Sencor SES 5000SS Espresso Coffee Machine User Manual

SES 5000SS

ESPRESSO COFFEE MACHINE WITH

A BUILT-IN GRINDER

Translation of the original manual

SES 5000SS

OFF

Power Espresso Heating Espresso

Grind SteamCold Espresso

1 2 3

4 5 6

Power Espresso Heating Espresso

Grind Steam Cold Espresso

C1 C2

G1 G2

PowerEspresso Heating Espresso

GrindSteam Cold Espresso

PowerEspresso Heating Espresso

GrindSteam Cold Espresso

PowerEspresso HeatingEspresso

GrindSteam Cold Espresso

- 1 -

04/2025

2025, .

Espresso Coffee Machine with a Built-in Grinder

User Manual

Important Safety Instructions

READ CAREFULLY AND STORE FOR FUTURE USE.

• This appliance is not to be used by children. Keep this

appliance and its power cable out of the reach of children.

• Appliances may be used by persons with reduced

physical, sensory or mental abilities or lack of experience

and knowledge, provided they are supervised or have

been instructed in the safe use of the appliance and

understand the potential hazards.

• Children must not play with the appliance.

• Cleaning and maintenance must not be performed by

unsupervised children.

• Keep the appliance and its power cord out of reach of

children younger than 8 years of age.

• If the power cord is damaged, have it replaced in

aprofessional service centre in order to prevent

adangerous situation. It is forbidden to use the appliance

with the power cord damaged.

• Always clean the parts of the appliance that come into

contact with food with clean warm water and alittle neutral

dishwashing liquid, rinse them with clean water and wipe

dry.

ESPRESSO COFFEE MACHINE WITH A BUILT-IN GRINDER

- 2 -

04/2025

2025, .

WARNING:

Incorrect use may lead to injury.

Always disconnect the appliance from the power

socket if you are leaving it unattended and before

assembly, disassembly or cleaning.

• This appliance is intended for household use. It is also

suitable for personal non-commercial use in spaces such as:

– kitchenettes in stores, offices and other workplaces;

– agriculture;

– hotels, motels and other residential spaces;

– bed and breakfast establishments.

• The appliance must not be immersed in water during

cleaning.

WARNING:

The filling hole must not be opened during use.

WARNING:

Prevent the plug from getting wet.

• The outer surface of the appliance heats up during use

and may be hot for some time after use. Be very careful.

• The appliance must not be placed in acabinet when in

use.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

- 3 -

04/2025

2025, .

Additional important safety instructions foruse of the appliance

• Before connecting the appliance to apower socket, make sure that its nominal voltage indicated on the rating plate matches the electrical voltage of

the socket.

• Connect the appliance only to aproperly earthed socket. For safety reasons, we do not recommend using adaptors or extension cables.

• Do not place the appliance on windowsills, sink drain trays or unstable surfaces. Always place the appliance on astable, flat and dry surface.

• Do not place the appliance on an electric or gas stove or near an open flame.

• Never use the appliance in the immediate vicinity of abath, shower or swimming pool.

• The appliance is designed formaking coffee or tea (only by dispensing hot water). Use the appliance only for its intended purpose.

• Do not use the appliance outdoors.

• Use the appliance according to the instructions in this user manual. Failure to do so may result in injury, damage to the appliance, or ahazardous

situation.

• Leave at least 15 cm of free space around and above the appliance to ensure proper air circulation during operation.

• Only use the top surface of the appliance to warm cups, the portafilter or filters. Do not use it to store other items.

• Fill the water tank with clean, cold water. Do not pour heated water or other liquids into it or insert any objects into it.

• Never fill the coffee bean hopper with ground or instant coffee, caramelised or otherwise specially treated coffee beans, cocoa beans or other items

that may damage the appliance.

• Before turning on the appliance, make sure that:

– the drip tray and grille are in place;

– the water tank is filled with asufficient amount of water and is properly in place. The water level must not exceed the maximum mark;

– the coffee bean hopper is correctly installed in the appliance and contains coffee beans.

• Never start, use or switch on the appliance withan empty water tank or an empty coffee bean hopper. There is arisk of damage to the appliance.

• Take extra care when operating the appliance to avoid scalding with hot water or steam.

• The hot water or steam dispenser may only be used continuously for amaximum of 99 seconds.

• Regularly check the water level in the tank while using the appliance. If the water level drops below the minimum mark, refill the tank according to

the instructions in this manual. Before adding water, first turn the appliance off and disconnect it from the power socket.

• Use the built-in coffee grinder only for grinding coffee beans. Do not use it for any other purposes.

• Ensure that no hair or other items enter the grinder area during the grinding process. The coffee bean hopper lid should always be properly closed

unless you are topping up the coffee beans.

• Be careful when handling afull drip tray. The water can be hot and there is arisk of scalding or burns.

• The appliance is equipped with abuilt-in thermal fuse that shuts it off when the pump is idling to prevent damage. If such asituation occurs, unplug

the power cable and allow the appliance to cool down for at least 30 minutes. Then you can use it again.

• Do not move the appliance when there is acup of coffee on the drip tray grille or with cups on the surface for heating them up.

• Ensure that the power cable does not come into contact with hot surfaces.

• Do not leave the power cord hanging over the edge of atable or awork bench.

• Unplug the appliance from the power socket by pulling the plug, not the power cable. Otherwise, damage to the power cable or the socket may

occur.

• Make sure that the power cable and plug do not come into contact with water or other fluids.

• To avoid the risk of electric shock, do not repair or modify the appliance yourself. All repairs should be carried out by an authorised service centre.

Tampering with the appliance may result in the loss of your legal rights regarding faulty performance or warranty for quality.

EXPLANATION OF SYMBOLS PLACED ON THE PRODUCT OR INTHE ACCOMPANYING DOCUMENTATION

The product meets all the basic requirements of the applicable EU directives.

This symbol on products or original documents means that used electric or electronic products must not be added to ordinary municipal

waste.

- 4 -

04/2025

2025, .

• Thank you for purchasing our SENCOR product; we hope it will serve

to your satisfaction.

• Prior to using this appliance, please read the user manual thoroughly,

even in cases when you are already familiar with the use of similar

types of appliances. Use the appliance only as described in this

user manual. Keep the manual for future reference. If you pass the

appliance on to another person, ensure that this user manual is

included.

• Carefully unpack the appliance and make sure not to discard any part

of the packaging material until you have found all its components. It

is recommended to keep the original packaging, packing material,

receipt and confirmation of the extent of the seller'sliability or warranty

certificate at least for the duration of the legal right of defective

performance or quality guarantee. When transporting the appliance,

we recommend packaging it again in the original box provided by the

manufacturer.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DESCRIPTION OF THE COFFEE MACHINE

A1 Coffee bean hopper lid

A2 Coffee bean hopper

A3 Coffee grinder – built into

thetop part of the coffee

machine

A4 Grind size adjustment

A5 Control panel

A6 Grinding chamber withground

coffee dispenser

A7 Portafilter holder with switch

A8 Cup warming plate

A9 Water tank lid

A10 Water tank handle

A11 Water tank

A12 Steam / hot water dispenser

control

A13 Brew head

A14 Steam wand

A15 Drip tray grille

A16 Full drip tray indicator

A17 Drip tray

A18 Portafilter

A19 Filters (for 1 and2 cups)

A20 Coffee measuring scoop

withtamper

A21 Dispenser ring

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DESCRIPTION OF THE COFFEE MACHINE

B1 Power button to switch the

coffee machine on/off

B2 Espresso Heating button for

the preparation of hot coffee

drinks

B3 Espresso button (“1” for single

cup; “2” for two cups)

B4 Grind button for grinding

coffee beans

B5 Steam to heating and froth

milk

B6 Cold Espresso button for the

preparation of cold coffee

drinks

B7 Coffee machine heating bar

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

PURPOSE OF USE

• The Sencor SES 5000SS coffee machine is designed forpreparing

coffee beverages (Espresso, Cappuccino or Latte) using freshly

roasted coffee beans. The coffee grinder is designed togrind freshly

roasted coffee beans. The coffee machine'ssteam wand is used

todispense hot water andfroth milk.

• The Sencor SES 5000SS coffee maker can prepare both hot coffee

(after the coffee maker has heated up) and cold coffee (cold brew),

when the coffee maker does not heat up, and the coffee is extracted

in cold water.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

BEFORE FIRST USE

• Before first use, remove the appliance and its accessories from the

packaging and discard all promotional labels and tags. Check that

neither the appliance nor any of its components is damaged.

• Place the coffee machine on aflat, dry and clean surface. Make

sure there is aclear space around the coffee machine, at least

35cm above it and 15 cm on the sides. Wipe the outer surface of the

appliance with aslightly dampened sponge and then wipe dry.

• Remove the water tank from the appliance. Rinse it with clean

water and asmall amount of neutral dishwashing detergent. Then

thoroughly rinse with clean water, dry, and place it back into the coffee

machine.

• Remove the drip tray and grille from themachine. Wash the drip tray,

the portafilter, the coffee measuring scoop and the stainless steel

baskets under clean running water with alittle kitchen detergent. Then

rinse with clean water and dry.

• Wipe the outer surface of the coffee machine and the coffee bean

hopper, including the lid, with adamp sponge, dry, and place them

back into the lower part of the appliance.

• Place the grille onto the drip tray and put it back into the coffee

machine.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SETUP BEFORE USE

Drip tray

• The drip tray with agrille catches drops of brewed coffee when the

portafilter is removed, hot water used to froth milk, and any spilled

milk during frothing. Therefore, make sure that both parts are correctly

installed andinserted into the appliance.

• We recommend emptying the appliance andwashing the drip tray

after each use. When washing, follow the instructions in the "Cleaning

and Maintenance" section.

Note:

The drip tray is equipped with a float to indicate when it is

full. When the liquid level in the drip tray pushes it up, the

drip tray must be emptied.

Filling the water tank

Open the lid of the water tank. Grasp the tank by the handle and lift it

upwards. Fill it with cold potable water up to the maximum mark and

insert it back. Then close the lid of the water tank. The water tank must be

properly seated in place for water to be pumped into the internal system.

Note:

The water you pour into the water tank should ideally be

at room temperature (approximately 25 °C). Too cold water

can negatively affect the final taste of the coffee beverage.

Do not leave the remaining water in the water tank for

more than one day. For brewing quality fresh coffee, it is

necessary to use fresh water. Otherwise, the final taste of

the coffee drink may be adversely affected.

Warning:

The maximum capacity of the water tank is 1.8 l. Do

not overfill it. Never fill the water tank with warm, hot

or sparkling water or liquids such as milk. Do not fill

the water tank when it is inserted in the appliance.

You risk splashing the appliance or overfilling the

water tank.

Adding coffee beans to the hopper

• Remove the hopper lid and pour fresh coffee beans into the hopper.

Put the lid back on.

• The hopper is not suitable forstoring coffee beans for along period

of time. If you do not plan to use the coffee machine for along time,

remove the hopper andpour the unused coffee beans into asuitable

container. Store coffee beans in an airtight container in acool and

dry place.

Espresso Coffee Machine with a Built-in Grinder

User Manual

- 5 -

04/2025

2025, .

Note:

Themaximum capacity of the hopper is 150 g of coffee

beans. Do not overfill it. Never fill the hopper with ground or

instant coffee, caramelised or otherwise specially treated

coffee beans, cocoa beans or other items that may damage

the appliance.

Adjusting the grind size

• The grind size can only be set by turning the grind size dial (A4)

clockwise andanticlockwise.

• Adjust the grind size while the grinder is in operation.

• Turn the dial (A4) towards FINE  to set afiner grind; turn the dial (A4)

towards  COARSE to set acoarser grind.

• For Espresso coffee, we recommend setting the grind size to 5. Adjust

the grind size as needed. Always adjust the size one step at atime and

then refine according to the resulting coffee.

• If the coffee flows out very slowly, it means that the beans are ground

too finely and acoarser grind should be set. If the coffee flows out too

quickly, it means that the beans are ground too coarsely and afiner

grind should be set.

Warning:

If you feel resistance when turning the grind size

dial, you have reached the size limits (1–3 or

18–20). Do not use brute force to rotate the dial any

further. Otherwise, you risk damaging the grind size

adjustment mechanism.

Inserting and removing the filter

• Insert the selected stainless steel filter into the portafilter so that the

protrusion on the filter fits into the hole in the portafilter (Figure C1).

Rotate the filter left or right (Figure C2).

• To remove the filter from theportafilter, rotate the filter in the portafilter

so that the protrusion on the filter is aligned with the hole in the

portafilter. Then remove it from theportafilter.

Warning:

Before removing the filter from theportafilter, make

sure that both the filter and theportafilter have cooled

down. Do not remove the filter from the portafilter

immediately after making coffee. They are very hot

andthere is arisk of injury.

Inserting the portafilter into the holder

Insert the portafilter into the holder so that it is perpendicular to the coffee

machine – see Figure D. The protruding parts at the edge of the portafilter

will fit into the holder and secure it firmly in place.

Grinding coffee

• Coffee can be ground immediately after turning on the coffee

machine; there is no need to wait for it to heat up.

• Press the Grind button to start grinding the coffee. The Grind button

will flash.

• The grinding process takes around 15 seconds. After that, the grinder

stops automatically.

• If you need to adjust the grinding time, follow the instructions inthe

“User Settings / Adjusting the grinding time” section further in

themanual.

• It is possible to install adispenser ring – see picture E, which will

prevent the ground coffee from spilling out of the filter.

Note:

The grinder will run continuously for amaximum of

3 minutes. After 3 minutes of running continuously, the

Grind button will flash quickly and the grinder cannot be

started again for another 6minutes. This is asafety feature

to protect the grinder from damage caused by overheating.

Allow the grinder to cool and then turn it back on.

Note:

If you fill the filter with ascoop of pre-ground coffee, keep

in mind that one levelled scoop is equivalent to roughly 7 g

of ground coffee. For one cup of coffee, fill the filter with one

level measuring scoop of ground coffee. The double cup

filter is filled with twice the amount of coffee.

Tamping the coffee (Figure F)

Spread the coffee inthe filter evenly andtamp it with the flat end of the

scoop. After tamping, the coffee inthe filter should be aligned with the

MAX line marked on the inner wall of the filter.

Clean the edges of the filter thoroughly of any ground coffee residue.

Note:

Use only ground coffee designed for use in Espresso

machines. Do not use ground coffee intended for use in

French presses, drip coffee makers, etc.

Installing and removing the portafilter

• Place the portafilter underneath the brew head so that the handle

points to the left and aligns with the open lock icon on the brew head

– see Figure G1. To attach the portafilter to the brew head, turn the

handle to the right into the closed lock position – see Figure G2.

• To remove the portafilter from the brew head, rotate the handle

counterclockwise until it aligns with the open lock icon. Remove

it from the brew head and move it above arubbish bin. Rotate the

portafilter so that the filter with the used coffee points downwards. Use

acoffee spoon to remove the coffee grounds. Avoid contact with the

surface of the filter or portafilter as they may still be hot. Before taking

the filter out of theportafilter, cool it under cold running water. Then

rinse the filter and the portafilter under clean running water and dry

them thoroughly.

Warming the cups

Once you turn on the coffee machine, the cup warming plate will

automatically heat up. Place empty coffee cups upside down on to

surface and let them warm up.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

USING THE COFFEE MACHINE

• Place the coffee machine on aflat, dry and clean surface at

asufficient distance from the power socket.

• Make sure that the water tank is filled with fresh water and that the

coffee machine is properly assembled.

Warning:

Before switching on the coffee machine, make

sure that the steam/hot water dispenser control is

set to "OFF". If it is not inthis position, the Espresso

andSteam buttons will flash quickly and the coffee

machine cannot be started.

Switching on and preheating the coffee machine

1. Plug the power cable into apower socket. Ashort beep will sound

and the Power button will flash.

2. Place acup or bowl under the brew head.

3. Make sure that the steam/hot water dispenser control (A12) is set to

the "OFF" position.

4. Press the Power button to turn on the coffee machine. You will hear

one short beep.

5. The Espresso Heating andCold Espresso buttons on the control

panel will light up.

6. Asmall amount of cold water will flow out through the brew head.

7. Press the Espresso Heating button and the coffee machine will start

to preheat. The coffee machine heating bar will gradually light up,

indicating that the coffee machine is heating up. Wait until the coffee

machine is preheated.

8. When all buttons, except for Cold Espresso, on the control panel and

the entire heating bar light up, the coffee machine is ready foruse.

9. Remove the cup or bowl from under the brew head and pour out the

water.

Flushing the coffee machine

We recommend following these steps when first using the coffee machine

or if the machine has not been used for an extended period.

1. Fill the water tank to the maximum level.

- 6 -

04/2025

2025, .

2. Insert one of the filters into the portafilter, but do not add any ground

coffee.

3. Insert the portafilter into the brew head.

4. Put abowl under the dispensing nozzle.

5. Make sure that the steam/hot water dispenser control (A12) is set to

the "OFF" position.

6. Plug the power cable into apower socket and switch on the coffee

machine.

7. Wait until the coffee machine is preheated.

8. Press the Espresso button once or twice and the coffee machine will

start. Water will be dispensed through the nozzle.

9. We recommend repeating this process another two times to

thoroughly rinse the coffee machine'sinternal system.

10. Direct the steam wand into the bowl. Immerse the tip of the steam

wand in the water that has flowed into the bowl.

11. Turn the steam/hot water dispenser control (A12) to

. The

coffee machine will start dispensing hot water through the steam

wand.

12. Let the water flow through the jet for about 20 seconds and then

switch the steam/hot water dispenser control (A12) to the “OFF”

position.

13. Then pour the water out of the bowl, remove the portafilter andfilter

andclean them according to the instructions in the "Cleaning

andMaintenance" section. Wipe the steam wand with aclean

sponge and adry cloth.

Warning:

Be careful when flushing the machine as the

discharged water is very hot and can cause scalding.

Warning:

Be careful when removing the portafilter and filter as

they are very hot and can cause burns.

Note:

The sound of the pump can be heard when brewing coffee

or frothing milk. This is normal.

Note:

Only one function of the coffee machine can be used at

atime – i.e. make coffee, froth milk, dispense hot water

or brew cold coffee. It is not possible to use two or more

functions at the same time.

Preparing Espresso

• The coffee machine is supplied with 2 stainless steel filters: asingle

cup filter and adouble cup filter.

• The single cup filter is suitable for making 1 Espresso, regular

Cappuccino or Latte macchiato.

• The double cup filter is suitable for making 2 cups of Espresso,

lungo, one large cup of strong coffee or intense/strong Espresso for

Cappuccino or Latte.

1. Insert the single cup or double cup filter in the portafilter, tamp the

coffee, andinsert the portafilter into the brew head.

2. Make sure the coffee machine is preheated.

3. Place acup/cups or amug/mugs under the portafilter.

4. Press the Espresso button once and the coffee machine will start

brewing 1 cup of coffee.

Press the Espresso button twice in arow. The button will light up red

and the machine will start brewing 2 cups of coffee.

5. When the machine starts, it will first brew the coffee by releasing

asmall amount of hot water into the filter toswell the ground coffee

in thefilter. After amoment, full coffee extraction begins.

6. The coffee machine automatically stops brewing once the preset

amount of coffee has been poured into the cup.

7. Remove the cup or mug with thedrink.

8. Remove the portafilter from the brew head andclean it following

the instructions inthe "Cleaning andMaintenance" section. We

recommend waiting for about 5 seconds before removing the

portafilter from the brew head. This will naturally release the

pressure and make it easier to remove the portafilter.

• You can stop brewing coffee at any time by pressing the Espresso

button.

• If you need to adjust the amount of Espresso coffee dispensed, follow

the instructions inthe “User Settings / Adjusting the amount of

Espresso dispensed” section.

Frothing milk

1. Pour the chilled milk into ajug. We recommend using milk with

ahigher fat content for abetter quality and richer froth.

2. Press the Steam button. This will flash to indicate that the water in

the tank is being heated to steam temperature. When the button

stops flashing andstays lit, the steam function can be used.

3. Immerse the steam wand in the milk.

4. Turn the steam/hot water dispenser control to

. The coffee

machine will start dispensing hot water through the steam wand.

5. Keep the steam wand just below the surface of the milk until it starts

to swirl in the jug.

6. Turn the steam/hot water dispenser control (A12) towards + to

increase the amount of steam dispensed. Turn it back again to

reduce the amount of steam emitted.

7. To create arich froth, bring the jet up close to the surface of the milk

to let in air bubbles. Keep the milk in the jug swirling. Once the foam

is rich enough, dip the jet deeper into the milk to warm it up. You can

judge whether the milk is at the correct temperature by touching the

bottom of the jug. Once the bottom starts to get too hot to keep your

hand on it, the milk is warm enough.

8. Once the milk is sufficiently heated andfrothed, turn the steam/hot

water dispenser control (A12) to the “OFF” position andpress the

Steam button to exit steam mode.

9. Wait until the steam is no longer coming out of the wand. Then

carefully remove the wand from the milk. This will prevent the milk

from splashing.

10. Wipe the end of the steam wand with asoft, slightly damp sponge.

It is important to wipe and clean the steam wand after each use to

prevent deposits and unwanted odours from dried milk residues.

Follow the instructions in the "Cleaning and Maintenance" section.

11. We recommend tapping themilk jug lightly on the worktop or table

to remove any excessively large bubbles and make the milk froth

more compact. Pour the hot andfrothed milk into the cup andenjoy

your coffee.

Tip:

You can also flush the steam wand as follows:

Point the steam wand at the hole inthe drip tray grille or

into acup. Turn the steam/hot water dispenser control

(A12) to the

position and let the hot water flow out

for about 20 seconds. Then turn the steam/hot water

dispenser control (A12) to the “OFF” position andwipe the

steam wand with asoft, slightly damp sponge.

Warning:

The steam gets very hot. Be careful not to scald

yourself.

Note:

The maximum steam dispensing time is 180 seconds.

Dispensing hot water

• Hot water can be used to make tea, instant cocoa, toheat cups, etc.

1. Point the steam wand into acup or mug.

2. Turn the steam/hot water dispenser control (A12) to . The

coffee machine will start dispensing hot water through the steam

wand.

3. Once the desired amount of water has flowed into the cup or mug,

turn the steam/hot water dispenser control (A12) to the "OFF"

position.

- 7 -

04/2025

2025, .

4. Remove the steam wand andwipe it with adry cloth.

The maximum volume of dispensed hot water is 200 ml.

Brewing cold coffee

1. Place the single cup filter in the portafilter, add and tamp down the

coffee and insert the portafilter in the brew head. You can also use

adouble cup filter.

2. Press the Power button to switch on the coffee machine.

3. Place acup/cups or amug/mugs under the portafilter.

4. Press the Cold Espresso button. Then press the Espresso button to

start brewing cold coffee.

5. When the machine starts, it will first release asmall amount of

cold water into the filter toswell the ground coffee in thefilter. After

amoment, full coffee extraction begins.

6. The coffee machine automatically stops brewing once the preset

amount of coffee has been poured into the cup.

7. Remove the cup or mug with thedrink.

8. Remove the portafilter from the brew head andclean it following

the instructions inthe "Cleaning andMaintenance" section. We

recommend waiting for about 5 seconds before removing the

portafilter from the brew head. This will naturally release the

pressure and make it easier to remove the portafilter.

9. Press the Cold Espresso button to end cold brew mode.

You can stop brewing coffee at any time by pressing the Espresso button.

If you need to adjust the amount of cold coffee dispensed, follow the

instructions inthe “User Settings / Adjusting the amount of Espresso

dispensed” section.

Note:

Cold coffee is brewed without heating the water. If you want

to make iced coffee, place ice cubes in acup or mug.

Important:

If you want to prepare acold brew when the coffee

machine is heated, you need to leave the coffee

machine to cool for at least 15 to 25 minutes.

Reheating the Espresso machine

• Every time it finishes brewing coffee / frothing milk, the coffee

machine automatically reheats to operating temperature. During this

time, the buttons on the control panel will flash and the heating bar

will gradually light up. You may hear aclicking sound as it heats. This

is normal.

• This means the coffee machine can also reheat evenbetween

individual uses. This is normal.

• The coffee machine cannot be started when it is heating up, so always

wait for it to finish.

Turning off the coffee machine

• If you are not going to be using the coffee machine, turn the main

power switch to the 0 (off) position. The coffee machine will shut

down. Unplug the power cord from the power socket.

Automatic shut-off

• If you do not use the coffee machine for more than 25 minutes, it will

automatically switch itself off.

Pressing any button will turn it on again andstart it heating up.

Coffee brewing tips

• We recommend using fresh roasted andground coffee beans. Coffee

beans should be ground to the level suitable for Espresso machines.

Grind the coffee beans just before brewing coffee.

• If the ground coffee is too fine, water will not flow through the coffee

even under high pressure. Such finely ground coffee resembles

powder and feels like salt when rubbed between the fingers.

• If the ground coffee is too coarse, water flows through the coffee too

quickly and the full flavour is not extracted. Make sure to use aquality

grinder for consistent grind size.

• Store coffee beans / ground coffee in an air-tight container in acool

anddark place. Store them for amaximum of 4 weeks.

• Do not store coffee beans / ground coffee in thefridge or freezer.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

USER SETTINGS

Adjusting the grinding time

If you need to adjust the preset grinding time, proceed as follows:

1. Hold down the Grind button for about 5 seconds. The grinder will

start.

2. When the grinder has ground the desired amount of coffee into the

filter, press the Grind button briefly. This stops the grinding process

and saves the grinding time.

Note:

The maximum grinding time for one batch of ground coffee

is 20seconds. When the grinder has run for 20 seconds, it

will stop automatically.

Adjusting the amount of Espresso dispensed

Adjusting the volume for 1 cup

If you need to adjust the amount of coffee dispensed for 1 cup, proceed

as follows:

1. Press and hold the Espresso button for about 5 seconds. The

machine will switch to the mode for adjusting the amount of coffee

dispensed. The one cup icon above the button will light up white.

2. Press the Espresso button briefly. The one cup icon above the

button will start flashing and the coffee machine will start brewing

coffee.

3. Once the desired amount of coffee has flowed into the cup, briefly

press the Espresso button. The machine will stop dispensing coffee

and the new amount to be dispensed will be saved.

The amount to be dispensed for 1 cup can be set from 30 ml to 400 ml.

Adjusting the volume for 2 cups

If you need to adjust the amount of coffee dispensed for 2 cups, proceed

as follows:

1. Press and hold the Espresso button for about 10 seconds. The

machine will switch to the mode for adjusting the amount of coffee

dispensed. The two cups icon above the button will light up red.

2. Press the Espresso button briefly. The two cups icon above the

button will start flashing and the coffee machine will start brewing

coffee.

3. Once the desired amount of coffee has flowed into the cup, briefly

press the Espresso button. The machine will stop dispensing coffee

and the new amount to be dispensed will be saved.

4. The amount to be dispensed for 2 cups can be set from 30 ml to

400 ml.

Restoring default factory settings

If you need to restore the machine to thedefault factory settings, press

andhold the Espresso Heating andCold Espresso buttons at the same

time. Abeep will sound to indicate that thedefault factory settings have

been restored.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CLEANING AND MAINTENANCE

• Before cleaning, switch off the coffee machine by pressing the Power

button, unplug the power cord from the mains socket and leave the

appliance to cool down.

• Do not use abrasive cleaning agents, solvents, etc. to clean any parts

of the appliance, as these could damage the surface of the appliance.

Warning:

To prevent the risk of electric shock, do not immerse

the appliance, power cable, or plug into water or any

other liquid.

Cleaning the filter, portafilter and brew head

The filter and portafilter must be thoroughly cleaned after each use.

1. Remove the portafilter with the used coffee from the brew head.

Dispose of the coffee grounds in the compost or in regular municipal

waste. If the coffee grounds are difficult to remove from the filter, use

atable knife or spoon.

2. Remove the filter from the portafilter by rotating the filter in

theportafilter so that the protrusion on the filter is aligned with the

hole in theportafilter. Then remove it from theportafilter.

- 8 -

04/2025

2025, .

Warning:

Take extra care as the coffee grounds, filter and

portafilter are very hot after use. There is arisk of

burns.

3. Rinse the filter and portafilter under warm running water and wipe

them dry with aclean cloth.

4. Wipe the bottom of the brew head (including the seal) with adamp

cloth to remove any ground coffee residues.

5. Insert the portafilter (without the filter) into the brew head.

6. Turn on the coffee machine andlet it heat up. Place acup/bowl

under the portafilter.

7. Press the Espresso button andlet the coffee machine finish brewing.

This will clean the brew head andremove any ground coffee

residues.

8. Remove andrinse the portafilter.

Note:

Place the portafilter and filters on the heating plate so that

they are preheated and ready for the next use.

Caution:

Do not wash the portafilter or filters in thedishwasher.

There is a risk of them being damaged.

Cleaning the drip tray

• The drip tray needs to be emptied and washed after each use of the

appliance.

• First, remove the grille from the tray and then pour out the water.

Wash the tray and grille in warm water with aneutral dishwashing

detergent. Rinse both parts under running water, dry them, and place

them back in their positions.

Cleaning the water tank

• Open the lid of the water tank. Grasp the tank by the handle and lift

it upwards.

• Pour out the remaining water.

• Rinse it with clean water and asmall amount of neutral dishwashing

detergent. Then thoroughly rinse with clean water, dry, and place it

back into the coffee machine.

• Wash the water tank lid in warm water with alittle kitchen detergent.

Rinse and wipe dry.

Cleaning the outer casing

Wipe the outer surface of the appliance with aslightly damp cloth and

dry it.

Cleaning the steam wand

• The steam wand should be cleaned after each use to prevent deposits

and unwanted odours from dried milk residues.

• After each use: Point the steam wand over the grille of the drip tray

andstart the hot water dispenser for afew seconds. This will remove

most of the milk residue in the nozzle. Wipe the steam wand with

aslightly damp cloth.

• Every 2 to 3 months: Unscrew the end of the steam wand. Immerse

it in atub of warm water containing alittle descaling agent. Leave it

overnight. Then pour out the water and clean the end of the steam

wand properly. Ifnecessary, use athin sharp object (such as apin or

aneedle). Rinse under warm running water. Screw back on andtest to

make sure that the steam wand is not blocked.

• Blocked nozzles: If the nozzle in the steam wand becomes blocked

with milk residue, clear it using athin sharp object (such as apin

or aneedle). Then run hot water through the steam wand for about

40seconds.

Cleaning the coffee bean hopper

• Remove the lid and move any beans into an airtight container.

• Wipe the hopper and the lid with asoft sponge slightly moistened in

warm water. Wipe dry with aclean cloth.

Cleaning andemptying the grinder

1. Empty the coffee bean hopper.

2. Insert the portafilter and filter into the holder.

3. Start the grinder by pressing the Grind button. Leave the grinder to

complete the grinding process. Repeat the grinding process until the

grinder is empty.

4. Remove the portafilter fromthe holder.

5. If necessary, use acleaning brush toclean andremove any ground

coffee residue at the ground coffee dispensing outlet.

We recommend emptying the grinder in this way whenever you put fresh

coffee beans into the hopper.

DESCALING

• Over time, minerals from the water can build up inside the

machine’ssystem. This is a natural process. Therefore, regular

descaling is necessary. Mineral deposits can spoil the taste of your

coffee.

• We recommend using descaling agents for coffee machines, which

are commonly available in shops.

• The machine should be descaled when the Espresso Heating, Cold

Espresso, Espresso andSteam buttons flash 5 times in arow, which is

after making approximately 500 cups of coffee. If you do not descale

the coffee machine, the warning will show every time it is switched on.

• Prepare adescaling solution ofwater anddescaling agent following

the dilution/preparation instructions given on the packaging/enclosed

leaflet.

Descaling the internal system

1. Make sure that the power cord plug is disconnected from the mains

socket.

2. Fill the water tank with adescaling solution of water anddescaling

agent following the instructions on the packaging / enclosed leaflet.

3. Insert afilter into the portafilter (without coffee) and insert the

portafilter into the brew head.

4. Place abowl (with acapacity of at least 450—500 ml) under the

portafilter.

5. Insert the plug into the mains socket and switch on the coffee

machine. Let it preheat.

6. When the coffee machine has heated up, point the steam wand into

the bowl andstart the hot water dispenser. Let the hot water run until

it stops automatically. Repeat afew more times. Turn the steam/hot

water dispenser control (A12) to the OFF position.

7. Pour the water out of the bowl andplace the empty bowl under the

portafilter.

8. Press the Espresso button andlet the water flow through the

portafilter. Wait until it stops andthen repeat the process afew more

times until the water tank is empty.

9. Remove the water tank, rinse it out andfill it with clean water. Insert it

back into the coffee machine.

10. Repeat steps 6 to 8 until the water tank is empty.

11. Remove and clean the water tank again. Remove the portafilter

andfilter andclean them following the process described above.

12. To end the descaling process andstart anew countdown, press

andhold the Espresso Heating andCold Espresso buttons for

3seconds.

Note:

If the coffee machine is heavily clogged with mineral

deposits, repeat the descaling process several times in

arow.

Note:

When descaling is complete, clean the water tank,

portafilter andfilter according to the instructions inthis

user'smanual.

Storage

• If you are not going to use the appliance for an extended period of

time, unplug it from the power socket, allow it to cool down and clean

it according to the instructions in the “Cleaning and Maintenance”

section.

• Before storing, ensure that the appliance and all accessories are

thoroughly clean and dry.

• Store the appliance in adry, clean, and well-ventilated place away

from extreme temperatures and out of the reach of children or pets.

- 9 -

04/2025

2025, .

TROUBLESHOOTING

Coffee maker

Problem Cause Solution

The coffee machine does not

switch on.

The power cable plug is incorrectly inserted in the

power socket.

Properly insert the plug into the power socket

The coffee is acidic. The coffee machine was not flushed properly after

descaling.

Flush the coffee machine thoroughly after descaling.

The coffee beans are rotten andrancid. Discard the coffee beans anduse new ones.

There is water under the

coffee machine.

The drip tray is full. Empty the drip tray.

The water tank is not correctly positioned in the

coffee machine.

Remove the tank andreinsert it.

The coffee machine is malfunctioning. Contact an authorised service centre.

After switching it on, the

machine makes aclicking

and jerky sound as it

dispenses the coffee.

This is normal as the machine heats up and

dispenses coffee.

This is not adefect.

The coffee is weak. The single cup filter was used for to brew adouble

coffee.

Use the double cup filter tobrew adouble coffee.

The ground coffee is too coarse. Adjust the grinding level to finer.

The coffee beans are not sufficiently roasted. Only use roasted coffee beans designed for this type of

coffee machine.

There is too little coffee in the filter. Add ground coffee to the filter.

The ground coffee is not tamped down enough. Tamp the ground coffee properly in the filter.

Not enough coffee is dispensed. The recommended amount for 1 cup of Espresso is 40 ml,

and 80 ml for 2 cups.

It is hard to insert the

portafilter into the brew head.

The silicone seal on the brew head is new. This is normal and will improve with use.

The portafilter falls out of the

brew head or leaks.

The portafilter is not properly inserted in the brew

head.

Insert the portafilter in the brew head andtighten.

The portafilter is not tightened properly. Tighten the portafilter until you feel resistance. The portafilter

handle should be perpendicular to the coffee machine.

There is no filter in the portafilter. Place afilter in the portafilter.

The silicone seal on the brew head is worn out or

damaged.

Have the brew head silicone seal replaced.

The coffee flows slowly or

only drips out.

The selected grind size is too fine. Select acoarser grind size.

There is too much ground coffee in the filter. Reduce the amount of ground coffee. After tamping, the

ground coffee should be no higher than the MAX mark.

The ground coffee is tamped too much in the filter. Use less force when tamping.

There are ground coffee residues on the edge of the

portafilter and filter.

Wipe the ground coffee residues offthe edge ofthe

portafilter and filter.

The brew head, its inner edge or the silicone seal

is dirty.

Wipe the brew head, its inner edge and the silicone seal with

aclean andslightly damp sponge.

The silicone seal on the brew head is worn out or

damaged.

Have the brew head silicone seal replaced.

The portafilter is not properly inserted in the brew

head.

Insert the portafilter in the brew head andtighten.

The dispensing holes in the portafilter are dirty

andblocked.

Clean the portafilter dispensing holes.

The holes inthe filter are blocked. Clean the filter.

The coffee is cold. The cup was not preheated. Preheat the cup.

The brew head, portafilter andfilter are cold. Let the brew head, portafilter andfilter warm up.

- 10 -

04/2025

2025, .

Problem Cause Solution

Coffee is not dispensing. The water tank is empty. Refill the water tank.

The ground coffee is too fine. Adjust the grinding level to coarser.

There is too much ground coffee in the filter. Reduce the amount of ground coffee.

The ground coffee is tamped too much in the filter. Apply moderate force when tamping.

The holes inthe filter are blocked. Clean the filter.

The dispensing holes in the portafilter are dirty

andblocked.

Clean the portafilter dispensing holes.

The brew head grille is dirty andblocked. Clean the brew head grille.

There is no or little froth on

the coffee.

The coffee beans are old or too dried out. Use freshly roasted coffee beans.

The ground coffee is too coarse. Adjust the grinding level to finer.

There is too little ground coffee in the filter. Add more ground coffee to the filter.

The ground coffee is inadequately tamped. Tamp the ground coffee properly.

Too much or too little coffee

is dispensed.

You have adjusted the dispensing settings. Adjust the amount of coffee dispensed or perform afactory

reset.

The coffee is bitter.

This may be due to the type androasting time of the

coffee beans.

Use adifferent type of coffee beans.

You have adjusted the coffee temperature setting. Adjust the coffee temperature or perform afactory reset.

You brewed the coffee immediately after using the

steam wand and the coffee has been burned in

thefilter.

After using steam, let the water flow out of the system to

avoid burning the coffee.

The coffee grounds are

too wet.

Asmall amount of water will remain in the grounds

after brewing the coffee.

Take out the portafilter, put it on the grille andlet the water

flow out.

There is too little ground coffee in the filter. Add more ground coffee to the filter.

The ground coffee is unevenly tamped in the filter. It is important to take time to evenly tamp the ground coffee.

The coffee flows unevenly

from theholes in

theportafilter.

The ground coffee is unevenly tamped in the filter. It is important to take time to evenly tamp the ground coffee.

The brew head or portafilter is blocked. Eliminate the cause of the blockage.

The pump makes an

unusual sound.

The water tank is empty. Refill the water tank.

The water tank is not correctly positioned in the

coffee machine.

Remove the tank andreinsert it.

The Espresso andSteam

buttons are flashing quickly.

The steam/hot water dispenser control is not set to

the OFF position.

Turn the steam/hot water dispenser control to the OFF

position.

Frothing milk

Problem Cause Solution

The milk is not frothy

enough.

The coffee machine has not heated up enough to

froth the milk.

Let the coffee machine preheat.

The milk is too warm. Let the milk cool down enough.

You're using skimmed milk. We recommend using whole milk for arich froth.

The steam wand is not sufficiently inserted in

themilk.

Immerse the tip of the steam wand in milk andfollow the

instructions inthe "Frothing milk" section.

The tip of the steam wand is blocked. Clean the steam wand.

The coffee is cold after

pouring in the milk.

The milk wasn't warm enough. Make sure that the milk is warm enough before pouring it in.

No steam comes out of the

steam wand.

The tip of the steam wand is blocked. Clean the steam wand.

The water tank is empty. Refill the water tank.

The coffee machine needs to be descaled. Descale the machine according to the instructions inthe

“Descaling” section.

The steam wand makes

awhistling sound.

The tip of the steam wand is immersed too deep in

themilk.

The tip of the steam wand should be just below the surface

of the milk.

- 11 -

04/2025

2025, .

Problem Cause Solution

When frothing the milk, there

is not much froth.

The milk is not fresh, it is warm or skimmed. Use only cooled whole milk.

You are using an unsuitable jug. Use astainless-steel jug for frothing the milk.

The milk was overcooked. Use only cooled whole milk.

The milk froth consists mainly of large bubbles. Immerse the tip of the steam wand in the milk andfollow the

instructions inthe "Frothing milk" section.

Tap the jug lightly on thetable or worktop to remove the

large bubbles andleave only the milk froth microbubbles.

When frothing, not enough air gets into the milk. The tip of the steam wand should be just below the surface

of the milk.

Coffee grinder

Problem Cause Solution

The coffee flows out too fast. The ground coffee is too coarse. Adjust the grinding level to finer.

The coffee beans are not sufficiently roasted. Only use roasted coffee beans designed for this type of

coffee machine.

There is too little coffee in the filter. Add ground coffee to the filter.

The ground coffee is not tamped down enough. Tamp the ground coffee properly in the filter.

The Grind button does not

light up after switching on the

coffee machine.

The coffee machine is not connected to the mains. Plug the power cord into the mains socket.

The grinder does not

dispense ground coffee.

The ground coffee dispenser outlet is blocked. Clean the grinder dispenser outlet.

The ground coffee is too

coarse evenwhen afine

grind size is set.

The grind size adjustment mechanism is damaged. Contact an authorised service centre.

If the problem is not listed in the table or if the problem persists, turn off

the coffee machine, disconnect it from the power source, and contact an

authorised service centre.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TECHNICAL SPECIFICATIONS

Rated voltage range ..............................................................................220–240 V~

Rated frequency ..........................................................................................50–60 Hz

Rated input power ..............................................................................................1350W

Power consumption in off mode .................................................................. 0.27 W

Noise level .........................................................................................................75 dB(A)

The declared noise emission level of the appliance is 75 dB(A), which

represents alevel Aof acoustic power with respect to areference acoustic

power of 1 pW.

The appliance automatically switches off in less than 25 minutes after

finishing the operation and when connected to the mains power.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

INSTRUCTIONS AND INFORMATION ON DISPOSAL OF USED

PACKAGING MATERIAL

Dispose of used packaging material at the location designated by the

municipality for waste disposal.

DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT

Used electrical andelectronic products must not be added to ordinary

municipal waste. For proper disposal and recycling of these products,

deliver them to designated collection points. Alternatively, in some

European Union states or other European countries the products can be

returned to the local retailer when buying an equivalent new product. By

properly disposing of this product, you help preserve valuable natural

resources and contribute to preventing potential negative impacts on the

environment and human health resulting from improper waste disposal.

For more details, contact your local authority or nearest collection point.

Fines may be imposed for improper disposal of this type of waste as per

national regulations.

For business entities in European Union States

To dispose of electric or electronic equipment, request the necessary

information from your retailer or supplier.

Disposal in other countries outside the European Union

To dispose of this product elsewhere, request the necessary information

on the correct disposal method from local authorities or your retailer.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Changes to text and technical parameters are reserved.

- 12 -

04/2025

2025, .

FAST ČR, a.s.

U Sanitasu 1621

CZ-251 01 Říčany

www.sencor.com

info@sencor.cz

Sencor SES 5000SS Espresso Coffee Machine

Product's Documents

User Manual

Specifications

Sencor SES 5000SS Questions and Answers
