4’’ Waterproof Rated Off-Road Speakers
Compact PowerSport Vehicle Speaker System
for ATV, UTV, 4x4, Jeep (800 Watt) (Pair)
PLUTV41BK
www.PyleUSA.com
2
PLUTV41BK Installation
Speaker Mounting suggestion as below:
Step 1: Unbolting the mounting bracket
Step 2: Slide in the buckle with rubber pad attached to the bracket stand of the speaker
Attach the set to handle bar of vehicle / ship
Step 3/4: Attach screw to lock the buckle
Step 5: Using accessories of Butt Connector to Connect Speaker wires (See Illustration 1,2,3)
AMP
AMP
Blue
Blue
yellow
yellow
+
+
+
+
-
-
-
-
AMP
1
2 3
Rubber Pad
www.PyleUSA.com
3
PLUTV41BK
4’’ Waterproof Rated O-Road Speakers
Compact PowerSport Vehicle Speaker System for ATV, UTV, 4x4, Jeep (800 Watt) (Pair)
Features:
• Pro Audio PowerSport Speakers
• Compact & High-Powered Output
• Marine Grade Waterproof Rated Construction
• Weatherproof & Water-Resistant Housing
• Sound System: (2) x 4.0'' Woofers + (2) x 0.5’’ Tweeters
• 2-Way Full Range Stereo Sound Reproduction
• Impressive Bass Response
• Integrated Speaker Wiring for Quick Connection
• Sleek Design, Machine Molded Speaker Cabinet Housing
• Rugged, Universal Mount Bracket Design for Roll-Bar / Roll-Cage
• Used for O-Road Outdoor Vehicles: ATV, UTV, 4x4, Jeeps, Marine Watercraft
What’s in the Box:
• (2) 4'' -inch ATV/UTV Speakers
• Speaker Connection Wires, 6.5' ft.
• Wire Butt Connectors, 16-22 AWG
• EVA Mounting Pads
Technical Specs:
• Power Output: 800 Watt MAX
• Marine Grade Waterproof Rating: IP-X5
• Speaker Size: 4’’ -inch (Each)
• Speaker Style: Passive Speakers
• Speaker Type: Polypropylene Cone, Butyl Rubber Surround (x2)
• Tweeter Type: Neodymium Dome (x2)
• Frequency Response: 85Hz-20kHz
• Impedance: 4 Ohm
• Magnet Type: 20 oz. Circuit
• Mid-Woofer Voice Coil Type: 1.0'', Aluminum
• Sensitivity: 90 dB +/- 2 dB @ 1M/1W
• Universal Mounting Brackets Roll-Bar / Roll-Cage Diameter: 1.25’’ ~ 2.0’’ -inches
• Speaker Dimensions: 5.6’’ x 8.4’’ x 7.3’’ -inches, with Bracket (-Each)
• Sold as: Pair
