This is a specially designed antenna for digital over-the-air TV
broadcast reception. It can receive all of the TV signals available in
your area in the VHF and UHF bands.
PACKAGE CONTENTS
• HDTV antenna
• Antenna stand
• Quick Setup Guide
FEATURES
• Receive free local HDTV broadcasts
• Flat prole design ts with any decor
• Multiple placement options: stand mount, lay at, or hang on
wall
• 5.4 ft. (1.6 m) integrated coaxial cable
SETTING UP AND USING YOUR ANTENNA
Positioning the antenna
1 Choose a mounting method:
2 If possible, place your antenna near a window and away from
sources of interference.
Connecting the antenna
If you have an HDTV with a digital TV (ATSC) tuner, you can
connect the antenna directly to the HDTV. Older TVs may require a
separate digital TV tuner, or digital converter box.
1 Connect the end of the antenna’s coaxial cable to the coaxial
jack on the back of your TV digital converter box, or set-top box.
Connect to an HDTV
OR
Connect to a TV through a digital converter box
Note: See the instructions for your digital converter box for connection
steps.
Before using your new product, please read these instructions to prevent any damage.
Stand
Antenna
Digital converter box
Coaxial cable
Video/audio cable (coaxial or composite cable)
O
U
T
I
N
A
N
TE
N
N
A
TV
OR
Attach the included stand OR OR Lay it at on a table Hang it on a wall
Antenna
HDTV
Coaxial cable
QUICK SETUP GUIDE
Multi-Directional
Flat HDTV Antenna
NS-ANT715
