trimmer is turned “OFF - 0.”
4. If your electricity is connected to a master power switch, we
suggest the trimmer be disconnected from the charger anytime
the master switch is off. Leaving the unit plugged into a dead
outlet or an unplugged charger will drain the battery.
5. If trimmer does not run and it is completely charged, turn the unit
“ON - I” and pinch or push the blades manually. (Oil may have
dried out between the blades, so they may be temporarily stuck
together.)
LITHIUM-ION BATTERY
REPLACEMENT, CLIPPER
DISPOSAL AND RECYCLING:
• For battery replacement send the entire, intact clipper unit to: Wahl
Annex 3001 North Locust, P.O. Box 578, Sterling, IL 61081
• Do not attempt to remove the battery. Lithium-Ion batteries can
explode, catch fire, and/or cause burns if disassembled, damaged, or
exposed to water or high temperatures.
• If you choose not to replace the battery, the entire, intact clipper unit
must be disposed. Do not attempt to remove the battery for disposal.
Lithium-Ion batteries may be subject to local disposal regulations.
Many locations prohibit disposal in standard waste receptacles.
Check your local laws and regulations.
• For recycling contact a government recycling agency, waste
disposal service, retailer, or visit online recycling sources, such as
www.batteryrecycling.com or www.rbrc.org.
TRAVEL PLUG
The travel plug is used to prevent
the trimmer from accidentally
powering on when traveling. When
the travel plug is engaged, the
power button will not function.
IMPORTANT SAFEGUARDS
When using your electrical appliance, basic
precautions should always be followed,
including the following:
READ ALL INSTRUCTIONS AND SAFEGUARDS
BEFORE USING THIS TRIMMER.
DANGER
To reduce the risk of death or injury by
electric shock:
1. Do not reach for an appliance that has
fallen into water. Unplug immediately from
the outlet.
2. Do not use while bathing or in a shower.
3. Do not place or store appliance where it can
fall or be pulled into a tub or sink. Do not place
in or drop into water or other liquid.
4. Except when charging, always unplug this
appliance from the electrical outlet immediately
after using.
5. Always unplug this appliance before cleaning.
6. (Rechargeable unit only.) Unplug the charger
before using trimmer.
WARNING
To reduce the risk of burns, electrical shock
15% battery capacity remaining. Once flashing starts, there
should be enough charge remaining to finish trimming before
re-charging the trimmer.
9. Once the LED begins flashing to indicate that it needs to
be re-charged, it will remain flashing until the trimmer is
completely re-charged or until the trimmer runs out of power.
Completely recharged means that enough charge time has
elapsed and the LED has gone from ON to OFF. Full charge
from a dead battery should take about 1 hour.
10. When trimmer is low in power, it should be connected to the
transformer and plugged into an outlet to assure maximum
power is available when it is next used. This transformer
is designed to completely charge the battery without
overcharging. Do not use the trimmer while it is charging.
11. The battery will take approximately 60 minutes to charge. The
Lithium Ion Trimmer also has quick charge capability.
12. Insert only recharging transformer plug supplied by the
manufacturer into charger receptacle.
TROUBLESHOOTING
• If the LED did not flash before the trimmer stopped running try
resetting the trimmer by charging the trimmer completely until the
LED shuts OFF.
• Trimming is disabled when charging or if the disabling plug is
inserted into the jack.
• If the trimmer is fully charged the LED may remain OFF if plugged
into the charger.
• If the trimmer unexpectedly stopped operating try resetting the
device by plugging the trimmer into the charger.
• If your Trimmer does not seem to take a charge, check the following
before returning it for repair:
1. Check outlet to make sure it is working by plugging in another
appliance.
2. Make sure the outlet simply is not connected to a light switch
which turns the power at the outlet off when lights are turned off.
3. Be sure the trimmer is properly connected to the recharging
transformer, all connections are secure and the switch on the
opening.
10. Do not use this appliance with a damaged
or broken blade or trimming attachment, as
facial injury may occur.
11. Always attach plug to appliance first, then
to outlet.
12. Use only the charger supplied by the
manufacturer to recharge.
To disconnect, turn unit “OFF - 0,”
then remove plug from outlet.
SAVE THESE INSTRUCTIONS
For Household Use Only
RECHARGING & SMART LED
1. This trimmer is conveniently designed for household use. It
should be allowed to charge completely for 1 hour before its
first use. If not charged completely prior to the first use, the
LED will flash while the trimmer is running.
2. Remove the trimmer, recharging transformer and accessories
from the packing material.
3. Connect the transformer to the trimmer. BE SURE TRIMMER IS
IN THE “OFF - 0” POSITION WHEN CHARGING.
4. Plug the recharging transformer into any convenient electrical
outlet at the correct voltage.
5. When charging the trimmer, the LED will be
ON.
6. When using the trimmer, the LED will be ON.
7. When charging is completed, the LED will go
from ON to OFF.
8. When the trimmer is about to run out of
energy, the LED will flash to indicate that you have less than
or injury to persons:
1. Do Not Crush, Disassemble, Heat Above
100°C (212°F), or Incinerate the appliance,
due to Risk of Fire, Explosion, or Burns.
2. This power unit is intended to be correctly
orientated in a vertical or floor mount position.
3. Close supervision is necessary when this
appliance is used by, on, or near children or
disabled persons.
4. Use this appliance only for its intended
use as described in this manual. Do not
use attachments not recommended by the
manufacturer.
5. Never operate this appliance if it has a
damaged cord or plug, if it is not working
properly, if it has been dropped or damaged,
or if it has been dropped into water. Return
the appliance to Wahl Clipper Corporation for
examination and repair.
6. Keep the cord away from heated surfaces.
7. Only insert approved transformer plug or
travel plug into charger receptacle.
8. Do not use outdoors or operate where aerosol
(spray) products are being used or where
oxygen is being administered.
9. Never drop or insert any object into any
Lithium•Ion+
STAINLESS STEEL
Operating Instructions for the
Lithium Ion Grooming Kits
Instrucciones de operación
de la recortadora recargable
Detachable Blade Trimmer
www.wahltrimmers.com
© 2013 Wahl Clipper Corporation
Part No. 93265
Printed in U.S.A.
For more information or Product Registration, visit www.wahltrimmers.com
5-YEAR LIMITED WARRANTY
Valid in U.S.A. Only
If your Wahl product fails to operate satisfactorily within five
(5) years from the date of original purchase or receipt as a gift,
Wahl will, at our option, repair or replace it and return it to you
FREE OF CHARGE. Do not return this product to store where
purchased. Products needing repair under this warranty should
be returned with postage prepaid to:
Wahl Clipper Corp.
Attn: Repair Department
3001 Locust Street
Sterling, Illinois 61081
Include a note describing the defect and the date of original
purchase or receipt as a gift (if in warranty). Products out of
warranty will be repaired at our standard repair charges.
This warranty is void and no repair or replacement will be made
under this warranty or otherwise if: (1) The product is modified
in any manner or repaired by anyone other than Wahl Clipper
Corporation or Wahl authorized service center. (2) The product
has been used commercially or subjected to unreasonable use.
This warranty gives you specific legal rights and you may
also have other rights which may vary from state to state. No
other written express warranty is given. Any implied warranty,
including any warranty of merchantability which may arise from
purchase or use, is limited to the year period provided in this
express warranty. Some states may not allow such limitation,
so it may not apply to you. No responsibility is assumed for
incidental or consequential damages of any type, or for the use
of unauthorized attachments. Some states may not allow the
exclusion or limitation of incidental or consequential damages, so
the limitation or exclusion may not apply to you. Outside U.S.A.,
check with store for Wahl authorized distributor’s warranty.
SERVICE AND REPAIR
If you have problems with your trimmer, send it prepaid
with a note explaining the problem to:
Wahl Clipper Corporation
Attn: Repair Department
3001 Locust Street
Sterling, IL 61081
Telephone (800) 767-9245
For products purchased outside the United States, contact your distributor.
If for any reason within 60 days of purchase of your Wahl
®
trimmer you are not satisfied with your trimmer and would
like a refund, just return your trimmer, together with the sales
receipt, to the retailer from whom you purchased it. Wahl will
reimburse all retailers who accept trimmers within 60 days of
purchase. If you have any questions regarding this money-
back guarantee, please call 1-800-767-9245 in the United
States.
60 Day Money Back Guarantee!
CARING FOR YOUR TRIMMER
OILING BLADES
For best results, put one or two drops of Wahl Clipper Oil on
the blades only when necessary, or approximately once a month.
Motor bearings are permanently lubricated—do not attempt to oil.
When oiling your trimmer, turn the trimmer “ON,” hold the unit
with the blades facing DOWN and squeeze one or two drops of oil
onto the blades. Wipe off excess oil with soft cloth.
NOTICE—DO NOT OVER OIL!
Excessive oiling or application of liquids will cause damage if
allowed to seep back into motor.
BLADE/HEAD CARE
Trimmer blades have precision-hardened and ground cutting teeth.
Blades should be handled carefully and never bumped or used to
cut dirty or abrasive material. Clean with the included brush.
Heads should be removed from the trimmer prior to
rinsing in water. After rinsing, allow the heads to air dry
completely before reattaching to the trimmer body. The
trimmer body should always be kept away from water
to maximize the life of the motor, battery, and control
components.
CLEANING/STORAGE
Before storing your trimmer, use the cleaning brush to whisk
any loose hairs from the unit and the blades. Store unit in such a
manner so that blades are protected from damage.
This appliance should be stored in a manner where it is not
subjected to Crushing, Heating above 100°C (212°F), or
Incineration.
FADE CUT
using T-Blade
1. Start at the temple and cut all the way around the head to establish the
ultimate location of the fade line. Always cut against the grain for the short
-
est cut. Don’t force the blade through the hair. Let the trimmer do the work.
2. Next, cut around the head again and up the nape of the neck to the fade
line, brushing away the cut hair as you go. Pull the scalp taut with the
thumb for the closest cut. Turn the trimmer upside down when necessary to
keep cutting against the grain. Make sure both sides of the head are even.
3. For the top of the head, cut with the grain using the individual guide
comb attachments. The smaller the number of the comb, the shorter the cut.
Comb or brush the hair as you cut for an even end result.
4. To complete the fade, blend the hair at the fade line by trimming up and
out across the line and against the grain all the way around the head. Then,
repeat all around, turning the trimmer upside down and cutting downward.
The final objective is to blend the hair so there is no real line, just a perfect
fade from bald to very short hair. You can achieve this by using the #1
guide comb attachment. Continue combing and cutting until you achieve
the desired effect.
5. To create a part, pick a spot off-center. Pull the scalp tight and with the
end of the blade perpendicular to the head, move the trimmer back and
forth to cut a line. Comb through it and cut again to make sure the cut is
precise.
5. Define the upper part of your beard
using the same technique.
6. For a neater finished look, replace
attachment blade to the detail blade.
Use this blade for fine, detail trimming
anywhere it is needed, such as at the
sideburns near the ears, goatees, etc.
DETAILING NECKLINES,
SIDEBURNS, MUSTACHES
& BEARDS
Slowly move trimmer downward on desired
areas to neatly trim and shape.
TRIMMING ARM & LEG HAIR
Simply glide the trimmer over your arm or leg until desired hair length
is achieved. The first time you trim the hair, start by using a longer guide
comb on the trimmer, then use progressively shorter settings if a shorter
length is preferred.
TRIMMING CHEST & STOMACH
Glide the trimmer over your torso region, in an upward motion until desired
hair length is achieved. For tight, scratch-free trimming, use the #1 guide
comb.
TRIMMING NOSE HAIR
Make sure the nasal passages are clean. Slowly move the ear/nose trimmer
in and out of each nostril, no more than 1/4-inch deep.
TRIMMING EAR HAIR
Make sure the outer areas of the ears do not contain any wax. Hold the ear
flat with one hand and carefully insert ear/nose trimmer no more than 1/4-
inch into the outer ear.
CAUTION: Do not insert the detailer or any other foreign object into
the inner ear. For hair growing on the outside of the ear, simply move the
detailer slowly along the edges of the ear.
TRIMMING EYEBROWS using Detailer Head
Slowly move detailer to neatly trim stray hairs. For precise, even trimming,
slowly move the detailer closer or farther away from eyebrows to achieve
desired length. Do not press against brow as it may remove too much hair.
SPECIAL FEATURES:
Your trimmer has been designed with several advanced
features to help you get perfect results every time you
trim. Your trimmer may be used to neatly trim goatees,
beards, mustaches, neckline, sideburns around the ears
and eyebrows, or anywhere you may need grooming.
It also makes a great all-around family trimmer for mini
haircuts and touch ups between trips to the barber or to
clean up the shape of the neck.
A Detachable blade system enables you to quickly
change from a standard-width blade for full grooming
to a narrow-width blade for detail trimming around a
mustache, goatee, or anywhere to define the hair line and clip
any stray whiskers.
To remove attachment, simply pull top edge of blade away from
body unit. To attach, align back
tab of attachment head to cavity
on the inner edge of trimmer unit
and push down on top of blade.
Should blades become damaged or dull or if you want additional
attachment heads for your trimmer, you may purchase them
from Wahl. Be sure to ask for the following attachment with part
number from our service and repair department (see last page for
contact information):
The trimmer you purchased may not have all of these heads, but
they will all work with your trimmer if you wish to purchase them.
Self-sharpening blades are made to maintain their shape and
sharpness for extended periods.
TRIMMING AND EDGING YOUR BEARD
The following are suggested trimming steps and trimmer positions.
You may find different procedures work better for you.
1. Comb your beard in the direction that it grows to help reveal
stray hairs that may be longer than the others.
2. Attach a guide to trim and taper your
beard. Begin with a guide of a long
trimming length. Trim toward your chin
in smooth, overlapping strokes, following
the lay of your beard. If you trim against
the way your beard naturally lays, the
trimmer will cut the hair much shorter
and the result may be patchy.
Change the trimming guides to progressively
shorter lengths until you reach the desired
length of beard. You may wish to trim closer near the ear and
down under the chin, changing to a longer guide toward the
front of the face and point of your chin.
3. To cut the outline of your beard,
remove the trimming guide. Starting
under your chin and working back
toward your jawbone and ears, cut
the outer perimeter of your beard
underneath the jawbone. Continue
the line all the way up to the ears and
hairline.
4.
Accentuate your beard line by using the
trimmer in a downward motion. Start
at the line you’ve created and, working
from the chin back toward the ears, trim
the area right under your beard line.
SERVICE AND REPAIR
If you have problems with your trimmer, send it prepaid
with a note explaining the problem to:
Wahl Clipper Corporation
Attn: Repair Department
3001 Locust Street
Sterling, IL 61081
Telephone (800) 767-9245
For products purchased outside the United States, contact your distributor.
If for any reason within 60 days of purchase of your Wahl
®
trimmer you are not satisfied with your trimmer and would
like a refund, just return your trimmer, together with the sales
receipt, to the retailer from whom you purchased it. Wahl will
reimburse all retailers who accept trimmers within 60 days of
purchase. If you have any questions regarding this money-
back guarantee, please call 1-800-767-9245 in the United
States.
60 Day Money Back Guarantee!
#1 Stubble Length
#2 Short
#3 Medium Short
CUTTING HAIR
The first time you cut the hair, cut only a small amount until you become
accustomed to how long each guide comb leaves the hair. Always start by
placing the largest guide comb on the trimmer, then use shorter combs if a
shorter length is desired.
Remember, between professional haircuts, the hair grows evenly all over
the head and a light trimming at the lower neck and sides may be all that is
needed to bring back that neat, well-groomed look.
For uniform cutting, allow the trimmer to cut its way through the hair. Do
not force it through at a faster rate.
1. Start by combing the hair so it falls into its natural direction.
2. Place the largest guide comb onto your trimmer and start by trimming
the sides from the bottom upwards. Hold the trimmer lightly against the
hair, with teeth of the guide comb pointing up but flat against the head.
Slowly lift the trimmer up and outward through the hair, cutting only a
small amount at a time.
Repeat around sides and back of head.
If you desire shorter hair, either change to a shorter guide comb or apply
more pressure and less lift away from head with the present attachment.
This entire procedure requires practice, and it is always better to leave too
much hair the first few haircuts.
1 3 5 7
2 4 6 8
#59307#59300-800
Trimmer Detailer T-Blade
Dual
Shaver
Detail
Shaver
Rotary
Nose
Trimmer
#59301 #2144-101 #59303 #58067-100
!
Loading ...
