H5
Before using the product, please read this user guide carefully, and follow the
instructions strictly. If you have any questions, please feel free to send an email to
our support team, we will try our best to solve the problems as soon as possible.
After reading, please keep it properly for future reference.
User Guide
Important safety instructions
To avoid safety accidents or machine failure, basic safety precautions should
always be followed when using your Brigii handheld vacuum cleaner, including
the following:
1.Do not allow to be used as a toy. Pay more attention when children use or
approach it. Please look after the children and make sure they will not use this
product as a toy. Children are prohibited from using, cleaning and maintaining the
machine without monitoring.
2.This appliance is not intended for use by infirm persons with reduced physical,
sensory or reasoning capabilities, or lack of experience and knowledge (including
young children), unless they have been given supervision or instruction by a
responsible person concerning use of the appliance to ensure that they can use it
safely.
3.Keep hair, loose clothing, fingers, and all parts of the body away from air inlet,
brush bar or moving parts. Do not point the hose, wand or tools at your eyes or ears
or put them in your mouth.
4.Do not put the objects in the machine air intake. Never use the machine when the
air intake is clogged; remove dust, cotton, hair, or other items that may reduce
airflow.
5.The filter should be cleaned at least once per month and should be cleaned up in
time when there is visible dust on the filter.
6.Turn off the vacuum cleaner before removing or installing the filter and other
components. Do not turn on the machine during charging.
7.Before use, please check whether the filter was installed correctly or damaged.
The machine must be working with installed properly filters. And the filters must be
kept dry after daily cleaning ensure so that the machine can operate.
8.Avoid raining or close to high temperature objects. Keep away from damp and
direct sunlight.
9.Do not wash or immerse the product in water or other liquid. Never handle the
product especially the charging port with wet hands.
10.Check the cleaning area before using machine, do not use to pick up the objects
larger than the suction pipe so as not to cloggy of the air inlet. Do not pick up
anything that is sharp, burning or smoking, such as glass, nails, cigarettes, matches,
hot ashes. Do not use to pick up any liquid or large number of powders (lime, flour,
etc.)
11.Besides professionals, the others do not open it for repairing or modifying internal
wiring.
12.This appliance includes a rechargeable lithium-ion battery pack. Do not expose
the battery pack or appliance to fire or excessive temperature (above
130°C(266°F)), as it may catch fire and explode.
13.Do not use a damaged or modified battery pack, as it may catch fire and explode.
14.Usage and storage of the appliance should be within the ambient temperature
range of 0-40°C(32°F-104°F). The vacuum cleaner cannot be charged when the
ambient temperature is above 40°C(104°F).
15.The charging speed may become slower in environments with temperatures
below 10°C(50°F), which is a common phenomenon. Do not leave battery in charger
over 24 hours.
16.Follow all the charging instructions and do not charge the battery pack out of the
Product specifications
temperature range specified in the instructions, otherwise, it may damage the
battery and increase the risk of fire.
17.Do not attempt to disassemble the battery pack.
18.Leaks from battery cells can occur under extreme conditions. If any liquid gets on
the skin, wash quickly with soap and water. If any liquid gets into the eyes, do not
rub eyes, immediately flush them with clean water continuously for a minimum of 15
minutes. Seek medical attention immediately.
This symbol on the device or its packaging indicates:
Do not dispose of electrical appliances as unsorted municipal waste;
use separate collection facilities. Contact your local authority for
information regarding the collection systems available. If electrical
appliances are disposed of in landfills or dumps, hazardous substances can
leak into the groundwater and get into the food chain, damaging your
health and well-being.
Product Name Handheld Vacuum Cleaner
Model H5 Product Net Weight About 700g
Rated Input Power
Med mode 60W,
Turbo mode140W
Battery Capacity 2500mAh*4 Product Dimensions 330mm*83mm*83mm
5V 2A
Troubleshooting
Suction decreased
The filter is clogged causing
the suction power to drop
No power
E5
No press on power Long press 2s
Out of power Charging
Battery problem
Conditions Reasons Solutions
Low power Charging
Air inlet or filter be clogged Clean the air inlet and the filter
Clean the filter on time
according to the instructions
or change the filter on time
Please make sure that the
ambient temperature at the
range of
-7.5°C-50°C(-45.5°F-122°F))
Please scan the QR code to
contact Brigii customer support
team
E6
Stop charging for 15min and
charge it when the device cools
down
Abnormal Noise
when using
Turn off the power ,took out of
objects, installing filter correctly
Incorrect filters installed and
foreign objects sucked
The device overheating or high
temperature of surroundings
Surrounding temperature
below-7.5°C(-45.5°F)
Filter clogged
E6
E7
Turn off the machine and make
sure the filter is installed
correctly
Please use,store and charge at
the ambient temperature of
0°-40°(32°F-104°F)
Clean the dust cup and filter,
then install it after drying
thoroughly
The device will inhale foreign
matter if the machine doesn't
install the filter, which will trigger
motor protection
The machine or ambient
temperature is too low
Please use,store and charge at
the ambient temperature of
0°-40°(32°F-104°F)
The machine or ambient
temperature is too low
E8
Turn off the machine for 15min
and wait until it cools down to
charge it
The device overheating or high
temperature of surroundings
www.brigii.com
