Samsung RS68N8320S9/EU Refrigerator

User Manual

For RS68N8320S9/EU. Additionally, the document applies to other Samsung models: RS6*N**, RS68N8320S9

PDF File Manual, 76 pages, Read Online | Download pdf file

RS68N8320S9/EU photo
background
Refrigerator
User manual
RS6*N**
SEUK Free Standing Appliance
Untitled-38 1 2018-06-08  2:16:45
Loading page 2...
Loading page 3...
Loading page 4...
Loading page 5...
Loading page 6...
Loading page 7...
Loading page 8...
Loading page 9...
Loading page 10...
Loading page 11...
Loading page 12...
Loading page 13...
Loading page 14...
Loading page 15...
Loading page 16...
Loading page 17...
Loading page 18...
Loading page 19...
Loading page 20...
Loading page 21...
Loading page 22...
Loading page 23...
Loading page 24...
Loading page 25...
Loading page 26...
Loading page 27...
Loading page 28...
Loading page 29...
Loading page 30...
Loading page 31...
Loading page 32...
Loading page 33...
Loading page 34...
Loading page 35...
Loading page 36...
Loading page 37...
Loading page 38...
Loading page 39...
Loading page 40...
Loading page 41...
Loading page 42...
Loading page 43...
Loading page 44...
Loading page 45...
Loading page 46...
Loading page 47...
Loading page 48...
Loading page 49...
Loading page 50...
Loading page 51...
Loading page 52...
Loading page 53...
Loading page 54...
Loading page 55...
Loading page 56...
Loading page 57...
Loading page 58...
Loading page 59...
Loading page 60...
Loading page 61...
Loading page 62...
Loading page 63...
Loading page 64...
Loading page 65...
Loading page 66...
Loading page 67...
Loading page 68...
Loading page 69...
Loading page 70...
Loading page 71...
Loading page 72...
Loading page 73...
Loading page 74...
Loading page 75...
Loading page 76...

Other documents for Samsung RS68N8320S9/EU

The following documents are available:
User Manual Photos

Specifications

Samsung RS68N8320S9/EU Questions and Answers


#1 What should I do when the display is not responding properly on my refrigerator?

When the display is locked
Step 1. Press the [Lock/Unlock] button for more than 3 seconds to change to the unlocked state. In case of Child Lock, press the Child Lock button for 5 seconds.
Step 2. Check the operation by pressing the temperature control button.
When the refrigerator is in Sabbath Mode
In Sabbath mode, the buttons, display, and internal lights do not function. However, the fridge and freezer continue to cool.
Step 1. If your model has an Automatic Control Lock, you will need to unlock it first.
Step 2. Touch and hold the correct button combination from the following list (or consult your user manual) for 5 seconds until the lights go out or come back on.
- Door Alarm and Water/Ice.
- Freezer and Door Alarm.
- Power Freeze and Power Cool.
When a specific button is intermittently not operated
If only a specific button is not available, it may be caused by a gap between the contacts of the button.
Press and hold [Lock/Unlock] to change to unlocked and then press the button with force.
When the display sometimes looks dim
The brightness and colour pattern of the refrigerator display may differ depending on the model. Especially if the overall colour of the door is white, the display may feel blurry. It is not a malfunction unless the character is broken or is not visible on the display.
Due to drastic power fluctuations (Only for the French Door model)
The display screen on your refrigerator may not function correctly due to drastic power fluctuations.
When this happens, the fridge screen will display 88 88.
- If the fridge display is showing 88 88 (all eights) and is still cooling properly, then unplug the refrigerator for 60 seconds and then plug it back in.
- If the display does not return to normal after 2 minutes, then contact an authorised Samsung service centre.
Display reset (Only for the Family Hub model)
If you encounter an abnormal symptom on the display, try resetting the display. This may solve the problem.
Step 1. Open the right-side fridge door and locate the switch cover on the top right corner of the door.
Step 2. Push up the cover to reveal the power switch.
Step 3. Turn the switch off and turn it on again.
Step 4. Reinsert the switch cover to the end until you hear a clicking sound.

#2 How to deactivate demo mode in my refrigerator?

Demo mode (also called Exhibition mode, Cooling Off mode, or Shop mode) is usually used in a situation where a refrigerator is displayed at a retail shop. This is to allow consumers to freely explore the inside and outside of the product. In Demo mode, the refrigerator lights up and appears to be working. However, the cooling function is disabled, and the control panel turns on but does not work.
If there is no cooling in the refrigerator or you can see the "O FF" or "OF OF" sign on the display, check if the refrigerator is in "Demo mode". If you want to deactivate demo mode, follow the instructions in the following guide.
General refrigerator (except Family Hub)
Step 1. Press and hold Button 1 and Button 2 at the same time until you hear a beep.
Step 2. If the Demo mode is not turned off after the above operation, press and hold Button 1, Button 2, and Button 4 at the same time until you hear a beep.
Step 3. Check the current temperature on the display when Demo mode is deactivated.
Family Hub
Step 1. Tap Apps, open the Fridge Manager app, and then tap Fridge Settings.
Step 2. Tap Cooling off Deactivate and then tap Proceed.
