USER
MANUAL
EN User Manual
Oven
BPK552220M
CONTENTS
1. SAFETY INFORMATION.............................................................................................2
2. SAFETY INSTRUCTIONS.............................................................................................4
3. PRODUCT DESCRIPTION...........................................................................................7
4. CONTROL PANEL....................................................................................................... 8
5. BEFORE FIRST USE..................................................................................................... 9
6. DAILY USE....................................................................................................................9
7. CLOCK FUNCTIONS.................................................................................................11
8. USING THE ACCESSORIES...................................................................................... 13
9. ADDITIONAL FUNCTIONS...................................................................................... 15
10. HINTS AND TIPS..................................................................................................... 16
11. CARE AND CLEANING.......................................................................................... 34
12. TROUBLESHOOTING.............................................................................................37
13. ENERGY EFFICIENCY.............................................................................................40
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler - features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com/webselfservice
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1.
SAFETY INFORMATION
Before the installation and use of the appliance,
carefully read the supplied instructions. The
www.aeg.com
2
manufacturer is not responsible for any injuries or
damage that are the result of incorrect installation or
usage. Always keep the instructions in a safe and
accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
• Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.
• Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
• Do not let children play with the appliance.
• Keep all packaging away from children and dispose of
it appropriately.
• Keep children and pets away from the appliance when
it operates or when it cools down. Accessible parts
may become hot during use.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2
General Safety
• Only a qualified person must install this appliance and
replace the cable.
• WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to
avoid touching heating elements.
• Always use oven gloves to remove or put in
accessories or ovenware.
ENGLISH
3
• Before carrying out any maintenance, disconnect the
appliance from the power supply.
• WARNING: Ensure that the appliance is switched off
before replacing the lamp to avoid the possibility of
electric shock.
• Do not use the appliance before installing it in the
built-in structure.
• Do not use a steam cleaner to clean the appliance.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can scratch
the surface, which may result in shattering of the glass.
• If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
• Excessive spillage must be removed before the
pyrolytic cleaning. Remove all parts from the oven.
• Use only the food sensor (core temperature sensor)
recommended for this appliance.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not pull the appliance by the
handle.
• Install the appliance in a safe and
suitable place that meets installation
requirements.
• Keep the minimum distance from
other appliances and units.
• Before mounting the appliance, check
if the oven door opens without
restraint.
• The appliance is equipped with an
electric cooling system. It must be
operated with the electric power
supply.
• The built-in unit must meet the
stability requirements of DIN 68930.
Cabinet minimum
height (Cabinet un-
der the worktop mini-
mum height)
600 (600) mm
Cabinet width 550 mm
Cabinet depth 605 (580) mm
Height of the front of
the appliance
594 mm
Height of the back of
the appliance
576 mm
Width of the front of
the appliance
549 mm
www.aeg.com4
Width of the back of
the appliance
548 mm
Depth of the appli-
ance
567 mm
Built in depth of the
appliance
546 mm
Depth with open
door
1017 mm
Ventilation opening
minimum size. Open-
ing placed on the
bottom rear side
550 x 20 mm
Mains supply cable
length. Cable is
placed in the right
corner of the back
side
1500 mm
Mounting screws 4 x 12 mm
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need
to be replaced, this must be carried
out by our Authorised Service Centre.
• Do not let mains cables touch or
come near the appliance door or the
niche below the appliance, especially
when it operates or the door is hot.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have
an isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation
device must have a contact opening
width of minimum 3 mm.
• Fully close the appliance door before
you connect the mains plug to the
mains socket.
• This appliance is supplied with a main
plug and a main cable.
2.3 Use
WARNING!
Risk of injury, burns and
electric shock or explosion.
• This appliance is for household use
only.
• Do not change the specification of
this appliance.
• Make sure that the ventilation
openings are not blocked.
• Do not let the appliance stay
unattended during operation.
• Deactivate the appliance after each
use.
• Be careful when you open the
appliance door while the appliance is
in operation. Hot air can release.
• Do not operate the appliance with
wet hands or when it has contact with
water.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully.
The use of ingredients with alcohol
can cause a mixture of alcohol and air.
ENGLISH
5
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
WARNING!
Risk of damage to the
appliance.
• To prevent damage or discoloration
to the enamel:
– do not put ovenware or other
objects in the appliance directly
on the bottom.
– do not put aluminium foil directly
on the bottom of cavity of the
appliance.
– do not put water directly into the
hot appliance.
– do not keep moist dishes and
food in the appliance after you
finish the cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel or
stainless steel has no effect on the
performance of the appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• This appliance is for cooking
purposes only. It must not be used for
other purposes, for example room
heating.
• Always cook with the oven door
closed.
• If the appliance is installed behind a
furniture panel (e.g. a door) make sure
the door is never closed when the
appliance is in operation. Heat and
moisture can build up behind a
closed furniture panel and cause
subsequent damage to the appliance,
the housing unit or the floor. Do not
close the furniture panel until the
appliance has cooled down
completely after use.
2.4 Care and cleaning
WARNING!
Risk of injury, fire, or damage
to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• Make sure the appliance is cold.
There is the risk that the glass panels
can break.
• Replace immediately the door glass
panels when they are damaged.
Contact the Authorised Service
Centre.
• Be careful when you remove the door
from the appliance. The door is
heavy!
• Clean regularly the appliance to
prevent the deterioration of the
surface material.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal
objects.
• If you use an oven spray, follow the
safety instruction on it's packaging.
• Do not clean the catalytic enamel (if
applicable) with detergents.
2.5 Pyrolytic cleaning
WARNING!
Risk of Injury / Fires /
Chemical Emissions (Fumes)
in Pyrolytic Mode.
Do not start the Pyrolysis if
the Plus Steam button is
pressed in.
• Before carrying out a Pyrolitic self-
cleaning function or the First Use
please remove from the oven cavity:
– any excess food residues, oil or
grease spills / deposits.
– any removable objects (including
shelves, side rails etc., provided
with the product) particularly any
non-stick pots, pans, trays,
utensils etc.
• Read carefully all the instructions for
Pyrolytic cleaning.
• Keep children away from the
appliance while the Pyrolytic cleaning
operates.
The appliance becomes very hot and
hot air is released from the front
cooling vents.
• Pyrolytic cleaning is a high
temperature operation that can
www.aeg.com
6
release fumes from cooking residues
and construction materials, as such
consumers are strongly advised to:
– provide good ventilation during
and after each Pyrolytic cleaning.
– provide good ventilation during
and after the first use at maximum
temperature operation.
• Unlike all humans, some birds and
reptiles can be extremely sensitive to
potential fumes emitted during the
cleaning process of all Pyrolytic
Ovens.
– Remove any pets (especially birds)
from the vicinity of the appliance
location during and after the
Pyrolytic cleaning and first use
maximum temperature operation
to a well ventilated area.
• Small pets can also be highly sensitive
to the localized temperature changes
in the vicinity of all Pyrolytic Ovens
when the Pyrolytic self cleaning
program is in operation.
• Non-stick surfaces on pots, pans,
trays, utensils etc., can be damaged
by the high temperature Pyrolytic
cleaning operation of all Pyrolytic
Ovens and can be also a source for
low level harmful fumes.
• Fumes released from all Pyrolytic
Ovens / Cooking Residues as
described are not harmful to humans,
including children, or persons with
medical conditions.
2.6 Internal lighting
WARNING!
Risk of electric shock.
• The type of light bulb or halogen
lamp used for this appliance is for
household appliances only. Do not
use it for house lighting.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Use only lamps with the same
specifications.
2.7 Service
• To repair the appliance contact the
Authorised Service Centre.
• Use original spare parts only.
2.8 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the appliance.
3.
PRODUCT DESCRIPTION
3.1 General overview
1
2
3
4
5
2 3 5 641
7
13
8
11
9
10
12
1
Control panel
2
Knob for the heating functions
3
Power lamp / symbol
4
Display
5
Control knob (for the temperature)
6
Temperature indicator / symbol
7
Plus Steam
8
Heating element
9
Lamp
10
Fan
11
Shelf support, removable
ENGLISH
7
12
Cavity embossment
13
Shelf positions
3.2 Accessories
Wire shelf
For cookware, cake tins, roasts.
Baking tray
For cakes and biscuits.
Grill- / Roasting pan
To bake and roast or as a pan to collect
fat.
Food Sensor
To measure the temperature inside food.
4. CONTROL PANEL
4.1 Buttons
Sensor field / Button Function Description
CLOCK To set a clock function.
MINUS To set the time.
MINUTE MIND-
ER
To set the MINUTE MINDER. Hold the
button for more than 3 seconds to acti-
vate or deactivate the oven lamp.
PLUS To set the time.
TEMPERATURE To check the oven temperature or the
temperature of the core temperature sen-
sor (if applicable). Use only while an oven
function is in operation.
PLUS STEAM To turn on the True Fan Cooking PLUS
function.
www.aeg.com8
4.2 Display
A B
DG EF C
A. Timer / Temperature
B. Heat-up and residual heat indicator
C. Core temperature sensor (selected
models only)
D. Door lock (selected models only)
E. Hours / minutes
F. Demo mode (selected models only)
G. Clock functions
5. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
To set the Time of day refer
to "Clock functions"
chapter.
5.1 Initial Cleaning
Remove all accessories and removable
shelf supports from the oven.
Refer to "Care and cleaning" chapter.
Clean the oven and the accessories
before the first use.
Put the accessories and the removable
shelf supports back to their initial
position.
6. DAILY USE
WARNING!
Refer to Safety chapters.
6.1 Retractable knobs
To use the appliance press the knob. The
knob comes out.
6.2 Heating functions
Oven function Application
Off position
The oven is off.
Oven function Application
True Fan
Cooking /
True Fan
Cooking PLUS
To bake on up to three
shelf positions at the
same time and to dry
food.
Set the temperature 20 -
40 °C lower than for Con-
ventional Cooking.
To add humidity during
the cooking. To get the
right colour and crispy
crust during baking. To
give more juiciness dur-
ing reheating.
Pizza Function
To bake pizza. To make
intensive browning and a
crispy bottom.
ENGLISH 9
Oven function Application
Conventional
Cooking
To bake and roast food
on one shelf position.
Bottom Heat
To bake cakes with crispy
bottom and to preserve
food.
Defrost
To defrost food (vegeta-
bles and fruit). The de-
frosting time depends on
the amount and size of
the frozen food.
Moist Fan Bak-
ing
This function is designed
to save energy during
cooking. For the cooking
instructions refer to
"Hints and tips" chapter,
Moist Fan Baking. The
oven door should be
closed during cooking so
that the function is not in-
terrupted and to ensure
that the oven operates
with the highest energy
efficiency possible. When
you use this function, the
temperature in the cavity
may differ from the set
temperature. The residu-
al heat is used. The heat-
ing power may be re-
duced. For general ener-
gy saving recommenda-
tions refer to "Energy Ef-
ficiency" chapter, Energy
Saving. This function was
used to comply with the
energy efficiency class
according to EN 60350-1.
When you use this func-
tion the lamp automati-
cally turns off after 30
seconds.
Grill
To grill flat food and to
toast bread.
Oven function Application
Turbo Grilling
To roast larger meat
joints or poultry with
bones on one shelf posi-
tion. To make gratins and
to brown.
Pyrolysis
To turn on the pyrolytic
cleaning of the oven. This
function burns off residu-
al dirt in the oven.
The lamp may turn off
automatically at a
temperature below 60 °C
during some oven functions.
6.3 Setting a heating function
1. Turn the knob for the heating
functions to select a heating function.
2. Turn the control knob to select the
temperature.
The lamp turns on when the oven
operates.
3. To turn off the oven, turn the knob
for the heating functions to the off
position.
6.4 Setting the function: True
Fan Cooking PLUS
This function increases humidity during
cooking.
WARNING!
Risk of burns and damage to
the appliance.
Released humidity can cause burns. After
the function stops, carefully open the
door.
1. Fill the cavity embossment with tap
water.
The maximum capacity of the cavity
embossment is 250 ml.
www.aeg.com
10
Fill the cavity embossment with water
only when the oven is cold.
CAUTION!
Do not refill the cavity
embossment during
cooking or when the
oven is hot.
2. Set the function: .
3. Press: Plus Steam
.
It works only with the function: True Fan
Cooking PLUS.
The indicator turns on.
4. Turn the control knob to set
temperature.
5. Preheat the empty oven for 10
minutes to create humidity.
6. Put food in the oven.
Refer to "Hints and tips" chapter.
Do not open the oven door during
cooking.
7. Turn the knob for the heating
functions to the off position, press
Plus Steam
to turn off the oven.
The indicator turns off.
8. Remove water from the cavity
embossment.
WARNING!
Make sure that the oven
is cold before you
remove the remaining
water from the cavity
embossment.
6.5 Heat-up indicator
When the oven function operates, the
bars in the display
appear one by one
when the temperature in the oven
increases, and disappear when it
decreases.
7. CLOCK FUNCTIONS
7.1 Clock functions table
Clock func-
tion
Application
TIME OF DAY
To show or change the
time of day. You can
change the time of day
only when the oven is off.
DURATION
To set how long the oven
works. Use only when a
heating function is set.
END
To set when the oven
turns off. Use only when a
heating function is set.
TIME DELAY
Combination of DURA-
TION and END function.
MINUTE
MINDER
Use to set a countdown
time. This function has no
effect on the operation of
the oven. You can set the
MINUTE MINDER at any
time, also if the oven is
off.
Clock func-
tion
Application
00:00
COUNT UP
TIMER
If you do not set any oth-
er clock function the
COUNT UP TIMER auto-
matically monitor how
long the oven works.
It is on immediately when
the oven starts to heat.
The Count Up Timer can-
not be used with the
functions: DURATION,
END, core temperature
sensor.
7.2 Setting and changing the
time
After the first connection to the mains,
wait until the display shows and
"12:00". "12" flashes.
1. Press or to set the hours.
2. Press to confirm and set the
minutes.
The display shows
and the set
hour. "00" flashes.
ENGLISH
11
3. Press or to set the current
minutes.
4. Press to confirm or the set time of
day will be saved automatically after
5 seconds.
The display shows the new time.
To change the time of day press
again and again until the indicator for the
time of day flashes in the display.
7.3 Setting the DURATION
function
1. Set a heating function.
2. Press
again and again until
starts to flash.
3. Press or to set the minutes and
then the hours. Press
to confirm.
When the set Duration time ends the
signal sounds for 2 minutes. and time
setting flash in the display. The oven
turns off automatically.
4. Press any button or open the oven
door to stop the signal.
5. Turn the knob for the heating
functions to the off position.
7.4 Setting the END function
1. Set a heating function.
2. Press
again and again until
starts to flash.
3. Press or to set the hours and
then the minutes. Press
to
confirm.
At the set End time the signal sounds for
2 minutes. and time setting flash in
the display. The oven turns off
automatically.
4. Press any button or open the oven
door to stop the signal.
5. Turn the knob for the heating
functions to the off position.
7.5 Setting the TIME DELAY
function
1. Set a heating function.
2. Press again and again until
starts to flash.
3. Press or to set the minutes and
then the hours for DURATION time.
Press to confirm.
The display shows flashing .
4. Press or to set the hours and
then the minutes for END time. Press
to confirm. The display shows
and the set temperature.
Oven turns on automatically later on,
works for the set DURATION time and
stops at the set END time.
At the set END time the signal sounds
for 2 minutes. and time setting flash
in the display. The oven turns off.
5. Press any button or open the oven
door to stop the signal.
6. Turn the knob for the heating
functions to the off position.
7.6 Setting the MINUTE
MINDER
Minute minder can be both set when the
oven is turned on and off.
1. Press again and again until and
"00" flash in the display.
2. Press
or to set the seconds
and than the minutes.
When the time you set is longer than
60 minutes, flash in the display.
3. Set the hours.
4. The MINUTE MINDER starts
automatically after 5 seconds.
After 90% of the set time the signal
sounds.
5. When the set time ends the signal
sounds for 2 minutes. "00:00" and
flash in the display. Press any
button to stop the signal.
7.7 COUNT UP TIMER
To reset the Count Up Timer, press and
hold
and . The timer starts to count
up again.
www.aeg.com
12
8. USING THE ACCESSORIES
WARNING!
Refer to Safety chapters.
8.1 Core temperature sensor
The core temperature sensor measures
temperature inside the food. When the
food is at the set temperature, the oven
turns off.
There are two temperatures to be set:
• the oven temperature (minimum 120
°C),
• the food core temperature.
CAUTION!
Use only the core
temperature sensor supplied
and the original replacement
parts.
Directions for the best results:
• Ingredients should be at room
temperature.
• Core temperature sensor cannot be
used for liquid dishes.
• During cooking the core temperature
sensor must remain in the dish and
the plug in the socket.
• Use recommended food core
temperature settings. Refer to "Hints
and tips" chapter.
Every time you put the core
temperature sensor in the
socket, you need to set the
core temperature time
again. You cannot select the
duration and end time.
The aoven calculates the
approximate cooking time, it
may change.
Food categories: meat, poultry
and fish
1. Set the oven function and
temperature.
2. Insert the tip of the core temperature
sensor into the centre of meat or fish,
in the thickest part if possible. Make
sure that at least 3/4 of the core
temperature sensor is inside of the
dish.
3. Put the plug of the core temperature
sensor into the socket located in the
front frame of the appliance.
The display shows the core temperature
sensor symbol.
When you use the core temperature
sensor for the first time, the default core
temperature is 60 °C.
While flashes, you can use the knob
for the temperature to change the
default core temperature. The display
shows the symbol of the core
temperature sensor and the default core
temperature.
4. Press
to save the new core
temperature, or wait 10 seconds for
the setting to be saved automatically.
The new default core temperature is
displayed during the next use of the core
temperature sensor.
When the food is at the set core
temperature, the default core
temperature and flashes. An acoustic
signal sounds for 2 minutes.
ENGLISH
13
5. Press any button or open the oven
door to stop the acoustic signal.
6. Remove the core temperature sensor
plug from the socket and remove the
dish from the appliance.
WARNING!
There is a risk of burns as the
core temperature sensor
becomes hot. Be careful
when you unplug it and
remove it from the dish.
Food category: casserole
1.
Set the oven function and
temperature.
2. Place half of the ingredients in a
baking dish.
3. Insert the tip of the core temperature
sensor exactly in the centre of the
casserole.The core temperature
sensor should be stabilized in one
place during baking. Use a solid
ingredient to achieve that. Use the
rim of the baking dish to support the
silicone handle of the core
temperature sensor. The tip of the
core temperature sensor should not
touch the bottom of a baking dish.
4. Cover the core temperature sensor
with the remaining ingredients.
5. Put the plug of the core temperature
sensor into the socket located in the
front frame of the appliance.
The display shows the core temperature
sensor symbol.
6. Press
to save the new core
temperature, or wait 10 seconds for
the setting to be saved automatically.
The new default core temperature is
displayed during the next use of the core
temperature sensor.
When the food is at the set core
temperature, the default core
temperature and flashes. An acoustic
signal sounds for 2 minutes.
7. Press any button or open the oven
door to stop the acoustic signal.
8. Remove the core temperature sensor
plug from the socket and remove the
dish from the appliance.
WARNING!
There is a risk of burns as the
core temperature sensor
becomes hot. Be careful
when you unplug it and
remove it from the dish.
Changing the temperature
during the cooking
You can change the temperature at any
time during the cooking:
1. Press :
• one time - the display shows the
set core temperature which
changes every 10 seconds to the
current core temperature.
• two times - the display shows the
current oven temperature which
changes every 10 seconds to the
set oven temperature.
• three times - the display shows
the set oven temperature.
www.aeg.com
14
2. Use the knob for the temperature to
change the temperature.
8.2 Inserting the accessories
Wire shelf:
Push the shelf between the guide bars of
the shelf support .
Baking tray/ Deep pan:
Push the baking tray / deep pan between
the guide bars of the shelf support.
9. ADDITIONAL FUNCTIONS
9.1 Using the Child Lock
When the Child Lock is on the oven
cannot be turned on accidentally.
1. Ensure the knob for the oven
functions is in the off position.
2. Press and hold and at the
same time for 2 seconds.
The signal sounds. SAFE and appear
on the display. The door is locked.
The symbol appear on
the display also when
Pyrolysis function operates.
To turn off the Child Lock, repeat step 2.
9.2 Using the Function Lock
You can turn on the Function Lock
function only when the oven operates.
When the Function lock is on the
temperature and time settings of a
running oven function cannot be
changed accidentally.
1. Select an oven function and set it
according your preferences.
2. Press and hold
and at the
same time for 2 seconds.
The signal sounds. Loc appears on the
display for 5 seconds.
Loc appears on the display
when you turn the knob for
the temperature or press any
button when the Function
lock is on.
When you turn the knob for the oven
functions, the oven stops.
When you turn off the oven while the
Function Lock is on, the Function Lock
switches automatically to the Child Lock.
Refer to "Using the Child Lock".
If the Pyrolysis function
operates, the door is locked
and appears on the
display.
To turn off the Function Lock, repeat
step 2.
9.3 Residual heat indicator
When you turn off the oven, the display
shows the residual heat indicator
if
the temperature in the oven is more than
40 °C.
ENGLISH
15
9.4 Automatic Switch-Off
For safety reasons the oven turns off
automatically after some time, if a
heating function works and you do not
change any settings.
(°C) (h)
30 - 115 12.5
120 - 195 8.5
200 - 245 5.5
(°C) (h)
250 - maximum 3
The Automatic Switch-off does not work
with the functions: Light, Food Sensor,
Duration, End Time.
9.5 Cooling fan
When the oven operates, the cooling fan
turns on automatically to keep the
surfaces of the oven cool. If you turn off
the oven, the cooling fan can continue to
operate until the oven cools down.
10. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
The temperature and baking
times in the tables are
guidelines only. They
depend on the recipes and
the quality and quantity of
the ingredients used.
10.1 Cooking
recommendations
Your oven may bake or roast differently
to the oven you had before. The tables
below show recommended settings for
temperature, cooking time and shelf
position for specific types of the food.
If you cannot find the settings for a
special recipe, look for the similar one.
10.2 Inner side of the door
On the inner side of the door you can
find:
• the numbers of the shelf positions.
• information about the oven functions,
recommended shelf positions and
temperatures for dishes.
10.3 True Fan Cooking PLUS
Use the second shelf position.
Use 150 ml of water.
Use a baking tray.
CAKES / PASTRIES / BREADS
(°C) (min)
Cookies /
Scones / Crois-
sants
150 - 180 10 - 20
Focaccia 200 - 210 10 - 20
Pizza 230 10 - 20
Bread rolls 200 20 - 25
Bread 180 35 - 40
Plum cake / Ap-
ple pie / Cinna-
mon rolls, baked
in a cake mould
160 - 180 30 - 60
Use 200 ml of water.
www.aeg.com
16
FROZEN READY MEALS
(°C) (min)
Pizza 200 - 210 10 - 20
Croissants 170 - 180 15 - 25
Lasagne 180 - 200 35 - 50
Use 100 ml of water.
Set the temperature to 110 °C.
FOOD REGENERATION
(min)
Bread rolls 10 - 20
Bread 15 - 25
Focaccia 15 - 25
Meat 15 - 25
Pasta 15 - 25
Pizza 15 - 25
Rice 15 - 25
FOOD REGENERATION
(min)
Vegetables 15 - 25
Use 200 ml of water.
Use a glass baking dish.
ROASTING
(°C) (min)
Roast beef 200 50 - 60
Chicken 210 60 - 80
Roast pork 180 65 - 80
10.4 Baking
Use the lower temperature the first time.
You can extend baking times by 10 – 15
minutes if you bake cakes on more than
one shelf position.
Cakes and pastries at different heights
do not always brown equally. There is no
need to change the temperature setting
if an unequal browning occurs. The
differences equalize during baking.
Trays in the oven can twist during baking.
When the trays become cold again, the
distortions disappear.
10.5 Tips on baking
Baking results Possible cause Remedy
The bottom of the cake
is not baked sufficiently.
The shelf position is incor-
rect.
Put the cake on a lower shelf.
ENGLISH 17
Baking results Possible cause Remedy
The cake sinks and be-
comes soggy or streaky.
The oven temperature is
too high.
Next time set slightly lower oven
temperature.
The baking time is too
short.
Next time set a longer baking
time and lower oven temperature.
The cake is too dry. The oven temperature is
too low.
Next time set higher oven tem-
perature.
The baking time is too long. Next time set shorter baking time.
The cake bakes uneven-
ly.
The oven temperature is
too high and the baking
time is too short.
Set lower oven temperature and
longer baking time.
The cake batter is not even-
ly distributed.
Next time spread the cake batter
evenly on the baking tray.
The cake is not ready in
the baking time speci-
fied in a recipe.
The oven temperature is
too low.
Next time set a slightly higher
oven temperature.
10.6 Baking on one shelf level
BAKING IN TINS
(°C)
(min)
Flan base -
short pastry,
preheat the
empty oven
True Fan Cooking 170 - 180 10 - 25 2
Flan base -
sponge cake
mixture
True Fan Cooking 150 - 170 20 - 25 2
Ring cake /
Brioche
True Fan Cooking 150 - 160 50 - 70 1
Madeira cake /
Fruit cakes
True Fan Cooking 140 - 160 70 - 90 1
Cheesecake Conventional Cooking 170 - 190 60 - 90 1
www.aeg.com18
CAKES / PASTRIES / BREADS
Use the third shelf position.
Use the function: True Fan Cook-
ing.
Use a baking tray.
(°C) (min)
Cake with crumble
topping
150 - 160 20 - 40
Fruit flans (made of
yeast dough /
sponge cake mix-
ture), use a deep
pan
150 35 - 55
CAKES / PASTRIES / BREADS
Use the third shelf position.
Use the function: True Fan Cook-
ing.
Use a baking tray.
(°C) (min)
Fruit flans made of
short pastry
160 - 170 40 - 80
CAKES / PASTRIES / BREADS
Preheat the empty oven.
Use the function: Conventional Cooking.
Use a baking tray.
(°C) (min)
Swiss roll 180 - 200 10 - 20 3
Rye bread: first: 230 20 1
then: 160 - 180 30 - 60
Buttered almond
cake / Sugar cakes
190 - 210 20 - 30 3
ENGLISH 19
CAKES / PASTRIES / BREADS
Preheat the empty oven.
Use the function: Conventional Cooking.
Use a baking tray.
(°C) (min)
Cream puffs / Eclairs 190 - 210 20 - 35 3
Plaited bread /
Bread crown
170 - 190 30 - 40 3
Fruit flans (made of
yeast dough /
sponge cake mix-
ture), use a deep pan
170 35 - 55 3
Yeast cakes with deli-
cate toppings (e.g.
quark, cream, cus-
tard)
160 - 180 40 - 80 3
Christstollen 160 - 180 50 - 70 2
BISCUITS
Use the third shelf position.
(°C) (min)
Short pastry biscuits True Fan Cooking 150 - 160 10 - 20
Rolls, preheat the empty
oven
True Fan Cooking 160 10 - 25
Biscuits made of sponge
cake mixture
True Fan Cooking 150 - 160 15 - 20
Puff pastries, preheat
the empty oven
True Fan Cooking 170 - 180 20 - 30
www.aeg.com20
BISCUITS
Use the third shelf position.
(°C) (min)
Biscuits made of yeast
dough
True Fan Cooking 150 - 160 20 - 40
Macaroons True Fan Cooking 100 - 120 30 - 50
Pastries made of egg
white / Meringues
True Fan Cooking 80 - 100 120 - 150
Rolls, preheat the empty
oven
Conventional
Cooking
190 - 210 10 - 25
10.7 Bakes and gratins
Use the first shelf position.
(°C) (min)
Baguettes topped with
melted cheese
True Fan Cooking 160 - 170 15 - 30
Vegetables au gratin,
preheat the empty
oven
Turbo Grilling 160 - 170 15 - 30
Lasagne Conventional Cooking 180 - 200 25 - 40
Fish bakes Conventional Cooking 180 - 200 30 - 60
Stuffed vegetables True Fan Cooking 160 - 170 30 - 60
Sweet bakes Conventional Cooking 180 - 200 40 - 60
Pasta bake Conventional Cooking 180 - 200 45 - 60
10.8 Multilevel Baking
Use the function: True Fan Cooking.
Use the baking trays.
ENGLISH 21
CAKES / PASTRIES
(°C)
(min)
2 positions
Cream puffs / Eclairs,
preheat the empty
oven
160 - 180 25 - 45 1 / 4
Dry streusel cake 150 - 160 30 - 45 1 / 4
BISCUITS / SMALL CAKES / PASTRIES / ROLLS
(°C)
(min)
2 positions 3 positions
Rolls 180 20 - 30 1 / 4 -
Short pastry bis-
cuits
150 - 160 20 - 40 1 / 4 1 / 3 / 5
Biscuits made of
sponge cake
mixture
160 - 170 25 - 40 1 / 4 -
Puff pastries,
preheat the
empty oven
170 - 180 30 - 50 1 / 4 -
Biscuits made of
yeast dough
160 - 170 30 - 60 1 / 4 -
Macaroons 100 - 120 40 - 80 1 / 4 -
Biscuits made of
egg white / Mer-
ingues
80 - 100 130 - 170 1 / 4 -
10.9 Tips on Roasting
Use heat-resistant ovenware.
Roast lean meat covered.
Roast large meat joints directly in the tray
or on the wire shelf placed above the
tray.
Put some water in the tray to prevent
dripping fat from burning.
Turn the roast after 1/2 - 2/3 of the
cooking time.
Roast meat and fish in large pieces (1 kg
or more).
Baste meat joints with their own juice
several times during roasting.
10.10 Roasting
Use the first shelf position.
www.aeg.com22
BEEF
(°C) (min)
Pot roast 1 - 1.5 kg Conventional
Cooking
230 120 - 150
Roast beef or fillet,
rare, preheat the
empty oven
per cm of thick-
ness
Turbo Grilling 190 - 200 5 - 6
Roast beef or fillet,
medium, preheat
the empty oven
per cm of thick-
ness
Turbo Grilling 180 - 190 6 - 8
Roast beef or fillet,
well done, preheat
the empty oven
per cm of thick-
ness
Turbo Grilling 170 - 180 8 - 10
PORK
Use the function: Turbo Grilling.
(kg)
(°C) (min)
Shoulder / Neck / Ham
joint
1 - 1.5 160 - 180 90 - 120
Chops / Spare rib 1 - 1.5 170 - 180 60 - 90
Meatloaf 0.75 - 1 160 - 170 50 - 60
Pork knuckle, precooked 0.75 - 1 150 - 170 90 - 120
VEAL
Use the function: Turbo Grilling.
(kg)
(°C) (min)
Roast veal 1 160 - 180 90 - 120
ENGLISH 23
VEAL
Use the function: Turbo Grilling.
(kg)
(°C) (min)
Veal knuckle 1.5 - 2 160 - 180 120 - 150
LAMB
Use the function: Turbo Grilling.
(kg)
(°C) (min)
Lamb leg / Roast
lamb
1 - 1.5 150 - 170 100 - 120
Lamb saddle 1 - 1.5 160 - 180 40 - 60
GAME
Use the function: Conventional Cooking.
(kg)
(°C) (min)
Saddle / Hare leg,
preheat the empty
oven
up to 1 230 30 - 40
Venison saddle 1.5 - 2 210 - 220 35 - 40
Haunch of venison 1.5 - 2 180 - 200 60 - 90
www.aeg.com24
POULTRY
Use the function: Turbo Grilling.
(kg)
(°C) (min)
Poultry, portions 0.2 - 0.25 each 200 - 220 30 - 50
Chicken, half 0.4 - 0.5 each 190 - 210 35 - 50
Chicken, poulard 1 - 1.5 190 - 210 50 - 70
Duck 1.5 - 2 180 - 200 80 - 100
Goose 3.5 - 5 160 - 180 120 - 180
Turkey 2.5 - 3.5 160 - 180 120 - 150
Turkey 4 - 6 140 - 160 150 - 240
FISH (STEAMED)
Use the function: Conventional Cooking.
(kg)
(°C) (min)
Whole fish 1 - 1.5 210 - 220 40 - 60
10.11 Crispy baking with:
Pizza Function
PIZZA
Use the first shelf position.
(°C) (min)
Tarts 180 - 200 40 - 55
Spinach flan 160 - 180 45 - 60
PIZZA
Use the first shelf position.
(°C) (min)
Quiche lor-
raine / Swiss
flan
170 - 190 45 - 55
Cheesecake 140 - 160 60 - 90
ENGLISH 25
PIZZA
Use the first shelf position.
(°C) (min)
Vegetable
pie
160 - 180 50 - 60
PIZZA
Preheat the empty oven before
cooking.
Use the second shelf position.
(°C) (min)
Pizza, thin
crust, use a
deep pan
200 - 230 15 - 20
Pizza, thick
crust
180 - 200 20 - 30
PIZZA
Preheat the empty oven before
cooking.
Use the second shelf position.
(°C) (min)
Unleavened
bread
230 - 250 10 - 20
Puff pastry
flan
160 - 180 45 - 55
Flammku-
chen
230 - 250 12 - 20
Pierogi 180 - 200 15 - 25
10.12 Grill
Preheat the empty oven before cooking.
Grill only thin pieces of meat or fish.
Put a pan on the first shelf position to
collect fat.
GRILL
Use the function: Grill
(°C) (min)
1st side
(min)
2nd side
Roast beef 210 - 230 30 - 40 30 - 40 2
Beef fillet 230 20 - 30 20 - 30 3
Pork loin 210 - 230 30 - 40 30 - 40 2
www.aeg.com26
GRILL
Use the function: Grill
(°C) (min)
1st side
(min)
2nd side
Veal loin 210 - 230 30 - 40 30 - 40 2
Lamb saddle 210 - 230 25 - 35 20 - 25 3
Whole fish, 0.5
kg - 1 kg
210 - 230 15 - 30 15 - 30 3 / 4
10.13 Frozen Foods
DEFROSTING
Use the function: True Fan Cooking.
(°C) (min)
Pizza, frozen 200 - 220 15 - 25 2
Pizza American, frozen 190 - 210 20 - 25 2
Pizza, chilled 210 - 230 13 - 25 2
Pizza snacks, frozen 180 - 200 15 - 30 2
French fries, thin 200 - 220 20 - 30 3
French fries, thick 200 - 220 25 - 35 3
Wedges / Croquettes 220 - 230 20 - 35 3
Hash browns 210 - 230 20 - 30 3
Lasagne / Cannelloni,
fresh
170 - 190 35 - 45 2
Lasagne / Cannelloni, fro-
zen
160 - 180 40 - 60 2
Baked cheese 170 - 190 20 - 30 3
Chicken wings 190 - 210 20 - 30 2
ENGLISH 27
10.14 Defrost
Remove the food packaging and put the
food on a plate.
Do not cover the food, as this can extend
the defrost time.
For large portions of food place an
upturned empty plate on the bottom of
the oven cavity. Put the food in a deep
dish and set it on top of the plate inside
the oven.
Use the first shelf position.
(kg)
(min)
Defrosting time
(min)
Further defrost-
ing time
Chicken 1 100 - 140 20 - 30 Turn halfway
through.
Meat, turn half-
way through
1 100 - 140 20 - 30 Turn halfway
through.
Trout 0.15 25 - 35 10 - 15 -
Strawberries 0.3 30 - 40 10 - 20 -
Butter 0.25 30 - 40 10 - 15 -
Cream, whip the
cream when still
slightly frozen in
places
2 x 0.2 80 - 100 10 - 15 Whip the cream
when still slightly
frozen in places.
Gateau 1.4 60 60 -
10.15 Preserving
Use only preserve jars of the same
dimensions available on the market.
Do not use jars with twist-off and
bayonet type lids or metal tins.
Use the first shelf position.
Put no more than six one-litre preserve
jars on the baking tray.
Fill the jars equally and close with a
clamp.
The jars cannot touch each other.
Put approximately 1/2 litre of water into
the baking tray to give sufficient moisture
in the oven.
When the liquid in the jars starts to
simmer (after approximately 35 - 60
minutes with one-litre jars), stop the oven
or decrease the temperature to 100 °C
(see the table).
Set the temperature to 160 - 170 °C.
SOFT FRUIT
(min)
Cooking time un-
til simmering
Strawberries / Blue-
berries / Raspber-
ries / Ripe gooseber-
ries
35 - 45
www.aeg.com28
STONE FRUIT
(min)
Cooking
time until
simmering
(min)
Continue
to cook at
100 °C
Peaches /
Quinces /
Plums
35 - 45 10 - 15
VEGETABLES
(min)
Cooking
time until
simmering
(min)
Continue to
cook at 100
°C
Carrots 50 - 60 5 - 10
Cucumbers 50 - 60 -
Mixed pickles 50 - 60 5 - 10
Kohlrabi /
Peas / Aspar-
agus
50 - 60 15 - 20
10.16 Dehydrating - True Fan
Cooking
Cover trays with grease proof paper or
baking parchment.
For a better result, stop the oven halfway
through the drying time, open the door
and let it cool down for one night to
complete the drying.
For 1 tray use the third shelf position.
For 2 trays use the first and fourth shelf
position.
VEGETABLES
(°C) (h)
Beans 60 - 70 6 - 8
Peppers 60 - 70 5 - 6
Vegetables for soup 60 - 70 5 - 6
Mushrooms 50 - 60 6 - 8
Herbs 40 - 50 2 - 3
Set the temperature to 60 - 70 °C.
FRUIT
(h)
Plums 8 - 10
Apricots 8 - 10
Apple slices 6 - 8
Pears 6 - 9
10.17 Food Sensor
BEEF Food core temperature (°C)
Rare Medium Well done
Roast beef 45 60 70
Sirloin 45 60 70
ENGLISH 29
BEEF Food core temperature (°C)
Less Medium More
Meatloaf 80 83 86
PORK Food core temperature (°C)
Less Medium More
Ham / Roast 80 84 88
Saddle chop / Pork loin, smoked /
Pork loin, poached
75 78 82
VEAL Food core temperature (°C)
Less Medium More
Roast veal 75 80 85
Veal knuckle 85 88 90
MUTTON / LAMB Food core temperature (°C)
Less Medium More
Mutton leg 80 85 88
Mutton saddle 75 80 85
Roast lamb / Lamb leg 65 70 75
GAME Food core temperature (°C)
Less Medium More
Hare saddle / Venison saddle 65 70 75
Hare leg / Hare, whole / Venison
leg
70 75 80
www.aeg.com30
POULTRY Food core temperature (°C)
Less Medium More
Chicken 80 83 86
Duck, whole / half / Turkey, whole /
breast
75 80 85
Duck, breast 60 65 70
FISH (SALMON, TROUT,
ZANDER)
Food core temperature (°C)
Less Medium More
Fish, whole / large / steamed /
Fish, whole / large / roasted
60 64 68
CASSEROLES - PRE-
COOKED VEGETABLES
Food core temperature (°C)
Less Medium More
Zucchini casserole / Broccoli cas-
serole / Fennel casserole
85 88 91
CASSEROLES - SAVOURY Food core temperature (°C)
Less Medium More
Cannelloni / Lasagne / Pasta bake 85 88 91
CASSEROLES - SWEET Food core temperature (°C)
Less Medium More
White bread casserole with / with-
out fruit / Rice porridge casserole
with / without fruit / Sweet noodle
casserole
80 85 90
10.18 Moist Fan Baking -
recommended accessories
Use the dark and non-reflective tins and
containers. They have better heat
absorption than the light colour and
reflective dishes.
ENGLISH 31
Pizza pan
Baking dish
Ramekins
Flan base tin
Dark, non-reflective
28 cm diameter
Dark, non-reflective
26 cm diameter
Ceramic
8 cm diameter,
5 cm height
Dark, non-reflective
28 cm diameter
10.19 Moist Fan Baking
For the best results follow suggestions
listed in the table below.
Use the third shelf position.
(°C) (min)
Pasta gratin 200 - 220 45 - 55
Potato gratin 180 - 200 70 - 85
Moussaka 170 - 190 70 - 95
Lasagne 180 - 200 75 - 90
Cannelloni 180 - 200 70 - 85
Bread pudding 190 - 200 55 - 70
Rice pudding 170 - 190 45 - 60
Apple cake, made of sponge cake mixture
(round cake tin)
160 - 170 70 - 80
White bread 190 - 200 55 - 70
10.20 Information for test
institutes
Tests according to: EN 60350, IEC 60350.
www.aeg.com32
BAKING ON ONE LEVEL. Baking in tins
(°C) (min)
Fatless sponge cake True Fan Cooking 140 - 150 35 - 50 2
Fatless sponge cake Conventional Cook-
ing
160 35 - 50 2
Apple pie, 2 tins Ø20
cm
True Fan Cooking 160 60 - 90 2
Apple pie, 2 tins Ø20
cm
Conventional Cook-
ing
180 70 - 90 1
BAKING ON ONE LEVEL. Biscuits
Use the third shelf position.
(°C) (min)
Short bread / Pastry strips True Fan Cooking 140 25 - 40
Short bread / Pastry strips,
preheat the empty oven
Conventional Cooking 160 20 - 30
Small cakes, 20 per tray,
preheat the empty oven
True Fan Cooking 150 20 - 35
Small cakes, 20 per tray,
preheat the empty oven
Conventional Cooking 170 20 - 30
MULTILEVEL BAKING. Biscuits
(°C) (min)
2 posi-
tions
3 posi-
tions
Short bread / Pastry
strips
True Fan Cooking 140 25 - 45 1 / 4 1 / 3 / 5
ENGLISH 33
MULTILEVEL BAKING. Biscuits
(°C) (min)
2 posi-
tions
3 posi-
tions
Small cakes, 20 per
tray, preheat the
empty oven
True Fan Cooking 150 23 - 40 1 / 4 -
GRILL
Preheat the empty oven for 5 minutes.
Grill with the maximum temperature setting.
(min)
Toast Grill 1 - 3 5
Beef steak, turn halfway
through
Grill 24 - 30 4
11. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
11.1 Notes on cleaning
Cleaning
Agents
Clean the front of the oven with a soft cloth with warm water and a mild
cleaning agent.
To clean metal surfaces, use a dedicated cleaning agent.
Clean stubborn stains with a special oven cleaner.
www.aeg.com34
Everyday Use
Clean the oven cavity after each use. Fat accumulation or other food re-
mains may cause fire. The risk is higher for the grill pan.
Dry the cavity with a soft cloth after each use.
Accessories
Clean all accessories after each use and let them dry. Use a soft cloth with
warm water and a cleaning agent. Do not clean the accessories in a dish-
washer.
Do not clean the non-stick accessories using aggressive agents, sharp-
edged objects or in a dishwasher.
11.2 Cleaning the cavity
embossment
The cleaning procedure removes
limestone residue from the cavity
embossment after cooking with steam.
For the function: True Fan
Cooking PLUS we
recommend to do the
cleaning procedure at least
every 5 - 10 cooking cycles.
1. Put 250 ml of white vinegar into the
cavity embossment at the bottom of
the oven.
Use maximum 6% vinegar without
any additives.
2. Let the vinegar dissolve the residual
limestone at the ambient
temperature for 30 minutes.
3. Clean the cavity with warm water and
a soft cloth.
11.3 Pyrolysis
CAUTION!
Do not start the Pyrolysis if
the Plus Steam button is
pressed in.
CAUTION!
Remove all accessories and
removable shelf supports.
Do not start the Pyrolysis if
you did not fully close the
oven door. In some models,
the display shows "C3"
when this error occurs.
WARNING!
The oven becomes very hot.
There is a risk of burns.
CAUTION!
If there are other appliances
installed in the same
cabinet, do not use them
when the Pyrolysis function
operates. It can cause
damage to the appliance.
1. Wipe out the cavity with a wet, soft
cloth.
2. Clean the inner side of the door with
hot water, so that the residues do not
burn from the hot air.
3. Set the Pyrolysis function. Refer to
"Daily use" chapter, "Oven
Functions".
4. When
flashes, press or to
set the pyrolysis duration:
Option Description
P1 Light clean-
ing. Duration:
1 h 30 min.
P2 Normal clean-
ing. Duration:
3 h.
After 2 seconds the pyrolysis starts.
You can use the END function to delay
the start of the cleaning.
During the pyrolysis the oven lamp is off.
ENGLISH
35
5. To change the default length of the
pyrolysis (P1 or P2), press to set
, and then press or .
6. When the oven is at the set
temperature, the door locks. The
display shows and the bars of the
heat indicator until the door unlocks.
7. When pyrolysis is completed, the
display shows the time of day. The
oven door stays locked.
8. When the oven is cool again, the
door unlocks.
11.4 Cleaning reminder
To remind you that the pyrolysis is
necessary, PYR flashes in the display for
10 seconds after each activation and
deactivation of the oven.
The cleaning reminder
goes out:
• after the end of the
pyrolysis.
• if you press and at
the same time while PYR
flashes in the display.
11.5 Removing and installing
the door
You can remove the door and the
internal glass panels to clean it. The
number of glass panels is different for
different models.
WARNING!
The door is heavy.
1. Open the door fully.
2. Fully press the clamping levers (A) on
the two door hinges.
A
A
3. Close the oven door to the first
opening position (approximately 70°
angle).
4.
Hold the door with one hand on each
side and pull it away from the oven at
an upwards angle.
5. Put the door with the outer side
down on a soft cloth on a stable
surface.
6. Hold the door trim (B) on the top
edge of the door at the two sides
and push inwards to release the clip
seal.
1
2
B
7. Pull the door trim to the front to
remove it.
8. Hold the door glass panels on their
top edge one by one and pull them
up out of the guide.
9. Clean the glass panel with water and
soap. Dry the glass panel carefully.
When the cleaning is completed, do the
above steps in the opposite sequence.
Install the smaller panel first, then the
larger and the door.
WARNING!
Make sure that the glasses
are inserted in the correct
position otherwise the
surface of the door may
overheat.
Make sure that you put the glass panels
(C, B and A) back in the correct
sequence. First, insert panel C, which has
a square printed on the left side and a
triangle on the right side. You will also
find those symbols embossed on the
door frame. The triangle symbol on the
glass must match the triangle on the
www.aeg.com
36
door frame, and the square symbol must
match the square. After that insert the
other two glass panels.
A B C
11.6 Replacing the lamp
WARNING!
Risk of electric shock.
The lamp can be hot.
1. Turn off the oven.
Wait until the oven is cooled down.
2. Disconnect the oven from the mains.
3. Put a cloth on the bottom of the
cavity.
The top lamp
1. Turn the lamp glass cover to remove
it.
2. Clean the glass cover.
3. Replace the lamp with a suitable 300
°C heat-resistant lamp.
4. Install the glass cover.
12. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
12.1 What to do if...
Problem Possible cause Remedy
You cannot activate or oper-
ate the oven.
The oven is not connected
to an electrical supply or it is
connected incorrectly.
Check if the oven is correctly
connected to the electrical
supply (refer to the connec-
tion diagram if available).
The oven does not heat up. The oven is deactivated. Activate the oven.
The oven does not heat up. The clock is not set. Set the clock.
The oven does not heat up. The necessary settings are
not set.
Make sure that the settings
are correct.
The oven does not heat up. The automatic switch-off is
activated.
Refer to "Automatic switch-
off".
ENGLISH 37
Problem Possible cause Remedy
The oven does not heat up. The Child Lock is on. Refer to "Using the Child
Lock".
The oven does not heat up. The door is not closed cor-
rectly.
Fully close the door.
The oven does not heat up. The fuse is blown. Make sure that the fuse is
the cause of the malfunction.
If the fuse is blown again
and again, contact a quali-
fied electrician.
The lamp does not operate. The lamp is defective. Replace the lamp.
The core temperature sensor
does not operate.
The plug of the core tem-
perature sensor is not cor-
rectly installed into the sock-
et.
Put the plug of the core tem-
perature sensor as far as
possible into the socket.
Steam and condensation
settle on the food and in the
cavity of the oven.
You left the dish in the oven
for too long.
Do not leave the dishes in
the oven for longer than 15 -
20 minutes after the cooking
process ends.
The display shows "C2". You want to start the Pyroly-
sis or Defrost function, but
you did not remove the core
temperature sensor plug
from the socket.
Remove the core tempera-
ture sensor plug from the
socket.
The display shows "C3". The cleaning function does
not operate. You did not
fully close the door, or the
door lock is defective.
Fully close the door.
The display shows "F102". • You did not fully close
the door.
• The door lock is defec-
tive.
• Fully close the door.
• Deactivate the oven with
the house fuse or the
safety switch in the fuse
box and activate it again.
• If the display shows
"F102" again, contact the
Customer Care Depart-
ment.
www.aeg.com38
Problem Possible cause Remedy
The display shows an error
code that is not in this table.
There is an electrical fault. • Deactivate the oven with
the house fuse or the
safety switch in the fuse
box and activate it again.
• If the display shows the
error code again, contact
the Customer Care De-
partment.
There is no good cooking
performance using the func-
tion: True Fan Cooking
PLUS.
You did not turn on correctly
the function: True Fan Cook-
ing PLUSwith the Plus
Steam.
Refer to "Activating the
function: True Fan Cooking
PLUS".
There is no good cooking
performance using the func-
tion: True Fan Cooking
PLUS.
You did not fill the cavity
embossment with water.
Refer to "Activating the
function: True Fan Cooking
PLUS".
You want to activate the
True Fan Cooking PLUS
function, but the Plus Steam
indicator does not switch on.
You did not select the heat-
ing function that support
Plus Steam.
Refer to "Activating the
function: True Fan Cooking
PLUS".
You want to activate the
True Fan Cooking PLUS
function, but the Plus Steam
indicator does not switch on.
The Plus Steam does not
work.
Deactivate the appliance
with the house fuse or the
safety switch in the fuse box
and activate it again.
Refer to "Activating the
function: True Fan Cooking
PLUS".
You want to activate the
cleaning function, but the
display shows "C4".
The Plus Steam is pressed. Press the Plus Steam again.
The water in the cavity em-
bossment does not boil.
The temperature is too low. Set the temperature at least
to 110 °C.
Refer to "Hints and tips"
chapter.
The water comes out of the
cavity embossment.
There is too much water in
the cavity embossment.
Deactivate the oven and
make sure that the appliance
is cold. Wipe the water with
a cloth or sponge. Add the
correct amount of water to
the cavity embossment. Re-
fer to the specific procedure.
ENGLISH 39
Problem Possible cause Remedy
The appliance is activated
and does not heat up. The
fan does not operate. The
display shows "Demo".
The demo mode is activa-
ted.
1. Deactivate the oven.
2. Press and hold the but-
ton .
3. The first digit on the dis-
play and Demo indicator
start to blink.
4. Enter the code 2468 by
pressing the buttons
or to change the val-
ues and press to con-
firm.
5. The next digit starts to
blink.
6. Demo mode deactivates
when you confirm the
last digit and the code is
correct.
12.2 Service data
If you cannot find a solution to the
problem yourself, contact your dealer or
an Authorised Service Centre.
The necessary data for the service centre
is on the rating plate. The rating plate is
on the front frame of the oven cavity. Do
not remove the rating plate from the
oven cavity.
We recommend that you write the data here:
Model (MOD.) .........................................
Product number (PNC) .........................................
Serial number (S.N.) .........................................
13. ENERGY EFFICIENCY
13.1 Product Information and Product Information Sheet*
Supplier's name AEG
Model identification BPK552220M 944187832
Energy Efficiency Index 81.2
Energy efficiency class A+
Energy consumption with a standard load, conven-
tional mode
1.09 kWh/cycle
www.aeg.com40
Energy consumption with a standard load, fan-forced
mode
0.69 kWh/cycle
Number of cavities 1
Heat source Electricity
Volume 71 l
Type of oven Built-In Oven
Mass 36.5 kg
* For European Union according to EU Regulations 65/2014 and 66/2014.
For Republic of Belarus according to STB 2478-2017, Appendix G; STB 2477-2017, Annex-
es A and B.
For Ukraine according to 568/32020.
Energy efficiency class is not applicable for Russia.
EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens
and grills - Methods for measuring performance.
13.2 Energy saving
The oven contains features
which help you save energy
during everyday cooking.
Make sure that the oven door is closed
properly when the oven operates. Do not
open the door too often during cooking.
Keep the door gasket clean and make
sure it is well fixed in its position.
Use metal cookware to improve energy
saving.
When possible, do not preheat the oven
before cooking.
Keep breaks between baking as short as
possible when you prepare a few dishes
at one time.
Cooking with fan
When possible, use the cooking
functions with fan to save energy.
Residual heat
If a programme with the Duration or End
Time selection is activated and the
cooking time is longer than 30 minutes,
the heating elements automatically turn
off earlier in some oven functions.
The fan and lamp continue to operate.
When you turn off the oven, the display
shows the residual heat. You can use that
heat to keep the food warm.
When the cooking duration is longer
than 30 minutes, reduce the oven
temperature to minimum 3 - 10 minutes
before the end of cooking. The residual
heat inside the oven will continue to
cook.
Use the residual heat to warm up other
dishes.
Keep food warm
Choose the lowest possible temperature
setting to use residual heat and keep a
meal warm. The residual heat indicator
or temperature appears on the display.
Moist Fan Baking
Function designed to save energy during
cooking.
When you use this function the lamp
automatically turns off after 30 seconds.
ENGLISH
41
14. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol .
Put the packaging in relevant containers
to recycle it. Help protect the
environment and human health by
recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
*
www.aeg.com
42
ENGLISH 43
www.aeg.com/shop
867335465-C-282019
