Pyle Home PVC1
Wall Mount Rotary Stereo Volume
Control Knob
User Manual
www.pyleaudio.com
Thank you for purchasing the Pyle Home PVC1! The PVC1 is a great way to
control the volume of your home speaker system using an existing wall-
mounted junction box in your home. This manual contains installation
instructions and a wiring diagram for your convenience. Your product
includes a one year limited warranty from the time of purchase.
Caution: This volume control is limited to a maximum of 50 watts RMS /
100 watts maximum per channel.
Mounting The Volume Control
The volume control is designed to be mounted in a standard electrical wall
box. Select a location that is within reach of the speaker wires and easy to
reach for using the volume control. Warning: You must mount the volume
control in a standard electrical box -- do not mount it directly on a wall.
Note: the depth of the unit is 2 5/8”.
