The default flight control is known as Mode 2. The left stick controls the aircraft’s altitude and heading, while the right
stick controls its forward, backward, left and right movements. The gimbal dial controls the camera’s tilt.
Quick Start Guide
V1.0
Phantom 4 Pro
The DJI PHANTOM
TM
4 Pro is a smart prosumer flying camera capable of shooting 4K video at 60fps and at up to
100mbps, and capturing 20 megapixel stills. 4 directions of obstacle avoidance allow it to intelligently avoid obstacles
during flight. Using upgraded TapFly
TM
and ActiveTrack
TM
through the DJI GO
TM
4 app, you can fly anywhere visible on
your screen or track a moving subject smoothly and easily with a simple tap. The brand new camera uses a 1-inch
CMOS sensor offering unprecedented clarity, lower noise, and better quality images.
Remote Controller
The powerful remote controller of the Phantom 4 Pro has a transmission range extending up to 4.3 mi (7 km)*. It
features physical buttons and dials to control exposure, camera tilt, photo capture and video recording.
Built into the remote controller is DJI LIGHTBRIDGE
TM
, which when paired with a compatible mobile device gives you
a live HD view from the Phantom’s camera. Dual frequency support makes the HD video downlink more stable. An
internal battery ensures a long battery life and ease of use.
Left Stick Right Stick
U
P
D
o
w
n
T
u
r
n
R
i
g
h
t
T
u
r
n
L
e
f
t
F
o
r
w
a
r
d
B
a
c
k
w
a
r
d
R
i
g
h
t
L
e
f
t
Gimbal Dial
1. Gimbal and Camera
2. Downward Vision System*
3. Micro USB Port
4. Camera/Linking Status Indicator
and Link Button
5. Camera Micro SD Card Slot
6. Forward Vision System
7. Infrared Sensing System*
8. Front LEDs
* The Vision and Infrared Sensing Systems are affected by surrounding conditions. Read the Disclaimer and Safety Guidelines and watch the
tutorials in the DJI GO 4 app or on the official DJI website to learn more.
http://www.dji.com/phantom-4-pro
www.dji.com
14
13
15
16
9. Motors
10. Propellers
11. Aircraft Status Indicators
12. Antennas
13. Rear Vision System
14. Intelligent Flight Battery
15. Power Button
16. Battery Level Indicators
11
1819
12
13
15
16
17
17
14
10
1
2
3
4
5
6
7
8
9
1. Power Button
2. Return-to-Home (RTH) Button
3. Control Sticks
4. Status LED
5. Battery Level LEDs
6. Power Port
7. Mobile Device Holder
8. Small Device Positioning Tabs
(for mobile phones)
9. Antennas
10. Handle Bar
11. Gimbal Dial
12. Camera Settings Dial
13. Record Button
14. Flight Mode Switch
15. Shutter Button
16. Intelligent Flight Pause Button
17. C1 and C2 Buttons
(customizable)
18. USB Port
19. Micro USB Port
Folded
6
1
2
3
4
5
8
9
10
11
12
