User Manual Samsung 65H8G - 65" Class H8G Quantum Series LED 4K UHD Smart Android TV

• Owner's manual - (English)

• Spec Sheet (web) - (English)

User Manual 4K HDR Smart TV Samsung 65H8G

Table of Contents

• What's in the box
• Getting started
• Step 1. Attach stand or mount
• Step 2. Connect devices to your TV
• Step 3. Get your remote ready
• Step 4. Power on the TV
• Step 5. Complete the first-time setup
• Step 6. Establish a network connection
• Step 7. Enjoy your TV!
• Troubleshooting
• Product Specifications
• Certification and Compliance

Attach stand or mount

Before you start using your TV, attach your TV stand or mount it on the wall.

CAUTION:

• Disconnect the A/C power cord before installing a stand or a wall mount bracket.
• The LED display on your TV is fragile. Make sure the TV screen is not scratched or damaged by hard objects or from pressure.
• After the installation is complete, make sure the TV is steady on a table or firmly attached to a wall mount, before removing all protective film, if any.

Attach the TV stand

To attach the TV stand legs to your TV:

1. Carefully place your TV face down on a clean, soft, flat surface.
2. Insert the TV Base Stand into the bottom slots on your TV.
3. Use the screws provided to secure each leg tightly.

Attach the Wall Mount Bracket (not included) (only for 75")

Before you begin the third-party manufacturer instructions, be sure to do the following things:

1. Place the TV face down on a clean, safe and cushioned surface.
2. Remove the TV stand if you already attached it.
3. Remove the two screws (as shown in the following figure) on the handle first, and remove the handles, then remove the two screws at the bottom of the back.
4. Fix the four wheels in the accessory bag at the position shown in the following figure.
5. Place the spacers (not included) in the corresponding bracket holes. See the Figure 3.

Insert the batteries

1. Take off the back cover to open the battery compartment of the remote control.
2. Insert two AAA size batteries. Make sure to match the (+) and (-) ends of the batteries with the (+) and (-) ends indicated in the battery compartment.
3. Restore the battery compartment cover.

Important Information about the remote and batteries

• Discard batteries in a designated disposal area. Do not throw them into a fire.
• Remove old batteries immediately to prevent them from leaking into the battery compartment.
• If you do not intend to use the remote control for a long time, then remove the batteries.
• Battery chemicals can cause a rash. If the batteries leak, clean the battery compartment with a cloth. If chemicals touch your skin then wash it immediately.
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc) or rechargeable (NiCd, NiMH, etc.) batteries.
• Do not continue using the remote if it gets warm or hot.
• Call our Support Center immediately on the support website.

Remote Control Range Information

• The remote control can work at a distance of up to 26 feet in front of the TV set.
• It can work at a 30 degree horizontal or vertical angle.

Troubleshooting

No sound or picture

• Check if the power cord is plugged into a powered AC outlet.
• Press the Power button on the remote control to activate the unit from 'Standby' mode.
• Check to see if the LED light is on or not. If it is, then the TV is receiving power.

I have connected an external source to my TV and I get no picture and/or sound.

• Check for the correct output connection on the external source and for the correct input connection on the TV.
• Make sure you have made the correct selection for the input mode for the incoming signal.

When I turn on my TV, there is a delay for a few seconds before the picture appears. Is this normal?

• Yes, this is normal. The TV is initializing and searching for previous setting information.

The picture is normal but there is no sound

• Check the volume settings.
• Check if 'Mute' mode is set to On.

Sound but no picture or black and white picture

• If the picture is black and white, unplug the TV from the AC outlet and replug it after 60 seconds.
• Check that the Color is set to 50 or higher.
• Try different TV channels.

The sound and/or picture is distorted or appears wavy

• An electric appliance may be affecting the TV. Turn off any appliances that are nearby and move it farther away from the TV.
• Insert the power plug of the TV set into another power outlet.

The sound and picture is blurry or cuts out

• If using an external antenna, check the direction, position and connection of the antenna.
• Adjust the direction of your antenna or reset or fine tune the channel.
