Scan the QR code on the device or the QR
code on the right side,or manually enter Device name
to confirm the device model,turn on the “Power switch”
by following APP instructions and go to the next step.
WiFi Setup Instructions
Scan the QR code in Figure 1 to download
and install “WeBack” APP,
or download and install from other APP stores Figure 1
Open App, directly log in if you have a “WeBack”
account; if not, you can select “New User”
to sign up, and click on "add device" after login
Confirm the family WIFI as shown in Figure 5
and enter the WIFI password
Link the
machine QR code
Figure 2 Figure 3
Figure 4
Figure 5
WiFi Setup Instructions
Confirm the family WIFI as shown in Figure 5 and enter the WIFI
password.Voice prompt "Robot is networking" and Wi-Fi light
flashes. Enter“Networking mode”. The App confirms to be
activated.Enter the device connection interface. Depending on
the WIFI signal strength, it may take few seconds or more.
a. If Binding successfully, enter the device management
interface.Click on the device to enter device control as shown in
figure 7, or click the option in the upper right corner for device
remarks, reservation, sharing and other operations.
b. If binding unsuccessfully, please confirm whether the WIFI
password is entered correctly; confirm whether your home
router wireless network frequency is 2.4G.
Device control interface is shown in figure 8
for multi-mode control of device or display of
device status and other information
How to control your device with
Authorized Smart Speaker
(Google home,Alexa,Siri)? Please
select "Third-party connection" in
WeBack as shown in Figure 9 and
Figure 10
Einstellung
Figure 6 Figure 7
Figure 8
Figure 9 Figure 10
