Installation instructions
Range hood
Mode: Extraction / Recirculation
DSTS9
1011458-R03
25/06/2018
1011458-R03
1
The appliance should be installed by qualified personnel only.
Each step must be carried out and checked in full in the order specified.
Validity
64004 (DSTS9, construction width 90 cm)
General notes
Identification plate
▸ Remove the grease filters. The identification plate is located on the inside of the appliance.
Installation accessories supplied
All fixing elements are contained in the scope of delivery.
Mains cable 12 self-tapping screws 3.5 × 9.5mm
Lower angle bracket 6 screws M4 × 8mm
Upper angle bracket 6 screws 4 × 15mm
Angle brackets
(are not used)
Accessories: Recirculation box
Extraction mode
The extracted air must not be fed into a chimney which is used for exhausting fumes from appliances burning gas or
other fuels.
Observe the local fire regulations.
Recirculation mode
The air outlet grille must not be covered during operation.
