USE & CARE INSTRUCTIONS
InvisiClean Aura II Air Purifier (Model IC-5018)
with Pre-filter, Activated Charcoal, True HEPA, UV-C Light, and Ionizer
2
READ AND SAVE THESE INSTRUCTIONS
WARNINGS
Failure to comply with the warnings listed below may
result in electric shock or serious injury.
This product should be used only in accordance with the specifications
outlined in this manual. Usage other than what has been specified here may
result in serious injury.
When using electrical appliances, basic precautions should always be followed to
reduce the risk of fire, electric shock, and injury to persons, including the following:
• Read all instructions before using appliance.
• IMPORTANT - This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit in a polarized
outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it
still does not fit, contact a qualified electrician. Do not attempt to defeat this safety
feature.
• To avoid fire or shock hazard, plug the appliance directly into an AC electrical outlet.
• Keep the cord out of heavy traffic areas. To avoid fire hazard, NEVER put the cord
under rugs, near heat registers, radiator, stoves, and heaters.
• To protect against electrical hazards, DO NOT immerse in water or other liquids. Do
not use near water.
• Children cannot recognize the hazards associated with the usage of electrical
appliances. For this reason, always supervise children when they are near the unit.
• Always unplug the air purifier before moving it, opening the grill, changing filters,
cleaning or whenever the air purifier is not in use. Be sure to pull by the plug and not
the cord.
• NEVER drop or insert any object into any openings.
• DO NOT run cord under carpeting.
• DO NOT cover cord with throw rugs, runners, or similar coverings.
• DO NOT route cord under furniture or appliances. Arrange cord away from traffic
area and where it will not be tripped over.
• DO NOT operate any appliance with a damaged cord or plug, if motor fan fails to
rotate, after the appliance malfunctions, or if it has been dropped or damaged in any
manner. Please contact the manufacturer for assistance.
3
• Use a ppliance only for intended househ old use as described in this manual. Any other
use not rec ommended by the manufacturer may cause fie, electric shock or injury to
persons.
• DO NOT use outdoors.
• DO NOT place anything on top of unit.
• NEVER block the air openings, grills/outlets or p la ce on a soft surface such as a bed
or sofa, as this could cause the unit to tip over, blocking the air intake or air outlet.
• DO NOT attempt to repair or adjust any electrical or mechanical functions on this
unit. Doing so will void your warranty. The inside o f the unit c ontains no user
serviceable parts. All servicing should be performed by qualified personnel only.
• WARNING: To reduce the risk of fire or electric shock, do not use this fan with any
solid-state speed control device.
TECHNICAL SPECI FICATIONS
Rated Voltage: AC 110V-240V, 60Hz
Rated Power: 55W
Noise Level: From 30dB(LOW) to 55dB(TURBO)
UV Light: Wavelength: 254 nanometers
Lamp life: Approx. 20,000 hours
Dimensions: 12.34(L) x 6.25(W) x 17.75(H) inches
4
PRODUCT STRUCTURE
AIR CLEANING SYSTE M
PRE-FILTER: Captures dust and allergen particles.
ACTIVATED CHARCOAL: Absorbs formaldehyde, benzene, a nd other VOC gases.
HEPA: Captures dust, smoke, pollen, and other allergens.
UV-C LIGHT: Destroys microorganisms such as viruses, bacteria, and fungi.
IONIZER: Negative ions improve air quality by combining pa rticulates to create
larger par ticle s that are easier to filter o ut a nd by reacting with odor molecules.
UV lamp
Front cover
Air outlet
3 in 1 filter(Pre-filter with charc oal
coating, HEPA filter)
Touch pa nel
Main unit
5
OPERATING INSTRUCTIONS
BEFORE OPERATING THE AIR PURIFIER:
1. Carefully remove your air purifier from box and plastic bag.
2. Select a firm, level, and flat location for the air purifier.
*For proper air flow, locate the unit at least 1 foot from any wall or furniture.
*Make sure none of the grills are blocked.
3. Before using, remove and discard the bags covering the filters.
4. Plug the power cord into an 120V AC outlet.
IMPORTANT: When moving the air purifier, always lift unit by the carrying handle
located on back.
OPERATING THE AIR PURIFIER
1. “POWER” BUTTON:
Press this button to turn the unit on or off.
2. “SLEEP MODE” BUTTON:
Press this button to turn on sleep mode. When in sleep mode, all the LEDs will be off
and the purifier will keep working. Press any button to cancel sleep mode.
3. “SPEED” BUTTON:
The fan speed of the unit can be adjusted to Low, Medium, High, and TURBO. Each
time that you press the fan speed button, the speed will adjust from I (Low) to II
(Medium) to III (High) to TURBO.
II
III
I
UV
-C ION
2H
4H 8H
RESET)
ON/OFF
(FILTER
SL
EEP
TURBO
MODE
SLEEP
MODE
SLEEP
TURBO
6
3. “UV-C /ION” BUTTON:
Press this button to turn on/off the UV lamp and I onizer function. The button can b e
cycled to turn both on and off and to turn on each function individually.
4. “TIMER” BUTTON:
1) By pressing this button, the purifier can be timed to operate for intervals of 2, 4,
and 8 hours, stopping automatically when the time has elapsed.
2) Press this button (Timer) to select the desired operating time.
3) To select the continuous operating mo de, press the button unti
l there
are no mor e indicator lights on.
Important note: When the unit is not in use, switch it off, and unplug it.
INSTALLING & REMOVING FILTERS
FILTER REPLACE INDICATOR
The power LED light flickering continuously indicates that it is time to replace the
filter. Replace the filter according to the directions then press the ON/OFF(Filter reset)
button and hold for 5 seconds to r estart the system. The light will stop flickering.
*The 3 in 1 HEPA filter will last approximately 3
-6 months depending on usage and
air quality.
1. Open the front cover from the top .
2. Remove the filter by pulling the two pull tabs.
3. Insert new filter into the unit. The pull tabs on the filter should be facing up and
towards you for corre ct installation.
4. Reattach the front cover of the unit and securely latch into place.
5. Press and hold FILTER RESET Button for 5 seconds to reset filter change indicator.
7
CLEANING & MAINTAINING
THE 3 in 1 HEPA FILTER
The air purifier should be cleaned at least once every month and the pre-filter attached
to the HEPA Filter should be cle aned every month. More frequent cleaning may be
required depending on environmental c onditions.
FILTERS
Clean with the brush attac hment of your vacuum cleaner. This will remove lint and dirt.
3 in 1 filter（
Charcoal coated pre-filter+HEPA）
NOTE:
-The 3 in 1 filter is one filter system. The multiple layers include: the carbon coated
pre-filter and HEPA Filter.
UV LAMP REPLACEMENT
1. Open the UV lamp cover using a screw driver.
2. Take off the UV lamp from the holder carefully and unplug the connector.
3. Connect the new UV lamp to the connector a nd insert the lamp back into the holder
carefully.
Note: Never look at the operating UV lamp dir ectly.
LAMP CONTAINS MERCURY
Hg
Manage in accordance with Spills, Disposal and Site Cleanup
Requirements. In case of breakage, follow clean-up procedures
provided by contacts below.
www.epa.gov/cflcleanup
1-866-284-4010
8
MAINTENANCE PRECAUTIONS
Use a clean, dry, soft cloth to wipe the external surface of the unit.
NOTE: Do NOT stick any foreign objects or your fingers inside of the unit.
CAUTION: Do NOT use gasoline, benzene, thinner, harsh cleaners, etc. on and/or in
the unit while cleaning as they will damage the product.
NEVER use alcohol or other solvents.
FREQUENTLY ASKED QUESTIONS
Before carryi
ng out any of the following service checks, unplug the unit from the
mains.
Insufficient air flow
Check that the filters are clean
Check for any obstructions in the air inlet and outlet
Unit will not start
Check the power supply and electric fuses.
Check that the Front Cover is latched firmly in place.
Check that the Filter is firmly in place.
Excessive noise
Check for any foreign objects in contact with the fan.
The filter may be clogged and ready for replacement.
The foam sealing gaskets have been installed
incorrectly.
Uneven positioning.
Why is the replace filter
light blinking?
The replace filter light is set to automatically go off
after 4,320 hours. It is only a reminder to check the
filter to keep the air purifier running smoothly.
To reset the light, please hold down the power button
while the unit is on for 5 seconds.
How often should I
change filters?
The filter replacement frequency varies greatly on
environment. We recommend checking the pre-filter
monthly. Vacuum off any visible dust and hair on the
pre-filter or replace the pre-filter with a new one.
For HEPA filter replacement
, we recommend going by
looking at the backside of the filter. Once the backside
turns a grayish color indicating that dirt has penetrated
to the last layer of the filter, we recommend changing it.
TROUBLESHOOTING GUIDE
Why does my air purifier
smell?
The scent is usually from the carbon pre-filter. You can
test if this is the case by running the filter without the
pre-filter attached. If this scent is bothersome, we
recommend using our gray pre-filter without carbon
coating. Please contact us for more information.
What does the ionizer do
and should I leave it on?
The ionizer produces negative ions that attract and
attach smaller particles together to make them heavy
and fall to the ground. The benefit of this is that falling
to the ground is better than being breathed in but the
downside is there will be an increase of dust on
furniture and surroundings.
What is the difference
between your 2 filters
you offer?
We offer two filters for this air purifier, the IC-5018-
Filter and IC-5018-Hepa-C-Filter. The IC-5018-Filter
features a HEPA filter with a pre-filter coated with
activated carbon. The IC-5018-Hepa-C-Fil
ter features
a HEPA filter with a honeycomb array of pelletized
carbon and a plain washable pre-filter. It has much
more activated carbon content and is optimized for
VOC gas and odor removal.
When should I change
the bulb?
The bulb should be changed yearly for optimum
performance.
How do I tell if my UV
lamp is working?
Please remove the filter and replace the door. You
should see a blue glow from the UV bulb when looking
into the unit from the air intake on th
e right side front
of the unit. Please only look at the UV light from a
distance and do not look at it directly for any length
of time.
My unit no longer
powers on, what should
I do?
First, please check another outlet to see if it is a
problem with the outlet. Second, please make sure the
two hooks at the bottom of the door are intact and not
broken off. If they are broken off, the safety sensor
will not be depressed and the unit will not power on.
Please conta
ct us to replace the door.
Dear Consumer,
InvisiClean warrants this product to be free of defects in materials or workmanship
commencing upon the date of the original purchase. Save your original sales
receipt to validate start of warranty period. Warranty is not valid without receipt. If
this product should become defective within the warranty period, we will repair or
replace any defective parts free of charge. All warranty repairs must be completed
by
InvisiClean.
This warranty does not cover unauthorized repairs. The warranty
does not include unusual wear, damage resulting from accident, or unreasonable
use of the product. This warranty only covers the product when used with genuine
InvisiClean accessories. This warranty covers product that was purchased from
authorized distributors. This warranty gives you specific legal rights and you may
also have
other rights (other rights may vary from state to
state in the U.S.A.). To
submit product under warranty the complete machine must be delivered pre-paid
to InvisiClean. Please include complete information including: the problem, the
model number of the product, the day of purchase, and a copy of the original sales
receipt along with your name, address, and telephone (email optional). Please
contact the or
iginal authorized retailer for return authorization and instructions.
Warranty: 1 year as from the date of purchase
