197D4609P001 49-60163-1 11-01 JR
GEAppliances.com
Write the model and serial numbers here:
Model # __________________________
Serial # __________________________
Find these numbers on a label on the
back of the wine cooler.
Wine Cooler
24 Bottle Model
Owner’s Manual
Safety Instructions . . . . . . . . . .2–4
Operating Instructions
Control Settings . . . . . . . . . . . . .5
Features . . . . . . . . . . . . . . . . . . . .6
Care and Cleaning
Cleaning the Condenser . . . . . .8
Cleaning the Defrost
Water Pan . . . . . . . . . . . . . . . . . .7
Cleaning the Inside . . . . . . . . . .8
Cleaning the Outside . . . . . . . . .7
Defrosting . . . . . . . . . . . . . . . . . .8
Installation . . . . . . . . . . . . . . . . .9
Moving . . . . . . . . . . . . . . . . . . . .8
Troubleshooting Tips . . . . .10, 11
Consumer Support
Consumer Support
. . .Back Cover
Warranty . . . . . . . . . . . . . . . . . .15
49-601631v05 12/20/01 1:25 PM Page 1
2
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
Safety InstructionsOperating InstructionsTroubleshooting TipsConsumer Support Care and Cleaning
DANGER! RISK OF CHILD ENTRAPMENT
Use this appliance only for its intended purpose as described
in this Owner’s Manual.
WARNING!
■ This wine cooler must be
properly installed and located
in accordance with these
instructions before it is used.
■ Do not allow children to
climb, stand or hang on the
shelves in the wine cooler.
They could damage the wine
cooler and seriously injure
themselves.
■ Do not store or use gasoline
or other flammable vapors
and liquids in the vicinity of
this or any other appliance.
■ Keep fingers out of the
“pinch point” areas;
clearances between the doors
and between the doors and
cabinet are necessarily small.
Be careful closing doors when
children are in the area.
■ Unplug the wine cooler before
cleaning and making repairs.
NOTE: We strongly recommend
that any servicing be performed by
a qualified individual.
■ Turning the temperature
control dial to the
OFF
position
stops cooling but does not shut
off power to the wine cooler.
When using electrical appliances, basic safety precautions
should be followed, including the following:
SAFETY PRECAUTIONS
Child entrapment and
suffocation are not problems of
the past. Junked or abandoned
refrigeration products are still
dangerous…even if they will sit
for “just a few days.” If you are
getting rid of your old appliance,
please follow the instructions
below to help prevent accidents.
Before You Throw Away Your Old
Refrigeration Product:
■ Take off the doors.
■ Leave the shelves in place so
that children may not easily
climb inside.
CFC Disposal
Old refrigeration products may
have a cooling system that used
CFCs (chlorofluorocarbons).
CFCs are believed to harm
stratospheric ozone.
If you are throwing away an old
refrigeration product, make sure
the CFC refrigerant is removed
for proper disposal by a qualified
servicer. If you intentionally
release this CFC refrigerant you
can be subject to fines and
imprisonment under provisions
of environmental legislation.
PROPER DISPOSAL OF THE WINE COOLER
49-601631v05 12/20/01 1:25 PM Page 2
GEAppliances.com
3
Safety Instructions Operating Instructions Troubleshooting Tips Consumer SupportCare and Cleaning
USE OF EXTENSION CORDS
Because of potential safety hazards under certain conditions,
we strongly recommend against the use of an extension cord.
However, if you must use an extension cord, it is absolutely necessary
that it be a UL-listed, 3-wire grounding type appliance extension cord
having a grounding type plug and outlet and that the electrical
rating of the cord be 15 amperes (minimum) and 120 volts.
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the third
(ground) prong from the power cord. For personal safety,
this appliance must be properly grounded.
The power cord of this
appliance is equipped with
a 3-prong (grounding) plug
which mates with a standard
3-prong (grounding) wall outlet
to minimize the possibility of
electric shock hazard from
this appliance.
Have the wall outlet and
circuit checked by a qualified
electrician to make sure the
outlet is properly grounded.
If you have only a standard
2-prong wall outlet, it is your
personal responsibility and
obligation to have it replaced
with a properly grounded
3-prong wall outlet.
The wine cooler should
always be plugged into its own
individual electrical outlet
which has a voltage rating that
matches the rating plate.
This provides the best
performance and also prevents
overloading house wiring circuits
which could cause a fire hazard
from overheated wires.
Never unplug your wine cooler
by pulling on the power cord.
Always grip plug firmly and pull
straight out from the outlet.
Repair or replace immediately
all power cords that have
become frayed or otherwise
damaged. Do not use a cord that
shows cracks or abrasion damage
along its length or at either end.
When moving the wine cooler
away from the wall, be careful
not to roll over or damage the
power cord.
49-601631v05 12/20/01 1:25 PM Page 3
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
4
WARNING!
USE OF ADAPTER PLUGS
Because of potential safety hazards under certain conditions,
we strongly recommend against the use of an adapter plug.
However, if you must use an
adapter, where local codes
permit, a
temporary connection
may be made to a properly
grounded 2-prong wall outlet
by use of a UL-listed adapter
available at most local hardware
stores.
The larger slot in the adapter
must be aligned with the
larger slot in the wall outlet to
provide proper polarity in the
connection of the power cord.
When disconnecting the power
cord from the adapter, always
hold the adapter in place with
one hand while pulling the
power cord plug with the other
hand. If this is not done, the
adapter ground terminal is very
likely to break with repeated use.
If the adapter ground terminal
breaks,
DO NOT USE
the wine
cooler until a proper ground
has been established.
Attaching the adapter ground terminal
to a wall outlet cover screw does not
ground the appliance unless the cover
screw is metal, not insulated, and the
wall outlet is grounded through the
house wiring. You should have the
circuit checked by a qualified electrician
to make sure the outlet is properly
grounded.
READ AND FOLLOW THIS SAFETY
INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
Safety InstructionsOperating InstructionsTroubleshooting TipsConsumer Support Care and Cleaning
49-601631v05 12/20/01 1:25 PM Page 4
About the control.
GEAppliances.com
5
Safety Instructions Operating Instructions Troubleshooting Tips Consumer SupportCare and Cleaning
Control Settings
The temperature range of the wine cooler is from the mid-forties
to the mid-sixties in degrees Fahrenheit.
As with any refrigeration product, there is a slight temperature
variance at different locations within the cabinet.
The coolest shelves in the unit are the two middle shelves.
Position your wine inventory accordingly (i.e, white wines in the
cooler zones and red in the warmer zones).
NOTE: Make sure that the wine bottles do not touch the back wall.
The bottles may collect condensation, which will drain into the
bottom of the unit.
For regular operation, the temperature control knob
should be set to the NORMAL position.
MAX is the coldest setting.
MIN is the warmest setting.
Once the bottles are loaded, allow at least 48 hours
before making any adjustments to the initial setting.
The temperature control is located on the back of the wine cooler.
49-601631v05 12/20/01 1:25 PM Page 5
6
Pull-Out Racks
The four racks can be pulled out 1/2 way to allow the easy
addition or removal of wine bottles.
The top rack holds up to five wine bottles with the necks
towards the back.
The center three racks hold up to five wine bottles with the
necks towards the front.
Up to four regular wine bottles can be placed in the
bottom of the unit. The bottom can also be used to store
large or irregularly shaped bottles.
Safety InstructionsOperating InstructionsTroubleshooting TipsConsumer Support Care and Cleaning
About the features.
Automatic Humidity Control
The inside of the wine cooler automatically maintains
the necessary level of humidity to protect wine corks
from drying out. As a result, frost may form on the
inner surfaces. See
Care and Cleaning
for instructions
on removing excessive frost buildup.
49-601631v05 12/20/01 1:25 PM Page 6
7
Safety Instructions Operating Instructions Troubleshooting Tips Consumer SupportCare and Cleaning
Cleaning the Outside
IMPORTANT: Unplug the wine cooler before cleaning.
Keep the outside clean.
The cabinet can be washed
with mild soap and water. Rinse thoroughly with
clear water. Never use abrasive scouring powders.
Use a glass cleaner or mild soap and water and
a soft cloth to clean the glass door. Do not use
any abrasive powders.
Do not wipe the wine cooler with a soiled dish cloth or wet towel.
These may leave a residue that can erode the paint. Do not use
scouring pads, powdered cleaners, bleach or cleaners containing
bleach because these products can scratch and weaken the
paint finish.
Protect the paint finish.
The finish on the outside of the
wine cooler is a high-quality, baked-on paint finish. With
proper care, it will stay new-looking and rust-free for years.
Apply a coat of kitchen/appliance wax when the wine
cooler is new, and then at least twice a year.
Care and cleaning.
GEAppliances.com
Cleaning the Defrost Water Pan
IMPORTANT: Unplug the wine cooler before cleaning.
The pan should be cleaned out at least once a year, or
whenever the wine cooler is defrosted.
Remove the pan by firmly pulling it straight out. When
replacing the pan, make sure to position it under the
drain tube.
Clean the pan using a clean cloth or sponge and a warm
water and baking soda solution—about one tablespoon
(15 ml) of baking soda to a quart (1 liter) of water. This
both cleans and neutralizes odors. Rinse and wipe dry.
Drain tube
Defrost
water pan
49-601631v05 12/20/01 1:25 PM Page 7
8
Safety InstructionsOperating InstructionsTroubleshooting TipsConsumer Support Care and Cleaning
Preparing to Move
Secure all loose items such as racks by taping them
securely in place to prevent damage.
Be sure the wine cooler stays in an upright position during moving.
Defrosting
Defrost whenever frost on the inside surfaces of the storage area
becomes 1/4
″
thick. Never use a heater of any kind, scraper
or sharp instrument to remove frost as it may damage the
wine cooler.
To defrost,
set the temperature control dial at
OFF
position.
Remove the contents and wipe inside surfaces and racks
with a clean towel. If frost does not come off easily, allow
the frost to melt somewhat and wipe off.
After defrosting,
clean the defrost water pan; see
Cleaning
the Defrost Water Pan
. Make sure inside surfaces are dry;
then return the contents to the wine cooler and turn the
temperature control to the desired setting.
Care and cleaning.
Cleaning the Inside
IMPORTANT: Unplug the wine cooler before cleaning.
To clean the inner liner and racks, use a warm water and
baking soda solution—about one tablespoon (15 ml)
of baking soda to a quart (1 liter) of water. This both
cleans and neutralizes odors. Rinse and wipe dry.
The vinyl door gasket may be cleaned with mild soap and
water, a baking soda solution or a mild scouring powder.
Rinse well.
Do not use detergents, scouring powders, spray cleaners or
other harsh chemicals to clean the interior.
Cleaning the Condenser
IMPORTANT: Unplug the wine cooler before cleaning.
Sweep away or vacuum up dust.
For best results, use a brush specially designed for this
purpose. It is available at most appliance stores.
49-601631v05 12/20/01 1:25 PM Page 8
9
Safety Instructions Operating Instructions Troubleshooting Tips Consumer SupportCare and Cleaning
Installing the wine cooler.
GEAppliances.com
Read these instructions completely and
carefully.
■ The wine cooler is intended for
freestanding operation
only. Do not enclose it or install it in a recessed area.
■ Do not install the wine cooler where the temperature
will go below 50°F (10°C) because it will not run
often enough to maintain proper temperatures.
■ Install it on a level floor or counter strong enough to
support it when fully loaded.
■ If it is placed on a countertop, the front surface of
the door should be 3″ (8 cm) or more back from the
edge of the countertop or stand to avoid accidental
tipping of the appliance during normal use.
■ Allow at least 2″ (6 cm) of space between the back
of the wine cooler and the wall, to allow proper air
circulation.
■ Do not install where it will be subject to direct
sunlight, heat or moisture.
Installing the Defrost Water Pan
The wine cooler comes with a defrost water pan that
is shipped inside the unit. It is important to install the
pan over the compressor as shown.
Slide the defrost water pan in so the two support pins
are fully seated in the mounting holes.
Make sure the pan is positioned under the drain tube.
Drain tube
Defrost
water pan
Mounting
holes
49-601631v05 12/20/01 1:25 PM Page 9
10
Troubleshooting Tips
Save time and money! Review the chart below first
and you may not need to call for service.
Safety InstructionsOperating InstructionsTroubleshooting TipsConsumer Support Care and Cleaning
Before you call for service…
Problem Possible Causes What To Do
Wine cooler does not
Control in
OFF
position. • Move the control to a
operate
temperature setting.
Wine cooler is • Push the plug completely
unplugged. into the outlet.
The unit was recently • The wine cooler is
turned off or unplugged. equipped with a
thermostat control device.
You must allow at least
three minutes before
restarting the unit or
plugging it back in.
The fuse is blown/circuit • Replace fuse or reset
breaker is tripped. the breaker.
Vibration or rattling
Wine cooler is on • Use shims to level the
(slight vibration
an uneven surface. wine cooler.
is normal)
Motor operates for
Normal when wine cooler • Wait 24 hours for the
long periods or cycles
is first plugged in. wine cooler to completely
cool down.
Often occurs when • This is normal.
large
amounts of wine
are placed in wine cooler.
Door left open. • Check to see if a bottle is
holding door open.
Hot weather or frequent • This is normal.
door openings.
Temperature control • See
About the control
.
set at the coldest setting.
Not enough clearance • Make sure there is enough
from the wall. air circulation around the
wine cooler.
49-601631v05 12/20/01 1:25 PM Page 10
11
Safety Instructions Operating Instructions Troubleshooting Tips Consumer SupportCare and Cleaning
GEAppliances.com
Problem Possible Causes What To Do
Wine cooler too warm
Temperature control • See
About the control
.
not set cold enough.
Warm weather or • Set the temperature
frequent door openings. control one step colder.
See
About the control
.
Door left open. • Check to see if a bottle is
holding door open.
Wine cooler has odor
Interior needs cleaning. • See
Care and cleaning
.
Defrost water pan • See
Care and cleaning
.
needs cleaning.
Moisture forms on
Not unusual during • Wipe surface dry.
outside of wine cooler
periods of high humidity.
Moisture collects inside
Too frequent or too long
(in humid weather,
door openings.
air carries moisture
Wine bottles touching • Reposition bottles.
into wine cooler when
the back wall.
door is opened)
Frost forms on interior
This is normal. • See the Defrosting section
surfaces of wine cooler
under
Care and cleaning
.
Wine cooler too cold
Temperature control • See
About the control
.
set too cold.
49-601631v05 12/20/01 1:25 PM Page 11
12
Safety InstructionsOperating InstructionsTroubleshooting TipsConsumer Support Care and Cleaning
Notes.
49-601631v05 12/20/01 1:25 PM Page 12
13
Safety Instructions Operating Instructions Troubleshooting Tips Consumer SupportCare and Cleaning
GEAppliances.com
49-601631v05 12/20/01 1:25 PM Page 13
Safety InstructionsOperating InstructionsTroubleshooting TipsConsumer Support Care and Cleaning
Notes.
14
49-601631v05 12/20/01 1:25 PM Page 14
This warranty is extended to the original purchaser and any succeeding owner for
products purchased for home use within the USA. In Alaska, the warranty excludes the
cost of shipping or service calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential
damages. This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state. To know what your legal rights are, consult your
local or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225
■ Service trips to your home to teach
you how to use the product.
■ Improper installation.
■ Failure of the product if it is
abused, misused, or used for
other than the intended purpose
or used commercially.
■ Loss of wine due to spoilage.
■Replacement of house fuses or
resetting of circuit breakers.
■Damage to the product caused by
accident, fire, floods or acts of God.
■Incidental or consequential damage
caused by possible defects with
this appliance.
What GE Will Not Cover:
15
All warranty service provided by our
Factory Service Centers, or an authorized
Customer Care
®
technician. To schedule
service, on-line, 24 hours a day, visit us at
GEAppliances.com, or call 800.GE.CARES
(800.432.2737).
Staple your receipt here.
Proof of the original
purchase date is needed
to obtain service under
the warranty.
Safety Instructions Operating Instructions Troubleshooting Tips Consumer SupportCare and Cleaning
For The Period Of: GE Will Replace:
One Year Any part
of the wine cooler which fails due to a defect
From the date of the
in materials or workmanship. During this
limited
original purchase one-year warranty,
GE will also provide,
free of charge,
all labor (does not include service trip to your home)
to replace the defective part.
Five Years The compressor
if it fails due to a defect in materials or
From the date of the
workmanship. This
additional four-year limited warranty
original purchase
does not include service labor charges or service trips to
your home.
Wine Cooler Warranty.
49-601631v05 12/20/01 1:25 PM Page 15
Printed in Mexico
Consumer Support.
GE Appliances Website
GEAppliances.com
Have a question or need assistance with your appliance? Try the GE Appliances Website
24 hours a day, any day of the year! For greater convenience and faster service, you can
now download Owner’s Manuals, order parts, catalogs, or even schedule service on-line.
You can also “Ask Our Team of Experts
™
” your questions, and so much more...
Schedule Service
GEAppliances.com
Expert GE repair service is only one step away from your door. Get on-line and
schedule your service at your convenience 24 hours any day of the year! Or call
800.GE.CARES (800.432.2737) during normal business hours.
Real Life Design Studio
GEAppliances.com
GE supports the Universal Design concept—products, services and environments that
can be used by people of all ages, sizes and capabilities. We recognize the need to
design for a wide range of physical and mental abilities and impairments. For details
of GE’s Universal Design applications, including kitchen design ideas for people
with disabilities, check out our Website today. For the hearing impaired, please call
800.TDD.GEAC (800.833.4322).
Extended Warranties
GEAppliances.com
Purchase a GE extended warranty and learn about special discounts that are available
while your warranty is still in effect. You can purchase it on-line anytime, or call
800.626.2224 during normal business hours. GE Consumer Home Services will
still be there after your warranty expires.
Parts and Accessories
GEAppliances.com
Individuals qualified to service their own appliances can have parts or accessories
sent directly to their homes (VISA, MasterCard and Discover cards are accepted).
Order on-line today, 24 hours every day or by phone at 800.626.2002 during normal
business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other
servicing generally should be referred to qualified service personnel. Caution must be
exercised, since improper servicing may cause unsafe operation.
Contact Us
GEAppliances.com
If you are not satisfied with the service you receive from GE, contact us on our Website
with all the details including your phone number, or write to:
General Manager, Customer Relations
GE Appliances, Appliance Park
Louisville, KY 40225
Register Your Appliance
GEAppliances.com
Register your new appliance on-line—at your convenience! Timely product registration
will allow for enhanced communication and prompt service under the terms of your
warranty, should the need arise. You may also mail in the pre-printed registration card
included in the packing material.
49-601631v05 12/20/01 1:25 PM Page 16
