1
4 5
2 3
6 7
MASSAGE ATTACHMENTS
*
Some kits may not include all attachments.
TRIAD ATTACHMENT
Three points of added pressure to massage multiple
areas at once.
KNUCKLE JOINT ATTACHMENT
For concentrated action between the fingers or toes.
Great for knee and elbow joints, too.
MUSCLE KNEADING ATTACHMENT
Delivers ripple-effect action for large muscle areas.
GENERAL BODY ATTACHMENT
For general, all-body massage.
POWER DISC
Large surface and prongs massage deep to
stimulate blood flow.
FACIAL VITALIZER
Provides beneficial, revitalizing facial massage.
(Apply cold cream or lotion to face prior to use.
Keep massager away from eyes.)
DEEP MUSCLE STIMULATOR
Reaches deep to relieve tired, aching muscles.
SPOT APPLICATOR
Lets you apply deep, pinpoint massage action to the
exact body area needing relief.
FOUR FINGER FLEX ATTACHMENT
Soft, finger-like nodes replicate a human touch
massage.
ACCUPOINT ATTACHMENT
Targets deep into tissue. Great for pinpointing
concentrated areas.
RAISED BUMP ATTACHMENT
Wide surface for an all-over muscle massage.
DEEP MUSCLE ATTACHMENT
Thumps smoothly, creating a gentle, relaxing
massage for all-over body use.
DEEP HEAT ATTACHMENT
Smooth, wide heat applicator for all-over heat
therapy.
COLD GEL ATTACHMENT
May reduce swelling and pain caused by
inflammation and relieves discomfort.
17. Do not use massager on:
a. Sensitive skin, swollen or inflamed areas, in the presence
of poor circulation, where skin eruptions are present, or in
the presence of unexplained calf or abdominal pain.
b. Varicose veins.
c. The front of the neck.
d. Genital areas.
e. Sleeping or unconscious persons.
18. When using a massage attachment, be sure to seat the
attachment fully onto the stem and keep it on while
massaging.
19. Do not use this massager for more than 20 minutes at one
time.
20. To disconnect, turn both switches to the OFF position, then
remove plug from outlet.
21. Do not use massager in close proximity to loose clothing or
jewelry.
22. Keep long hair away from massager while in use.
SAVE THESE INSTRUCTIONS
For Household Use Only
DEEP HEAT ATTACHMENT
To insert Deep Heat Attachment, simply align the special track bar with
the grooved section in the massager stem (see diagram), then press
firmly onto stem. To detach, use thumb and two fingers and pull away
from stem.
When Deep Heat Attachment is correctly aligned and pushed on the
stem, the electrical heat element is automatically connected. If using the
massager for the first time, begin with
the lowest heat setting. Test the
surface for a comfortable
temperature. The massager will heat
to the desired level within four
minutes.
NOTE: When using heat, always
check temperature before placing
massager against skin. Every person
reacts differently to certain temperatures. We suggest the following
before use — check temperature by lightly touching with fingertips the
silver heat plate on the massager. If uncomfortable to your touch, reduce
temperature by (1) rubbing massaging surface on soft cloth, (2) moving
the HEAT button to a lower setting, or (3) turning off unit for a short
period before applying to your skin. Keep the massager moving
constantly any time heat is on. Never use heat on swollen or inflamed
areas, or on skin eruptions.
NEVER use the heat applicator if the plastic housing is cracked or
broken, or if the metal plate is loose, bent or lifted.
CAUTION: The two holes in the stem of the massager are like an
electrical plug — electrical power is transmitted through them.
NEVER allow water near the stem, and never insert anything into the
holes.
IMPORTANT SAFEGUARDS
When using an electrical appliance, basic precautions should
always be followed, including the following:
READ ALL INSTRUCTIONS AND SAFEGUARDS BEFORE
USING.
DANGER
To reduce the risk of death or electric shock:
1. Do not reach for an appliance that has fallen into water.
Unplug immediately.
2. Do not use while bathing or in the shower.
3. Do not place or store appliance where it can fall or be pulled
into a tub or sink. Do not place in or drop into water or other
liquid.
4. Always unplug this appliance from the electrical outlet
immediately after using and before cleaning.
5. Do not use massager without attachments.
WARNING
To reduce the risk of burns, fire, electric shock or injury to
persons:
1. This appliance should never be left unattended when plugged
in. Unplug from outlet when not in use, and before putting
on or taking off parts.
2. Do not operate this appliance under a blanket or pillow.
Excessive heating can occur and cause fire, electric shock or
injury to persons.
3. Close supervision is necessary when this appliance is used
by, on, or near children or disabled persons.
4. This massager contains an electro magnetic motor. To avoid
risk of injury, it must not be used within six inches of an
implantable cardiac device.
5. Use heated surfaces carefully. May cause serious burns. Do
not use over insensitive skin areas or in the presence of poor
circulation. The unattended use of heat by children or
incapacitated persons may be dangerous.
6. Never apply the gel pack directly to skin. Direct application of
this gel pack to the skin may cause frostbite.
7. The gel pack and contents are safe when used as directed. If
the gel pack is accidentally punctured or tears, discontinue
using immediately. If the gel comes in contact with the skin,
wash with soap and water. If skin becomes irritated or if the
gel enters the eyes or mouth, contact a physician
immediately. Keep gel pack out of reach of children and pets
to avoid risks posed if gel pack is punctured or torn.
8. Check local laws and regulations for proper disposal of the
gel pack.
9. Use this appliance only for its intended use, as described in
this manual. Do not use attachments not recommended by
the manufacturer.
10. Never operate this appliance if it has a damaged cord or plug,
if it is not working properly, if it has been dropped or
damaged, or dropped into water. Return to Wahl for
examination and repair.
11. Do not carry this appliance by supply cord or use cord as a
handle.
12. Keep the cord away from heated surfaces.
13. Never drop or insert any object into any opening on this
appliance.
14. Do not use outdoors.
15. Do not operate where aerosol (spray) products are being
used or where oxygen is being administered.
16. In case of pregnancy, diabetes or illness, consult your
physician before using this massager.
9' Cord
Ergonomically
Designed
2 Massage Intensities
2 Heat Settings
OPERATING INSTRUCTIONS
To reduce the risk of electric shock, this appliance has a polarized plug
(one blade is wider than the other). This plug will fit in a polarized outlet
only one way. If the plug does not fit fully into the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician to install the
proper outlet. Do no change the plug in any way.
1. With both of the massager switches in the OFF position, plug the
power cord into an AC outlet. (Make sure the voltage of power
supply is the same as that indicated on massager.)
2. Place the desired massage attachment on the stem of the
massager. The attachments easily press on and pull off. If heat is
desired, the heat attachment must be used. (See special
instructions below for using the Deep Heat Attachment.)
3. Slide the top switch to the desired massaging speed —
I - LOW or II -HIGH.
■ I - LOW — for soothing massage.
■ II - HIGH — for vigorous, deep-penetrating action.
4. Slide the bottom switch to the desired heat setting — I - LOW or II -
HIGH. Use heat only with the Deep Heat Attachment. Heat may be
applied alone or with the massaging feature.
5. Apply the massager to the targeted area, using continual
movement. A circular motion is often most effective. (See
MASSAGE TECHNIQUES.)
CLEANING/STORAGE
Always unplug massager before cleaning.
To clean, simply wipe unit with a dry, soft cloth. Do not immerse in
water or use any harsh cleaners or solvents. When storing unit, make
sure cord is not twisted or kinked.
Line Voltage
Amplitude &
Frequency Setting
220/50
240/50
100/50
120/60
220/60
Vibration for Single-
speed Models
(vibrations/min.)
100 Hz
(6000)
120Hz
(7200)
2-Speed Models
LOW (1) HIGH (2)
Setting Setting
100 Hz 50Hz
(6000) (3000)
120 Hz 60 Hz
(7200) (3600)
MASSAGER VIBRATION FREQUENCY
Deep Heat
Attachment
Massager
Stem
3-YEAR LIMITED WARRANTY
Valid in U.S.A. Only
If your Wahl product fails to operate satisfactorily within three (3) years from the date
of original purchase or receipt as a gift, Wahl will, at our option, repair or replace it and
return it to you FREE OF CHARGE. Please mail your product prepaid to Wahl Clipper
Corporation, 3001 Locust Street, Sterling, Illinois 61081, Attention: Repair Department,
with a note describing the defect and the date of original purchase or receipt as a gift (if
in warranty). Products out of warranty will be repaired at our standard repair charges.
This warranty is void and no repair or replacement will be made under this warranty or
otherwise if:
1. The product is modified in any manner or repaired by anyone other than Wahl Clipper
Corporation or Wahl authorized service center.
2. The product has been used commercially or subjected to unreasonable use.
This warranty gives you specific legal rights and you may also have other rights which
may vary from state to state. No other written express warranty is given. Any implied
warranty, including any warranty of merchantability which may arise from purchase or
use is limited to the years period provided in the express warranty. Some states may
not allow such limitation, so it may not apply to you. No responsibility is assumed
for incidental or consequential damages of any type or for the use of unauthorized
attachments. Some states may not allow the exclusion or limitation of incidental or
consequential damages, so the limitation or exclusion may not apply to you.
SERVICE AND REPAIR
This unit has no user-serviceable parts. If you have problems with your
massager, do not return it to store where purchased. Send it prepaid
with a note explaining the problem to:
Wahl Clipper Corporation
Attention: Repair Department
3001 Locust Street
Sterling, Illinois 61081
Telephone: (800) 767-9245
For products purchased outside the United States, contact your Wahl
distributor.
© 2016 Wahl Clipper Corporation • Part No. 93342-5201 • Printed in China
massagers.wahl.com
The Brand Used By Professionals
®
Since 1919
Heat Therapy
™
Heated Therapeutic Massager
For more information or Product Registration, visit massagers.wahl.com
COLD GEL ATTACHMENT
**DO NOT MICROWAVE. FOR COLD THERAPY USE ONLY**
Place gel pack in the freezer. After 1-2 hours, the gel pack will reach the
desired cold temperature. It is ideal to allow the gel pack to freeze
overnight for optimal cold therapy. Cold will last for 20-30 minutes then
remain cool. If the gel pack is uncomfortable during use, discontinue
use immediately.
MASSAGE TECHNIQUES
SHOULDERS AND NECK — Massage each shoulder toward
back of neck to point just behind and below ear. Then back to shoulder.
Repeat several times.
ARMS — Start with a gentle massage of the palms and fingers. Next,
using a circular motion, move upward to forearms. Then up to
biceps and shoulders.
LEGS — If desired, massage bottoms of feet. Then, using a circular
motion, massage each leg from calf on up and over thigh.
CHEST — Massage from center of chest outward, and up toward
each shoulder.
BACK — Massage from top of spine to bottom, and from center
outward.
ABDOMEN — Relax abdominal muscles by massaging from center
outward, using a gentle, circular motion.
JOINTS — Relieve tired, aching knees and elbows with smooth,
circular strokes.
FACE — Gently massage from the nose outward, taking care to avoid
contact with the eye.
SCALP — Start at the back of the neck and massage up to the top of
the head. Using this up and down motion, massage across the scalp.
Loading ...
