User Manual Samsung QN65Q72AAFXZC 65" 2021 Q72A QLED 4K Smart TV

• Owner's manual - (English)

Owner’s Manual  QLED 4K Smart TV Samsung QN65Q72AAFXZC

TABLE OF CONTENTS

• Connections
• Remote Control and Peripherals
• Smart Features
• TV Viewing
• Picture and Sound
• System and Support
• Precautions and Notes
• Troubleshooting
• FAQ
• Accessibility Guidance

Connections

External Storage: USB Flash Drive, Hard Disk Drive (HDD)

• The connection method and available external devices may differ depending on the model.
• Some functions may not be supported depending on the model or geographical area.
• Using HDMI Troubleshooting, you can check the connection to HDMI cable and external devices (takes approximately 2 minutes).

Connecting an Antenna

• An antenna connection is not necessary if you connect a cable box or satellite box.
• The port on your TV may differ from the following figure depending on the product model and region

Establishing a wired Internet connection

• If the TV does not automatically connect to the network, refer to "Network Issues" in "Troubleshooting."
• To connect a LAN cable, use a CAT 7 (*STP type) cable for the connection. (100/10 Mbps) * Shielded Twisted Pair
• The TV will not be able to connect to the Internet if your network speed is below 10 Mbps.
• This function may not be supported depending on the model.

Establishing a wireless Internet connection

Make sure that you have the wireless access point's name (SSID) and password settings before attempting to connect. The network name (SSID) and security key are available on the wireless access point's configuration screen. See the wireless access point's user manual for more information.

• The image on your TV may differ from the image above depending on the model and geographical area.
• If no wireless access point is found, select Add Network at the bottom of the list and enter the network name (SSID).
• If your wireless access point has a WPS or PBC button, select Use WPS at the bottom of the list, and then push the WPS or PBC button on your access point within 2 minutes. The TV will connect automatically.
• To view or delete previously connected network names (SSIDs), move the focus to Manage Saved Networks, and then press the Select button.

Connecting an IP control device to the TV

You can connect an IP control device to the TV remotely to manage your IP device.

• To use this function, Power On with Mobile must be turned on.
• Turning this feature on may allow other IP control devices to control your TV. We recommend turning this feature on only if an authorized third-party custom controller is installed and configured specifically for a Samsung TV and if your Wi-Fi network is password protected.
• This function may not be supported depending on the model.

Using Tap View

By tapping the mobile device on your TV, you can watch Multi View or mobile device's screen through the TV screen. When you tap a mobile device on your TV while running a music app on your mobile device, the TV screen switches to the Music Wall screen.

• This function may not be supported depending on the model.
• This function is available in Samsung mobile devices with Android 8.1 or higher.
• Music Wall screen is a function that allows you to enjoy music along with visual video effects that change according to the genre and beat of the music.

1. Enable Tap View on your mobile device.
2. Turn on the screen of your mobile device.
3. Tap your mobile device on the TV. The TV screen switches to Multi View, Music Wall, or mobile device's screen
4. Watch Multi View, Music Wall, or mobile device's screen on the TV screen

• The displayed TV screen may differ depending on the model.
• This function enables Screen/Sound Mirroring by detecting vibrations generated when you tap the mobile device on the TV.
• Be sure to tap away from the TV screen and bezel corners. It may scratch or break the TV or mobile device screen.
• We recommend using your mobile device with the cover in place and lightly tap it on any external edge of the TV.

Precautions and Notes

Before Using the Recording and Timeshift Functions

• To set up a Schedule Recording, you must first set the TV's clock. Set the Clock.
• You can set up a maximum total of 30 Schedule Viewing and Schedule Recording entries.
• Recordings are DRM-protected and therefore cannot be played back on a computer or on a different TV. In addition, these files cannot be played back on your TV if its video circuit has been replaced.
• For a USB device for recording, it is recommended to use the USB hard disk that supports USB 2.0 or later and 5,400 rpm or higher. However, RAID-type USB hard drives are not supported.
• USB memory sticks are not supported.
• The total recording capacity may differ with the amount of available hard drive space and the recording quality level.
• Schedule Recording requires at least 100 MB of free space on the USB storage device. Recording will stop if the available storage space falls below 50 MB while recording is in progress.
• If the available storage space falls below 500 MB while both the Schedule Recording and Timeshift functions are in progress, only the recording will stop.
• The maximum recording time is 720 minutes.
• Videos are played according to the TV settings.
• If the input signal is changed while recording is in progress, the screen will go blank until the change is made. In this case, recording will resume, but the button will not be available.
• When using the Record or Schedule Recording function, the actual recording may start a second or two later than the specified time.
•  If the Schedule Recording function is operating while a recording is being made on an HDMI-CEC external device, the priority is given to the Schedule Recording.
• Connecting a recording device to the TV automatically deletes abnormally saved recorded files.
• If the Sleep Timer or Auto Power Off has been set, the TV will override these settings, continue to record, and turn off after the recording has ended.

Before using the timeshift function

• For a USB device for recording, it is recommended to use the USB hard disk that supports USB 2.0 or later and 5,400 rpm or higher. However, RAID-type USB hard drives are not supported.
• USB memory sticks or flash drives are not supported.
• The total recording capacity may differ with the amount of available hard drive space and the recording quality level.
• If the available storage space falls below 500 MB while both the Schedule Recording and Timeshift functions are in progress, only the recording will stop.
• The maximum amount of time available for the Timeshift function is 90 minutes.
• The Timeshift function is not available for locked channels.
• Time-shifted videos are played according to the TV settings.
• The Timeshift function may be terminated automatically once it reaches its maximum capacity.
• The Timeshift function requires at least 1.5 GB of free space available on the USB storage device.
