FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 42-70-0058 Housing Clip (1)
2 31-15-2126 USB-C Port Cover (1)
3 31-15-2127 Heated Garment Port Cover (1)
4 44-66-1211 USB-C Wall Plug (Optional) (1)
5 42-44-1211 2-ft. USB-C to USB-C Cable (Optional) (1)
6 12-20-0904 Service Nameplate (Not Shown) (1)
7 10-22-0301 Warning Label (Not Shown) (1)
0
00
EXAMPLE:
Component Parts (Small #)
Are Included When Ordering
The Assembly (Large #).
1
54
32
FIG. NOTES
6,7 A clean, dry surface is essential for proper
performance for any adhesive system. The area
intended for application of any adhesive label or
nameplate must be prepared by cleaning with
isopropyl alcohol. The solvent is to be applied with a
clean, lint free applicator and the surface allowed to
dry before applying the label or nameplate.
BULLETIN NO.
54-04-1215
SERVICE PARTS LIST
CATALOG NO. 48-59-1211
REVISED BULLETIN
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
M12™ TOP-OFF™ Power Supply and Charger
SERIAL NO.
DATE
June 2024
