1/16” 1/8” 3/16”
TRIMMING NOSE HAIR
Make sure the nasal passages are clean. Slowly move Rotary Head in
and out of each nostril, no more than 1/4-inch deep. Keep the side of the
cutting head firmly against the skin to prevent a tickling sensation. (The
Detail Head may also be used.)
TRIMMING EAR HAIR
Make sure the outer areas of the ears do not contain any wax. Hold the ear
flat with one hand and carefully insert Rotary Head no more than 1/4-inch
into the outer ear.
CAUTION: Do not insert the Rotary Head or any other foreign object
into the inner ear. For hair growing on the outside of the ear, simply move
the Rotary Head slowly along the edges of the ear. (The Detail Head may
also be used.)
TRIMMING EYEBROWS
Slowly move detailer to neatly trim stray hairs. For precise, even trimming,
slowly move the detailer closer or farther away from eyebrows to achieve
desired length.
TRIMMING WITH ATTACHMENT COMBS
Your trimmer includes three trimming attachments; stubble, medium
and long. The stubble guide has 1 bar, the medium-cut attachment has
two bars and the long-cut attachment has three bars.
These attachments are ideal for blending, tapering and
defining beards, as well as for achieving a “close trim”
stubble look around the face. To use the attachments,
go with the hair direction. To achieve closer looks, go
against the hair direction.
RECYCLE/REPLACEMENT
OF NI-CAD BATTERY
Do not mix old and new batteries. Do not mix alkaline, standard
(carbon-zinc), or rechargeable (Ni-Cad, Ni-MH, etc.) batteries.
Under normal use, the rechargeable nickel-cadmium batteries in your
trimmer may last up to five years. At the end of their life, when they
will no longer take a full charge, the nickel-cadmium batteries must
be removed and recycled or disposed of properly. Do not attempt to
replace the batteries. All servicing or battery replacement should be
performed by an Authorized WAHL Service Location. To remove the
battteries for recycling or disposal, follow these steps:
1. Unplug transformer from outlet, disconnect cord
from trimmer and allow the batteries to
completely run down before
disassembly.
2. Remove
any attached
trimming
heads.
3. Pry the trimmer
housing apart.
INSTALLATION/REMOVAL OF TRIMMING HEADS
Make sure trimmer unit is turned “OFF”.
1. Turn trimmer head counterclockwise and
lift off.
2. Place trimmer head on trimmer and turn
trimmer head clockwise to lock on.
TRIMMING AND EDGING
YOUR BEARD
The following are suggested trimming steps and trimmer positions. You
may find different procedures work better for you.
1. Comb your beard in the direction that it grows to help reveal stray hairs
that may be longer than the others.
2. Attach the guide comb to trim and taper your
beard. With the blades pointing toward you, begin
with the 5-position guide set at a long trimming
length. For best results, start at each sideburn and
stroke downward toward your neck. Trim toward
your chin in smooth, overlapping strokes, following the lay of your beard.
If you trim against the way your beard naturally lays, the trimmer will cut
the hair much shorter and the result may be patchy. Adjust the guide comb
to progressively shorter settings until you reach the desired length of
beard. You may wish to set the guide comb to cut closer near the ear and
down under the chin, changing to a longer setting toward the front of the
face and point of your chin. Always be sure the guide is snapped solidly
into the desired position before you start to trim.
3. Remove the 5-position guide and cut the outline of your beard. Starting
under your chin and working back toward your jawbone and ears, cut the
outer perimeter of your beard underneath the jawbone. Continue the line all
the way up to the ears and hairline.
4. Accentuate your beard line by using the trimmer in a downward motion.
Start at the line you’ve created and, working from the chin back toward the
ears, trim the area right under your beard line.
5. Define the upper part of your beard using the same technique.
6. For a neater finished look, use the guide comb on position 2. Then,
using the trimmer in an upward motion, start trimming under the chin with
short, outward, rolling strokes. Continue trimming until entire jawline is
blended.
TRIMMING YOUR MUSTACHE
1. Comb your mustache.
2. Hold the trimmer in a vertical position with the blades pointing toward
you in order to define the line of your mustache.
3. With the guide set at a fairly long trimming length, begin trimming your
mustache, starting at the top and working down to your upper lip. Use
progressively closer settings to get the look and length you desire.
4. For tapering the mustache, set the guide comb at a medium length.
Starting in the middle of your mustache, follow the lip line and taper with
short upward strokes of the trimmer, working out toward the corners until a
gentle shape is created on the bottom of your mustache.
5. As a finishing step, remove the guide and, using only the bare blades,
make a definitive line at the bottom of your mustache.
DETAILING SIDEBURNS, MUSTACHES & BEARDS
using trimmer head.
Slowly move trimmer across desired areas to neatly trim and shape.
TRIMMING ARM & LEG HAIR using trimmer head.
Simply glide the trimmer over your arm or leg until desired hair length is
achieved. The first time you trim the hair, start by using a longer setting on
the guide comb on the trimmer, then use progressively shorter settings if a
shorter length is preferred.
TRIMMING CHEST & STOMACH HAIR with
trimmer head.
Glide the trimmer over your torso region, in an upward motion until
desired hair length is achieved. The first time you trim the hair, start by
using a longer setting on the 5-position guide comb on the trimmer, then
use progressively shorter settings if a shorter length is preferred.
For the cleanest look, simply attach the shaver
head.The shaver makes for the perfect tool to clean up,
in, and around your beard, mustache, or other facial hair.
Shave against hair growth while stretching the skin. After
every use, remove the shaver foil by pressing the button
on the shaver head and carefully using cleaning brush
provided.
SAVE THESE
INSTRUCTIONS
For Household Use Only
RECHARGING
1. This trimmer is conveniently designed for household use. It
should be allowed to charge overnight before first use.
2. Remove the trimmer, recharging transformer and accessories
from the packing material.
3. Connect the transformer to the trimmer. BE SURE TRIMMER IS
IN THE “OFF - 0” POSITION WHEN CHARGING.
4. Plug the recharging transformer into any convenient electrical
outlet at the correct voltage.
5. When trimmer is low in power, it should be connected to the
transformer and plugged into an outlet to assure maximum
power is available when it is next used. This transformer
is designed to continuously charge the battery without
overcharging.
6. Ni-Cad battery life may be extended with the following
procedure: Once every month, let the trimmer run until the
motor stops. Move the switch to the “OFF - 0” position and
recharge fully overnight.
TROUBLESHOOTING
If your Trimmer does not seem to take a charge, check the following
before returning it for repair:
1. Check outlet current by plugging in another appliance.
2. Make sure the outlet simply is not connected to a light switch which
turns the power at the outlet off when lights are turned off.
3. Be sure the trimmer is properly connected to the recharging
transformer, all connections are secure and the switch on the
trimmer is turned “OFF - 0.”
4. If your electricity is connected to a master power switch, we
not subjected to crushing, heating above 100°C (212°F), or
incineration.
SPECIAL FEATURES:
Your trimmer has been designed with several advanced features to help
you get perfect results every time you trim. Your trimmer may be used
to touch-up around ears, nose and eyebrows, neatly detail goatees,
beards, mustaches, neckline, sideburns, or anywhere you may need
grooming.
suggest the trimmer be disconnected from the charger anytime
the master switch is off. Leaving the unit plugged into a dead
outlet or an unplugged charger will drain the battery.
5. If trimmer does not run and it is completely charged, turn the unit
“ON - I” and pinch or push the blades manually. (Oil may have
dried out between the blades, so they may be temporarily stuck
together.)
CARING FOR YOUR TRIMMER
OILING BLADES
For best results, use Wahl Clipper Oil on the blades only when
necessary, or approximately once a month. Motor bearings are
permanently lubricated—do not attempt to oil.
When oiling your trimmer, turn the trimmer “ON - I,” hold the unit
with the blades facing DOWN and squeeze three drops across the
front of the blade and one drop on each side on the heel of the
blade. Wipe off excess oil with soft cloth.
NOTICE—DO NOT OVER OIL!
Excessive oiling or application of liquids will cause damage if
allowed to seep back into motor.
BLADE CARE
Trimmer blades have precision-hardened, ground and lapped
cutting teeth. Blades should be handled carefully and never
bumped or used to cut dirty or abrasive material. Never rinse the
blades with water, or the blades may rust. Clean with the included
brush.
CLEANING/STORAGE
Before storing your trimmer, use the cleaning brush to whisk
any loose hairs from the unit and the blades. For units with a
soft-touch grip, use a damp cloth to wipe down the body of the
trimmer, taking care not to get the blades wet. Store unit in such a
manner so that blades are protected from damage.
When the trimmer is not in use, the trimmer blade guard
attachment should be in place to protect the blades.
This appliance should be stored in a manner where it is
grooming.wahl.com
© 2018 Wahl Clipper Corporation
Part No. 56500-001
Printed in China
For more information or Product Registration, visit grooming.wahl.com
3-YEAR LIMITED WARRANTY
Valid in U.S.A. Only
If your Wahl product fails to operate satisfactorily within three
(3) years from the date of original purchase or receipt as a gift,
Wahl will, at our option, repair or replace it and return it to you
FREE OF CHARGE. Do not return this product to store where
purchased. Products needing repair under this warranty should
be returned with postage prepaid to:
Wahl Clipper Corp.
Attn: Repair Department
3001 Locust Street
Sterling, Illinois 61081
Include a note describing the defect and the date of original
purchase or receipt as a gift (if in warranty). Products out of
warranty will be repaired at our standard repair charges.
This warranty is void and no repair or replacement will be made
under this warranty or otherwise if: (1) The product is modified
in any manner or repaired by anyone other than Wahl Clipper
Corporation or Wahl authorized service center. (2) The product
has been used commercially or subjected to unreasonable use.
This warranty gives you specific legal rights and you may
also have other rights which may vary from state to state. No
other written express warranty is given. Any implied warranty,
including any warranty of merchantability which may arise from
purchase or use, is limited to the year period provided in this
express warranty. Some states may not allow such limitation,
so it may not apply to you. No responsibility is assumed for
incidental or consequential damages of any type, or for the use
of unauthorized attachments. Some states may not allow the
exclusion or limitation of incidental or consequential damages, so
the limitation or exclusion may not apply to you. Outside U.S.A.,
check with store for Wahl authorized distributor’s warranty.
SERVICE AND REPAIR
If you have problems with your trimmer, send it prepaid
with a note explaining the problem to:
Wahl Clipper Corporation
Attn: Repair Department
3001 Locust Street
Sterling, IL 61081
Telephone (800) 767-9245
For products purchased outside the United States, contact your distributor.
If for any reason within 60 days of purchase of your Wahl
®
trimmer you are not satisfied with your trimmer and would
like a refund, just return your trimmer, together with the sales
receipt, to the retailer from whom you purchased it. Wahl will
reimburse all retailers who accept trimmers within 60 days of
purchase. If you have any questions regarding this money-
back guarantee, please call 1-800-767-9245 in the United
States.
60 Day Money Back Guarantee!
Operating Instructions for
Rechargeable Trimmer
Instrucciones para operar la
Recortadora Recargable
All In One
Detail
Head
Ear/Nose
Head
Shaving
Head
Mustache
Comb
The trimmer you
purchased may not
have all of these heads.
5-Position
Guide
CONTAINS SEALED, RECHARGEABLE NICKEL-
CADMIUM BATTERY. MUST BE RECYCLED OR
DISPOSED OF PROPERLY.
The RBRC Battery Recycling Seal on the nickel-cadmium (Ni-Cd) battery
contained in this product indicates Wahl is voluntarily participating in an
industry program to collect and recycle these batteries at the end of their useful
life, when taken out of service in the United States or Canada. The RBRC
program provides a convenient alternative to placing used Ni-Cd batteries into
the trash or the municipal waste stream, which is illegal in some areas. Please
call 1-800-8-BATTERY for information on Ni-Cd battery recycling in your area.
Wahl’s involvement in this program is part of our commitment to preserving
our environment and conserving our natural resources.
On/Off
Switch
Trimming
Head
1/16” Guide
1/8” Guide
3/16” Guide
Cleaning
Brush
Blade
Oil
Loading ...
