic dealer. Follow all instructions
packed with the kit.
Food
1. Do not use your oven for home canning or the
heating of any closed jar. Pressure will build
up and the jar may explode. In addition, the
microwave oven cannot maintain the food at the
correct canning temperature. Improperly canned
food may spoil and be dangerous to consume.
2. Do not attempt to deep fat fry in your microwave
oven.
3. Eggs in their shell and whole hard-boiled eggs
should not be heated in microwave ovens since
they may explode, even after microwave heating
has ended.
4. Potatoes, apples, egg yolks, whole squash and
sausages are examples of foods with nonporous
skins. This type of food must be pierced before
cooking, to prevent bursting.
5. When heating liquids, e.g. soup. sauces and
beverages in your microwave oven, overheating
the liquid beyond boiling point can occur without
evidence of bubbling. This could result in a
sudden boil over the hot liquid. To prevent this
possibility the following steps should be taken.
(a) Avoid using straight-sided containers with
narrow necks.
(b) Do not overheat.
(c) Stir the liquid before placing the container in the
oven and again halfway through cooking time.
(d) After heating, allow to stand in the oven for
a short time, stirring again before carefully
removing the container.
(e) Microwave heating of beverages can result in
delayed eruptive boiling, therefore care must
be taken when handling the container.
6. DO NOT USE A CONVENTIONAL MEAT
THERMOMETER IN THE MICROWAVE OVEN.
To check the degree of cooking of roasts and
poultry use a MICROWAVE THERMOMETER.
Alternatively, a conventional meat thermometer
may be used after the food is removed from the
oven. If undercooked, return meat or poultry to
the oven and cook for a few more minutes at the
recommended power level. It is important to ensure
that meat and poultry are thoroughly cooked.
7. COOKING TIMES given in the cookbook are
APPROXIMATE. Factors that may affect cooking
time are preferred degree of moisture content,
starting temperature, altitude, volume, size, shape of
food and utensils used. As you become familiar with
the oven, you will be able to adjust for these factors.
8. It is better to UNDERCOOK RATHER THAN
OVERCOOK foods. If food is undercooked, it
can always be returned to the oven for further
cooking. If food is overcooked, nothing can be
done. Always start with minimum cooking times
recommended.
9. Extreme care should be taken when cooking
popcorn in a microwave oven. Cook for minimum
time as recommended by manufacturer. Use
the directions suitable for the wattage of your
microwave oven. NEVER leave oven unattended
when popping popcorn.
10. When heating food in plastic or paper containers,
keep an eye on the oven due to the possibility of
ignition.
11. The contents of feeding bottles and baby food jars
shall be stirred or shaken and the temperature
checked before consumption, in order to avoid
burns.
- Eng-6 -
- Eng-7 -
English
Feature Diagram
q Oven Window
Door Safety Lock System
Door Release Pad
Push to open the door. Opening the door during
cooking will stop the cooking process without
cancelling the program. Cook resumes as soon
as the door is closed and Start Pad is pressed. It
is quite safe to open the door at any time during a
cooking program and there is no risk of Microwave
exposure.
Control Panel
Glass Tray
a. DO NOT operate the oven without the Roller
Ring and Glass Tray in place.
b. Only use the Glass Tray specifically designed for
this oven. Do not substitute any other Glass Tray.
c. If the Glass Tray is hot, allow to cool before
cleaning or placing in water.
d. DO NOT cook directly on the Glass Tray.
Always place food on a microwave-safe dish, or
on a rack set in a microwave-safe dish.
e. If food or utensil on the Glass Tray touches
oven walls, causing the tray to stop moving,
the tray will automatically rotate in the opposite
direction. This is normal.
f. Glass Tray can rotate in either direction.
Roller Ring
a. Roller Ring should be cleaned regularly to avoid
excessive noise.
b. Roller Ring and Glass Tray should be used at
the same time.
Identification Plate
Oven Air Vent
Waveguide Cover (do not remove)
Wire Rack
a. A Wire Rack is included with the oven in order
to facilitate browning of small dishes.
b. Wire Rack should be cleaned regularly.
c. When using Wire Rack in the manual GRILL
or COMBINATION cooking modes, be careful
to choose heat-proof containers; containers
made of plastic or paper may melt or burn when
exposed to the heat radiating from the grill.
d. When using the COMBINATION mode, never
place any aluminum or metal container directly
on Wire Rack. Always insert a glass plate or
dish between Wire Rack and the aluminum
container. This will prevent sparking that may
damage the oven.
e. Do not use Wire Rack when cooking in the
MICROWAVE mode only.
Warning Label
Power Supply Cord
Power Supply Plug
Menu Label
h Stopper (irremovable)
The stopper ensures sufficient space at the back
of the oven to provide adequate ventilation.
Grill Elements
kOven light
Oven light will turn on during cooking and also
when door is opened.
Note
1. The above illustration is for reference only.
2. The glass tray and wire rack are the only accessories with this oven. All other cooking
utensils mentioned in this manual must be purchased separately.
hh
k
q
(NN-GT69JS)
(NN-GT65JB)
- Eng-8 -
- Eng-9 -
English
Control Panel
1 Display Window
2 Micro Power pad (page 12)
3 Grill pad (page 14)
4 Combination pad (page 15)
5 Turbo Defrost pad (page 13)
6 Sensor Cook pad (page 18)
7 Auto Cook pads (page 17, 20)
8 More/Less/Weight pads
Set desired weight by pressing the
/ pads.
/ pads also can be used for Sensor Cook
function to increase/decrease the cooking time.
(see details on page 18)
9 Add Time pad (page 16)
10 Time pads
11 Quick 30 pad (page 16)
12 Timer/Clock pad (page 11, 23)
13 Stop/Reset pad:
Before cooking: One tap clears all your
instructions.
During cooking: One tap temporarily stops the
cooking process. Another tap cancels all your
instructions and colon or time of day appears in the
display window.
14 Start pad
After cooking program setting, one tap allows
oven to begin functioning. If door is opened or
Stop/Reset Pad is pressed once during oven
operation, Start Pad must be pressed again to
restart oven.
Note
If an operation is set and Start Pad is
not pressed, after 6 minutes, the oven
will automatically cancel the operation.
The display will revert back to clock or
colon mode.
Beep Sound
When a pad is pressed correctly, a beep
will be heard. If a pad is pressed and
no beep is heard, the unit did not or
cannot accept the instruction. The oven
will beep twice between programmed
stages. At the end of any complete
program, the oven will beep 5 times.
* NN-GT65JB and NN-GT69JS – The
design of your control panel may vary from
the panel displayed, but the words on the
pads will be the same.
q
- Eng-8 -
- Eng-9 -
English
Cooking Modes
The diagrams shown below are examples of the accessories. It may vary depending on the recipe/dish
used.
Cooking modes Uses
Accessories
to use
Containers
Microwave
• Defrosting.
• Reheating.
• Melting:butter,chocolate,
cheese.
• Cookingfish,vegetables,
fruits, eggs.
• Preparing:stewedfruits,
jam, sauces, custards,
pastry, caramel, meat, fish.
• Bakingcakeswithout
browning.
–
Microwaveable (e.g.
Pyrex® dishes, plates
or bowls) directly on the
glass tray.
No metal.
Grill
or
• Grillingthinpiecesofmeat
or fish.
• Grillingtoast
Wire rack –
• Browningofgratindishes
or meringue pies.
–
Metal or heatproof, directly
on the glass tray.
Combination
or
• Roastingmeatsteaksand
chicken pieces.
Wire rack No metal.
• Cookinglasagne,meat,
potato, or vegetable
gratins.
• Bakingcakesand
puddings with browning.
–
Microwaveable and
heatproof, directly on the
glass tray.
No metal.
- Eng-10 -
- Eng-11 -
English
Cookware and Utensil Chart
Microwave Grill Combination
Wire rack
(oven accessories)
no yes yes
Aluminium foil for shielding yes for shielding
Ceramic Plate yes yes yes
Browning Dish yes no no
Brown paper bags no no no
Dinnerware
oven/microwave safe
yes yes yes
non-oven/microwave safe no no no
Disposable
paperboard containers
yes* yes* yes*
Glassware
oven glassware & ceramic
yes yes yes
non-heat resistant no no no
Metal cookware no yes no
Metal twist-ties no yes no
Oven cooking bag yes yes* yes
Paper towels and napkins yes no no
Plastic defrosting rack yes no no
Plastic dishes
microwave safe
yes no no
non microwave safe no no no
Microwave safe plastic wrap yes no no
Straw, wicker, wood yes no no
Thermometers
microwave safe
yes no no
conventional no yes no
Waxed paper yes yes yes
Silicon bakeware yes* yes* yes*
* Check manufacturers’ recommendation, must withstand heat or follow the recipe instructions.
- Eng-10 -
- Eng-11 -
English
Clock Setting
You can use the oven without setting the clock.
1. Press twice.
Colon will blink in the
display window.
3. Press once.
Colon stops blinking;
time of day is entered
and locked in the display
window.
Time counts up in minutes.
2. Set the time by pressing the
Time pads.
Time appears in the display
window; colon is blinking.
Note
1. To reset time of day, repeat steps 1-3.
2. The clock will keep the time of day as long as oven is plugged in and electricity is supplied.
3. Clock is a 12-hour display.
4. Oven will not operate while colon is blinking.
To set:
This feature allows you to prevent operation of the oven by a young child; however, the door can still open.
This feature can be set when colon or time of day is displayed.
To set or cancel child safety lock, Start Pad or Stop/Reset Pad must be pressed 3 times within 10 seconds.
Press Start three times.
Colon or time of day will
disappear. Actual time will not
be lost.
“
” appears in the
display window.
Press Stop/Reset three times.
Colon or time of day will reappear
in the display window.
To cancel:
Child Safety Lock Setting
- Eng-12 -
- Eng-13 -
English
Micro Power Setting
Press Power Level Example of Use
once 1000 W (HIGH) Boil water. Reheat. Cook vegetables, rice, pasta and noodles.
twice 800 W (MED-HIGH) Cook poultry, meat, cakes, desserts. Heat milk.
3 times 600 W (MEDIUM) Cook beef, lamb, eggs, fish and seafood. Melt butter.
4 times 440 W (MED-LOW) Simmer soups, stews and casseroles (less tender cuts).
5 times 300 W (DEFROST) Thaw foods.
6 times 100 W (LOW) Keep cooked foods warm, simmer slowly.
Note
1. It is possible to programme no more than 3 stages cooking as one cooking set. For 2 or 3
stages cooking, repeat steps 1 and 2 above before pressing Start Pad. When operating,
two beeps will be heard between each stage. (Please refer to page 24 for details).
2. You can increase the cooking time during cooking if required. Time can be increased in
1 minute increments, up to 10 minutes. Press 'Add Time' pad once, then press '1 min' pad
to a maximum of 10 minutes. After selecting 'Add Time' function, time should be added
within a 5 second period. Cooking time can not be decreased during cooking.
3. Do not use metal containers on microwave mode.
4. Stand time can be programmed after micro power and time setting. Refer to using the timer
page 23.
1. Press to select
micro power level.
(see chart below)
3. Press Start.
The time in the
display window will
count down.
2. Set cooking time.
Select cooking time by pressing the Time pads.
(1000 W: up to 30 minutes
Other Powers: up to 99 minutes and
50 seconds)
- Eng-12 -
- Eng-13 -
English
Turbo Defrost Setting
This feature allows you to defrost meat, poultry and seafood automatically by setting the weight.
The serving/weight is 0.1 kg to 3 kg.
Food Maximum Weight
Minced meat, Chicken Pieces, Chops 3 kg
Beef roast, lamb, whole chickens 3 kg
Whole fish, scallops, prawns, fish fillets 1 kg
1. Press once.
(default weight is 0.1 kg)
3. Press Start.
Defrosting time
appears in the display
window and begins to
count down.
2. Select the weight of food by
pressing Turbo Defrost pad or
/ pads.
Tips for Turbo defrost
Meat, which is with bones. For example, if the meat with bones has the same weight as the pure meat, the
meat in the former one is lighter than the latter one. So, subtract 0.5 kg for 2 kg meat with bones is better for
defrosting and 0.25 kg for meat with bones which is less than 2 kg.
Two buzz beeps
Turn over the meat, chicken, fish and shellfish. Separate the stewed meat, chicken pieces and meat loaf. Apart
the meat loaf from the hamburger. Shield the edge of chicken wings, roast, fat or bones.
Key to defrosting
For evenly defrosting, turn over the foods or move the position of the foods in the
containers during the progress of defrosting.
Remove the package of
the raw meat and place
it on the plate.
Shield the front part of
the chicken drumsticks
by using aluminum foil.
Shield the head and tail
of the whole fish by using
aluminum foil.
Remove the package of
the fish fillet and place it
on the plate.
or
- Eng-14 -
- Eng-15 -
English
Grill Setting
There are three power levels for grill. When grilling, heat is radiated from the two heater. The oven door must be
kept closed to prevent cooking odours from spreading in the kitchen and so as not to waste energy. The grill is
especially suitable for thin slices of meat and seafood as well as bread and meals.
Select Grill setting, set the time and start the oven. The food being grilled should normally be turned over after half
the grilling time. When the oven door is opened, the program is interrupted. Turn the food over, place it back the
oven, close the door and restart oven. While grilling, the oven door can be opened at any time to check the food.
Press Power Level Example of Use
once Grill 1 (HIGH) Slice meat or poultry pieces
twice Grill 2 (MEDIUM) Seafood
3 times Grill 3 (LOW) Garlic bread, toast
1. Press to select grill setting.
(see chart below)
2. Set desired cooking time by
pressing the Time pads.
(up to 99 minutes and
50 seconds)
3. Press Start.
The cooking time
appears in the display
window and begins to
count down.
Guidelines
Accessories to use
1. Use the Wire Rack provided.
2. Do not attempt to preheat the grill.
3. Most meat items e.g. sausages, chops can be cooked on the hottest setting Grill 1. This setting is also
suitable for toasting bread, muffins and tea cakes etc.
4. Grill 2 is used for those that require a longer grill time e.g. fish or chicken portions.
5. Never cover the food when grilling.
6. Always use oven gloves when removing the food and Wire Rack after grilling as they will be very hot.
7. After grilling it is important that the Wire Rack is removed for cleaning before reuse and that the oven walls
and floor are wiped with a cloth squeezed in hot soapy water to remove any grease.
8.
You can increase the cooking time during cooking if required. Time can be increased in 1 minute increments,
up to 10 minutes. Press
'
Add Time
'
pad once, then press
'
1 min
'
pad to a maximum of 10 minutes. After
selecting
'
Add Time
'
function, time should be added within a 5 second period. Cooking time can not be
decreased during cooking.
When grilling, you can place foods directly on Wire Rack with a heatproof dish underneath. Or you can place
food directly onto a metal or heatproof container, then placed on the glass tray.
Wire Rack with a heatproof
dish underneath
metal or heatproof container
- Eng-14 -
- Eng-15 -
English
Guidelines
Accessories to use
Combination Setting
There are three power levels for this feature. It’s a good way for roasting foods by combining microwave and grill
effectively.
It’s suitable for roasting poultry, meat and seafood. This function can ensure the foods even cooking and keep
the crispness of certain foods. Please open the door and turn over the foods when half of the cooking time, then
continue cooking.
When cooking, you can place foods directly on the base of the oven in a microwaveable and heatproof dish. Or
you can place foods directly on Wire Rack with a microwaveable and heatproof dish underneath.
Press Power Level Example of Use
once Combination 1 (HIGH) Whole poultry
twice Combination 2 (MEDIUM) Beef, lamb, seafood
3 times Combination 3 (LOW) Baked potatoes, puddings
1. Press to select
combination setting.
(see chart below)
2. Set desired cooking time by
pressing the Time pads.
(up to 99 minutes and
50 seconds)
3. Press Start.
The cooking time
appears in the display
window and begins to
count down.
1. Never cover the food when cooking.
2. Always use oven gloves when taking out the food.
3. Do not use if operating the oven with less than 200 g of food on a manual program. For small quantities do
not cook by combination mode, cook by grill only for best results.
4. Do not preheat on combination mode.
5.
You can increase the cooking time during cooking if required. Time can be increased in 1 minute increments,
up to 10 minutes. Press
'
Add Time
'
pad once, then press
'
1 min
'
pad to a maximum of 10 minutes. After
selecting
'
Add Time
'
function, time should be added within a 5 second period. Cooking time can not be
decreased during cooking.
Wire Rack with a microwaveable
and heatproof dish underneath
microwaveable and
heatproof dish
- Eng-16 -
- Eng-17 -
English
To Cook Using the Quick 30 Function
1. Press Quick 30 to set the desired
cooking time (up to 5 minutes).
Each press is 30 seconds.
Time appears in the display. Power
level is pre-set at 1000 W.
This function allows you to quickly set cooking time in 30 second increments.
Note
1. This function is only available for Microwave. Select desired micro power level before
pressing Quick 30.
2. After setting the time by Quick 30, you cannot use the Time pads.
This feature allows you to add cooking time at the end of previous cooking.
Note
1. This function is only available for Microwave, Grill, Combination and Timer function and it is
not available for Turbo Defrost and Auto Cook.
2. The Add Time function will not operate after 1 minute cooking.
3. The Add Time function can be used after the 3-stage cooking.
4. The power level is the same as the last stage.
3. Press Start.
Time will be added.
The time in the display
window will count down.
2. Add cooking time by pressing the
Time pads.
Maximum cooking time:
Microwave: 1000 W up to 30 minutes;
other powers up to 99 minutes and
50 seconds; Grill, Combination: up to
99 minutes and 50 seconds.
Using the Add Time Function
2. Press Start.
The cooking will start and the time
in the display will count down.
At the end of cooking, five beeps
will sound.
1. After cooking, press 'Add
Time' pad.
- Eng-16 -
- Eng-17 -
English
Note
1. Use a microwave safe cup.
2. Heated coffee/milk can erupt if not mixed with air. Do not heat coffee/milk in your
microwave oven without stirring before and halfway through heating.
3. Care must be exercised not to overheat coffee/milk when using the coffee/milk feature. It
is programmed to give proper result when heating 1 cup or 2 cups of coffee/milk, starting
from room temperature for coffee and refrigerator temperature for milk. Overheating will
cause an increased risk of scalding, or water eruption.
4. 1 cup of milk is 200 ml to 250 ml and 1 cup of coffee is 150 ml to 200 ml.
Auto Cook Setting — To Use Beverage
This feature allows you to reheat coffee/milk without setting micro power and time.
Press
Beverage
Menu Number
(Press
/ Pad)
Menu
1x
1-1 1 cup coffee
1-2 2 cups coffee
2x
2-1 1 cup milk
2-2 2 cups milk
1. Put the beverage
into the oven
2. Press Beverage Pad
Press once to reheat
coffee. Press twice to
reheat milk.
4. Press Start.
Cooking time
appears in the
Display Window
and begins to
count down.
3. Select the Weight of
beverage by pressing the
/ Pads
For example: To reheat
2 cups coffee press
Beverage Pad once, then
press " " Pad twice.
- Eng-18 -
- Eng-19 -
English
Note
1. The room temperature surrounding the oven should be below 35 °C.
2. Be sure the glass tray, the outside of the cooking containers and the inside of the
microwave are dry before placing food in the oven. Residual beads of moisture turning into
steam can mislead the sensor.
3. Food should always be covered loosely, but completely, with plastic warp. (Do not use any
snap closing lids.)
4. DO NOT open the oven door until 2 beeps sound and cooking time appears in the display
Window. Doing so will cause inaccurate cooking since the steam from food is no longer
contained within the oven cavity. Once the cooking time begins to count down, the oven
door may be opened to stir, turn, or rearrange foods.
5. All food should have a covered stand time of at least 3 to 5 minutes.
6. If cavity is overheated, " " appears in the display window, then cannot use this
function. Operate again after " " disappear.
7. Food being reheated should weigh between 125 g and 1.0 kg. For foods weighing less than
125 g and more than 1.0 kg, use a manual micro power setting.
Sensor Cook Setting
The Sensor Cooking features enable you to cook a variety of foods at Sensor of a pad. There is no need to select
the power level or cooking time as the foods are automatically cooked by detecting a build-up of steam on the
humidity sensor. As foods cook in a microwave, steam is produced. When foods are covered, the steam will build
up and escape from the dish and burst. This burst of steam is detected by the humidity sensor and then the oven
automatically calculate the remaining cooking time. All you need to do is to select the correct cooking category.
1. Select desired menu
number by pressing
this pad.
2. / (More/Less) Pads (Optional*):
Preferences for food doneness vary
with each individual. After having
using Sensor Cook a few times, you
may decide you would prefer your
food cooked to a different doneness.
By using the
/ (More/Less)
pads, the programs can be adjusted
to cook food for a longer or shorter
time. *If you are satisfied with the
result of the Sensor program, you
don't have to use this pad.
3. Press Start.
Menu No.
Menu Category Recommended Weight Range
3 Sensor Reheat
125 g - 1.0 kg
4 Vegetables
125 g - 500 g
5 Root Vegetables
125 g - 1.0 kg
6 Fish
125 g - 500 g
7 Chicken
400 g - 1.0 kg
Press
- Eng-18 -
- Eng-19 -
English
Sensor Cook Setting (continued)
3. Sensor Reheat
All foods must be pre-cooked. Suitable for casseroles,
plate dinners, stews, pasta dishes (except lasagne).
Foods should be stored in refrigerator or at room
temperature. Do not reheat frozen foods on this
setting. Do not reheat in foil or plastic containers.
All foods should be covered with lid or plastic wrap.
Open the door to STIR WHEN TWO BEEPS HEARD
during cooking, press Start Pad to continue.
4. Vegetables
It is suitable for cooking all types of leaf, green
and soft varieties, including broccoli, squash,
cauliflower, cabbage, asparagus, beans, celery,
zucchini, spinach, capsicum or a mixture of these.
Cut all vegetables into the same size pieces.
Place vegetable in a suitable size microwave safe
casserole. Add 1 tablespoon to ¼ cup water if you
prefer a softer cooked texture. Butter, herbs etc. may
be added before heating, but do not add salt until
serving. Cover with lid or plastic wrap. Open the door
to STIR WHEN TWO BEEPS HEARD during cooking,
press Start Pad to continue.
5. Root Vegetables
Suitable for cooking root vegetables such as
potatoes, sweet potatoes, pumpkin, onions, swede,
carrots, turnip and beetroot. All vegetables should
be trimmed or prepared and cut into even sized
pieces. Place vegetable in a suitable size microwave
safe casserole. Add 1 tablespoon to ¼ cup of water
to vegetables if you prefer a softer cooked texture.
Cover with lid or plastic wrap. If desired, butter, herbs
etc. may be added but do not add salt until after
cooking. Open the door to STIR WHEN TWO BEEPS
HEARD during cooking, press Start Pad to continue.
At the completion of cooking, stir larger quantities of
vegetables. Let stand, covered, for 2 to 3 minutes.
6. Fish
It is suitable for cooking whole fish and fish fillets.
Put the prepared fish in a microwave safe dish.
Add sauce and water. Cover with plastic wrap. After
cooking large portions of fish, allow the fish to stand 3
to 5 minutes before serving.
(It may be necessary to adjust the amount of water or
sauce to your personal preference.)
Shield the eye and tail area of whole fish with small
amounts of aluminum foil to prevent overcooking.
Note:
Thickness of fish should not be more than 3 cm.
7. Chicken
It is suitable for cooking chicken pieces, such as
wings, drumsticks, thighs, half breasts etc. Chicken
pieces should be thawed completely before cooking.
Pierce the chicken pieces and marinate with gravy
or vegetables if needed. Put the prepared chicken
pieces in a microwave safe casserole. Add oil if you
prefer a softer cooked texture. Cover dish securely
with lid or plastic wrap. Open the door to STIR WHEN
TWO BEEPS HEARD during cooking, press Start
Pad to continue.
- Eng-20 -
- Eng-21 -
English
Auto Cook Setting — Others
Press
Menu No.
Menu Category Weight
Recommended containers
or accessory
8 Bread
50 g 100 g 150 g 200 g
Microwave safe dish
9 Chinese Bun
70 g 100 g 150 g 200 g
Microwave safe dish with
plastic wrap
10 Sausages
50 g 100 g 150 g 200 g
Microwave safe dish with
plastic wrap
11 Frozen Vegetables
120 g 180 g 250 g 370 g
Casserole with lid or plastic
wrap
Press
Menu No.
Menu Category Weight
Recommended containers
or accessory
12 Casserole Rice
100 g 200 g 300 g
Casserole with lid
13 Congee
100 g 200 g 300 g
Casserole with lid
14 Instant Noodles 1 serv. 2 servs. - Casserole with lid
15 Double Boil 4-6 serv. 1-3 servs. - Casserole with lid
Press
Menu No.
Menu Category Weight
Recommended containers
or accessory
16 Roast Chicken
600 g 900 g 1200 g 1500 g
Microwave safe container with
upturned dish
17 Roast Beef/Lamb
200 g 400 g 600 g 800 g
Wire rack with dish underneath
18 BBQ Meat Pieces
200 g 400 g 600 g 800 g
Wire rack with dish underneath
19 Reheat Fried Foods
50 g 150 g 350 g 500 g
Wire rack with dish underneath
1. Select desired menu number.
Press to select the desired pad
until the desired menu number
appears in the display window.
2. Select the Weight of food
by pressing
/ pads.
(see chart below)
3. Press Start.
The cooking time
appears in the display
window and begins to
count down.
or
or
- Eng-20 -
- Eng-21 -
English
Note
1. When you select an Auto Cook program, the auto and cooking function indicators light and
menu number appear in the display.
2. Only cook foods within the weight ranges described.
3. Always weigh the food rather than relying on the package information.
4. Most foods benefit from a standing time, after cooking with an Auto Cook Program, to allow
heat to continue conducting to the centre.
Auto Cook Setting — Others (continued)
Press
Menu No.
Menu Category Weight
Recommended containers
or accessory
20
Cream Cheese
50 g 100 g 150 g 200 g 250 g 300 g
Microwave safe dish with
plastic wrap
21
Chocolate
50 g 100 g 150 g 200 g 250 g 300 g
Microwave safe dish
22
Butter
50 g 100 g 150 g 200 g 250 g 300 g
Microwave safe dish with
plastic wrap
23
Ice Cream
300 g 600 g 900 g 1200 g
- - -
8. Bread
It is suitable for reheating bread at freezing
temperature (-18 °C). Put the bread on a suitable size
microwave safe dish on glass tray. Cook without cover.
Select the program and weight then press Start.
Note: 50 g = one standard slice of bread.
9. Chinese Bun
It is suitable for reheating buns such as frozen creamy
custard bun, etc., Place food on a microwave safe dish
in a radial pattern, sprinkle with some water. Put the
food on a suitable size microwave safe dish on glass
tray, Cover with plastic wrap. Select the program and
weight then press Start.
See the chart below.
Note: 35- 40 g= one standard piece of bun.
10. Sausages
It is suitable for reheating frozen sausages, put the food
on a microwave safe dish in a radial pattern, without
cover. Select the program and weight then press Start.
See the illustration below.
11. Frozen Vegetables
Suitable for all types of frozen vegetables, like
frozen peas, sweet corn or mixed vegetables. Place
prepared vegetables into a container, add 1 tbsp. of
water per 100 g of vegetables, and cover with lid or
plastic wrap. Do not add salt/butter until after cooking.
(Not suitable for vegetables in butter or sauce.) Select
the program and weight then press Start. Open the
door to STIR WHEN TWO BEEPS HEARD during
cooking, press Start Pad to continue.
12. Casserole Rice
It is suitable for cooking white rice including short, long
grain, jasmine and basmati. Place rice in a suitable
size microwave safe casserole. Add recommended
water listed below. Allow at least ½ depth of volume for
evaporation to prevent boiling over. Partially cover with
lid. Select the program and weight then press Start.
Open the door to STIR WHEN TWO BEEPS HEARD
during cooking, press Start Pad to continue. Stand 5
minutes covered after cooking.
Rice will boil over if the casserole is too small. This
setting is not suitable for cooking brown rice.
Rice
Recommended
Water
Recommended
casserole
volume
100 g 250 ml 2.25 L
200 g 400 ml 3 L
300 g 600 ml 4 L
- Eng-22 -
- Eng-23 -
English
Auto Cook Setting — Others (continued)
13. Congee
It is suitable for cooking congee/porridge. Place the
rice in a suitable size microwave safe casserole. Add
recommended water listed below. Allow at least ½
depth of volume for evaporation to prevent boiling
over. Partially cover with lid. Select the program
and weight then press Start. Open the door to STIR
WHEN TWO BEEPS HEARD during cooking, press
Start Pad to continue. Stand 5-10 minutes covered
after cooking.
Congee
Recommended
Water
Recommended
casserole volume
100 g 750 ml 2.25 L
200 g 1100 ml 3 L
300 g 1700 ml 4 L
14. Instant Noodles
It is suitable for cooking instant noodles. Place the
instant noodles and seasonings in a suitable size
microwave safe casserole. Add recommended boiling
tap water listed below. Allow at least ½ depth of
volume for evaporation to prevent boiling over. Cover
with lid. Select the program and weight then press
Start. Open the door to STIR WHEN TWO BEEPS
HEARD during cooking, press Start Pad to continue.
Stand 1-2 minutes after cooking.
Serving Recommended hot tap water
1 Serv. 450 ml
2 Servs. 800 ml
15. Double Boil
It is suitable for cooking traditional soups; herbal
soup, bird nest soup, etc., that requires slow simmer
or "double boil". This method ensures food remains
tender without losing its shape. It also extracts
and retains the aromatic flavor of the food. Place
all ingredients in a microwave safe casserole. Add
recommended ingredients listed below. Allow at least
½ depth of volume for evaporation to prevent boiling
over. Cover with lid. Select the program and weight
then press Start. Open the door to STIR WHEN TWO
BEEPS HEARD during cooking, press Start Pad to
continue, add salt at the end of cooking.
Serving
Recommended
tap water
Meat Vegetables
4-6 servs. 1000 ml 500 g 400 g
1-3 servs. 700 ml 250 g 200 g
16. Roast Chicken
It is suitable for roasting whole chicken. Pierce and
marinate the chicken before roasting. Put the prepared
chicken onto an upturned saucer in a microwave
safe dish with chicken breast side down. Select the
program and weight then press Start. Open the door
to TURN OVER WHEN TWO BEEPS HEARD during
cooking, press Start Pad to continue.
17. Roast Beef/Lamb
It is suitable for cooking beef and lamb. Meat may be
cooked with gravy and vegetables. Place prepared
beef/lamb on a wire rack with dish underneath. Select
the program and weight then press Start. Open the
door to TURN OVER WHEN TWO BEEPS HEARD
during cooking, press Start Pad to continue.
Note: Meat should be thawed completely. Thickness
of meat should not be more than 2 cm.
18. BBQ Meat Piece
It is suitable for cooking meat pieces. Cut the meat
into thin pieces. Pierce the meat pieces and marinate
with gravy or vegetables if needed. Place prepared
meat pieces on a wire rack with dish underneath.
Select the program and weight then press Start.
Open the door to TURN OVER WHEN TWO BEEPS
HEARD during cooking, press Start Pad to continue.
19. Reheat Fried Foods
It is suitable for reheating most kinds of fried foods,
like fried chicken, curry puffs, fried spring rolls and
etc. Arrange fried foods on a wire rack with dish
underneath. Select the program and weight then press
Start. Open the door to TURN OVER WHEN TWO
BEEPS HEARD during cooking, press Start Pad to
continue.
20. Cream Cheese
Remove wrapper, cut cheese into 3 cm cube, and
place in a microwave safe bowl/dish. Cover with
plastic wrap. Select the program and weight then
press Start. If food needs more time cooking or weight
exceeds range, cook using Defrost for melting.
21. Chocolate
Remove wrapper, separate chocolate into small
pieces, and place into a microwave safe dish. Cook
without cover. Select the program and weight then
press Start. After heating, stir until completely melted.
If food needs more time cooking or weight exceeds
range, cook using Defrost for melting.
Note: Chocolate holds its shape even when softened.
22. Butter
Remove wrapper, cut butter into 3 cm cube, and place
into a microwave safe dish. Melt with plastic wrap.
Select the program and weight then press Start. Stir
after cooking. If food needs more time cooking or
weight exceeds range, cook using Defrost for melting.
23. Ice Cream
Soften slightly without lid. Select the program and
weight then press Start. If food needs more time
cooking or weight exceeds range, cook using Defrost
for melting.
Note
The Symbols " ", " ", " " on page 19, 21-22 are intended to prompt you which features
are used during cooking. "
" will not be display on the display window.
: Combination : Grill : Microwave
- Eng-22 -
- Eng-23 -
English
Timer Setting (Kitchen Timer/Standing Time/Delay Start)
To Use as a Kitchen Timer
Press once.
Select desired time by pressing
the Time pads.
(up to 99 minutes and 50 seconds)
Press Start.
Time will count down
without oven operating.
To Set Standing Time
Set the desired
cooking program.
Press Start.
Cooking will start. After
cooking, standing time will
count down without oven
operating.
Select desired time by pressing
the Time pads.
(up to 99 minutes and 50 seconds)
Press once.
To Set Delay Start
Set the desired
cooking program.
Press once.
Select desired delay time by
pressing the Time pads.
(up to 99 minutes and 50 seconds)
Press Start.
Delayed time will count
down. Then cooking will
start.
Note
1. If oven door is opened while Standing Time, Delay Start or Kitchen Timer has been set, the
time in the display window will continue to count down.
2. Delay Start and Standing Time can not be programmed together with Turbo Defrost and Auto
Cook. This is to prevent the standing temperature of the food from rising before defrosting or
cooking begins. A change in the starting temperature could cause in accurate results.
3. When using Standing Time or Delay Start, it’s up to 2 Power stages.
- Eng-24 -
- Eng-25 -
English
3-Stage Setting
Example: Continually set [Combination 1] 9 minutes, [Combination 3] 13 minutes and [Grill 2]
2 minutes.
1. Press once.
(See page 15 for
directions.)
5. Press twice.
(See page 14
for directions.)
2. Set as 9 minutes
by pressing the
Time pads.
3. Press 3 times.
(See page 15
for directions.)
4. Set as 13 minutes
by pressing the
Time pads.
7. Press.
The time will count
down at the first stage
in the display window.
6. Set as 2 minutes
by pressing the
Time pads.
Note
1. When operating, two beeps sound will be heard between each stage.
2. This feature is not available for Turbo Defrost and Auto Cook.
Cook 300 g fish fillets Roast 1 kg whole chicken
1-stage 600W 3'00" Combination1 9'00"
2-stage 440W 2'00" Combination3 13'00"
3-stage 300W 2'00" Grill 2 2'00"
Example to use
- Eng-24 -
- Eng-25 -
English
Food Characteristics
Microwaves are a form of high frequency
electromagnetic waves (app. 12 cm wave length)
similar to those used by a radio. Electricity is
converted into microwave energy by the magnetron
tube. The microwaves travel from the magnetron
tube to the oven cavity where they are reflected,
transmitted or absorbed.
Reflection
Microwaves are reflected by
metal just as a ball is bounced
off a wall. A combination of
stationary (interior walls) and
rotating metal (glass tray or
stirrer fan) helps assure that the
microwaves are well distributed
within the oven cavity produce
even cooking.
Transmission
Microwaves pass through some
materials such as paper, glass
and plastic much like sunlight
shining through a window.
Because these substances
do not absorb or reflect the
microwave energy, they are
ideal materials for microwave
oven cooking containers.
Absorption
Microwaves are absorbed by
food. They penetrate to a depth
of about 2-4 cm. Microwave
energy excites the molecules
in the food (especially water,
fat and sugar molecules), and
causes them to vibrate very
quickly.
The vibration causes friction and heat is produced. In
large foods, the heat which is produced by friction is
conducted to the center to finish cooking the food.
Microwaves and How They Work
FOOD CHARACTERISTICS
Food characteristics which affect conventional
cooking are more pronounced with microwave
heating.
Size –– Small portions cook faster than large ones.
Shape –– Uniform
sizes heat
more evenly. To
compensate for
irregular shapes,
place thin pieces
toward the centre
of the dish and
thicker pieces toward the edge of dish.
Starting Temperatures –– Room temperature foods
take less time to heat up than refrigerator frozen
foods.
Bone and Fat ––
Both affect heating.
Bones may cause
irregular heating.
Large amounts of fat
absorb microwave
energy and meat
next to these areas
may overcook.
Density –– Porous, airy foods take less time to heat
than heavy, compact foods.
- Eng-26 -
- Eng-27 -
English
Cooking Techniques
Timing
A range in heating time is given in each recipe.
The time range compensates for the uncontrollable
differences in food shapes, starting temperature
and regional preferences. Always cook food for the
minimum cooking time given in the recipe and check
for doneness. If the food is undercooked, continue
cooking. It is easy to add time to an undercooked
product. Once the food is overcooked, nothing can be
done!
Spacing
Individual foods, such as baked potatoes, cupcakes
and hors d’oeuvres, will heat more evenly if placed in
the oven equal distance
apart. When possible,
arrange foods in a
circular pattern.
Similarly, when placing foods in a baking dish,
arrange around the outside of dish, not lined up next
to each other. Food
should NOT be stacked
on top of each other.
Piercing
The skin or membranes on some foods will cause
steam to build up during microwave cooking. Foods
must be pierced, scored or have a strip of skin peeled
off before cooking to allow steam to escape.
Eggs:
Pierce egg yolk twice
and egg white several
times with a toothpick.
Whole Clams and Oyster:
Pierce several times with a toothpick.
Whole Potatoes and Vegetables: Pierce with a fork.
Frankfurters and Sausages: Score smoked polish
sausage and frankfurters. Pierce fresh sausage with
a fork.
Browning
Foods will not have the same brown appearance as
conventionally cooked foods or those foods which
are cooked utilizing a browning feature. Meats
and poultry may be coated with browning sauce,
Worcestershire sauce, barbecue sauce or shake-on
browning sauce. To use, combine browning sauce
with melted butter or margarine; brush on before
cooking.
For quick breads or muffins, brown sugar can be
used in the recipe in place of granulated sugar, or
the surface can be sprinkled with dark spices before
baking.
Covering
As with conventional cooking moisture evaporates
during microwave cooking. Because microwave
cooking is done by time and not direct heat, the rate
of evaporation cannot be easily controlled. This,
however, can be easily corrected by using different
materials to cover dishes. However, unless specified,
a recipe is heated uncovered. Casserole lids or cling
film are used for a tighter seal. Various degrees of
moisture retention are also obtained by using wax
paper or paper towels.
Stirring
Stirring is usually necessary during microwave
cooking. We have noted when stirring is helpful, using
the words once, twice, frequently or occasionally to
describe the amount of stirring required. Always bring
the cooked outside edges toward the centre and the
less cooked centre portions toward the outside.
- Eng-26 -
- Eng-27 -
English
Cooking Techniques (continued)
Turning and Rearranging
It is not possible to stir some foods to redistribute the
heat. At times, microwave energy will concentrate
in one area of a food. To help ensure even cooking,
some foods need to be turned or rearranged. Turn
over large foods such as roasts or turkeys. Generally,
they are turned over once halfway through heating.
Rearrange small items such as chicken pieces,
shrimp or hamburger patties. Rearrange pieces from
the edge to the centre and pieces from the center to
the edge of the dish.
Standing Time
Most foods will continue to cook by conduction after
the microwave oven is turned off. In meat cookery,
the internal temperature will rise 5 °C if allowed to
stand, covered, for 10-20 minutes.
Casseroles and vegetables need a shorter amount of
standing time, but this standing time is necessary to
allow foods to complete cooking in the center without
overcooking on the edges.
Testing for Results
The same test for doneness used in conventional
cooking may be used for microwave cooking.
Cakes are done when a wooden stick comes out
clean and cake pulls away from side of the pan.
Chicken is done when juices are clear yellow and
drumstick moves freely.
Meat is done when fork tender or splits at fibres.
Fish is done when it flakes and is opaque.
Converting Favorite Recipes
Select recipes that convert easily to microwave
cooking such as casseroles, stews, baked chicken,
fish and vegetable dishes. The results from foods
such as cooked soufflles or two-crust pies would be
less than satisfactory. Never attempt to deep fat fry in
your microwave oven. A basic rule, when converting
conventional recipes to microwave recipes, is to cut
the suggested cooking time to a quarter. Also, find
a similar microwave recipe and adapt that time and
power setting. Season meats with herbs and spices
(and half the salt) before cooking; the rest of the salt
after cocking.
Stews are not browned before cooking. Omit any oil
or fat that would be used for browning. Cut stew meat
into 2.5 cm pieces. Cut carrots, potatoes and other
firm vegetables into small pieces. Carrots should be
thinly sliced and potatoes cut into dice.
Cover with glass lid and cook at 1000 W to bring
liquid to a boil and cook at 100 W until tender. Stir
occasionally. Note: A small plate placed on top of
the meat and vegetables will help stop the meat
overcooking.
Casseroles microwave cook well. Cut foods into
uniform pieces. Condensed soup makes a good base
for casseroles.
Select a dish that is large enough to allow for stirring.
Cooking covered with a glass lid or cling film reduces
cooking time. Stir occasionally during cooking. To
keep crumb topping crisp sprinkle on before stand
time.
Heating Frozen Foods
Most frozen convenience foods have microwave
heating directions on the back of the package. Refer
to these directions for recommended power levels,
heating times and general instructions.
General Directions for Heating Frozen
Convenience Foods
Pierce pouch vegetables or entrees with a fork or
knife. Place pouch in a dish before heating.
Frozen foods in metal containers deeper than
2 cm such as lasagna or baked stuffed potatoes,
must be removed from the foil container and placed
in an appropriately sized microwave-safe container.
Heat covered with a lid or plastic wrap.
NOTE: If food is difficult to be removed from
container, rinse the bottom of the container with hot
water.
To heat frozen dinner in foil containers, remove
dinner from box, if there is a foil cover, remove it.
Some foods, such as bread, French fries or batter
type desserts such as brownies, do not microwave
well. Remove these types of food from tray. Cover
tray except desserts with plastic wrap. Heat
according to manufacturers’ directions. Place foil tray
in the center of the oven. Foil tray should not touch
oven walls or other metals. Leave at least 2-3 cm
space between foil tray and oven walls. Heat only 1
foil tray in the oven at a time.
- Eng-28 -
- Eng-29 -
English
DEFROST
Preparing Foods for Freezing
The finished quality of the prepared food will depend
on the original quality before freezing, the care the
food receives during freezing, and the techniques and
times used for defrosting. Select fresh, good quality
food and freeze as soon as possible after purchasing.
Heavy-duty plastic wraps and bags, and freezer wrap
are suitable for use in the freezer. Meats may also
be frozen in their store packaging for short periods of
time.
Notes: If aluminum foil is used for wrapping, all
pieces of foil must be removed before defrosting
prevent arcing.
When WRAPPING FOR FREEZING, arrange meat,
poultry, fish and seafood in thin uniform layers.
Package minced meat in 2.5-5 cm thick rectangular,
square or round shapes.
Remove giblets from fresh whole poultry. (The giblets
may be frozen separately, if desired.) Clean and dry
poultry. Tie legs and wings with string.
Remove all air before sealing plastic bags. LABEL
package with type and cut of meat, date and weight.
FREEZE foods in a freezer which is maintained at -
18 °C or lower. Defrosting time given in the charts on
page 29 are for thoroughly frozen foods. (i.e. foods
should be frozen at least 24 hours before defrosting)
DEFROST
To use, select 300 W and program the defrosting
time. Follow defrosting times and directions given in
this section and page 29.
Techniques for Defrosting
1) Foods should be frozen in moisture and vapor
proof wrapping materials. Small items such as
chops, hamburger patties, fish fillets, poultry
pieces etc. should be frozen in 1 or 2 pieces
layers.
2) Remove original wrapper. Set meat on a
microwave roasting rack placed in a dish. Set
300 W and heat for the time recommended in the
chart on page 29.
3) Turn over meat or poultry two or three times
during defrost. Shield edges and unevenly
shaped ends of roasts halfway through the defrost
cycle.
4) Halfway through the defrost cycle, break apart
ground beef, shrimp, scallops or crab meat.
Separate chops or poultry pieces and remove
meat that is defrosted.
5) Large roast, or whole poultry may still be icy in
center. Allow to stand.
Cooking Techniques (continued)
- Eng-28 -
- Eng-29 -
English
Defrosting Chart
The times given below are a guideline only. Always check the progress of the food by opening the oven
door and then re-starting. For larger quantities adjust times accordingly. Food should not be covered
during defrosting.
Food Weight/Quantity Time & Mode Method
Beef/Lamb/Joint (1) (3) 450 g (1 lb) 300 W 6-8 mins standing 30 mins
Steaks (1) (3) 2 pcs 250 g 300 W 3-4 mins standing 3 mins
Minced beef (1) (3) 450 g (1 lb) 300 W 6-7 mins standing 5 mins
Stewing steak (1) (3) 450 g (1 lb) 300 W 6-8 mins standing 10 mins
Whole chicken (1) (3) 450 g (1 lb) 300 W 5-7 mins standing 10 mins
Chicken portions (1) (3) 450 g (1 lb) 300 W 6-8 mins standing 5 mins
Whole Fish (1) (3) 450 g (1 lb) 300 W 6-8 mins standing 5 mins
Fish Fillets (2) (3) 450 g (1 lb) 300 W 5-7 mins standing 5 mins
Prawns (2) (3) 450 g (1 lb) 300 W 4-6 mins standing 5 mins
Fruits, Soft (1) 250 g 300 W 2-3 mins standing 2 mins
Margarine (3) 250 g 300 W 1-2 mins standing 2 mins
Cheese (3) 450 g (1 lb) 300 W 2-4 mins standing 2 mins
Plated Meals Homemade
Adult Size (2)
350 g 300 W 5-6 mins standing 3-5 mins
Cooked Fruit (2) 540 g 300 W 4-5 mins standing 3-5 mins
Cooked Meat (2) 520 g 300 W 6-8 mins standing 3-5 mins
Quiche (3) 1 pc 65 g 300 W 1-2 mins standing 2 mins
Casseroles (1) 750 g 1000 W 6-7 mins standing 3-5 mins
Bread rolls (1) 1 pc 85 g 1000 W 20-30 secs standing 5 mins
Brioche large (1) (3) (4) 1 pc 400 g
Combination 2; 3 mins
30 secs
standing 5 mins
Croissants (1) (4) 2 pcs 100 g
Combination 2; 1 min-
1 min 30 secs
Add 1 min grill 1 for more
crispness
Pastry puff (1) (3) 1 roll 375 g
300 W 2 mins-
2 mins 30 secs
Stand time 20 mins in
refrig erator
Pastry shortcrust (1) (3) 1 roll 500 g 300 W 4-5 mins
Stand time 20 mins in
refrig erator
Pizza dough (1) (3) 1 ball 240 g
300 W 2 mins-
2 mins 30 secs
standing 10 mins
Doughnuts (1) (4) 2 pcs 100 g
Combination 2; 1 min-
1 min 30 secs
Stand 3 mins in oven
Waffles (1) (4) 2 pcs 40 g
Combination 2; 1 min-
1 min 30 secs
Add 1 min grill 1 for more
crispness
Fruit tarte (3) 470 g 300 W 4-5 mins standing 5 mins
(1) Turn or stir at half time.
(2) Separate and turn several times.
(3) Remove packaging and place on a heat resistant plate.
(4) Place on wire rack, if required in a heatproof dish.
- Eng-30 -
- Eng-31 -
English
Reheating Chart
The times given in the charts below are a guideline only, and will vary depending on starting temperature,
dish size etc.
Food Weight/Quantity Time & Mode Method
Drinks-Coffee-Milk
Coffee 1 mug 235 ml 1000 W 1 min 30 secs
Stir before, and after
reheating.
Coffee 2 mugs 470 ml
1000 W 2 mins 30 secs-
3 mins
Milk 1 mug 235 ml
1000 W 1 min 20 secs-
1 min 30 secs
Breads
Croissants
1 pc 50 g
1000 W 10-20 secs or Grill
1; 3 mins-3 mins 30 secs
Place on microwave safe
plate on glass tray. Do
not cover. If using grill
mode, use wire rack or
heatproof plate. Turn at
half time.
2 pcs 100 g
1000 W 30-40 secs or
Grill 1; 4 mins
Rolls
1 pc
1000 W 10-20 secs or Grill
1; 3 mins-3 mins 30 secs
4 pcs
1000 W 30-40 secs or
Grill 1; 4-5 mins
Naan Bread 225 g 1000 W 30-40 secs
Do not cover. Turn at half
time.
Pitta Bread 2 pcs 1000 W 20-30 secs
Plated meals-Homemade
Vegetables (cooked)
300 g
1000 W 2 mins-
2 min 30 secs
Cover. Stir at half time.
700 g
1000 W 5 min-
5 mins 30 secs
Potato puree 500 g 1000 W 3-4 mins
Rice, quinoa, couscous 300 g
1000 W 2 mins-
2 mins 20 secs
Babyfood 120 g 600 W 30-40 secs
Canned Food
Baked Beans 225 g
1000 W 1 min 30 secs-
2 min
Place in a microwave
safe bowl on glass tray.
Cover. Stir halfway.
Spaghetti in tomato
sauce
200 g 1000 W 1 min 30 secs
Cream of tomato soup 400 g 1000 W 2 mins 30 secs
Chicken soup 425 g 1000 W 3 mins 30 secs
Pastry Products
Quiche 400 g
1000 W 2-3 mins or
Combination 2; 4-6 mins
Place on microwave
safe plate on glass tray.
Do not cover. If using
combination mode, use
heatproof plate.
Samosas/spring rolls 4 pcs 240 g
1000 W 1-1 min 30 secs or
Combination 2; 5-6 mins
Purchased Convenience Foods
Cottage pie (chilled) 450 g
1000 W 5-6 mins or
Combination 2; 12-15 mins
Place on microwave
safe plate on glass tray.
Do not cover. If using
combination mode, use
heatproof plate.
Lasagne (chilled) 400 g
1000 W 7-8 mins or
Combination 2; 10-12 mins
Shepherd’s pie (Frozen) 450 g
1000 W 3-4 mins then
Combination 2; 22-25 mins
- Eng-30 -
- Eng-31 -
English
Cooking Chart
Food Weight/Quantity Time & Mode Method
Beans & Pulses-should be pre-soaked (except lentils)
Chick peas 225 g
1000 W 8 mins then
440 W 35-40 mins
Use 600 ml (1 pt) boiling
water in a large bowl.
Cover. Stir halfway.
Lentils 225 g 440 W 15-20 mins
Red kidney beans 225 g
1000 W 15 mins then
440 W 35-40 mins
Fresh vegetable, slice, chop into even sized pieces. Place in microwave safe dish.
Asparagus 200 g 1000 W 4-5 mins
Add 30 ml (2 tbsp)
of water, cover. Stir
halfway.
Broccoli 250 g 1000 W 3-4 mins
Potatoes 250 g 1000 W 4-5 mins
Lamb/Beef-from raw-Caution: Hot Fat! Remove dish with care.
Chops 450 g (1 lb) Combination 2; 10 mins
Place on wire rack
with heatproof plate
underneath. Turn
halfway.
Joint 450 g (1 lb)
600 W 10-13 mins then
Combination 1; 6-10 mins
Place on upturned saucer
in microwave safe dish
or rack on glass tray.
Cover and turn joint over
halfway. Drain off fat
during cooking. Uncover
when using Combination
mode.
Pasta-Place in a large 3 litre (6 pints) microwave safe bowl
Macaroni 225 g 1000 W 13-15 mins Use 1 litre (1¾ pints)
boiling water. Cover. Stir
halfway.
Spaghetti, Tagliatellie 225 g 1000 W 11-12 mins
Pizza-Fresh chilled- N.B. Remove all packaging. Pizza will have a soft base.
Thin & Crispy 300 g
1000 W 2-3 mins or
Combination 2; 10-12 mins
Place on heatproof plate
on glass tray. Do not
cover.
If using combination
mode, please use wire
rack.
Deep Pan 400 g
1000 W 4-6 mins or
Combination 2; 10-12 mins
Potato Products Part Cooked-Frozen
Croquettes 300 g Combination 2; 12-13 mins
Place on wire rack on
glass tray. Turn halfway.
Waffles 2 pcs 120 g Grill 1; 14 mins
Sausages-from raw-Caution: Hot Fat! Remove dish with care.
Thick 4 pcs 240 g
1000 W 2-3 mins or
Combination 2; 8-10 mins
Place on microwave
safe plate on glass
tray. Cover. If using
combination/grill mode,
use wire rack. Do not
cover. Turn halfway.
Thin 4 pcs 120 g
1000 W 1 min 30 secs-
2 mins 30 secs or
Grill 1; 7-8 mins
Note
Always check that food is piping hot after reheating in the microwave. If unsure, return to
oven. Foods will still require a stand time, especially if they cannot be stirred. The denser the
food the longer the stand time.
- Eng-32 -
- Eng-33 -
English
Before Requesting Service
ALL THESE THINGS ARE NORMAL:
The oven causes interference with
my TV.
Some radio, TV, Wi-Fi, cordless telephone, baby monitor, blue tooth
or other wireless equipment interference might occur when you cook
with the microwave oven. This interference is similar to the interference
caused by small appliances such as mixers, vacuums, hair dryers, etc.
It does not indicate a problem with your oven.
Steam accumulates on the oven
door and warm air comes from the
oven vents.
During cooking, steam and warm air are given off from the food. Most
of the steam and warm air are removed from the oven by the air which
circulates in the oven cavity. However, some steam will condense on
cooler surfaces such as the oven door. This is normal and safe. Steam
will disappear after the oven is cool down.
I accidentally operate my microwave
oven without any food in it.
Operating the oven empty for a short time will not damage the oven.
However, we do not recommend this to be done.
There are humming and clicking
noises from my oven when I cook
by Combination.
These noise occur as the oven automatically switch the Grill. This is
normal.
The oven has an odor and
generates smoke when using
Combination and Grill function.
It is essential that your oven is wiped out regularly particularly after
cooking by Combination or Grill. Any fat and grease that builds up on
the roof and walls of the oven will begin to smoke if not cleaned.
Some smoke will be given off
from the cavity when using Grill,
Combination, for the first time.
It caused by the excessive oil in the cavity and oil used for rust
protection volatilizing.
PROBLEM POSSIBLE CAUSE REMEDY
Oven will not turn on.
The oven is not plugged firmly.
Remove plug from outlet, wait
10 seconds and re-insert.
Circuit breaker or fuse is tripped
or blown.
Contact the specified service center.
There is a problem with the
outlet.
Plug another appliance into the outlet
to check if the outlet is working.
Oven will not start
cooking.
The door is not closed completely. Close the oven door securely.
Start Pad was not pressed after
programming.
Press Start Pad.
Another program has already
been entered into the oven.
Press Stop/Reset Pad to cancel the
previous program and program again.
The program has not been
entered correctly.
Program again according to the
Operating Instructions.
Stop/Reset Pad has been
pressed accidentally.
Program oven again.
When the oven is turning
on, there is noise coming
from Glass Tray.
The roller ring and oven bottom
are dirty.
Clean these parts according to care
of your oven (See next page).
The “
” appears in the
display window.
The Child Safety Lock was activated
by pressing Start Pad 3 times.
Deactivate Lock by pressing Stop/
Reset Pad 3 times.
“H00”, “H97” or “H98” appears
in the display window.
The display indicates a problem
with microwave generation system.
Contact the specified service centre.
"
" appears in the
display window.
The cavity is overheated. Operate again after it cools down.
If it seems there is a problem with the oven, contact an authorized Service Center.
- Eng-32 -
- Eng-33 -
English
1. Turn the oven off and remove the power plug
from the wall socket before cleaning, if possible.
2. Keep the oven cavity clean. When food splatters
or spilled liquids adhere to oven walls, wipe with
a damp cloth. Mild detergent may be used if the
oven gets very dirty. The use of harsh detergent
or abrasives is not recommended.
3. The outside oven surfaces should be cleaned
with a damp cloth. To prevent damage to the
operating parts inside the oven, water should not
be allowed to seep into the ventilation openings.
4. Do not allow the Control Panel to become
wet. Clean with a soft, damp cloth. Do not use
detergents, abrasives or spray-on cleaners on the
Control Panel. When cleaning the Control Panel,
leave oven door open to prevent oven from
accidentally turning on. After cleaning press Stop/
Reset Pad to clear display window.
5. If steam accumulates inside or around the outside
of the oven door, wipe with a soft cloth. This may
occur when the microwave oven is operated
under high humidity conditions and in no way
indicates malfunction of the unit.
6. It is occasionally necessary to remove the glass
tray for cleaning. Wash the tray in warm sudsy
water or in a dishwasher.
7. The roller ring and oven cavity floor should be
cleaned regularly to avoid excessive noise. Simply
wipe the bottom surface of the oven with mild
detergent, water or window cleaner and dry.
The roller ring may be washed in mild sudsy water
or dish washer. Cooking vapors collect during
repeated use but in no way affect the bottom
surface or roller ring wheels. When removing the
roller ring from cavity floor for cleaning, be sure to
replace in the proper position.
8. When using the GRILL or cooking in the
COMBINATION mode, some foods may inevitably
splatter grease on to the oven walls. If the oven is
not cleaned, occasionally it may start to “smoke”
during use. These marks will be more difficult to
clean later.
9. After GRILL or COMBINATION cooking the
ceiling and walls of the oven should be cleaned
with a soft cloth squeezed in soapy water.
Particular care should be taken to keep the
window area clean particularly after cooking
by GRILL or COMBINATION. Stubborn spots
inside the oven can be removed by using a small
amount of microwave oven cleaner sprayed onto
a soft damp cloth. Wipe onto problem spots,
leave for recommended time and then wipe off.
Avoid cleaning oven door and the microwave
feed guide area situated on the right hand side of
the cavity wall.
DO NOT SPRAY DIRECTLY INSIDE THE OVEN.
A steam cleaner is not to be used for cleaning.
10. When it becomes necessary to replace the oven
light, please consult a dealer to have it replaced.
11. The oven should be cleaned regularly and any
food deposits removed.
Care of your Microwave Oven
* IEC Test Procedure
Specifications subject to change without notice.
As for the voltage requirement, the production month, country and serial number, please refer to the
identification plate on the microwave oven.
Technical Specifications
Model name:
NN-GT65JB NN-GT69JS
Power Supply: 220 V 50 Hz 230 - 240 V 50 Hz
Power Consumption: Microwave 4.8 A 1050 W 4.5 A 1050 W
Grill 5.3 A 1160 W 4.9 A 1160 W
Combination 8.8 A 1920 W 8.2 A 1950 W
Cooking Power: Microwave* 1000 W
Grill 1100 W
Outside Dimensions (W × H × D): 525 mm × 310 mm × 414 mm
Oven Cavity Dimensions (W × H × D): 359 mm × 247 mm × 362 mm
Overall Cavity Volume: 31 L
Glass Tray Diameter: Ø340 mm
Operating Frequency: 2450 MHz
Uncrated Weight: Approx. 13.2 kg
Trim Kit
Model Number:
NN-TK612GSQP
Outside Dimensions (W × H): 596 mm (W) × 410 mm (H)
Cabinet Opening (W × H × D): 562 mm (W) × 395 mm (H) × 480 mm (D)
