Blu-ray Disc™ / DVD
Player
Owner's Manual
Manual del Propietario
FWBP505F
To obtain a more detailed Electronic Copy of this
Manual or much further contents, go to
Para obtener una Copia Electrónica más detallada de este Manual o mucho otras
contenido, visite
www.sanyo-av.com
Need help? Please Call Toll Free 1 866 212 0436 or visit our Web Site above:
¿Necesita ayuda? Llame por favor sin costo al 1 866 212 0436 ó visite nuestro
Sitio Web en:
2
CONTENTS
INTRODUCTION ................................................3
Safety Instructions .................................................... 3
Included Accessories ................................................ 4
FEATURES ......................................................... 5
Features .....................................................................5
Product Info ............................................................... 6
Symbols Used in this Owner’s Manual ...................6
FUNCTIONAL OVERVIEW ................................ 7
Front Panel ................................................................7
Rear Panel..................................................................7
Remote Control ......................................................... 8
Guide to On-Screen Display ..................................10
CONNECTIONS ............................................... 11
Connection to a TV .................................................. 11
Connection to an Audio System ............................12
HDMI Audio Output ................................................13
BEFORE YOU START ....................................... 14
Finding a Viewing Video Source Input on Your TV 14
Initial Setup .............................................................14
INFORMATION ON PLAYBACK ...................... 16
Information on Playback ........................................ 16
Guide to File List ..................................................... 19
How to Insert a Disc ................................................19
BASIC PLAYBACK ........................................... 20
Playing Back a Disc ................................................. 20
Playing Back Contents from a USB Memory Stick ..21
Using the T itle / Disc / Pop Menu...........................22
SPECIAL PLAYBACK ....................................... 23
Fast Forward / Fast Reverse ................................... 23
Slow Forward Playback ..........................................23
Step by Step Playback ............................................ 23
Repeat Playback ...................................................... 24
Slide Show ..............................................................24
PiP (BONUSVIEW™) Setting .................................. 25
Title / Chapter Search .............................................26
Track / File Search ...................................................26
Time Search ............................................................ 27
Number Select Search ............................................27
Switching Subtitles .................................................28
Switching Audio Soundtrack ..................................29
Switching Camera Angles ...................................... 30
Noise Reduction ......................................................30
CLEAR+ .................................................................... 31
LIST OF SETTINGS ......................................... 32
SETUPS ........................................................... 35
HDMI CEC ................................................................ 35
HDMI Video Resolution ..........................................36
Parental ....................................................................37
Software Update .....................................................39
Voice Guide .............................................................40
Restore Default Settings .........................................40
TROUBLESHOOTING ...................................... 41
LANGUAGE CODE LIST .................................. 44
SPECIFICATIONS ............................................. 45
MAINTENANCE ............................................... 46
TRADEMARK INFORMATION ........................ 47
GLOSSARY ......................................................48
LIMITED WARRANTY ...................................... 50
ESPAÑOL ......................................................... 51
Mando a Distancia .................................................. 51
Encontrar el Canal de Video en su Televisor .........52
Instalacion Inicial ....................................................53
GARANTÍA LIMITADA .....................................54
EN 3
Register Online at www.sanyo-av.com/support/ today to get the most benefits from your purchase.
Registering your model with SANYO makes you eligible for all of the valuable benefits such as software
upgrades and important product notifications. Register Online at www.sanyo-av.com/support/
1. INTRODUCTION
1.1. Safety Instructions
To Avoid the Hazards of Electrical Shock and Fire
• Do not handle the AC power cord with wet hands.
• Do not pull on the AC power cord when disconnecting it from an AC outlet. Grasp it by the plug.
• Do not put your fingers or objects into the unit.
Location and Handling
• Do not install the unit in direct sunlight, near strong magnetic fields, or in a place subject to dust or strong
vibration.
• Avoid a place with drastic temperature changes.
• Install the unit in a horizontal and stable position. Do not place anything directly on top or bottom of the unit.
Depending on your external devices, noise or disturbance in the picture and/or sound may be generated if
the unit is placed too close to them. In this case, please ensure enough space between the external devices
and the unit.
• Depending on the environment, the temperature of this unit may increase slightly. This is not a malfunction.
• Be sure to remove the disc and unplug the AC power cord from the outlet before moving the unit.
• In order to avoid interruption of ventilation, this unit should not be placed in built-in equipment such as a
book cabinet, rack, etc., and the vents of this unit should not be covered with anything such as a tablecloth,
curtain, newspaper, etc. Make sure to leave a space of 5.9 inches (15cm) or more around this apparatus.
• When installing this unit in a temperate environment, avoid a place with rapid temperature changes.
• This unit should not be used in a tropical environment as it has not been evaluated under such conditions.
• No objects should be placed directly on or under this unit, especially lighted candles or other flaming
objects.
Dew Condensation Warning
• Dew condensation may form inside the unit in the following conditions. If so, do not use this unit at least for
a few hours until its inside gets dry.
- The unit is moved from a cold place to a warm place.
- Under conditions of high humidity.
- After heating a cold room.
Note about Recycling
• This unit’s packaging materials are recyclable and can be reused. Please dispose of any materials
in accordance with your local recycling regulations.
• Batteries should never be thrown away or incinerated but disposed of in accordance with your
local regulations concerning chemical wastes.
• For product recycling information, please visit - www.sanyo-av.com
Click on
Disposal of Used Batteries
• In certain localities, disposing batteries with household waste is not permitted. Please ensure you dispose of
batteries according to local regulations.
EN 4
1.2. Included Accessories
• Remote Control (NC092UL)
• Quick Start Guide
SANYO is a registered trademark of SANYO Electric Co., Ltd. and is used by Funai Electric Co., Ltd. and Funai
Corporation, Inc. under license from SANYO Electric Co., Ltd.
Any liability related to SANYO products, including design and quality, is the sole responsibility of Funai Electric
Co., Ltd. and Funai Corporation, Inc.
Please contact Funai Corporation, Inc. for any questions or claims related to SANYO products:
www.sanyo-av.com
© 2017 Funai Electric Co., Ltd.
All rights reserved. No part of this manual may be reproduced, copied, transmitted, disseminated, transcribed,
downloaded or stored in any storage medium, in any form or for any purpose without the express prior written
consent of Funai.
Furthermore, any unauthorized commercial distribution of this manual or any revision hereto is strictly prohibited.
Information in this document is subject to change without notice. Funai reserves the right to change the content
herein without the obligation to notify any person or organization of such changes.
EN 5
2. FEATURES
2.1. Features
Blu-ray Disc™
You can enjoy Blu-ray Disc™ which is capable of
storing five times more data than a conventional DVD.
BD-Java
With some Blu-ray discs which contain Java
applications, you can enjoy interactive functions such
as games or interactive menus.
DVD upscaling for enhanced picture quality
Your current DVD will look even better than before
thanks to video upscaling. Upscaling will increase
the resolution of standard definition DVD to high
definition up to 1080p over an HDMI connection. The
picture will be less jagged and more realistic for a
near high definition experience.
Enjoy your content on different kinds of media
Full backwards compatibility with DVD, CD and USB
Memory Stick ensures that you can continue to enjoy
your current audio-video collection. Additionally, you
can enjoy AVCHD (for DVD-RW/-R only) / JPEG files.
Listen to rich multi-channel surround sound
Multi-channel surround sound, which realizes real-
to-life sound and makes you feel that you are really
there.
Easy and simple connection to your HDTV via HDMI
Connect this unit to your HDTV with one single HDMI
(High-Definition Multimedia Interface) cable. It is
recommended to use a High Speed HDMI cable for
better compatibility. The high definition video output
signal will be transferred to your HDTV without
conversion to analog signals, so you will get excellent
picture and sound quality, completely free from noise.
Thanks to other multiple outputs, you can also easily
connect to your home theater system or amplifier.
HDMI CEC(Consumer Electronics Control)
This unit supports HDMI CEC, which allows integrated
system control over an HDMI cable and is part of the
HDMI standard. This function may not work properly
on some devices.
PiP (BONUSVIEW™)
Some BD-videos have the PiP function which enables
you to display the Secondary Video in the Primary
Video. You can call up the Secondary Video by
pressing [MODE] whenever the scene contains a
Secondary Video.
Pop Menu
Some BD-videos have a Pop Menu which is a
navigation menu that can be called up and be
operated on the TV screen without interrupting
playback. You can call up the Pop Menu by pressing
[DISC MENU]. Contents in the Pop Menu vary
depending on the disc.
HDMI 1080p/24 output (Blu-ray Disc™ only)
This unit is equipped with the feature which can
provide smooth movement during playback of film
originated material with the frame rate of 24 frames
per second with progressive. (Available only when
the display device is connected with an HDMI cable.)
Refer to ˝HDMI Video Resolution˝ on page 36.
Playing back contents from a USB Memory Stick
You can play back JPEG files stored on a USB Memory
Stick. BD-ROM discs sometimes store picture-in-
picture commentary, subtitles or other extras on a
USB Memory Stick for use during playback with the
BD-video.
Playing back AVCHD files
This unit supports playback of AVCHD format files
(new format for high definition video camcorders)
recorded on a disc / SD Memory Card using USB card
reader / USB hub (not included). Your high definition
personal archive is playable in HD quality.
x.v.Color
This unit supports playback of video contents on
discs recorded with ˝x.v.Color˝ technology. To watch
this video content with the ˝x.v.Color˝ space, a TV or
other display device supporting both video image
reproduction using ˝x.v.Color˝ standard and capability
of manual switching of its color space setting is
required. Please refer to the user manual of your
display device for further information.
EN 6
2.2. Product Info
˝Product Info˝ screen provides information about this unit’s software version.
You can also download the latest software from the SANYO website and update it yourself if it is newer than
the version currently on your unit. The current version of software on your unit can be seen on the ˝Product
Info˝ screen.
To access ˝Product Info˝, follow the procedure below.
1. Press [HOME].
2. Use [
] to select ˝Settings˝, then press [OK].
3. Use [
] to select ˝Others˝, then press [OK].
4. Use [
] to select ˝Product Info˝, then press [OK].
2.3. Symbols Used in this Owner’s Manual
To specify which media type each function is applicable to, a combination of the symbols shown below will be
depicted next to that function's explanation.
Symbol Description
[BD Video]
Description refers to BD-video
[DVD Video]
Description refers to DVD-video
[CD]
Description refers to audio CD / DTS-CD
[AVCHD]
Description refers to DVD-RW/-R with AVCHD files
[JPEG]
Description refers to BD-RE/-R, DVD-RW/-R, CD-RW/-R and USB Memory Stick with JPEG files
If you do not find any of the symbols listed above under the function heading, the operation is applicable to all
media.
EN 7
3. FUNCTIONAL OVERVIEW
3.1. Front Panel
1 3* 4*2 5 6 7
* The unit can also be turned on by pressing this button.
1. Disc tray
2. Infrared sensor window
3.
(OPEN/CLOSE) button*
4.
(PLAY/PAUSE) button*
• Press to start playback or resume playback.
• During playback, press to pause playback.
5.
(POWER) button
6. Power-On indicator
• Flashes while unit is starting up.
• Dims and flickers when IR remote signal is
received.
7. USB Input
CautionC
• Do not connect any device other than USB Memory Stick or USB card reader into the USB Input. (e.g. PC,
external HDD, digital camera, keyboard, mouse, etc.)
• When connecting a USB Memory Stick, connect it directly to the USB Input. Do not use a USB extension
cable.
NoteD
• Due to new ENERGY STAR
®
requirements, this unit will automatically turn on the screen saver after 5
minutes of inactivity and enter standby mode after 25 minutes of inactivity.
3.2. Rear Panel
21
1. AC power cord 2. HDMI OUT jack
CautionC
• Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent
damage to the unit.
• This unit does not have a TV RF modulator.
EN 8
3.3. Remote Control
1 12*
13
14
16
17
2
3
4
11
15
18
19
5
6*
7
8
20
21
9
10
* The unit can also be turned on by pressing these
buttons.
1.
(POWER) button
• Press to Turn On the unit, or to switch the unit
into Standby mode. (To completely Turn Off the
unit, you must unplug the AC power cord.)
2. DISC MENU button
• During Playback (Blu-ray Disc™ or DVD), press
to select the Menu (Top Menu or Pop Menu/
Menu).
3.
buttons
• Press to select items or settings.
4. SEARCH button
• Press to display the Number Select Menu or the
Search Menu.
5.
(REVERSE) button
• During playback, press to Fast Reverse the
playback.
6.
(PLAY) button*
• Press to start playback or resume playback.
7.
(SKIP) button
• During playback, press once to return to the
beginning of the current Title, Chapter, Track or
File.
• During playback, press twice to return to the
previous Title, Chapter, Track or File.
• During the JPEG playback, press to return to the
previous File.
8.
(STOP) button
• Press to Stop playback.
9. DISPLAY button
• Press to Display the on-screen display menu.
10. REPEAT button
• Press to select Repeat mode.
11. RED / GREEN / BLUE / YELLOW buttons
• Press to activate shortcut keys on some BD-
video functions. When a file list is shown, press
to switch between pages.
12.
(OPEN/CLOSE) button*
• Press to Open or Close the disc tray.
13. HOME button
• Press to display the Home Menu.
14. MODE button
• During playback, press to display the Play Menu.
15. OK button
• Press to confirm or select menu items.
16. RETURN button
• Press to Return to the previously displayed
menu or screen function.
17.
(FORWARD) button
• During playback, press to Fast Forward the
playback.
• When playback is in pause, press to Slow
Forward the playback.
18.
(SKIP) button
• During playback, press to Skip to the next
Chapter, Track or File.
• When playback is in pause mode, press to
Forward the playback picture by picture.
19.
(PAUSE) button
• Press to Pause playback.
20. AUDIO button
• Press to select the Audio Channel (such as audio
languages) on a disc.
21. SUBTITLE button
• Press to select Subtitles on a disc.
continued on next page
EN 9
NoteD
• The Power-On indicator on the front panel dims
and flickers when it receives the IR signal from the
remote control.
• Use the included remote control. Remote-control
operation on any other remote control, such as a
universal remote control, is not guaranteed.
■ Installing the Batteries in the Remote Control
Install 2 AAA (1.5V) batteries matching the polarity
indicated inside battery compartment of the remote
control.(not included)
1 2 3
CautionC
Incorrect use of batteries can result in hazards such as
leakage and bursting. Please observe the following:
• Lithium or ni-cad and ni-mh rechargeable batteries
are not recommended to use for remote control.
• Do not mix different types of batteries such as
alkaline and standard (carbon-zinc).
• Do not mix new and old batteries together.
• Do not use different kinds of batteries together.
Although they may look similar, different batteries
may have different voltages.
• Make sure that the + and - ends of each battery
match the indications in the battery compartment.
• Remove batteries from battery compartment, when
the remote is not going to be used for a month or
more.
• When disposing of used batteries, please comply
with governmental regulations or environmental
public rules that apply in your country or area.
• Do not recharge, short-circuit, heat, burn or
disassemble batteries.
■ Using the Remote Control
Remote Control Usage Guidelines:
• Make sure that there are no obstacles between the
remote control and the infrared sensor window on
the unit.
• Remote operation may become unreliable if strong
sunlight or fluorescent light is shining on the
infrared sensor window of the unit.
• Remote controls of different devices can interfere
with each other. Avoid using a remote control from
another device which is located close to the unit.
• Replace the batteries when you notice a fall-off in
the operating range of the remote control.
• The maximum operable ranges from the unit are
as follows.
- Line of sight:
approx. 23 feet (7 m)
- Either side of the center:
approx. 16 feet (5 m) within 30°
- Above:
approx. 16 feet (5 m) within 15°
- Below:
approx. 10 feet (3 m) within 30°
30˚ 30˚
16 feet (5 m) 23 feet (7 m) 16 feet (5 m)
EN 10
3.4. Guide to On-Screen Display
■ Home Menu
When you Turn On the unit, Home Menu will appear automatically. Otherwise, press [HOME].
Disc
Disc
Disc
1
2
3
USB Memory Stick Settings
1. ˝Disc˝: Initiates playback of inserted disc, displays a list of Tracks / Files or the Media
Filter Menu
2. ˝USB Memory Stick˝: Displays a list of Tracks / Files on the connected USB Memory Stick or the Media Filter Menu
For a list of supported file formats, refer to page 17.
3. ˝Settings˝: To access the Setup Menu
■ Setup Menu
TV Aspect
Progressive Mode
Video Out
Audio Out
HDMI
Playback
Others
>
>
16:9 Wide
Auto
1
2
1. Category
2. Menus / Options: Displays options for the highlighted item on the left whenever available
■ Play Menu
During playback, press [MODE] to display the Play Menu.
e.g.) Blu-ray Disc™
Search
Audio
Subtitle
Repeat
Noise Reduction
CLEAR+
EN 11
4. CONNECTIONS
4.1. Connection to a TV
■ HDMI Connection (Supports up to 1080i
(
*
1)
, 1080p
(
*
2)
, 1080p/24
(
*
3)
resolution.)
HDMI IN
Your TV
HDMI cable
(not Included)
No analog audio connection required.
(*1) 1080i: Outputs video data with a frame rate of 30 frames per second.
(*2) 1080p: Outputs video data with a frame rate of 60 frames per second.
(*3) 1080p/24: Outputs video data with a frame rate of 24 frames per second.
• Do not tilt the connector when inserting it into the HDMI jack, and make sure the shapes of the jack and the
connector are matched.
• When connected to an HDCP incompatible display device, the picture will not be displayed properly.
• Use an HDMI cable with the HDMI logo (a certified HDMI cable) for this connection. High Speed HDMI cable
(also known as HDMI category 2 cable) is recommended for better compatibility.
NoteD
• If the TV receives no Audio / Video signal after properly connecting the unit and the TV with an HDMI cable, it
may be the TV. Please refer to the TV’s user’s manual.
• If the TV receives no Audio signal after properly connecting the unit and the TV with an HDMI cable, make
sure the TV input is not an HDMI-DVI Input terminal.
EN 12
4.2. Connection to an Audio System
• When you change the connections, all devices should be Turned Off.
• When connecting the unit to an external audio system, refer to the User Manual for Setup / Configuration
help.
■ HDMI Audio Connection
HDMI IN
AV receiver / amplifier with
an HDMI input jack
HDMI cable
(not Included)
EN 13
4.3. HDMI Audio Output
˝Audio Output˝
setting A
˝Bitstream˝ ˝LPCM˝
˝
BD Audio Mode
˝
setting A
˝
Primary Audio Only
˝
"All" or
"Primary/
Secondary Audio"
˝
Primary Audio Only
˝
"All" or
"Primary/
Secondary Audio"
Media
È
Audio Source
È
Which audio format can be output depends on the compatibility of the connected
device.
BD-Video
Dolby Digital Dolby Digital or Downmix 2ch PCM Downmix 2ch PCM
Dolby Digital Plus
Dolby Digital Plus
or
Dolby Digital
or
Downmix 2ch PCM
*
1
Dolby Digital
or
Downmix 2ch PCM
*
1
Downmix 2ch PCM
*
1
Downmix 2ch PCM
*
1
Dolby TrueHD
Dolby TrueHD
or
Dolby Digital
or
Downmix 2ch PCM
*
2
Dolby Digital
or
Downmix 2ch PCM
*
2
Downmix 2ch PCM
*
2
Downmix 2ch PCM
*
2
DTS
®
DTS
®
or Downmix 2ch PCM
Downmix 2ch PCM
DTS-HD
®
DTS-HD
®
or
DTS
®
or
Downmix 2ch PCM
*
3
DTS
®
or
Downmix 2ch PCM
*
3
Downmix 2ch PCM
*
3
LPCM Multi LPCM
DVD-Video
Dolby Digital Dolby Digital or
Downmix 2ch PCM Downmix 2ch PCM
DTS
®
DTS
®
or Downmix 2ch PCM
Downmix 2ch PCM
MPEG Multi LPCM Multi LPCM
LPCM Multi LPCM
Audio CD LPCM 2ch LPCM
DTS-CD
DTS
®
DTS
®
or Downmix 2ch PCM
Downmix 2ch PCM
AVCHD
Dolby Digital Dolby Digital or Downmix 2ch PCM Downmix 2ch PCM
LPCM Multi LPCM
*1) Only Dolby Digital parts in Dolby Digital Plus Stream are decoded, then it will Downmix 2ch PCM.
*2) Only 2ch presentation parts in Dolby TruHD Stream are decoded.
*3) Only the core substream is decoded.
NoteD
• If the connected device is not compatible with the HDMI BITSTREAM, audio will be output as multi LPCM
or 2-channel down-mixed LPCM depending on the capability of the connected device even if you select
˝Bitstream˝ in ˝Audio Output˝ setting.
• When playing back a BD-Video which only contains the primary audio, the audio output will be the same
case as ˝Primary Audio Only˝ even if the ˝BD Audio Mode˝ is set to ˝All˝ or ˝Primary/Secondary Audio˝.
• If “BD Audio Mode” is set to “All” or “Primary/Secondary Audio”, HD Audio will not be output. In order to
enable the Button Sound feature, set “BD Audio Mode” to “All”. (The Button Sound setting may be found in
the Pop Menu.
• In order to configure “Audio Output” in the “HDMI” settings, “Voice Guide” must be set to “Off”.
EN 14
5. BEFORE YOU START
5.1. Finding a Viewing Video Source Input on Your TV
After you have completed all of the connections to your TV, review the steps below.
1. Press [
(POWER)] to Turn On the unit.
2. Turn On your TV.
3. Please locate the Source / Input / AUX / Video button on TV’s remote control. The button may vary on the TV
brand and model. Once you have located the button, press until you see ˝Please Wait...˝ on the Screen.
Please Wait...
This is the correct viewing of the video Source Input.
• If the TV is connected by an HDMI cable, it may take a few moments for the opening picture to appear.
5.2. Initial Setup
Please follow the instructions below to complete the initial setup.
1. Language setup screen will appear. Use [
] to select your language, then press [OK].
Please select your language for on-screen
display.
If you want use the Voice Guide function,
please set to “English” or “Español”
English
Español
Français
Language
2. Voice Guide Setup screen will appear. Use [ ] to select “On” or “Off”, then press [OK].
Switch Voice Guide On or Off. Sets On the
Voice Guide, “Audio Output” setting will set to
“LPCM” automatically. If Voice Guide is On, it
will not be able to set the “Audio Output”.
On
Off
Return
Voice Guide
This screen will not appear when “Français” is selected under the “Language” setting.
continued on next page
EN 15
■ How to Reset the OSD Language
You can reset the OSD language if you selected the wrong language.
1. Press [HOME] to display the Home Menu.
2. Use [
] to select ˝ ˝, then press [OK].
• This item is ˝Settings˝ (English) / ˝Configuraciones˝ (Spanish) / ˝Paramètres˝ (French).
• From here on, please select one of the following items you can find on screen:
3. Use [
] to select ˝Playback˝ (English) / ˝Reproducción˝ (Spanish) / ˝Lecture˝ (French), then press [OK].
4. Use [
] to select ˝Language˝ (English) / ˝Idioma˝ (Spanish) / ˝Langue˝ (French), then press [OK].
5. Use [
] to select your desired language, then press [OK].
6. If the items that were set are displayed in your desired language, then press [HOME] to exit.
EN 16
6. INFORMATION ON PLAYBACK
6.1. Information on Playback
■ Playable Discs and Files
Playable discs Logos
Blu-ray Disc™
- BD-video
- BD-RE* (ver. 2.1)
(Recorded in BDMV format)
- BD-R* (ver. 1.1 / 1.2 / 1.3)
(Recorded in BDMV format)
(Unfinalized disc may not be played back.)
DVD-video
DVD-RW
(finalized video mode discs only)
DVD-R
(finalized video mode discs only)
CD-DA (audio CD)
CD-RW
CD-R
DTS-CD -
(*) Due to the intentional progression of the Blu-ray Disc™ format by its standard setting authority, the
company cannot guarantee or warrant the playability of future extensions of the Blu-ray Disc™ format with
this product.
Playable files Media
AVCHD
DVD-RW/-R
SD Memory Card using USB card reader / USB hub (not included)
JPEG
BD-RE/-R
DVD-RW/-R
CD-RW/-R
USB Memory Stick
Readable device Playable files / data
USB Memory Stick JPEG, picture-in-picture commentary, Subtitles or other extras for some BD-ROM.
NoteD
• This unit may not be able to play back discs recorded on PC’s or other recorders.
continued on next page
EN 17
■ Recommended Specifications
AVCHD
This unit cannot play back stand-alone AVCHD files (*.m2ts, *.mts or *.m2t) written to a DVD or copied to an
SD Memory Card. The DVD or SD Memory Card containing AVCHD files must have a proper file and folder
structure meeting AVCHD format specifications. Please use AVCHD compliant device / software to burn or
copy AVCHD files to DVD or SD Memory Card. (Please refer to user manuals of your device / software for more
information.)
JPEG
Resolution
• Upper limit: 4,096 x 4,096 dots (sub sampling is 4:4:4)
5,120 x 5,120 dots (sub sampling is up to 4:2:2 or 4:2:0)
• Lower limit: 32 x 32 dots
• Maximum file size of a picture: 12MB
■ Folder / File Number Limitations
Blu-ray Disc™, DVD and USB Memory Stick
• 999 folders (groups) and 9,999 files
CD
• 255 folders (groups) and 999 Tracks / Files
Caution / Note for USB Memory Stick
CautionC
• Do not try to open or modify the USB Memory Stick.
• Do not touch the terminal surface with your fingers or any metals.
NoteD
• This unit supports USB Memory Stick with FAT16 / FAT32 file system.
• This unit does not support NTFS file system.
• This unit may not read USB Memory Sticks formatted on a computer. If that is the case, please reformat the
USB Memory Sticks on this unit and try again. Please not that all files stored on the USB Memory Stick will
be erased upon format.
• Please keep the USB Memory Sticks in their cases when you are not using them.
• Some USB Memory Sticks may not work with this unit.
• This unit can read SD Memory Cards using a USB card reader (not included).
- Readable cards: SD Memory Card (8 MB - 2 GB)
miniSD Memory Card (16 MB - 2 GB)
microSD Memory Card (256 MB - 2 GB)
SDHC Memory Card (4 GB - 32 GB)
miniSDHC Memory Card (4 GB - 8 GB)
microSDHC Memory Card (4 GB - 16 GB)
- Readable files: AVCHD / JPEG
• Depending on a USB card reader or USB hub, connected card or device may not be recognized.
continued on next page
EN 18
■ Unplayable Media and Files
The following discs will not be played back on this unit.
• CD-ROM • CD-I (compact disc-interactive)
• DVD-RAM • VSD (video single disc)
• DVD-audio • video CD
• HD DVD • SVCD
• SDXC Memory Card • microSDXC Memory Card
• unfinalized disc • BD-RE (ver. 1.0)
• BD-RE (ver. 2.1) (Recorded in BDAV format) • BD-R (ver. 1.1 / 1.2 / 1.3) (Recorded in BDAV format)
• BDXL™
• Blu-ray Disc™ / DVD / CD / USB Memory Stick / SD Memory Card containing DivX
®
files
• Blu-ray Disc™ / USB Memory Stick that contains AVCHD files
• Blu-ray Disc™ / DVD hybrid disc (played back as a BD-video only)
• DVD-RW/-R recorded in non compatible recording format
• Super Audio CD - Only the sound on the CD layer can be heard. The sound on the high-density Super Audio
CD layer cannot be heard.
• Playability of dual discs is not guaranteed.
• This unit cannot play back the disc contents protected by Windows Media™ Digital Rights Management
(DRM).
■ Region Codes
This unit has been designed to play back BD-video with region ˝A˝ and DVD-video with
region ˝1˝ or ˝ALL˝. You cannot play back BD-video or DVD-video that is labeled for other
regions.
Look for the symbols on your BD-video or DVD-video. If these region symbols do not
appear on your BD-video or DVD-video, you cannot play back the disc on this unit. The
letter or number inside the globe refers to region of the world. BD-video or DVD-video
discs labeled for a specific region can only be played back on players with the same
region code.
BD-video
DVD-video
■ Hint for Disc Playback
The contents of a disc are generally divided into sections or folders (group of titles / files) as shown below.
BD-video, DVD-video, AVCHD
Audio CD
Track 1 Track 2 Track 3 Track 4 Track 5
Title 1
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
Title 2
JPEG
File 1 File 2 File 3 File 4 File 5
folder (group) 1 folder (group) 2
continued on next page
EN 19
■ Description for Icons
[ ] : group (folder) icon
[
] : music file icon
[
] : photo file icon
- ˝Folders˝ refers to the group of files.
- ˝Track˝ refers to the contents recorded on the audio CD.
- ˝Files˝ refers to the contents on a disc which are recorded in AVCHD or JPEG file format.
NoteD
• Unrecognizable characters will be replaced with asterisks.
6.2. Guide to File List
■ Picture File List
Thumbnail
06051_1140
Page Up Page Down Media Mode
--- / 999
TR
CD
DATA
Folder_001 Folder_002
1
2
3
4
1. Current File number / Total number of Files
2. Playback status symbol
3. Media type
4. Group (folder) / File list (thumbnails)
■ How to Navigate through the File List
• For picture file list, use [ ] to move the highlight up, down, left and right. Press
[RETURN] to go back to the previous hierarchy.
• To access the files in a Group (folder), select the desired Group (folder), then press [OK].
• Press [RED] or [GREEN] to change the page list up or down.
• Press [YELLOW] to go back to the file type (˝Photo˝ / ˝AVCHD˝) selection screen.
• Press [HOME] to Exit.
6.3. How to Insert a Disc
1. Press [ (OPEN/CLOSE)] to Open the disc tray.
2. Place the Disc on the disc tray with its label side facing up.
3. Press [
(OPEN/CLOSE)] to Close the disc tray.
• It may take a while to load the disc.
Align the Disc to the disc tray guide.
EN 20
7. BASIC PLAYBACK
7. 1. Playing Back a Disc
[BD Video]
[DVD Video]
[CD]
[AVCHD]
[JPEG]
1. Insert a disc (refer to ˝How to Insert a Disc˝ on page 19).
• For Blu-ray Disc™ / DVD / audio CD or a disc containing only one type of file, playback will start
automatically. If not, press [
(PLAY)] (or [ (PLAY/PAUSE)] on the unit).
• Some discs may show a Title or a Disc Menu. In this case, refer to ˝Using the Title / Disc / Pop Menu˝ on
page 22.
2. Select the type of the file you want to play back, then press [OK].
a b
a. For ˝Photo˝, thumbnail screen will appear.
• Refer to ˝Picture File List˝ on page 19 and ˝How to Navigate through the File List˝ on page 19.
b. For ˝AVCHD˝, playback will start automatically.
To Skip to the next Title / Chapter / Track / File: Press [
(SKIP)].
To Skip to the previous Title / Chapter / Track / File: Press [
(SKIP)].
To Pause playback: Press [
(PAUSE)] (or [ (PLAY/PAUSE)] on the unit).
To Return to Normal playback: Press [
(PLAY)] (or [ (PLAY/PAUSE)] on the unit).
To Stop playback: Press [
(STOP)].
Playback will be in Resume-On-Stop mode. To clear the resume information, press [
(STOP)] again.
■ Resume-On-Stop Mode
Blu-ray Disc™ / DVD / AVCHD
When you press [
(PLAY)] (or [ (PLAY/PAUSE)] on the unit) next time, the playback will start from the
point where it has been stopped.
Audio CD
Playback will start from the point where it is stopped next time you press [
(PLAY)] (or [ (PLAY/PAUSE)] on
the unit). If you press [OK] instead of [
(PLAY)](or [ (PLAY/PAUSE)] on the unit), playback will start from the
beginning of the Track / File instead of resuming from the stop point.
JPEG
Playback will start from the beginning of the current file next time you press [
(PLAY)] (or [ (PLAY/PAUSE)]
on the unit) or [OK].
NoteD
• Playback will also Stop and the Home Menu will appear when you press [HOME].
• For BD-Java application, the Resume-On-Stop may not be available.
• If you press [OK] instead of [
(PLAY)] (or [ (PLAY/PAUSE)] on the unit), playback can be started from the
beginning of the disc even if it was in the Resume-On-Stop mode.
• Resume-On-Stop mode remains in effect even after Power is Turned Off, but will be cancelled once the disc is
ejected.
• With regard to the multi-border BD-RE/-R, additionally recorded sections cannot be recognized.
• With regard to the multi-border DVD-RW/-R, additionally recorded sections may not be recognized.
continued on next page
EN 21
NoteD for JPEG Playback
• Every press of [
] will turn the image by 90 degrees when an image is displayed.
• During playback, press [DISC MENU] to display thumbnail screen.
• Some unplayable folders or files may be listed due to the recording status.
• High-resolution JPEG files take longer to be displayed.
• Progressive JPEG files (JPEG files saved in progressive format) cannot be played back on this unit.
7.2. Playing Back Contents from a USB Memory Stick
[JPEG]
You can play back JPEG files stored on a USB Memory Stick. With the USB Memory Stick, you can also enjoy
the following functions. For a list of supported file formats, refer to page 17.
• Special additional contents for BD-ROM.
(For more information about the special additional contents, refer to the instruction book that came with the
disc.)
1. Connect a USB Memory Stick.
2. Press [HOME].
3. Use [
] to select ˝USB Memory Stick˝, then press [OK].
4. Follow step 2 in ˝Playing Back a Disc˝ on page 20.
CautionC
• Do not disconnect the USB Memory Stick or switch the unit to Standby mode while a content on the USB
Memory Stick is being accessed. It may result in malfunction or loss of the stick's data.
• If you connect a USB Memory Stick or SD Memory Card via a USB card reader or USB hub, BD-ROM data
will be written onto the first connected card or device. Connecting a USB Memory Stick directly to this unit is
recommended.
• Occasionally, SD Memory Cards / Micro SD Memory Cards will not be recognized when using certain
Adapters. In such cases, try a different USB Adapter.
NoteD
• When connecting more than two USB Memory Sticks to a USB Hub, this unit may fail to recognize them.
In such cases, disconnect the USB Hub from the unit then reconnect it, or use less USB Memory Sticks at a
time.
• The resume information will be cleared when;
- [
(STOP)] is pressed while in the Resume-On-Stop mode.
- the USB Memory Stick is disconnected.
- the unit is switched to Standby mode.
• Do not delete the folders or files on the USB Memory Stick with your computer. This unit may not read USB
Memory Sticks formatted on a computer.
• If a folder or file name includes one of the following unrecognizable characters, the folder or file name may
not be displayed correctly.
- Unrecognizable characters:
. , " = + [ ] ; / \ : | ¥
• This unit can read JPEG files and AVCHD on an SD Memory Card by using USB card reader / USB hub (not
included).
EN 22
7.3. Using the Title / Disc / Pop Menu
[BD Video]
[DVD Video]
[AVCHD]
Some BD-videos, DVD-videos or AVCHD files may contain a Title Menu which describes the contents of the disc,
or a Disc Menu which guides you through the available functions on the disc.
• With such discs, a Title Menu or a Disc Menu may appear automatically when you insert the disc. Otherwise,
press [DISC MENU] to call up the Menu Select Menu. Use [
] to select ˝Top Menu˝ or ˝Pop Menu/Menu˝,
then press [OK]. Refer to the disc’s manual on how to navigate through the menu.
e.g.) Blu-ray Disc™
Pop Menu
Top Menu
NoteD
• Menus vary among discs. Refer to the information accompanying the disc for details.
• [DISC MENU] may not work with some discs.
EN 23
8. SPECIAL PLAYBACK
8.1. Fast Forward / Fast Reverse
[BD Video]
[DVD Video]
[CD]
[AVCHD]
1. During playback, press [ (FORWARD)] repeatedly for Fast Forward.
During playback, press [
(REVERSE)] repeatedly for Fast Reverse.
2. Press [
(PLAY)] (or [ (PLAY/PAUSE)] on the unit) to return to Normal playback.
NoteD
• For Blu-ray Disc™, DVD and AVCHD, speed changes at 5 different levels.
• For audio CD, speed changes at 3 different levels.
• For audio CD, Fast Forward / Fast Reverse search between different files are not available.
8.2. Slow Forward Playback
[BD Video]
[DVD Video]
[AVCHD]
1. During playback, press [ (PAUSE)] (or [ (PLAY/PAUSE)] on the unit). Then press [ (FORWARD)].
Every time you press [
(FORWARD)], the playback speed changes at 3 different levels.
2. Press [
(PLAY)] (or [ (PLAY/PAUSE)] on the unit) to return to Normal playback.
NoteD
• Slow Reverse is not available.
8.3. Step by Step Playback
[BD Video]
[DVD Video]
[AVCHD]
1. In pause mode, press [ (SKIP)] repeatedly.
Every time you press [
(SKIP)], playback will advance one step at a time.
2. Press [
(PLAY)] (or [ (PLAY/PAUSE)] on the unit) or [ (PAUSE)] to return to Normal playback.
NoteD
• Step by step reverse is not available.
EN 24
8.4. Repeat Playback
Available repeat functions vary depending on the disc.
1. During playback, press [REPEAT].
2. Use [
] to select the desired repeat mode.
• You can also change the repeat mode by pressing [REPEAT] repeatedly.
REPEAT MODE AVAILABLE MEDIA
Chapter Repeat
[BD Video]
[DVD Video]
[AVCHD]
The current Chapter will be played back repeatedly.
Title Repeat
[BD Video]
[DVD Video]
[AVCHD]
The current Title will be played back repeatedly.
Track Repeat
[CD]
[JPEG]
The current Track or File will be played back repeatedly.
All Repeat
[CD]
All Tracks in the media will be played back repeatedly.
Group Repeat
[JPEG]
The current Group (folder) will be played back repeatedly.
Random Repeat
[CD]
Repeats the random playback.
Random Repeat
[JPEG]
Repeats the random playback in a folder.
3. Press [RETURN] to Exit.
NoteD
• The repeat setting will be cancelled when you stop playback.
• When the repeat setting is set for an JPEG folder (file), the repeat setting will be cancelled if you select
another JPEG folder (file) to play back.
• You can also use the Repeat function from the Play Menu. Play Menu can be called up by pressing [MODE].
8.5. Slide Show
[JPEG]
1. Follow steps 1 and 2 in ˝Playing Back a Disc˝ on page 20.
2. Open the folder which contains the desired JPEG files.
3. Use [
] to select a desired file to be played back, then press [ (PLAY)] (or [ (PLAY/PAUSE)]
on the unit) or [OK].
• An image will be played back from the selected file and go to the next one in turn every 10 seconds.
4. Press [
(STOP)] to Stop playback.
• When you press [DISC MENU] in the stop mode, the highlight goes back to the first item.
• When you press [DISC MENU] in the Resume-On-Stop mode, the highlight goes back to the file played
last.
NoteD
• Large-size JPEG files take a few moments to be displayed.
EN 25
8.6. PiP (BONUSVIEW™) Setting
[BD Video]
Some BD-videos have the PiP function which enables you to display the Secondary Video in the Primary Video.
PiP 1 / 8
Primary Video
Secondary Video
1. During playback, press [MODE] to display the Play Menu.
2. Use [
] to select ˝PiP˝ then press [OK].
• PiP information will appear.
3. Use [
] to select the Secondary Video you want to show.
• The Secondary Video will be displayed with the Secondary Audio.
• Use [
] to switch between current setting and ˝Off˝.
4. Press [RETURN] to Exit.
• How to select the Secondary Audio output, refer to ˝Switching Audio Soundtrack˝ on page 29.
NoteD
• Not that the secondary video will be displayed at any time during playback. Depending on the scene, the
secondary video may not be available.
EN 26
8.7. Title / Chapter Search
[BD Video]
[DVD Video]
[AVCHD]
■ Using [ (SKIP)] / [ (SKIP)]
1. During playback, press [ (SKIP)] to Skip the current Title or Chapter and move to the next.
The Title or Chapter will move forward one at a time.
• If there is no Chapter in one Title, the current Title may be Skipped.
To go back to the beginning of the current Title or Chapter, press [
(SKIP)].
Press [
(SKIP)] repeatedly to go to the previous Title or Chapter. The Title or Chapter may move backward
one at a time.
■ Using [SEARCH]
1. During playback, press [SEARCH] to display the Search Menu.
2. Press [SEARCH] or use [
] to select ˝
TT
˝ or ˝
CHP
˝, then press [OK].
e.g.) Blu-ray Disc™
Search 1 / 999
TT
3. Use [ ] to select the Title / Chapter number, then press [OK].
Playback will start from the beginning of the Title / Chapter.
NoteD
• As for the BD-video, how it performs will be strongly determined by the disc, and may not perform as
described.
• For DVD, the Title Search can be performed on the Home menu by pressing [SEARCH] while in the Stop
mode or the Resume-On-Stop mode.
• You can also perform the Title / Chapter Search from the Play Menu. Play Menu can be called up by pressing
[MODE].
8.8. Track / File Search
[CD]
[JPEG]
■ Using [ (SKIP)] / [ (SKIP)]
1. During playback, press [ (SKIP)] to Skip the current Track or File and move to the next.
The Track / File will move forward one at a time. To go back to the beginning of the current Track / File,
press [
(SKIP)].
Press it repeatedly to go to the previous Track / File. The Track / File will move backward one at a time.
■ Using [SEARCH]
1. During playback, press [SEARCH].
• For JPEG files, skip to step 3.
2. Press [SEARCH] or use [
] to select ˝
TR
˝, then press [OK].
3. Use [
] to select the Track number, then press [OK].
Playback will start from the beginning of the Track.
NoteD
• You can also perform the Track / File Search from the Play Menu. Play Menu can be called up by pressing
[MODE].
EN 27
8.9. Time Search
[BD Video]
[DVD Video]
[CD]
[AVCHD]
1. During playback, press [SEARCH] to display the Search Menu.
2. Press [SEARCH] or use [
] to select ˝ ˝, then press [OK].
e.g.) Blu-ray Disc™
Search 00:12:44 / 11:13:14
3. Enter the time count you want to jump to.
• Use [
] to enter the first digit of the time counter, then press [ ].
• When the last digit is entered, press [OK].
Playback will start from the desired time entered.
NoteD
• You can also perform the Time Search from the Play Menu. Play Menu can be called up by pressing [MODE].
8.10. Number Select Search
[BD Video]
[DVD Video]
[AVCHD]
Some BD-videos and DVD-videos or AVCHD files have button menus to jump to each button displayed scene.
During playback the scenes which have the button menu, you can enter the button number by using the
Number Select Menu.
1. During playback, press [SEARCH] repeatedly to select the Number Select Menu.
e.g.) Blu-ray Disc™
0000
Number
• For BD-Java, the Number Select Menu of single-digit is displayed.
• For DVD, the Number Select Menu of double-digit is displayed.
• For BD-videos and AVCHD files, the Number Select Menu is displayed even if there is no button menu in
the scene.
2. Use [
] to enter the number you want to jump to.
• To move the digit that you wish to change, press [
] .
3. After all digit numbers are entered, press [OK].
Playback of the selected scene will start.
NoteD
• As for the BD-video, how it performs will be strongly determined by the disc, and may not perform as
described.
EN 28
8.11. Switching Subtitles
Some video materials may have subtitles in one or more languages. For commercially available discs, the
supported languages can be found on the disc case. Follow the steps below to switch the Subtitle language
during playback.
[BD Video]
1. During playback, press [SUBTITLE].
2. Use [
] to select ˝Primary˝, ˝Secondary˝ or ˝Style˝, then press [OK].
• You can also change the setting by pressing [SUBTITLE] repeatedly when the highlight is on ˝Primary˝.
˝Primary˝: Sets the Subtitle for the Primary Video.
˝Secondary˝: Sets the Subtitle for the Secondary Video.
˝Style˝: Sets Style of the Subtitle.
3. Use [
] to select your desired Subtitle or Style.
Subtitle Primary
Secondary
Style
1 ENG / 3
Off
Off
• Use [ ] to switch between current Subtitle setting and ˝Off˝.
4. Press [RETURN] repeatedly to Exit.
[DVD Video]
[AVCHD]
1. During playback, press [SUBTITLE].
2. Use [
] to select your desired Subtitle.
• You can also change the setting by pressing [SUBTITLE] repeatedly.
Subtitle 1 ENG / 32
• Use [ ] to switch between current Subtitle setting and ˝Off˝.
3. Press [RETURN] to Exit.
NoteD
• Some discs will only allow you to change the subtitles from the Disc Menu or Pop Menu. Press [DISC MENU]
to select the ˝Top Menu˝ or ˝Pop Menu˝ (or ˝Menu˝).
• If the disc has no Subtitle language or Subtitle Style, ˝Not Available˝ will be displayed on the TV screen.
• During playback of the Secondary Video, the Primary Subtitle setting is not available except when there is no
Subtitle for the Secondary Video.
• You can also change the Subtitle setting from the Play Menu. Play Menu can be called up by pressing
[MODE].
EN 29
8.12. Switching Audio Soundtrack
When playing back video material recorded with two or more soundtracks (these are often in different audio
languages or audio formats), you can switch them during playback. For Blu-ray Disc™, available audio varies
depending on ˝BD Audio Mode˝ setting. Refer to page 32.
[BD Video]
1. During playback, press [AUDIO].
2. Use [
] to select ˝Primary˝ or ˝Secondary˝, then press [OK].
• You can also change the setting by pressing [AUDIO] repeatedly when the highlight is on ˝Primary˝.
˝Primary˝: Sets the audio for the Primary Video.
˝Secondary˝: Sets the audio for the Secondary Video.
3. Use [
] to select your desired audio stream channel.
Audio Primary
Secondary
1 ENG DD Multi-ch /3
1 ENG DTS Multi-ch /3
[Decoding Format] : Dolby Audio - Dolby Digital
• For ˝Secondary˝, use [ ] to switch between current audio setting and ˝Off˝.
4. Press [RETURN] repeatedly to Exit.
[DVD Video]
[CD]
[AVCHD]
1. During playback, press [AUDIO].
2. Use [
] to select your desired audio stream channel.
• You can also change the setting by pressing [AUDIO] repeatedly.
Audio 1 ENG DD Multi-ch /3
[Decoding Format] : Dolby Audio - Dolby Digital
• For audio CD, you can select following options.
˝Stereo˝: Both right and left channels are active (stereo).
˝L-ch˝: Only left channel is active.
˝R-ch˝: Only right channel is active.
3. Press [RETURN] to Exit.
NoteD
• The Secondary Audio will not be output when the Secondary Video is not displayed or when ˝BD Audio
Mode˝ is set to ˝Primary Audio Only˝. (For some Blu-ray discs, Secondary Audio will be output even when
Secondary Video is Off.)
• The sound mode cannot be changed during playback of discs not recorded in multiple audio mode.
• Some discs allow changing the audio language setting from Disc Menu. (Operation varies depending on the
discs. Refer to the manual accompanying the disc.)
• [AUDIO] may not work on some discs with multiple audio streams or channels (e.g. DVDs that allow
changing audio setting on the disc menu).
• If the disc has no audio language, ˝Not Available˝ will be displayed on the TV screen.
• For DTS-CD (5.1 music disc), selecting audio streams or channels is not available.
• You can also change the Audio setting from the Play Menu. Play Menu can be called up by pressing [MODE].
EN 30
8.13. Switching Camera Angles
[BD Video]
[DVD Video]
Some BD-videos and DVD-videos contain scenes which have been shot simultaneously from various angles.
You can change the Camera Angle when
appears on the TV screen.
1. During playback, press [MODE] to display the Play Menu.
2. Use [
] to select ˝Angle˝, then press [OK].
3. Use [
] to select your desired angle.
• The selected Angle will be displayed on the display bar at the top of the TV screen.
4. Press [RETURN] to Exit.
NoteD
• If ˝Angle Icon˝ setting is set to ˝Off˝,
will not appear on the TV screen.
8.14. Noise Reduction
[BD Video]
[DVD Video]
[AVCHD]
Reduces the noise of the playback picture.
1. During playback, press [MODE] to display the Play Menu.
2. Use [
] to select ˝Noise Reduction˝, then press [OK].
3. Use [
] to select your desired setting.
e.g.) Blu-ray Disc™
Noise Reduction Off
˝On˝: Activates noise reduction.
˝Off˝: Deactivates noise reduction.
4. Press [RETURN] to Exit.
NoteD
• The setting will remain the same even if the unit is switched to Standby mode.
EN 31
8.15. CLEAR+
[BD Video]
[DVD Video]
[AVCHD]
CLEAR+ enhances the contrast of the picture and makes edges crisp. It is effective especially for DVD’s.
1. During playback, press [MODE] to display the Play Menu.
2. Use [
] to select ˝CLEAR+˝, then press [OK].
3. Use [
] to select your desired setting.
e.g.) Blu-ray Disc™
CLEAR+ Off
˝On˝: Gives low-definition videos high-definition like picture quality.
˝Off˝: Shows the original picture as recorded.
4. Press [RETURN] to Exit.
NoteD
• This operation is prohibited during Fast Forward, Fast Reverse, Slow Forward playback and pause mode.
• Pictures may appear whiter depending on the material and the connected TV. In this case, turn ˝CLEAR+˝ Off.
• ˝CLEAR+˝ is not effective under the following conditions.
- When the material is in 1080p/24 which is commonly used in Blu-ray discs.
EN 32
In ˝Settings˝, you can customize various kinds of settings as you prefer.
Refer to the following instructions to navigate through the Setup Menu.
1. Press [HOME] to access the Home Menu.
2. Use [
] to select ˝Settings˝, then press [OK].
3. Use [
] to select the desired Category, then press [OK].
4. Use [
] to move up and down the list to select Menus / Options.
5. To make a selection or to access options of an item, select the desired item, then press [OK].
• To go back to the previous screen, press [RETURN].
6. Press [HOME] to Exit.
Refer to the following table for the types of settings you can customize.
The item highlighted in gray is the default setting.
Category Menus / Options
Video Out TV Aspect 4:3 Letter Box
4:3 Pan & Scan
16:9 Wide
16:9 Squeeze
Progressive Mode Auto
Video
AudioOut Voice Guide On
Off
DRC Auto
On
Off
BD Audio Mode All
Primary/Secondary Audio
Primary Audio Only
HDMI HDMI CEC On
Off
Video Resolution Auto
480p
AudioOutput Bitstream
LPCM
9. LIST OF SETTINGS
continued on next page
EN 33
Category Menus / Options
Playback Language Auto
English
Español
Français
Audio Original
Bulgarian Italian
Chinese Japanese
Czech Korean
Danish Norwegian
Dutch Polish
English Portuguese
Finnish Romanian
French Russian
German Slovak
Greek Spanish
Hungarian Swedish
Icelandic Turkish
Irish Other
Subtitle Off
Bulgarian Italian
Chinese Japanese
Czech Korean
Danish Norwegian
Dutch Polish
English Portuguese
Finnish Romanian
French Russian
German Slovak
Greek Spanish
Hungarian Swedish
Icelandic Turkish
Irish Other
Disc Menu Bulgarian Italian
Chinese Japanese
Czech Korean
Danish Norwegian
Dutch Polish
English Portuguese
Finnish Romanian
French Russian
German Slovak
Greek Spanish
Hungarian Swedish
Icelandic Turkish
Irish Other
BD Rating Level Off
Age Setting
DVD Rating Level Off
8 [Adult] 4 [PG-13]
7 [NC-17] 3 [PG]
6 [R] 2 [G]
5 [PGR] 1 [Kid Safe]
Password Change
Angle Icon On
Off
continued on next page
EN 34
Category Menus / Options
Others Software Update Disc
USB Memory Stick
Product Info
Initialize Reset Settings
Format USB Memory Stick
(Unit) Erase Saved BD-ROM Data
(USB Memory Stick) Erase Saved BD-ROM Data
Reset All Settings
OSS
EN 35
10. SETUPS
10.1. HDMI CEC
HOME A ˝Settings˝ A ˝HDMI˝ A ˝HDMI CEC˝
HDMI CEC allows integrated system control over HDMI and is part of the HDMI standard. This function may
not work properly depending on the device connected to the unit. When ˝HDMI CEC˝ setting is set to ˝On˝ the
functions listed below will be available.
■ One Touch Play
When the buttons below are pressed then operations are performed on this unit, the TV will automatically be
Turned On and switched to the appropriate video Source Input.
Buttons for one touch play:
• [
(PLAY/PAUSE)] (on the unit)
• [
(PLAY)], [ (SKIP)], [ (SKIP)], [HOME] (on the remote control)
• [DISC MENU] (on the remote control when the a disc is inserted in the unit)
■ One Touch Standby
When you press and hold [ (POWER)] for 2 seconds, it turns Off the TV first and then Turns Off the power on
this unit.
When the connected HDMI CEC compatible display device is Turned Off first, then it Turns Off the power to this
unit.
■ System Information
Get & Set Menu Language
The unit recognizes the OSD language set on the TV and automatically sets the same language as the Player
Menu Language (OSD menu language) for this unit. ˝Language˝ under ˝Playback˝ on page 33 for available
languages.
• Feature is available only when ˝Auto˝ is selected in the Setup Menu ˝Language˝ section in ˝Settings˝ while
connected via an HDMI cable.
EN 36
10.2. HDMI Video Resolution
HOME A ˝Settings˝ A ˝HDMI˝ A ˝Video Resolution˝
Set the resolution of the video signal being output from the HDMI OUT jack.
You can select the desired ˝Video Resolution˝ among the settings listed below: ˝Auto˝,˝480p˝.
Actual Output Resolution:
Setting in the
˝Video Resolution˝
Source
480i/60 480p/60 720p/60 1080i/60 1080p/60 720p/24 1080p/24
Auto The highest resolution supported by your display device will automatically be in effect.
480p 480p/60
• For AVCHD, outputting the video in 24 frames per second (1080p/24) is not available.
NoteD
• The selected resolution must also be supported by your display device.
• If your TV and the unit are connected by a DVI cable and if ˝Auto˝ is selected, ˝480p˝ will be automatically in
effect.
• Refer also to your TV’s manual.
• When connected to an HDCP incompatible display device, the picture will not be displayed properly.
• The audio signals from the HDMI OUT jack (including the sampling frequency, the number of channels and
bit length) may be limited by the connected device.
• Among the display devices that support HDMI, some do not support audio output (for example, projectors).
While connected to a device such as a projector, audio will not be output from the HDMI OUT jack.
• When this unit’s HDMI OUT jack is connected to a DVI-D compatible display device(s) (HDCP compatible)
with an HDMI-DVI converter cable, the signals are output in digital RGB.
• HDMI video resolution does not work during the playback of a BD-video.
Copyright protection system
To play back the digital video images of a BD-video or DVD-video via an HDMI connection, it is necessary
that both the player and the display device (or an AV receiver / amplifier) support a copyright protection
system called HDCP (high-bandwidth digital content protection system). HDCP is copy protection technology
that comprises data encryption and authentication of the connected AV device. This unit supports HDCP.
Please read the operating instructions of your display device (or an AV receiver / amplifier) for more
information.
EN 37
10.3. Parental
Some BD-videos or DVD-videos feature parental lock levels. Playback will stop if the ratings exceed the levels
you set, it will require you to enter a password before the disc will play back. This feature prevents your
children from viewing inappropriate material.
1. Enter your 4-digit password.
• Use [
] to enter the first digit of your password, then press [ ].
• When 4-digit numbers are entered, press [OK].
For the first time use:
Enter any 4-digit number (except for 4737). That number will be used as the password. Record your
password, in case you forget it.
• If you forget the password, enter ˝4737˝. The password will be cleared and rating level will be set to ˝Off˝.
■ BD Rating Level
HOME A ˝Settings˝ A ˝Playback˝ A ˝BD Rating Level˝
1. Use [
] to select ˝Settings˝ in the Home Menu, then press [OK].
2. Use [
] to select ˝Playback˝, then press [OK].
3. Use [
] to select ˝BD Rating Level˝, then press [OK].
4. Enter your 4-digit password.
• Use [
] to enter the first digit of your password, then press [ ].
• When 4-digit numbers are entered, press [OK].
5. Use [
] to select your desired option, then press [OK].
˝Off˝: To release the limitation.
˝Age Setting˝: To set the age limitation.
After selecting ˝Age Setting˝, enter the age.
• Use [
] to enter the first digit of the age, then press [ ].
• When 3-digit numbers are entered, press [OK].
e.g.)
For age 6, enter ˝006˝.
For age 15, enter ˝015˝.
6. Press [HOME] to Exit.
continued on next page
EN 38
■ DVD Rating Level
HOME A ˝Settings˝ A ˝Playback˝ A ˝DVD Rating Level˝
1. Use [
] to select ˝Settings˝ in the Home Menu, then press [OK].
2. Use [
] to select ˝Playback˝, then press [OK].
3. Use [
] to select ˝DVD Rating Level˝, then press [OK].
4. Enter your 4-digit password.
• Use [
] to enter the first digit of your password, then press [ ].
• When 4-digit numbers are entered, press [OK].
5. Use [
] to select your desired level, then press [OK].
6. Press [HOME] to Exit.
RATING EXPLANATIONS
Off Parental is inactive; all discs can be played back.
8 [Adult] DVD software of any grades (adult / general / children) can be played back.
7 [NC-17] No one under 17.
6 [R] Restricted; under 17.
5 [PGR] Parental Guidance Recommended.
4 [PG-13] Unsuitable for children under 13.
3 [PG] Parental Guidance suggested.
2 [G] General Audience.
1 [Kid Safe] Suitable for children.
■ Password Change
HOME A ˝Settings˝ A ˝Playback˝ A ˝Password Change˝
1. Use [
] to select ˝Settings˝ in the Home Menu, then press [OK].
2. Use [
] to select ˝Playback˝, then press [OK].
3. Use [
] to select ˝Password Change˝, then press [OK].
4. Enter your 4-digit password.
• Use [
] to enter the first digit of your password, then press [ ].
• When 4-digit numbers are entered, press [OK].
5. Enter a new 4-digit password in the same way as the step 4.
6. Reenter the same new 4-digit password in the same way as the step 4.
7. Press [HOME] to Exit.
To temporarily disable parental lock:
Some discs allow you to temporarily disable parental lock. When you try to play them back, the password entry
screen will be displayed.
Follow the instruction which appears on the TV screen to disable parental lock.
EN 39
10.4. Software Update
HOME A ˝Settings˝ A ˝Others˝ A ˝Software Update˝
This unit lets you update the software yourself using a software update disc, USB Memory Stick.
The available discs are below:
• BD-RE/-R
• DVD-RW/-R
• CD-RW/-R
■ Disc / USB Memory Stick Update
You can update the software by using a disc or USB Memory Stick.
Prepare a blank disc or USB Memory Stick for software update:
Access www.sanyo-av.com, and download the latest version software to a blank disc or USB Memory Stick
using a PC by following the directions described on the website.
• Use a blank disc or USB Memory Stick, download one software per disc or USB Memory Stick. Write the
software in the root directory of the disc or USB Memory Stick.
• For more details on how to download the software, please refer to the website.
1. Use [
] to select ˝Settings˝ in the Home Menu, then press [OK].
2. Use [
] to select ˝Others˝, then press [OK].
3. Use [
] to select ˝Software Update˝, then press [OK].
4. Use [
] to select ˝Disc˝ or ˝USB Memory Stick˝, then press [OK].
5. Use [
] to select ˝Yes˝, then press [OK].
6. Insert the disc or connect the USB Memory Stick for software update.
7. After loading disc or USB Memory Stick, confirmation message will appear. Select ˝Yes˝ and press [OK].
8. The unit will restart automatically, then software update will start.
• It may take a while to complete the updating.
9. After the update finishes, this unit will restart. Remove the disc or the USB Memory Stick from the unit.
CautionC
• Please do not unplug the AC power cord, eject the disc or disconnect the USB Memory Stick or press
[
(POWER)] to turn the unit to Standby mode while performing a ˝Disc / USB Memory Stick Update˝.
NoteD
• Software update will not change any of the current settings.
EN 40
10.5. Voice Guide
HOME A ˝Settings˝ A ˝Audio Out˝ A ˝Voice Guide˝
1. Use [
] to select “Settings” in the Home Menu, then press [OK].
2. Use [
] to select “Audio Out”, then press [OK].
3. Use [
] to select the “Voice Guide”, then press [OK].
4. Use [
] to select “On” or “Off”, then press [OK].
5. Press [HOME] to Exit.
NoteD
• In order to enable the Voice Guide function, the OSD language needs to be set to English or Spanish.
Voice Guide is not available in French.
• When Voice Guide is set to On, the HDMI Audio Output setting (Settings A HDMI A Audio Output) is fixed to
LPCM. Setting for HDMI Audio Output can be changed only when Voice Guide is set to Off.
10.6. Restore Default Settings
HOME A ˝Settings˝ A ˝Others˝ A ˝Initialize˝
Menus to reset player settings, format a USB Memory Stick.
1. Use [
] to select ˝Settings˝ in the Home Menu, then press [OK].
2. Use [
] to select ˝Others˝, then press [OK].
3. Use [
] to select ˝Initialize˝, then press [OK].
4. Use [
] to select the desired setting, then press [OK].
˝Reset Settings˝:
All the settings except for the ˝Parental˝ settings will be reset to default.
˝Format USB Memory Stick˝ (Only available when a USB Memory Stick is connected):
Initialize the USB Memory Stick.
˝(Unit) Erase Saved BD-ROM Data˝:
Clears the data saved for the BD-ROM contents, such as BD-ROM game scores, on this player.
˝(USB Memory Stick) Erase Saved BD-ROM Data˝
(Only available when a USB Memory Stick is connected):
Clears the supplemental data for the BD-ROM playback, such as Subtitle data, from the USB Memory Stick.
˝Reset All Settings˝
Resets this unit to factory default settings.
5. Use [
] to select ˝Yes˝, then press [OK].
6. Confirmation message will appear. Press [OK] to complete the setting.
7. Press [HOME] to Exit.
CautionC
• Do not remove the USB Memory Stick while executing ˝Format USB Memory Stick˝ or ˝(USB Memory Stick)
Erase Saved BD-ROM Data˝. It will damage the USB Memory Stick.
NoteD
• ˝Format USB Memory Stick˝ and ˝(USB Memory Stick) Erase Saved BD-ROM Data˝ are not available when a
Blu-ray Disc™ is in the unit.
EN 41
11. TROUBLESHOOTING
Problem Tip
No power. Check the AC power cord, if it is properly connected.
Try another power outlet.
Unplug the AC power cord, and wait for about 5-10 seconds. Plug it back
in and attempt to power On the unit.
No sound or picture. Make sure both the TV and Blu-ray Disc™ player are Turned On.
Confirm the connections to the TV are made properly as shown in the
˝CONNECTIONS˝ on page 11.
Check to see whether the connected TV or another device supports HDCP.
(This unit will not output a video signal unless the other device supports
HDCP.)
No reaction to the remote control. Reduce the distance to infrared sensor window.
Confirm that the player’s AC power cord is plugged into a power outlet.
Check the batteries in the remote control and make sure they are inserted
properly by + or - symbols.
Aim the remote at the unit’s remote receiver. Then press any arrow key and
confirm the Power-On indicator dims and blinks when a remote button is
pushed. Please check IR signal. Refer to ˝IR Signal Check˝ on page 46.
No Audio / Video signal on the
display device via HDMI cable.
If the unit is connected to a non-certified HDMI device, the Audio / Video
signal will not output to that device.
Make sure the display device is on the correct Input / Video source.
Perform the HDMI hotplug: Disconnecting the HDMI cable from the
display device, Turn On both devices, and replug the HDMI cable back in.
Check with the TV manufacturer, if there are any software updates
available for the TV.
Check to see if the HDMI cable is a certified version.
No high-definition video signal on
the TV screen.
Does the disc contain high-definition video? High-definition video is only
available when the disc contains it.
Does the TV support high-definition video? High-definition video is only
available when the TV supports it.
Distorted picture. Sometimes a small amount of picture distortion may appear. This is not a
malfunction.
Completely distorted picture or
black / white picture with Blu-ray
Disc™ / DVD.
Make sure the disc is compatible with this unit.
No sound or distorted sound. Adjust the volume.
Check to see if the speakers are connected correctly.
Check the HDMI connection.
Make sure the HDMI cable is not plugged into an HDMI-DVI adapter or
Projector which does not handle Digital sound.
Check the settings in ˝AudioOut˝ menu.
Picture freezes momentarily during
disc playback.
Check the disc for fingerprints / scratches and clean with a soft cloth
wiping from the center to the outer edge.
Cannot play back a disc. Make sure that the disc is playable on this unit.
Check the region code of the disc. This unit supports the following region
codes.
- Blu-ray Disc™: ˝A˝
- DVD: ˝ALL˝ or ˝1˝
For DVD-RW/-R, make sure that the disc is finalized.
Clean the disc.
Is the disc a newer title? This problem may be solved by software update.
Refer to ˝Software Update˝ on page 39.
continued on next page
EN 42
Problem Tip
No return to start-up screen when
disc is removed.
Soft reset this unit by turning it Off for 30 seconds, then On again.
To completely reset the unit, press and hold [
(POWER)] on the front panel
for 10 seconds to shut down the unit or unplug the AC power cord from the
AC outlet for 5-10 seconds.
in the upper right hand corner
of the TV screen.
The operation is not possible.
Buttons do not work or the unit
stops responding.
To soft reset the unit, press and hold [
(POWER)] on the front panel for
10 seconds to shut down the unit or to hard reset the unit by unplugging
the AC power cord from the AC outlet for 5-10 seconds.
The unit does not respond to
some operating commands during
playback.
The operations may be prohibited by the disc. Refer to the instructions
for the disc.
The unit cannot read Blu-ray
Disc™ / DVD/ CD.
Condensation? (Let sit 1 or 2 hours)
Check to see if the disc is compatible with this unit. (Refer to page 16.)
Wipe dirt off the disc from the center to the outside or replace the disc.
Refer to ˝Cleaning Discs˝ on page 46.
Scene shooting Angle does not
switch.
Angles cannot be switched for Blu-ray Disc™ / DVD which do not contain
multiple Angles. In some cases multiple Angles are only recorded for
specific scenes.
Playback does not start when a
Title is selected.
Check the settings in ˝Parental˝ menu.
The password for rating level has
been forgotten.
Enter the default password ˝4737˝, then your forgotten password will be
cleared. Then to change password go to ˝Password Change˝ on page 38.
Error message appears when I
select ˝Auto˝ in the ˝Language˝.
Make sure that the unit is connected to a TV that is compatible with HDMI
CEC and the ˝HDMI CEC˝ is set to ˝On˝.
This error message may appear when your TV's OSD language is not
supported by this unit.
Cannot play back AVCHD file. This unit cannot play back stand-alone AVCHD files (*.m2ts, *.mts or
*.m2t) written to a DVD. The DVD containing AVCHD files must have a
proper file and folder structure meeting AVCHD format specifications.
Please use AVCHD compliant device / software to burn or copy AVCHD
files to DVD. (Please refer to user manuals of the device / software for
more information.)
The capacity of the USB Memory
Stick decreased.
Data may be written on the USB Memory Stick when a BD-video uses the
Virtual Package feature while a USB Memory Stick is connected to the
unit.
Cannot play back a MPEG-2 video
and audio from the USB Memory
Stick.
MPEG-2 is not compatible with this unit.
Cannot read the contents on the
USB Memory Stick.
The USB Memory Stick is not compatible with this unit or the contents
may be damaged.
Try and Turn Off the unit, then turn it back On.
To soft reset the unit, press and hold [
(POWER)] on the front panel for
10 seconds to shut down the unit or to hard reset the unit by unplugging
the AC power cord from the AC outlet for 5-10 seconds.
Cannot play back BD-Video. Connect a USB Memory Stick (256MB or more of available memory)
which is formatted on this unit. Some discs require memory when
playing back the content.
Do not disconnect the USB Memory Stick during playback.
Cannot use BD-Live. BD-Live function cannot be performed because this unit does not
connect the internet.
Cannot play back 3D. Some discs may not be played back because this unit does not support
3D.
Cannot load a Blu-ray Disc™ (stuck
in ˝Loading…˝ mode) and cannot
Open the disc tray to eject the disc.
Unplug unit from AC outlet for 20 seconds. Plug unit back in and press
the [
(OPEN/CLOSE)] on the unit to eject the disc.
continued on next page
EN 43
Problem Tip
The software update screen
appears after Turning On the unit.
Please complete the software update.
When the software update has failed, the software update screen will
keep appearing after turning the unit on. If the software update continues
failing, please try it by using a USB Memory Stick with the update
software installed in its root directory. In this case, please change the file
name as below.
˝E****UH10000FA1.bin˝ A ˝UPDATE10000FA1.BIN˝
Do not change the numbers. The file name is case sensitive.
Cannot read a USB Memory Stick. The format of the USB Memory Stick is not compatible with this unit.
Please try and format it on this unit (All data will be deleted).
Cannot play back JPEG files from
a disc.
Make sure that the disc was recorded in the UDF, ISO9660 or JOLIET
format.
Cannot find a JPEG file. Make sure that the selected Group (folder) does not contain more than
9,999 files for Blu-ray Disc™ / DVD / USB Memory Stick and 999 files for
CD.
Make sure that the file extension is .jpg / .JPG / .jpeg / or .JPEG.
No Audio signal from Surround
system of the audio system.
Make sure the audio system is turned on.
Check the Input mode on the audio system if it is on the correct channel.
Check if the Surround system is compatible with either Bitstream or
LPCM. If not sure please check the user manual or contact the Surround
manufacturer. Once confirmed check the setting in the ˝Settings˝ of this
unit.
Increase the volume level of the Surround system.
NoteD
• Do not attempt to repair the Blu-ray Disc™ Player yourself. This may cause severe injury, irreparable damage
to your Blu-ray Disc™ Player and void your warranty.
• Please have available your Blu-ray Disc™ Player model and serial number before contacting us. These
numbers are available on the cabinet, as well as on the packaging.
EN 44
12. LANGUAGE CODE LIST
Language Code Language Code Language Code Language Code
A-B French [FRE] 5264 Macedonian 5957 Siswat 6565
Abkhazian 4748 Frisian 5271 Malagasy 5953 Slovak [SLO] 6557
Afar 4747 Galician 5358 Malay 5965 Slovenian 6558
Afrikaans 4752 Georgian 5747 Malayalam 5958 Somali 6561
Albanian 6563 German [GER] 5051 Maltese 5966 Spanish [SPA] 5165
Amharic 4759 Greek [GRE] 5158 Maori 5955 Sundanese 6567
Arabic 4764 Greenlandic 5758 Marathi 5964 Swahili 6569
Armenian 5471 Guarani 5360 Moldavian 5961 Swedish [SWE] 6568
Assamese 4765 Gujarati 5367 Mongolian 5960 T
Aymara 4771 Hausa 5447 Nauru 6047 Tagalog 6658
Azerbaijani 4772 Hebrew 5451 Nepali 6051 Tajik 6653
Bashkir 4847 Hindi 5455 Norwegian [NOR] 6061 Tamil 6647
Basque 5167 Hungarian [HUN] 5467 O-R Tatar 6666
Bengali;Bangla 4860 I-K Occitan 6149 Telugu 6651
Bhutani 5072 Icelandic [ICE] 5565 Oriya 6164 Thai 6654
Bihari 4854 Indonesian 5550 Oromo (Afan) 6159 Tibetan 4861
Bislama 4855 Interlingua 5547 Panjabi 6247 Tigrinya 6655
Breton 4864 Interlingue 5551 Pashto;Pushto 6265 Tonga 6661
Bulgarian [BUL] 4853 Inupiak 5557 Persian 5247 Tsonga 6665
Burmese 5971 Irish [GLE] 5347 Polish [POL] 6258 Turkish [TUR] 6664
Byelorussian 4851 Italian [ITA] 5566 Portuguese [POR] 6266 Turkmen 6657
C-E Japanese [JPN] 5647 Quechua 6367 Twi 6669
Cambodian 5759 Javanese 5668 Rhaeto-Romance 6459 U-Z
Catalan 4947 Kannada 5760 Romanian [RUM] 6461 Ukrainian 6757
Chinese [CHI] 7254 Kashmiri 5765 Russian [RUS] 6467 Urdu 6764
Corsican 4961 Kazakh 5757 S Uzbek 6772
Croatian 5464 Kinyarwanda 6469 Samoan 6559 Vietnamese 6855
Czech [CZE] 4965 Kirghiz 5771 Sangho 6553 Volapuk 6861
Danish [DAN] 5047 Kirundi 6460 Sanskrit 6547 Welsh 4971
Dutch [DUT] 6058 Korean [KOR] 5761 Scots Gaelic 5350 Wolof 6961
English [ENG] 5160 Kurdish 5767 Serbian 6564 Xhosa 7054
Esperanto 5161 L-N Serbo-Croatian 6554 Yiddish 7155
Estonian 5166 Laothian 5861 Sesotho 6566 Yoruba 7161
F-H Latin 5847 Setswana 6660 Zulu 7267
Faroese 5261 Latvian;Lettish 5868 Shona 6560
Fiji 5256 Lingala 5860 Sindhi 6550
Finnish [FIN] 5255 Lithuanian 5866 Singhalese 6555
NoteD
• If you choose a language that has a 3-letter-language code (written in bracket), the code will be displayed
every time you change the Subtitle language setting on page 28 or audio language setting on page 29.
If you choose any other languages, ˝---˝ will be displayed instead.
EN 45
13. SPECIFICATIONS
General
Signal system NTSC Color
Power requirements 120 V AC, 60 Hz
Power consumption 15 W (standby: 0.5 W)
Dimensions (width x height x depth) 11.1 x 1.7 x 7.9 inches (280.0 x 41.0 x 198.5 mm)
Weight 2.2 lbs. (1.0 kg)
Operating temperature 41°F (5°C) to 104°F (40°C)
Operating humidity Less than 80 % (no condensation)
Terminals
USB input
TYPE A
HDMI output
HDMI jack x 1
Digital Video: 480p, 720p, 1080i, 1080p, 1080p/24
Digital Audio
NoteD
• The specifications and design of this product are subject to change without notice.
EN 46
14. MAINTENANCE
■ Servicing
• Please refer to relevant topics on ˝TROUBLESHOOTING˝ on page 41 before returning the product.
• If this unit becomes inoperative, do not try to correct the problem by yourself. There are no user-serviceable
parts inside. Eject the disc (if possible), disconnect the USB Memory Stick (if connected to the unit), place
the unit into Standby mode, unplug the AC power plug, and please contact: 1-866-212-0436 or visit :
www.sanyo-av.com
■ Cleaning the Cabinet
• Wipe the front panel and other exterior surfaces of the unit with a soft cloth.
• Never use a solvent, thinner, benzene or alcohol to clean the unit. Do not spray insecticide liquid near the
unit. Such chemicals may discolor the surface or damage the unit.
■ Cleaning Discs
• When a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from the center to outside. Do not
wipe in a circular motion.
• Do not use solvents such as benzine, thinner, commercially available cleaners, detergent, abrasive cleaning
agents or antistatic spray intended for analog records.
■ Cleaning the Disc Lens
• If this unit still does not perform properly although you refer to the relevant sections and to
˝TROUBLESHOOTING˝ in this user manual, the laser optical pickup unit may be dirty. Consult your dealer or
an Authorized Service Center for inspection and cleaning of the laser optical pickup unit.
■ Disc Handling
• Handle the discs so that fingerprints and dust do not adhere to the surfaces of the discs.
• Always store the disc in its protective case when it is not used.
• Note that discs with special shapes (heart-shaped discs, octagonal discs, etc.) cannot be played back on this
unit. Do not attempt to play such discs, as they may damage the unit.
■ IR Signal Check
If the remote control does not work properly, you can test IR signal using a digital camera
(including a cellphone with a built-in camera) to see if the remote control sends out the infrared
signal.
1. Turn On the digital camera.
2. Direct a digital camera to the remote control, then press and hold any button on the remote
control.
• If infrared light appears on the digital camera display, the remote control is working.
EN 47
15. TRADEMARK INFORMATION
˝Blu-ray Disc™˝, ˝Blu-ray˝ and ˝Blu-ray Disc™˝ logo
are trademarks of the Blu-ray Disc Association.
˝BONUSVIEW™˝ and ˝BONUSVIEW™˝ logo are
trademarks of the Blu-ray Disc Association.
Manufactured under license from Dolby Laboratories.
Dolby, Dolby Audio, and the double-D symbol are
trademarks of Dolby Laboratories.
Java and all Java based trademarks and logos are
trademarks or registered trademarks of Oracle and/or
its affiliates.
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS Licensing
Limited.
DTS, the Symbol, & DTS and the Symbol together
are registered trademarks, and DTS 2.0+Digital Out
is a trademark of DTS, Inc. © DTS, Inc. All Rights
Reserved.
The terms HDMI and HDMI High-Definition
Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
˝x.v.Color˝ and ˝x.v.Color˝ logo are trademarks of
Sony Corporation.
is a trademark of DVD Format/Logo Licensing
Corporation.
˝AVCHD˝ and the ˝AVCHD˝ logo are trademarks of
Panasonic Corporation and Sony Corporation.
THIS PRODUCT IS LICENSED UNDER THE AVC
PATENT PORTFOLIO LICENSE FOR THE PERSONAL
AND NON-COMMERCIAL USE OF A CONSUMER
TO (i) ENCODE VIDEO IN COMPLIANCE WITH
THE AVC STANDARD (˝AVC VIDEO˝) AND/OR (ii)
DECODE AVC VIDEO THAT WAS ENCODED BY A
CONSUMER ENGAGED IN A PERSONAL AND NON-
COMMERCIAL ACTIVITY AND/OR WAS OBTAINED
FROM A VIDEO PROVIDER LICENSED TO PROVIDE
AVC VIDEO. NO LICENSE IS GRANTED OR SHALL
BE IMPLIED FOR ANY OTHER USE. ADDITIONAL
INFORMATION MAY BE OBTAINED FROM MPEG LA,
L. L. C. SEE HTTP://WWW.MPEGLA.COM
THIS PRODUCT IS LICENSED UNDER THE VC-1
PATENT PORTFOLIO LICENSE FOR THE PERSONAL
AND NON-COMMERCIAL USE OF A CONSUMER
TO (i) ENCODE VIDEO IN COMPLIANCE WITH
THE VC-1 STANDARD (˝VC-1 VIDEO˝) AND/OR (ii)
DECODE VC-1 VIDEO THAT WAS ENCODED BY A
CONSUMER ENGAGED IN A PERSONAL AND NON-
COMMERCIAL ACTIVITY AND/OR WAS OBTAINED
FROM A VIDEO PROVIDER LICENSED TO PROVIDE
VC-1 VIDEO. NO LICENSE IS GRANTED OR SHALL
BE IMPLIED FOR ANY OTHER USE. ADDITIONAL
INFORMATION MAY BE OBTAINED FROM MPEG LA,
L.L.C. SEE HTTP://WWW.MPEGLA.COM
EN 48
16. GLOSSARY
AACS
Advanced Access Content System (AACS) is the
content protection scheme used with Blu-ray discs.
Analog Audio
An electrical signal that directly represents sound.
Compare this to digital audio which can be an
electrical signal, but is an indirect representation of
sound. See also ˝Digital Audio˝.
Aspect Ratio
The width of a TV screen relative to its height.
Conventional TVs are 4:3 (in other words, the TV
screen is almost square); widescreen models are 16:9
(the TV screen is almost twice as wide as its height).
AVCHD
AVCHD is a new format for high definition video
camcorders which can record and play high-
resolution HD images.
Blu-ray Disc™
Blu-ray Disc™ is a next generation optical video disc
which is capable of storing much more data than
a conventional DVD. The large capacity makes it
possible to benefit from the features such as high-
definition videos, multi-channel surround sounds,
interactive menus and so on.
Chapter
Just as a book is split up into several chapters, a Title
on a BD-video or DVD-video is usually divided into
chapters. See also ˝Title˝.
Cinavia™
Cinavia Notice
This product uses Cinavia technology to limit the
use of unauthorized copies of some commercially-
produced film and videos and their soundtracks.
When a prohibited use of an unauthorized copy is
detected, a message will be displayed and playback or
copying will be interrupted.
More information about Cinavia technology is
provided at the Cinavia Online Consumer Information
Center at
http://www.cinavia.com
To request additional information about Cinavia by
mail, send a postcard with your mailing address to:
Cinavia Consumer Information Center, P.O. Box 86851,
San Diego, CA, 92138, USA.
This product incorporates proprietary technology
under license from Verance Corporation and is
protected by U.S. Patent 7,369,677 and other U.S.
and worldwide patents issued and pending as well
as copyright and trade secret protection for certain
aspects of such technology.
Cinavia is a trademark of Verance Corporation.
Copyright 2004-2015 Verance Corporation. All
rights reserved by Verance. Reverse engineering or
disassembly is prohibited.
Digital Audio
An indirect representation of sound by numbers.
During recording, the sound is measured at discrete
intervals (44,100 times a second for CD audio) by an
analog-to-digital converter, generating a stream of
numbers. On playback, a digital-to-analog converter
generates an analog signal based on these numbers.
See also ˝Sampling Frequency˝ and ˝Analog Audio˝.
Dolby Digital
The system to compress digital sound developed by
Dolby Laboratories. It offers you sound of stereo (2ch)
or multi-channel audio.
Dolby Digital Plus
Dolby Digital Plus is the next generation digital audio
compression technology developed as an extension
to Dolby Digital. Blu-ray Disc™ supports 7.1 multi-
channel surround sound output.
Dolby TrueHD
Dolby TrueHD is a lossless coding technology
developed for next generation optical discs. Blu-ray
Disc™ supports 7.1 multi-channel surround sound
output.
DTS
®
(Digital Theater System)
DTS
®
is a multi channel surround sound system. You
can enjoy movie dynamic and realistic sound like
movie theater. DTS surround sound technologies
were developed by DTS, Inc.
DTS-HD
®
DTS-HD
®
is a multi-channel technology developed as
an extension of the original DTS Coherent Acoustics
format. Blu-ray Disc™ supports 7.1 multi-channel
surround sound output.
HDMI (High-Definition Multimedia Interface)
A digital interface between an audio and video
Source. It can transmit component video, audio, and
control signal with one cable connection.
JPEG (Joint Photographic Experts Group)
JPEG is a method of compressing still picture files.
You can copy JPEG files on BD-RE/-R, DVD-RW/-R,
CD-RW/-R, or USB Memory Stick from a computer and
play back the files on this unit.
Local Storage
A storage area of sub contents for playing virtual
packages on BD-video.
continued on next page
EN 49
PCM (Pulse Code Modulation)
The most common system of encoding digital audio,
found on CD and DAT. Excellent quality, but requires a
lot of data compared to formats such as Dolby Digital
and MPEG audio. For compatibility with digital audio
recorders (CD, MD and DAT) and AV amplifiers with
digital Inputs, this unit can convert Dolby Digital, DTS,
and MPEG audio to PCM. See also ˝Digital Audio˝.
Region Code
Regions associate discs and players with particular
areas of the world. This unit will only play back discs
that have compatible region codes. You can find the
region code of your unit by looking on the rear panel.
Some discs are compatible with more than one region
(or all regions).
Sampling Frequency
The rate which sound is measured by a specified
interval to turn into digital audio data. The numbers
of sampling in one second defines as sampling
frequency. The higher the rate, the better the sound
quality.
Title
A collection of chapters on BD-video or DVD-video.
See also ˝Chapter˝.
Track
Audio CD uses Tracks to divide up the content of a
disc. The BD-video or DVD-video equivalent is called a
Chapter.
See also ˝Chapter˝.
x.v.Color
˝x.v.Color˝ is a promotion name given to the products
that have the capability to realize a wide color space
based on the xvYCC specifications and is a trademark
of Sony Corporation.
WARRANTY COVERAGE:
This warranty obligation is limited to the terms as set forth
below.
WHO IS COVERED:
This product warranty is issued to the original purchaser or the
person receiving the product as a gift against defects in materials
and workmanship as based on the date of original purchase
(“Warranty Period”) from an Authorized Dealer. The original sales
receipt showing the product name and the purchase date from an
authorized retailer is considered such proof.
WHAT IS COVERED:
This warranty covers new products if a defect in material or
workmanship occurs and a valid claim is received within the
Warranty Period. At its option, the company will either (1) repair
the product at no charge, using new or refurbished replacement
parts, or (2) exchange the product with a product that is new or
which has been manufactured from new, or serviceable used
parts and is at least functionally equivalent or most comparable
to the original product in current inventory, or (3) refund the
original purchase price of the product.
Replacement products or parts provided under this warranty are
covered against defects in materials and workmanship from the
date of the replacement or repair for ninety (90) days or for the
remaining portion of the original product’s warranty, whichever
provides longer coverage for you. When a product or part is
exchanged, any replacement item becomes your property and
the replaced item becomes company property. When a refund is
given, your product becomes company property.
Note: Any product sold and identified as refurbished or renewed
carries a ninety (90) day limited warranty.
Replacement product can only be sent if all warranty
requirements are met. Failure to follow all requirements can
result in delay.
WHAT IS NOT COVERED - EXCLUSIONS AND LIMITATIONS:
This Limited Warranty applies only to new company
manufactured products that can be identified by the trademark,
trade name, or logo affixed to it. This Limited Warranty does not
apply to any hardware product or any software, even if packaged
or sold with the product, as manufacturers, suppliers, or
publishers may provide a separate warranty for their own
products packaged with the bundled product.
The company is not liable for any damage to or loss of any
programs, data, or other information stored on any media
contained within the product, or other additional product or part
not covered by this warranty. Recovery or reinstallation of
programs, data or other information is not covered under this
Limited Warranty.
This warranty does not apply (a) to damage caused by accident,
abuse, misuse, neglect, misapplication, or non-supplied product,
(b) to damage caused by service performed by anyone other than
company approved Authorized Service Location, (c) to a product
or a part that has been modified without written company
permission, or (d) if any serial number has been removed or
defaced, or (e) product, accessories or consumables sold “AS IS”
without warranty of any kind by including refurbished product
sold “AS IS” by some retailers.
This Limited Warranty does not cover:
• Shipping charges to return defective product.
• Labor charges for installation or setup of the product, adjustment
of customer controls on the product, and installation or repair of
antenna/signal source systems outside of the product.
• Product repair and/or part replacement because of improper
installation or maintenance, connections to improper voltage
supply, power line surge, lightning damage, retained images or
screen markings resulting from viewing fixed stationary
content for extended periods, product cosmetic appearance
items due to normal wear and tear, unauthorized repair or
other cause not within the control of the company.
• Damage or claims for products not being available for use, or
for lost data or lost software.
• Damage from mishandled shipments or transit accidents when
returning product.
• A product that requires modification or adaptation to enable it
to operate in any country other than the country for which it
was designed, manufactured, approved and/or authorized, or
repair of products damaged by these modifications.
• A product used for commercial or institutional purposes
(including but not limited to rental purposes).
• Product lost in shipment and no signature verification receipt
can be provided.
• Failure to operate per Owner’s Manual.
TO OBTAIN ASSISTANCE…
Contact the Customer Care Center at:
www.sanyo-av.com
1 866 212 0436
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS
WARRANTY IS THE EXCLUSIVE REMEDY FOR THE CONSUMER,
WITH THE ISSUING COMPANY NOT LIABLE FOR ANY
INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT.
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW,
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN
DURATION TO THE DURATION OF THIS WARRANTY.
Some states do not allow the exclusions or limitation of
incidental or consequential damages, or allow limitations on how
long an implied warranty lasts, so the above limitations or
exclusions may not apply to you.
LIMITED WARRANTY
NINETY (90) DAY LABOR / ONE (1) YEAR PARTS
This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.
FUNAI CORPORATION, Inc. 19900 Van Ness Avenue, Torrance, CA 90501
LIMITED WARRANTY
back cover
ES 51
17. ESPAÑOL
17. 1. Mando a Distancia
1 12*
13
14
16
17
2
3
4
11
15
18
19
5
6*
7
8
20
21
9
10
* La unidad también se puede encender pulsando
estos botones.
1. Botón
(ENCENDIDO)
• Pulse el botón para encender la unidad, o para
pasar la unidad al modo de espera. (Para apagar
completamente la unidad, debe desconectar el
cable de alimentación de CA.)
2. Botón DISC MENU
• Durante la reproducción (Blu-ray Disc™ o DVD),
púlselo seleccionar el menú (menú superior o
menú emergente/menú).
3. Botones de
• Púlselos para seleccionar elementos o
configuraciones.
4. Botón SEARCH
• Púlselo para mostrar el menú de selección de
número o el menú de buscar.
5. Botón
(REVERSO)
• Durante la reproducción, púlselo para invertir
rápido la reproducción.
6. Botón
(REPRODUCIR)*
• Púlselo para iniciar o reanudar la reproducción.
7. Botón
(SALTAR)
• Durante la reproducción, púlselo una vez para
volver al comienzo del título, capítulo, pista o
archivo actual.
• Durante la reproducción, pulse dos veces sobre
la tecla para volver al título, capítulo, pista o
archivo anterior.
• Durante la reproducción de archivos JPEG,
púlselo para volver al archivo anterior.
8. Botón
(DETENER)
• Púlselo para detener la reproducción.
9. Botón DISPLAY
• Púlselo para visualizar el menú desplegable en
pantalla.
10. Botón REPEAT
• Presione para seleccionar el modo de repetición.
11. Botones de ROJO / VERDE / AZUL / AMARILLO
• Púlselos para activar las teclas de atajo en
algunas funciones de BD-vídeo. Cuando se
despliega la lista de archivos, presione para
cambiar las páginas.
12. Botón
(ABRIR/CERRAR)*
• Púlselo para cerrar o abrir la bandeja para
discos.
13. Botón HOME
• Púlselo para mostrar el menú de inicio.
14. Botón MODE
• Durante la reproducción, púlselo para visualizar
el menú de reproducción.
15. Botón OK
• Púlselo para confirmar o seleccionar elementos
de menú.
16. Botón RETURN
• Púlselo para volver a la pantalla de funciones o
menú mostrado anteriormente.
17. Botón
(ADELANTAR)
• Durante la reproducción, púlselo para avanzar
rápido la reproducción.
• Cuando la reproducción esté en pausa, púlselo
para avanzar lentamente la reproducción.
18. Botón
(SALTAR)
• Durante la reproducción, púlselo para saltar al
siguiente capítulo, pista o archivo.
• Cuando la reproducción esté en modo de pausa,
púlselo para avanzar la reproducción imagen a
imagen.
19. Botón
(PAUSAR)
• Púlselo para pausar la reproducción.
Continua en la página siguiente
ES 52
20. Botón AUDIO
• Púlselo para seleccionar el canal de sonido
(como idiomas de sonido) de un disco.
21. Botón SUBTITLE
• Púlselo para seleccionar los subtítulos de un
disco.
NotaD
• El indicador Encendido en el panel frontal se
atenúa y parpadea cuando se recibe la señal IR del
control remoto.
• Use el control remoto suministrado. No se
garantiza la operación de control remoto en
cualquier otro control remoto, tal como un control
remoto universal.
17.2. Encontrar el Canal de Video en su Televisor
Revise los siguientes pasos despues de haber completado todas las conexiones a su TV.
1. Presione [
(ENCENDIDO)] para Encender la unidad.
2. Encienda su televisor.
3. Busque el boton Source / Input / AUX / Video en el control remoto del televisor. El boton puede variar en
funcion de la marca y el modelo del televisor. Una vez localizado el boton presione hasta ver ˝Please Wait...˝
en la pantalla.
Please Wait...
Esta es la visualización correcta de la entrada de la fuente de video.
• Si la TV está conectada por medio de un cable HDMI, puede tomar algunos minutos para que aparezca la
imagen de abertura.
ES 53
17.3. Instalacion Inicial
Por favor, siga las instrucciones que se exponen a continuacion para completar la configuracion inicial.
1. Aparece la pantalla de configuracion del idioma. Utilice [
] para seleccionar su idioma y pulse luego
[OK].
Por favor, seleccione su idioma para el menú en
pantalla.
Si desea usar la función de Guía por voz, ajuste
"English" o "Español".
English
Español
Français
Idioma
2. Aparecerá la pantalla de configuración de Guía por Voz. Use [ ] para seleccionar “On” u “Off”, y
después presione [OK].
Enciende o apaga la Guía por voz. Enciende la
Guía de voz, el ajuste "Salida acústica" se
ajustará en "LPCM" automáticamente. Si la
Guía por Voz está encendida, no podrá ajustar
la "Salida acústica".
Enc.
Apdo.
Retorno
GuÍa por voz
Esta pantalla no aparecerá cuando se seleccione “Français” en el ajuste de “Idioma”.
■ Cómo restablecer el Idioma OSD
Puede restablecer el idioma OSD si seleccionó el ajuste de idioma equivocado.
1. Presione [HOME] para desplegar el Menú de Inicio.
2. Utilice [
] para seleccionar ˝ ˝, despés presione [OK].
• Esta partida es ˝Settings˝ (inglés) / ˝Configuraciones˝ (español) / ˝Paramètres˝ (francés).
• A partir de aquí, por favor seleccione una de las siguientes partidas que puede encontrar en la pantalla:
3. Utilice [
] para seleccionar ˝Playback˝ (inglés) / ˝Reproducción˝ (español) / ˝Lecture˝ (francés), y
después presione [OK].
4. Utilice [
] para seleccionar ˝Language˝ (inglés) / ˝Idioma˝ (español) / ˝Langue˝ (francés), y después
presione [OK].
5. Utilice [
] para seleccionar el idioma que desee, después presione [OK].
6. Si las partidas de ajuste se despliegan en el idioma que seleccionó, presione [HOME] para salir.
GARANTÍA LIMITADA
back cover
ECS00UL / ECS00UH
★★★★★
COBERTURA DE GARANTÍA:
La obligación de ésta garantía se limita a los términos
establecidos a continuación.
QUIÉNES ESTÁN CUBIERTOS:
La compañía le garantiza el producto al comprador original o a la
persona que lo recibe como regalo contra defectos en los
materiales y en la mano de obra, a partir de la fecha de la compra
original ("período de garantía") en el distribuidor autorizado. El
recibo de ventas, donde aparecen el nombre del producto y la
fecha de la compra en un distribuidor autorizado, se considerará
comprobante de esta fecha.
LO QUE ESTÁ CUBIERTO:
Esta garantía cubre productos nuevos si se produce algún
defecto en el material o la mano de obra y la compañía recibe un
reclamo válido dentro del período de garantía. A su propia
discreción, ésta (1) reparará el producto sin costo, usando piezas
de repuesto nuevas o reacondicionadas; (2) intercambiar el
producto con uno nuevo o que se haya fabricado a partir de
partes nuevas o usadas a las que se pueda dar servicio y con por
lo menos la funcionalidad equivalente o más comparable con el
producto original en el inventario actual, o (3) reembolsar el
precio de compra original del producto.
La compañía garantiza productos o piezas de repuesto
proporcionados bajo esta garantía contra defectos en los
materiales y en la mano de obra durante noventa (90) días o por
el resto de la garantía del producto original, lo que le proporcione
más cobertura. Cuando se cambia un producto o una pieza, el
artículo que usted recibe pasa a ser de su propiedad y el que le
entrega a la compañía pasa a ser propiedad de ésta última.
Cuando se proporcione un reembolso, su producto pasa a ser
propiedad de la compañía.
Nota: Cualquier producto que se venda y que esté identificado
como reacondicionado o renovado tiene una garantía limitada de
noventa (90) días.
El producto de reemplazo sólo se puede enviar si se cumplen
todos los requisitos de la garantía. El incumplimiento de tales
requisitos puede ocasionar un retardo.
LO QUE NO SE CUBRE: EXCLUSIONES Y LIMITACIONES:
La garantía limitada aplica sólo a los productos nuevos
fabricados por o para la compañía que se pueden identificar por
la marca registrada, el nombre comercial o por tener el logotipo
correspondiente. Esta garantía limitada no se aplica a ningún
producto de hardware ni de software que no sea de la compañía,
incluso si viene empacado con el producto o si se vende junto
con éste. Los fabricantes, proveedores o editores que no sean de
la compañía pueden proporcionar una garantía por separado
para sus propios productos empacados con el producto.
La compañía no es responsable por ningún daño o pérdida de
programas, datos u otra información almacenados en algún
medio contenido en el producto, ni por ningún otro producto o
pieza que no esté cubierta por esta garantía. La recuperación o la
reinstalación de programas, datos u otra información no está
cubierta por esta garantía limitada.
Esta garantía no aplica (a) a daños causados por accidente,
abuso, mal uso, negligencia, mala aplicación o por productos no
provistos por la compañía; (b) a daño provocado por servicio
realizado por cualquier persona ó establecimiento de servicio no
autorizado por la compañía; (c) a productos o piezas que se
hayan modificado sin la autorización por escrito de la compañía;
(d) si se ha retirado o desfigurado el número de serie; y tampoco
se aplica la garantía a (e) productos, accesorios o insumos
vendidos TAL COMO ESTÁN sin garantía de ningún tipo, lo que
incluye productos vendidos TAL COMO ESTÁN por algunos
distribuidores.
Esta garantía limitada no cubre:
• Cargos de envío para regresar el producto defectuoso.
• Los costos de mano de obra por la instalación o configuración
del producto, el ajuste de controles del cliente en el producto y
la instalación o reparación de sistemas de antena o fuente de
señal externos al producto.
• La reparación del producto o el reemplazo de piezas debido a
instalación o mantenimiento inadecuada, a conexiones hechas
a un suministro de voltaje inadecuado, sobrevoltaje de la línea
de alimentación, daño causado por relámpagos, imágenes
retenidas o marcas en la pantalla producto de la visualización
de contenido fijo durante períodos prolongados, reparaciones
cosméticas debido al desgaste normal, reparaciones no
autorizadas u otras causas que no se encuentren bajo el
control de la compañía.
• Daños o reclamos por productos que no están disponibles
para su uso, por datos perdidos o por pérdida de software.
• Daños debido a mala manipuración en el transporte o
accidentes de envío al devolver el producto.
• Un producto que requiera modificación o adaptación para
permitir su funcionamiento en algún país que no sea el país
para el que se diseñó, fabricó, aprobó y/o autorizó o la
reparación de productos dañados por estas modificaciones.
• Un producto que se use para propósitos comerciales o
institucionales (lo que incluye, entre otros, los de alquiler).
• La pérdida del producto en el envío y cuando no se pueda
proporcionar una firma que verifique el recibo.
• No operar según el Manual del propietario.
PARA OBTENER AYUDA…
Comuníquese con el Centro de Atención al Cliente al:
www.sanyo-av.com
1 866 212 0436
LA REPARACIÓN O EL REEMPLAZO, SEGÚN LO DISPONE ESTA
GARANTÍA, ES LA SOLUCIÓN EXCLUSIVA PARA EL CLIENTE. LA
COMPAÑÍANO SERÁ RESPONSABLE DE LOS DAÑOS
INCIDENTALES O INDIRECTOS QUE INFRINJAN ALGUNA
GARANTÍA EXPRESA O IMPLÍCITA SOBRE ESTE PRODUCTO.
CON EXCEPCIÓN DE LO QUE PROHÍBA LA LEY VIGENTE, TODA
GARANTÍA IMPLÍCITA DE COMERCIABILIDAD Y ADECUACIÓN
PARA UN PROPÓSITO PARTICULAR EN ESTE PRODUCTO ESTÁ
LIMITADA EN DURACIÓN A LO QUE ESPECIFIQUE ESTA
GARANTÍA.
Algunos estados no permiten las exclusiones ni la limitación de los
daños incidentales o indirectos, ni permiten limitaciones sobre la
duración de la garantía implícita, de modo que las limitaciones o
exclusiones anteriores pueden no aplicarse a usted.
GARANTÍA LIMITADA
NOVENTA (90) DÍAS EN MANO DE OBRA / UNA (1) AÑO EN PARTES
Esta garantía le otorga derechos legales específicos. Usted puede tener otros derechos que varían entre los diferentes estados y provincias.
FUNAI CORPORATION, Inc. 19900 Van Ness Avenue, Torrance, CA 90501
