Everdure HSE201W Thermoconduction Heater

User Manual - Transcript

• Page 1: HEAT LIVE RELAX OPERATION MAINTENANCE AND SAFETY INSTRUCTIONS FOR EVERDURE EVO HSE151W HSE201W HSE152W amp HSE202W HEATERS
• Page 2 - English - : HEAT LIVE RELAX INTRODUCTION Congratulations on purchasing your new EVO Thermoconducting electric heater from Everdure A revolutionary new design this heater uses up to 90 less oil than a standard oil column heater with a unique formula that allows the liquids to convert to a vapour increasing the amount of heat generated by convection This coupled with the patented French design makes it a suitable appliance for any modern home Add on the fast heatup time under 2 minutes and an economy function to help keep the family budget intact makes it a must for anyone looking for a safe heater that can be used almost anywhere within the home We hope you will enjoy this appliance for years to come OTHER PRODUCTS AVAILABLE FROM EVERDURE Now you know who we are why not look at some of the other products we have to offer Barbecues Cooking Products Gas Heaters
• Page 3 - English - : HEAT LIVE RELAX IMPORTANT SAFETY INSTRUCTIONS IMPORTANT Read the safety precautions of this booklet carefully before attempting to assemble install operate or maintain the product described Protect yourself and others by observing all safety information Failure to comply with instructions could result in personal injury andor property damage If you are unsure about anything regarding your heater or these instructions please contact Everdure on 1300 766 066 in Australia or 09 415 6000 in New Zealand before operating your appliance 1 Read all instructions carefully before using the heater 2 Use this heater only as described in this manual Any other use not recommended by the manufacturer may cause fire electrical shock or injury to persons Do not modify this appliance 3 Remove the package and ensure that the appliance is undamaged keep packing box for later storage In case of doubt do not use the appliance and contact Everdure Service Do not let children play with any parts of the packaging 4 This appliance is not intended for use by persons including children with reduced physical sensory or mental capabilities or lack of experience or knowledge unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety Children should be supervised to ensure that they do not play with the appliance Extreme caution is necessary when the heater is used by or near children or individuals with decreased mental and physical capacity and whenever the heater is left operating unattended 5 Before you use the appliance check if the voltage marked on the rating label corresponds to the mains in your home The appliance must be connected to a grounded power supply 6 This heater is filled with a precise quantity of oil Do not try to refill or adjust the level of oil Repairs requiring opening the oil container can only be made by Everdure Service who should be contacted if a leak is found 7 Avoid using extension cords as the extension cord may overheat and cause a risk of fire If the use of an extension cord cannot be avoided always use one with a minimum rating of 13Amps Do not use this appliance with a programmer timer or any other device that switches the appliance on automatically since a fire risk exists if the appliance is covered or positioned incorrectly 8 Do not pull the power cord to disconnect with the power source Always grasp the plug to pull it out 9 Do not run power cords under rugs or other combustible materials Do not place power cords in areas where they can be a tripping hazard 10 Do not insert any objects into the heater as it may cause an electric shock or fire or damage to the heater Do not block or tamper with the heater in any manner while it is in operation WARNING To prevent a possible fire do not cover the appliance in any manner 11 Do not leave the heater unattended Always unplug the heater when not in use WARNING The Main Power Switch should not be used as the sole means of disconnecting power Always unplug the power cord before servicing or moving the unit 12 This heater is hot when in use To avoid burns do not let bare skin touch hot surfaces Always use the handle when moving the heater where available or hold on the sides if not available make sure the unit is turned off Keep combustible materials such as furniture pillows bedding papers clothes and curtains at least 1m from the heater to the sides front rear amp top 13 The heater has hot and arcing or sparking parts inside It must NOT be used in potentially dangerous locations such as flammable explosive chemicalladen or wet atmospheres This heater is intended for general indoor domestic use ONLY 14 This heater is not intended for use in wet or damp locations Never locate a heater where it may fall into a bathtub or other water container 15 Do not use the heater outdoors WARNING To avoid danger of electric shock unplug from outlet when not in use and before cleaning If the supply cord is damaged it must be replaced by a special cord or assembly available from an authorised person In order to avoid overheating do not cover the heater The heater must NOT be located immediately below a socket outlet Do not use the heater in the immediate surroundings of a bath shower or swimming pool
• Page 4 - English - : HEAT LIVE RELAX GENERAL SPECIFICATIONS MODEL HSE151W HSE201W HSE152W HSE202W V OLTAGE RATING 220240V 50Hz 220240V 50Hz 220240V 50Hz 220240V 50Hz POWER CONSUMPTION 13501500W 2000W 13501500W 2000W HEATER SIZE cm H x W xL 59 x 19x60 59x19x74 64x235x565 64x235x71 W EIGHT kg 125 165 1 Control Panel 2 Handle W heels INSTALLATION This appliance comes with a number of parts which must be assembled to the main body before use Check each part is present amp in good condition before proceeding A xle 1pc 2 Space r 2pcs Screw 2pcs W ashe r 2pcs 5 Screw Cove r 2pcs W heel 2pcs Front Front Air Outlet Air Outlet Model HSE151W HSE201W Model HSE152W HSE202W
• Page 5 - English - : HEAT LIVE RELAX 1 Place one wheel onto the axle Fix wheel into place with one washer and one screw amp push the screw cover into the centre of the wheel Push a spacer over the other end of the axle up to the wheel 2 Push the axle assembly through the supplied hole in the appliance at the front of the HSE151W amp HSE201W as shown or rear of the HSE152W amp HSE202W Push the second spacer over the axle Place the second wheel onto the axle Fix wheel into place with one washer and one screw amp push the screw cover into the centre of the wheel 3 For HSE151W amp HSE201W a foot needs to be attached to the underside of the appliance rear with 2 screws Turn the appliance upside down on a clean smooth surface and place the foot over the 2 screw holes Attach the foot to the appliance with the 2 small screws provided Put the appliance back to the upright position before connecting power Install to Pins
• Page 6 - English - : HEAT LIVE RELAX OPERATING INSTRUCTIONS CONTROL PANEL POWER ONOFF BUTTON Make sure the power supply and power switch are on Press the Power OnOff Button once and the unit will now be active and the Power Indicator will light up The display will start flashing the current thermostat temperature setting default is 25C and then switch to the current ambient temperature Press a second time and the appliance will revert back to the standby mode Note If the thermostat temperature is set to a level below the ambient temperature the unit will not run Once the ambient temperature falls below the set thermostat temperature the unit will turn on and start to produce heat TEMPERATURE CONTROL BUTTONS The appliance starts with the thermostat temperature set to 25C Pressing the or will adjust the running temperature to between 16C amp 32C The new thermostat temperature will be displayed flashing for a few seconds after the operation is completed amp then the display will revert to the ambient temperature POWER CONTROL KNOB The amount of power used by the heater can be also be adjusted with the Power Control Knob Increasing the power setting will allow the heater to heat up faster but use more power where decreasing the setting will allow the heater to reach its set temperature over a longer time A higher setting is best for heating up a cold room fast where a lower setting is better for keeping a warm room at the set temperature The power setting is shown on the power display ECO ONOFF BUTTON Pressing this button adjusts the thermostat temperature setting to 3C below what is set ie if the thermostat temperature has been left at the default 25C the heater will run to 22C The ECO display will light up to show it is operational Turn this function off by pressing it a second time Power Display Temperature Display Power Indicator Light Power Control Knob Power OnOff Button ECO Display Temperature Control Buttons ECO OnOff Button
• Page 7 - English - : HEAT LIVE RELAX CLEANING amp MAINTENANCE WARNING ALWAYS UNPLUG THE CORD BEFORE MOVING OR SERVICING DO NOT IMMERSE HEATER IN WATER OR POUR WATER ON HEATER CAUTION Do not use gasoline benzene thinner harsh cleaners etc as they will damage the heater NEVER use ALCOHOL OR SOLVENTS Do not use detergents polish or other abrasive cleaning powders as they can damage the surface of the heater To clean wipe with a dry cloth to remove dust and then a damp cloth to remove any stains Use a vacuum cleaner to remove dust amp lint from within the outer metal grids of the appliance STORAGE Store the heater with these instructions in the original packaging in a cool dry place WEEE WARNING This product should not be disposed of with household waste Please recycle where facilities exist and check with your local authority for recycling advice Always follow the regulations concerning the disposal of oil HINTS amp TIPS Where possible your electric heater should be connected to a power outlet that uses a separate 10 amp power circuit This will avoid overloading your household fuse In the event that your household fuse is overloaded and trips please note this is normally caused by the use of excessive power outlets at the same time your heater is operating for example a steam iron kettle toaster etc Please ensure to check the use of the power circuit and adjust when heater is in use ie turn off the heater when boiling a kettle Should you still experience difficulty contact Everdure Service for assistance This appliance contains a safety tipover switch which will turn the unit off if it falls onto its side To restart right the appliance to its correct position This appliance also contains a thermal cutout and will automatically switch off if it overheats If this happens turn the appliance off amp turn off the power at the wall switch wait 15 minutes for the appliance to cool down and restart If the source of the overheating can be found covered with towels too close to walls or seats etc the source should be removed or the position of the appliance adjusted It is important that you retain these instructions proof of purchase as well as other important documents about this product for future reference Due to continual product development Everdure reserves the right to alter specifications or appearances without notice Dispose of packaging responsibly recycle where facilities are available
• Page 8 - English - : HEAT LIVE RELAX A division of Shriro Australia Pty Ltd 104 Vanessa St Kingsgrove NSW 2208 In Australia 1300 766 066 In New Zealand 09 415 6000 wwweverdurecom IM Ref EVOHSEXXXW 12201402 HEAT LIVE RELAX
