CP.PT.000642 Dji Cameras User Manual

V1.6

2017.04

User Manual

MAVIC PRO

Using this manual

Legends

Warning Important Hints and Tips Reference

Read Before the First Flight

Read the following documents before using the MAVIC

Pro:

1. Mavic Pro In the Box

2. Mavic Pro User Manual

3. Mavic Pro Quick Start Guide

4. Mavic Pro Disclaimer and Safety Guidelines

5. Mavic Pro Intelligent Flight Battery Safety Guidelines

We recommend that you watch all tutorial videos on the ofcial DJI

website and read the Disclaimer

before you y. Prepare for your rst ight by reviewing the Mavic Pro Quick Start Guide and refer to the

User Manual for more details.

Video Tutorials

Please watch the tutorial videos at the link below, which demonstrates how to use Mavic Pro safely:

http://www.dji.com/mavic

Download the DJI GO 4 App

Ensure to use the DJI GO

4 app during ight. Scan the QR code on the right to download

the latest version.

The Android version of the DJI GO 4 app is compatible with Android 4.4 or later.

The iOS version of the DJI GO 4 app is compatible with iOS 9.0 or later.

Download the DJI Assistant 2

Download the DJI Assistant 2 at http://www.dji.com/mavic/download

Searching for Keywords

Search for keywords such as “battery” and “install” to nd a topic. If you are using Adobe Acrobat

Reader to read this document, press Ctrl+F on Windows or Command+F on Mac to begin a search.

Navigating to a Topic

View a complete list of topics in the table of contents. Click on a topic to navigate to that section.

Printing this Document

This document supports high resolution printing.

Contents

Using this manual

Legends

Read Before the First Flight

Video Tutorials

Download the DJI GO 4 App

Download the DJI Assistant 2

Product Prole

Introduction

Features Highlights

Preparing the Mavic Pro

Aircraft Diagram

Remote Controller Diagram

Aircraft

Aircraft Prole

Flight Mode

Flight Status Indicator

Return-to-Home (RTH)

Intelligent Flight Mode

Forward and Downward Vision System

Flight Recorder

Attaching and Detaching the Propellers

Intelligent Flight Battery

Remote Controller

Remote Controller Prole

Using the Remote Controller

Dual Remote Controller Mode

Linking the Remote Controller

Camera and Gimbal

Camera Prole

Gimbal

DJI GO 4 App

Equipment

Editor

SkyPixel

Flight

Flight Environment Requirements

Flight Limits and No-Fly Zones

Preight Checklist

Calibrating the Compass

Auto Takeoff and Auto Landing

Starting/Stopping the Motors

Flight Test

Appendix

Specications

Firmware Updates

Intelligent Flight Mode

Remote Controller LCD Screen Menu Information

After-Sales Information

Product Prole

This section introduces the Mavic Pro

and lists the components of the aircraft

and remote controller.

Product Profile

Product Prole

Introduction

The DJI Mavic

Pro is DJI’s smallest ying camera, featuring a fully stabilized camera, Intelligent

Flight Modes and Obstacle Avoidance inside a revolutionary folding design. It captures 4K videos

and 12 megapixel photos, and is capable of both ActiveTrack

and TapFly

making complex

shots effortless.

Mavic Pro boasts a maximum ight speed of 40 mph (65 kph) and a maximum ight time of 27

minutes*.

* Maximum ight time was tested in 0 wind at a consistent 15.5 mph (25 kph). This value should be taken

for reference only.

Features Highlights

The Mavic Pro is an ultra-portable aircraft thanks to its revolutionary folding design.

Camera and Gimbal: With the Mavic Pro, you are shooting 4K video at up to 30 frames per second and

capturing 12 megapixel photos that look crisper and cleaner than ever, all stabilized by the compact on-

board gimbal.

Flight Controller: The next-generation ight controller has been updated to provide a safer, more reliable

ight experience. The aircraft is able to automatically return to its home point when transmission signal is

lost or battery level is low. Apart from being able to hover in door at low altitudes, the aircraft is also able

to sense and avoid obstacles on its route, enhancing safety.

HD Video Downlink: Built into the Remote Controller is DJI’s latest long-range transmission technology

OCUSYNC

, offering a maximum transmission range of 4.3 mi (7 km) and making it possible to control

your aircraft up and stream video to your mobile device at 1080p.

Preparing the Mavic Pro

All arms of the aircraft are folded on delivery. Follow the instructions below to unfold all the arms.

Preparing the Aircraft

Remove the gimbal cover and gimbal clamp from

the camera.

Attaching the Propellers

Attach the white ringed propellers to the mounting base with white marks. Press the propeller down onto

the mounting plate and rotate in the lock direction until it is secured. Attach the other propellers to the

mounting base without marks.

The gimbal cover is used to protect the gimbal. Remove it when necessary.

Use the Gimbal Clamp and Gimbal Cover to protect the gimbal when the Mavic Pro is not in use.

Product Profile

Mavic Pro

User Manual

Preparing the Remote Controller

1. Unfold the mobile device clamps and the antennas.

2. Choose an appropriate RC cable based on the type of mobile device used. An RC cable with a

Lightning Connector has been connected and the Standard Micro USB connector cable and the USB

Type-C connector cable are included. An optional Reverse Micro USB connector cable is available.

Insert the mobile device and secure it.

Unfold the front arms and the propellers before the rear ones. All arms and propellers must be

unfolded before powering on the aircraft, or it may affect Self Diagnostic Testing.

Ensure the Control Mode Switch is toggled to "RC" when using the Remote Controller to control

the aircraft.

You can also connect your mobile device to the remote controller using a USB cable. Plug one end

of the cable into your mobile device and the other end into the USB port on the bottom of the remote

controller. Ensure to disconnect the RC cable from the Micro USB port on the remote controller when

using a USB cable.

Marked Unmarked

Unfold the Arms

1. Unfold the front arms, followed by the rear arms of the aircraft as shown.

2. Unfold all propeller blades.

Refer to the gure below for how to replace the RC cable

The RC cable slider must be replaced if using an USB

Type-C RC cable.

Micro USB Connector

Reverse Micro USB

Connector

Lightning Connector

USB Type-C Connector

Product Profile

Mavic Pro

User Manual

Aircraft Diagram

Remote Controller Diagram

Propeller

Motor

Front LED Indicator

Forward Vision System

Landing Gear

(with built-in antennas)

Gimbal and Camera

Intelligent Flight Battery

Link Button

Linking Status Indicator

Camera Micro SD Card Slot

Control Mode Switch

Micro USB Port

Aircraft Status Indicator

Downward Vision System

1. Antennas

Relays aircraft control and video

signal.

2. Return to Home (RTH) Button

Press and hold the button to initiate

Return to Home (RTH). Press again to

cancel RTH.

3. Power Button

Used to turn the remote controller on

and off.

4. Control Stick

Controls the orientation and

movement of the aircraft.

1413

Product Profile

Mavic Pro

User Manual

1716

10. C1 Button

The default conguration is listed below.

Set these values based on your preference

in the DJI GO 4 app.

Press once to focus on the center or add a

waypoint when using Waypoints.

11. C2 Button

The default conguration is listed below.

Set these values based on your preference

in the DJI GO 4 app.

Press once to playback or delete a

waypoint when using Waypoints.

12. Gimbal Dial

Control the camera's tilt.

13. Camera Settings Dial

Turn the dial to adjust camera settings.

(Only functions when the remote controller

is connected to a mobile device running

the DJI GO 4 app)

14. Record Button

Press to start recording video. Press again

to stop recording.

5. LCD Screen

Displays the aircraft and Remote Controller's

system status.

6. Flight Pause Button

Press once for emergency braking.

7. 5D Button

The default conguration is listed below. Set

these values based on your preference in

the DJI GO 4 app.

Left: Zoom In

Right: Zoom Out

Up: Gimbal Forward

Down: Gimbal Downward

Press down: Bring up DJI GO 4 Intelligent

Flight menu.

8. Mobile Device Clamp

Securely mounts your mobile device onto

the remote controller.

9. USB Port

Connection to mobile device for DJI GO 4

app.

15. Shutter Button

Press to take a photo. If burst mode is

selected, a pre-set number of photos will be

taken.

16. Power Port

Connect to the Charger to charge the

remote controller battery. Connect this port

to your mobile device using the RC cable.

17. Flight Mode Switch

Switch between P-mode and S-mode.

Aircraft

This section introduces the Flight

Controller, Forward and Downward

Vision System, and the Intelligent Flight

Battery.

Aircraft

Aircraft Prole

The Mavic Pro aircraft comprises of a flight controller, video downlink, propulsion system and an

Intelligent Flight Battery. This section introduces the features of the ight controller, video downlink and

other aircraft components.

Flight Mode

The following ight modes are available for Mavic Pro:

P-mode (Positioning):

P-mode works best when the GPS signal is strong. The aircraft utilizes the GPS and

Forward and Downward Vision Systems to locate itself, automatically stabilize, and

navigate between obstacles. Advanced features such as TapFly and ActiveTrack

are enabled in this mode.

When the Forward Vision System is enabled and lighting conditions are sufcient,

the maximum ight attitude angle is 16° with a maximum ight speed of 22 mph

(36 kph). When forward obstacle sensing are disabled, the maximum ight attitude

angle is 25° and the maximum ight speed is 36 mph (58 kph).

The aircraft will automatically switch to ATTI mode when the GPS signal is

weak and lighting conditions are too dark for the Forward and Downward

Vision Systems, it will not be able to automatically avoid obstacles and only use

its barometer for position ing to control altitude. Intelligent Flight Mode is not

available in ATTI mode.

Note: P-mode requires larger stick movements to achieve high speeds.

S-mode (Sport):

The aircraft is using GPS for positioning. As Forward and Downward Vision

Systems are disabled, the aircraft will not be able to sense and avoid obstacles

when in Sport Mode. Ground Station and the Intelligent Flight functions are also not

available in Sport Mode.

Note: Aircraft responses are optimized for agility and speed making it more

responsive to stick movements.

The Forward Vision System is disabled in S-mode (Sport), which means the aircraft will not

be able to automatically avoid obstacles on its route.

The aircraft’s maximum speed and braking distance are signicantly increased in S-mode

(Sport). A minimum braking distance of 30 meters is required in windless conditions.

Descending speed is signicantly increased in S-mode (Sport).

The aircraft’s responsiveness is signicantly increased in S-mode (Sport), which means a small

stick movement on the remote controller will translate into a large travel distance of the aircraft.

Be vigilant and maintain adequate maneuvering space during ight.

Use the Flight Mode switch to change the ight mode of the aircraft.

Aircraft

Mavic Pro

User Manual

Flight Status Indicator

The Mavic Pro has Front LEDs and Aircraft Status Indicator. The positions of these LEDs are shown in the

gure below:

The Front LEDs show the orientation of the aircraft. The Front LEDs glow solid red when the aircraft is

turned on to indicate the front (or nose) of the aircraft (the Front LED can be turned off in the DJI GO 4

app). The Aircraft Status Indicator communicates the system status of the ight controller. Refer to the

table below for more information about the Aircraft Status Indicator.

Aircraft Status Indicator Description

Normal

Alternating red, green and yellow

ashes

Turning On and Self Diagnostic Testing

Alternate yellow and green ashing Warming Up

Slow green ashing P-mode with GPS

×2 Two green ashes

P-mode with Forward and Downward Vision

Systems

Slow yellow ashing

No GPS and Forward and Downward Vision

Systems

Fast green ashing Braking

Warning

Fast yellow ashing Remote Controller Signal Lost

Slow red ashing Low Battery Warning

Fast red ashing Critical Low Battery Warning

Red ashing IMU Error

—

Solid Red Critical Error

Fast alternating red and yellow ashing Compass Calibration Required

Front LED

Aircraft Status Indicator

Aircraft

Mavic Pro

User Manual

Return-to-Home (RTH)

Return-to-Home (RTH) function brings the aircraft back to the last recorded Home Point. There are three

types of RTH: Smart RTH, Low Battery RTH, and Failsafe RTH. This section describes these three scenar-

ios in detail.

GPS

Description

Home Point

If a strong GPS signal was acquired before takeoff, the Home Point is

the location from which the aircraft launched. The GPS signal strength

is indicated by the GPS icon ( ). The aircraft status indicator will

blink rapidly when the home point is recorded.

Failsafe RTH

If the Home Point was successfully recorded and the compass is functioning normally, Failsafe RTH

will be automatically activated if the remote controller signal is lost for a specified amount of time (3

seconds when using the remote controller and 20 seconds when using Wi-Fi). Return-to-Home can be

cancelled by the pilot, allowing them to regain control when the remote controller signal connection is re-

established.

1 Record Home Point 3 Remote Controller Signal Lost

2 Conrming Home Point

6 Landing (after user conrmed landing)

4 Signal Lost for Extended Time

RTH (adjustable altitude)

Height over HP<=Failsafe Altitude

Height over HP>Failsafe Altitude

Elevate to Failsafe Altitude

Failsafe Altitude

Aircraft cannot return to the Home Point when the GPS signal is weak or unavailable.

Aircraft will stop ascending and immediately return to the Home Point if you move the left stick

in the aircraft reaches 20 meters (65 feet) altitudes or beyond during Failsafe.

The aircraft cannot avoid obstruction during Failsafe RTH if Forward Vision System is disabled.

It is important to set a suitable Failsafe altitude before each ight. Launch the DJI GO 4 app,

enter “Camera” and tap to set the Failsafe Altitude.

User cannot control the aircraft while it is ascending to its failsafe altitude. However, user can

press RTH button to exit the ascent and regain control.

Aircraft can sense and avoid obstacles when Forward Vision System is enabled and the lighting

conditions are sufcient. The aircraft will automatically climb to avoid an obstacle and y to the

Home Point at the new altitude. To ensure the aircraft returns home forwards, it cannot rotate or

y left and right during RTH while the Forward Vision System is enabled.

Forward Vision System can be enabled during ight or RTH only.

Hovering at 2 meters above

the Home Point

Aircraft

Mavic Pro

User Manual

Low Battery RTH

The low battery level failsafe is triggered when the DJI Intelligent Flight Battery is depleted to a point that

may affect the safe return of the aircraft. Users are advised to return home or land the aircraft immediately

when prompted. The DJI GO 4 app will display a notice when a low battery warning is triggered. The

aircraft will automatically return to the Home Point if no action is taken after a ten-second countdown. The

user can cancel the RTH procedure by pressing the RTH button on the remote controller. The thresholds

for these warnings are automatically determined based on the aircraft’s current altitude and distance from

the Home Point.

The aircraft will land automatically if the current battery level can only support the aircraft long enough

to descend from its current altitude. The user can still use the remote controller to alter the aircraft’s

orientation during the landing process.

The Battery Level Indicator is displayed in the DJI GO 4 app, and is described below:

Battery level Indicator

Critical Low battery level warning

(Red)

Low battery level

warning (Yellow)

Sufcient battery level

(Green)

Remaining ight time

Power requires

to return home

12:29

Smart RTH

Use the RTH button on the remote controller or tap the RTH button in the DJI GO 4 app and follow the on-

screen instructions when GPS is available to initiate Smart RTH. The aircraft status indicator will blink to

display the current status. The aircraft will sense and avoid obstacles on its ight path during Smart RTH.

The aircraft may choose to navigate or hover in place to avoid collision. User can manually navigate the

aircraft to avoid obstacles if the Forward Vision System is disabled or if light levels are low. The pilot can

also immediately exit Smart RTH using the Flight Pause Button on the remote controller or by pressing the

Stop icon in the DJI GO 4 app.

Landing Protection will activate during Smart RTH, Precision Landing and when using Auto Landing in the

DJI GO 4 app:

1. When Landing Protection determines that the ground is suitable for landing, the Mavic Pro will land

gently.

2. If Landing Protection determines that the ground is not suitable for landing, the Mavic Pro will hover and

wait for pilot conrmation.

3. If Landing Protection is not operational, the DJI GO 4 app will display a landing prompt when the Mavic

Pro descends below 0.5 meters. Pull down on the throttle or use the auto landing slider to land.

Aircraft

Mavic Pro

User Manual

Battery Level

Warning

Remark

Aircraft Status

Indicator

DJI GO 4 App Flight Instructions

Low battery

level warning

Battery power

is low. Land the

aircraft.

Aircraft status

indicator blinks

RED slowly.

Tap “Go-home” to have the

aircraft return to the Home

point automatically, or

“Cancel” to resume normal

ight. If no action is taken,

the aircraft will automatically

go home after 10 seconds.

Remote controller will sound

an alarm.

Fly the aircraft

back and land

it as soon as

possible, then

stop the motors

and replace the

battery.

Critical Low

battery level

warning

The aircraft

must land

immediately.

Aircraft status

indicator blinks

RED quickly.

The DJI GO 4 app display

will ash red and the aircraft

will start to descend. The

remote controller will sound

an alarm.

Allow the aircraft to

descend and land

automatically.

Estimated

remaining

ight time

Estimated

remaining ight

based on current

battery level.

N/A N/A N/A

When the Critical low battery level warning is triggered and the aircraft begins to land

automatically, push the left stick upward to make the aircraft hover at its current altitude, giving

you an opportunity to navigate to a more appropriate landing location.

The colored zones and markers on the battery level indicator bar reect the estimated

remaining ight time. They are automatically adjusted according to the aircraft’s current

location and status.

Precision Landing

The Mavic Pro automatically scans and attempts to match the terrain features underneath during Return to

Home. When current terrain matches home point terrain, the Mavic will start landing immediately to achieve

precision landing. The DJI GO 4 app will show a terrain feature mismatch prompt if matching fails.

Precision Landing performance is subject to the following conditions:

a. Home point is recorded upon take off, and cannot not be refreshed during ight.

b. Aircraft must take off vertically. Take off altitude must be greater than 10 meters.

c. Home point terrain features remain largely unchanged.

d. Home point terrain with no distinctive features will affect the performance.

e. Lighting conditions cannot be too light nor too dark.

The following actions are available during landing:

a. Pull throttle down to accelerate landing.

b. Moving the control sticks in any other direction will stop Precision Landing. The Mavic Pro

will descend vertically and Landing Protection will remain active.

Aircraft

Mavic Pro

User Manual

Obstacle Avoidance During RTH

Aircraft can now sense and actively attempt to avoid obstacles during RTH, provided that the lighting

conditions are adequate for the Forward Vision System. Upon detecting an obstacle, the aircraft will act

as follows:

1. Aircraft decelerates when an obstacle is sensed at 49 ft (15 m) ahead.

2. Aircraft stops and hovers then starts ascending vertically to avoid the obstacle. The aircraft will

stop climbing when it is at least 16 ft (5 m) above the detected obstacle.

3. RTH procedures resume. The aircraft will continue ying to the Home Point at the current altitude.

10 m

5 m

RTH Altitude

The aircraft cannot avoid obstructions during RTH when the Forward Vision

System is disabled. Therefore, it is important to set a suitable Failsafe altitude

before each ight. Launch the DJI GO 4 app and enter “Camera” and tap to

set the Failsafe altitude.

10 m

5 m

RTH Altitude

If Return to Home (RTH), including Smart RTH and Low Battery RTH, is

triggered and the aircraft is further than 20 m from the home point:

1. It will return to home at the current altitude if flying at or above the RTH

altitude.

2. It will ascend to the RTH altitude if ying below it.

10 m

5 m

RTH Altitude

If RTH, including Smart RTH and Low Battery RTH, is triggered between 16 ft

and 66 ft (5 m and 20 m) from the home point, and Forward Vision System is

activated:

1. If aircraft's current altitude is greater than 32 ft (10 m), the aircraft will return

to the home point at the current altitude.

2. If aircraft's current altitude is lower than 32 ft (10 m), the aircraft will first

automatically ascend to 32 ft (10 m), from the current altitude.

The ight speed will be adjusted to 9 mph (14 kph). The aircraft will start

landing immediately if the Forward Vision System is deactivated. When entering

Failsafe RTH, the Forward Vision System status is evaluated and RTH will adapt

accordingly.

10 m

5 m

RTH Altitude

Aircraft automatically descends and lands if RTH is triggered when the aircraft

is within a 16 ft (5 m) radius of the Home Point.

返航高度

5米

10米

Aircraft cannot return to the Home Point when the GPS signal is weak or is

unavailable.

20米

Press the Flight Pause button to exit from RTH. The aircraft will stop

ascending and hover.

RTH Safety Notices

Aircraft

Mavic Pro

User Manual

15 meters

5 meters

Intelligent Flight Mode

TapFly

Introduction

With the TapFly feature, users can now tap on the mobile device screen to y in the designated direction

without using the remote controller. The aircraft will automatically avoid obstacles it sees or brake and

hover provided that the lighting is appropriate (< 300 lux) nor too bright (> 10,000 lux).

To ensure the aircraft returns home forwards, it cannot rotate during RTH while the

Forward Vision System is enabled.

The aircraft cannot avoid obstacles above, beside, or behind the aircraft.

2 meters

SPORT

Using TapFly

Ensure the battery level is more than 50% for the Intelligent Flight Battery, and the aircraft is in P-mode.

Then follow the steps below to use TapFly:

1. Take off and ensure the aircraft is ying at least 6ft (2m) above the ground.

2. Launch the DJI GO 4 app and tap , then tap , read and understand the prompts.

09:29

61%

P-GPS

TapFly

ActiveTrack

Gesture

Joystick

H 10.0MD 30M

VS 2.0M/S VPS 2.0MH.S 10.0 M/S

READY TO GO (GPS)

Aircraft

Mavic Pro

User Manual

3. Tap once on the target direction and wait for the icon to appear. Tap again to conrm the selection

and the aircraft will y in that direction.

DO NOT guide the aircraft to fly towards people, animals, small and fine objects (e.g. tree

branches and power lines) or transparent objects (e.g. glass or water).

Watch for the obstacles in the ight path and stay clear of them.

There may be deviations between the expected and the actual ight path of TapFly selection.

The selectable range for the target direction is limited. You cannot make a TapFly selection close to

the upper or lower edge of the screen.

TapFly Mode may not work properly when the aircraft is ying over water or snow covered

areas.

Be extra cautious when ying in dark (< 300 lux ) or bright (>10,000 lux) environments.

09:29

61%

P-GPS

H 10.0MD 30M

VS 2.0M/S VPS 2.0MH.S 10.0 M/S

READY TO GO (GPS)

After conrming the TapFly selection, the aircraft will y in the direction marked by the icon . Note: You

can still use the control stick to control the movement of the aircraft during the ight.

09:29

61%

P-GPS

STOP

H 10.0MD 30M

VS 2.0M/S VPS 2.0MH.S 10.0 M/S

READY TO GO (GPS)

The aircraft will automatically adjust its speed when it senses an obstacle in front or if it is ying too close

to the ground. However, this feature should not be relied upon for navigation between obstacles.

Failsafe procedures will override TapFly. If the GPS signal weakens, the aircraft will exit autonomous ight

and return to home.

Aircraft

Mavic Pro

User Manual

Exit TapFly

Use the following methods to exit TapFly:

1. Press the Flight Pause button on the remote controller.

2. Pull back the pitch stick on the remote controller for 3 seconds or above.

3. Tap “STOP” button on the screen.

STOP

Aircraft will stop and hover after exiting from TapFly. Tap a new target direction to continue ying or begin

manual ight.

ActiveTrack

ActiveTrack allows you to mark and track a moving object on your mobile device screen. The aircraft will

automatically avoid obstacles in its ight path. No external tracking device is required.

The Mavic Pro can automatically identify and trace bikes and other vehicles, people and animals, and

use different tracking strategies for each.

Using ActiveTrack

Ensure the Intelligent Flight Battery has more than 50% power and the aircraft is in P-mode. Then follow

the steps below to use ActiveTrack:

1. Take off and hover at least 6ft (2m) above the ground.

OR OR

Flight Pause button

2 meters

SPORT

2. In the DJI GO 4 app, tap and tap to bring up the ight modes and then select ActiveTrack.

09:29

61%

P-GPS

TapFly

ActiveTrack

Gesture

Joystick

H 10.0MD 30M

VS 2.0M/S VPS 2.0MH.S 10.0 M/S

READY TO GO (GPS)

Aircraft

Mavic Pro

User Manual

3. Tap on the subject you want to track then tap to conrm selection. If the subject is not automatically

recognized, drag a box around it. The box will turn green when tracking is in progress. If the box

turns red, the object could not be identied and you should try again.

09:29

61%

P-GPS

ActiveTrack

H 10.0MD 30M

VS 2.0M/S VPS 2.0MH.S 10.0 M/S

READY TO GO (GPS)

ActiveTrack includes following functions:

Trace Spotlight Prole

The aircraft tracks the

subject at a constant

distance. Use the roll stick

on the remote controller or

the slider in DJI GO 4 to

circle the subject.

Aircraft will not trace a subject

automatically, but it keeps the

camera pointing at the subject

during ight. The remote controller

can be used to maneuver the

aircraft, but yaw is disabled. Using

the left stick and gimbal dial will

adjust subject framing.

The aircraft tracks the subject

at constant angle and distance

from the side. Use the roll stick

on the remote control to circle

the subject.

DO NOT select an area containing people, animals, small, ne objects (e.g. tree branches

and power lines) or transparent objects (e.g. glass or water).

Stay clear of obstacles near the ight path, particularly when the aircraft is ying backward.

Be extra vigilant when using ActiveTrack in any of the following situations:

)

The tracked subject is not moving on a level plane.

)

The tracked subject changes shape drastically while moving.

)

The tracked subject could be blocked or out of sight for a long time.

)

The tracked subject is moving on a snowy surface.

e) Available light is low (< 300 lux) or high (> 10,000 lux).

f) The tracked subject has a similar color or pattern as its surrounding environment.

Aircraft

Mavic Pro

User Manual

Exiting ActiveTrack

Use the following methods to exit ActiveTrack:

1. Press the Flight Pause button on the remote controller.

2. Tap the “STOP” button on the screen.

STOP

After exiting ActiveTrack, the aircraft will hover in place, at which point you may choose to y manually,

track another subject, or return to home.

You must follow local privacy laws and regulations when using ActiveTrack.

Aircraft will not be able to avoid obstacles while in Prole or Spotlight Mode. Use these

modes in open areas.

The aircraft will sense and avoid obstacles on its ight path.

If the aircraft loses track of the subject, because it is moving too fast or obscured, re-select

the subject to resume tracking.

Gesture Mode

In Gesture Mode, the Mavic’s Vision System recognizes gestures, allowing it to follow and capture seles

without a phone or a controller. Follow the steps below to use Gesture Mode:

Modes Prompts Front LEDs Remarks

1. Conrm the

subject

Slow Red Flashing

Ensure the forward vision system is active

and there is enough light. Tap the icon and

move in front of the camera for the Mavic to

recognize you.

2. Conrm the

distance

×2

Red Flashes Twice

Raise your arms and wave to the Mavic,

the Front LED will blink red twice once it

conrms the shooting distance.

3. Sele Count

Down

Fast Red Flashing

Put your fingers in front on your face as

shown.

Gesture Mode can only be used in Photo Mode.

Fly the aircraft 2 meters or higher above the ground then move in front of the camera to be

recognized. Front LED Indicators will blink red rapidly if the Mavic Pro fails to recognize a

subject.

Enabling GPS on your phone will allow the Mavic to follow with more accuracy while ying

in Gesture Mode.

Aircraft

Mavic Pro

User Manual

Forward and Downward Vision System

The Mavic Pro is equipped with a Forward and Downward Vision System that constantly scans for

obstacles in front of it, allowing it to avoid collisions by going around, over or hovering. The down-

ward Vision System uses ultrasound and image data to help the aircraft maintain its current position.

With the help of the Downward Vision System, your Mavic Pro can hover in place more precisely

and y indoors or in other environments where a GPS signal is not available. The main components

Only use Tripod Mode where the GPS signal is strong or light conditions are ideal for the vision

system. If GPS signal is lost and if the vision system cannot function, it will automatically switch

to Atti mode. In this case, ight speed will increase and the aircraft cannot hover in place. Use

Tripod Mode carefully.

Tripod Mode

Tap the icon in the DJI GO 4 app to enable Tripod Mode. In Tripod Mode, the maximum ight speed

is limited to 2.2 mph (3.6 kph). Responsiveness to stick movements is also reduced for smoother more

controlled movements.

It is important that you only fly in conditions where the Vision Position System can function

correctly; otherwise the Terrain Follow Mode will not work.

Push the right stick up until ight speed reaches 3m/s or more to enter Fixed-Wing Mode. Do

not move the sticks in any other direction.

Flight speed cannot be reduced while using Fixed-Wing Mode. You can only push the right

stick up to accelerate. Pushing the right stick down will exit Fixed-Wing Mode.

Other Intelligent Flight Modes and Portrait Mode are disabled when using Fixed-Wing Mode.

Fixed-Wing Mode is available in both P mode and S mode.

Terrain Follow Mode

The Downward Vision System is utilized in Terrain Follow Mode to maintain a height above ground between 1

and 13 meters. This mode is designed for use on grassland sloped at no more than 20°.

Enable the Terrain Follow Mode by tapping the Intelligent Flight Mode icon in the DJI GO 4 app. When this

mode is enabled, the aircraft’s current height will be recorded. The aircraft will maintain the recorded height

during ight and ascend when the slope rises. However, the aircraft will not descend in downward slopes.

Cinematic Mode

Tap the Intelligent Flight Mode icon in the DJI GO 4 app to enable Cinematic Mode. In Cinematic mode,

the braking distance for the aircraft is extended. The aircraft will slow down gently until it stops, keeping

footage smooth and stable even if control inputs are choppy.

Fixed-Wing Mode

The aircraft will y forward automatically at a certain speed after entering Fixed-Wing Mode. Push the left

stick up to ascend and down to descend. Push either stick left or right to rotate the aircraft. Pushing the

right stick up will accelerate and pushing down will exit Fixed-Wing Mode.

In the DJI GO 4 app, tap the icon and enable Fixed-Wing Mode. Push the right stick up until the C1

icon appears, then press the C1 button on the remote controller to enter Fixed-Wing Mode. Push the right

stick down for 3 seconds or press the C2 button on the remote controller to exit Fixed-Wing Mode.

Aircraft

Mavic Pro

User Manual

Detection Range

The detection range of the Forward and Downward Vision System is depicted as follow. Note that the

aircraft cannot sense or avoid the obstacles that are not within the detection range.

1 1

3 3

Quick Calibration

Use quick calibration when the DJI GO 4 app notify that vision sensor calibration is required. Tap

through “Aircraft Status” -> “Vision Sensors” to start quick calibration.

Quick calibration is quick x to vision sensor issues. Connecting the aircraft to a computer to

carry out a full calibration using DJI Assistant 2 is recommended when possible. Only calibrate

when lighting conditions are adequate and on textured surfaces i.e. grass.

Do not calibrate the aircraft on highly reective surfaces such as Marble or ceramics.

Point the aircraft toward the screen

Align the boxes

Pan and tilt the aircraft

Calibrating Sensors

Forward and Downward Vision Systems cameras installed on the aircraft are calibrated on delivery.

However these cameras are vulnerable to excessive impact and will require occasional calibration

via DJI Assistant 2 or the DJI GO 4 app. Follow the steps below to calibrate the camera.

Repeat the steps above to calibrate the Downward Vision System cameras.

of the Forward and Downward Vision System are located on the nose and the bottom of the aircraft;

they include [1] [2] four monocular sensors and [3] two ultrasonic sensors.

Aircraft

Mavic Pro

User Manual

Using the Downward Vision System

The Downward Vision System is activated automatically when the aircraft is turned on. No further

action is required. The Downward Vision System is typically used in indoor environments where

GPS is unavailable. Using the Downward Vision System, the aircraft can hover precisely even with-

out GPS.

Follow the steps below to use Downward Vision System:

1. Toggle the ight mode switch to P-mode.

2. Place the aircraft on a at surface. Note that the Downward Vision System cannot work

properly on surfaces without clear pattern variations.

3. Turn on the aircraft. The aircraft status indicator will ash green two times, which

indicates the Downward Vision System is ready. Gently push the left stick up to lift

off and the aircraft will hover in place.

2m以上

SPORT

Assisted Braking from Forward Vision System

in front. Forward and Downward Vision Systems work best when lighting is adequate and the obstacle is

clearly marked or textured. The aircraft must y at no more than 22mph (36kph) to allow sufcient braking

distance.

Aircraft

Mavic Pro

User Manual

The performance of the Forward and Downward Vision Systems are affected by the surface being

own over. Ultrasonic sensors may not be able to accurately measure distances when operating

above sound-absorbing materials and the camera may not function correctly in suboptimal

environments. The aircraft will switch from P-mode to Atti mode automatically if neither GPS nor

Forward and Downward Vision Systems are available. Operate the aircraft with great caution in

the following situations:

Flying over monochrome surfaces (e.g. pure black, pure white, pure red, pure green).

Flying over a highly reective surfaces.

Flying at high speeds of over 22mph (36kph) at 2 meters or over 11mph (18kph) 1 meter.

Flying over water or transparent surfaces.

Flying over moving surfaces or objects.

Flying over inclined surfaces that will deect sound waves away from the aircraft.

Flying over small and ne objects (e.g. tree branches and power lines).

Flying in an area where the lighting changes frequently or drastically.

Flying over extremely dark (lux < 10) or bright (lux > 100,000) surfaces.

Flying over surfaces that can absorb sound waves (e.g. thick carpet).

Flying over surfaces without clear patterns or texture.

Flying over surfaces with identical repeating patterns or textures (e.g. tiling).

Keep sensors clean at all times. Dirt or other debris may adversely affect their effectiveness.

The Downward Vision System is only effective when the aircraft is at altitudes of 0.3 to 13 meters.

Forward and Downward Vision Systems may not function properly when the aircraft is ying

over water.

The Forward and Downward Vision System may not be able to recognize patterns on the

ground in low light (less than 100lux).

Do not use other ultrasonic devices with a frequency of 40KHz when Forward and Downward

Vision Systems are in operation.

Keep animals away from the aircraft when the Downward Vision System is activated. The sonar

sensor emits high frequency sounds that are audible to some animals.

Flight Recorder

Flight data is automatically recorded to the internal storage of the aircraft. This includes flight

telemetry, aircraft status information, and other parameters. To access this data, connect the aircraft

to the PC through the Micro USB port.

Attaching and Detaching the Propellers

Use only DJI approved propellers with your Mavic Pro. White ring and unmarked propellers indicate

where they should be attached and in which direction whey should spin.

Propellers White Ring Unmarked

Figure

Attach On Motors with white marks Motors without white marks

Legends

Lock : Turn the propellers in the indicated direction to mount and tighten.

Aircraft

Mavic Pro

User Manual

Attaching the Propellers

Attach the white ringed propellers to the mounting base with white marks. Press the propeller down onto

the mounting plate and rotate in the lock direction until it is secured. Attach the other propellers to the

mounting bases without marks. Unfold all the propellers blades.

Marked Unmarked

Detaching the Propellers

Press the propellers down into the motor mount and rotate in the unlock direction.

Be aware of the sharp edges of the propellers. Handle with care.

Use only the DJI approved propellers. Do not mix propeller types.

Stand clear of the motors and DO NOT touch the propellers when they are spinning.

Check that the propellers and motors are installed correctly and rmly before every ight.

Ensure that all propellers are in good condition before each ight. DO NOT use aged, chipped,

or broken propellers.

To avoid injury, STAND CLEAR of and DO NOT touch propellers or motors when they are spinning.

ONLY use original DJI propellers for a better and safer ight experience.

The Intelligent Flight Battery must be fully charged before using it for the rst time.

Intelligent Flight Battery

Introduction

The DJI Intelligent Flight Battery has a capacity of 3830 mAh, a voltage of 11.4 V, and a smart charge/

discharge functionality. It should only be charged using an appropriate DJI approved charger.

Intelligent Flight Battery Charger

Aircraft

Mavic Pro

User Manual

DJI Intelligent Flight Battery Functions

1. Battery Level Display: The LED indicators display the current battery level.

2. Auto-Discharging Function: To prevent swelling, the battery automatically discharges to below 65% of

total power when it is idle for more than ten days. It takes around two days to discharge the battery to

65%. It is normal to feel moderate heat being emitted from the battery during the discharge process.

Discharge thresholds can be set in the DJI GO 4 app.

3. Balanced Charging: Automatically balances the voltage of each battery cell when charging.

4. Overcharge Protection: Charging automatically stops when the battery is fully charged.

5. Temperature Detection: The battery will only charge when the temperature is between 5°C (41°F) and

40°C (104°F).

6. Over Current Protection: The battery stops charging when a high amperage (more than 8.5A) is

detected.

7. Over Discharge Protection: To prevent over-discharge damage, discharging automatically stops.

8. Short Circuit Protection: Automatically cuts the power supply when a short circuit is detected.

9. Battery Cell Damage Protection: The DJI GO 4 app displays a warning message when a damaged

battery cell is detected.

10. Sleep Mode: To save power, the battery will cut off power supply and enter sleep mode after 20

minutes of inactivity.

11. Communication: Information pertaining to the battery’s voltage, capacity, current, etc. is transmitted to

the aircraft’s main controller.

Refer to

Mavic Pro Intelligent Flight Battery Safety Guidelines

before use. Users take full

responsibility for all operations and usage.

Using the Battery

LED2

LED1

LED3

LED4

Battery Level Indicators

Power Button

Turning ON/OFF

Turning On:

Press the Power Button once, then press again and hold for 2 seconds to turn on. The remote

controller system status screen will display the current battery level.

Turning Off:

Press the Power Button once, then press again and hold for 2 seconds to turn off.

Aircraft

Mavic Pro

User Manual

The Battery Level Indicators will also show the current battery level during charging and

discharging. The indicators are dened below.

: LED is on.

: LED is ashing.

: LED is off.

Low Temperature Notice:

1. Battery capacity is signicantly reduced when ying in low temperature (-10°C and 5°C) environments.

2. Batteries cannot be used in extremely low temperature (< -10°C) environments.

It is recommended to fully charged the battery when taking off in temperature between -10°C and 5°C.

3. End the flight as soon as the DJI GO 4 app displays the “Low Battery Level Warning” in low

temperature environments.

4. Keep the battery indoors to warm it before ying in low temperature environments.

5. To ensure optimal performance of the battery, keep the battery temperature above 20°C.

In cold environments, insert the battery into the battery compartment and turn on the aircraft for

approximately 1-2 minutes to warm up before taking off.

Checking the Battery Level

The Battery Level Indicators display how much power remains. When the battery is turned off, press the

Power Button once, the Battery Level Indicators will light up to display the current battery level. See below

for details.

Battery Level Indicators

LED1 LED2 LED3 LED4 Battery Level

87.5%~100%

75%~87.5%

62.5%~75%

50%~62.5%

37.5%~50%

25%~37.5%

12.5%~25%

0%~12.5%

=0%

Charging the Intelligent Flight Battery

1. Connect the Battery Charger to a power source (100-240V, 50/60Hz).

2. Connect the Battery to the Charger to start charging.

3. The Battery Level Indicator will display the current battery level as it is charging.

4. The Intelligent Flight Battery is fully charged when the Battery Level Indicators are all off. Detach the

battery from the Charger.

5. Allow battery temperature to drop to room temperature before storing for an extended period.

6. The charger will stop charging the battery if the battery cell’s temperature is not within the operating

range (5°C to 40°C).

Aircraft

Mavic Pro

User Manual

Charger

Intelligent Flight Battery

Power Outlet

Battery Level Indicators While Charging

LED1 LED2 LED3 LED4 Battery Level

0%~25%

25%~50%

50%~75%

75%~100%

Fully Charged

Battery Protection LED Display

The table below shows battery protection mechanisms and corresponding LED patterns.

Battery Level Indicators while Charging

LED1 LED2 LED3 LED4 Blinking Pattern Battery Protection Item

LED2 blinks twice per second Over current detected

LED2 blinks three times per second Short circuit detected

LED3 blinks twice per second Over charge detected

LED3 blinks three times per second Over-voltage charger detected

LED4 blinks twice per second Charging temperature is too low

LED4 blinks three times per second Charging temperature is too high

Always turn off the battery before inserting it or removing it from the Mavic Pro. Never insert or

remove a battery when it is turned on.

After these issues are resolved, press the Power Button to turn off the Battery Level Indicator. Unplug the

Intelligent Flight Battery from the charger and plug it back in to resume charging. You do not need to un-

plug and plug in the charger in the event of a room temperature error; the charger will resume charging

when the temperature is within the allowable range.

DJI does not take any responsibility for damage caused by third-party chargers.

How to discharge the Intelligent Flight Battery before transport the batteries for long trip:

Fly the Mavic Pro outdoors until there is less than 20% of power left, or until the battery can no

longer be turned on.

Remote Controller

This section describes the features

of the remote controller and includes

instructions for controlling the aircraft

and the camera.

Remote Controller

Remote Controller Prole

The Mavic Pro remote controller is a multi-function wireless communication device that integrates the

video downlink system and aircraft remote control system. The video downlink and aircraft remote control

system operate at 2.4 GHz. The remote controller features a number of camera control functions, such

as taking and previewing photos and videos, as well as controlling gimbal motion. The battery level is

displayed via the LCD Screen of the remote controller.

Compliance Version:

The remote controller is compliant with local compliance and regulations.

Operating Mode:

Control can be set to Mode 1 or Mode 2, or to a custom mode.

Mode 1:

The right stick serves as the throttle.

Mode 2:

The left stick serves as the throttle.

To prevent transmission interference, do not operate more than three aircraft in the same area.

Using the Remote Controller

Turning the Remote Controller On and O

The Mavic Pro remote controller is powered by a 2S rechargeable battery that has a capacity of

2970 mAh. Follow the steps below to turn on your remote controller:

1. When the remote controller is turned off, press the Power Button once. The LCD Screen will display the

current battery level.

2. Press once, then again and hold the Power Button to turn on the remote controller.

3. The remote controller will beep when it is turned on.

4. Repeat Step 2 to turn off the remote controller.

Remote Controller

Mavic Pro

User Manual

Charger

Power Outlet

Controlling the Camera

Shoot videos/photos, and adjust camera settings via the Shutter Button, Record Button, and Camera Set-

tings Dial on the remote controller.

Camera Settings Dial

Turn the dial to adjust camera settings such as ISO, shutter speed, without letting go of the remote

controller.

2. Shutter Button

Press to take a photo. If burst mode is activated, multiple photos will be taken with a single press.

3. Record Button

Press once to start recording video, then press again to stop recording.

4. Gimbal Dial

Control the tilt of the gimbal.

Charging the Remote Controller

Charge the remote controller using the included charger. Refer to the gure below for more details.

Remote Controller

Mavic Pro

User Manual

The Remote Control is set to Mode 2 by default.

Stick Neutral/Mid-Point: Control sticks are in the center position.

Moving the Control Stick: The control stick is pushed away from the center position.

Right StickLeft Stick

Turn RightTurn Left

Down

RightLeft

Down

Turn RightTurn Left

RightLeft

Forward

Backward

Left Stick Right Stick

Forward

Backward

Right Stick

Down

Forward

Backward

Left Stick

Turn RightTurn Left

RightLeft

Controlling the Aircraft

This section explains how to control the orientation of the aircraft through the remote controller. Control

can be set to Mode 1 , Mode 2 or Mode 3, or to a custom mode.

Mode 1

Mode 2

Mode 3

Remote Controller

Mavic Pro

User Manual

Remote Controller

(Mode 2)

Aircraft

(

Indicates Nose Direction)

Remarks

Moving the left stick up and down changes the

aircraft’s elevation.

Push the stick up to ascend and down to descend.

When both sticks are centered, the Mavic Pro will

hover in place.

The more the stick is pushed away from the center

position, the faster the Mavic Pro will change

elevation. Always push the stick gently to prevent

sudden and unexpected elevation changes.

Moving the left stick to the left or right controls the

rudder and rotation of the aircraft.

Push the stick left to rotate the aircraft counter-

clockwise, push the stick right to rotate the aircraft

clockwise. If the stick is centered, the Mavic Pro

will maintain its current orientation.

The more the stick is pushed away from the center

position, the faster the Mavic Pro will rotate.

Moving the right stick up and down changes the

aircraft’s forward and backward pitch.

Push the stick up to fly forward and down to fly

backward.

Mavic Pro

will hover in place if the stick is

centered.

Push the stick further away from the center position for

a larger pitch angle (maximum 30˚) and faster ight.

Moving the right stick control left and right changes

the aircraft’s left and right pitch.

Push left to y left and right to y right. The Mavic

Pro will hover in place if the stick is centered.

Press the Flight Pause button once to exit from

the ActiveTrack, TapFly and Intelligent Navigation

ight mode. The aircraft will hover at the current

position.

Keep the remote controller away from magnetic materials to avoid it being affected by magnetic

interference.

Ensure the control sticks are in the center position and not being squeezed by external force

during transportation or storage.

Remote Controller

Mavic Pro

User Manual

Position Flight Mode

SPORT

P-mode

SPORT

S-mode

Flight Mode Switch

Toggle the switch to select the desired flight mode.

Choose between P-mode and S-mode.

P-mode (Positioning)

P-mode works best when the GPS signal is strong. The aircraft utilizes the GPS

and Forward and Downward Vision Systems to locate itself, automatically stabilize, and navigate between

obstacles. Advanced features such as TapFly and ActiveTrack are enabled in this mode.

Note: P-mode requires larger stick movements to achieve high speeds.

S-mode (Sport):

The handling of the aircraft is adjusted in to enhance maneuverability and speed.

Maximum speed is increased to 40mph (65kph). Forward Vision System is disabled in this mode.

The Flight Mode is locked in P Mode by default, regardless of switch position. To switch ight modes, go

to Camera view in the DJI GO 4 app, tap and enable “Multiple Flight Modes”. After enabling multiple

ight modes, toggle the switch to P and then to S to y in Sport Mode.

The Mavic Pro is y in P-mode by default every time after powering on. Toggle the Flight Mode Switch to

P and then to S every time before you use S mode.

RTH Button

Press and hold the RTH button to start the Return-to-Home (RTH) procedure. The aircraft will then return to

the last recorded Home Point. Press this button again to cancel the RTH procedure and regain control of

the aircraft.

SPORT

Remote Controller

Mavic Pro

User Manual

Optimal Transmission Range

The transmission signal between the aircraft and the remote controller is most reliable within the area that

depicted below:

Optimal Transmission Range

Ensure that the aircraft is ying within the optimal transmission zone. To achieve the best transmission

performance, maintain the appropriate relationship between the operator and the aircraft.

strong weak

LCD Screen

The LCD Screen displays various system statuses including ight telemetry and battery level in real time.

Refer to the gure below for the meaning of each icon on the LCD Screen.

Flight speed

Aircraft battery level

GPS signal strength

Flight mode*

RC signal strength

Motor rotation

speed

System status prompt

RC battery level

Distance to the ground

Vision System

Camera status

Flight altitude

Exposure compensation

Ascend/Descend

Flight distance

Sport modes

Micro SD

placement

* On the remote controller’s screen, the Primary remote controller displays MCTL while the Secondary

remote controller displays ight mode.

Remote Controller

Mavic Pro

User Manual

Dual Remote Controller Mode

Mavic Pro supports Dual Remote Controller Mode, Mavic Pro rmware version 01.03.0400, DJI GO 4 app

iOS v4.0.5 or DJI GO 4 app Android v4.0.5 are required. Two remote controllers can connect to the same

aircraft in Dual Remote Controller Mode.

Both the Primary remote controller and the Secondary remote controller are able to control the orientation

of the aircraft and the movement of the gimbal and camera operation after the remote controllers have

been linked to the aircraft.

Please pay attention to the below operation differences of the Primary and Secondary remote controller.

1. Gimbal Dial

Both Primary remote controller and Secondary remote controller are able to control the gimbal dial

but the Primary remote controller has priority. For example, the Secondary remote controller is unable

to control the gimbal dial when the Primary remote controller is using the gimbal dial. However, after

stopping control of the gimbal dial for two seconds, the Secondary remote controller is able to control

the gimbal dial.

2. Control Stick

Both the Primary remote controller and Secondary remote controller are able to control the orientation

of the aircraft using control sticks. The Primary remote controller has priority. The Secondary remote

controller is unable to control the aircraft’s orientation when the Primary remote controller is operating

the control sticks. When the control sticks are idle for two seconds, the Secondary remote controller is

able to control the aircraft’s orientation.

To ensure ight safety, when pulling down the throttle stick on the Secondary remote controller, push

both sticks down and inwards. When the Primary remote controller is controlling the aircraft, the aircraft

will not respond to that command, even if the Primary remote controller has been idle for more than two

seconds.

The Secondary remote controller sticks need to be released so that the Secondary remote controller is

able to control the aircraft.

3. Flight Mode Switch

Only use the Primary remote controller to switch the ight mode. The Flight Mode Switch is disabled on

the Secondary remote controller.

4. DJI GO 4 App Settings

The display and parameter settings for the Primary and Secondary remote controllers in DJI GO 4 are

the same. Everything except the ght controller, vision system, video transmission, Intelligent Flight

Battery and gimbal parameters cannot be set up when using the Secondary remote controller. Display

and parameter settings in the DJI GO 4 for Primary and Secondary remote controllers are the same.

Remote Controller

Mavic Pro

User Manual

Linking the Remote Controller

The remote controller is linked to your aircraft before delivery. Linking is only required when using a new

remote controller for the rst time. Follow these steps to link a new remote controller:

1. Turn on the remote controller and connect to the mobile device, and turn on the aircraft. Launch the

DJI GO 4 app.

2. Enter “Camera” and tap on and then tap the “Linking Primary RC” or “Linking Secondary

RC” button to conrm.

Toggle the Control Mode switch to RC mode before linking.

3. The remote controller is ready to link.

4. Locate the linking button on the side of the aircraft, as shown in the gure below. Press the link button

to start linking. The Linking Status Indicator will display a solid green once the remote controller is

successfully linked to the aircraft, and the LCD screen on the remote controller will display the aircraft’s

information.

Link Button

Linking Status Indicator

The remote controller will un-link itself from an aircraft if a new remote controller is linked to the

same aircraft.

In dual remote controller mode, the slave remote controller must be relinked to the aircraft when

the master remote controller has been relinked to the aircraft.

Camera and Gimbal

This section provides the technical

specications of the camera and

explains the gimbal’s operation modes.

Gimbal Camera

Camera and Gimbal

Camera Prole

The on-board camera uses the 1/2.3 inch CMOS sensor to capture video up to 4K at 30 fps with the

Mavic Pro and 12 megapixel stills. You may choose to record video in either MOV or MP4 formats.

Available picture shooting modes include burst, continuous, and interval mode. A live preview of what the

camera sees can be monitored on the connected mobile device via the DJI GO 4 app.

Camera Micro SD Card Slot

To store your photos and videos, insert the Micro SD card into the slot, as shown below, before

turning on the Mavic Pro. The Mavic Pro comes with a 16 GB Micro SD card and supports Micro

SD cards up to 64 GB. A UHS-1 Micro SD card is recommended due to their fast read and write

speeds allowing you to save high-resolution video data.

Do not remove the Micro SD card from the Mavic Pro when it is turned on.

To ensure the stability of the camera system, single video recordings are capped at 30 minutes.

Camera Data Port

Turn on the Mavic Pro and connect a USB cable to the Micro USB Port to download photos and videos to

your computer.

The aircraft must be turned on before attempting to access the les on the Micro SD card.

Gimbal Camera

Mavic Pro

User Manual

Gimbal

Gimbal Prole

The 3-axis gimbal provides a steady platform for the attached camera, allowing you to capture clear,

stable images and video. The gimbal can tilt the camera within a 120˚ range.

Use the gimbal dial on the remote controller to control camera tilt, or go to Camera View in the DJI

GO 4 app, tap and hold on the screen until a blue circle appears, then drag the circle to control

the camera’s tilt.

The controllable range of the gimbal roll axis is 0° to 90°, enabling you to shoot in Landscape

Mode and Portrait Mode. The roll axis will rotate 90° when Portrait Mode is enabled.

It is recommended to use the Portrait Mode for taking photos instead of recording video. When

the aircraft is own in ways that taxes the system, for example emergency braking or ying in

Sport Mode, the gimbal roll axis will reach its endpoint and cause the gimbal to vibrate.

-90°

0°

30°

Gimbal Operation Modes

Two gimbal operation modes are available. Switch between the different operation modes on the camera

settings page of the DJI GO 4 app. Note that your mobile device must be connected to the remote

controller for changes to take effect. Refer to the table below for details:

Follow Mode

The angle between the gimbal’s orientation and aircraft’s nose remains

constant at all times.

FPV Mode

The gimbal will synchronize with the movement of the aircraft to provide a

rst-person perspective ying experience.

Remove the Gimbal Clamp before powering on the aircraft.

A gimbal motor error may occur in these situations:

(1) The aircraft is placed on uneven ground or the gimbal’s motion is obstructed.

(2) The gimbal has been subjected to excessive external force, such as a collision.

Take off from at, open ground and protect the gimbal at all times.

Flying in heavy fog or clouds may make the gimbal wet, leading to temporary failure. The

gimbal will recover full functionality after it dries.

It is normal for the gimbal to beep upon initialization.

DJI GO 4 App

This section introduces the main

functions of the DJI GO 4 app.

DJI GO 4 App

The DJI GO 4 app is a mobile application designed specically for DJI equipment. Use this app to control

the gimbal, camera, and other aircraft functions. The app features Equipment, Editor, SkyPixel and Me

sections, which are used for conguring your aircraft, editing and sharing your photos and videos with

others.

Connect your DJI device

Mavic Pro

Use AEB shoot to get more dynanic image

Learn more

Camera

80%

Equipment Editor Skypixel Me

Equipment

Enter Camera View by tapping Camera on the DJI GO 4 welcome screen.

Camera View

09:29

61%

P-GPS

READY TO GO (GPS)

H 10.0MD 30M

VS 2.0M/S VPS 2.0MH.S 10.0 M/S

10 118 97654321

DJI GO 4 App

Mavic Pro

User Manual

1. System Status

READY TO GO (GPS)

: This icon indicates aircraft ight status and various warning messages.

2. Obstacles Detection Status

: Red bars are displayed when obstacles are close to the aircraft. Orange bars are

displayed when obstacles are in detection range.

3. Battery Level Indicator

: The battery level indicator provides a dynamic display of the battery level. The colored

zones on the battery level indicator represent the power levels needed to carry out different functions.

4. Flight Mode

: The text next to this icon indicates the current ight mode.

Tap to congure the MC (Main Controller) Settings. These settings allow you to modify ight limits and

set gain values.

5. Camera Parameters

Displays camera settings parameters and capacity of the Micro SD card.

6. GPS Signal Strength

: Shows the current GPS signal strength. White bars indicate adequate GPS strength.

7. Forward Vision System Status

: Tap into this button to enable or disable features provided by the Forward Vision System.

8. Remote Controller Signal

: This icon shows the strength of the remote controller signal. The icon will blink when an

interference is recognized during ight. When there are no additional warnings in DJI GO 4, it means

that the interference will not affect operation and overall ight experience.

9. HD Video Link Signal Strength

: This icon shows the strength of the HD video downlink connection between the aircraft and the

remote controller. The icon will blink when an interference is recognized during ight. When there are

no additional warnings in DJI GO 4, it means that the interference will not affect operation and overall

ight experience.

10. Battery Level

61%

: This icon shows the current battery level.

Tap to view the battery information menu, set the various battery warning thresholds, and view the

battery warning history.

. Focus/Metering Button

/ : Tap to switch between focus and metering mode. Tap to select object for focusing or

metering. Auto Focus-Continuous will be triggered automatically according to the status of the aircraft

and camera after enabling Auto Focus.

DJI GO 4 App

Mavic Pro

User Manual

12. General Settings

: Tap to enter general setting menu for setting metrics, enabling livestream, display ight routes

and so on.

13. Auto Exposure Lock

: Tap to lock the exposure value.

14. Gimbal Slider

: Displays the pitch of the gimbal.

15. Photo/Video Button

: Tap to switch between photo and video recording modes.

16. Shoot / Record Button

/ : Tap to start shooting photos or recording video.

17. Camera Settings

: Tap to set ISO, shutter and auto exposure values of the camera.

18. Playback

: Tap to enter the playback page and preview photos and videos as soon as they are captured.

19. Flight Telemetry

D 30M

: Distance between the aircraft and the Home Point.

H 10.0M

: Height from the ground.

HS 10.0M/S

: Aircraft horizontal speed.

VS 2.0M/S

: Aircraft vertical speed.

20. Map

Tap to view map.

21. Intelligent Flight Mode

: Tap to select Intelligent Flight Mode.

22. Smart RTH

: Initiate RTH home procedure. Tap to have the aircraft return to the last recorded home point.

23.

Auto Takeoff/Landing

/ : Tap to initiate auto takeoff or landing.

DJI GO 4 App

Mavic Pro

User Manual

Slide left in the Camera view to enter the menu shown below.

09:29

61%

P-GPS

READY TO GO (GPS)

H 10.0MD 30M

VS 2.0M/S VPS 2.0MH.S 10.0 M/S

Portrait/Landscape Gimbal up/down

Adjust screen brightness

Home Point: Aircraft Home Point: Me

Portrait/Landscape

Switch to Portrait mode by tapping the icon.

Gimbal up/down

Tap the icon to point the camera downward or forward.

Home Point

Use aircraft location or remote controller location as the home point.

Control Mode Switch

Using Mobile Device to Control Aircraft

Apart from using the included remote controller, you may use the Wi-Fi connection on the mobile device

to control the aircraft. Follow the instructions below to learn how to control the aircraft over Wi-Fi.

1. Power off the aircraft, then toggle the Control Mode Switch to the “Wi-Fi” position.

2. Power on the aircraft.

3. Turn on your mobile device's Wi-Fi and enter the Wi-Fi password shown on the front arm to connect to

the Mavic network.

4. Tap icon to take off the aircraft automatically. Tap on the screen and use the Virtual Joysticks to

navigate the aircraft.

24. Back

: Tap this icon to return to the main menu.

DJI GO 4 App

Mavic Pro

User Manual

Using Virtual Joysticks

Ensure the mobile device has been connected to the aircraft before using the Virtual Joysticks. The

illustrations below are based on Mode 2 (left stick as throttle).

09:29

61%

P-GPS

READY TO GO (GPS)

Virtual Joysticks GUI

Left Right

Move the aircraft upwards, downwards or rotate to the left or right by pressing on the left half of the

screen. Move the aircraft forwards, backwards or rotate to the left or right by pressing on the right half of

the screen.

Tap on the " " button to enable or disable Virtual Joysticks.

Launch the DJI GO 4 app and tap the icon on the top right of your screen, then scan the Wi-

Fi QR Code on the front arm to start connection. Note that this feature is available on Android

devices.

When using Wi-Fi in a wide open area with no Electromagnetic Interference, transmission

distance is approximately 262ft (80m) at an altitude of 164ft (50m). The maximum ight speed

is 9mph (14kph), maximum ascent speed is 2m/s and maximum descent speed is 1m/s.

The Wi-Fi frequency of your mobile device can be set to 2.4GHz (default) or 5GHz. On

supported devices, set Wi-Fi to 5GHz for less interference.

Press and hold the linking button for 5 seconds or more to set Wi-Fi password and SSID. Press

and release to rest the transmission frequency to 2.4 GHz.

Using Wi-Fi mode in a wide open area with less Electromagnetic Interference. If the Wi-Fi is

severely affected by the Electromagnetic Interference, use the remote controller to fly your

aircraft instead.

The area beyond the white cycle is also responsive to control commands.

DJI GO 4 App

Mavic Pro

User Manual

Editor

An intelligent video editor is built into the DJI GO 4 app. After recording several video clips and

downloading them to your mobile device, go to Editor on the home screen. You can then select a

template and a specied number of clips which are automatically combined to create a short lm that can

be shared immediately.

SkyPixel

View and share the photos and videos in the SkyPixel page.

If you already have a DJI account, you will be able to participate in forum discussions, and share your

creation with the community.

Flight

This section describes safe ight

practices and ight restrictions.

Flight

Once pre-ight preparation is complete, it is recommended that you use the ight simulator in the DJI GO

4 app to hone your ight skills and practice ying safely. Ensure that all ights are carried out in an open

area.

Flight Environment Requirements

1. Do not use the aircraft in severe weather conditions. These include wind speeds exceeding 10 m/s,

snow, rain and fog.

2. Fly in open areas. Tall structures and large metal structures may affect the accuracy of the on-board

compass and GPS system.

3. Avoid obstacles, crowds, high voltage power lines, trees, and bodies of water.

4. Minimize interference by avoiding areas with high levels of electromagnetism, including base stations

and radio transmission towers.

5. Aircraft and battery performance is subject to environmental factors such as air density and temperature.

Be very careful when ying at altitudes greater than 16404 feet (5000 meters) above sea level, as the

performance of the battery and aircraft may be affected.

6. The Mavic Pro cannot use P-mode within the polar areas.

Flight Limits and No-Fly Zones

All unmanned aerial vehicle (UAV) operators should abide by all regulations set forth by government and

regulatory agencies including the ICAO and the FAA. For safety reasons, ights are limited by default,

which helps users operate this product safely and legally. Flight limitations include height limits, distance

limits, and No-Fly Zones.

When operating in P-mode, height limits, distance limits, and No-Fly Zones function concurrently to

manage ight safety.

Maximum ight altitude & Radius Limits

Maximum flight altitude and radius limits may be changed in the DJI GO 4 app. Be aware that the

maximum ight altitude cannot exceed 1640 feet (500 meters). In accordance with these settings, your

Mavic Pro will y in a restricted cylinder, as shown below:

Maximum Flight Altitude

Max Radius

Home Point

Height of aircraft

when turned on

Flight

Mavic Pro User Manual

GPS Signal Weak Blinking Yellow

Flight Limits DJI GO 4 App Aircraft Status Indicator

Maximum

Flight

Altitude

Height is restricted to 16 feet (5

meters) when the GPS signal is

weak and Downward Vision System

is activated. Height is restricted to

98 feet (30 meters) when the GPS

signal is weak and Downward

Vision System is inactivated.

Warning: Height limit

reached.

None.

Max Radius No limits

If the aircraft ies out of the limit, you can still control the aircraft, but you cannot y it any farther.

If the aircraft ies out of the max radius, it will y back within range automatically when

GPS signal is strong.

For safety reasons, please do not y close to airports, highways, railway stations, railway lines,

city centers, or other sensitive areas. Fly the aircraft only within your line of sight.

No-Fly Zones

All No-Fly Zones are listed on the DJI official website at http://www.dji.com/flysafe/no-fly. No-Fly

Zones are divided into Airports and Restricted Areas. Airports include major airports and flying

elds where manned aircraft operate at low altitudes. Restricted Areas include border lines between

countries or sensitive institute.

GPS Signal Strong Blinking Green

Flight Limits DJI GO 4 App Aircraft Status Indicator

Maximum Flight

Altitude

Aircraft's altitude cannot

exceed the specied value.

Warning: Height

limit reached.

None.

Max Radius

Flight distance must be within

the max radius.

Warning: Distance

limit reached.

Rapid red ashing

when close to the max

radius limit.

Preight Checklist

1. Remote controller, Intelligent Flight Battery, and mobile device are fully charged.

2. Propellers are mounted correctly and rmly.

3. Micro SD card has been inserted, if necessary.

4. Gimbal is functioning normally.

5. Motors can start and are functioning normally.

6. The DJI GO 4 app is successfully connected to the aircraft.

7. Ensure that the sensors for the Forward and Downward Vision System are clean.

Flight

Mavic Pro

User Manual

Calibrating the Compass

Only calibrate the compass when the DJI GO 4 app or the status indicator prompt you to do so. Observe

the following rules when calibrating your compass:

DO NOT calibrate your compass where there is a chance of strong magnetic interference, such

as magnetite, parking structures, and steel reinforcements underground.

DO NOT carry ferromagnetic materials with you during calibration such as cellular phones.

The DJI GO 4 app will prompt you to resolve the compass issue if the compass is affected by

strong interference after calibration is complete. Follow the prompted instructions to resolve the

compass issue.

Calibration Procedures

Choose an open area to carry out the following procedures.

1. Tap the Aircraft Status Bar in the app and select “Calibrate”, then follow the on-screen instructions.

2. Hold the aircraft horizontally and rotate 360 degrees. The Aircraft Status Indicators will display a solid

green light.

3. Hold the aircraft vertically, with nose pointing downward, and rotate it 360 degrees around the center

axis.

Flight

Mavic Pro User Manual

If the Aircraft Status Indicator blinks red and yellow after the calibration procedure, move your

aircraft to a different location and try again.

DO NOT calibrate the compass near metal objects such as a metal bridge, cars, scaffolding.

If the aircraft status indicator is blinking red and yellow alternately after placing the aircraft on

the ground, the compass has detected magnetic interference. Change your location.

Auto Takeoff and Auto Landing

Auto Takeoff

Use auto takeoff only if the Aircraft Status Indicators are blinking green. Follow the steps below to use the

auto takeoff feature:

1. Launch the DJI GO 4 app, and enter “Camera” page.

2. Complete all steps on the pre-ight checklist.

3. Tap “ ”, and conrm that conditions are safe for ight. Slide the icon to conrm and takeoff.

4. Aircraft takes off and hovers at 1.2 meters above ground.

Aircraft Status Indicator blinks rapidly when it is using the Downward Vision System for

stabilization. The aircraft will automatically hover below 13 meters. It is recommended to wait

until there is sufcient GPS before using the Auto Take-off feature.

4. Re-calibrate the aircraft if the aircraft status indicators blink red.

Auto-Landing

Use auto-landing only if the Aircraft Status Indicator is blinking green. Follow the steps below to use the

auto-landing feature:

1. Tap on , to ensure the landing condition is ideal. Slide to conrm.

2. Abort landing process immediately by using the button on the screen.

3. a. When Landing Protection determines that the ground is suitable for landing, the Mavic Pro will

land gently.

b. If Landing Protection determines that the ground is not suitable for landing, the Mavic Pro will hover

and wait for pilot conrmation.

c. If Landing Protection is not operational, the DJI GO 4 app will display a landing prompt when the

Mavic Pro descends below 0.5 meters. Pull down on the throttle or use the auto landing slider to

land.

4. Aircraft will land and turn off automatically.

Flight

Mavic Pro

User Manual

Stopping the Motors

There are two methods to stop the motors.

Method 1: When Mavic Pro has landed, push the left stick down , then conduct the same CSC that was

used to start the motors, as described above . Motors will stop immediately. Release both sticks once

motors stop.

Method 2: When the aircraft has landed, push and hold the left stick down. The motors will stop after three

seconds.

Method 1 Method 2

Flight Test

Takeo/Landing Procedures

1. Place the aircraft in an open, at area with the battery level indicators facing towards you.

2. Turn on the remote controller and your mobile device, then turn on the Intelligent Flight Battery.

3. Launch the DJI GO 4 app and enter the Camera page.

4. Wait until the Aircraft Indicator blinks green. This means the Home Point is recorded and it is now safe

to y. If they ash yellow, the Home Point has not been recorded.

5. Push the left stick up slowly to take off or use Auto Takeoff.

6. Shoot photos and videos using the DJI GO 4 app.

7. Pull down the left stick to descend, the aircraft will hover at 1.5 ft (0.5 m) above the ground for about 1

second, then hold the left stick at its lowest position until you touch the ground and the motors stop.

8. Turn off the Intelligent Flight Battery rst, then the Remote Controller.

Stop Motors Mid-ight

Stop motors mid-ight will cause the aircraft to crash. The motors can only be stopped mid-ight when the

ight controller detects a critical error. (This setting can be changed in the DJI GO 4 app)

Starting/Stopping the Motors

Starting the Motors

A Combination Stick Command (CSC) is used to start the motors. Push both sticks to the bottom

inner or outer corners to start the motors. Once the motors have started spinning, release both sticks

simultaneously.

Flight

Mavic Pro User Manual

When the Aircraft Status Indicator blinks yellow rapidly during ight, the aircraft has entered Failsafe

mode.

A low battery level warning is indicated by the Aircraft Status Indicators blinking red slowly or

rapidly during ight.

Watch our video tutorials for more ight information.

Video Suggestions and Tips

1. Go through the full pre-ight checklist before each ight.

2. Select the desired gimbal operation mode in the DJI GO 4 app.

3. Only shoot video when ying in P-mode.

4. Always y in good weather and avoid ying in rain or heavy wind.

5. Choose the camera settings that suit your needs. Settings include photo format and exposure

compensation.

6. Perform ight tests to establish ight routes and preview scenes.

7. Push the control sticks gently to keep the aircraft’s movement smooth and stable.

Appendix

Specications

Aircraft

Weight 1.62 lbs (734 g)

Weight (including gimbal cover) 1.64 lbs (743 g)

Dimensions 83 × 83 × 198 mm (folded)

Diagonal Length (propellers excluded) 335 mm

Max Ascent Speed 16.4 ft/s (5 m/s) in Sport Mode

Max Descent Speed 9.8 ft/s (3 m/s)

Max Speed 40.4 mph (65 kph) in Sport Mode without wind

Max Service Ceiling Above Sea Level 16404 feet (5000 m)

Max Flight Time 27 minutes (0 wind at a consistent 15.5 mph (25 kph))

Max Hovering Time 24 minutes (0 wind)

Avg. Flight Time 21 minutes (general ight, 15% battery left)

Max Flight Distance 8 mi (13 km, 0 wind)

Operating Temperature 32° to 104° F (0° to 40° C)

Satellite Positioning Systems GPS/GLONASS

Gimbal

Controllable Range Pitch: -90° to +30°, Roll: 0°or 90° (Horizontally and vertically)

Forward Vision System

Sensing Range

Precision measurement range: 2 ft (0.7 m) to 49 ft (15 m)

Detectable range: 49 ft (15 m) to 98 ft (30 m)

Operating Environment Surfaces with clear patterns and adequate lighting (lux > 15)

Downward Vision System

Velocity Range ≤ 22.4 mph (36 kph) at 6.6 ft (2 m) above ground

Altitude Range 1 - 43 feet (0.3 - 13 m)

Operating Range 1 - 43 feet (0.3 - 13 m)

Operating Environment Surfaces with a clear patterns and adequate lighting (lux > 15)

Camera

Sensor

1/2.3” CMOS Effective pixels:12.35 Megapixels

(Total pixels: 12.71 M)

Lens

78.8° FOV, 28 mm (35 mm format equivalent) f/2.2

Distortion <1.5% Focus from 0.5 m to ∞

ISO Range 100 - 3200 (video), 100 - 1600 (photo)

Electronic Shutter Speed 8 s to 1/8000 s

Max Image Size 4000×3000

Still Photography Modes

Single shot

Burst shooting: 3/5/7 frames

Auto Exposure Bracketing (AEB):

3/5 bracketed frames at 0.7EV Bias

Interval

HDR

Appendix

Mavic Pro

User Manual

Remote Controller

Operating Frequency 2.400 GHz to 2.4835 GHz

Max Transmission Distance

FCC Compliant: 4.3 mi (7 km); CE Compliant: 2.5 mi (4 km)

Unobstructed and free of interference.

Operating Temperature 32° to 104° F (0° to 40° C)

Battery 2970 mAh

Transmitter Power ( EIRP ) FCC: ≤ 26 dBm; CE: ≤ 20 dBm

Operating Voltage 950 mA @ 3.7 V

Supported Mobile Device Size

Thickness supported: 6.5 - 8.5 mm, Max length: 160 mm

Supported USB port types:

Lightning, Micro USB (Type-B), USB Type-C

Charger

Voltage 13.05 V

Rated Power 50 W

Intelligent Flight Battery

Capacity 3830 mAh

Voltage 11.4 V

Battery Type LiPo 3S

Energy 43.6 Wh

Net Weight Approx. 0.5 lbs (240 g)

Operating Temperature 41° to 104° F (5° to 40° C)

Max. Charging Power 100 W

Video Recording Modes

C4K: 4096×2160 24p, 4K: 3840×2160 24/25/30p

2.7K: 2720×1530 24/25/30p

FHD: 1920×1080 24/25/30/48/50/60/96p

HD: 1280×720 24/25/30/48/50/60/120p

Video Storage Bitrate 60 Mbps

Supported File Systems FAT32 (≤ 32 GB), exFAT (> 32GB)

Photo JPEG, DNG

Video MP4, MOV (MPEG-4 AVC/H.264)

Supported SD Cards

microSD

. Max capacity: 64GB Class 10 or UHS-1 rating

required.

Firmware Updates

Use DJI Assistant 2 or DJI GO 4 app to update aircraft and remote controller.

Using the DJI GO 4 App

Connect the remote controller and the DJI GO 4 app, You will be reminded if a new rmware upgrade

is available. To start upgrading, connect your mobile device to the Internet and follow the on-screen

instructions.

Appendix

Mavic Pro

User Manual

Using DJI Assistant 2

Use the DJI Assistant 2 to update the rmware for the remote controller and the aircraft simultaneously.

Follow the instructions below to update the rmware through DJI Assistant 2:

1. With the remote controller and the aircraft powered off, connect the remote controller to the computer

through the charging port using a micro USB cable.

2. Power on the remote controller and aircraft.

3. Launch DJI Assistant 2 and login with your DJI account.

4. Select “Mavic Pro” and click on the “Firmware Updates” on the left panel.

5. Select the rmware version that you wish to update.

6. Wait for the rmware to be downloaded and rmware update will start automatically.

7. Reboot the aircraft and the remote controller after the rmware update is complete.

The remote controller and the aircraft can also be updated separately.

If you connect the aircraft to the computer via the aircraft’s micro USB port, you are only able to

update the aircraft rmware.

The rmware update will take around 15 minutes. It is normal that the gimbal goes limp, aircraft

status indicator blinks abnormally and the aircraft reboots. Please wait patiently until the update

is complete.

Ensure the computer has access to the Internet.

Ensure the batteries have at least 50% power.

Do not disconnect the aircraft from the computer during rmware update.

Intelligent Flight Mode

Intelligent Flight mode includes Course Lock, Home Lock, Point of Interest (POI), Follow Me and

Waypoints features to assist users to create professional shoots during the ight. Course Lock and Home

Point lock helps to lock the orientation of aircraft so that the user can focus more on other operations.

Point of Interest, Follow Me and Waypoints mode enable aircraft to y automatically according to the

pre-set ight maneuvers.

Course Lock

Lock the current nose direction as the aircraft’s forward direction. The aircraft will

move in the locked directions regardless of its orientation (yaw angle).

Home Lock Pull the pitch stick backward to move the aircraft toward its recorded Home Point.

Point of Interest

The aircraft will orbit around the subject automatically to allow the operator can be

more focus on framing their shoot on the subject in Point of Interest.

Follow Me

A virtual tether is created between the aircraft and the mobile device so that the

aircraft can track your movement as you move. Note that Follow Me performance is

subject to the GPS accuracy on the mobile device.

Waypoints

Record a flight path, then the aircraft will fly along the same path repeatedly

while you control the camera and orientation. The ight path can be saved and

re-apply in the future.

Enable Multiple Flight Mode by launching the DJI GO 4 app > Camera View > > Multiple Flight Mode

before using the Intelligent Flight Mode for the rst time.

Appendix

Mavic Pro

User Manual

Remote Controller LCD Screen Menu Information

Remote Controller Status

BAT xx PCT Remote Controller battery level.

SHUTDOWN_ Remote controller is powering off.

CHARGING_ Remote controller is charging.

USB PLUGGED Mavic Pro has been connected to a computer.

FC U-DISK Flight Controller is reading data.

UPGRADING Upgrading.

BINDING Aircraft is binding with the remote controller.

Before Flight

CONNECTING_ The remote controller is connecting to the aircraft.

SYS INITING System is initiating.

READY TO GO Ready to take off.

Flight Mode

BEGINNER In Beginner Mode.

GPS MODE In P-GPS Mode.

OPTI MODE In P-OPTI Mode.

ATTI MODE In P-ATTI Mode.

SPORT MODE In Sport Mode.

Flight Status

TAKING OFF Taking off.

LANDING Landing.

GOING HOME Returning to Home.

NAV GOHOME Returning to home.

NAV LANDING Landing.

MAX ALT. Aircraft has reached maximum altitude.

MAX RADIUS Aircraft has reached maximum radius.

OBSTACLE Obstacle detected.

NO FLY ZONE Aircraft is in a No Fly zone.

Intelligent Flight Mode Status

TRIPOD In Tripod Mode.

ACTIVETRACK Using ActiveTrack.

TAP FLY Using TapFly.

COURSE LOCK In Course Lock Mode

HOME LOCK In Home Lock Mode

POI MODE In Point of Interest Mode

WAY POINT In Waypoints Mode.

FOLLOW ME In Follow Me Mode.

TERRAIN In Terrain Follow Mode.

System Waning and Error Information

SYS WARNING+CHECK APP System Warning. See DJI GO 4 app for more information.

UNACTIVATED+CHECK APP Aircraft not Activated. See DJI GO 4 app for more information.

MAG INTERF+CHECK APP Compass Error. See DJI GO 4 app for more information.

BATTERY ERR+CHECK APP Battery Error. See DJI GO 4 app for more information.

SD ERR+CHECK APP Micro SD Card Error. See DJI GO 4 app for more information.

CALIBRATING IMU Calibrating/Did not restart aircraft after calibration is

complete.

Appendix

Mavic Pro

User Manual

STICK ERR+RE-CTR STCK Control stick is not centered. Re-center it.

WHEEL ERR+RE-CTR WHEL Left Dial on the remote controller is not centered. Re-center it.

STICK ERR Control stick error. Calibrate the control sticks in the DJI GO 4 app.

MECH ERR Remote Controller Error. Calibrate the remote controller in the DJI

GO 4 app. If this problem persists, contact DJI support.

STICK EMI3+AUTO RTH Control Sticks are experiencing severe electromagnetic

interference and cannot function. The aircraft will return to home

and land immediately.

STICK EMI2+MANUAL RTH Control Sticks are experiencing electromagnetic interference and

may not function. Use Smart RTH and land the aircraft as soon as

possible.

STICK EMI1 Control Sticks are experiencing slight electromagnetic

interference, y the aircraft to another location.

SD FULL Micro SD Card is full.

NO PROP No propellers attached.

BAT TEMP HI Intelligent Flight Battery is too hot.

BATTERY ERR Intelligent Flight Battery error.

BAT TEMP LO Intelligent Flight Battery is too cold.

LOW BATTERY Intelligent Flight Battery low battery.

RC LOW BAT Remote Controller low battery.

NO RC SIGNL Remote Controller signal lost.

RC TEMP HI Remote Controller too hot.

NO RTH Aircraft cannot Return to Home.

After-Sales Information

Visit the following pages to learn more about After-sales policy and warranty information:

1. After-sales Policy: http://www.dji.com/service

2. Refund Policy: http://www.dji.com/service/refund-return

3. Paid Repair Service: http://www.dji.com/service/repair-service

4. Warranty Service: http://www.dji.com/service/warranty-service

This content is subject to change.

Download the latest version from

http://www.dji.com/mavic

If you have any questions about this document, please contact DJI by

sending a message to

[email protected]

DJI Support

http://www.dji.com/support

MAVIC

is a trademark of DJI.

CP.PT.000642 Dji Cameras

Product's Documents

User Manual

Specifications

Dji CP.PT.000642 Questions and Answers

Related Products

CP.PT.000084 Dji Cameras

CP.PT.000689 Dji Cameras

CP.PT.00000130.01 Dji Cameras

CP.BX.000103 Dji Cameras

CP.MA.00000019.01 Dji Cameras
