English
Congratulations on your purchase, and welcome to Philips! To fully
benet from the support that Philips offers, register your product at
www.philips.com/welcome.
1 Important
Read this user manual carefully before you use the appliance and keep it
for future reference.
• WARNING: Do not use this appliance
near water.
• Never immerse the brush body in
water or any other liquid, nor rinse it
under the tap.
• Always switch off the appliance after
use.
• This appliance can be used by
children aged from 8 years and above
and persons with reduced physical,
sensory or mental capabilities or
lack of experience and knowledge
if they have been given supervision
or instruction concerning use of
the appliance in a safe way and
understand the hazards involved.
• Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
• Always return the appliance to a
service centre authorized by Philips
for examination or repair. Repair by
unqualied people could result in an
extremely hazardous situation for the
user.
• Never use any accessories or
parts from other manufacturers
or that Philips does not specically
recommend. If you use such
accessories or parts, your guarantee
becomes invalid.
Register your product and get support at
在以下网站注册并获得支持
www.philips.com/welcome
HP4585
HP4586
HP4588
HP4589
EN User manual
ZH-CN 用户手册
© 2015 Koninklijke Philips N.V.
保留所有权利
3140 035 38734
• Do not use the appliance for any
other purpose than described in this
manual.
• Do not use the appliance on articial
hair.
• Never block the ion outlet.
• Do not insert metal objects into
the ion outlet to avoid unexpected
dangers.
• Do not use this ion brush together
with hairdryer for styling purpose.
• Never rinse the brush body under tap
water.
• Do not expose the brush under
sunlight for long period of time. The
ultraviolet ray may lead to aging in the
brush, which the product can break
easily.
• Use and store the appliance at a
temperature between 15ºC and 35ºC.
• The applicance runs on one 1.5V
AAA alkaline battery.
• Open battery compartment in order
to install or remove the battery.
• The bypack battery is not
rechargeable. Non-rechargeable
batteries are not to be recharged.
• The rechargeable battery must be
removed out of the appliance before
being charged.
• Batteries are to be inserted with the
correct polarity.
• Exhausted batteries are to be
removed from the appliance and safely
disposed of.
• If the appliance is to be stored unused
for a long period, the batteries should
be removed.
• The supply terminals are not to be
short-circuited.
Electromagnetic elds (EMF)
This Philips appliance complies with all applicable standards and
regulations regarding exposure to electromagnetic elds.
Environment
Do not throw away the appliance with the normal household
waste at the end of its life, but hand it in an ofcial collection
point for recycling. By doing this, you help to preserve the
environment.
2 Introduction
The new Philips Ionic Styling Brush helps to make your hair smooth
and shiny anytime, anywhere with great brushing experience.
• Ionic Care
This ionic styling brush has built-in ionizer, which generates negative ions
and neutralize positive charge of static electricity. It helps to reduce frizz
and bring back shine and smoothness to your hair instantly.
• Gentle Bristle
All bristles tips are seamless to avoid scrubbing damage on scalp or hair
trapping during usage. The special round ball tip has bigger touching
surface so that it’s more gentle to vulnerable scalp.
• Optimal 3D Large Cushion
The optimally designed bristle cushion enables better force distribution
and follows the contours of the head naturally for more convenience
and comfort.
• Ergonomic Shape Brush
The seamless and ergonimically curved shell ts in women’s hand
perfectly, ensuring great handling experience.
• Detachable Bristle Cushion
Bristle cushion can be easily detached so that you may clean it with
water regularly to keep bristle clean.
3 Use your ionic styling brush
Install and detach the brush cushion
1 ( Fig.C ) To remove the brush cushion ( a ), push the release
button ( b ) to detach it.
2 ( Fig.E ) To install the brush cushion ( a ), press it down into the
brush body, you will hear a “click” if it is installed correctly.
Install and remove the battery
The ionic styling brush runs on one 1.5V AAA alkaline battery. (Fig. D)
We provide with one 1.5V AAA battery.
1 To remove the battery compartment cover, pull it off the appliance.
2 Put the battery in the battery holder or remove the battery out of
the compartment.
3 Push the battery compartment cover back onto the
appliance (‘click’).
Note
• Make sure that the + and - poles of the battery point in the right
direction.
• Make sure that your hands are dry when you insert the battery.
• To avoid damage due to battery leakage. Remove the battery if
you are not going to use the appliance for a month or more.
• Do not leave empty battery in the appliance.
Brush your hair ( Fig.B )
1 Turn on the ion styling brush by sliding the power on/off switch
( f ) to .
» The power-on indicator ( d ) lights up.
» When the appliance is powered on, ions are automatically and
continuously released, reducing frizz and providing additional
shine.
» You may hear a sizzling sound. It’s commom because it is caused
by the ion generator.
2 Brush softly your hair from the roots to the ends. Repeat this step
several times for smoother results.
3 Switch to to switch off the appliance.
» You may hear a sizzling sound. It’s common because the ions are
not released fully.
After use:
1 You can use a damp cloth to clean the brush body ( e ).
2 To clean the brush cushion ( a ):
• Use your ngers to remove the dust or hair on the brush.
• Detach the brush cushion from the brush body and rinse it under
tap water (Fig. F).
Note
• Make sure the brush cushion is completely dried before re-
attaching to the brush body.
• Never use corrosive liquid to clean the brush cushion as it
may cause damage to the product. It is recommended to use
household cleanser to clean the brush cushion if needed.
3 Keep it in a safe and dry place or put it in your makeup bag for daily
use.
Tips & Tricks
1 The ionic brush performs better when the hair is slightly wet.
2 If you wish to use the brush after washing your hair, dry your hair
until 70% dry. Do not over dry your hair because it may affect the
result.
3 Comb your hair slowly and repeatedly from the root until your hair
is smooth. The time to comb varies according to your hair type and
length.
4 It is not easy to observe the effect if :
• you have short or natural curly hair.
• your hair is easy to curl.
• your hair condition is too dry or damaged.
• you have straightening perm within 3 to 4 months.
• you have some short newly grown hair.
5 Apply leave in hair conditioner to your hair after brushing for
best result.
4 Guarantee and service
If you need information e.g. about replacement of an attachment or if
you have a problem, please visit the Philips website at www.philips.com
or contact the Philips Customer Care Centre in your country (you nd
its phone number in the worldwide guarantee leaet). If there is no
Consumer Care Centre in your country, go to your local Philips dealer.
The bristle has a guarantee period of 3 months. If needed, you may
purchase a separate bristle from Philips service center.
5 Troubleshooting
Problem Cause Solution
The appliance
does not
work.
The battery is
exhausted.
Replace the battery.
You have not place
the battery in the
battery compartment
correctly.
Put the battery in the
compartment in accordance
with the + and - indications
in the compartment.
You have not
attach the battery
compartment cover
properly.
Push the battery
compartment cover onto
the appliance (‘click’).
The ion
indicator does
not light up
The battery is installed
incorrectly.
The battery is nearly
empty.
Check if the battery is
installed with the right pole.
Replace with a new battery.
简体中文
感谢您的惠顾，欢迎光临飞利浦！为了
您能充分享受飞利浦提供的支持，请在
www.philips.com/welcome 注册您的
产品。
1 重要事项
使用产品之前，请仔细阅读本用户手册，
并妥善保管以供日后参考。
• 警告：请勿在靠近水的地方使用本
产品。
• 警告符号注释：禁止用在打
开的水龙头下进行清洗。
• 不要将梳体浸入水中，也不
要在自来水龙头下冲洗。
• 使用后，务必关闭产品电源。
• 本产品适合由 8 岁或以上年龄的儿
童以及肢体不健全、感觉或精神上
有障碍或缺乏相关经验和知识的人
士使用，但前提是有人对他们使用
本产品进行监督或指导，以确保他
们安全使用，并且让他们明白相关
的危害。
• 不得让儿童玩耍本产品。不要让儿
童在无人监督的情况下进行清洁和
保养。
• 产品只能送到飞利浦授权的服务中
心检修。由不合格人员进行修理可
能将用户置于极度危险的境地。
• 切勿使用由其它制造商生产的，或
未经飞利浦特别推荐的任何附件或
部件。如果使用此类附件或部件，
您的保修将失效。
• 请勿将本产品用于本手册中说明以
外的任何其它用途。
• 请勿将产品用于假发。
• 请勿阻塞负离子排出口。
• 请勿将金属物体插入负离子排出
口，避免出现意外危险。
• 请勿将负离子造型梳与电吹风一起
使用进行美发造型。
• 请勿在水龙头下冲洗梳体。
• 请勿将造型梳长时间曝晒于阳光
下。紫外线可能导致造型梳老化，
造成产品容易折断。
• 建议在 15ºC 至 35ºC 之间的温度
下使用和存放产品。
• 产品使用一节1.5V AAA碱性电池工
作。
• 打开电池盖以安装或取出电池。
• 随附的电池为非可充电电池。 不可
对非可充电电池进行充电。
• 若使用可充电电池, 电池充电前须将
其从产品中取出。
• 安装电池时需确保极性正确。
• 电池电量耗尽后, 应将其从产品中取
出并安全地弃置。
• 若长期不使用本产品, 应将电池
取出。
• 产品的正负极之间不可短路。
电磁场(EMF)
本飞利浦产品符合所有有关暴露于电磁场
的适用标准和法规。
环保
弃置产品时，请不要将其与一般生
活垃圾堆放在一起；应将其交给官
方指定的回收中心。这样做有利于
环保。
2 简介
飞利浦全新上市的负离子造型梳能够随时
随地保持您的秀发顺滑柔亮，同时带来出
色的使用体验。
• 负离子养护
该负离子梳内置离子发生器，可以产生负
离子，中和静电的正电荷。有助于减少
静电带来的毛躁，即时重现顺滑柔亮的
秀发。
• 圆润梳齿
所有梳齿尖端均采用圆润光滑无缝连接，
避免在使用过程伤害头皮或拉扯头发。特
殊球形顶端具有更大的接触面，更轻柔地
呵护脆弱的头皮。
• 3D充气齿垫
经过优化设计的梳齿垫能够获得更好地分
散作用力，自然跟随头部轮廓，用起来更
方便舒适。
• 人性化的梳体设计
根据人体工程学设计的弧面背壳能很好的
贴合女士的手形，确保出色的握持体验。
• 可拆卸梳齿垫
梳齿垫可轻松拆卸，便于经常用水清洁，
令梳齿始终洁净如新。
E
D
C
B
F
a
b
c
d
e
g
f
A
English
a Brush cushion
b Brush cushion relase button
c Ion outlet
d Power-on indicator
e Brush body
f Power on/off switch
g Battery compartment
