KEY FEATURES
AVAILABLE MODELS
ZOOM
UP/DOWN ICONIC RANGE HOOD
REDEFINING LUXURY AND RANGEHOOD TECHNOLOGY. The zoom is a chandelier style up and down motion
range hood that will add elegance and luxury functionality to island installations. Use the Zoom cylinder by itself, the
white glass OR stainless steel lamp shade with lighting or use your own custom shade. The lamp shade offers 6 LED
ceiling lights wired to a separate on / off switch.
ZOOMIS16SS400-B
shown
ZOOMIL16SS400
with VANILLA-SH
ZOOMIL16SS400
with OCEANA-SH
model # description size / color cfm sones
ZOOMIS16SS400-B Zoom 16" SS 400 1.0 - 6.6
ZOOMIL16SS400* Zoom with ceiling light fixture* 16" SS* 400 1.0 - 6.6
* choose a shade size / color*
VANILLA-SH 21" WH
OCEANA-SH 21" SS
* Choose the Zoom Island Hood (ZOOMIS16SS400-B) by itself OR
Zoom Island plus Ceiling Light Fixture (ZOOMIL16SS400).
Vanilla OR Oceana shades kits pair with the ZOOMIL16SS400
ZOOMIL16SS400 with
CUSTOM SHADE
Remote Control (included)
Control all features of the hood
from the convenience of a wireless
remote control
Charcoal Filter (included)
High quality charcoal filter to clean
and recirculate the air
6 LED Lights (ZOOM-
IL16SS400)
The IL version of the Zoom lights
the area with 6 energy efficient
LED lights.
Up/Down Technology
The hood can be lowered and
retracted easily with the included
remote control.
SPECIFICATIONS DIMENSIONS
ACCESSORIES
Rev :4/19
2 Cabot Road Hudson, MA 01749 • TEL: (508) 358-5353 • E-Mail: info@faberonline.com www.faberonline.com
Imagined in Italy
WARNING! Product specifications are subject to
change without notification. Consult the installation
instructions before you begin installing this range
hood. * Check local make up air codes for
guidelines.
PERFORMANCE
ZOOM
UP/DOWN ICONIC RANGE HOOD
Min. / Max ceiling height (IL) 8' min - 9' max
Min. / Max ceiling height (IS) 7' min - 9' max
Maximum Zoom movement 34"
Zoom width | height 16 1/8" | 16 5/16"
recirculation only
(NON-DUCTED ONLY)
Yes - charcoal filters included
controls 5 speed digital control
lighting (Zoom hood IS and IL) 4 LED (1 Watt) - spot lights
lighting (Ceiling fixture IL) 6 LED (1Watt) - spot lights
24-hour antipollution mode yes
30 Minute delay auto shut o yes
Perimetric filter system yes
10 Minute Intensive speed yes
grease filters dishwasher safe mesh
ADA compliant yes - remote control included
AC power
350 watts / 2.9 amps
SPEED 1 2 3 BOOST
CFM 150 250 350 390
Sones 1 3 5.1 6.6
IMPORTANT NOTE: Custom designed
shades must be at least 16 15/16" high x
20 1/4" wide. Shade materials must be
made of non-combustable materials.
# FILTER1 –
Charcoal Filter Kit
High quality charcoal filter
for use when recirculating
the air back into the kitchen.
Filters out odor and should be
replaced every 6 months.
# FILTER1LL –
Long Lasting Charcoal
Filter Kit
New washable charcoal filter can
be recharged and washed up to 8
times. For use when recirculating
the air back into the kitchen. Filters
out odor and can last up to 4 years
ZOOMIS16SS400-B
ZOOMIS16SS400-B Top Diagram
6
RANGEHOOD DIMENSIONS
Ø5 7/8"
4 3/16" 4 3/16"
4 3/16
"
4 3/16
"
16
1/8"
16 15/16"
Max. 51
5/8"
Min. 24" Min. 30"
ZOOMIL16SS400 with Oceana
ZOOMIL16SS400 with Vanilla
