Overview
概覽
Preparing for use
準備使用
Using the induction cooker
使用電磁爐
Using the timer
使用定時功能
Cleaning
清潔
Recommended types and sizes of cookware
建議的廚具種類和大小
Specifications are subject to change without notice
© 2016 Koninklijke Philips N.V.
All rights reserved.
HD4937_AUS_UM_v4.0
HD4937
Always there to help you
Register your product and get support at
www.philips.com/welcome
Preset time for delayed cooking
預約時間延時烹飪
English
1 Your induction cooker
Congratulations on your purchase and welcome to
Philips! To fully benet from the support that Philips
oers, register your product at www.philips.com/
welcome.
2 What’s in the box
Induction cooker main unit Warranty card
Important information leaet User manual
Magnet
Overview
a
Cooking plate
d
Control panel
b
Cooking zone
e
Air outlets
c
Air inlet
f
Power cord
Controls overview
g
Congee button
q
On/O button
h
Saute button
r
Hot Pot button
i
Steam/Stew button
s
Boil button
j
Roast button
t
Increase button
k
Soup button
u
Preset/Timer button
l
Milk/Fondue button
v
Decrease button
m
Preset indicator
w
Manual button
n
Display screen
x
Slow Cook button
o
Timer indicator
y
Menu button
p
Cooking power
3 Before first use
Remove all packaging materials from the induction
cooker.
Preparing for use
1 Place the appliance on a dry, stable and level
surface.
2 Make sure there is at least 10cm free space around
the appliance to prevent overheating.
3 Always place the cookware on the cooking zone
during cooking.
4 Make sure you use cookware of the correct types
and sizes (see the table below).
Recommended types and sizes of
cookware
Material Cookware with a bottom made of iron or
magnetic stainless steel
Shape Cookware with a at bottom
4 Using the induction cooker
There are ten cooking modes: Congee ( ), Saute
( ), Steam/Stew ( ), Roast ( ), Soup ( ),
Milk/Fondue ( ), Slow Cook ( ), Manual ( ),
Boil ( ) and Hot Pot ( ).
1 Follow the steps in “Preparing for use”.
2 Press the On/O button ( ), the On/O indicator
lights up.
3 Press the cooking buttons or the Menu button
to choose the desired cooking mode. The
corresponding indicator lights up and the
induction cooker starts working in the selected
mode.
4 When the cooking is nished, press the On/O
button ( ) to switch o the appliance.
5 Unplug the induction cooker after the fan stops
working.
Note
• During cooking, you can change the power level by
pressing the Increase ( ) or Decrease ( ) button.
• In Boil ( ), Soup ( ), Steam/Stew ( ), Congee ( )
and Milk/Fondue ( ) modes, the cooking power
automatically changes for better cooking result.
Default cooking time and temperature
Refer to below table for the default cooking time and
temperature of dierent cooking modes.
Cooking mode Default cooking power
Congee ( )
1400W (0-2 mins)
1600W (3-15 mins)
1400W (16-25 mins)
400W (26-60 mins)
100W (60 mins onwards)
Saute ( ) 1200W (adjustable)
Steam/Stew ( )
1800W (0-5 mins)
1400W (6-15 mins)
1200W (15 mins onwards)
Roast ( ) 1200W
EN User manual ZH-T 使用手冊
Cooking mode Default cooking power
Soup ( )
1400W (0-2 mins)
1600W (3-15 mins)
1400W (16-25 mins)
400W (26-60 mins)
100W (60 mins onwards)
Milk/Fondue ( ) 800W
Slow Cook ( )
1800W (0-2 mins)
1600W (3-15 mins)
1400W (16-25 mins)
400W (26 mins onwards)
Manual ( ) 1200W (adjustable)
Boil ( )
Starts with 1800W.
When water is brought to boil,
the power drops to 800W
and the appliance keeps the
water at boiling temperature
for another 3 minutes. After
that the appliance turns o
automatically.
Hot Pot ( ) 1800W (adjustable)
Cooking
mode
Default
cooking
time
Timer Ideas for Use
Congee ( ) 3 hrs
1-180 mins
Lentils,
Legumes,
Beans
Saute ( ) 2 hrs
1-120 mins
/
Steam/Stew
( )
1 hr
1-120 mins
Casseroles
Stewing Fruit
Roast ( ) 2 hrs
1-120 mins
/
Soup ( ) 3 hrs
1-180 mins
/
Milk/Fondue
( )
20 mins
/
Good for Dairy
Chocolate/
Cheese Fondu
Slow Cook
( )
6 hrs
1-600
mins
Lamb Shanks
Manual ( ) 2 hrs
1-120 mins
Boiling water
and leaving
it on boil for
your Pasta &
Noodle
Maker Dem-
onstrations
Boil ( ) 20 mins
/
Bring water
to boil for a
cuppa
www.philips.com/welcome
User manual
HD4937
www.philips.com/welcome
Safety leaet
HD4937
www.philips.com/welcome
Warranty
HD4937
10cm
10cm
c
a
b
d
e
f
g h i j k l n om p
u tvwxy rs q
• If the magnet sticks to your pan / cookware, then it will be suitable
for use on your Philips induction cooker. Please use the magnet in
the box for checking.
• 如果磁性貼可以貼住您的平底鍋
/
炊具，則該平底鍋
/
炊具適用于您的飛利浦
電磁爐。請使用包裝盒內的磁性貼進行檢測。
Material: Ferrous/Magnetic
材質：鐵制
/
磁性
