REVISED BULLETIN
SERVICE PARTS LIST
BULLETIN NO.
STARTING
SERIAL NO.
WIRING INSTRUCTION
DATE
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
CATALOG NO.
MILWAUKEE TOOL
l
www.milwaukeetool.com
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 2
54-06-2215
USB RECHARGEABLE FOLDING FLOOD LIGHT
2114-21
J84A
May 2020
0
00
EXAMPLE:
Component Parts (Small #)
Are Included When Ordering
The Assembly (Large #).
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 31-21-0058 Battery Cover (1)
2 31-15-0575 USB Cover (1)
3 12-20-2114 Service Nameplate (Not Shown) (1)
1
2
FIG. NOTES
3 A clean, dry surface is essential for proper
performance for any adhesive system. The area
intended for application of any adhesive label or
nameplate must be prepared by cleaning with
isopropyl alcohol. The solvent is to be applied with a
clean, lint free applicator and the surface allowed to
dry before applying the label or nameplate.
