Samsung ME6144W 40L 1000W Microwave

User Manual - Transcript

• Page 1: Code No DE6803248A Microwave Oven Owners Manual ME6124W ME6124ST ME6144W ME6144ST ME6124WXSA03248AENfm Page 1 Friday March 31 2006 1121 AM
• Page 2 - English - : Safety RECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY Failure to observe the following safety precautions may result in harmful exposure to microwave energy a Do not attempt to operate this oven with the door open since open door operation can result in harmful exposure to microwave energy It is important not to defeat or tamper with the safety interlocks b Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces c Do not operate the oven if it is damaged It is particularly important that the oven door close properly and that there is no damage to the 1 Door bent or dented 2 Hinges and latches broken or loosened 3 Door seals and sealing surfaces d The oven should not be adjusted or repaired by anyone except properly qualified service personnel Safety Precautions Important Safety Instructions Read Carefully and keep for future reference Before cooking food or liquids in your microwave oven please check that the following safety precautions are taken DO NOT use any metallic cookware in the microwave oven Metallic containers Dinnerware with gold or silver trimmings Skewers forks etc Reason Electric arcing or sparking may occur and may damage the oven DO NOT heat Airtight or vacuumsealed bottles jars containers Ex Baby food jars Airtight food Ex Eggs nuts in shells tomatoes Reason The increase in pressure may cause them to explode Tip Remove lids and pierce skins bags etc DO NOT operate the microwave oven when it is empty Reason The oven walls may be damaged Tip Leave a glass of water inside the oven at all times The water will absorb the microwaves if you accidentally set the oven going when it is empty DO NOT cover the rear ventilation slots with cloths or paper Reason The cloths or paper may catch fire as hot air is evacuated from the oven ALWAYS use oven gloves when removing a dish from the oven Reason Some dishes absorb microwaves and heat is always transferred from the food to the dishThe dishes are therefore hot DO NOT touch heating elements or interior oven walls Reason These walls may be hot enough to burn even after cooking has finished even though they do not appear to be so Do not allow inflammable materials to come into contact with any interior area of the oven Let the oven cool down first To reduce the risk of fire in the oven cavity Do not store flammable materials in the oven Remove wire twist ties from paper or plastic bags Do not use your microwave oven to dry newspapers If smoke is observed keep the oven door closed and switch off or disconnect the oven from the power supply Take particular care when heating liquids and baby foods ALWAYS allow a standing time of at least 20 seconds after the oven has been switched off so that the temperature can equalize Stir during heating if necessary and ALWAYS stir after heating Take care when handling the container after heating You may burn yourself if thecontainer is too hot A risk of delayed eruptive boiling exists ME6124WXSA03248AENfm Page 2 Friday March 31 2006 1121 AM
• Page 3 - English - : Safety Precautions To prevent delayed boiling and possible scalding you should put a plastic spoon or glass stick into the beverages and stir before during and after heating Reason During the heating of liquids the boiling point can be delayed this means that eruptive boiling can start after the container is removed from the oven You may scald yourself In the event of scalding follow these FIRST AID instructions Immerse the scalded area in cold water for at least 10 minutes Cover with a clean dry dressing Do not apply any creams oils or lotions NEVER fill the container to the top and choose a container that is wider at the top than at the bottom to prevent the liquid from boiling over Bottles with narrow necks may also explode if overheated ALWAYS check the temperature of baby food or milk before giving it to the baby NEVER heat a babys bottle with the teat on as the bottle may explode if overheated Be careful not to damage the power cable Do not immerse the power cable or plug in water and keep the power cable away from heated surfaces Do not operate this appliance if it has a damaged power cable or plug Stand at arms length from the oven when opening the door Reason The hot air or steam released may cause scalding Keep the inside of the oven clean Reason Food particles or spattered oils stuck to oven walls or floor can cause paint damage and reduce the efficiency of the oven You may notice a Clicking sound during operationespecially when the oven is in defrosting Reason This sound is normal when the electrical power output is changing When the microwave oven is operating without any load the power will be cut off automatically for safety You can operate the oven normally after letting it stand for over 30 minutes IMPORTANT SAFETY INSTRUCTIONS During cooking you should look into the oven from time to time when food is being heated or cooked in disposable containers of plastic paper or other combustible materials IMPORTANT Young children or infirm persons should NEVER be allowed to use or play with the microwave oven Nor should they be left unattended near the microwave oven when it is in use Items of interest to children should not be stored or hidden just above the oven WARNING If the door or door seals are damaged the oven must not be operated until it has been repaired by a competent person WARNING It is hazardous for anyone other than a comperent person to carry out any service or repair operation which involves the removal of a cover which gives protection against exposure to microwave energy WARNING Liquids and other foods must not be heated in sealed containers since they are liable to explode WARNING Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use Please recycle or dispose of the packaging material for this product in an environmentally responsible manner Please contact your local authorities in regard to the enviromentally safe disposal of this product ME6124WXSA03248AENfm Page 3 Friday March 31 2006 1121 AM
• Page 4 - English - : Installing Your Microwave Oven Place the oven on a flat level surface that strong enough to safely bear the weight of the oven Never block the air vents as the oven may overheat and automatically switch itself off It will remain inoperable until it has cooled sufficiently For your personal safety plug the cable into a 3pin 240 Volt 50Hz AC earthed socket If the power cable of this appliance is damaged it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard Do not install the microwave oven in hot or damp surroundings like next to a traditional oven or radiator The power supply specifications of the oven must be respected and any extension cable used must be of the same standard as the power cable supplied with the oven Wipe the interior and the door seal with a damp cloth before using your microwave oven for the first time How a Microwave Oven Works Cooking Principle As the centre of the food is cooked by heat dissipation cooking continues even when you have taken the food out of the oven Standing times specified in recipes and in this booklet must therefore be respected to ensure Even cooking of the food right to the centre The same temperature throughout the food Your New Microwave oven Checking Parts Unpack your microwave oven and check to make sure that you have all the parts shown here If any part is missing or broken call your dealer Warranty and Service Information When contacting Samsung please provide the specific model and serial number infor mation which is usually located on the back or bottom of the product Please record these numbers below along with the other requested information Keep this informa tion in a safe place as a permnent record of your purchase to aid in identification in case of theft or loss and a copy of your sales receipt as a proof of purchase if waranty service is needed MODEL NUMBER SERIAL NUMBER DATE PURCHASED PURCHASED FROM Warranty service can only be performed by a Samsung Authorized Service Center If you should require warranty service provide the above information with a copy of your sales receipt to the Samsung Authorized Service Center Setting Up Your Microwave Oven Place the oven on a flat sturdy surface and plug the cord into a grounded outlet once plugged in the display on your oven will show Make sure there is adequate ventilation for your oven by leaving at least four inches of space behind above and to the side of the oven Open the oven door by pulling on the handle Wipe the inside of the oven with a damp cloth Place the preassembled ring in the indentation in the center of the oven Place the glass tray on top of the ring so that the three glass tabs in the center of the tray fit securely into the tabs on the floor of the oven When you install your oven make sure there is adequate ventilation for your oven by leaving at least 10 cm 4 inches of space behind and on the sides of the oven and 20 cm 8 inches of space above Remove all packing materials inside the oven Install the roller ring and turntable Check that the turntable rotates freely The microwaves generated by the magnetron are distributed uniformly as the food rotates on the turntable The food is thus cooked evenly The microwaves are absorbed by the food up to a depth of about 1 inch 25 cm Cooking then continues as the heat is dissipated within the food Cooking times vary according to the container used and the properties of the food Quantity and density Water content Initial temperature refrigerated or not 20cm above 10cm behind 10cm on the side Microwave oven Glass tray Roller guide ring kg g Oz Lbs QTY ME6124WXSA03248AENfm Page 4 Friday March 31 2006 1121 AM
• Page 5 - English - : Your New Microwave oven Control Panel Buttons Model ME6124W ME6124ST Model ME6144W ME6144ST 1 Clock 2 Sound 3 One Touch Sensor Cook Buttons 4 BeverageINSTANT COOK 5 Auto Cook Menus 6 Auto Defrost 7 Number Button 8 Power Level 9 PauseCancel 10 One Minute 11 Pizza Reheat INSTANT COOK 12 Auto Reheat 13 MoreLess 14 Kitchen Timer 15 Start 1 Clock 2 Sound 3 One Touch Sensor Cook Buttons 4 Pizza Reheat INSTANT COOK 5 Auto Cook Menus 6 Auto Defrost 7 Number Button 8 Power Level 9 PauseCancel 10 One Minute 11 Beverage INSTANT COOK 12 Custom Cook 13 Auto Reheat 14 MoreLess 15 Kitchen Timer 16 Start ME6124WXSA03248AENfm Page 5 Friday March 31 2006 1121 AM
• Page 6 - English - : Your New Microwave oven Table of Content Safety 2 Safety Precautions 2 Installing Your Microwave Oven 3 How a Microwave Oven Works 3 Your New Microwave oven 4 Checking Parts 4 Warranty and Service Information 4 Setting Up Your Microwave Oven 4 Control Panel Buttons 5 Table of Content 6 Operation 6 Setting the Clock 6 Using the PauseCancel Button 6 Using the One Minute Button 6 Using the Sensor Cook Buttons 6 Sensor Cooking Guide 7 Using the Instant Cook Buttons 7 Using the RicePasta Buttons 7 Using the MeatFish Buttons 8 Using the Snack Bar Button 9 Reheating Automatically 9 Defrosting Automatically 9 Setting and Using the Custom Cook Button 10 Programming the Custom Cook button 10 Using the Custom Cook button 10 Setting Cooking Times amp Power Levels 10 Demonstration Mode 10 Using the MoreLess Buttons 10 Switching the Beeper OnOff 10 Using the Kitchen Timer 10 Setting the Child Protection Lock 10 Power Saving Feature 10 Cooking Instructions 11 Cooking Utensils 11 Cooking Techniques 11 General Tips 11 Auto Sensor Cook 15 Utensils amp Cover For Sensor Cooking 15 Important 15 Cooking Guide 15 Auto Defrosting Guide 13 Recipes 14 Appendix 15 Troubleshooting Guide 15 Care and Cleaning 15 Error Message 15 Specifications 16 Operation Setting the Clock Press the Clock button The ENTER and TIME indicators flash Use the number buttons to enter the current time You must press at least three numbers to set the clock If the current time is 500 enter 500 When 5 seconds has elapsed ENTER indicator flash and Cloc will be displayed Press Clock again A colon will blink indicating that the time is set If there is a power interruption you will need to reset the clock You can check the current time while cooking is in progress by pressing the Clock button Using the PauseCancel Button The PauseCancel button allows you to clear instructions you have entered It also allows you to pause the ovens cooking cycle so that you can check the food To pause the oven during cooking press PauseCancel once To restart press Start To stop cooking erase instructions and return the oven display to the time of day press PauseCancel twice To correct a mistake you have just entered press PauseCancel once then re enter the instructions Using the One Minute Button This button offers a convenient way to heat food in one minute increments at the High power level Press the One Minute button once for each minute you wish to cook the food For example press it twice for two minutes The time will display and the oven starts automatically Add minutes to a program in progress by pressing the One Minute button for each minute you want to add Using the Sensor Cook Buttons By actually sensing the steam that escapes as food heat this feature automatically adjusts the ovens heating time for various types and amounts of precooked food All food should be precooked and at refrigerator temperature Press the Sensor Cook button corresponding to the food you are cooking Popcorn for example The display shows and your microwave oven will begin cooking automatically When cooking popcorn wait at least five minutes between each bag to avoid overheating the glass tray If you want to check the current time while cooking is in progress press the Clock button ME6124WXSA03248AENfm Page 6 Friday March 31 2006 1121 AM
• Page 7 - English - : Operation Sensor Cooking Guide Follow the instructions below when sensor cooking different types of food Using the Instant Cook Buttons Press the Instant Cook button corresponding to the food you are cooking Beverage for example The display shows the first serving size ENTER and QTY will flash Press the button repeatedly to select the serving size you want The display will cycle through all available serving sizes Once you select the correct serving size the microwave will begin cooking automatically When the cooking time is over the oven will beep The oven will then beep every minute Using the RicePasta Buttons Press the RicePasta button corresponding to the food you are cooking The display shows A1item code Press the RicePasta button repeatedly to select the item you wantRefer to the RicePasta Chart below Press the Number or b ut t o n t o s el e c t th e se r v i n g s i z e yo u w a nt Refer to the RicePasta Chart below for the serving Press Start button to begin cooking RicePasta Chart Food Amount Procedure Popcorn 85g 100g 1 package Use only one microwaveonly bag of popcorn at a time Use caution when removing and opening hot bag from oven Let oven cool for at least 5 minutes before using again Potatoes 1 to 6 EA Prick each potato several times with fork Place on turntable in spokelike fashion Let stand 35 min Let oven cool for at least 5 minutes before using again Fresh Vegetables 1 to 4 cups Place fresh vegetables in microwavesafe dish and add 2 Tbsp of water Cover with microwave safe plastic wrap or lid Using the glass cover gives the best results If using plastic wrap be sure to leave a small opening near the edge of dish for ventilation Remove vegetable from oven let sit covered for 2 minutes stir or serve Let oven cool for at least 5 minutes before using again Single Entrees 220g 400g Remove food from outer wrapping and follow box instructions for covering and standing Let oven cool for at least 5 minutes before using again Item Weight Remarks Beverage ½ cup 1 cup 2 cups Use measuring cup or mug do not cover Place the beverage in the oven After heating stir well Pizza reheat 1 Slice 2 Slices 3 Slices 4 Slices Put the pizza on a microwavesafe plate with wide end of slice towards the outside edge of the plate Do not let slices overlap Do not cover Before serving let stand 12 min Code Item Weight Initial Temperature Remarks A1 White Rice 12 serves RiceRoom WaterRoom Wash rice with cold water until water runs clear Place the rice and water in a microwavesafe rice cooker or round glass Pyrex dish with a lid and after cooking allow rice to stand without removing lid Stand rice for 35 minutes and stir to separate grains A2 Dry Pasta 12 serves Water boiling water Place dry pasta into microwavesafe rice cooker or bowl or round Glass Pyrex dish breaking if necessary to fit without lids on and cook uncovered After cooking put on lid allow standing time of 25 minutes Stir and serve A3 Frozen Pasta 12 serves Water boiling water Place frozen pasta into microwavesafe rice cooker or bowl or round Glass Pyrex dish without lids on and cook uncovered After cooking put on lid allow standing time of 25 minutes Stir and serve A4 Fresh Pasta 12 serves Water boiling water Place fresh pasta into microwavesafe rice cooker or bowl or round Glass Pyrex dish without lids on and cook uncovered After cooking put on lid allow standing time of 25 minutes Stir and serve A5 Spaghetti 12 serves Water boiling water Place dry spaghetti into microwavesafe rice cooker or bowl or round Glass Pyrex dish breaking if necessary to fit without lids on and cook uncovered After cooking put on lid allow standing time of 25 minutes Stir and serve A6 2 Minute noodle 13 serves Water boiling water Break noodle cake and place into a microwavesafe large bowl Pour boiling water over noodles and cook uncovered After oven beeps at half cooking time stir well and press start to continue After cooking and then standing time of two minutes stir and serve A7 Porridge 12 serves Porridge oats Room Waterampmilk Cold Place dry porridge oats and water or milk in a microwave safe bowl and cook uncovered After oven beeps stir the oats well and press start to continue After cooking stir well and top with brown sugar or honey 1Serv 2Serv Rice 100g 200g Water 250ml 375ml 1Serv 2Serv Pasta 100g 200g Water 3cups 5cups 1Serv 2Serv Pasta 125g 250g Water 3cups 5cups 1Serv 2Serv Pasta 125g 250g Water 3cups 5cups 1Serv 2Serv Sp agh etti 100g 200g Water 3cups 5cups 1 Serv 2 Serv 3 serv Noodle 1 packet 2 packets 3 packets Wa ter 500 ml 1000 ml 1500 ml 1Serv 2Serv Oats 35g 70g Water amp Milk 185 m l 375ml ME6124WXSA03248AENfm Page 7 Friday March 31 2006 1121 AM
• Page 8 - English - : Operation Using the MeatFish Buttons Press the MeatFish button corresponding to the food you are cooking The display shows A1item code Press the MeatFish button repeatedly to select the item you wantRefer to the MeatFish Chart below Press the Number or b ut t o n t o s el e c t t he s e r vi n g s iz e yo u w a nt Refer to the MeatFish Chart below for the serving Press Start button to begin cooking MeatFish Chart MeatFish Chart Code Item Weight Initial Tempe rature Remarks A1 Chicken Breast 200 250g 300 350g 400 450g Refrige rated Select fresh chicken breasts score insert 34 cuts with a sharp knife along breast and cook plain or firstly marinate with you favorite flavor for two hours or overnight covered in the refrigerator Or sprinkle breasts with soy sauce or lemon juice or your favorite shaker herbs salt or pepper Then cover breasts with baking paper tucked in on plate or in Pyrex dish and cook At half cooking time oven will beep turn breasts over and press start to continue After cooking stand breasts for 35 minutes Serve A2 Fish Fillet 150 200g 250 300g 350 400g Refrige rated Select fresh fish fillets and cook plain or marinate with you favorite seafood marinade for two hours or overnight covered in the refrigerator Or sprinkle fillets with lemon juice or your favorite shaker herbs especially lemon pepper seasoning salt or pepper Then cover fillets with baking paper tucked in on plate or in Pyrex dish and cook After cooking stand filletss for 3 minutes Serve Code Item Weight Initial Tempe rature Remarks A3 Sea Food 150 200g 250 300g 350 400g Refrig erated Select fresh seafood and set out on microwavesafe plate or Pyrex dish Sprinkle with lemon juice or salt if desired cover seafood with baking paper eg Glad Bake tucked in around and cook After cooking stand seafood for 3 minutes Serve A4 Casserole 1 dish Refrig erated Ingredients For casserole 2 medium carrots 85g to 110g Before peeling 2 medium onions 110g to 140g Before peeling 2 medium potatoes165g to 195g before peeling 450 ground chuck beef teaspoon salt cup water teaspoon pepper Peel and slice vegetables into inch thick slices Form beef into 12 small flat pattie using the 2inch Reynolds Brass Ring Flattern patties In 2quart casserole layer half of beef patties half of carrots half of onions and half of potatoes Springkle with salt and pepper Repeat layers making sure that top layer of beef patties is completely covered with vegetables Add water Press layer down into casserole Cover After cooking stand casserole for 5 minutes Serve A5 Bacon 100 125g 200 225g 300 325g Refrig erated Select fresh bacon rashers from your butcher deli or supermarket Place on the absorbent paper towel on microwavesafe plate or Pyrex dish and cover with another piece of paper towel and cook Serve A6 Meatball 1 dish Refrig erated Ingredients For Meat Balls 450 g ground beefcup chopped onion1 egg beaten 1 teaspoon salt teaspoon pepper and 2 tabl espoons waterCombine all ingredients and mix well Shape into 20 x 25mm meat balls Place meat balls in utensil Cover with microwave cling wrap turning back one corner of the wrap by about 50mm to vent Cook After cooking stand meat balls for 5 minutes Serve A7 Meat loaf 1 dish Refrig erated Ingredients For meat loaf 675g ground chuck beef cup fine dry bread crumbles cup chopped onion cup chopped green pepper 1 cup milk1 egg 2 tablespoons ketchup teaspoon pepper cup teaspoon salt Combine all ingredients mix well Pack meat mixture firmly in loaf dish smooth out top Cover with plastic wrap turning back one corner about 2 inches to vent Place in oven parallel to front of oven After cooking stand casserole for 5 minutes Serve ME6124WXSA03248AENfm Page 8 Friday March 31 2006 1121 AM
• Page 9 - English - : Operation Using the Snack Bar Button Press the Snack Bar button corresponding to the food you are cooking The display shows A1item code Press the Snack Bar button repeatedly to select the item you wantRefer to the Snack Bar Chart below Press the Number or button to select the serving size you want Only the 1 buttonserving is available for TORTILLA Refer to the Snack Bar Chart below for the serving Press Start button to begin cooking Snack Bar Chart Defrosting Automatically To thaw frozen food set the weight of the food and the microwave automatically sets the defrosting time power level and standing time Press the Auto Defrost button The display shows 1 ENTER and kg will flash To set the type of your food press the Auto Defrost button repeatedly You can also use the number buttons to enter the weight of the food directly It is possible to set up to a maximum of 2 kgexcept to bread Press the Start button The display will show cooking time during defrosting the oven will beep to let you know to turn the food over Open the oven door and turn the food over Press the start button to resume defrosting See page 13 for the Auto Defrosting Guide Reheating Automatically To reheat food select the type of dish and the number of servings you want to reheat and the microwave automatically sets the reheating time Press the Auto Reheat button repeatedly to select the type of dish you wish to reheat The initial serving size for each dish is one serving You can select up to four cups for casseroles and pasta Rice tinned reheat Only one serving is available for a plate of food The display shows the dish and quantity you have chosen Use the number buttons to increase the serving size For example for three servings press the 3 buttonRefer to the Auto Reheat Chart below for the servings The display shows the number of servings you have selected Press the Start button The display will show Cooking Time Auto Reheat Chart Code Item Weight Initial Temperature Remarks A1 Tortilla 400g Refrigerated Cut top off tortilla bag remove moisture sachet and place bag of tortilla directly in center of microwave turntable Heat Use heated tortilla immediately as required A2 Chicken wings 45 PCS 810 PCS Refrigerated Place wings around plate spokefashion Cover with wax paper A3 Frozen Pie 5060g 100110g 150160g Frozen Place frozen party pies into microwave oven on microwavesafe plate or Pyrex dish uncovered Heat After cooking stand pies for 1 minute Serve A4 Baby Food 70g 110g 170g Room Remove metal top from room temperature jars of baby food Remove plastic lid and metal lid from cups of baby food replace lid discarding metal lid Place jar cup in center of turntable and microwave on high power until temperature is reached Stir well Serve The MoreLess key cannot be used with the baby food key A5 Garlic Bread 200g 400g 600g Refrigerated Remove garlic bread sticks from packaging and place into microwave oven on microwavesafe plate or Pyres dish Heat After cooking stand garlic bread sticks for 3 minutes to melt butter in centre completely Serve A6 Chicken Nuggets 4 PCS 8 PCS Refrigerated Put a paper on top of plate and arrange nuggets in spoke fashion on paper towel Do not cover Let stand 1 min A7 Potato Wedge 4 PCS 8 PCS Room Cut potato into 4 even wedges scoop or out potato flesh leaving about 14 inch of skin Place skins in spoke fashion around plate Sprinkle with bacon onions and Cheese Microwave on High power for until cheese is melted Item Code Weight Remarks Plate of food A1 1 serving Use only precooked refrigerated foods Cover plate with vented plastic wrap or wax paper Contents 85110 g meat poultry or fish up to 170 g with bone ½ cup starch potatoes pasta rice etc ½ cup vegetables about 85110 g Casserole A2 14 Cups Use only refrigerated foods Cover with lid or vented plastic wrap Stir foods well before serving Pasta Reheat A3 Rice Reheat A4 Tinned Soup A5 ME6124WXSA03248AENfm Page 9 Friday March 31 2006 1121 AM
• Page 10 - English - : Operation S etting and Using the Custom Cook Button ME6144WME6144ST Only The Custom Cook button memeoizes the time and power setting for a particular food Programming the Custom Cook button Press the Custom Cook button Press the button twice to delete the previous Custom setting The display shows ENTER and COOK TIME will flash Use the Number buttons to enter the amount of cooking time The display will show the amount of time you have set Press Power Level and use the Number buttons to enter the power level The display will show the power level you have set and The display will show CUST You can set the power level from 0 to 9 1 Warm 6 Simmer 2 Low 7 Medium High 3 Defrost 8 Reheat 4 Medium Low 9 Sauté 5 Medium 0 High Press the Custom Cook button again The display will read you setting are now stored in the ovens memory Using the Custom Cook button Press the Custom button after memorizing a recipe the press Start button You can check the power level while cooking is in progress by pressing the Power Level button Setting Cooking Times amp Power Levels Your microwave allows you to set up to two different stages of cooking each with its own time length and power level The power level button lets you control the heating intensity from Warm 1 to High 0 Onestage Cooking For simple onestage cooking you only need to set a cooking time The power level is auto matically set to High If you want to set the power to any other level you must set it using the Power Level button Use the number buttons to set a cooking time You can set a time from one second to 99 minutes 99 seconds To set a time over one minute enter the seconds too For example to set 20 minutes enter 2 0 0 0 If you want to set the power level to something other than High press the Power Level button then use the number buttons to enter a power level Power Levels 1 PL10 Warm 6 PL60 Simmer 2 PL20 Low 7 PL70 Medium High 3 PL30 Defrost 8 PL80 Reheat 4 PL40 Medium Low 9 PL90 Sauté 5 PL50 Medium 0 PLHi High Press the Start button to begin cooking If you want to change the power level press PauseCancel before you press Start and reenter all of the instructions Some recipes require different stages of cooking at different temperatures You can set mul tiple stages of cooking with your microwave Multistage Cooking Follow steps 1 and 2 in the OneStage Cooking section on the previous page When entering more than one cooking stage the Power Level button must be pressed before the second cooking stage can be entered To set the power level at High for a stage of cooking press the Power Level button twice Use the number buttons to set a second cooking time Press the Power Level button then use the number buttons to set the power level of the second stage of cooking Press Start to begin cooking You can check the Power Level while cooking is in progress by pressing the Power Level button Demonstration Mode You can use the Demonstration Mode to see how your microwave oven operates without the oven heating Hold the button and then press the button To turn demo mode off repeat step 1 above Using the MoreLess Buttons The MoreLess buttons allow you to adjust preset cooking times They only work in the RicePasta MeatFish Snack Bar Auto Reheat Pizza Reheat Beverage or Time Cook Kitchen Time modes Use the MoreLess but ton only after you have already begun cooking with one of these procedures The MoreLess feature cannot be used with the Sensor Cook button The MoreLess key cannot be used with the Auto defrost key To ADD more time to an automatic cooking procedure Press the More 9 button To REDUCE the time of an automatic cooking procedure Press the Less 1 button If you wish to increasedecrease in Time Cook Kitchen Time mode by 10sec press the More9 or Less1 button Switching the Beeper OnOff You can switch the beeper off whenever you want Press the Sound button The display shows ON START will flash Press the Sound button to turn the volume off The display shows OFFSTART will flash Press Start The display returns to the time of day Using the Kitchen Timer Press the Kitchen Timer button Use the Number buttons to set the length of time you want the timer to run Press Start to begin Kitchen Timer The display counts down and beeps when the time has elapsed Note The microwave does not turn on when the Kitchen timer is used Setting the Child Protection Lock You can lock your microwave oven so it cant be used by unsupervised children Hold the button and then press the button The display shows Loc At this point the microwave oven cannot be used until it is unlocked To unlock it repeat step 1 above Power Saving Feature After 5 minutes in standby status after cooking time or in current time display mode the display of the microwave oven is turned off At this time press any key to return to the previous state and to turn the display on again However the power saving feature does not turn the display off in the following status In case of Error1 Error2 Error3 or Error4 ME6124WXSA03248AENfm Page 10 Friday March 31 2006 1121 AM
• Page 11 - English - : Cooking Instructions Cooking Utensils Recommended Use Glass and glassceramic bowls and dishes Use for heating or cooking Microwavable browning dish Use to brown the exterior of small items such as steaks chops or pancakes Follow the directions provided with your browning dish Microwavable plastic wrap Use to retain steam Leave a small opening for some steam to escape and avoid placing it directly on the food Wax paper Use as a cover to prevent spattering Paper towels and napkins Use for shortterm heating and covering they absorb excess moisture and prevent spattering Do not use recycled paper towels which may contain metal and can catch fire Paper plates and cups Use for shortterm heating at low temperatures Do not use recycled paper which may contain metal and can catch fire Thermometers Use only those labeled Microwave Safe and follow all directions Check the food in several places Conventional thermometers may be used once the food has been removed from the oven Limited Use Aluminum foil Use narrow strips of foil to prevent overcooking of exposed areas Using too much foil can damage your oven so be careful Ceramic porcelain and stoneware Use these if they are labeled Microwave Safe If they are not labeled test them to make sure they can be used safely Never use dishes with metallic trim Plastic Use only if labeled Microwave Safe Other plastics can melt Straw wicker and wood Use only for shortterm heating as they can be flammable Not Recommended Glass jars and bottles Regular glass is too thin to be used in a microwave and can shatter Paper bags These are a fire hazard except for popcorn bags that are designed for microwave use Styrofoam plates and cups These can melt and leave an unhealthy residue on food Plastic storage and food containers Containers such as margarine tubs can melt in the microwave Metal utensils These can damage your oven Remove all metal before cooking Testing Utensils If you are not sure whether a dish is microwavesafe or not you can perform this test Fill a 1 cup glass measuring cup with water and put it inside your oven next to the dish you want to test Press the One Minute button once to heat them for one minute at High power The water should be warm and the dish you are testing should be cool If the dish is warm then it is absorbing microwave energy and is not acceptable for use in the microwave Cooking Techniques Stirring Stir foods such as casseroles and vegetables while cooking to distribute heat evenly Food at the outside of the dish absorbs more energy and heats more quickly so stir from the outside to the center The oven will turn off when you open the door to stir your food Arrangement Arrange unevenly shaped foods such as chicken pieces or chops with the thicker meatier parts toward the outside of the turntable where they receive more microwave energy To prevent overcooking place thin or delicate parts toward the center of the turntable Shielding Shield food with narrow strips of aluminum foil to prevent overcooking Areas that need shielding include poultry wingtips the ends of poultry legs and corners of square bak ing dishes Use only small amounts of aluminum foil Larger amounts can damage your oven Turning Turn foods over midway through cooking to expose all parts to microwave energy This is especially important with large items such as roasts Standing Foods cooked in the microwave build up internal heat and continue to cook for a few minutes after the oven stops Let foods stand to complete cooking especially foods such as roasts and whole vegetables Roasts need this time to complete cooking in the center without overcooking the outer areas All liquids such as soup or hot chocolate should be shaken or stirred when cooking is complete Let liquids stand a moment before serving When heating baby food stir well and test the temperature before serv ing Adding Moisture Microwave energy is attracted to water molecules Food that is uneven in moisture con tent should be covered or allowed to stand so that the heat disperses evenly Add a small amount of water to dry food to help it cook General Tips Dense foods such as potatoes take longer to heat than lighter foods Foods with a delicate texture should be heated at a low power level to avoid becoming tough Altitude and the type of cookware you are using can affect cooking time When using a new recipe use the minimum cooking time and check the food occasionally to prevent overcooking Foods with a nonporous skin such as potatoes or hot dogs should be pierced to prevent bursting Frying with heating oil or fat is not recommended Fat and oil can suddenly boil over and cause severe burns Some ingredients heat faster than others For example the jelly inside a jelly doughnut will be hotter than the dough Keep this in mind to avoid burns Home canning in the microwave oven is not recommended because all harmful bacteria may not be destroyed by the microwave heating process Although microwaves do not heat the cookware the heat from the food is often transferred to the cookware Always use pot holders when removing food from the microwave and instruct children to do the same Making candy in the microwave is not recommended as candy can heat to very high temperatures Keep this in mind to avoid injury ME6124WXSA03248AENfm Page 11 Friday March 31 2006 1121 AM
• Page 12 - English - : Cooking Instructions Auto Sensor Cook The Auto Sensor allows you to cook your food automatically by detecting the amount of moistures generated from the food while cooking When cooking food many kinds of moistures are generated The Auto Sensor determines the proper time and power level by detecting these moistures from the food eliminating the need to set the cooking time and power level When you cover a container with its lid or plastic wrap during Sensor Cooking the Auto Sensor will detect the moistures generated after the container has been saturated with steam Shortly before cooking ends the remaining cooking time will begin its count down This will be a good time for you to rotate or stir the food for even cooking if it is necessary Before auto sensor cooking food may be seasoned with herbs spices or browning sauces A word of caution though salt or sugar may cause burn spots on food so these ingredients should be added after cooking The MoreLess function pad is used to increase or decrease cooking time You should use this function to adjust the degree of cooking to suit your personal taste Utensils amp Cover For Sensor Cooking To obtain good cooking results with this function follow the directions for selecting appropriate containers and covers in the charts in this book Always use microwavesafe containers and cover them with their lids or with plastic wrap When using plastic wrap turn back one corner to allow steam to escape at the proper rate Always cover with the lid intended for the utensil being used If the utensil does not have its own lid use plastic wrap Fill containers at least half full Foods that require stirring or rotating should be stirred or turned toward the end of the Sensor Cook cycle after the time has started to count down on the display Important It its not advisable to use the auto sensor cooking feature on a continuous cooking operation ie one cooking operation immediately after another Install the oven in a well ventilated location for proper cooling and airflow and to ensure the sensor will operate accurately To avoid poor results do not use the Auto sensor when the room ambient temperature is too high or too low Do not use volatile detergent to clean your oven Moisture resulting from this detergent may affect the sensor Avoid placing the oven near high moisture or gas emitting appliances since this will interfere with the proper performance of the Auto Sensor Always keep the inside of the oven clean Wipe all spills with a damp cloth This oven is designed for household use only Cooking Guide Guide for Cooking Meat in Your Microwave Place meat on a microwavesafe roasting rack in a microwavesafe dish Start meat fatside down Use narrow strips of aluminum foil to shield any bone tips or thin meat areas Check the temperature in several places before letting the meat stand the recommended time The following temperatures are removal temperatures The temperature of the food will rise during the standing time Guide for Cooking Poultry in Your Microwave Place poultry on a microwavesafe roasting rack in a microwavesafe dish Cover poultry with wax paper to prevent spattering Use aluminum foil to shield bone tips thin meat areas or areas that start to overcook Check the temperature in several places before letting the poultry stand the recommended time Food Cook TimePower Level Directions Roast Beef Boneless Up to 4 lbs Cooking Time 812 min 05 kg for 50C Rare 913 min 05 kg for 55C Medium 1015 min 05 kg for 65C Well Done Power Level High0 for first 5 min then Medium5 Place roast fatside down on roasting rack Cover with wax paper Turn over when cooking time is half up Let stand 10 min Pork Boneless or bonein Up to 4 lbs Cooking Time 1216 min 05 kg for 70C Well Done Power Level High0 for first 5 min then Medium5 Place roast fatside down on roasting rack Cover with vented plastic wrap Turn over when cooking time is half up Let stand 10 min Food Cook TimePower Level Directions Whole Chicken Up to 4 lbs Cooking Time 710 min 05kg 80C Power Level Medium High7 Place chicken breastside down on roasting rack Cover with wax paper Turn over when the cooking time is half up Cook until juices run clear and meat near the bone is no longer pink Let stand 510 min Chicken Pieces Up to 2 lbs Cooking Time 710 min 05kg 80C dark meat 75C light meat Power Level Medium High7 Place chicken boneside down on dish with the thickest portions towards the outside of the dish Cover with wax paper Turn over when the cooking time is half up Cook until juices run clear and meat near the bone is no longer pink Let stand 510 min ME6124WXSA03248AENfm Page 12 Friday March 31 2006 1121 AM
• Page 13 - English - : Cooking Instructions Guide for Cooking Seafood in Your Microwave Cook fish until it flakes easily with a fork Place fish on a microwavesafe roasting rack in a microwavesafe dish Use a tight cover to steam fish A lighter cover of wax paper or paper towel provides less steaming Do not overcook fish check it at minimum cooking timeGuide for Cooking Eggs in Your Microwave Never cook eggs in the shell and never warm hardcooked eggs in the shell they can explode Always pierce whole eggs to keep them from bursting Cook eggs just until set they become tough if overcooked Guide for Cooking Vegetables in Your Microwave Vegetables should be washed just before cooking Often no extra water is needed If dense vegetables such as potatoes carrots and green beans are being cooked add about ¼ cup water Small vegetables sliced carrots peas lima beans etc will cook faster than larger ones Whole vegetables such as potatoes acorn squash or corn on the cob should be arranged in a circle on the turntable before cooking They will cook more evenly if turned over after half the cooking time Always place vegetables like asparagus and broccoli with the stem ends pointing towards the edge of the dish and the tips toward the center When cooking cut vegetables always cover the dish with a lid or vented microwavable plastic wrap Whole unpeeled vegetables such as potatoes squash eggplant etc should have their skin pricked in several spots before cooking to prevent them from bursting For more even cooking stir or rearrange whole vegetables halfway through the cooking time Generally the denser the food the longer the standing time Standing time refers to the time necessary for dense large foods and vegetables to finish cooking after they come out of the oven A baked potato can stand on the counter for five minutes before cooking is completed while a dish of peas can be served immediately Auto Defrosting Guide Follow the instructions below when defrosting different types of food Notes Check foods when the oven signals After the final stage small sections may still be icy let them stand to continue thawing Do not defrost until all ice crystals have thawed Shielding roasts and steaks with small pieces of foil prevents the edges from cooking before the center of the food has defrosted Use narrow flat smooth strips of aluminum foil to cover the edges and thinner sections of the food Food Cook TimePower Level Directions Steaks Up to 07 kg Cooking Time 711 min 05 kg Power Level Medium High7 Arrange steaks on roasting rack with meaty portions towards the outside of rack Cover with wax paper Turn over and rearrange when cooking time is half up Cook until fish flakes easily with a fork Let stand 35 min Fillets Up to 07 kg Cooking Time 48 min 05 kg Power Level Medium High7 Arrange fillets in a baking dish turning any thin pieces under Cover with wax paper If over ½ inch thick turn over and rearrange when cooking time is half up Cook until fish flakes easily with a fork Let stand 23 min Shrimp Up to 07 kg Cooking Time 46½ min 05 kg Power Level Medium High7 Arrange shrimp in a baking dish without overlapping or layering Cover with wax paper Cook until firm and opaque stirring 2 or 3 times Let stand 5 min Code Item Weight Initial Temperature Remarks Meat 1002000g 2060 mins Shield the sdges with aluminium foil Turn the meat over when the over beeps This programme is suitable for beef lamb pork steaks chops minced meat Poultry 1002000g 2060 mins Shield the leg and wing tios with aluminium foil Turn the poultry over when the oven beeps This programme is suitable for whole shicken as well as for chicken portions Fish 1002000g 2050 mins Shield the tail of a whole fish with aluminium foil Turn the fish over when the oven beeps This programme is suitable for whole fishes as well as for fish fillets Sea Food 1002000g 2050 mins Shield the tail of a whole fish with aluminium foil Turn the fish over when the oven beeps This programme is suitable for shrimp prawn shell fish clarn Bread Cake 100700g 530 mins Put bread on a piece of kitchen paper and turn over as soon as the oven beeps Place cake on a ceramic plate and if possible turn over as soon as the oven beeps Oven keeps operating and is stoppde when you open the door This programme is suitable for all kinds of bread slicde or whole as well as for bread rolls and baguettes Arrange bread rolls in a circle This programme is suitable for all kinds of yeast cake biscuit cheese cake and puff pastry It is not suitable for shortcrust pastry fruit and cream cakes as well as for cake with chocolate topping ME6124WXSA03248AENfm Page 13 Friday March 31 2006 1121 AM
• Page 14 - English - : Cooking Instructions Recipes Beef and Barley Stew 675 g beef stew cubes cut into ½inch pieces ½ cup chopped onion 2 Tbs allpurpose flour 1 Tbs Worcestershire sauce 1 can 380405g beef broth 2 medium carrots cut into ½inch slices about 1 cup ½ cup barley 1 bay leaf ¼ tsp pepper 1 pkg 250280g frozen peas thawed In a 2quart casserole combine beef onion flour and Worcestershire mix well Cover with lid Cook at High0 for 6 to 8 minutes until beef is no longer pink stirring once Stir in beef broth carrots barley bay leaf and pepper Cover with lid Cook at Medium for 1 to 1½ hours until carrots and beef are tender stirring 2 to 3 times Stir in peas Cover with lid Cook at Medium for 10 minutes Let stand for 10 minutes Remove bay leaf before serving Makes 6 servings Broccoli and Cheese Casserole ¼ cup butter or margarine ¼ cup chopped onion 1½ Tbs flour ½ tsp salt ¼ tsp dry mustard 18 tsp pepper 1½ cups milk ¼ cup chopped red pepper 225g 2 cups cheddar cheese shredded 1 pkg 250280g frozen chopped broccoli thawed 4 cups cooked spiral shaped pasta 225g dry In a 2quart casserole cook butter and onion at High0 for 1 to 2 minutes until onion is soft stirring once Add flour salt mustard and pepper mix well Cook at High0 for 30 to 60 seconds until mixture boils Stir in milk until smooth Stir in red pepper Cook at High0 for 2 to 3 minutes until mixture boils and thickens slightly stirring twice Stir in cheese until melted Add broccoli and pasta mix well Cover with lid Cook at High0 for 4 to 6 minutes until heated through stirring once Stir before serving Makes 6 servings Warm Potato Salad 900g small red potatoes cut into ½inch pieces 4 slices bacon uncooked cut into ½inch pieces ¼ cup chopped onion 2 tsp sugar 1 tsp salt 1 tsp flour ½ tsp celery seed tsp pepper 2½ Tbs apple cider vinegar In a 2quart casserole combine potatoes and ¼ cup water Cover with lid Cook at High0 until potatoes are tender 710 min stir twice Drain and set aside to cool slightly In a medium bowl cook bacon at High0 until crisp 2½3½ min stir once Place bacon on a paper towel Reserve 1 Tbs drippings Combine drippings and onion Cover with plastic wrap turn back a corner to vent steam Cook at High0 until tender 1½2½ min stir once Stir in sugar salt flour celery seed and pepper Cook at High0 until mixture boils 3040 sec Stir in vinegar and ½ cup water Cook at High0 until liquid boils and thickens slightly 12 min stir once Add bacon to dressing Pour dressing over potatoes Stir well Makes 6 servings Black Bean Soup 1 cup chopped onion 1 clove garlic minced 2 cans 420g each black beans drained 1 can 390450g stewed tomatoes chopped 1 can 385405g chicken broth 1 can 195240g corn 1 can 110g chopped green chilies 12 tsp ground cumin or to taste Place onion and garlic in a 3quart casserole Cover with lid Cook at High0 for 2 to 4 minutes until tender Add one can of beans mash beans with a fork Add remaining ingredients mix well Cook uncovered at High0 for 10 minutes stir Reduce power to Medium and cook for 5 minutes Stir before serving Makes about 2 quarts ME6124WXSA03248AENfm Page 14 Friday March 31 2006 1121 AM
• Page 15 - English - : Appendix Troubleshooting Guide Before you call a repair person for your oven check this list of possible problems and solutions Neither the ovens display nor the oven operate Properly insert the plug into a grounded outlet If the outlet is controlled by a wall switch make sure the wall switch is turned on Remove the plug from the outlet wait ten seconds then plug it in again Reset the circuit breaker or replace any blown fuse Plug another appliance into the outlet if the other appliance doesnt work have a qualified electrician repair the outlet Plug the oven into a different outlet The ovens display works but the power wont come on Make sure the door is closed securely Check to see if packing material or other material is stuck to the door seal Check for door damage Press Cancel twice and reenter all cooking instructions The power goes off before the set time has elapsed If there has not been a power outage remove the plug from the outlet wait ten seconds then plug it in again If there was a power outage the time indicator will display Reset the clock and any cooking instructions Reset the circuit breaker or replace any blown fuse The food is cooking too slowly Make sure the oven is on its own 10A amp circuit line Operating another appliance on the same circuit can cause a voltage drop If necessary move the oven to its own circuit You see sparks or arcing Remove any metallic utensils cookware or metal ties If using foil use only narrow strips and allow at least one inch between the foil and interior oven walls The turntable makes noises or sticks Clean the turntable roller ring and oven floor Make sure the turntable and roller ring are positioned correctly Using your microwave causes TV or radio interference This is similar to the interference caused by other small appliances such as hair dryers Move your microwave further away from other appliances like your TV or radio Care and Cleaning Follow these instructions to clean and care for your oven Keep the inside of the oven clean Food particles and spilled liquids can stick to the oven walls causing the oven to work less efficiently Wipe up spills immediately Use a damp cloth and mild soap Do not use harsh detergents or abrasives To help loosen baked on food particles or liquids heat two cups of water add the juice of one lemon if you desire to keep the oven fresh in a fourcup measuring glass at High power for five minutes or until boiling Let stand in the oven for one or two minutes Remove the glass tray from the oven when cleaning the oven or tray To prevent the tray from breaking handle it carefully and do not put it in water immediately after cooking Wash the tray carefully in warm sudsy water or in the dishwasher Clean the outside surface of the oven with soap and a damp cloth Dry with a soft cloth To prevent damage to the operating parts of the oven dont let water seep into the openings Wash the door window with very mild soap and water Be sure to use a soft cloth to avoid scratching If steam accumulates inside or outside the oven door wipe with a soft cloth Steam can accumulate when operating the oven in high humidity and in no way indicates microwave leakage Never operate the oven without food in it this can damage the magnetron tube or glass tray You may wish to leave a cup of water in the oven when it is not in use to prevent damage if the oven is accidentally turned on Error Message If Error1 and Error3 are displayed please let oven cool for at least 5 minutes If these messages are displayed frequently please call our service line If you open the door on the way to sensing Error4 will be displayed If Error2 is displayed please call our service line immediately If you have a problem you cannot solve Contact your local dealer or SAMSUNG after sales service ME6124WXSA03248AENfm Page 15 Friday March 31 2006 1121 AM
• Page 16 - English - : Appendix Specifications Model Number ME6124W ME6124ST Oven Cavity 12 cuft Controls 10 power levels including defrost Timer 99 minutes 99 seconds Power Source 240 V 50 Hz Power consumption Microwave 1550 Watts Power Output 1000 Watts IEC705 Operating frequency 2450 MHz Outside Dimensions 523 W X 297 H X 415 D Oven Cavity Dimensions 368 W X 229 H X 396 D Weight Net 155 kg Model Number ME6144W ME6144ST Oven Cavity 14 cuft Controls 10 power levels including defrost Timer 99 minutes 99 seconds Power Source 240 V 50 Hz Power consumption Microwave 1550 Watts Power Output 1000 Watts IEC705 Operating frequency 2450 MHz Outside Dimensions 555 W X 313 H X 439 D Oven Cavity Dimensions 375 W X 249 H X 408 D Weight Net 180 kg Samsung Electronics Co Ltd ME6124WXSA03248AENfm Page 16 Friday March 31 2006 1121 AM
