EXAMPLE:
Component Parts (Small #) Are Included
When Ordering The Assembly (Large #).
0
00
REVISED BULLETIN DATE
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
SERVICE PARTS LIST
WIRING INSTRUCTION
54-04-0005
June 2020
BULLETIN NO.
L74A
STARTING
SERIAL NO.
2846-20
CATALOG NO.
M18™ Top O 175W Power Supply
MILWAUKEE TOOL
l
www.milwaukeetool.com
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 1
FIG. NOTES
2,5 A clean, dry surface is essential for proper performance
for any adhesive system. The area intended for application
of any adhesive label or nameplate must be prepared by
cleaning with isopropyl alcohol. The solvent is to be applied
with a clean, lint free applicator and the surface allowed to
dry before applying the label or nameplate.
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 31-15-0126 USB Cover (1)
2 10-20-5693 Warning Label (1)
3 --------------- M3 x 18mm Flat Hd. T-20 Screw (2)
4 14-36-0015 Hanging Hook Assembly (1)
5 12-20-0522 Service Nameplate (1)
1
2
3
(2x)
5
4
3
