GB
Quick Guide
THANK YOU FOR PURCHASING A HOTPOINT PRODUCT.
To receive more comprehensive assistance, register the
appliance on
www.hotpoint.co.uk/register
Before using the appliance carefully read the Health and Safety guide.
Before using the machine, it is imperative that the transport bolts are removed. For more
detailed instructions on how to remove them, see the Installation Guide.
CONTROL PANEL
For all testing institutes:
2) Long wash cycle for cottons: set wash cycle 3 with a temperature of 40°C.
3) Long wash cycle for synthetics: set wash cycle 5 with a temperature of 40°C.
* By selecting the cycle and excluding the spin cycle, the washing machine will drain only.
The cycle duration indicated on the display or instruction manual is an estimate based on
standard conditions. The actual duration may vary in relation to several factors, such as
the temperature and pressure of the incoming water, ambient temperature, amount of
detergent, load quantity and type, load balancing and any additional options selected.
1) Test wash cycle in compliance with regulation 1061/2010:
This cycle is designed for normally soiled cotton loads and is the most ecient in terms of
both electricity and water consumption; it should be used for garments washable at 60°C or
at 40°C. The actual washing temperature may dier from the indicated value.
PRODUCT DESCRIPTION
1.
3.
2.
5.
4.
7.
6.
8.
1. Top
2. Detergent dispenser drawer
3. Control panel
4. Handle
5. Porthole door
6. Drain pump (behind the plinth)
7. Plinth (removable)
8. Adjustable feet (2)
DETERGENT DISPENSER DRAWER
Compartment *:
Do not insert detergent in this compartment.
Compartment 1: Washing detergent (powder
or liquid)
If liquid detergent is used, the removable plastic
partition A (supplied) should be used for proper
dosage.
If powder detergent is used, place the partition
into slot B.
Compartment 2: Additives (fabric softeners, etc.)
The fabric softener must not exceed the “MAX” level.
! Use powder detergent for white cotton garments, for pre-washing, and
for washing at temperatures over 60°C.
! Follow the instructions given on the detergent packaging.
1
2
A
B
*
WASH CYCLE TABLE
1. ON/OFF button
2. TEMPERATURE knob
3. SPIN SPEED knob
4. WASH CYCLE PROGRESS indicator lights
5. DOOR LOCKED indicator light
6. START/PAUSE button and indicator light
7. OPTION buttons and indicator lights
8. WASH CYCLE SELECTOR KNOB
1
8
3
5
6
7
4
2
Maximum load 8 kg
Power input in o mode 0.5 W / in left-on mode 8 W
Detergents and
Additives
Recommended
detergent
Residual
dampness %
Energy con-
sumption kWh
Total water l
Wash cycle
Temperature
Max.
spin speed
(rpm)
Max.
load
(kg)
Duration
(minutes)
Wash
Fabric
softener
Powder Liquid
Default Range
1 2
1 Anti Stain 40°C
- 40°C 1400 5 180’
–
– – –
2 Whites 60°C
- 90°C 1400 8 145’
– – –
3 Cotton (2) 40°C
- 60°C 1400 8 220’
–
53 1.03 92
4
Eco Cotton 60° - 40° (1)
60°C
60°C 1400 8 225’
53 1.23 55
40°C 1400 8 220’
53 1.03 92
5 Synthetics (3) 40°C
- 60°C 1000 4.5 125’
–
46 0.56 65
6 Anti Allergy Plus 60°C
- 60°C 1400 5 195’
– – –
7 Baby 40°C
- 40°C 1000 5 145’
–
– – –
8 Bed & Bath 60°C
- 60°C 1400 8 140’
– – –
9 Fast Wash 60’ 60°C
- 60°C 1400 3.5 60’
– – –
10 Fast Wash 30’ 30°C
- 30°C 800 3.5 30’
–
– – –
11 Cotton 20°C 20°C
- 20°C 1400 8 175’
–
– – –
12 Shirts 40°C
- 40°C 600 2 80’
–
– – –
13 Wool 40°C
- 40°C 800 2 85’
–
– – –
14 Delicates 30°C
- 30°C 0 1 80’
–
– – –
Rinse – – 1400 8 50’ –
– – – – –
Spin + Pump Out * – – 1400 8 10’ – – – – – – –
Required dosage Optional dosage
