MICROWAVE OVEN
INSTRUCTION MANUAL
ML-EC42P(SS)
Please review this instruction manual before operating.
CONTENTS
PRODUCT SAFETY
Precautions to avoid possible exposure to excessive microwave energy
Important safety instructions
Grounding instructions
Radio interference
Utensils
Materials you can use in microwave oven
Materials can not be used in microwave oven
01
03
07
09
10
11
13
PRODUCT SETTING
Setting up your oven
14
INSTRUCTION FOR USE
Before using for the first time
Operation
1. Power levels
2. Clock setting
3. Kitchen timer
4. Microwave cook
5. Convection cook
6. Combination function (convection + microwave)
7. Warm hold function
8. One touch start
9. Time defrost
17
18
19
19
20
20
21
22
23
23
24
10. Auto defrost function
11. Auto bake & roast function
12. Sensor cook
13. Sensor reheat
14. Popcorn
15. Air fry
16. Favorite function
17. Muti-stage cooking
18. Turn on/off the buzzer sound
19. Energy saver mode
20. Lock function
21. Cooking end reminder function
22. Other specifications
23. Turntable reset function
24. Inquiring function
Cleaning
24
25
26
26
27
27
2
30
31
31
31
31
32
32
32
33
MAINTENANCE
Trouble shooting
One year limited warranty
35
36
9
BEFORE OPERATING THIS PRODUCT, READ,
UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
BE SURE TO SAVE THIS BOOKLIST FOR FUTURE
REFERENCE.
NOTE
01
PRODUCT SAFETY
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
(a). Do not attempt to operate this oven with the door open
since open door operation can result in harmful exposure to
microwave energy.
It is important not to defeat or tamper with the safety
interlocks.
(b). Do not place any object between the
oven front face and the door or allow
soil or cleaner residue to accumulate on
sealing surfaces.
(c). Do not operate the oven if it is damaged. It is particularly
important that the oven door closes properly and that there is
no damage to the:
(1). DOOR (bent)
(2). HINGES AND LATCHES (broken or loosened)
(3). DOOR SEALS AND SEALING SURFACES
(d). The oven should not be adjusted or repaired by anyone
except properly qualied service personnel.
02
SPECIFICATIONS
MODEL
ML-EC42P(SS)
RATED VOLTAGE
120V~ 60Hz
RATED INPUT POWER (MICROWAVE)
1500W
RATED OUTPUT POWER (MICROWAVE)
1000W
RATED INPUT POWER (CONVECTION)
1750W
All pictures in this manual are for illustrative purposes only; these may be
slightly different from the purchased equipment, please refer to the
actual product.
NOTE
OVEN CAPACITY
1.5 cu.ft.
TURNTABLE DIAMETER
1 inch
EXTERNAL DIMENSIONS
NET WEIGHT
Approx. 45.5 lbs
21.77x21.5x12.99 inch
3.6
03
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before
using the appliance.
Read and follow the
specific:
"PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE
ENERGY" found on page 1.
This appliance must be
grounded. Connect only to
properly grounded outlet.
See "GROUNDING
INSTRUCTIONS" found on
page 7.
Install or locate this
appliance only in
accordance with the
provided installation
instructions.
As with any appliance,
close supervision is
necessary when used by
children.
This appliance should be
serviced only by qualified
service personnel. Contact
nearest authorized service
facility for examination,
repair, or adjustment.
When cleaning surfaces
of door and oven that
comes together on closing
the door, use only mild,
nonabrasive soaps, or
detergent applied with a
sponge or soft cloth.
When using electrical appliances basic safety
precautions should be followed, including the
following. To reduce the risk of burns, electric shock,
re, injury to persons or exposure to excessive
microwave energy.
WARNING
04
Liquids, such as water,
coee, or tea are able
to overheat beyond the
boiling point without
appearing to be boiling.
Visible bubbling or boiling
when the container
is removed from the
microwave oven is not
always present.
THIS COULD RESULT
IN VERY HOT LIQUID
SUDDENLY BOILING OVER
WHEN THE CONTAINER IS
DISTURBED OR A UTENSIL
IS INSERTED INTO THE
LIQUID. To reduce the risk
of injury to persons:
1. Do not overheat the
liquid.
2. Stir the liquid both
before and halfway
through heating it.
3. Do not use straight-
sided containers with
narrow necks.
4. After heating, allow
the container to stand
in the microwave oven
for a short time before
removing the container.
5. Use extreme care when
inserting a spoon or
other utensil into the
container.
Keep cord away from
heated surface.
Oversized food or
oversized metal utensils
should not be inserted in
a microwave/toaster oven
as they may create a fire or
risk of electric shock.
IMPORTANT SAFETY INSTRUCTIONS
05
To reduce the risk of fire in
the oven cavity:
1. Do not overcook
food. Carefully attend
appliance when
paper, plastic, or other
combustible materials
are placed inside
the oven to facilitate
cooking.
2. Remove wire twist-ties
from paper or plastic
bag before placing bag
in oven.
3. If material inside of the
oven ignite, keep oven
door closed, turn oven
o, and disconnect the
power cord, or shut o
power at the fuse or
circuit breaker panel.
4. Do not use the cavity
for storage purposes.
Do not leave paper
products, cooking
utensils, or food in the
cavity when not in use.
Do not cover or block any
openings on the appliance.
Some products such as
whole eggs and sealed
containers, for example,
closed glass jars are able to
explode and should not be
heated in this oven.
Do not store this appliance
outdoors. Do not use this
product near water - for
example, near a kitchen
sink, in a wet basement,
near a swimming pool, or
similar location.
Do not immerse cord or
plug in water or any other
liquid.
IMPORTANT SAFETY INSTRUCTIONS
06
IMPORTANT SAFETY INSTRUCTIONS
Use this appliance only
for its intended use as
described in the manual.
Do not use corrosive
chemicals or vapors in
this appliance. This type
of oven is specifically
designed to heat, cook or
dry food.
It is not designed for
industrial or laboratory use.
Do not operate this
appliance if it has a
damaged cord or plug, if it
is not working properly, or
if it has been damaged or
dropped.
Do not clean with metal
scouring pads.
Pieces can burn o the pad
and touch electrical parts
involving a risk of electric
shock.
Do not let cord hang over
edge of table or counter.
Do not use paper products
when appliance is operated
in the toaster mode.
Do not store any materials,
other than manufacturer's
recommended accessories,
in this oven when not in
use.
Do not cover racks or any
other part of the oven with
metal foil. This will cause
over-heating of the oven.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY(NOT FOR
COMMERCIAL USE)
07
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electric current. This appliance is
equipped with a cord having a grounding wire with a grounding
plug. The plug must be plugged into an outlet that is properly
installed and grounded.
WARNING - Improper use of the grounding can result in a risk of
electric shock. Consult a qualified electrician or serviceman if the
grounding instructions are not completely understood, or if doubt
exists as to whether the appliance is properly grounded. If it is
necessary to use an extension cord, use only a 3-wire extension
cord that has a 3-blade grounded plug, and 3-slot receptacle
that will accept the plug on the appliance. The marked rating of
the extension cord shall be equal to or greater than the electrical
rating of the appliance.
Electric Shock Hazard:
Touching some of the internal components can
cause serious personal injury or death. Do not
disassemble this appliance.
DANGER
08
GROUNDING INSTRUCTIONS
Electric Shock Hazard:
Improper use of the grounding can result in electric
shock. Do not plug into an outlet until appliance is
properly installed and grounded.
1. A short power-supply cord is provided to reduce
the risks resulting from becoming entangled in or
tripping over a longer cord.
2. Longer cord sets or extension cords are available
and may be used if care is exercised in their use.
3. If a long cord or extension cord is used:
(1). The marked electrical rating of the cord set or
extension cord should be at least as great as
the electrical rating of the appliance.
(2). The extension cord must be a grounding-type
3-wire cord.
(3). The longer cord should be arranged so that it
will not drape over the counter top or tabletop
where it can be pulled on by children or
tripped over unintentionally.
WARNING
09
RADIO INTERFERENCE
1. Operation of the microwave oven may cause interference to
your radio, TV or similar equipment.
2. When there is interference, it may be reduced or eliminated by
taking the following measures:
(1). Clean door and sealing surface of the oven.
(2). Reorient the receiving antenna of radio or television.
(3). Relocate the microwave oven with respect to the receiver.
(4). Move the microwave oven away from the receiver.
(5). Plug the microwave oven into a dierent outlet so that
microwave oven and receiver are on dierent branch circuits.
This device complies
with part 18 of the FCC
Rules.
10
UTENSILS
Personal Injury Hazard:
Tightly-closed utensils could explode. Closed
containers should be opened and plastic pouches
should be pierced before cooking.
See the instructions on "Materials you can use in
microwave oven ." or "Materials can not be used
in micro wave oven."
There may be certain non-metallic utensils that are
not safe to use for microwaving. If in doubt, you can
test the utensil in question following the procedure
below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup
of cold water (250ml) along with the utensil
in question.
2. Cook on maximum power for 1 min.
3. Carefully feel the utensil. If the empty
utensil is warm, do not use it for microwave
cooking.
4. Do not exceed 1 min cooking time.
KEEP THE CAVITY CLEAN
CAUTION
NOTE
11
MATERIALS YOU CAN USE IN
MICROWAVE OVEN
UTENSILS REMARKS
Browning dish
Follow manufacturer’s instructions.
The bottom of browning dish must be at least 3/16 inch
(5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Dinnerware
Microwave-safe only. Follow manufacturer’s
instructions. Do not use cracked or chipped dishes.
Glass jars
Always remove lid. Use only to heat food until just
warm. Most glass jars are not heat resistant and may
break.
Glassware
Heat-resistant oven glassware only. Make sure there is
no metallic trim. Do not use cracked or chipped dishes.
Oven cooking bags
Follow manufacturer’s instructions. Do not close with
metal tie.
Make slits to allow steam to escape.
Paper plates and cups
Use for short–term cooking/warming only. Do not leave
oven unattended while cooking.
Paper towels
Use to cover food for reheating and absorbing fat. Use
with supervision for a short-term cooking only.
Parchment paper
Use as a cover to prevent splattering or a wrap for
steaming.
Plastic
Microwave-safe only. Follow the manufacturer’s
instructions. Should be labeled “Microwave Safe”. Some
plastic containers soften, as the food inside gets hot.
“Boiling bags” and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
12
UTENSILS REMARKS
Plastic wrap
Microwave-safe only. Use to cover food during cooking
to retain moisture. Do not allow plastic wrap to touch
food.
Thermometers
Microwave-safe only (meat and candy thermometers).
Wax paper
Use as a cover to prevent splattering and retain
moisture.
MATERIALS YOU CAN USE IN
MICROWAVE OVEN
13
MATERIALS CAN NOT BE USED IN
MICROWAVE OVEN
UTENSILS REMARKS
Aluminum tray
May cause arcing. Transfer food into microwave-safe
dish.
Food carton with metal
handle
May cause arcing. Transfer food into microwave-safe
dish.
Metal or metal trimmed
utensils
Metal shields the food from microwave energy.
Metal trim may cause arcing.
Metal twist ties
May cause arcing and could cause a fire in the oven.
Paper bags
May cause a fire in the oven.
Plastic foam
Plastic foam may melt or contaminate the liquid
inside when exposed to high temperature.
Wood
Wood will dry out when used in the microwave oven
and may split or crack.
14
PRODUCT SETTING
SETTING UP YOUR OVEN
NAMES OF MICROWAVE OVEN PARTS AND ACCESSORIES
Remove the oven and all materials from the carton and oven cavity.
A. Control panel
B. Glass tray
C. Turntable shaft
D. Turntable ring assembly
E. Door assembly
F. Observation window
G. Safety interlock system
E
G
F
B
AD C
Grill Rack
(Can only be used without microwave function
and must be placed on the glass tray.)
Grill Tray
(Can only be used without microwave function
and must be placed on the grill rack.)
Instruction Manual
Glass Tray
(Can be used under all functions)
15
Cleaning the cooking compartment and putting the turntable in place.
For new installations, make sure all packaging and shipping tape has been removed from the
turntable shaft.
Before using the appliance to prepare food for the first time, you will need to put the turntable in
place correctly. You must clean the cooking compartment and accessories.
TURNTABLE INSTALLATION
1
2
3
SETTING UP YOUR OVEN
How to put the turntable in place:
1. Place the turntable ring assembly③ into the recess
in the cooking compartment.
2. Place the glass tray①on the turntable ring assembly③.
Fit the raised, curved lines in the center of the glass tray
bottom between the three spokes of the shaft.
Make sure that the glass tray①engages in the
turntable shaft② in the center of the cooking
compartment floor. The rollers on the shaft should fit inside
the turntable bottom ridge.
• Never use the appliance without the turntable. Make sure that it is
properly engaged. The turntable can turn clockwise or anti-clockwise.
• Never place the glass tray upside down. The glass tray should never
be restricted.
• Both glass tray and turntable ring assembly must always be used
during cooking.
• All food and containers of food are always placed on the glass tray
for cooking.
• Never restrict the movement of the turntable.
• If glass tray or turntable ring assembly cracks or breaks, contact your
nearest authorized service center.
NOTE
16
COUNTERTOP INSTALLATION
Remove all packing material and accessories. Examine the oven for any damage such as dents
or broken door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not
remove the light brown Mica cover that is attached to the oven cavity to protect the magnetron.
INSTALLATION
1. Select a level surface that provide enough open space for the intake and/or outlet vents.
A minimum clearance of 3.0 inches (7.5cm) is required between the oven and any adjacent walls.
One side must be open.
The minimum installation height is 3.0ft(91.4cm).
a. Leave a minimum clearance of 12 inches (30cm) above the oven.
b. Do not remove the legs from the bottom of the oven.
c. Blocking the intake and/or outlet openings can damage the oven.
d. Place the oven as far away from radios and TV as possible.
Operation of microwave oven may cause interference to your radio or TV reception.
2. Plug microwave oven into a standard household outlet. Be sure the voltage and the frequency
is the same as the voltage and the frenquency on the rating label.
Top
Right
DISTANCE
(INCHES/CM)
SIDE
Left
Front
Behind
12 inches/30cm
Open
3.0 inches/7.5cm
Open
3.0 inches/7.5cm
NOTE
12 inches(30cm )
3.0 inches
(7.5cm)
>3.0ft
(91.4cm)
3.0 inches
(7.5cm)
Open
• Do not install oven over a range cooktop
or other heat-producing appliance.
If installed near or over a heat source, the
oven could be damaged and the warranty
would be avoid.
The accessible surface may be
hot during operation
17
INSTRUCTION FOR USE
BEFORE USING FOR THE FIRST TIME
This section tells you what you need to do before using your microwave to prepare food for the
first time. Read the section entitled beforehand
"IMPORTANT SAFETY IN
Before you can use your new appliance, you will need to put the turntable in place correctly.
You must also clean the cooking compartment and accessories.
• Never use the appliance without the turntable.
• Make sure that it is properly engaged.The turntable can urn clockwise
or anti-clockwise.
NOTE
on
STRUCTIONS"
t
page 3.
The appliance may produce unpleasant odors when it is used for the first time.
18
OPERATION
CONTROL PANEL AND FEATURES
STOP/Cancel
START/+30Sec.
19
1. POWER LEVELS
Ten power levels are available.
Prior to cooking, press Power Level and "PL10" will display. Then press number pads to select a
different power level. Please refer to page 16 "MICROWAVE COOK" for detailed power level setting.
10
PL10
100%
9
PL9
90%
8
PL8
80%
7
PL7
70%
6
PL6
60%
5
PL5
50%
4
PL4
40%
3
PL3
30%
2
PL2
20%
1
PL1
10%
LEVEL POWER DISPLAY
2. CLOCK SETTING
When the microwave oven is plugged into an outlet, "0:00" will display.
Press Timer/Clock twice.
a
• If the numbers entered are not within the range between 1:00 to 12:59,
the setting will not be accepted until valid numbers are entered.
• In the process of setting clock, if the STOP/Cancel pad is pressed or
if there is no operation within 1 minute, the display will automatically
return to the previous clock setting.
Press Timer/Clock to finish clock setting.
c
Press the number pads to enter the current clock time.
b
NOTE
20
3. KITCHEN TIMER
4. MICROWAVE COOK
a
Press Micro once.
Press Power Level several times to select a different power
level if desired.
or
Press number pads to enter the cooking time.
The maximum cooking time is 99 minutes and 99 seconds.
b
Press Power Level once, pads 0 through
9 to select a different power level if desired.
See the POWER LEVEL table above.
• The Kitchen Timer setting is different from the Clock setting; it is simply
a timer.
• During the Kitchen Timer function, no cooking function can be set into
operation.
• Kitchen Timer amount cannot be increased by pressing START/+30Sec.
• Pressing STOP/Cancel will cancel the Timer countdown.
Press Timer/Clock once.
a
When it's time. The oven will beep 5 times. The time of day will display if the time has
been set.
d
Press START/+30Sec. to confirm setting, The countdown starts.
c
c
Press the number pads to enter the time amount.
The maximum time is 99 minutes and 99 seconds.
b
NOTE
21
Example : To cook the food with 50% microwave power for 15 minutes.
• Press Micro.
• Press Power Level , then press "5" .
• Press START/+30Sec. to start cooking. The countdown starts.
In the process of setting, if the STOP/Cancel pad is pressed or if there
is no operation within 1 minute, the oven will automatically return to
display the clock.
NOTE
Press START/+30Sec. twice to start preheating.
b
• Press the number pads to enter the current clock time.
Press START/+30Sec. to start cooking. The countdown starts.
d
5. CONVECTION COOK
a
Press Conv. more times to choose the desired cooking
temperature.
or
Press Conv.
once, press
More or Less
or number
pads to choose the desired cooking temperature. Temperature selections (° F):100,170, 250,
275, 300, 325, 350, 375, 400, 425.
or
22
• If no preheat needed, press START/+30Sec. once in step b and skip
• If Convection Cooking without preheating, place food into oven at the
start of cooking.
• If preheating, do not place food into oven until cooking temperature
is reached.
• Once the oven preheats to the selected cooking temperature, the oven
will beep once to remind you to enter the cook time, and the temperature
will flash. If no operation in 5 minutes, the oven will beep 5 times and
return to display the clock.
• The oven must preheat to the selected cooking temperature, and the oven
door must be opened before convection cooking time can be entered.
Press number pads to enter the cooking time.
The maximum cooking time is 99minutes and 99 seconds.
d
Press START/+30Sec. to start cooking. The countdown starts.
e
NOTE
When the oven preheats to the selected cooking temperature, it will beep twice; open the
door and place food in oven.
c
6. COMBINATION FUNCTION (CONVECTION + MICROWAVE)
Press START/+30Sec. to confirm.
b
Press Combo more times to choose the cooking temperature.
a or
Press Combo
once, press
More or Less
or number
pads to choose the cooking temperature. Temperature selections (° F): 170, 250, 275, 300,
325, 350, 375.
or
step c above.
23
7. WARM HOLD FUNCTION
• Warm Hold function can be used after Microwave cook, Convection
cook, Combination cook, Defrost cook and Multi-stage cooking.
• The maximum cook time of Warm Hold function is 99 minutes.
• Cooking will be canceled if you open the door or press STOP/ Cancel
during Warm Hold function.
Press Warm Hold.
a
b
Press START/+30Sec. to start cooking. The countdown starts.
NOTE
8. ONE TOUCH START
Instant cooking at 100% power level and 1 to 6 minutes cooking time can be started by
pressing number pads 1 to 6.
a
Press START/+30Sec. to increase the cooking time by 30 seconds
with each press. The maximum cooking time is 99 minutes,
99 seconds.
b
During cooking, press More or Less pad to increase or decrease
cooking time by 10 seconds.
c
Press START/+30Sec. to start cooking. The countdown starts.
d
Press number pads to enter the cooking time.
The maximum cooking time is 99minutes and 99 seconds.
c
• Time can also be added in 30 seconds increments by pressing START/+30Sec.
during Microwave Cooking, Time Defrost and Multi-stage Cooking.
• Time cannot be added by pressing START/+30Sec. during Weight
Defrost and Kitchen Timer functions.
NOTE
24
9. TIME DEFROST
Press the number pads to input the defrost time.
The maximum time is 99 minutes and 99 seconds.
b
Press Time Defrost once.
a
Press START/+30Sec. to start defrosting. The countdown starts.
c
c
Press START/+30Sec. to start defrosting. The countdown starts.
10. AUTO DEFROST FUNCTION
b
Press number pads to enter the weight to be defrosted.
If the weight input is not between the weight range listed on the
table above, the input will be invalid. The machine will not work.
Press Auto Defrost more timesto choose the defrost food type.
a or
Press Auto Defrost once,
press More or Less pad to choose the
defrost food type. See table below.
Meat
Poultry
Fish
Bread
0.1-6.0 Lbs
0.1-6.0 Lbs
0.1-6.0 Lbs
0.1-1.0 Lbs
FOOD WEIGHTLED DISPLAY
dEF1
dEF2
dEF3
dEF4
25
Frozen Pizza
Muffins
Biscuit/DinnerRoll/
Bread Stick
Frozen French Fries
Beef
Whole Chicken
Turkey Breasts
Pork
AUTO BAKE & ROAST CHART:
FOOD DISPLAY
WEIGHT/
PORTION
RECOMMENDED
GRILL
Ab-1
Ab-2
Ab-3
Ab-4
Ar-1
Ar-2
Ar-3
Ar-4
10 oz
6 each
7 oz
4-10 oz
2.0-4.0 Lbs
2.5-6.0 Lbs
3.0-6.0 Lbs
2.0-4.0 Lbs
Higher grill rack
Lower grill rack
Higher grill rack
Higher grill rack
Lower grill rack
Lower grill rack
Lower grill rack
Lower grill rack
11. AUTO BAKE & ROAST FUNCTION
Press Auto Bake & Roast more times to choose the menu
from "Ab-1" to "Ar-4".
a
For the Ab-1 to Ab-3 menu:
press the number 1 to confirm the weight
b
c
Press START/+30Sec. to start cooking. The countdown starts.
For the Ab-4 to Ar-4 menu:
press the number pads to adjust the weight.
• During cooking of meat, poultry and fish, the oven will beep twice to
remind you to turn over the food.
• Open the door to pause operation. Turn over food, close the door and
press START/+30Sec. to resume defrost cycle. If you do not open door
to pause operation, the oven will continue the defrost cycle without
interruption.
NOTE
26
12. SENSOR COOK
Press START/+30Sec. to start cooking.
Once the food has been sensed, the countdown starts.
b
SENSOR COOK CHART:
Potato
Fresh Vegetable
Frozen Vegetable
Frozen Entree
Rice
Casserole
Ground Meat
Fish/Seafood
Scrambled Eggs
Frozen Pizza
FOOD DISPLAY
PAD
WEIGHT/PORTION
SC-1
SC-2
SC-3
SC-4
SC-5
SC-6
SC-7
SC-8
SC-9
SC-0
1
2
3
4
5
6
7
8
9
0
1-4 PCS (8-10 oz/PCS)
1-4 CUP (8.5 oz/cup)
1-4 CUP (8.5 oz/cup)
10-20 oz
1-2 CUP(7.8 oz/cup)
1-4 CUP(8.5 ozcup)
4-32 oz
4-32 oz
2-5 each
6-12 oz
Press Sensor Cook more times to choose the type of food.
a
or
Press Sensor Cook once,
press number pads to choose the type
of food.
13. SENSOR REHEAT
Press START/+30Sec. to start cooking.
Once the food has been sensed, the countdown starts.
b
Press Sensor Reheat more times to choose the type of food.
a
or
Press Sensor Reheat once,
press number pads 1through 3 to
choose the type of food.
27
Auto Bake Chart:
Dinner Plate
Soup/Sauce
Casserole
FOOD DISPLAY
WEIGHT/PORTION
Sr-1
Sr-2
Sr-3
8-24 oz
1-4 CUP (8.5 oz/cup)
1-4 CUP (8.5 oz/cup)
14. POPCORN
Press START/+30Sec. to cook. The countdown starts.
b
Press Popcorn more times to choose the weight.
a
Press Popcorn
once, press
More or Less
or number
pads 1 through 3to choose the weight. You can choose 1.75 oz, 3.0 oz and 3.5 oz.
or
or
15. AIR FRY
a
Press “ AIR FRY” more times to select menu from H1 to H10.
Press “ AIR FRY” once, press the number
pads to select menu from H1 to H10.
a
b
Press “START/+30Sec.” three times to start cooking.
or
If you not to set the temperature and time, you need to:
28
If you want to set the temperature and time, you need to:
a
Refer to step a above to select the menu,press “START/+30Sec.”
confirmation menu.
b
In the
temperature
confirmation
interface, you
o
can select 350 ~ 425F with More or Less or number pads, and press the “START/+30Sec.” to
enter the time interface.
or
c
In the time confirmation interface,
you can add or subtract 30s with More
or Less or re-enter the time with the
number pads.
or
d
In the time confirmation interface, press the “START/+30Sec.”
when the closing state and time are not 0 and the temperature
sensor is normal.
Air Fry Chart :
Frozen French Fries
Frozen Onion Rings
Frozen Chicken nuggets
Frozen Chicken wings
Frozen Chicken legs
Chicken Tenders
Coconut Tenders
Fish Sticks
Spring Rolls
Mozzarella Sticks
FOOD DISPLAY
WEIGHT/PORTION
H1
H2
H3
H4
H5
H6
H7
H8
H9
H10
About 8oz
About 8oz
About 11oz
About 11oz
About 14oz
About 8oz
About 8oz
About 7oz
About 9oz
About 8oz
29
To program a setting, follow the steps listed below.
Example: Cook food at 80% Power Level for 3 minutes and 20 seconds; save as memory 2.
• Press Favorite twice; screen displays 2.
• Press Micro
• Press Power Level once, then press "8" .
• Press Favorite to save the procedure. Oven beeps once.
• Press START/+30Sec. to save the procedure and start cooking.
• Auto Menu cannot be set in Favorite function.
• The next time you want to run the program, just press Favorite twice,
and then press START/+30Sec.
NOTE
• Press number pads to enter the cooking time.
or
16. FAVORITE FUNCTION
Press Favorite to program and choose up to three cooking functions. Each function will
be indicated by 1, 2 or 3 in the display.
a
Press Favorite repeatedlyuntil your desired setting number
appears in the display.
b
Press START/+30Sec. to begin it.
A maximum of two cooking stages can be set for each setting.
c
30
17. MUTI-STAGE COOKING
At most 2 stages can be set for cooking. If one stage is Defrost, it will automatically set to be the
first stage.
Auto Menu and Preheat cannot be set in Multi-stage Cooking.
NOTE
EXAMPLE: 80% Power Level for 5 minutes followed by 60% Power Level for 10 minutes;
saved as memory 3.
• Press Favorite 3 times.
• Press START/+30Sec. to immediately start multi-stage cooking.
• The next time you want to run the program, just press Favorite three
times, and then press START/+30Sec.
• If you do not want to save a particular multi-stage program as a
procedure, do not press Favorite as the first step. Press START/+30Sec.
after programming both stages.
NOTE
• Press Micro once, press number pads
to set cook time.
• Press Power Level once, then press "8"
to choose 80% first stage cooking power.
1
• Press Micro again, then press number
pads to set cook time.
2
• Press Power Level once,
then press "6" to choose 60% second
stage cooking power.
31
18. TURN ON/OFF THE BUZZER SOUND
It is default that the buzzer sounds is onfix spacing of. In waiting
state, long pressing on number 8 for 3 seconds, it sounds a long beep,
turn o ffor turn on the sound.
• This model has mute function and energy-saving mode.
• This function can work under lock function too.
NOTE
19. ENERGY SAVING MODE
In child-locked mode, press the " STOP/Cancel " once (less than
3 seconds) and release to enter the Energy Saving Mode .
b
Above operation is the only way to start the Energy Saving mode.
c
The Energy Saving mode works only if the door is closed.
d
In standby mode, press the " STOP/Cancel " once (less than 3 seconds
to avoid starting the child lock function ) to enter the Energy Saving
mode.
a
20. LOCK FUNCTION
To unlock, press STOP/Cancel for 3 seconds, you will hear a long
beep and "LOC" will disappear.
b
If the clock has been set, the oven will return to display the clock. Otherwise, "0:00"will display.
c
To lock the microwave so that it cannot be operated by children
or other unintended users, press STOP/Cancel pad for 3 seconds.
You will hear a long beep. "LOC" will display.
a
21. COOKING END REMINDER FUNCTION
The oven will beep five times to alert the user that cooking time has ended. "End" will display.
32
22. OTHER SPECICATIONS
A single beep sounds to indicate that a pad is correctly pressed; if pad is not correctly pressed,
no beep sound.
b
23. TURNTABLE RESET FUNCTION
When cooking has finished, if the turntable is not at the initial position, it will enter the turntable
reset function. At this time, the lamp, fan and turntable are working, “ ” will dynamic
display. After the turntable has reset, the oven stops cooking and reminds that cooking has
finished.
a
In waitng state, press number key “5” for 3 seconds, there will
be a long “beep” denoting turntable reset function is turnned
off. To turn on the turntable reset function, in waiting state
press number key “5” for 3 seconds, there will be a long “beep”
denoting that turntable reset function is released.
b
START/+30Sec. must be pressed to continue cooking if the door
is opened during cooking.
a
• This function only works for one completed cooking. If pause or open
the oven door during cooking, the current cooking cannot enter the
turntable reset function.
• Under the reset state, if opening the door or “STOP/Cancel” button
is pressed, the oven will go back to waiting state.
24. INQUIRING FUNCTION
a
When oven is cooking, press Timer/Clock for the time of day to
appear for three seconds in the display.
b
When oven is cooking, press Conv. , Power Level or Combi pads for cooking power to appear
for three seconds in the display.
or or
NOTE
Harsh or abrasive
cleaning agents
33
CLEANING
With good care and cleaning, your appliance will retain its appearance and remain fully functioning
for a long time to come. We will explain here how you should correctly care for and clean your appliance.
WARNING
• Scratched glass in the appliance door may develop into a crack.
Do not use a glass scraper, sharp or abrasive cleaning aids or
detergents.
• The surface of the appliance may become damaged if it is not
cleaned properly. Microwave energy may escape.
Clean the appliance on a regular basis, and remove any food
remnants immediately.
• Do not immerse the appliance in water or clean under a jet of
water.
Cleaning agent
To ensure that the different surfaces are not damaged by using the wrong cleaning agent, observe
the information Wash new sponge cloths thoroughly before use.
Do not use:
Metal or glass scrapers to
clean the door panels
Hard scouring pads
or sponges
Cleaning agents with a
high alcohol content
Metal or glass scrapers
to clean the door seal
APPLIANCE FRONT
Hot soapy water:
Clean using a dish cloth andthen dry with a soft cloth.
Do not use metal or glass scrapers for cleaning.
below.
34
RECESS IN THE COOKING COMPARTMENT
TURNTABLE AND ROLLER RING
DOOR PANEL
APPLIANCE FRONT
Glass cleaner:
Clean with a dish cloth. Do not use glass scrapers.
Hot soapy water:
When placing the turntable back into its recess,
it must engage properly.
Damp cloth:
Water must not be allowed to run into the appliance through the
turntable drive. Dry the turntable drive with a cloth.
Hot soapy water or vinegar solution:
Clean using a dish cloth and then dry with a soft cloth. Do not
use oven spray or any other aggressive oven cleaners or
abrasive materials. Scouring pads, rough sponges and pan
cleaners are also unsuitable. These items scratch the surface.
Allow the interior surfaces to dry completely.
Hot soapy water:
Clean using a dish cloth and then dry with a soft cloth.
Remove splashes and patches of limescale, grease, starch and
albumin immediately. Corrosion can form under these patches
or splashes. Do not use glass cleaners or metal or glass scrapers
for cleaning.
PLATE
APPLIANCE CAVITY
MAINTENANCE
TROUBLE SHOOTING
Check your problem by using the chart below and try the solutions for each problem.
If the microwave oven still does not work properly, contact the nearest authorized service center.
Oven will not start
Arcing or sparking
Unevenly cooked foods
Overcooked foods
Undercooked foods
Improper defrosting
a. Electrical cord for oven is not
plugged in.
b. Door is open.
c. Wrong operation is set.
TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY
a. Plug into the outlet.
b. Close the door and try again.
c. Check instructions
a. Materials to be avoided in
microwave oven were used.
b. The oven is operated when
empty.
c. Spilled food remains in the
cavity.
a. Use microwave-safe cookware
only.
b. Do not operate with oven
empty.
c. Clean cavity with wet towel.
a. Materials to be avoided in
microwave oven were used.
b. Food is not defrosted
completely.
c. Cooking time, power level is
not suitable.
d. Food is not turned or stirred.
a. Use microwave-safe cookware
only.
b. Completely defrost food.
c. Use correct cooking time,
power level.
d. Turn or stir food.
Cooking time, power level is not
suitable.
Use correct cooking time, power
level.
a. Materials to be avoided in
microwave oven were used.
b. Food is not defrosted
completely.
c. Oven ventilation ports are
restricted.
d. Cooking time, power level is
not suitable.
a. Use microwave-safe cookware
only.
b. Completely defrost food.
c. Check to see that oven venti-
lation ports are not restricted.
d. Use correct cooking time,
power level
a. Materials to be avoided in
microwave oven were used.
b. Cooking time, power level is
not suitable.
c. Food is not turned or stirred.
a. Use microwave-safe cookware
only.
b. Use correct cooking time,
power level.
c. Turn or stir food.
35
ONE YEAR LIMITED WARRANTY
This product carries a warranty stating that it will be free from defects in material and workmanship
for a period of one year from the date of purchase. This warranty is valid for the original retail
purchaser from the date of initial retail purchase and is not transferable. Keep your original sales
receipt.
IMPORTANT:
1. This warranty does not cover damages resulting from accident, misuse or abuse, lack of reasonable
care, the affixing of any attachments not provided with the product, loss of parts, or subjecting
the appliance to any but the specified voltage. ( Read directions carefully. )
2. This warranty is void if this product is ever used for other than private household purposes.
3. This warranty is void if this product is ever used outside of United State.
If service is required during the warranty period, properly pack your unit. We recommend using
the original carton and packing materials.
If additional assistance is needed, please contact customer assistance at:
Midea America Corp. expressly disclaims all responsibility for consequential damages or incidental
losses caused by use of the appliance. Some states do not allow this exclusion or limitation of
incidental or conse quential losses so the foregoing disclaimer may not apply to you. This warranty
gives you specific legal rights, and you may also have other rights which may vary from state to state.
The serial number can be found on the back cabinet. We suggest that you record the serial number
of your unit in the space below for future reference
Model Number : ____________________
Serial Number : _____________________
SAVE THIS FOR YOUR RECORDS
Made in China
Product registration is not mandatory. Failure to complete and return the card or form does
not diminish the consumer' s warranty rights.
36
customercare@us.toshiba-lifestyle.com
855-204-5313
