EM925A5A-BS
Microwave
Solo Oven
Instruction
Welcome to the world of
TOSHIBA
BEFORE OPERATING THIS PRODUCT,
READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
BE SURE TO SAVE THIS BOOKLIST FOR FUTURE REFERENCE
CONTENTS
OPERATION
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE
ENERGY
IMPORTANT SAFETY INSTRUCTIONS
GROUNDING INSTRUCTIONS
UTENSILS
SETTING UP YOUR OVEN
MAINTENANCE
PRECAUTIONS TO AVOID
120V~ 60Hz
Rated Voltage:
Rated Input Power(Microwave):
Rated Output Power(Microwave):
Oven Capacity:
Turntable Diameter:
External Dimensions:
Net Weight:
Specifications
Model:
10.6 inch
1350
W
Approx. 27.3 Lbs
900W
0.9 cu.ft.
19.1X16.1X11.5 inch
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
EM925A5A-BS
EN-2
Do not attempt to operate this oven with the door open since this can result
in harmful exposure to microwave energy. It is important not to
defeat or tamper with the safety interlocks.
a. DOOR (bent)
b. HINGES AND LATCHES (broken or loosened)
c. DOOR SEALS AND SEALING SURFACE
The oven should not be adjusted or reparied by anyone except properly
qualified service personnel.
Do not place any object between the oven front face and the door or allow
soil or cleaner residue to accumulate on sealing surfaces.
Do not operate the oven if it is damaged. It is particularly important
that the oven door closes properly and that there is no damage to the:
1.
2.
3.
4.
Read all instructions before using the appliance.
Read and follow the specific: " PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY" found on page 2.
As with most cooking appliances, close supervision is necessary to reduce the risk
of a fire in the oven cavity.
1.
2.
3.
To reduce the risk of burns, electric shock, fire, injury to persons or
exposure to excessive microwave oven energy when using your appli-
ance, follow basic safety precautions, including the following:
IMPORTANT SAFETY
INSTRUCTIONS WARNING
EN-3
To reduce the risk of fire in the oven cavity:
This oven must be grounded. Connect only to properly grounded outlet. See
"GROUNDING INSTRUCTIONS" found on page 6.
Install or locate this oven only in accordance with the installation instructions
provided.
Some products such as whole eggs and sealed containers-for example, closed glass
jars-are able to explode and should not be heated in the oven.
4.
5.
6.
7.
Do not overcook food. Carefully attend the appliance when paper, plastic, or other
combustible materials are placed inside the oven to facilitate cooking.
Remove wire twist-ties and metal handles from paper or plastic containers/ bags
before placing them in the oven.
If materials inside the oven ignite, keep the oven door closed. Turn the oven off,
and unplug the appliance. Disconnect the power cord, shut off power at the fuse
or circuit breaker panel.
Do not leave paper products, cooking
utensils, or food in the cavity when not in
use.
a.
b.
c.
d.
Do not use the cavity for storage purposes.
8.
9.
10.
Use this appliance only for its intended uses as described in this manual. Do not
designed to heat or cook or dry food. It is not designed for industrial or laborato-
ry use.
As with any appliance, close supervision is necessary when used by children.
Do not operate this oven if it has a damaged cord or plug, if it is not working
properly or if it has been damaged or dropped.
EN-4
use corrosive chemicals or vapors in this appliance. This oven is specifically
11.
12.
13.
14.
15.
16.
17.
18.
19.
This microwave should be serviced only by qualified service personnel.
Do not cover or block any openings on the oven.
Do not store or use this appliance outdoors.
Do not use this oven near water, for example, near a kitchen sink, in a wetbasement,
near a swimming pool, or similar locations.
Do not immerse cord or plug in water.
Keep cord away from heated surfaces.
Do not let cord hang over edge of table or counter.
When cleaning surfaces of door and oven that comes together on closing the door,
use only mild, nonabrasive soaps or detergents applied with a sponge of soft cloth.
This appliance is for private household use only.
Contact nearest authorized service facility for examination, repair or adjustment.
IMPORTANT SAFETY
INSTRUCTIONS WARNING
20.
Liquids, such as water, coffee, or tea are able to be overheated beyond the
boiling point without appearing to be boiling. Visible bubbling or boiling when
the container is removed from the microwave oven is not always present. THIS
COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE
CONTAINER IS DISTURBED OR A SPOON OR OTHER UTENSIL IS INSERTED INTO
THE LIQUID.
Do not overheat the liquid.
Stir the liquid both before and halfway through heating it.
Do not use straight-sided containers with narrow necks.
After heating, allow the container to stand in the microwave oven for a short
time before removing the container.
Use extreme care when inserting a spoon or other utensil into the container.
a.
b.
c.
d.
e.
EN-5
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY
INSTRUCTIONS WARNING
CAUTION:
GROUNDING INSTRUCTIONS
DANGER
WARNING
This appliance must be grounded. In the event of an electrical short circuit, ground-
ing reduces the risk of electric shock by providing an escape wire for the electric
current. To protect against electrical shock, this appliance is equipped with a cord
having a 3 prong grounding-type plug for insertion into a proper grounding-type
receptacle. DO NOT alter the plug for use in a 2-prong receptacle. If the plug will not
Touching some of the internal components can cause serious personal injury or
death. Do not disassemble this appliance.
Electric Shock Hazard
(grounding) plug
Three-pronged
EN-6
fit into a receptacle, have the proper receptacle installed by a qualified electrician.
Do not insert your fingers into any gaps or holes; it may cause injuries.
Improper use of the grounding can result
in a risk of electric shock
EN-8
GROUNDING INSTRUCTIONS
A short power-supply cord is provided to reduce the risks resulting from becom-
ing entangled in or tripping over a longer cord.
Longer cord sets or extension cords are available and may be used if care is
exercised in their use.
If a long cord sets or extension cord is used:
a.
b.
c.
The marked electrical rating of the cord set or extension marked electrial
rating of the cord set or extension cord should be at least as great as the
electrical rating of the appliance.
The extension cord must be a grounding -type 3-wire cord.
The longer cord should be arranged so that it will not drape over the counter-
top or tabletop where it can be pulled on by children or tripped over uninten-
tionally.
completely understood or if doubt exists as to whether the appliance is properly
grounded. If it is necessary to use an extension cord, use only a 3-wire extension
cord that has a 3-pronged grounding plug , and a 3-slot receptacle that will accept
the plug on the appliance.The marked rating of the extension cord shall be equal to
or greater than the electrical rating of the appliance.
1.
2.
3.
EN-7
Consult a qualified electrician or serviceman if the grounding instructions are not
GROUNDING INSTRUCTIONS
Operation of the microwave oven may cause interference to your radio, TV or
similar equipment.
When there is interference, it may be reduced or eliminated by taking the follow-
ing measures:
a.
b.
c.
d.
e.
Clean door and sealing surface of the oven.
Reorient the receiving antenna of radio or television.
Relocate the microwave oven with respect to the receiver.
Move the microwave oven away from the receiver.
RADIO INTERFERENCE
EN-8
Plug the microwave oven into a different outlet so that microwave oven and
receiver are on different branch circuits.
UTENSILS
GROUNDING INSTRUCTIONS
See the instructions on "Materials you can use in microwave oven or to be avoided
in microwave oven." There may be certain non-metallic utensils that are not safe to
use for microwaving. If in doubt, you can test the utensil in question following the
procedure below.
Fill a microwave-safe container with 1 cup of cold water (250ml) along with the
utensil in question.
Cook on maximum power for 1 minute.
Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave
cooking.
Do not exceed 1 minute cooking time.
1.
2.
3.
4.
Tightly-closed utensils could explode. Closed containers should be opened and
plastic pouches should be pierced before cooking.
UTENSIL TEST:
HOUSEHOLD INDOOR USE ONLY
CAUTION
Electric Shock Hazard
EN-9
SAVE THESE INSTRUCTIONS
MATERIALS YOU CAN USE IN MICROWAVE OVEN
EN-10
Shelding only. Small smooth pieces can be used to cover thin
parts of meat or poultry to prevent overcooking. Arcing can occur if
foil is too close to oven walls. The foil should be at least 1
inch (2.5cm) away from oven walls.
UTENSILS
Aluminum foil
REMARKS
Follow manufacturer’s instructions.The bottom of browning dish
must be at least 3/16 inch (5mm) above the turntable. Incorrect
usage may cause the turntable to break.
Browning dish
Microwave-safe only. Follow manufacturer’s instructions. Do not
use cracked or chipped dishes.
Dinnerware
Always remove lid. Use only to heat food until just warm. Most
glass jars are not heat resistant and may break.
Glass jars
Heat-resistant oven glassware only. Make sure there is no metallic
trim. Do not use cracked or chipped dishes.
Glassware
Follow manufacturer’s instructions. Do not close with metal tie.
Make slits to allow steam to escape.
Oven cooking bags
Use for short–term cooking/warming only. Do not leave oven
unattended while cooking.
Paper plates and cups
Use to cover food for reheating and absorbing fat. Use with
supervision for a short-term cooking only.
Paper towels
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Microwave-safe only ( meat and candy thermometers).
Use as a cover to prevent splattering and retain moisture.
Parchment paper
Microwave-safe only. Follow the manufacturer’s instructions.
Should be labeled "Microwave Safe". Some plastic cont ainers
soften, as the food inside gets hot. "Boiling bags" and tightly closed
plastic bags should be slit, pierced or vented as directed by
package.
Plastic
Wax paper
Thermometers
Plastic wrap
UTENSILS REMARKS
MATERIALS TO BE AVOIDED IN MICROWAVE OVEN
May cause arcing. Transfer food into microwave-safe dish.
Aluminum tray
Metal twist ties
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
Food carton with
metal handle
Paper bags
Plastic foam
Wood
Plastic foam may melt or contaminate the liquid inside when
exposed to high temperature.
Wood will dry out when used in the microwave oven and may
split or crack.
EN-11
May cause a fire in the oven.
SETTING UP YOUR OVEN
NAMES OF OVEN PARTS AND ACCESSORIES
Glass tray 1
Turntable ring 1
Insrtuction Manual 1
Control panel
Turntable shaft
Turntable ring
Glass tray
Observation window
Oven Door
Safety interlock system
A
B
C
D
E
F
G
.
.
.
.
.
.
.
F
G
A
C B
E
D
EN-12
Remove the oven and all materials from the carton and oven cavity. Your
oven comes with the following accessories:
SETTING UP YOUR OVEN
TURNTABLE INSTALLATION
a. Never place the glass tray upside down. The glass tray should never be restricted.
b. Both glass tray and turntable ring must always be used during cooking.
c. All food and containers of food are always placed on the glass tray for cooking.
Turntable ring
Turntable shaft
Hub (underside)
Glass tray
EN-13
SETTING UP YOUR OVEN
COUNTERTOP INSTALLATION
INSTALLATION
1.
Select a level surface that provide enough open space for the intake
and/or outlet vents.
A minimum clearance of 3.0 inches (7.5cm) is required between the oven and any adjacent walls.
One side must be open.
(1)
(2)
(3)
(4)
Leave a minimum clearance of 12 inches (30cm) above the oven.
Do not remove the legs from the bottom of the oven.
Blocking the intake and/or outlet openings can damage the oven.
Place the oven as far away from radios and TV a s possible.
Operation of microwave oven may
cause interference to your radio or TV reception.
EN-14
OPEN
12 inches(30cm )
3.0 inches(7.5cm )
3.0 inches(7.5cm)
Remove all packing material and accessories. Examine the oven for any damage such as dents or
broken door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not remove
the light brown Mica cover that is attached to the oven cavity to protect the magnetron.
SETTING UP YOUR OVEN
INSTALLATION
2.Plug your oven into a standard household outlet. Be sure the voltage and
the frequency is the same as the voltage
WARNING
Do not install oven over a range cooktop or other heat-producing appli-
ance. If installed near or over a heat source, the oven could be damaged
and the warranty would be avoid.
The accessible surface may
be hot during operation
EN-15
OPERATION
CONTROL PANEL AND FEATURES
(1)
(7)
(8)
(9)
(11)
(2)
(12)
Auto Menu (Popcorn,Potato,Pizza,Frozen Vegetable,Bevereage amd Dinner Plate)
Number Pads
START/ +30 SEC
Time Defrost
STOP Cancel Hold 3 sec: Before
cooking starts, press to clear all
previous settings. During cooking,
press once to stop oven; press twice
to stop oven and clear all settings.
Display
(5)
(6)
(11)
Time Cook
Memory
(10)
(12)
(3) Power Level
(4) Clock and Settings
(5) Weight Defrost
(6) Kitchen Timer
(10) Stop/Cancel:
EN-16
(8)
(1)
(2)
(3)
(4)
(7)
(9)
1.POWER LEVELS
OPERATION
Prior to or during cooking, press Power Level and "PL10" will display. Then press
number pads to select a different power level.
2.CLOCK SETTING
(1)
(2)
(3)
Press Clock & Settings once, "00:00" will appear in the display.
Press the number pads to enter the current clock time. For example, if the time is
now 10:12, press " 1, 0, 1, 2 " in order.
Press Clock ettings to finish clock setting, " : " will flash and the numbers will
appear as a clock time in the display.
Level 10 9 8 7 6 5 4 3 2 1
Power 100% 90% 80% 70% 60% 50% 40% 30% 20% 10%
Display PL10 PL 9 PL 8 PL 7 PL 6 PL 5 PL 4 PL 3 PL 2 PL 1
NOTE:
If the numbers entered are not within the range between 1:00 to 12:59, the setting
will not be accepted until valid numbers are entered.
In the process of setting clock, if the pad is pressed or if there is no operation
within 1 minute, the display will automatically return to the previous clock setting.
Ten power levels are available.
When the microwave oven is plugged into an outlet, "0:00" will display.
& S
EN-17
Press Kitchen Timer once, "00:00" will appear in the display.
Press the number pads to enter the time amount. The maximum amount of time
that can be entered is 99 minutes, 99 seconds.
When the time amount elapses, the oven will beep 5 times.
OPERATION
Press Time Cook , "00:00" will appear in the display.
Press number pads to enter the cooking time. The maximum cooking time is 99
minutes,99 seconds.
Press Power Level, PL10 will flash. Press number pads 0
through 9 to select a
different power level if desired. See the POWER LEVEL table
above.
Press to start cooking. The remaining cooking time will display.
a.
b.
c.
d.
Press Time Cook , "00:00" will display.
Press "1, 5, 0, 0" in order for 15:00 to appear in the display.
Press Power Level , then press "5" to select 50% microwave power.
Press to start cooking. Buzzer sounds once. The remaining cooking
time will display.
4.MICROWAVE COOK
(1)
(2)
(3)
(4)
3. KITCHEN TIMER
(1)
(2)
(3)
(4)
Note:
During the Kitchen Timer function, no cooking function can be set into operation.
Kitchen Timer amount cannot be increased by pressing .
Pressing will cancel the Timer countdown.
Example : To cook the food with 50% microwave power for 15 minutes.
EN-18
Press to confirm setting, and the timer will start to count down.
The Kitchen Timer setting is different from the Clock setting; it is simply a timer.
NOTE:
In the process of setting, if the pad is pressed or if there is no operation within
1 minute, the oven will automatically return to display the clock.
OPERATION
Instant cooking at 100% power level and 1 to 6 minutes cooking time can be
started by pressing number pads 1 to 6. Press to increase the cooking
time by 30 seconds with each press. The maximum cooking time is 99 minutes,
99 seconds.
Instant cooking at 100% power level and 30 seconds cooking time can be
started by pressing . Each repeated press will increase cooking time by 30
seconds. The maximum cooking time is 99 minutes, 99 seconds.
NOTE:
Time can also be added in 30 second increments by pressing during Micro-
wave Cooking, Time Defrost and Multi-stage Cooking.
Time cannot be added by pressing during Weight Defrost and Kitchen Timer
functions.
(1)
(2)
5.ONE TOUCH START
Press Time Defrost , "dEF2" will appear in the display.
Press the number pads to input the defrost time.
Press to start defro cooking. And the remaining defrost time will display.
(1)
(2)
(4)
6.TIME DEFROST
(3) The default microwave power is power level 3. If you want to change the power level,
level, press
Power Level once, and PL3 will display; then press the number pad for
the desired power level.
EN-19
OPERATION
(2) Press number pads to input weight to be defrosted.
disp
(1) Press
Input the
(4) Press
to start defrosting and the cooking time remaining will be
(3) If the weight input is not between 4 to100 Oz, the input will be invalid. A beep
Weight Defrost
weight range between 4 to100 Oz.
layed.
once,"dEF1" will display.
will sound and the unit will not work until valid numbers are entered.
Press Popcorn , "1.75" will appear in the display.
Press Popcorn two more times to choose the weight, "3.0" and "3.5" will
display in order.
(1)
(2)
8. POPCORN
repeatedly until the number you wish appears in the display
Press 3 Times: 3 po
"1",
Potato
Press nce : 1 potato (approx. 8.0 oz)
Press Twice: 2 potatoes ( approx. 16.0 oz)
"2", "3" will display in order.
tatoes (approx. 24.0 oz)
O
Oven beeps 5 times when
9. POTATO
(1) Press
Press to cook. The remaining time will display.
(2)
cooking finish.
10. FROZEN VEGETABLE
7. WEIGHT DEFROST FUNCTION
Press Frozen Vegetable , "4.0" will appear in the display.
Press Frozen Vegetable two more times to choose the weight, "8.0" and "16.0" will
display in order.
(1)
(2)
Oven beeps 5 times when
Press to cook. The remaining time will display.
(3)
cooking finish.
Oven beeps 5 times when
Press to cook. The remaining time will display.
(3)
cooking finish.
EN-20
OPERATION
11. BEVERAGE
Press Beverage , "1" will appear in the display.
Press Beverage two more times to choose the weight, "2" and "3" will
display in order. One cup is about 4.0 Oz.
(1)
(2)
Oven beeps 5 times when
Press to cook. The remaining time will display.
(3)
cooking finish.
12. DINNER PLATE
Press Dinner Plate , "9.0" will appear in the display.
Press Dinner Plate two more times to choose the weight, "12.0" and "18.0" will
display in order.
(1)
(2)
Oven beeps 5 times when
Press to cook. The remaining time will display.
(3)
cooking finish.
Press Pizza , "4.0" will appear in the display.
Press Pizza two more times to choose the weight, "8.0" and "14.0" will
display in order.
(1)
(2)
Oven beeps 5 times when
Press to cook. The remaining time will display.
(3)
cooking finish.
13. PIZZA
EN-21
OPERATION
Press Memory to program and choose up to three cooking procedures.Each
procedure will be indicated by 1, 2 or 3 in the display.
Press Memory until your desired procedure number appears in the display.
Press to begin it. A maximum of two cooking stages can be set for each
procedure.
To program a procedure, follow the steps listed below. Example: Cook food at
80% Power Level for 3 minutes and 20 seconds; save as memory 2.
14. MEMORY FUNCTION
(1)
(2)
(3)
Press Memory twice; screen displays 2.
Press Time Cook , then press "3" , "2" and "0" in order.
Press Power Level once, then press "8" for "PL 8" to display.
Press to save the procedure. Oven beeps once.
Or press twice directly to save and start cooking.
To choose the procedure from the memory list, press Memory twice.
Screen will display "2". Press to run procedure.
a.
b.
c.
d.
e.
NOTE:
Auto Menu cannot be set in Memory function.
It is default that the buzzer sounds is open.In waiting state, long pressing on number
turns off the sound.
When the sounds turn off, long pressing on 8 for 3 seconds, it sounds a long beep
and the sound turn off. All the buttons has no beep when they are pressed, including
the ending cooking sounds is turn off too.
Note: All models has mute function and energy-saved function.
This function can work under lock function too.
15. TURN ON/OFF THE BUZZER SOUND
EN-22
8 for 3 seconds, it sounds a long beep,
OPERATION
At most 2 stages can be set for cooking. If one stage is Defrost, it will automatically
set to be the first stage.
16.Muti-Stage Cooking
EXAMPLE: 80% Power Level for 5 minutes followed by 60% Power Level for 10
minutes; saved as memory 3.
NOTE: Auto Menu cannot be set in Multi-stage Cooking.
Press Memory 3 times; screen displays 3.
Press Time Cook, then press "5" , "0" and "0" to set first stage cook time.
Press Power Level once, then press "8" to choose 80% first stage cooking
power.
Press Time Cook again, then press "1", "0", "0" and "0" to set second stage
Press Power Level again, then press "6" to choose 60% second stage cooking
power.
Press to immediately start multi-stage cooking.
To choose the procedure from the memory list, press Memory three times.
Screen will display "3"; press to run procedure.
a.
b.
c.
d.
e.
f .
g.
NOTE:
If you do not want to save a particular multi-stage program as a procedure, do not
press Memory as the first step. Press after programming both stages.
cook time.
In standby mode, press the " " once (less than 3 seconds to avoid
starting the child lock
functi on to enter the Energy Saver mode.
)
In child-locked mode, press the "
" once (less than 3 seconds)
and release to enter the
Energy Saver Mode .
Above operation is the only way to start the Energy Saver mode.
The Energy Saver mode works only if the door is closed.
(1)
(2)
(3)
(4)
17.ENERGY SAVER MODE
EN-23
Food
Beef
Whole Chicken
Turkey Breasts
Pork
Weight/Portion
2.0-4.0 Lbs
2.5-6.0 Lbs
3.0-6.0 Lbs
2.0-4.0 Lbs
OPERATION
To lock the microwave so that it cannot be operated by children or other
unintended users, press pad for 3 seconds. You will hear a long beep.
" " will display.
To unlock, press for 3 seconds, you will hear a long beep and " "
20.Cooking End Reminder Function
The oven will beep five times to alert the user that cooking time has ended.
must be pressed to continue cooking if the door is opened during cooking.
A single beep sounds to indicate that a pad is correctly pressed; if pad is not
correctly pressed, no beep sounds.
21.Other Specifications
(1)
(2)
18.LOCK FUNCTION
(1)
(2)
When oven is cooking, press Clock Settings for the time of day to appear for
When oven is cooking, press Power Level pad for cooking power to
appear for three seconds in the display.
19.INQUIRING FUNCTION
(1)
(2)
three seconds in the display.
will disappear.
EN-24
MAINTENANCE
Cooking time,
power level is not suitable.
Use correct cooking time,
power level.
Check your problem by using the chart below and try the solutions for each prob-
lem.
TROUBLESHOOTING
TROUBLE
Oven will not start
Arcing or sparking
Unevenly cooked foods
Overcooked foods
Undercooked foods
Improper defrosting
Sensor cooked foods
not properly cooked
Cover or lid over food must contain
vent hole for escaping steam.
Do not open door to stir orturn food
before sensor-detected cooking time
appears in display.
a.
b.
a.
b.
c.
Materials to be avoided inmicrowa-
veoven were used.
Cooking time, power level is not
suitable.
Food is not turned or stirred.
a.
b.
c.
d.
Use microwave-safe cookware only.
Completely defrost food.
Use correct cooking time, power
level.
Turn or stir food.
a.
b.
c.
d.
Materials to be avoided in microwave
oven were used.
Food is not defrosted completely.
Cooking time, power level is not
suitable.
Food is not turned or stirred.
a.
b.
c.
Materials to be avoided in microwave
oven were used.
The oven is operated when empty.
Spilled food remains in the cavity.
a.
b.
c.
Use microwave-safe cookware only.
Do not operate with oven empty.
Clean cavity with wet towel.
a.
b.
c.
Plug into the outlet.
Close the door and try again.
Check instructions
a.
b.
c.
Electrical cord for oven is not
plugged in.
Door is open.
Wrong operation is set.
a.
b.
c.
Use microwave-safe cookware only.
Use correct cooking time, power
level.
Turn or stir food
a.
b.
c.
d.
Use microwave-safe cookware only.
Completely defrost food.
Check to see that oven venti-lation
ports are not restricted.
Use correct cooking time, power
level
a.
b.
c.
d.
Materials to be avoided in microwave
oven were used.
Food is not defrosted completely.
Oven ventilation ports are restricted.
Cooking time, power level is not
suitable.
Cover or lid on food not vented.
Door opened before sensor-detect -
ed cooking time appears in display.
a.
b.
EN-25
Possible Cause
Possible Remedy
EN-26
ONE YEAR LIMITED WARRANTY
This product carries a warranty stating that it will be free from defects in material and
workmanship for a period of one year from the date of purchase. This warranty is valid
for the original retail purchaser from the date of initial retail purchase and is not
transferable. Keep your original sales receipt.
IMPORTANT:
If service is required during the warranty period, properly pack your unit. We
If additional assistance is needed, please contact
recommend using the original carton and packing materials.
customer assistance at:
Some states do not allow this exclusion
quential losses so the foregoing disclaimer may not
rights which may vary from state to state.
SAVE THIS FOR YOUR RECORDS
Made in China
apply to you. This warranty gives you specific legal rights, and you may also have other
expressly disclaims all responsibility for consequential damages or Midea America Corp
incidental losses caused by use of the appliance.
or limitation of incidental or conse
The serial number can be found on the back cabinet. We suggest that you record the
serial number of your unit in the space below for future reference
Model Number:_______________________
Serial Number:________________________
800-842-1289
Midea Am erica Corp
.
5 Sylvan Way,
Parsippany, NJ 07054
1. This warranty does not cover damages resulting from accident, misuse or abuse,
lack of reasonable care, the affixing of any attachments not provided with the
product, loss of parts, or subjecting the appliance to any but the specified
voltage. ( Read directions carefully. )
2. This warranty is void if this product is ever used for other than private household
purposes.
3. This warranty is void if this product is ever used outside of United State .
s
Customer Assistance: 800-842-1289
Midea America Corp
5 Sylvan Way, Parsippany, NJ 07054
PN:16170000A58805
