INSTRUCTION MANUAL 2.6kW Portable Air Conditioner for Dimplex DC09MINI

CONTENTS

  • WARNINGS AND PRECAUTIONS
  • STRUCTURE
  • OPERATION
  • CLEANING AND MAINTENANCE
  • TECHNICAL REFERENCE DATA
  • WARRANTY

OPERATION

DIRECTIONS

  1. Plug the unit into a suitable power outlet.
  2. Turn the control knob to the “FAN” position. This will put the appliance into “FAN MODE”.
  3. Turning the control knob to the “COOL” position, will put the appliance in “COOLING MODE”.
  4. The “FULL” indicator light will illuminate when the internal water tank is full. Note: The unit will also stop working until the tank is emptied.
  5. The “OPERATION” indicator light will illuminate when the unit is on and working.
  6. Turn the control knob to the "ON/OFF" position, to turn the unit off.

DRAINING THE WATER TANK: When the air conditioner is used, condensation may be produced that cannot be removed via the exhaust hose. This water is captured by an internal water tank. When the water tank is full, the unit will stop working and the FULL indicator light will turn on. When the FULL indicator light has turned on, the water tank must be manually drained by following the below steps:

  1. Switch off and unplug the unit.
  2. Move the unit to a suitable place to drain the water. Consider placing a tray or container under the outlet to catch the water.
  3. Remove the lower drain plug (9) - refer to parts illustration
  4. Slightly tilt the unit to the rear to drain the water.
  5. Once the water has completely drained, replace the drain plug (9).

IMPORTANT:

  • Ensure the drain plug is re-fitted to the drain outlet before use.
  • Extend the exhaust back out the window before restarting the unit.

CLEANING & MAINTENANCE

CLEANING THE FILTERS WARNING: Always unplug the unit before moving or before any cleaning. The filters are located on the side of the unit. Remove & clean the filters by following the below instructions.

  1. Press the button near the handle.
  2. Remove the top panel.
  3. Remove the air filter by lifting upwards
  4. Wash the filter in running water, and allow to dry completely before reinstalling.
  5. Wipe any dust from the exterior of the unit, with a soft damp cloth.

IMPORTANT: The control panel and other parts must not come into contact with water or any other liquids.

  • Do not dispose of electrical appliances as unsorted municipal waste.
  • Use separate collection facilities
