EC042A5C-BS
Microwave
Convection Oven
Instruction
Welcome to the world of
TOSHIBA
BEFORE OPERATING THIS PRODUCT,
READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
BE SURE TO SAVE THIS BOOKLIST FOR FUTURE REFERENCE
CONTENTS
OPERATION
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE
ENERGY
IMPORTANT SAFETY INSTRUCTIONS
GROUNDING INSTRUCTIONS
UTENSILS
SETTING UP YOUR OVEN
MAINTENANCE
Do not attempt to operate this oven with the door open since this can result
in harmful exposure to microwave energy. It is important not to
defeat or tamper with the safety interlocks.
120V~ 60Hz
1000W
Rated Voltage:
Rated Input Power(Microwave):
Rated Output Power(Microwave):
Oven Capacity:
Turntable Diameter:
External Dimensions:
Net Weight:
Specifications
a. DOOR (bent)
b. HINGES AND LATCHES (broken or loosened)
c. DOOR SEALS AND SEALING SURFACE
The oven should not be adjusted or reparied by anyone except properly
qualified service personnel.
Do not place any object between the oven front face and the door or allow
soil or cleaner residue to accumulate on sealing surfaces.
Do not operate the oven if it is damaged. It is particularly important
that the oven door closes properly and that there is no damage to the:
Model:
13.6 inch
1.5 cu.ft.
Rated Input Power(Convection):
1500
W
1 0W40
21.73X21.38X12.83 inch
Approx. 44.75 Lbs
1.
2.
3.
4.
EN-2
EC042A5C-BS
PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
Read all instructions before using the appliance.
Read and follow the specific: " PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY" found on page 2.
As with most cooking appliances, close supervision is necessary to reduce the risk of
a fire in the oven cavity.
To reduce the risk of fire in the oven cavity:
This oven must be grounded. Connect only to properly grounded outlet. See
"GROUNDING INSTRUCTIONS" found on page 6.
Install or locate this oven only in accordance with the installation instructions
provided.
Some products such as whole eggs and sealed containers-for example, closed glass
jars-are able to explode and should not be heated in the oven.
1.
2.
3.
4.
5.
6.
7.
To reduce the risk of burns, electric shock, fire, injury to persons or
exposure to excessive microwave oven energy when using your
appliance, follow basic safety precautions, including the following:
Do not overcook food. Carefully attend the appliance when paper, plastic, or other
combustible materials are placed inside the oven to facilitate cooking.
Remove wire twist-ties and metal handles from paper or plastic containers/ bags
before placing them in the oven.
If materials inside the oven ignite, keep the oven door closed. Turn the oven off,
and unplug the appliance. Disconnect the power cord, shut off power at the fuse
or circuit breaker panel.
Do not leave paper products, cooking
utensils, or food in the cavity when not in
use.
a.
b.
c.
d.
EN-3
Do not use the cavity for storage purposes.
IMPORTANT SAFETY
INSTRUCTIONS WARNING
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
Use this appliance only for its intended uses as described in this manual. Do not
use corrosive chemicals or vapors in this appliance. This oven is specifically
designed to heat or cook or dry food. It is not designed for industrial or laboratory
use.
As with any appliance, close supervision is necessary when used by children.
Do not operate this oven if it has a damaged cord or plug, if it is not working properly
or if it has been damaged or dropped.
This microwave should be serviced only by qualified service personnel.
Do not cover or block any openings on the oven.
Do not store or use this appliance outdoors.
Do not use this oven near water, for example, near a kitchen sink, in a wetbasement,
near a swimming pool, or similar locations.
Do not immerse cord or plug in water.
Keep cord away from heated surfaces.
Do not let cord hang over edge of table or counter.
When cleaning surfaces of door and oven that comes together on closing the door,
use only mild, nonabrasive soaps or detergents applied with a sponge of soft cloth.
This appliance is for private household use only.
EN-4
Contact nearest authorized service facility for examination, repair or adjustment.
IMPORTANT SAFETY
INSTRUCTIONS WARNING
20.
Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling
point without appearing to be boiling. Visible bubbling or boiling when the container
is removed from the microwave oven is not always present. THIS COULD RESULT
IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE CONTAINER IS
DISTURBED OR A SPOON OR OTHER UTENSIL IS INSERTED INTO THE
LIQUID.
Do not overheat the liquid.
Stir the liquid both before and halfway through heating it.
Do not use straight-sided containers with narrow necks.
After heating, allow the container to stand in the microwave oven for a short
time before removing the container.
Use extreme care when inserting a spoon or other utensil into the container.
a.
b.
c.
d.
e.
EN-5
IMPORTANT SAFETY
INSTRUCTIONS WARNING
SAVE THESE INSTRUCTIONS
CAUTION:
Do not insert your fingers into any gaps or holes; it may cause injuries.
DANGER
WARNING
This appliance must be grounded. In the event of an electrical short circuit, grounding
reduces the risk of electric shock by providing an escape wire for the electric current. To
protect against electrical shock, this appliance is equipped with a cord having a 3 prong
grounding-type plug for insertion into a proper grounding-type receptacle. DO NOT alter
the plug for use in a 2-prong receptacle. If the plug will not fit into a receptacle, have the
proper receptacle installed by a qualified electrician.
Touching some of the internal components can cause serious personal injury or death.
Do not disassemble this appliance.
Electric Shock Hazard
(grounding) plug
Three-pronged
EN-6
Improper use of the grounding can result
in a risk of electric shock
.
GROUNDING INSTRUCTIONS
EN-8
A short power-supply cord is provided to reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
Longer cord sets or extension cords are available and may be used if care is
exercised in their use.
If a long cord sets or extension cord is used:
a.
b.
c.
The marked electrical rating of the cord set or extension marked electrial rating of
the cord set or extension cord should be at least as great as the electrical rating of
the appliance.
The extension cord must be a grounding -type 3-wire cord.
The longer cord should be arranged so that it will not drape over the countertop or
tabletop where it can be pulled on by children or tripped over unintentionally.
Consult a qualified electrician or serviceman if the grounding instructions are not
completely understood or if doubt exists as to whether the appliance is properly
grounded. If it is necessary to use an extension cord, use only a 3-wire extension cord
that has a 3-pronged grounding plug , and a 3-slot receptacle that will accept the plug on
the appliance.The marked rating of the extension cord shall be equal to or greater than
the electrical rating of the appliance.
1.
2.
3.
EN-7
GROUNDING INSTRUCTIONS
GROUNDING INSTRUCTIONS
Operation of the microwave oven may cause interference to your radio, TV or similar
equipment.
When there is interference, it may be reduced or eliminated by taking the following
measures:
a.
b.
c.
d.
e.
Clean door and sealing surface of the oven.
Reorient the receiving antenna of radio or television.
Relocate the microwave oven with respect to the receiver.
Move the microwave oven away from the receiver.
Plug the microwave oven into a different outlet so that microwave oven and
receiver are on different branch circuits.
RADIO INTERFERENCE
EN-8
UTENSILS
See the instructions on "Materials you can use in microwave oven or to be avoided in
microwave oven." There may be certain non-metallic utensils that are not safe to use for
microwaving. If in doubt, you can test the utensil in question following the procedure
below.
Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil
in question.
Cook on maximum power for 1 minute.
Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave
cooking.
Do not exceed 1 minute cooking time.
1.
2.
3.
4.
Tightly-closed utensils could explode. Closed containers should be opened and plastic
pouches should be pierced before cooking.
UTENSIL TEST:
CAUTION
Electric Shock Hazard
EN-9
GROUNDING INSTRUCTIONS
HOUSEHOLD INDOOR USE ONLY
SAVE THESE INSTRUCTIONS
Shelding only. Small smooth pieces can be used to cover thin
parts of meat or poultry to prevent overcooking. Arcing can occur if
foil is too close to oven walls. The foil should be at least 1
inch (2.5cm) away from oven walls.
MATERIALS YOU CAN USE IN MICROWAVE OVEN
UTENSILS
Aluminum foil
REMARKS
Follow manufacturer’s instructions.The bottom of browning dish
must be at least 3/16 inch (5mm) above the turntable. Incorrect
usage may cause the turntable to break.
Browning dish
Microwave-safe only. Follow manufacturer’s instructions. Do not
use cracked or chipped dishes.
Dinnerware
Always remove lid. Use only to heat food until just warm. Most
glass jars are not heat resistant and may break.
Glass jars
Heat-resistant oven glassware only. Make sure there is no metallic
trim. Do not use cracked or chipped dishes.
Glassware
Follow manufacturer’s instructions. Do not close with metal tie.
Make slits to allow steam to escape.
Oven cooking bags
Use for short–term cooking/warming only. Do not leave oven
unattended while cooking.
Paper plates and cups
Use to cover food for reheating and absorbing fat. Use with
supervision for a short-term cooking only.
Paper towels
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Microwave-safe only ( meat and candy thermometers).
Use as a cover to prevent splattering and retain moisture.
Parchment paper
Microwave-safe only. Follow the manufacturer’s instructions.
Should be labeled "Microwave Safe". Some plastic cont ainers
soften, as the food inside gets hot. "Boiling bags" and tightly closed
plastic bags should be slit, pierced or vented as directed by
package.
Plastic
Wax paper
Thermometers
Plastic wrap
EN-10
UTENSILS REMARKS
MATERIALS TO BE AVOIDED IN MICROWAVE OVEN
May cause arcing. Transfer food into microwave-safe dish.
Aluminum tray
Metal twist ties
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
Food carton with
metal handle
Paper bags
May cause a fire in the oven.
Plastic foam
Wood
Plastic foam may melt or contaminate the liquid inside when
exposed to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
EN-11
SETTING UP YOUR OVEN
NAMES OF OVEN PARTS AND ACCESSORIES
Glass tray 1
Turntable ring
1
Instruction Manual 1
Grill Rack (Only be used in Convection
function and be placed on the glass tray)
Control panel
Turntable shaft
Turntable ring
Glass tray
Observation window
Oven Door
Safety interlock system
A.
B.
C.
D.
E.
F.
G.
EN-12
F
G
A
C B
E
D
Remove the oven and all materials from the ca rton and oven cavity. Your
oven comes with the following accessories:
SETTING UP YOUR OVEN
TURNTABLE INSTALLATION
a. Never place the glass tray upside down. The glass tray should never be restricted.
b. Both glass tray and turntable ring must always be used during cooking.
c. All food and containers of food are always placed on the glass tray for cooking.
Turntable ring
Turntable shaft
Hub (underside)
Glass tray
EN-13
SETTING UP YOUR OVEN
COUNTERTOP INSTALLATION
INSTALLATION
1.
Remove all packing material and accessories. Examine the oven for any damage such as dents or
broken door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not remove
the light brown Mica cover that is attached to the oven cavity to protect the magnetron.
Select a level surface that provide enough open space for the intake and/or
outlet vents.
A minimum clearance of 3.0 inches (7.5cm) is required between the oven and any adjacent walls. One
side must be open.
(1)
(2)
(3)
(4)
Leave a minimum clearance of 12 inches (30cm) above the oven.
Do not remove the legs from the bottom of the oven.
Blocking the intake and/or outlet openings can damage the oven.
Place the oven as far away from radios and TV a s possible.
Operation of microwave oven may cause interference to your radio or TV reception.
EN-14
OPEN
12 inches(30cm )
3.0 inches( 7.5cm )
3.0 inches(
7.5cm)
SETTING UP YOUR OVEN
INSTALLATION
2.
Plug your oven into a standard household outlet. Be sure the voltage and the
WARNING
Do not install oven over a range cooktop or other heat-producing appliance. If
installed near or over a heat source, the oven could be damaged and the
warranty would be avoid.
The accessible surface may
be hot during operation
EN-15
the frequency is the same as the voltage and the frenquency on the
rating label.
OPERATION
CONTROL PANEL AND FEATURES
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
(15)
(17)
Microwave
Auto Menu (Auto Bake, Auto Roast, Popcorn)
Sensor Menu (Sensor Cook, Sensor Reheat)
Auto Defrost
More
Number Pads
Timer/Clock
START ADD 30 SEC
Convection
Combination
Favorite
Warm Hold
Time Defrost
Less
Power Level
STOP Cancel Hold 3 sec: Before
cooking starts, press to clear all
previous settings. During cooking,
press once to stop oven; press twice
to stop oven and clear all settings.
Display
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(10)
(11)
(12)
(13)
(15)
(16)
(14)
(9)
(17)
EN-16
(16)
1.POWER LEVELS
OPERATION
Prior to or during cooking, press Power Level and "PL10" will display. Press Power Level
pad, a number pad to select a different power level.
2.CLOCK SETTING
(1)
(2)
(3)
Press Timer/Clock twice, "00:00" will appear in the display. The first set of zeros will
flash; ":" and the other zero set will be lighted.
Press the number pads to enter the current clock time. For example, if the time is now
10:12, press " 1, 0, 1, 2 " in order.
Press Timer/Clock to finish clock setting, " : " will flash and the numbers will appear
as a clock time in the display.
NOTE:
If the numbers entered are not within the range between 1:00 to 12:59, the setting will
not be accepted until valid numbers are entered.
In the process of setting clock, if the pad is pressed or if there is no operation
within 1 minute, the display will automatically return to the previous clock setting.
Ten power levels are available.
When the microwave oven is plugged into an outlet, "0:00" will display.
EN-17
Level 10 9 8 7 6 5 4 3 2 1
Power 100% 90% 80% 70% 60% 50% 40% 30% 20% 10%
Display PL10 PL 9 PL 8 PL 7 PL 6 PL 5 PL 4 PL 3 PL 2 PL 1
Press Timer/Clock once, "00:00" and "Timer" will appear in the display.
Press the number pads to enter the time amount. The maximum amount of time that
can be entered is 99 minutes, 99 seconds.
Press to confirm setting, the timer indicator will flash, and the timer will start
to count down.
When the time amount elapses, timer indicator will disappear. The oven will beep 5
times. "End" will display. The time of day will display by opening the door or pressing
.
OPERATION
Press Micro , "00:00" and "Cook" will appear in the display.
Press number pads to enter the cooking time. The maximum cooking time is 99
minutes,99 seconds.
Press Power Level; PL10 will flash. Press Power Level several times or pads 0
through 9 to select a different power level if desired. See the POWER LEVEL table
above.
Press to start cooking. The remaining cooking time will display. "Cook"
will flash.
a.
b.
c.
d.
Press Micro , "00:00" and "Cook"will display.
Press "1, 5, 0, 0" in order for 15:00 to appear in the display.
Press Power Level , then press "5" to select 50% microwave power.
Press to start cooking. Buzzer sounds once. The remaining cooking
time will display. "Cook" will flash.
4.MICROWAVE COOK
(1)
(2)
(3)
(4)
3. KITCHEN TIMER
(1)
(2)
(3)
(4)
Note:
The Kitchen Timer setting is different from the Clock setting; it is simply a timer.
During the Kitchen Timer function, no cooking function can be set into operation.
Kitchen Timer amount cannot be increased by pressing .
Pressing will cancel the Timer countdown.
Example: To cook the food with 50% microwave power for 15 minutes.
EN-18
NOTE:
In the process of setting, if the pad is pressed or if there is no operation within
1 minute, the oven will automatically return to display the clock.
OPERATION
Press Conv. once, "350" will flash. "Conv.", "F" and corresponding temperature icons
will display.
Press Conv. more times or press More or Less to choose the desired cooking
temperature.Temperature selections (
°
100 F):170, 250, 275, 300, 325, 350, 375,
400, 425. Press to confirm.
Press to start preheating. When the oven preheats to the selected cooking
temperature,it will beep twice; open the door and place food in oven.
Press number pads to enter the cooking time. The maximum cooking time is 99
minutes, 99seconds. "F" will disappear.
Press to start cooking. The remaining cook time will display. "Conv." and
corresponding temperature icons will flash.
5. CONVECTION COOK
(1)
(2)
(3)
(4)
(5)
NOTE:
If no preheat needed, skip step 3 above.
If preheating, do not place food into oven until cooking temperature is reached.
If Convection Cooking without preheating, place food into oven at the start of cooking.
Once the oven preheats to the selected cooking temperature, the oven will beep twice to
remind you to enter the cook time, and the temperature will flash. If no operation in 5
minutes, the oven will beep 5 times and return to display the clock.
The oven must preheat to the selected cooking temperature, and the oven door must be
opened before convection cooking time can be entered.
EN-19
NOTE:
Warm Hold function can be entered after cooking. The oven will beep twice to denote
entering Warm Hold function.
Warm Hold function can be used after Microwave cook, Convection cook, Combination
cook, Defrost cook and Multi-stage cooking.
The maximum cook time of Warm Hold function is 99 minutes.
Cooking will be canceled if you open the door or press during Warm Hold
function.
Press Timer/Clock once, "00:00" and "Timer" will appear in the display.
Press the number pads to enter the time amount. The maximum amount of time that
can be entered is 99 minutes, 99 seconds.
Press to confirm setting, the timer indicator will flash, and the timer will start
to count down.
When the time amount elapses, timer indicator will disappear. The oven will beep 5
times. "End" will display. The time of day will display by opening the door or pressing
.
Press Warm Hold, "Hold" will display.
Press to start cooking. The remaining defrost time will count down from
99 minutes.
7.WARM HOLD FUNCTION
(1)
(2)
OPERATION
Press Combi, "350" will flash. "Cook" , "Conv." , "F" and corresponding temperature
icons will display.
Press Combi more times or press More or Less to choose the cooking temperature.
Temperature selections (° F): 170, 250, 275, 300, 325, 350, 375,400,425.
Press number pads to enter the cooking time. The maximum cooking time is 99
minutes, 99 seconds. "F" will disappear.
Press to start cooking. The remaining cook time will display. "Conv."and
corresponding temperature icons will flash.
6.COMBINATION FUNCTION (CONVECTION + MICROWAVE)
(1)
(2)
(3)
(4)
Press to confirm.
EN-20
Press Time Defrost , "00:00", "Cook" and "DEF." will appear in the display.
Press the number pads to input the defrost time.
Press to start defrosting. "Cook" and "DEF." will flash, and the remaining
defrost time will display.
Instant cooking at 100% power level and 1 to 6 minutes cooking time can be started
by pressing number pads 1 to 6. Press to increase the cooking time by 30
seconds with each press. The maximum cooking time is 99 minutes, 99 seconds.
Instant cooking at 100% power level and 30 seconds cooking time can be started by
pressing . Each repeated press will increase cooking time by 30 seconds.
The maximum cooking time is 99 minutes, 99 seconds.
During cooking, press More or Less pad to increase or decrease cooking time by 10
seconds.
NOTE:
Time can also be added in 30 seconds increments by pressing during Microwave
Cooking, Time Defrost and Multi-stage Cooking.
Time cannot be added by pressing during Weight Defrost and Kitchen Timer
functions.
OPERATION
8.ONE TOUCH START
(1)
(2)
(3)
9.TIME DEFROST
(1)
(2)
(3)
EN-21
Press number pads to enter the weight to be defrosted. See table above.If the weight
input is not between the weight range listed on the table above, the input will be
invalid. The unit will not work until valid numbers are entered.
Press to start defrosting and the remaining cooking time will be displayed.
"Cook" and "DEF." indicator will flash.
NOTE:
During cooking of meat, poultry and Fish, the oven will beep twice to remind you to turn
over the food.
Open the door to pause operation. Turn over food, close the door and press to
resume defrost cycle. If you do not open door to pause operation, the oven will continue
the defrost cycle without interruption.
10.Auto Defrost Function
(1)
(2)
Press Auto Defrost , "dEF1" , "Cook" and "DEF." will appear in the display.
Press Auto Defrost more times or press More / Less pad to choose the defrost food
type, "dEF1" through "dEF4". See table below.
LED display
Food
Weight
dEF1
Meat
0.1-6.0 Lbs
dEF2
Poultry
0.1-6.0 Lbs
dEF3
Fish
0.1-6.0 Lbs
dEF4
Bread
0.1-1.0 Lbs
(3)
(4)
OPERATION
EN-22
Press Auto Bake, "Ab-1", "Cook", "Conv." and "Auto" will display.
Press Auto Bake more times to choose the menu, "Ab-1" though "Ab-4". See Auto
Bake Chart below.
For Ab-1, Ab-2 and Ab-3, press number pad 1 to choose the default weight or
portion. Press to start cooking.
For Ab-4, press number pads to adjust the portion or weight. Press to start
cooking. The remaining cooking time and corresponding temperature icons will
display. "Conv." and "Auto" will flash.
11.AUTO BAKE FUNCTION
(1)
(2)
(3)
Press Auto Roast, "Ar-1", "Cook", "Conv." and "Auto" will display.
Press more times to choose the menu, "Ar-1" through "Ar-4". See Auto Roast Chart
Auto Roast below.
Press number pads to adjust the weight or portion.
Press to start cooking. The remaining cooking time and corresponding
temperature icons will display. "Cook", "Conv." and "Auto" will flash.
12.AUTO ROAST FUNCTION
(1)
(2)
(3)
(4)
AUTO BAKE CHART:
AUTO BAKE CHART:
Food
Frozen Pizza
Muffins
Biscuit/DinnerRoll/Bread Stick
Frozen French Fries
Display
Ab-1
Ab-2
Ab-3
Ab-4
Weight/Portion
10 oz
6 each
7 oz
4-16 oz
Food
Beef
Whole Chicken
Turkey Breasts
Pork
Display
Ar-1
Ar-2
Ar-3
Ar-4
Weight/Portion
2.0-4.0 Lbs
2.5-6.0 Lbs
3.0-6.0 Lbs
2.0-4.0 Lbs
OPERATION
EN-23
Press Sensor Cook, "SC-1", "SEN." and "Auto" will display.
Press Sensor Cook more times or press number pads to choose the type of food.
Press to start cooking. "SC-", "SEN." and "Auto" will flash. Once the item has
been sensed, the remaining cooking time will display. "SEN.", "Cook" and "Auto" will
flash.
Food
Beef
Whole Chicken
Turkey Breasts
Pork
Weight/Portion
2.0-4.0 Lbs
2.5-6.0 Lbs
3.0-6.0 Lbs
2.0-4.0 Lbs
Auto Bake Chart:
Food
Potato
Fresh Vegetable
Frozen Vegetable
Frozen Entree
Rice
Casserole
Ground Meat
Fish/Seafood
Scrambled Eggs
Frozen Pizza
Display
SC-1
SC-2
SC-3
SC-4
SC-5
SC-6
SC-7
SC-8
SC-9
SC-0
Pad
1
2
3
4
5
6
7
8
9
0
Weight/Portion
1-4 PCS (8-10 oz/PCS)
1-4 CUP (250 ml/cup)
1-4 CUP (250 ml/cup)
10-20 oz
1-2 CUP(220 g/cup)
1-4 CUP(250 ml/cup)
4-32 oz
4-32 oz
2-5 each
6-12 oz
13. Sensor Cook
(1)
(2)
(3)
OPERATION
EN-24
Press Sensor Reheat , "Sr-1", "SEN." and "Auto" will display.
Press Sensor Reheat more times or press number pads 1 through 3 to choose the
type of food.
Press to start cooking. "Sr-", "SEN." and "Auto" will flash. Once the item has
been sensed, the remaining cooking time will flash. "SEN." , "Cook" and "Auto" will
flash.
14. SENSOR REHEAT
(1)
(2)
(3)
Press Popcorn , "1.75", "Auto" , "Cook" and "Oz" will appear in the display.
Press Popcorn two more times or press More or Less to choose the weight, "3.0" and
"3.5" will display in order.
Press to cook. "Oz" disappears. "Auto" and "Cook" will flash. The remaining
time will display.
15. POPCORN
(1)
(2)
(3)
Auto Bake Chart:
Food
Dinner Plate
Soup/Sauce
Casserole
Display
Sr-1
Sr-2
Sr-3
Weight/Portion
8-24 oz
1-4 CUP (250 ml/cup)
1-4 CUP (250 ml/cup)
OPERATION
EN-25
Press Favorite to program and choose up to three cooking procedures.Each
procedure will be indicated by 1, 2 or 3 in the display.
Press Favorite until your desired procedure number appears in the display.
Press to begin it. A maximum of two cooking stages can be set for each
procedure.
To program a procedure, follow the steps listed below. Example: Cook food at 80%
Power Level for 3 minutes and 20 seconds; save as memory 2.
16. FAVORITE FUNCTION
(1)
(2)
(3)
Press Favorite twice; screen displays 2.
Press Micro , then press "3" , "2" and "0" in order.
Press Power Level once, then press "8" for "PL 8" to display.
Press Favorite to save the procedure. Oven beeps once.
Or press directly to save and start cooking.
To choose the procedure from the memory list, press Favorite twice.
Screen will display "2". Press to run procedure.
a.
b.
c.
d.
e.
NOTE:
Auto Menu cannot be set in Favorite function.
OPERATION
EN-26
At most 2 stages can be set for cooking. If one stage is Defrost, it will automatically set
to be the first stage.
17.Muti-Stage Cooking
EXAMPLE: 80% Power Level for 5 minutes followed by 60% Power Level for 10
minutes; saved as memory 3.
NOTE: Auto Menu and Preheat cannot be set in Multi-stage Cooking.
Press Favorite 3 times; screen displays 3.
Press Micro, then press "5" , "0" and "0" to set first stage cook time.
Press Power Level once, then press "8" to choose 80% first stage cooking power.
Press Micro again, then press "1", "0", "0" and "0" to set second stage cook time.
Press Power Level again, then press "6" to choose 60% second stage cooking
power.
Press to immediately start multi-stage cooking.
To choose the procedure from the memory list, press Favorite three times. Screen
will display "3"; press to run procedure.
a.
b.
c.
d.
e.
f .
g.
When oven is cooking, press Timer/Clock for the time of day to appear for three
seconds in the display.
When oven is cooking, press Conv., Power Level or Combi pads for cooking power
to appear for three seconds in the display.
18.INQUIRING FUNCTION
(1)
(2)
NOTE:
If you do not want to save a particular multi-stage program as a procedure, do not press
Favorite as the first step. Press after programming both stages.
OPERATION
EN-27
To lock the microwave so that it cannot be operated by children or other unintended
users, press pad for 3 seconds. You will hear a long beep. "LOC" will display.
To unlock, press for 3 seconds, you will hear a long beep and "LOC" will
disappear.
If the clock has been set, the oven will return to display the clock. Otherwise, "0:00"
will display.
20.Cooking End Reminder Function
The oven will beep five times to alert the user that cooking time has ended. "End" will
display. The time of day will display by opening the door or pressing pad.
must be pressed to continue cooking if the door is opened during cooking.
A single beep sounds to indicate that a pad is correctly pressed; if pad is not correctly
pressed, no beep sounds.
21.Other Specifications
(1)
(2)
19.LOCK FUNCTION
(1)
(2)
OPERATION
EN-28
MAINTENANCE
Cooking time,
power level is not suitable.
Use correct cooking time,
power level.
Check your problem by using the chart below and try the solutions for each problem.
TROUBLESHOOTING
TROUBLE
Oven will not start
Arcing or sparking
Unevenly cooked foods
Overcooked foods
Undercooked foods
Improper defrosting
Sensor cooked foods
not properly cooked
Cover or lid over food must contain
vent hole for escaping steam.
Do not open door to stir orturn food
before sensor-detected cooking time
appears in display.
a.
b.
a.
b.
c.
Materials to be avoided
inmicrowaveoven were used.
Cooking time, power level is not
suitable.
Food is not turned or stirred.
a.
b.
c.
d.
Use microwave-safe cookware only.
Completely defrost food.
Use correct cooking time, power level.
Turn or stir food.
a.
b.
c.
d.
Materials to be avoided in microwave
oven were used.
Food is not defrosted completely.
Cooking time, power level is not
suitable.
Food is not turned or stirred.
a.
b.
c.
Materials to be avoided in microwave
oven were used.
The oven is operated when empty.
Spilled food remains in the cavity.
a.
b.
c.
Use microwave-safe cookware only.
Do not operate with oven empty. Clean
cavity with wet towel.
a.
b.
c.
Plug into the outlet.
Close the door and try again.
Check instructions
a.
b.
c.
Electrical cord for oven is not
plugged in.
Door is open.
Wrong operation is set.
a.
b.
c.
Use microwave-safe cookware only.
Use correct cooking time, power level.
Turn or stir food
a.
b.
c.
d.
Use microwave-safe cookware only.
Completely defrost food.
Check to see that oven venti-lation
ports are not restricted.
Use correct cooking time, power level
a.
b.
c.
d.
Materials to be avoided in microwave
oven were used.
Food is not defrosted completely.
Oven ventilation ports are restricted.
Cooking time, power level is not suitable.
Cover or lid on food not vented.
Door opened before sensor-detected
cooking time appears in display.
a.
b.
Possible Cause
Possible Remedy
EN-29
EN-30
ONE YEAR LIMITED WARRANTY
This product carries a warranty stating that it will be free from defects in material and
workmanship for a period of one year from the date of purchase. This warranty is valid
for the original retail purchaser from the date of initial retail purchase and is not
transferable. Keep your original sales receipt.
IMPORTANT:
If service is required during the warranty period, properly pack your unit. We
If additional assistance is needed, please contact
recommend using the original carton and packing materials.
customer assistance at:
Some states do not allow this exclusion
quential losses so the foregoing disclaimer may not
rights which may vary from state to state.
SAVE THIS FOR YOUR RECORDS
Made in China
apply to you. This warranty gives you specific legal rights, and you may also have other
expressly disclaims all responsibility for consequential damages or Midea America Corp
incidental losses caused by use of the appliance.
or limitation of incidental or conse
The serial number can be found on the back cabinet. We suggest that you record the
serial number of your unit in the space below for future reference
Model Number:_______________________
Serial Number:________________________
800-842-1289
Midea Am erica Corp
.
5 Sylvan Way,
Parsippany, NJ 07054
1. This warranty does not cover damages resulting from accident, misuse or abuse,
lack of reasonable care, the affixing of any attachments not provided with the
product, loss of parts, or subjecting the appliance to any but the specified
voltage. ( Read directions carefully. )
2. This warranty is void if this product is ever used for other than private household
purposes.
3. This warranty is void if this product is ever used outside of United State .
s
Customer Assistance: 800-842-1289
Midea America Corp
5 Sylvan Way, Parsippany, NJ 07054
PN.:16170000A58904
