SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER).
OWNER’S MANUAL AND SAFETY INSTRUCTIONS
ITEM: 95516
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: (909) 628 0880 MON-FRI 9AM TO 3PM PST
HIGH PRESSURE PROPANE STOVE BURNER
1
IMPORTANT SAFETY INFORMATION
GENERAL SAFETY WARNINGS
Read these instructions for use carefully. Familiarise yourself with the appliance before connecting it to a gas
cylinder. Keep these instructions for future reference. This instruction manual contains important information
necessary for the proper assembly and safe use of the appliance. Follow all warnings and instructions when
using the appliance. If you have questions about assembly, operation, servicing or repair of this product,
please call Customer Service at 909.628.0880.
This appliance can produce carbon monoxide which has no odor.
CARBON MONOXIDE HAZARD
USE EXTREME CAUTION: Using it in an enclosed space can kill you.
NEVER use this appliance in an enclosed space such as a camper,tent, car or home.
EXPLOSION FIRE HAZARD
Never store propane near high heat, open ames, pilot lights, direct sunlight, other ignition sources or
where temperatures exceed 120degrees F (49°C).
Propane is heavier than air and can accumulate in low places. If you smell gas, leave the area immediately.
NEVER install or remove propane tank while outdoor stove is lighted, near ame, pilot lights, other ignition
sources or while outdoor stove is hot to touch.
During operation, this product can be a source of ignition. Never use the stove in spaces that contain or
may contain volatile or airborne combustibles, or products such as gasoline, solvents, paint thinner, dust
particles or unknown chemicals. Minimum clearances from combustible materials: 12 inches from the
sides & 48 inches from the top.
Provide adequate clearances around air openings into the combustion chamber.
This stove is a combustion appliance. All combustion appliances produce carbon monoxide (CO) during
the combustion process. This product is designed to produce extremely minute, non-hazardous amounts
of CO if used and maintained in accordance with all warnings and instructions. DO NOT block air ow into
or out of the stove.
Carbon Monoxide (CO) poisoning produces u-like symptoms, watery eyes, headaches, dizziness, fatigue
and possibly death. You can’t see it and you can’t smell it. It’s an invisible killer. If these symptoms are
present during operation of this product get fresh air immediately.
For outdoor use only.
NEVER use inside house, camper, tent, vehicle or other unventilated or enclosed areas. This stove
consumes air (oxygen). DO NOT use in unventilated or enclosed areas to avoid endangering your life.
2
IMPORTANT SAFETY INFORMATION
SAVE THESE WARNINGS
This product is fueled by propane gas. Propane gas is invisible, odorless,and ammable. An odorant is
normally added to help detect leaks and can be described as a “rotten egg” smell. The odorant can fade
over time so leaking gas is not always detectable by smell alone.
Propane gas is heavier than air and leaking propane will sink to the lowest level possible. It can ignite by
ignition sources including matches, lighters,sparks or open ames of any kind many feet away from the
original leak. Use only propane gas set up for vapor withdrawal.
Propane gas should be stored or used in compliance with local ordinances and codes or with ANSI/NFPA
58. Turn off propane when not in use.
CALIFORNIA PROPOSITION 65:WARNING: This fuel, and by products of combustion of this fuel,contain
chemicals known to the state of California to cause cancer,birth defects, or other reproductive harm.
Keep all connections and ttings clean. Inspect propane cylinder and stove propane connections for
damage before attaching.
During set up, check all connections and ttings for leaks using soapy water. Never use a ame. Bubbles
indicate a leak. Check that the connection is not cross-threaded and that it is tight. Perform another leak
check. If there is still a leak, remove the cylinder and contact Stark Tools for service or repairs.
Use as a cooking appliance only. NEVER alter in any way or use with any device or part not specically
designed and sold for this product.
Clean stove frequently to avoid grease accumulation and possible grease res.
NEVER leave stove unattended when hot or in use.
Keep out of reach of children.
Propane stoves and appliances are for outdoor use only. They should be placed on a at, level surface
that is sturdy and never near a wall or other obstruction.
Never store propane near high heat, open ames, pilot lights, direct sunlight, other ignition sources.
Minimum clearances from combustible materials: 12 inches from the sides and 48 inches from the top.
When cooking with oils, re’s can happen easily. Use extreme caution when using this stove and never
leave it unattended while in use.
Be sure to provide adequate clearances around air openings into the combustion chamber.
WARNING: Not for home or recreational vehicle use. We cannot foresee every use which may be made
of our products. Check with your local re safety authority if you have questions about use. Other standards
govern the use of fuel gases and heat producing products for specic uses. Your local authorities can advise
you about these.
• Never rell disposable cylinders.
• Use the preset regulator that came with the stove. Do not attempt to adjust.
During stove set-up, check all ttings for leaks using soapy water. Never use a ame.
IMPORTANT SAFETY INFORMATION
When cooking with oil or grease, the thermometer provided MUST be used. Follow instructions in this
manual for proper installation and use of thermometer. Follow instructions to make sure thermometer is
working properly.
NEVER let the oil or grease temperature get hotter than 350°F (177°C). If the temperature goes above
400°F (200°C) or if oil begins to smoke, IMMEDIATELY turn burner OFF. Wait for the temperature to
decrease to less than 350°F (177°C) before relighting burner. If there is a lid or cover, do not remove.
After reaching 450°F (230°C), oil or grease temperature can rapidly increase to its point of spontaneous
combustion or a serious grease re. Therefore, never leave cooker unattended, always monitor the
thermometer.
When cooking with oil or grease have a type BC or ABC re extinguisher readily available. In the event
of an oil or grease re DO NOT attempt to extinguish with water. Turn off the gas at the supply cylinder.
Immediately call the re department. A Type BC or ABC re extinguisher may, in some circumstances
contain the re.
NEVER overll the cooking pot with oil, grease or water. Follow instructions in this manual for establishing
proper oil, grease or water levels.
Failure to completely thaw and dry food may cause oil or grease to overow. When frying with oil or
grease, all foods products MUST be completely thawed and towel dried to remove excess water. Follow
instructions in this manual for frying foods.
In the event of rain, snow, hail,sleet or other forms of precipitation while cooking with oil or grease, cover
the cooking vessel immediately and turn off burner(s) and gas supply. DO NOT attempt to move the
appliance or the cooking vessel.
DO NOT place an empty cooking vessel on the appliance while in operation. The intense heat will melt
an empty pot. Use caution when placing anything on the cooking vessel.
NEVER use a cooking vessel larger than the capacity and diameter recommended by the manufacturer.
In sunlight or other bright light, the ame may be almost invisible. Use extreme caution keeping hands,
hair and clothing away from the cooker. Never put face or hands over burner while lighting. Make sure to
turn cooker off when not in use. Always wear cooking mitts when handling the cooker, cookware, cooking
utensils and accessories.
NEVER ll the Cylinder beyond 80% full. All LP Cylinders in excess of 2.2 lbs(1.0 Kg.) propane capacity,
must include a collar to protect the cylinder valve.
The valve on the propane tank is the “ON/OFF” valve. When nished cooking, or in case of an emergency,
turn the tank valve clockwise to the “OFF” position. Be sure to close the tank valve before disconnecting
the hose. Caution - The valve on the hose and regulator assembly controls the ame intensity only. It is
not an “ON/OFF” valve.
ALWAYS check for gas leaks before lighting.
Follow lighting procedures as stated in this manual. Use a replace match or gas appliance butane lighter.
This appliance will be hot during and after use. Use insulated oven mitts or gloves for protection from hot
surfaces or splatter from hot cooking liquids. Always wear shoes while cooking.
Use Barton appliances only in accordance with state and local ordinances and codes. In the absence of
local codes, installation must conform with the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Storage
and Handling of Liqueed Petroleum Gases, ANSI/NFPA 58 or CSA B149.1, Natural Gas and Propane
Installation Code.
3
PARTS and ATTRIBUTES
BURNER
TOP RACK
REGULATOR
CONNECTOR
HOLDERS
BOTTOM RACK
CSA certied regulator, hose and connector included
Detachable holders for easy storage
4
37,000 BTU
Heavy duty burner with weatherproof coating frame
OPERATION
1. The hose and regulator is a pre-assembled unit. DO NOT take apart. Simply
connect the hose and regulator assembly to the LP gas cylinder and to the cooker.
2. Make sure the valve on the LP cylinder is clean. Connect the hose to the
cylinder valve by turning the hand wheel to the right. Hand tighten.
CAUTION: The control valve controls the “volume” of gas only. Use the valve on
the propane tank to turn the gas supply on or off.
3. Connect the valve to the propane cylinder. Use the regulator valve to increase or decrease the amount
of gas needed. Closing the regulator valve on the hose will shut off the ow of gas to the burner.
NOTE: Using a small brush or spray bottle, splash on a soapy liquid (ex. Dish
washing liquid and water, or 50% non-ammonia soap and 50% water) on the
connections around the regulator and cylinder connection. Any bubbles that
appear indicate a gas leak. If so, turn off the gas and tighten the ttings some
more.
DO NOT use the cooker if a gas leak is detected and cannot be stopped.
4. After you are certain there are no leaks, turn tank valve and regulator valve to
“OFF” position. Wait 5 minutes for any gas fumes to go away before lighting the
burner.
5. When you are sure there are no leaks, turn cylinder valve and regulator control
valve on hose to the closed position.
6. Reopen cylinder valve fully.
7. Have a standard match, replace match or long-nosed propane lighter
lit and ready to place over the burner.
8. Before lighting, Turn air control shutter on the burner to an almost
closed position. After lighting, turn air control shutter to open position to
achieve a better ame.
5
9. Light the burner from the bottom, keeping hands and face away from
the top of the cooker.
10. Place lighter over the burner, then slowly open regulator valve until
burner ignites.
11. Adjust air shutter on burner for a blue ame. (In direct sunlight, ame
may appear clear.)
12. Adjust the regulator control valve for desired ame height.
13. When lighting for the rst time, you will smell paint burning at the top for a few minutes. This is normal.
14. When nished using the cooker, turn off gas from the cylinder valve rst. It will take a few seconds for
the re to go out and for the propane gas to “bleed” from the hose and regulator assembly. After the re is
completely out, turn regulator control valve to the “OFF” position.
15. If ame is accidentally extinguished, turn propane tank off. Wait 30 seconds, then repeat these steps.
OPERATION
DISCLAIMER
6
Intense heat from the cooker will burn away paint from parts of the frame and windscreen ashing. This will
cause a slight ‘odor’ for a few minutes during the initial use. The exposed steel will rust. Occasional care
must be taken to prolong the life of your cooker.
1. Store cooker in a cool dry place. DO NOT store outside exposed to weather. Storage of an appliance
indoors is permissible only if the cylinder is disconnected. If storing cooker indoors, detach and leave LP
cylinder outdoors. LP cylinders must NOT be stored in a building, garage or any other enclosed area.
2. For long term storage, cover the cast iron burner and the hose and regulator assembly in a plastic bag.
3.
Spiders and small insects have been known to spin webs inside the tube of the cast iron burner.
Obstructions in the tube interfere with the ow of air and gas through the burner. A clogged tube may result
in a re beneath the appliance. If this happens, remove the cast burner from the frame and clean the tube
with a stiff, bent wire or screwdriver. We also advise cleaning inside the top ports as well.
4.
DO NOT t a m p e r w i t h o r a t t e m p t r e p a i r s o n t h e b u r n e r s , f r a m e s , v a l v e s , o r L P c y l i n d e r s .
5. Always close LP cylinder valve rst after use. Always use and store LP cylinder in an upright position.
Store out of the reach of children. Never store or transport LP cylinders in occupied enclosures. If storing
cooker indoors, detach and leave LP cylinder outdoors.
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE
UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL
PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
PLEASE READ THE FOLLOWING CAREFULLY
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only and are not available individually
as replacement parts.
PRODUCT MADE IN CHINA
