OPERATOR’S MANUAL
Model SPX7000E-RM Form No. SJ-SPX7000E-RM-880E-V1
R
2-IN-1 ELECTRIC PRESSURE
WASHER + WET/DRY VAC
THANKS FOR YOUR PURCHASE
OF A REMANUFACTURED PRODUCT.
snowjoe.com
To make sure you get the most out of
your
product, be sure to register online at
to enjoy full product support.
PASTE UPC LABEL HERE
© 2018 by Snow Joe
®
, LLC
All rights reserved. Original instructions.
SAVE THESE INSTRUCTIONS
A Division of Snow Joe
®
, LLC
OPERATOR’S MANUAL
Model SPX7000E-RM Form No. SJ-SPX7000E-RM-880E-V1
R
2-IN-1 ELECTRIC PRESSURE
WASHER + WET/DRY VAC
2
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Any electrical appliance can be dangerous if used incorrectly.
Some of the safety precautions given in this manual apply
generally to many appliances. Other warnings are specic to
the use of this electric pressure washer + wet/dry vacuum.
Always follow these safety guidelines. Failure to do so may
result in serious bodily injury or death.
mWARNING! This indicates a hazardous situation, which,
if not avoided, could result in death or serious injury.
mCAUTION! This indicates a hazardous situation, which,
if not avoided, could result in minor or moderate injury.
mDANGER! This indicates a hazardous situation, which,
if not followed, will result in death or serious injury.
General Safety
mWARNING! This appliance is not intended for use
by children or by unassisted, unsupervised persons whose
physical, sensory, or mental capabilities prevent them from
using it safely. Children should be supervised to ensure that
they do not play with the appliance.
Before starting up your machine, please check it carefully for
any defects. If you nd any, do not start up your machine.
Contact your authorized Snow Joe
®
+ Sun Joe
®
dealer or
call the Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563).
mWARNING! When using the pressure washer + wet/dry
vacuum, basic safety precautions should always be followed
to reduce the risk of re, electric shock, and personal injury.
These include:
• Keep work area clean and well-lit – Cluttered, dark areas
invite accidents.
• Know your product – Know how to stop the machine and
bleed pressure quickly. Thoroughly familiarize yourself with
the controls.
• Keep bystanders away – All visitors and pets should be
kept a safe distance away from the work area.
• Use the right product – Do not use this machine for any
job except that for which it is intended.
• Dress properly – Do not wear loose clothing or jewelry.
They can get caught in moving parts. Protective rubber
gloves and non-slip footwear are recommended when
working outdoors.
•
mCAUTION! – Exercise caution to avoid slipping or falling.
Wear protective footwear that will protect your feet and
improve your footing on slippery surfaces.
• Stay alert – Watch what you are doing. Use common
sense. Do not operate the pressure washer + wet/dry
vacuum when you are tired, or under the inuence of
alcohol or drugs.
• Do not overreach –
Keep proper footing and balance at
all times.
• Avoid unintentional starting – Do not carry a plugged-
in machine with your nger on the trigger. Make sure the
switch is o before plugging in the machine.
• Do not abuse the cord – Never carry the machine by the
cord or yank the cord to disconnect it from the receptacle.
Keep the cord away from heat, oil, and sharp edges.
• Use safety glasses – Also use safety footwear, snug-
tting clothing, protective gloves, and hearing and head
protection.
• Store indoors – NEVER store the pressure washer + wet/
dry vacuum outdoors or where it could freeze. The pump
could be seriously damaged.
• Ground Fault Circuit Interrupter (GFCI) – GFCI protection
should be provided on the circuits or outlets to be used for
this pressure washer + wet/dry vacuum. Receptacles are
available having built-in GFCI protection and may be used
for this measure of safety.
• Inspect electrical cables – The insulation of the power
cord should be perfectly intact. If the power cord is
damaged or shows any signs of wear or tear, do not use the
machine. Contact your authorized Snow Joe
®
+ Sun Joe
®
dealer or call the Snow Joe
®
+ Sun Joe
®
customer service
center at 1-866-SNOWJOE (1-866-766-9563).
mWARNING! Do not use this appliance without reading
this instruction manual.
mWARNING! Do not use the appliance within range of
other people unless they are wearing protective clothing.
• Disconnect the tool – Disconnect from the electrical power
supply before performing any maintenance task.
3
• Keep children away – This high-pressure electric pressure
washer + wet/dry vacuum must not be used by children or
untrained personnel.
• To ensure appliance safety, use only original replacement
parts from the manufacturer or those approved by the
manufacturer.
mWARNING! During cleaning, maintenance, or when
replacing parts, disconnect the machine from its power source
by removing the plug from the socket outlet.
• Check for damaged parts – Do not use the appliance if
the supply cord or other important parts of the appliance
are damaged (e.g. safety devices, high-pressure hoses,
trigger gun).
mWARNING! If an extension cord is used, the plug and
socket must be of watertight construction.
NOTE: It is not recommended to use an extension cord with
this pressure washer + wet/dry vacuum.
mWARNING! Inadequate extension cords can be
dangerous.
mWARNING! Power cords on drums should always be
completely unwound to prevent the cord from overheating.
• Power cord connections should be kept dry and o the
ground.
• If the power cord is damaged, do not use the appliance.
Contact your authorized Snow Joe
®
+ Sun Joe
®
dealer or
call the Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563).
• Keep the machine on a stable, at surface during operation,
handling, transportation, and storage. Sudden overturn of
the machine can cause bodily injury.
• In the event of an accident or breakdown, switch o the
machine immediately. (If contact with detergent occurs,
rinse with an abundance of clean water.)
General Safety for Pressure
Washer
mWARNING! When using as pressure washer, high-
pressure jets can be dangerous if subject to misuse. The
jet must not be directed at persons, pets, live electrical
equipment, or the appliance itself.
mWARNING! Water that has owed through backow
preventers is considered to be non-potable.
mWARNING! High-pressure hoses, ttings, and
couplings are important for the safe operation of the appliance.
Use only hoses, ttings, and couplings recommended by the
manufacturer.
• Check the water temperature – This pressure washer is
not meant to pump hot water. NEVER connect it to a hot
water supply as it will signicantly reduce the life of the
pump.
• Do not direct the jet at yourself or others in order to clean
clothes or footwear.
• Risk of explosion – Do not spray ammable liquids.
• This high-pressure electric pressure washer must not be
used at temperatures below 32ºF (0°C).
General Safety for Wet/Dry
Vacuum
mDANGER! Do not manually place objects into the
vacuum inlet while operating the unit as this can seriously
damage the unit and/or harm the operator. Keep both hands
away from the air inlet while the power is on.
DO NOT ATTEMPT to remove material or hold material to be
vacuumed when the wet/dry vacuum is on. Make sure the wet/
dry vacuum is o when clearing jammed material from the
vacuum inlet.
mCAUTION! Do not operate the wet/dry vacuum
without the dust compartment properly attached. If the dust
compartment is not properly attached, the machine may
unintentionally move forward and throw out objects through
the blowout opening and cause injury.
• Maintain the wet/dry vacuum with care – Keep the
air inlet/outlet clear and clean for optimal performance
and to reduce the risk of injury. Keep the housing dry,
clean and free from oil and grease. Follow the additional
recommendations described in the maintenance section of
this manual.
• Avoid dangerous environments – Do not use the wet/
dry vacuum in rain, damp or wet locations. Do not operate
the wet/dry vacuum in gaseous or explosive atmospheres
or use the wet/dry vacuum to pick up ammable or
combustible liquids. Motors in these tools normally spark,
and the sparks might ignite fumes.
• Keep rm footing and maintain good balance at all times.
Do not overreach. Overreaching can result in loss of
balance.
• Do not pick up anything that is burning or smoking, such as
cigarettes, matches or hot ashes.
• Do not use without the dust compartment or lters in place.
• Do not put any object into the tool's openings. Do not use
the tool with any opening blocked; keep openings free of
dust, lint, hair or any other object that may reduce air ow.
• Check the work area before each use. Remove all objects
such as rocks, broken glass, nails, wire or string which can
be thrown or become entangled in the machine.
4
• Prevent cords, plastic bags, or similar items from getting
sucked in. This may cause an overload or blocking of the
motor.
Electrical Safety
ATTENTION: If there are problems with the electrical
MAINS, short voltage drops may appear when starting the
equipment. This can, in turn, inuence other equipment
(e.g. cause a lamp to blink). If the MAINS-IMPEDANCE Zmax
< 0.335 OHM, such disturbances are not expected. (If you
require assistance, contact your local supply authority for
further information).
mWARNING! Electrical Shock Hazard – Before starting
up your machine, please check it carefully for any defects.
If you nd any, do not start up your machine. Contact your
authorized Snow Joe
®
+ Sun Joe
®
dealer or call the
Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563).
The following should be observed when connecting the
unit to the electric supply:
• The electric supply connection should be performed by a
qualied person.
IMPORTANT: Only use water without any impurities for the
pressure washer. If there is a risk of running sand into the inlet
water (i.e. from your own well), an additional lter should be
installed.
Safety devices
The unloader valve can reduce pressure if it exceeds preset
values. The spray gun features a locking device. When the lock
is activated, the spray gun cannot be operated.
1. Thermal sensor – A thermal sensor protects the motor
against overloading. The machine will restart after a few
minutes when the thermal sensor has cooled.
2. Double insulation – In a double-insulated appliance, two
systems of insulation are provided instead of grounding.
No grounding means is provided on a double-insulated
appliance, nor should a means for grounding be added
to the appliance. Servicing a double-insulated appliance
requires extreme care and knowledge of the system, and
should be performed only by qualied service personnel at
an authorized Snow Joe
®
+ Sun Joe
®
dealer. Replacement
parts for a double-insulated appliance must be identical
to the parts they replace. A double-insulated appliance
is marked with the words “Double Insulation” or “Double
Insulated.” The symbol
(square within a square) may
also be marked on the appliance.
3. Ground fault circuit interrupter (GFCI) protection – A
GFCI should be provided on the circuit(s) or outlet(s) to be
used for this electric pressure washer + wet/dry vacuum.
Receptacles are available having built-in GFCI protection
and may be used for this measure of safety.
4. It is not recommended to use an extension cord with
this pressure washer + wet/dry vacuum. The unit comes
standard with a 35 ft GFCI power cable. Using an
extension cord may cause a drop in line voltage resulting
in loss of power and overheating.
5. To reduce the risk of electric shock, this appliance has
a polarized plug (i.e. one blade is wider than the other).
The appliance plug will t into a polarized outlet only
one way.
If the appliance plug does not t fully into the outlet,
reverse the plug. If the plug still does not t, make sure
that you are using the correct polarized wall outlet. If the
plug still does not t, contact a qualied electrician to
install the proper wall outlet. Do not modify the appliance
plug, power cord receptacle, or power cord plug in
any way.
Use only extension cords that are intended for outdoor
use. These extension cords are identied by marking
"Acceptable for use with outdoor appliance; store indoors
while not in use". Use only extension cord having an
electrical rating not less than the rating of the product. Do
not use damaged extension cords. Examine extension
cord before using and replace if damaged. Do not
abuse extension cord and do not yank on any cord to
disconnect. Keep cord away from heat and sharp edges.
Always disconnect extension cord from the receptacle
before disconnecting the product from the extension cord.
m WARNING m
Electric shock may cause SEVERE INJURY or
DEATH. Heed these warnings:
• Do not allow any part of the electric pressure washer
+ wet/dry vacuum to make contact with water while
it is in operation. If the appliance becomes wet while
turned o, wipe dry before starting.
• Do not use an extension cord over 25 ft. The
pressure washer + wet/dry vacuum comes equipped
with a 35 ft power cable. Combined cord length
must not exceed 60 ft. Any extension cord must be
14-gauge (or heavier) to safely power the pressure
washer.
• Do not touch the appliance or its plug with wet hands
or while standing in water. Wearing rubber boots
oers some protection.
EXTENSION CORD CHART
Cord Length:
Min. Wire Gauge (A.W.G.):
25 ft (7.6 m)
14
5
6. To prevent the appliance cord from disconnecting from the
extension cord during operation, make a knot with the two
cords as shown in Table 1.
7. Do not abuse the cord. Never pull the pressure washer
+ wet/dry vacuum by the cord or yank the cord to
disconnect it from the receptacle. Keep the cord away
from heat, oil, and sharp edges.
Risk of electrocution
• Inspect cord before using.
• Do not use if cord is damaged.
• Keep all connections dry and o the ground.
• Do not touch plug with wet hands.
• Keep cord away from heat and sharp edges.
• Do not spray electrical apparatus and wiring.
Risk of explosion
• Do not spray ammable liquids.
• Do not use acids, bases, solvents, or any ammable
material in this product. These substances can cause
physical injuries to the operator and irreversible damage to
the machine.
Additional safety instructions
• High-pressure: keep clear of nozzle.
• Injection hazard: equipment can cause serious injury if the
spray penetrates the skin.
• Do not point the gun at anyone or at any part of the body.
• In case of skin penetration, seek medical aid immediately.
• Before servicing, cleaning, or removing any parts, shut o
the power and relieve pressure.
• This machine is not suitable for connection to the potable
water mains.
• Use the handle to transport the unit. Do not lift the machine
by the dust compartment handle.
Product Description
Purpose
• This electric high pressure washer is intended for residential
use only. It is designed for medium-to-heavy duty cleaning
jobs on boats, motorcycles, RV’s, ATV’s, trailers, decks,
barbecues, siding, patio furniture, and more.
• This electric wet/dry vacuum is designed to clean hard
surfaces as paved paths, courtyards and terraces. It is only
suitable for vacuuming light materials such as grass, leaves,
small twigs and pieces of paper. The vacuuming of heavy
materials such as metal, stones, branches and broken glass
is expressly excluded.
Areas of application
• Never use the machine in potentially explosive areas under
any circumstances!
• The operating temperature must be between 32ºF (0ºC) and
104ºF (40ºC).
• The machine consists of an assembly with a pump, which
is encased in a shock-absorbing housing. To provide the
operator with an optimal working position, the machine is
equipped with a spray wand and a non-slip handle grip,
whose shape and conguration comply with applicable
regulations.
• Do not cover or modify the spray wand or the spray nozzle
in any way.
• The high-pressure electric power washer is designed to be
used with cold or lukewarm water; higher temperatures can
damage the pump.
• Do not use water that is dirty, gritty, or contains any
chemical products, as such impurities could impair
operation and shorten the life of the machine.
(B) Connect plug and receptacle
Cord set Appliance cord
(A) Tie cord as shown
Table 1. Method of Securing Extension Cord
6
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate.
To reduce the risk of injury, user
must keep all bystanders at least
49 ft (15 m) away.
Always keep the power cable
away from heat sources, oils, or
sharp edges. Immediately remove
plug from the mains if the cable is
damaged, frayed, or entangled.
READ THE OPERATOR'S
MANUAL(S) – Read, understand,
and follow all instructions in the
user manual(s) before attempting
to assemble and operate.
SAFETY ALERT – Indicates a
precaution, a warning, or a danger.
WEAR EYE AND HEARING
PROTECTION – For protection
against injury, wear ear defenders
and safety goggles.
Double Insulation – When servicing, use only identical replacement parts.
WARNING! Do not expose the
unit to rain or wet conditions.
Keep dry.
Machine not suitable for connection
to the potable water mains.
WARNING! Electrical shock hazard.
WARNING! Turn the machine OFF
and disconnect it from the power
supply before inspecting, cleaning,
changing accessories, or conducting
any other maintenance task.
Symbols SymbolsDescriptions Descriptions
Wear non-slip footwear that will
protect your feet and improve your
footing on slippery surfaces.
Wear safety gloves during
use to protect hands.
Store indoors. Never store the
electric pressure washer + wet/
dry vacuum outdoors. If the pump
freezes, permanent damage may
result.
5
7
Know Your Electric Pressure Washer + Wet/Dry Vacuum
Read the owner’s manual and safety rules carefully before operating the pressure washer + wet/dry vacuum. Compare the
illustration below to the unit in order to familiarize yourself with the location of the various controls and adjustments. Save this
manual for future reference.
Technical Data
Rated Voltage .........................................120 V ~ 60 Hz
Motor ...................................................... 12 A (Pressure washer)
10 A (Vacuum system)
Max Water Inlet Temperature .................104ºF/40ºC
Max Water Inlet Pressure .......................0.7 MPa
Max Flow ................................................ 1.45 GPM
Detergent Tank Capacity ........................ 25.4 oz (0.75 l)
Rated Pressure ....................................... 1133 PSI
Max Pressure ............................................. 1700 PSI
High-pressure Hose Length ...................... 20 ft (6 m)
Power Cord Length ................................... 35 ft (10.7 m)
Air Flow ...................................................... 5 ft
3
/min (1.5 m
3
/min)
Dust Tank Capacity ................................... 0.8 gal (3 l)
Working Air Pressure ................................. ≥12 kPa
Weight (no attachments) ............................ 25.6 lbs (11.6 kg)
1. Handle
2. Trigger gun
3. Trigger gun holder
4. Dust tank
5. Water outlet
6. Air outlet
7. Wheel (2)
8. Air inlet ( Vacuum hose connector)
2
3
4
5
6
7
10
8
11
12
13
14
15
16
17
9
1
9. Power cord holder
10. High pressure hose
11. Vacuum hose
12. High-pressure hose holder
13. Trigger
14. High pressure hose connector
15. Water inlet (garden hose connection)
16. Power cord with GFCI
17. Removable detergent tank
18. Extension tubes (2)
19. Spray wand
20. Adjustable nozzle
21. Dusting brush
22. Crevice nozzle
23. Furniture brush
24. Wet/dry bristle brush
25. Wet/dry oor brush
18
19
20
22
23
24
25
21
8
Unpacking
Carton Contents
• Electric pressure washer + Wet/dry vacuum
• Handle
• Two (2) large Phillips head screws (for handle)
• Spray wand
• Trigger gun
• Trigger gun holder
• Needle clean-out tool (included with manual packet)
• High-pressure hose
• Garden hose adapter (female coupler)
• 5-ft wet/dry vacuum hose
• Extension tubes (2)
• Furniture brush
• Crevice nozzle + dusting brush
• Wet/dry bristle brush
• Wet/dry oor brush
• Manuals with registration card
1. Carefully remove the pressure washer + wet/dry vacuum
and check to see that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new electric
pressure washer + wet/dry vacuum. The packaging is
made of recyclable materials. Properly dispose of these
materials in accordance with local regulations.
IMPORTANT! The equipment and packaging material are not
toys. Do not let children play with plastic bags, foils, or small
parts. These items can be swallowed and pose a suocation
risk!
mWARNING! Do not connect to power supply until
assembly is complete. Failure to comply could result in
accidental starting and possible serious personal injury.
Assembly
Tools required: Phillips head screwdriver
1. Slide the holder into position and secure it to the unit with
two large screws (Fig. 1).
Fig. 1
Handle
2 large
screws
2. Slide the trigger gun holder into position (Fig. 2).
Connect as Pressure Washer
1. Fit the spray wand into the gun and rotate it until the two
parts are completely locked (Fig. 3).
2. Connect the silver end of the high-pressure hose to the
trigger gun and twist the nut as indicated to secure the
connection (Fig. 4).
Fig. 2
Trigger
gun
holder
Trigger gun
Spray wand
Fig. 3
9
3. Connect the other end of the high-pressure hose to the
water outlet on the washer and twist the black rotatable
end-piece as indicated to secure the connection (Fig. 5).
mWARNING! Keep hose away from sharp objects.
Bursting hoses may cause injury. Examine hoses regularly and
replace if damaged. Do not attempt to mend a damaged hose.
4. Connect the garden hose adapter (female coupler) to
the water inlet of the pressure washer, then thread your
garden hose (male end) into the garden hose adapter
(Fig. 6). The garden hose must have an internal diameter
of at least 13 mm (1/2 in.) and must be reinforced. The
water supply must be at least equal to the washer delivery
capacity.
NOTE: The machine is not suitable for connection to the
potable water main.
5. Attach garden hose to water supply (Fig. 7).
Connect as Vacuum
mWARNING! Make sure the unit is not connected to
power and is switched o before assembly.
1. Insert the vacuum tube in the air inlet, turn the coupler
clockwise for a secure lock (Fig. 8).
Fig. 4
High pressure hose
Trigger gun
Fig. 5
High-pressure
water outlet
High-pressure hose
Fig. 6
Water inlet
(female coupler)
Garden hose
This end to
water inlet
Garden hose
(male end)
Fig. 7
Connect to water supply
Garden hose
Fig. 8
Vacuum hose
Air inlet
Coupler
10
2. Two extension tubes are equipped with the unit. Insert
the vacuum hose into the rst extension tube, and turn
counterclockwise to lock. Follow the same instruction to
assemble the second extension tube (Fig. 9).
3. Select the desired accessory, connect it with the end of
the extension tube, turn counterclockwise to lock securely.
Your wet/dry vacuum is ready for use (Fig. 10).
Operation
Using the Pressure Washer
mWARNING! The intake water temperature must not
exceed 104ºF/40ºC. The water supply must not exceed
0.7 MPa.
mCAUTION! The washer must only be used with clean
water; use of unltered water containing corrosive chemicals
will damage the washer.
mIMPORTANT! This pressure washer is equipped with
a micro-switch sensitive to water ow. This Total Stop System
(TSS) senses water ow in the pump. When the trigger is
released, water stops owing through the pump. The TSS then
automatically turns the motor o to protect the pump from
overheating, thus saving energy and prolonging pump life.
1. Position the washer as CLOSE as possible to the water
supply.
2. The washer must be used on a secure and stable surface
in a standing, upright position (Fig. 11).
3. Make sure the unit is switched o before plugging the unit
into the power outlet.
4. Check that the electrical supply voltage and frequency
(Volt/Hz) correspond to those specied on the rating plate.
If the power supply is correct, you may now plug the
pressure washer into the power outlet (Fig. 12).
Fig. 9
Vacuum hose
Extension tube
A
Extension tube B
Fig. 10
Extension tube
Selected
accessory
Fig. 11
RESET
TEST
Fig. 12
GFCI
Power light
indicator
Reset
11
NOTE: The GFCI may need to be reset when rst plugged
into the electric outlet. Press the "Reset" button until
the power light indicator on the GFCI illuminates when
plugged in.
5. Turn the water supply tap on completely.
6. Release the safety lock, then press the trigger for a few
seconds until the water ow is steady. Operating the
pressure washer in this manner will allow air to escape
and discharge residual pressure in the hose
(Figs. 13 – 14).
7. Keeping the trigger pressed, push the PW(I) side of the
ON/OFF switch (Fig. 15).
8. When re-starting the motor, always keep the trigger
pressed.
NOTE: The motor only runs when the trigger is operated
and shuts o when the trigger is released.
Using the adjustable spray nozzle
mWARNING! High-pressure jets can be dangerous if
subject to misuse. The jet must not be directed at persons,
pets, live electrical equipment, or the appliance itself.
1. The washer is equipped with an adjustable nozzle.
2. The water pressure can be adjusted from low pressure (–)
to high pressure (+) by turning the pressure adjustment
knob. The nozzle tip can be adjusted from pencil spray
(wide open tip) to fan spray (narrow tip) by turning the
nozzle tip adjustment knob (Fig. 16).
mWARNING! Do not adjust the nozzle while the trigger
is squeezed. Doing so could result in damage.
Fig. 13
Trigger
Safety lock
Fig. 14
PW(I) OFF(0) VAC (II)
Fig. 15
Pressure washer
switch
Fig. 16
Fan spray
Pencil spray
Pressure adjustment knob
Nozzle tip
adjustment knob
Nozzle tip
12
Working with Detergents
When cleaning with the pressure washer, some cleaning tasks
can be solved with water alone, but for most tasks cleaning
with detergent allows for more eective dirt removal.
mWARNING! Use only detergents specically designed
for use with pressure washers, such as Sun Joe
®
HOUSE +
DECK WASH (SPX-HDC1G), Sun Joe
®
SNOW FOAM AUTO
WASH (SPX-FCS1G), or Sun Joe
®
HEAVY DUTY CLEANER
(SPX-APC1G). DO NOT USE household detergents, acids,
alkaline solutions, bleaches, solvents, ammable material, or
industrial grade solutions. These could damage the pressure
washer. Many detergents may require mixing prior to use.
Prepare the cleaning solution as instructed on the solution
bottle.
1. Set the adjustable nozzle to the fan-spray setting (Fig. 16).
2. Remove the detergent compartment cap with suction
tube. Gently pull the onboard detergent compartment out
of its storage position. (Figs. 17 – 18).
3. Fill the tank with detergent designed specically for use
with pressure washers (Fig. 19).
4. Insert the suction tube back into the tank and cap the tank
closed. Push the tank back into storage position on the
unit.
mCAUTION! Always test the detergent in an
inconspicuous area before use.
5. Turn on the pressure washer. Pull the trigger to operate
the unit. The liquid detergent will automatically mix with
water and be discharged through the nozzle.
6. Apply detergent from the bottom to the top of the dry
surface to be cleaned.
NOTE: Wetting the surface rst is not recommended as it
dilutes the detergent and reduces its cleaning ability.
7. Allow the detergent to remain on the surface for a short
time before rinsing. Do not allow the detergent to dry on
the surface.
mCAUTION! Damage may occur to painted surfaces if
the detergent is allowed to dry on the surface. Wash and rinse
a small section at a time. Avoid working on hot surfaces or in
direct sunlight.
8. Rinse with clean water under high pressure. When working
on a vertical surface, rinse from the bottom up, then rinse
from the top down to avoid streaking. Hold the nozzle 6-8
inches away from the work surface at a 45° angle.
9. When you have nished using the detergent injection
system, remove the detergent suction tube from the
detergent tank and insert it into 1.3 gal (5 L) of fresh water.
Siphon water for one minute so that all the detergent is
ushed through the system. Remove the detergent tank
and rinse it until it is thoroughly cleaned.
mCAUTION! Failure to follow these cleaning instructions
will cause the injection system to become clogged and
inoperable.
Fig. 17
Detergent tank
Detergent tank cap
with suction tube
Fig. 18
Detergent tank
Fig. 19
Detergent tank
Pressure washer
detergent
13
mIMPORTANT! NEVER USE:
• Bleach, chlorine products, and other corrosive chemicals
• Liquids containing solvents (e.g. paint thinners, gasoline,
oils)
• Tri-sodium phosphate products
• Ammonia products
• Acid-based products
These chemicals will harm the unit and will damage
the cleaning surface.
Shutting down
1. Turn the switch to the OFF (0) position and unplug the
power cord from the outlet.
2. Turn o the water source.
3. Hold the trigger to release water pressure.
4. Disconnect the garden hose from the water inlet on
the unit.
5. Disconnect the high-pressure hose connection on the
trigger gun handle.
6. Release the trigger and engage the gun safety lock.
mWARNING! Turn o the water supply and squeeze the
trigger to depressurize the unit. Failure to do so could result in
personal injury due to discharge of high-pressure water.
Taking a break
If you are taking a break of ve minutes or more between
cleaning tasks:
1. Engage the gun safety lock (Fig. 13).
2. Turn the switch to the OFF (0) position.
3. Unplug the power cord from the outlet.
Using the Wet/Dry Vacuum
mWARNING! This equipment incorporates parts such
as switches, motors or the like that tend to produce arcs or
sparks that can cause an explosion. Do not pick up ammable,
combustible, or hot materials. Do not use around explosive
liquids or vapors, as electrical devices produce arcs or sparks
which can cause a re or explosion – do not use at lling
stations or anywhere gasoline is stored or dispensed.
1. Make sure the lter is installed before starting.
2. Make sure the dust compartment and the vacuum hose
are installed properly and locked securely.
3. Install the desired cleaning accessory onto the end of the
hose. Use the extension tubes if needed.
4. Check that the electrical supply voltage and frequency
(Volt/Hz) correspond to those specied on the rating plate.
If the power supply is correct, you may now plug the
vacuum into the power outlet (Fig. 12).
5. Push the VAC(II) side of the ON/OFF switch (Fig. 20).
6. After the vacuum job is done, push the OFF(O) position of
the switch, unplug the power cord. Disassemble and store
all the vacuum accessories.
Adjust the Air Flow
The air ow of the unit is adjustable through the air block
located on the end of the vacuum hose. To adjust the air ow,
following the instruction below.
1. Remove the extension tube from the vacuum hose to
expose the air block.
2. To reduce the air ow, slide up the air block to expose the
air vent on the vacuum hose, the suction power will be
reduced. To increase the air ow, slide down the air block
to cover the air vent, the suction power will be increased
(Fig. 21).
3. Reassemble the extension tubes and selected accessory
and resume working.
PW(I) OFF(0) VAC (II)
Fig. 20
Vacuum switch
Fig. 21
Vacuum hose
Air block
Air vents
14
Using the Equipped Attachments
The unit is equipped with 4 attachments: utility nozzle, wet/
dry oor brush, crevice nozzle, and wet/dry furniture brush.
Choose dierent attachment based on the specic cleaning
project you are working on.
1. The wet/dry oor brush can be adjusted to extend out or
retract in. Simply follow the symbol on the brush switch to
adjust the brush (Fig. 22).
2. The crevice nozzle can be stored inside of the unit with the
dust tank being removed (Fig. 23). Make sure to remove
the stored crevice nozzle and lock in the dust tank before
using the unit.
Clean the Dust Tank
The dust tank needs to be cleaned every time after using to
avoid deterioration and obstructing air ow, which will reduce
the performance of the vacuum. Follow the instructions below
to clean the dust tank
1. Switch o and unplug the unit.
2. Push the dust tank lock inside and pull out the dust tank
at the same time (Fig. 24).
3. Grab the dust tank handle and turn counterclockwise, the
dust tank cap with lter will be removed from the dust bin
(Fig. 25).
4. Remove any debris or dust from the dust bin. Rinse the
dust bin with warm water if needed. Replace it back and
lock securely before using.
Storage
m
CAUTION! Always store your pressure washer + wet/
dry vacuum in a location where the temperature will not fall
below 32ºF (0ºC). The pump in this machine is susceptible to
permanent damage if it freezes. FREEZE DAMAGE IS NOT
COVERED BY THE WARRANTY.
• Store the pressure washer + wet/dry vacuum indoors
in a dry, covered area where it is not subject to adverse
weather conditions.
• It is important to store this product in a frost-free area.
• Always empty water from the dust bin, all hoses, the
pump, and the detergent bottle (if using) before storing.
Fig. 22
Brush adjustment
switch
Fig. 23
Crevice nozzle
Fig. 24
Dust tank
Dust tank handle
Dust tank
lock
Fig. 25
Dust
bin
Dust tank cap
withlter
15
mCAUTION! The use of a pump protector is
recommended to prevent cold weather damage during storage
over the winter months.
Winterizing + long-term storage
If you must store your pressure washer + wet/dry vacuum in a
location where the temperature falls below 32ºF (0ºC), you can
minimize the chance of damage to your machine by utilizing
the following procedure:
• Disconnect all water connections.
• Turn on the machine as pressure washer for a few
seconds until the remaining water in the pump exits. Turn
o immediately.
• Do not allow the high-pressure hose to become kinked.
• Store the machine and accessories in a room that does
not reach freezing temperatures.
• Do not store near a furnace or other sources of heat that
may dry out the pump seals.
• Operate the pressure washer with non-corrosive/non-toxic
anti-freeze, a pump saver, or a pump protector before
storing for the winter.
mWARNING! Before reusing, completely ush the unit
out with clear water. Anti-freeze products can damage
paintwork, so you must ensure there is no anti-freeze left in the
system before using it again.
Maintenance
m
CAUTION! Before working on the pressure washer +
wet/dry vacuum, disconnect the plug from the power supply
socket.
Clean the Adapter Filter and the Nozzle
1. To ensure good performance, check and clean the adapter
lter (Fig. 26). Remove the lter and rinse with warm water
to prevent any foreign matter from clogging the pump (Fig.
27).
2. Clean the nozzle with the needle clean-out tool provided
(Fig. 28). Remove the spray wand from the gun; remove
any dirt from the nozzle hole and rinse.
Clean and Change the Dust Filter
mWARNING! Use only original manufacturer’s
replacement parts, accessories and attachments. Failure to do
so can cause possible injury and poor performance.
To order genuine replacement parts or accessories for the
Sun Joe
®
SPX7000E-RM electric pressure washer + wet/dry
vacuum, please visit snowjoe.com or contact the
Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563).
1. Remove the dust tank from the unit, and separate the dust
bin and dust tank cap with lter (Figs. 24 – 25).
2. Grab the lter handle on the bottom, screw clockwise to
remove the dust tank cap from the old lter assembly (Fig.
29).
Fig. 26
Adapterlter Garden hose adapter
Fig. 27
Filter
Fig. 28
Needle clean-out tool
16
3. Insert the new lter assembly inside the dust tank cap.
Replace the dust tank in the unit and resume working.
4. Instead of replacing, the dust lter assembly can also be
washed. Use a screw driver to remove the 3 screws that
secure the black retainer, take out the oating ball
(Fig. 30).
5. Rinse the dust lter, oating ball and the retainer with
warm water, and reassemble the lter assembly.
Disposal
Recycling the Pressure Washer + Wet/
Dry Vacuum
• Do not dispose of electrical appliances as unsorted
municipal waste. Use separate collection facilities.
• Contact your local government agency for information
regarding the collection systems available.
• If electrical appliances are disposed of in landlls
or dumps, hazardous substances can leak into the
groundwater and get into the food chain, damaging your
health and well-being.
Service + Support
If your Sun Joe
®
SPX7000E-RM electric pressure washer
+ wet/dry vacuum requires service or maintenance, please
call the Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563).
Model + Serial Numbers
When contacting the company, reordering parts, or arranging
service from an authorized dealer, you will need to provide the
model and serial numbers, which can be found on the decal
located on the housing of the unit. Copy these numbers into
the space provided below.
S P X 7 0 0 0 E - R M
Record the following numbers from the housing or handle of your
new product:
Model #:
Serial #:
Fig. 29
Filter assembly
Filter handle
Dust tank cap
Fig. 30
Filter
Floating ball
Retainer
17
Troubleshooting
• Disconnect the unit from the electrical power supply before carrying out maintenance on the machine or when checking that
its parts are in proper working order.
• To avoid unnecessary hassles, consult the following table before contacting customer service with any mechanical issues.
Problems Possible Cause Possible Solution
Machine refuses
to start
• Power failure/machine not
plugged into a working receptacle.
• Defective socket.
• Fuse has blown.
• Defective extension cord.
• Check to make sure machine is plugged into
a working outlet.
• Check the power cord and reset the GFCI.
Try a dierent outlet.
• Replace fuse. Switch o any other machines
that are using the same circuit.
• Try the unit without an extension cord.
• Check the hoses and connections are airtight.
• Clean or replace valves/seals.
• Please call the Snow Joe
®
+ Sun Joe
®
customer
service center at 1-866-SNOWJOE (1-866-766-9563)
for assistance.
• Replace fuse. Switch o other machines using
the same circuit.
• Check that the mains voltage corresponds to
specication on the model tag.
• Leave the washer for 5 minutes to cool down.
• Clean the nozzle.
• Install a fuse with a higher amp rating than the
amp consumption of the machine. Try the unit
without an extension cord.
• Allow machine to run by holding the trigger until
regular working pressure resumes.
• Check that the water supply corresponds to the
specications required.
• WARNING! Avoid using long, thin hoses
(minimum 1/2 in. diameter).
• Clean the nozzle.
• Clean the water inlet lter.
• Straighten out the hose to remove any kinks/blockages.
• Please call the Snow Joe
®
+ Sun Joe
®
customer service
center at 1-866-SNOWJOE (1-866-766-9563) for
assistance.
• Wait for pump/hoses or accessories to thaw.
• Connect inlet water.
• Clean the water inlet lter.
• Clean the nozzle.
• Pump sucking air.
• Valves dirty, worn out, or stuck.
• Pump seals worn out.
• Fuse has blown.
• Incorrect mains voltage.
• Thermal sensor activated.
• Nozzle partially blocked.
• Fuse too small.
• Air in inlet hose.
• Inadequate supply of mains water.
• Nozzle partially blocked.
• Water lter blocked.
• Hose kinked.
• Pump/spray gun is leaking.
• Trigger mechanism is broken.
• Pump/hoses or accessories frozen.
• No water supply.
• Water inlet lter blocked.
• Nozzle blocked.
Fluctuating pressure
Machine stops
Fuse blows
Machine pulsating
Machine often starts
and stops by itself
Machine starts, but
no water comes out
18
Optional Accessories
m
WARNING! ALWAYS use only authorized Snow Joe
®
+ Sun Joe
®
replacement parts and accessories. NEVER use
replacement parts or accessories that are not intended for use with this electric pressure washer + wet/dry vacuum. Contact
Snow Joe
®
+ Sun Joe
®
if you are unsure whether it is safe to use a particular replacement part or accessory with your pressure
washer + wet/dry vacuum. The use of any other attachment or accessory can be dangerous and could cause injury or
mechanical damage.
25-Foot Medium-duty Extension Hose for
SPX Pressure Washer Series
Solid Brass Universal Quick Connector
(Garden Hose to Pressure Washer Adapter)
SPX-25H
SPX-UQC
ModelAccessories Item
2
1
3
Sun Joe
®
House + Deck All-Purpose Pressure
Washer Rated Concentrated Cleaner
SPX-HDC1G
Sun Joe
®
Premium Snow Foam Pressure
Washer Rated Car Wash Soap + Cleaner
SPX-FCS1G
Sun Joe
®
All-Purpose Heavy Duty Pressure
Washer Rated Cleaner + Degreaser
SPX-APC1G
Sun Joe’s complete line of premium pressure washer accessories and attachments
make it easy to get your dirty work done, and also help you get the most out of your model!
SHOP ONLINE now at sunjoe.com
NOTE: Accessories are subject to change without any obligation on the part of Snow Joe
®
+ Sun Joe
®
to provide notice of such
changes. Accessories can be ordered online at snowjoe.com or via phone by contacting the Snow Joe
®
+ Sun Joe
®
customer
service center at 1-866-SNOWJOE (1-866-766-9563).
1919
SNOW JOE
®
+ SUN JOE
®
REFURBISHED GOODS WARRANTY
GENERAL CONDITIONS:
Snow Joe
®
+ Sun Joe
®
operating under Snow Joe
®
, LLC warrants
this refurbished product to the original purchaser for 90 days
against defects in material or workmanship when used for normal
residential purposes. If a replacement part or product is needed,
it will be sent free of charge to the original purchaser except as
noted below.
The duration of this warranty applies only if the product is put to
personal use around the household. It is the owner’s responsibility
to correctly perform all maintenance and minor adjustments
explained in the owner’s manual.
HOW TO OBTAIN YOUR REPLACEMENT PART OR PRODUCT:
To obtain a replacement part or product, please visit
snowjoe.com/help or email us at [email protected] for
instructions. Please be sure to register your unit beforehand to
speed up this process. Certain products may require a serial
number, typically found on the decal axed to the housing
or guard of your product. All products require a valid proof
of purchase.
EXCLUSIONS:
• Wearing parts like belts, augers, chains and tines are
not covered under this warranty. Wearing parts can be
purchased at snowjoe.com or by calling 1-866-SNOWJOE
(1-866-766-9563).
• Batteries are covered in full for 90-days from the date of
purchase.
Snow Joe
®
+ Sun Joe
®
may from time to time change the design
of its products. Nothing contained in this warranty shall be
construed as obligating Snow Joe
®
+ Sun Joe
®
to incorporate
such design changes into previously manufactured products, nor
shall such changes be construed as an admission that previous
designs were defective.
This warranty is intended to cover product defects only.
Snow Joe
®
, LLC is not liable for indirect, incidental or
consequential damages in connection with the use or misuse of
the Snow Joe
®
+ Sun Joe
®
products covered by this warranty.
This warranty does not cover any cost or expense incurred
by the purchaser in providing substitute equipment or service
during reasonable periods of malfunction or non-use of this
product while waiting for a replacement part or unit under this
warranty. Some states do not allow exclusions of incidental or
consequential damages so the above exclusions may not apply
in all states. This warranty may give you specic legal rights in
your state.
HOW TO REACH US:
We’re here to help Monday through Friday from 9AM to 6PM EST.
You can reach us at 1-866-SNOWJOE (1-866-766-9563), online
at snowjoe.com, via email at [email protected] or tweet us
@snowjoe.
EXPORTS:
Customers who have purchased Snow Joe
®
+ Sun Joe
®
products exported from the United States and Canada should
contact their Snow Joe
®
+ Sun Joe
®
distributor (dealer) to obtain
information applicable to your country, province or state. If for
any reason, you are not satised with the distributor’s service,
or if you have diculty obtaining warranty information, contact
your Snow Joe
®
+ Sun Joe
®
seller. If in the event your eorts are
unsatisfactory, please reach out to us directly.
snowjoe.com
