E6/E60 Instructions for Use
2
Table of contents
Control elements 4
Important information 6
Proper use ......................................................................................................................................................6
For your safety ...............................................................................................................................................6
1 Preparing and using for the first time 10
Setting up the machine ..............................................................................................................................10
Filling the bean container ...........................................................................................................................10
Determining the water hardness ..............................................................................................................10
First-time use .................................................................................................................................................11
Connecting milk ...........................................................................................................................................12
Connect accessory (with wireless connection) .......................................................................................13
2 Preparation 14
Espresso and coffee .....................................................................................................................................14
Two espressi and two coffees .....................................................................................................................14
Cappuccino and macchiato ........................................................................................................................15
Caffè Barista and lungo Barista .................................................................................................................15
Espresso doppio ...........................................................................................................................................16
Milk foam .......................................................................................................................................................16
Hot water .......................................................................................................................................................16
Permanently setting the amount of water for the cup size .................................................................17
Adjusting the grinder ..................................................................................................................................18
3 Daily operation 19
Filling the water tank ...................................................................................................................................19
Switching on the machine ..........................................................................................................................19
Daily maintenance .......................................................................................................................................19
Regular maintenance .................................................................................................................................20
Switching off the machine .........................................................................................................................20
4 Permanent settings in programming mode 22
Adjusting the product settings .................................................................................................................22
Automatic switch-off ..................................................................................................................................24
Setting the water hardness .......................................................................................................................24
Language ......................................................................................................................................................25
Unit for amount of water ...........................................................................................................................25
5 Maintenance 26
Rinsing the machine ...................................................................................................................................26
Rinsing the fine foam frother ....................................................................................................................26
Cleaning the fine foam frother .................................................................................................................27
Dismantling and rinsing the fine foam frother......................................................................................28
Inserting/changing the filter ......................................................................................................................28
Your E6
3
Table of contents
Cleaning the machine ................................................................................................................................29
Descaling the machine ..............................................................................................................................30
Descaling the water tank ...........................................................................................................................32
Cleaning the bean container .....................................................................................................................33
6 Display messages 34
7 Troubleshooting 35
8 Transport and environmentally friendly disposal 37
Transport/ Emptying the system .............................................................................................................37
Disposal .........................................................................................................................................................37
9 Technical data 38
10 Index 39
11 JURA contact details/ Legal information 44
These instructions for use apply to the following models:
U
E6
U
E60
In the interests of clarity, however, the instructions for use only refer
to the ‘E6’ model.
Warnings
J WARNING
J CAUTION
Always take note of any information marked with the words CAUTION
or WARNING and a warning sign. The signal word WARNING draws your
attention to potential serious injury, and the signal word CAUTION to
potential minor injury.
CAUTION CAUTION draws your attention to potential damage to the machine.
Symbols used
T
Prompt to take action. This symbol means that you are being prompted to
perform some action.
E
Information and tips to make it even easier to use your E6.
‘Coffee’ Display
Scope of validity
Symbol description
4
Control elements
Control elements
1
13
12
10
9
11
2
3
4
5
7
6
8
14
1 Cover of filler funnel for cleaning tablet
2 Filler funnel for cleaning tablet
3 Bean container with aroma preservation
cover
4 Water tank cover
5 Water tank
6 Mains cable (back of the machine)
7 Coffee grounds container
8 Drip tray
9 Cover cap for grinder adjustment switch
10 Grinder adjustment switch
11 On/Off button Q
12 Fine foam frother
13 Height-adjustable coffee spout
14 Cup grille
5
Control elements
3
1
2
1 Display
2 Multi-function buttons (button function
depends on what is shown in the display)
3 Switch for hot water and steam
preparation
Service socket for optional JURA Smart Connect
6
Important information
Important information
The machine is designed and intended for private
domestic use. It should only be used for coffee
preparation and to heat milk and water. Use for
any other purpose will be deemed improper. JURA
Elektroapparate AG cannot accept any responsibil-
ity for the consequences of improper use.
Before using the machine read these instructions
for use thoroughly and completely and comply
with the instructions they contain. A warranty ser-
vice is not applicable for damage or defects caused
by non-compliance with the instructions for use.
Keep these instructions for use close to the machine
and pass them on to the next user.
Please carefully read and observe the important
safety information set out below.
To avoid danger of potentially fatal electric shock:
U
Never use a machine which is damaged or has
a defective mains cable.
U
In the event of signs of damage, for example if
there is a smell of burning, unplug the machine
immediately from the power supply and con-
tact JURA service.
U
For models with a permanently connected
mains cable: If the mains cable of this machine
is damaged, it must be repaired either directly
by JURA or by an authorised JURA service cen-
tre.
U
For machines with a plug-in mains cable: If the
mains cable of this machine is damaged it
must be replaced with a special mains cable,
Proper use
For your safety
J
7
Important information
which is available directly from JURA or from
authorised JURA service centres.
U
Make sure that the E6 and the mains cable are
not located close to hot surfaces.
U
Be careful to ensure that the mains cable is not
trapped and does not rub against sharp edges.
U
Never open and repair the machine yourself.
Do not modify the machine in any way that is
not described in these instructions for use. The
machine contains live parts. If opened, there is
a danger of potentially fatal injury. Repairs
may only be carried out by authorised JURA
service centres, using original spare parts and
accessories.
U
To completely and safely disconnect the
machine from the power supply, first switch
off the E6 using the On/Off button Q. Only
then should you remove the mains plug from
the power socket.
There is a risk of scalds or burns on the spouts and
fine foam frother:
U
Place the machine out of the reach of children.
U
Do not touch any hot parts. Use the handles
provided.
U
Be careful to ensure that the fine foam frother
is correctly installed and clean. If incorrectly
fitted or if it becomes blocked, the fine foam
frother or its parts might come off.
U
Your E6 can be remotely operated using
mobile devices. When preparing a product or
initiating a maintenance programme, make
sure that other people are not put at risk – for
example, through contact with the spouts.
8
Important information
A defective machine is not safe and could cause
injury or fire. To avoid damage and any associated
risk of injury or fire:
U
Never allow the mains cable to loosely hang
down. The mains cable could pose a tripping
hazard or become damaged.
U
Protect the E6 from environmental influences
such as rain, frost and direct sunlight.
U
Before cleaning, switch the E6 off with the
On/Off button Q. Always wipe the E6 with a
damp cloth rather than a wet one, and protect
it from prolonged exposure to water splash.
U
Do not immerse the E6, mains cable or con-
nections in water.
U
Do not put the E6 or any individual parts in the
dishwasher.
U
Do not use alkaline cleaning agents; only use
a soft cloth and mild cleaning agents.
U
Only connect the machine to the mains volt-
age in accordance with the information on the
rating plate. The rating plate is located on the
underside of your E6. Further technical data is
provided in these instructions for use (see
Chapter 9 ‘Technical data’).
U
Connect the E6 directly to a domestic power
socket. Using multi-socket adapters or exten-
sion cords may cause overheating.
U
Please only use original JURA maintenance
products. Use of products that are not explic-
itly recommended by JURA could damage the
machine.
U
Do not use any coffee beans treated with addi-
tives or caramelised coffee beans.
U
Only fill the water tank with fresh, cold water.
9
Important information
U
Switch the machine off with the On/Off but-
ton Q if you are going to be absent for a longer
period of time and remove the mains plug
from the power socket.
U
Children may not clean or service the machine
unless supervised by a responsible person.
U
Do not allow children to play with the machine.
U
Keep children under the age of 8 away from
the machine, or supervise them constantly.
U
Children aged 8 and over may only operate
the machine without supervision if they have
been instructed in how to use it safely. Chil-
dren must be able to recognise and under-
stand the potential dangers arising from incor-
rect use.
People, including children, who
U
do not have the physical, sensory or mental
capabilities to use the machine safely or
U
are inexperienced or lack knowledge in how to
use the machine safely
must be supervised by a responsible person when
using it, or must be instructed in how to use it cor-
rectly.
Safety when handling the CLARIS Smart filter car-
tridge:
U
Filter cartridges should be kept out of the
reach of children.
U
Store filter cartridges in a dry place in the
sealed packaging.
U
Protect cartridges from heat and direct
sunlight.
U
Do not use damaged filter cartridges.
U
Do not open filter cartridges.
10
1 Preparing and using for the first time
1 Preparing and using for the first time
When setting up your E6, please note the following:
U
Place the E6 on a horizontal surface that is not sensitive to
water.
U
Choose a spot for your E6 which protects the machine against
overheating. Ensure that the ventilation slots are not covered.
Coffee beans which have been treated with additives (e.g. sugar),
ground coffee or freeze-dried coffee will damage the grinder.
T Only use roasted, untreated coffee beans to fill the bean con-
tainer.
T Remove the aroma preservation cover.
T Remove any dirt or foreign objects from inside the bean
container.
T Fill the bean container with coffee beans and close the
aroma preservation cover.
When you use the machine for the first time, you must set the water
hardness. If you do not know the hardness of your water, you can
find this out first. Use the Aquadur® test strips supplied with the
machine.
T Hold the test strip briefly (for 1second) under flowing water.
Shake off the water.
T Wait for about 1minute.
Setting up the machine
Filling the bean container
CAUTION
Determining the water
hardness
11
1 Preparing and using for the first time
T You will then be able to read the degree of water hardness
from the discolouration of the Aquadur® test strip and the
description on the packaging.
If the machine is operated with a defective mains cable, there is a
danger of potentially fatal electric shock.
T Never use a machine which is damaged or has a defective
mains cable.
Milk, sparkling mineral water or other liquids can damage the water
tank or the machine.
T Only fill the water tank with fresh, cold water.
Precondition:The bean container has been filled.
T Insert the mains plug into a power socket.
T Press the On/Off button Q to switch the E6 on.
‘Sprachauswahl’
E To display more languages, press the ‘>’ button.
T Press the button that corresponds to the language you want,
e.g.
‘English’.
‘Saved’ appears briefly on the display.
‘Water hardness’
E If you do not know the hardness of your water, you must find
this out first (see Chapter 1 ‘Preparing and using for the first
time – Determining the water hardness’).
T Press the
‘<’ or ‘>’ button to change the setting for the
water hardness.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Filter operation’
First-time use
J
WARNING
CAUTION
12
1 Preparing and using for the first time
T Place a receptacle under the fine foam frother and under the
coffee spout.
T Remove the water tank and rinse it with cold water.
T Fit the filter cartridge extension supplied on top of the
CLARIS filter cartridge Smart.
T Insert the filter cartridge with its extension into the water
tank.
T Turn the filter cartridge clockwise until it audibly clicks into
place.
T Fill the water tank with fresh, cold water and reinsert the
tank.
E The machine automatically detects that you have just inserted
the filter cartridge.
‘Saved’ appears briefly on the display.
‘Open switch’
T Turn the switch to the§ position.
‘Filter is being rinsed’, water flows out of the fine foam
frother.
Rinsing of the filter stops automatically.
‘Close switch’
appears on the display.
T Turn the switch to the °position.
‘System is filling’
‘Empty drip tray’
T Empty the drip tray and put it back into the machine.
‘Machine is rinsing’
The start screen is displayed. Your E6 is ready for use.
Your E6 creates fine, creamy, feather-light milk foam with a perfect
consistency. The most important requirement for frothing milk is a
milk temperature of 4–8°C. We would therefore recommend using
a milk cooler or a milk container.
Connecting milk
13
1 Preparing and using for the first time
T Remove the protective cover from the fine foam frother.
T Connect the milk pipe to the fine foam frother.
T Connect the other end of the milk pipe to a milk container
or a milk cooler.
You have the option of connecting your E6 wirelessly to a compat-
ible accessory (e.g. the Cool Control milk cooler). To do this, the
receiver of the Cool Control or the JURA Smart Connect must be
plugged into the service socket.
E The Smart Connect can be protected against unauthorised
access using a PIN. Activate the PIN function via J.O.E.
®
– your
JURA app. You will find more information at
www.jura.com/smartconnect.
E Please note that you can only connect either the accessory or
J.O.E.
®
to the coffee machine via Smart Connect and not both
at the same time.
Precondition:The start screen is displayed.
T Position the accessory near the coffee machine (a maximum
of 0.5 m away).
T Switch on the accessory and the coffee machine.
T Press the reset button of the Smart Connect (e.g. with a
paper clip).
T Then (within 30 sec.) press and hold the reset button of the
accessory until the LED lights up to indicate the successful
connection.
Connect accessory (with
wireless connection)
14
2 Preparation
2 Preparation
Basic information about preparing drinks:
U
The display shows four products you can prepare. Press
the
‘>’ button to display more products.
U
During the grinding operation you can select the coffee
strength of single products by pressing the
‘<’ and ‘>’ but-
tons.
U
During preparation you can change the preset amounts (e.g.
water and amount of milk foam) by pressing the
‘<’ and ‘>’
buttons.
U
You can make permanent settings for all products in pro-
gramming mode (see Chapter 4 ‘Permanent settings in pro-
gramming mode – Adjusting the product settings’).
U
You can stop preparation at any time. To do this, press the
‘Cancel’ button.
Coffee tastes best served hot. A cold porcelain cup cools the bever-
age – and impairs the taste. We therefore recommend prewarming
the cups. The full coffee aroma can develop only in prewarmed cups.
You can purchase a JURA cup warmer from your specialised dealer.
Example:Proceed as follows to prepare one coffee.
Precondition:The start screen is displayed.
T Place a cup under the coffee spout.
T Press the
‘Coffee’ button.
The preset amount of water for coffee flows into the cup.
To prepare two speciality coffees, press the appropriate preparation
button twice (within approximately 1 second).
Example:Proceed as follows to prepare two espressi.
Precondition:The start screen is displayed.
Espresso and coffee
Two espressi and two
coffees
15
2 Preparation
T Place two cups under the coffee spout.
T Press the
‘Espresso’ button twice (within 1 second).
‘2xEspresso’, the preset amount of water flows into the
cups.
Example:Proceed as follows to prepare one cappuccino.
Precondition:The start screen is displayed. Milk is connected to the
fine foam frother.
T Place a cup under the coffee spout and the fine foam frother.
E When preparing a macchiato, depending on the size of the
cup, the cup may need to be moved to under the coffee spout
after the milk foam has been prepared.
T Press the
‘Cappuccino’ button.
As soon as the machine has heated up,
‘Open switch’
appears.
T Turn the switch to the§ position.
The milk foam is prepared.
‘Close switch’
T Turn the switch to the °position.
The preset amount of water for espresso flows into the cup.
To ensure that the fine foam frother always works properly, you
must clean it daily when you have been preparing milk (see Chap-
ter 5 ‘Maintenance – Cleaning the fine foam frother’).
For the ‘caffè Barista’ and ‘lungo Barista’, blend the coffee with hot
water. This results in a full-bodied speciality coffee which is particu-
larly easy to digest. You can change the amount of this additional
water (see Chapter 4 ‘Permanent settings in programming mode –
Adjusting the product settings’).
Example:Proceed as follows to prepare a ‘caffè Barista’.
Precondition:The start screen is displayed.
Cappuccino and
macchiato
Caffè Barista and lungo
Barista
16
2 Preparation
T Place a cup under the coffee spout and the fine foam frother.
T Press the
‘Caffè Barista’ button.
The preset amount of water for coffee flows into the cup.
‘Open switch’
T Turn the switch to the§ position.
Hot water flows out of the fine foam frother.
‘Close switch’
T Turn the switch to the °position.
‘Doppio’ is Italian for ‘double’. When you select Espresso doppio,
two espressi are prepared one after the other. The result is an extra
full-bodied and aromatic speciality coffee.
Precondition:The start screen is displayed. Milk is connected to the
fine foam frother.
T Place a cup under the fine foam frother.
T Press the
‘Milk foam’ button
As soon as the machine has heated up,
‘Open switch’
appears.
T Turn the switch to the§ position.
The milk foam is prepared.
‘Close switch’
T Turn the switch to the °position.
To ensure that the fine foam frother always works properly, you
must clean it daily when you have been preparing milk (see Chap-
ter 5 ‘Maintenance – Cleaning the fine foam frother’).
There is a danger of scalding from hot water splashes.
T Avoid direct contact with the skin.
Precondition:The start screen is displayed.
Espresso doppio
Milk foam
Hot water
J
CAUTION
17
2 Preparation
T Place a cup under the fine foam frother.
T Turn the switch to the§ position.
The preset amount of water flows into the cup.
‘Close switch’
T Turn the switch to the °position.
It is easy to permanently adjust the amount of water for all single
products to the cup size. Adjust the amount once as shown in the
following example. Every time you prepare a drink in the future, this
amount will be dispensed.
Example:Proceed as follows to permanently set the amount of
water for one coffee.
Precondition:The start screen is displayed.
T Place a cup under the coffee spout.
T Press and hold the
‘Coffee’ button until ‘Enough coffee?
Press button’
appears.
T Release the
‘Coffee’ button.
Preparation starts and the coffee flows into the cup.
T Press any button except
‘Cancel’ as soon as there is sufficient
coffee in the cup.
Preparation stops.
‘Saved’ appears briefly on the display.
E You can alter this setting at any time by repeating the above
procedure.
E You can also permanently set the amounts for all single prod-
ucts in programming mode (see Chapter 4 ‘Permanent set-
tings in programming mode – Adjusting the product set-
tings’).
Permanently setting the
amount of water for the
cup size
18
2 Preparation
You can adjust the grinder to suit the degree of roast of your coffee.
If you adjust the consistency of grind when the grinder is not oper-
ating, the grinder adjustment switch could be damaged.
T Only adjust the consistency of grind when the grinder is run-
ning.
The consistency of grind is correct if the coffee flows regularly from
the coffee spout. In addition a fine, thick crema forms.
Example: Proceed as follows to change the consistency of grind
during the preparation of an espresso.
Precondition:The start screen is displayed.
T Place a cup under the coffee spout.
T Open the cover of the grinder adjustment switch.
T Press the
‘Espresso’ button to start preparation.
T Turn the grinder adjustment switch to the desired position
while the grinder is running.
The preset amount of water flows into the cup. Preparation
stops automatically.
T Close the cover of the grinder adjustment switch.
Adjusting the grinder
CAUTION
19
3 Daily operation
3 Daily operation
Daily maintenance of the machine and hygiene when handling milk,
coffee and water are key to a perfect coffee result in the cup every
time. You should therefore change the water daily.
Milk, sparkling mineral water or other liquids can damage the water
tank or the machine.
T Only fill the water tank with fresh, cold water.
T Open the water tank cover.
T Remove the water tank and rinse it with cold water.
T Fill the water tank with fresh, cold water and reinsert the
tank.
T Close the water tank cover.
T Place a receptacle under the coffee spout.
T Press the On/Off button Q to switch the E6 on.
‘Machine is rinsing’, rinsing stops automatically. The start
screen is displayed.
To ensure that you get many years of reliable service out of your E6
and to guarantee the optimum coffee quality, the machine requires
daily maintenance.
T Pull out the drip tray.
T Empty the coffee grounds container and the drip tray. Rinse
them both with warm water.
E Always empty the coffee grounds container when the machine
is switched on. This is the only way of resetting the coffee
grounds counter.
T Refit the coffee grounds container and the drip tray.
Filling the water tank
CAUTION
Switching on the
machine
Daily maintenance
20
3 Daily operation
T Clean the fine foam frother (see Chapter 5 ‘Maintenance –
Cleaning the fine foam frother’).
T Remove the milk pipe and rinse it thoroughly under running
water.
T Dismantle and rinse the fine foam frother (see Chapter 5
‘Maintenance – Dismantling and rinsing the fine foam
frother’).
T Rinse the water tank with clean water.
T Wipe the surface of the machine with a clean, soft, damp
cloth (e.g. microfibre cloth).
You will find more information about caring for your E6 in program-
ming mode (page
‘2/4’) under ‘Information’.
Carry out the following maintenance actions regularly or as
required:
U
In the interests of hygiene, we recommend changing the milk
pipe and interchangeable milk spout on a regular basis
(approximately every 3 months). Replacements are available
from specialised dealers. Your E6 is equipped with the HP1
milk system.
U
Clean the inside of the water tank, e.g. with a brush. Further
information about the water tank is provided in these instruc-
tions for use (see Chapter 5 ‘Maintenance – Descaling the
water tank’).
U
Traces of milk and coffee may stick to the top and bottom of
the cup grille. If this happens, clean the cup grille.
When the E6 is switched off, the system is automatically rinsed if a
speciality coffee has been prepared.
T Place a receptacle under the fine foam frother and under the
coffee spout.
T Press the On/Off button Q.
E If milk has been prepared, you will be prompted to clean the
milk system (
‘Clean the milk system’). After 10seconds the
switch-off process continues automatically.
‘Machine is rinsing’
Regular maintenance
Switching off the
machine
21
3 Daily operation
If milk has been prepared but you have not started milk sys-
tem cleaning, you will first need to rinse the milk system
(
‘Rinse the milk system’/ ‘Open switch’).
T Turn the switch to the§ position.
‘Milk system is being rinsed’
‘Close switch’
T Turn the switch to the °position.
Your E6 is switched off.
22
4 Permanent settings in programming mode
4 Permanent settings in programming mode
Press the ‘ Pc ’ button to enter programming mode. You can navi-
gate through the programme items and permanently save the
required settings using the multi-function buttons. The following
settings can be made:
Programme
item
Sub-item Explanation
‘1/4’ ‘Clean’,
‘Descale’,
‘Clean the milk system’,
‘Filter’ (only if filter is
fitted)
T Start the required maintenance programme here.
‘2/4’ ‘Rinse the coffee system’,
‘Rinse the milk system’,
‘Information’
T Here you can start the desired maintenance
programme or find out what maintenance actions are
required.
‘3/4’ ‘Expert mode’
T Select your settings for speciality coffees and hot
water.
‘4/4’ ‘Choose language’
T Select your language.
‘Units’
T Select the unit for the amount of water.
‘Switch off after’
T Set the time after which the E6 should switch off
automatically.
‘Water hardness’
T You can set the water hardness of the water used.
In the programme item
‘Expert mode’ you can make individual set-
tings for all speciality coffees and hot water. The following perma-
nent settings can be made:
Product Coffee
strength
Amount Temperature
‘Espresso’ 8 levels Water: 15ml–80ml normal, high
‘Coffee’ 8 levels Water: 25ml–240ml normal, high
‘2xEspresso’,
‘2xCoffee’
– Water: the amount set for the single
product is doubled.
as for single product
‘Caffè Barista’,
‘Lungo Barista’
8 levels Water: 25ml–240ml
Bypass water: 0ml–240ml
Adjusting the product
settings
23
4 Permanent settings in programming mode
Product Coffee
strength
Amount Temperature
‘Espresso doppio’
(2 brewing operations)
8 levels Water: 30ml–160ml normal, high
‘Cappuccino’ 8 levels Water: 25ml–240ml
Milk foam: 3sec.–120sec.
normal, high
‘Macchiato’ 8 levels Water: 15ml–80ml
Milk foam: 3sec.–120sec.
normal, high
‘Milk foam’ – Milk foam: 3sec.–120sec. –
‘Hot water’ – Water: 25ml–450ml low, normal, high
Permanent settings in programming mode always follow the same
model.
Example:Proceed as follows to change the coffee strength for one
coffee.
Precondition:The start screen is displayed.
T Press the
‘ Pc ’ button.
T Press the
‘>’ button several times until page ‘3/4’ is
displayed.
T Press the
‘Expert mode’ button.
E Next select the button of the product for which you would like
to make settings. No product is prepared at this point.
E To display more products, press the
‘>’ button.
T Press the
‘Coffee’ button.
T Press the
‘Coffee strength’ button.
T Press the
‘<’ or ‘>’ button to change the setting for the cof-
fee strength.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
T Press the
‘’ button for around 2 seconds to exit program-
ming mode.
24
4 Permanent settings in programming mode
By instructing your E6 to automatically switch itself off, you can cut
down your energy consumption. If this function is activated, your E6
switches off automatically after the preset time following the last
action on the machine.
You can set the automatic switch-off to 15minutes, 30minutes or
1–9hours.
Precondition:The start screen is displayed.
T Press the
‘ Pc ’ button.
T Press the
‘>’ button several times until page ‘4/4’ is
displayed.
T Press the
‘Switch off after’ button.
T Press the
‘<’ or ‘>’ button to change the switch-off time.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
T Press the
‘’ button to exit programming mode.
The harder the water is, the more frequently the E6 needs to be
descaled. It is therefore important to set the water hardness accu-
rately.
The water hardness was set when the machine was first used. You
can change this setting at any time.
The water hardness can be adjusted on a continuous scale between
1 °dH and 30 °dH.
Precondition:The start screen is displayed.
T Press the
‘ Pc ’ button.
T Press the
‘>’ button several times until page ‘4/4’ is
displayed.
T Press the
‘Water hardness’ button.
T Press the
‘<’ or ‘>’ button to change the setting for the
water hardness.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
T Press the
‘’ button to exit programming mode.
Automatic switch-off
Setting the water
hardness
25
4 Permanent settings in programming mode
In this programme item you can set the language used by your E6.
Example:Proceed as follows to change the language from
‘English’
to
‘Deutsch’.
Precondition:The start screen is displayed.
T Press the ‘ Pc ’ button.
T Press the
‘>’ button several times until page ‘4/4’ is
displayed.
T Press the
‘Choose language’ button.
E To display more languages, press the
‘>’ button.
T Press the button that corresponds to the language you
want, e.g.
‘Deutsch’.
‘Gespeichert’ appears briefly on the display.
T Press the
‘’ button to exit programming mode.
In the programme item
‘Units’ you can set the unit used for the
amount of water.
Example:Proceed as follows to change the unit for the amount of
water from
‘ml’ to ‘oz’.
Precondition:The start screen is displayed.
T Press the
‘ Pc ’ button.
T Press the
‘>’ button several times until page ‘4/4’ is
displayed.
T Press the
‘Units’ button.
T Press the
‘oz’ button.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
T Press the
‘’ button to exit programming mode.
Language
Unit for amount of water
26
5 Maintenance
5 Maintenance
Basic information about maintenance:
U
Press the ‘ Pc ’ button to view a list of the maintenance pro-
grammes. When the bar is completely filled with red, your E6
will prompt you to perform the appropriate maintenance pro-
gramme.
U
Carry out each maintenance programme when you are
prompted to do so.
U
In the interests of hygiene, you should clean the fine foam
frother daily when you have been preparing milk.
You can start coffee system rinsing manually at any time.
Precondition:The start screen is displayed.
T Place a receptacle under the coffee spout.
T Press the
‘ Pc ’ button.
T Press the
‘>’ button.
T Press the
‘Rinse the coffee system’ button to start the rinse
operation.
The operation stops automatically.
After each milk preparation, the E6 prompts you to perform a milk
system rinse.
Precondition:
‘Rinse the milk system’ is displayed.
T Place a receptacle under the fine foam frother.
T Press the
‘ Pc ’ button.
‘Open switch’
T Turn the switch to the§ position.
The fine foam frother is rinsed.
‘Close switch’
T Turn the switch to the °position.
Rinsing the machine
Rinsing the fine foam
frother
27
5 Maintenance
To ensure that the fine foam frother always works properly, you
must clean it daily when you have been preparing milk
If the wrong cleaning agent is used, the machine could be damaged
and/or traces could be left behind in the water.
T Use only original JURA maintenance products.
E JURA milk system cleaner is available from specialised dealers.
Precondition:The start screen is displayed.
T Press the
‘ Pc ’ button.
T Press the
‘Clean the milk system’ button.
T Press the
‘Start’ button.
T Press the
‘Next’ button.
‘Milk system cleaner’
T Remove the milk pipe from the milk container or milk cooler.
T Pour 250ml of fresh water into a receptacle and add 1 capful
of milk system cleaner.
T Immerse the milk pipe in the receptacle.
T Place a receptacle under the fine foam frother.
T Press the
‘Next’ button.
As soon as the machine has heated up,
‘Open switch’
appears.
T Turn the switch to the§ position.
The fine foam frother and the milk pipe are cleaned.
‘Close switch’
T Turn the switch to the °position.
‘Fresh water’
T Rinse the receptacle thoroughly, fill it with 250ml of fresh
water and immerse the milk pipe in the water.
T Empty the other receptacle and place it under the fine foam
frother once more.
T Press the
‘Next’ button.
‘Open switch’
T Turn the switch to the§ position.
The fine foam frother and the milk pipe are rinsed with fresh
water.
‘Close switch’
T Turn the switch to the °position.
Cleaning the fine foam
frother
CAUTION
28
5 Maintenance
To make sure the fine foam frother works properly, and in the inter-
ests of hygiene, it must be dismantled and rinsed daily if you have
been preparing milk.
T Remove the milk pipe and rinse it thoroughly under running
water.
T Remove the fine foam frother.
T Dismantle the fine foam frother into its individual parts.
T Rinse all the parts under running water. If there are severely
dried-on milk residues, firstly immerse the individual parts
in a solution of 250ml cold water and 1 capful of JURA milk
system cleaner. Then rinse the parts thoroughly.
T Re-assemble the fine foam frother.
E Ensure that all individual parts are correctly and firmly con-
nected to ensure optimum operation.
T Re-fit the fine foam frother on the milk system.
Your E6 no longer has to be descaled if you are using the CLARIS
Smart filter cartridge.
E Once the filter cartridge stops working (depending on the
water hardness setting), the E6 will prompt you to change the
filter.
E CLARIS Smart filter cartridges are available from specialised
dealers.
Precondition:The start screen is displayed. The filter symbol !
lights up red (if you are already using a filter and it is depleted).
T Remove and empty the water tank.
T Turn the filter cartridge anticlockwise and remove it along
with the extension from the water tank.
T Fit the filter cartridge extension on top of a new CLARIS
Smart filter cartridge.
Dismantling and rinsing
the fine foam frother
Inserting/changing the
filter
29
5 Maintenance
T Insert the filter cartridge with its extension into the water
tank.
T Turn the filter cartridge clockwise until it audibly clicks into
place.
T Fill the water tank with fresh, cold water and reinsert the
tank.
The machine automatically detects that you have just
inserted/changed the filter cartridge.
‘Open switch’
T Turn the switch to the§ position.
‘Filter is being rinsed’
‘Close switch’
T Turn the switch to the °position.
After 180preparations or 80switch-on rinses, the E6 will prompt you
to clean it.
If the wrong cleaning agent is used, the machine could be damaged
and/or traces could be left behind in the water.
T Use only original JURA maintenance products.
E The cleaning programme lasts approximately 20 minutes.
E Do not interrupt the cleaning programme. The quality of
cleaning will be impaired if you do so.
E JURA cleaning tablets are available from specialised dealers.
Precondition:
‘Clean machine’ is displayed.
T Press the
‘ Pc ’ button.
‘Clean’
T Press the ‘Start’ button.
T Press the
‘Next’ button.
‘Empty coffee grounds container’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Clean’
Cleaning the machine
CAUTION
30
5 Maintenance
T Place a receptacle under the coffee spout.
T Press the
‘Next’ button.
‘Machine is being cleaned’, water flows out of the coffee
spout.
The operation is interrupted,
‘Add cleaning tablet’.
T Open the cover of the filler funnel for the cleaning tablet.
T Insert a JURA cleaning tablet into the filler funnel.
T Close the cover of the filler funnel.
T Press the
‘Next’ button.
‘Machine is being cleaned’, water flows out of the coffee
spout several times.
The operation stops automatically.
‘Empty coffee grounds container’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
The E6 builds up deposits of limescale over time and automatically
prompts you to descale it when necessary. The degree of calcifica-
tion depends on the hardness of your water.
E If you are using a CLARIS Smart filter cartridge, you will not be
prompted to descale.
If the descaling agent comes into contact with the skin or eyes, this
can cause irritation.
T Avoid contact with the skin or eyes.
T Rinse off the descaling agent with clean water. Should you get
any descaling agent in your eye, see a doctor.
If the wrong descaling agent is used, the machine could be dam-
aged and/or traces could be left behind in the water.
T Use only original JURA maintenance products.
If the descaling operation is interrupted, there may be damage to
the machine.
T Allow the descaling programme to run to the end.
Descaling the machine
J
CAUTION
CAUTION
CAUTION
31
5 Maintenance
If the descaling agent comes into contact with sensitive surfaces
(e.g. marble), damage cannot be ruled out.
T Clean up any splashes immediately.
E The descaling programme lasts approximately 40minutes.
E JURA descaling tablets are available from specialised dealers.
Precondition:
‘Decalcify machine’ is displayed.
T Press the
‘ Pc ’ button.
‘Descale’
T Press the ‘Start’ button.
T Press the
‘Next’ button.
‘Empty drip tray’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Agent in tank’
T Remove and empty the water tank.
T Completely dissolve 3JURA descaling tablets in a receptacle
holding 500ml of water. This may take several minutes.
T Pour the solution into the empty water tank and insert it
into the machine.
‘Open switch’
T Place a receptacle under the fine foam frother.
T Turn the switch to the§ position.
‘Machine is being descaled’ appears and water flows out of
the fine foam frother repeatedly.
The operation is interrupted,
‘Close switch’.
T Turn the switch to the °position.
‘Machine is being descaled’, the descaling operation is con-
tinued.
The operation is interrupted,
‘Empty drip tray’.
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Rinse the water tank’ / ‘Fill water tank’
CAUTION
3x
32
5 Maintenance
T Empty the receptacle and place it under the fine foam
frother and the coffee spout.
T Remove the water tank and rinse it thoroughly.
T Fill the water tank with fresh, cold water and reinsert the
tank.
‘Open switch’
T Turn the switch to the§ position.
‘Machine is being descaled’, the descaling operation is con-
tinued.
The operation is interrupted,
‘Close switch’.
T Turn the switch to the °position.
The descaling operation is continued. Water flows out of the
coffee spout.
The operation is interrupted
‘Empty drip tray’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
E If the descaling operation stops unexpectedly, rinse the water
tank thoroughly.
Limescale deposits may form in the water tank. To ensure correct
function of the machine, descale the water tank from time to time.
T Remove the water tank.
T If you use a CLARIS Smart filter cartridge, remove this.
T Completely fill the water tank and dissolve 3 JURA descaling
tablets in it.
T Leave the water tank with the descaling solution for several
hours (e.g. overnight).
T Empty the water tank and rinse it thoroughly.
T If you use a CLARIS Smart filter cartridge, insert this again.
T Fill the water tank with fresh, cold water and reinsert the
tank.
Descaling the water tank
33
5 Maintenance
Coffee beans may be covered with a slight oil film which remains on
the walls of the bean container. These traces may negatively affect
the coffee result. For this reason clean the bean container from time
to time.
Precondition:
‘Fill bean container’ is displayed.
T Switch the machine off with the On/Off button Q.
T Remove the aroma preservation cover.
T Clean the bean container with a soft, dry cloth.
T Fill the bean container with coffee beans and close the
aroma preservation cover.
Cleaning the bean
container
34
6 Display messages
6 Display messages
Message Cause/Result Action
‘Fill water tank’ The water tank is empty. You
cannot prepare any products.
T Fill the water tank (see Chapter 3 ‘Daily
operation – Filling the water tank’).
‘Empty coffee
grounds
container’
The coffee grounds container is
full. You cannot prepare any
products.
T Empty the coffee grounds container and
the drip tray (see Chapter 3 ‘Daily
operation – Daily maintenance’).
‘Drip tray not
fitted’
The drip tray is not inserted
correctly or is not inserted at all.
You cannot prepare any products.
T Fit the drip tray.
‘Fill bean
container’
The bean container is empty.
You cannot prepare any speciality
coffees, but you can prepare hot
water and milk.
T Fill the bean container (see Chapter 1
‘Preparing and using for the first time –
Filling the bean container’).
‘Rinse the milk
system’
The E6 requests a milk system
rinse.
T Perform milk system rinsing (see
Chapter 5 ‘Maintenance – Rinsing the fine
foam frother’).
The filter
symbol at the
bottom of the
display lights
up red.
The filter cartridge no longer
works.
T Replace the CLARIS Smart filter cartridge
(see Chapter 5 ‘Maintenance – Inserting/
changing the filter’).
‘Clean machine’ The E6 is prompting you to clean
it.
T Perform cleaning (see Chapter 5
‘Maintenance – Cleaning the machine’).
‘Decalcify
machine’
The E6 is prompting you to
descale it.
T Perform descaling (see Chapter 5
‘Maintenance – Descaling the machine ’).
‘Too hot’ The system is too hot to start a
maintenance programme.
T Wait for several minutes until the
system has cooled or prepare a speciality
coffee or hot water.
35
7 Troubleshooting
7 Troubleshooting
Problem Cause/Result Action
Insufficient foam is
produced when the milk
is frothed or milk sprays
out of the fine foam
frother.
The fine foam frother is
dirty.
T Clean the fine foam frother
(see Chapter 5 ‘Maintenance – Cleaning
the fine foam frother’).
T Dismantle and rinse the fine foam
frother (see Chapter 5 ‘Maintenance –
Dismantling and rinsing the fine foam
frother’).
Coffee only comes out in
drips when it is being
prepared.
The coffee is ground too
finely and obstructs the
system. The water hardness
may not have been
correctly set.
T Set the grinder to a coarser setting
(see Chapter 2 ‘Preparation – Adjusting
the grinder’).
T Perform descaling (see Chapter 5
‘Maintenance – Descaling the
machine ’).
‘Fill water tank’ is
displayed although the
water tank is full.
The water tank float is
trapped.
T Descale the water tank (see Chapter 5
‘Maintenance – Descaling the water
tank’).
Little or no water or
steam comes out of the
fine foam frother.
The pump is very quiet.
The connector of the fine
foam frother may be
blocked by milk residues or
limescale fragments
loosened during descaling.
T Remove the fine foam frother.
T Unscrew the black connector.
T Clean the connector thoroughly.
T Screw the connector back on tightly
by hand.
Grinder is making a very
loud noise.
There are foreign objects
in the grinder.
T Contact customer support in your
country (see Chapter 11 ‘JURA contact
details/ Legal information’).
‘ERROR2’ or ‘ERROR5’
is displayed.
If the machine has been
exposed to the cold for a
long period of time,
heating may be disabled
for safety reasons.
T Warm the machine at room tempera-
ture.
36
7 Troubleshooting
Problem Cause/Result Action
Other
‘ERROR’ messages
are displayed.
–
T Switch the E6 off with the
On/Off button Q. Contact customer
support in your country (see Chapter 11
‘JURA contact details/ Legal informa-
tion’).
E If you were unable to solve the problem, contact customer
support in your country (see Chapter 11 ‘JURA contact details/
Legal information’).
37
8 Transport and environmentally friendly disposal
8 Transport and environmentally friendly disposal
Keep the packaging for your E6. It should be used to protect the
machine during transport.
In order to protect the E6 from frost during transport, the system
must be emptied.
Precondition:The start screen is displayed.
T Remove the milk pipe from the fine foam frother.
T Place a receptacle under the fine foam frother.
T Press the
‘Milk foam’ button.
As soon as the machine has heated up,
‘Open switch’
appears.
T Turn the switch to the§ position.
‘Milk foam’, hot steam is discharged from the fine foam
frother.
T Remove and empty the water tank.
T Press the
‘>’ button several times until ‘Amount of milk’ /
‘60sec.’ is displayed.
Steam will continue to be discharged from the fine foam
frother until the system is empty.
‘Close switch’
T Turn the switch to the °position.
‘Fill water tank’
T Press the On/Off button Q.
Your E6 is switched off.
Please dispose of old machines in an environmentally neutral way.
H
Old machines contain valuable, recyclable materials which should
be recycled. Please therefore dispose of old machines via suitable
collection systems.
Transport/ Emptying the
system
Disposal
38
9 Technical data
9 Technical data
Voltage 220–240V~, 50Hz
Power 1450W
Conformity mark
A
Pump pressure static, max. 15bar
Holding capacity of water tank
(without filter)
1.9l
Holding capacity of bean container 280g
Holding capacity of coffee grounds
container
max. 16 portions
Cable length approx. 1.1m
Weight approx. 9.6kg
Dimensions (WHD) 28.0 35.1 43.9cm
Information for testers (repeat test in accordance with DIN VDE
0701-0702): The central grounding point (CGP) is located on the
underside of the machine, right next to the mains cable's connec-
tion point.
39
10 Index
10 Index
A
Addresses 44
Adjusting the product settings 22
Aroma preservation cover
Bean container with aroma preservation
cover 4
Automatic switch-off 24
B
Bean container
Bean container with aroma preservation
cover 4
Cleaning 33
Filling 10
Bus bar
Technical data 38
Button
On/Off button 4
Bypass amount of water 15
C
Caffè Barista 15
Cappuccino 15
Central grounding point 38
CLARIS Smart filter cartridge
Changing 28
Inserting 28
Cleaning
Bean container 33
Fine foam frother 27
Machine 29
Coffee 14
Two coffees 14
Coffee grounds container 4
Coffee spout
Height-adjustable coffee spout 4
Connect accessory 13
Consistency of grind
Adjusting the grinder 18
Grinder adjustment switch 4
Contact details 44
Cover
Filler funnel for cleaning tablet 4
Water tank 4
Cup grille 4
Customer support 44
D
Daily maintenance 19
Descaling
Machine 30
Water tank 32
Display 5
Display messages 34
Disposal 37
Double product 14
Drip tray 4
E
Emptying the system 37
Errors
Troubleshooting 35
Espresso 14
Two espressi 14
Espresso doppio 16
F
Filler funnel
Filler funnel for cleaning tablet 4
Filling
Bean container 10
Water tank 19
Filter
Changing 28
Inserting 28
Fine foam frother 4
Cleaning 27
Dismantling and rinsing 28
Rinsing 26
First-time use 11
G
Grinder adjustment switch 4
Grounding point 38
H
Height-adjustable coffee spout 4
Hotline 44
Hot water 16
Hot water and steam preparation
Switch for hot water and steam
preparation 5
40
10 Index
J
JURA
Contact details 44
L
Language 25
M
Macchiato 15
Machine
Cleaning 29
Daily maintenance 19
Descaling 30
Regular maintenance 20
Rinsing 26
Setting up 10
Switching off 20
Switching on 19
Mains cable 4
Maintenance 26
Daily maintenance 19
Regular maintenance 20
Messages, display 34
Milk
Connecting milk 12
Milk foam 16
Milk system
Cleaning the fine foam frother 27
Rinsing the fine foam frother 26
P
Permanently setting the water for the
cup size 17
Permanent settings in programming
mode 22
Preparation 14
Cappuccino 15
Coffee 14
Espresso 14
Espresso doppio 16
Hot water 16
Lungo Barista 15
Macchiato 15
Milk foam 16
Two coffees 14
Two espressi 14
Two speciality coffees 14
Problems
Troubleshooting 35
Product settings
Adjusting 22
Programming mode 22
Automatic switch-off 24
Language 25
Setting the water hardness 24
Unit for amount of water 25
Proper use 6
R
Regular maintenance 20
Rinsing
Fine foam frother 26
Machine 26
S
Safety 6
Safety information 6
Settings
Permanent settings in programming
mode 22
Setting up
Setting up the machine 10
Smart Connect 13
Switch for hot water and steam
preparation 5
Switching off 20
Switching on 19
Switch-off
Automatic switch-off 24
Symbol description 3
T
Technical data 38
Tel 44
Transport 37
Troubleshooting 35
Two products 14
U
Unit for amount of water 25
Use, First-time 11
41
10 Index
W
Water hardness
Determining the water hardness 10
Setting the water hardness 24
Water tank 4
Descaling 32
Filling 19
Wireless connection 13
42
43
44
11 JURA contact details/ Legal information
11 JURA contact details/ Legal information
JURA Elektroapparate AG
Kaffeeweltstrasse 10
CH-4626 Niederbuchsiten
Tel. +41 (0)62 38 98 233
E You will find additional contact details for your country at
www.jura.com.
E If you need assistance with using your machine, you can find
this at www.jura.com/service.
The machine complies with the following directives:
U
2014/35/EU– Low Voltage Directive
U
2014/30/EU– Electromagnetic Compatibility
U
2009/125/EC– Ecodesign Directive
U
2011/65/EU– RoHS Directive
We reserve the right to make technical changes. The diagrams used
in these instructions for use are for illustration purposes only and do
not represent the original colours of the machine. Some details of
your E6 may vary.
Your opinion is important to us! Use the contact details at
www.jura.com.
The instructions for use contain information which is protected by
copyright. It is not permitted to photocopy these instructions for use
or translate them into another language without the prior written
consent of JURA Elektroapparate AG.
Directives
Technical changes
Feedback
Copyright
J74319/E6/en/201907
