INTRODUCTION AND WARRANTY
LED Bulb with Emergency Function
& Solar Charging
INSTALLATION INSTRUCTION
TECHNICAL DATA:
PRODUCT FEATURES
BULB USAGE METHODS
CHARGING METHODS
INSTALLATION DIAGRAM
INSTALLATION INSTRUCTIONS (AC MODE)
1. Ensure that the power is switched off.
2. Fix the bulb into the E27 bulb holder.
3. Switch the bulb on/off as normal.
Note: During power failure (emergency mode), the CCT function wont work and the LED color will be
only white.
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any
another query, please contact our dealer or local vendor from whom you have purchased the product. They are
trained and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The
warranty does not apply to damage caused by incorrect installation or abnormal wear and tear. The company
gives no warranty against damage to any surface due to incorrect removal and installation of the product. The
products are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the
warranty. This product is warranted for manufacturing defects only.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST
DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
WARNING
1. Please make sure to turn off the power before starting the installation.
2. Do not use with dimmers
3. Do not replace the battery.
4. Do not expose to water.
5. Avoid using into totally enclosed luminaries.
6. Keep away from fire or high temperature.
This marking indicates that this
product should not be disposed
of with other household wastes.
2
YEARS
WARRANTY
*
Model
VT-2417
Input AC 220~240V, 50 Hz
Power
AC MODE: 7W
EMERGENCY MODE: 1.5W (6400K)
Lumens
AC MODE - 500 LM
EMERGENCY MODE: 130 LM
Solar Panel DC 6V, 2W
Charging time 8H
Working time 6H
Battery Capacity 3.7V, 2200mAh
CRI/Ra >80
Beam Angle:
120
Base: E27
Color:
AC Mode: 3000K - 6400K (Changeable)
Emergency Mode: White (6400K)
ADDITIONAL CCT FUNCTION (ONLY FOR AC MODE)
1. When you switch on/off the bulb first time, the color will be White (6400K).
2. When you switch on/off the bulb second time will be Warm White (3000K).
3, When you switch on/off the bulb third time, will be Day White (4000K).
ACCESSORIES INCLUDED
1. Solar Panels (Wire Length 3M)
2. E27 Holder with hook and on/off switch.
3. Micro USB Cable
Output DC 5V
Input DC 5V
Sturdy Hook
Easy to carry it to anywhere with this hook
ON/OFF Switch
Press the top button to turn the light on / off.
E27 Base
Static control switch (top and side can be
illuminated by touching the lamp)
USB interface
Can charge the phone
Micro-USB Charging Port
It can be charged by usb charger and solar
panel.
Charging indicator
Blue light when charging via solar panel or USB
charger
Note: when the battery becomes 100%, the blue
indicating light will stop blinking.
LED
1
2
3
Finger Touching
ON/OFF Switch
E27 Cap with Hook
AC 220~204V
CCT Changeable
with Wall Switch
(AC Mode)
ENGLISH ENGLISH ENGLISH
