REVISED BULLETIN
SERVICE PARTS LIST
MILWAUKEE ELECTRIC TOOL CORPORATION
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 1
BULLETIN NO.
STARTING
SERIAL NO.
WIRING INSTRUCTION
DATE
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
CATALOG NO.
54-06-2395
M18™ ROVER™ MOUNTING FLOOD LIGHT
2365-20
J43A
Jun. 2017
0
00
EXAMPLE:
Component Parts (Small #)
Are Included When Ordering
The Assembly (Large #).
1
2
3
4
3
4
MILWAUKEE TOOL
l
www.milwaukeetool.com
13135 W. Lisbon Road, Brookeld, Wisc. 53005
Drwg. 1
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 05-88-0013 M2.5 x 8 Pan Hd. Machine Screw (4)
2 44-06-0011 Lens Assembly (1)
3 --------------- Lens Cover (1)
4 --------------- Lens (1)
5 12-20-2335 Service Nameplate (Not Shown) (1)
FIG. NOTES
5 A clean, dry surface is essential for proper performance for any
adhesive system. The area intended for application of any
adhesive label or nameplate must be prepared by cleaning with
isopropyl alcohol. The solvent is to be applied with a clean, lint
free applicator and the surface allowed to dry before applying the
label or nameplate.
