User Manual Samsung VS80N8015K2/SP POWERstick PRO™ Vacuum cleaner

Samsung VS80N8015K2/SP POWERstick PRO™ Vacuum cleaner - Use Manual - Use Guide PDF.
Documents: Go to download!
  • Owner's manual - (English)

User manual Vacuum cleaner Samsung VS80N8015K2/SP

Contents

  • Preparation
  • Safety information
  • Installation
  • Name of the parts
  • Accessories
  • Installing the wall mount
  • Installing the wall mount
  • Disassembling the wall mount
  • Operation
  • Using the vacuum cleaner
  • Charging the vacuum cleaner
  • Using the handle
  • Storing the vacuum cleaner
  • Using the accessories
  • Maintenance
  • Maintaining the vacuum cleaner
  • When to empty the dustbin
  • Emptying the dustbin without causing dust clouds
  • Emptying and Cleaning the dustbin
  • Cleaning the sponge filter
  • Cleaning the outlet filter
  • Cleaning the accessories
  • Appendix
  • Notes and cautions
  • Battery usage
  • Operation
  • Maintenance
  • Troubleshooting

Safety information

  • Before operating the appliance, please read this manual thoroughly and retain it for your reference.
  • Because the following operating instructions cover various models, the characteristics of your vacuum cleaner may differ slightly from those described in this manual.

Maintenance

Emptying and Cleaning the dustbin

  1. While pressing the dustbin release button, remove the dustbin by pulling it in the direction of the arrow.
  2. Grip the groove on the dustbin cover, and then pull the cover off.
  3. Empty the dustbin. Pull the lever on the dustbin to remove any tangled dust, and then push the lever back in all the way until you hear it click.
  4. After cleaning the dustbin, dry it in the shade.
  5. Make sure the marks printed on the dustbin cover and dustbin are aligned, and then put the cover back on the dustbin.
  6. Re-attach the dustbin by pushing it as shown in the illustration until you hear it click.

Caution

  • Do not disassemble the battery or the battery charger.
  • Do not apply heat to the battery and do not put the battery in a fire.
  • As the battery is manufactured only for this product, do not use the battery for other electronic appliances or other purposes.
  • Removing the battery during operation may cause product malfunction.
  • If the battery is removed while the vacuum cleaner motor is operating, the battery may not work for 30 seconds after being re-attached for safety reasons.
  • Battery charging time and usage time may shorten with increased battery use. When the battery no longer charges or runs down quickly, replace the exhausted battery with a new one.
  • Use only the battery charger and batteries provided by the manufacturer. (Battery charger : SLPS-200FGOT, Battery : VCASBT80)
  • Before inserting the battery, confirm that the battery is being inserted in the correct direction and orientation.
  • When discarding a dead battery, put it into a battery collection box for recycling.
  • If you are not going to use your vacuum cleaner for a long time, detach the battery from the vacuum.


See other models: NK24N5703BM/UR MG23K3575AW/EU DV80H4200CW/SP NQ50J3530BS/EU WW12K8412OW/FQ

Samsung VS80N8015K2/SP | File type: PDF | Filename: "Samsung POWERstick PRO™ with Cyclone Force, 150W VS80N8015K2:SP ".pdf | Size: 9.86 MB | Language: English

Download User Manual

Product Infomation and Reviews - VS80N8015K2/SP photo

VS80N8015K2 SP Photo

Samsung in United States

1-800-726-7864 Mon - Fri: 8AM - 12AM (EST) / Sat - Sun: 9AM - 11PM (EST) Sat - Sun: HOME APPLIANCE 9AM - 6PM (EST)

Samsung VS80N8015K2/SP Questions and Answers


#1 how long is the charging time?
270 min

#2 how many voltage?
32.4 V

#3 what are the dimensions of this product?
Dimension
252 x 375 x 1110 mm and 2.95 kg
