ORIGINAL INSTRUCTIONS
PRODUCT SAFETY
GENERAL POWER TOOL SAFE-
TY WARNINGS
WARNING: Read all safety
warnings, instructions,
illustrations and
specifications provided with
this power tool.
Failure to
follow all instructions listed
below may result in electric
shock, fire and/or serious injury.
Save all warnings and
instructions for future
reference.
The term “power tool” in the
warnings refers to your mains-
operated (corded) power tool
or battery-operated (cordless)
power tool.
1. WORK AREA SAFETY
a)Keep work area clean and
well lit.
Cluttered or dark
areas invite accidents.
b)Do not operate power tools
in explosive atmospheres,
such as in the presence of
flammable liquids, gases
or dust.
Power tools create
sparks which may ignite the
dust or fumes.
c)Keep children and
bystanders away while
operating a power tool.
10
Distractions can cause you to
lose control.
2) ELECTRICAL SAFETY
a)Power tool plugs must
match the outlet. Never
modify the plug in any
way. Do not use any
adapter plugs with earthed
(grounded) power tools.
Unmodified plugs and
matching outlets will reduce
risk of electric shock.
b)Avoid body contact with
earthed or grounded
surfaces, such as pipes,
radiators, ranges and
refrigerators.
There is an
increased risk of electric
shock if your body is earthed
or grounded.
c)Do not expose power tools
to rain or wet conditions.
Water entering a power tool
will increase the risk of electric
shock.
d)Do not abuse the cord.
Never use the cord for
carrying, pulling or
unplugging the power tool.
Keep cord away from heat,
oil, sharp edges or moving
parts.
Damaged or entangled
cords increase the risk of
electric shock.
e)When operating a power
11
tool outdoors, use an
extension cord suitable
for outdoor use.
Use of a
cord suitable for outdoor use
reduces the risk of electric
shock.
f) If operating a power tool
in a damp location is
unavoidable, use a residual
current device (RCD)
protected supply.
Use of
an RCD reduces the risk of
electric shock.
3) PERSONAL SAFETY
a)Stay alert, watch what
you are doing and use
common sense when
operating a power tool. Do
not use a power tool while
you are tired or under the
influence of drugs, alcohol
or medication.
A moment of
inattention while operating
power tools may result in
serious personal injury.
b)Use personal protective
equipment. Always wear
eye protection.
Protective
equipment such as dust mask,
non-skid safety shoes, hard
hat, or hearing protection
used for appropriate
conditions will reduce
personal injuries.
c)Prevent unintentional
12
starting. Ensure the switch
is in the off-position
before connecting to
power source and/or
battery pack, picking up or
carrying the tool.
Carrying
power tools with your finger
on the switch or energising
power tools that have the
switch on invites accidents.
d)Remove any adjusting key
or wrench before turning
the power tool on.
A wrench
or a key left attached to a
rotating part of the power tool
may result in personal injury.
e)Do not overreach. Keep
proper footing and balance
at all times.
This enables
better control of the power
tool in unexpected situations.
f) Dress properly. Do not
wear loose clothing or
jewellery. Keep your hair
and clothing away from
moving parts.
Loose clothes,
jewellery or long hair can be
caught in moving parts.
g)If devices are provided
for the connection of dust
extraction and collection
facilities, ensure these are
connected and properly
used.
Use of dust collection
can reduce dust-related
hazards.
13
h)Do not let familiarity
gained from frequent
use of tools allow you
to become complacent
and ignore tool safety
principles.
A careless action
can cause severe injury within
a fraction of a second.
4) POWER TOOL USE AND
CARE
a)Do not force the power
tool. Use the correct power
tool for your application.
The correct power tool will do
the job better and safer at the
rate for which it was designed.
b)Do not use the power tool
if the switch does not turn
it on and off.
Any power tool
that cannot be controlled with
the switch is dangerous and
must be repaired.
c)Disconnect the plug from
the power source and/or
remove the battery pack,
if detachable, from the
power tool before making
any adjustments, changing
accessories, or storing
power tools.
Such preventive
safety measures reduce the
risk of starting the power tool
accidentally.
d)Store idle power tools out
of the reach of children
14
and do not allow persons
unfamiliar with the power
tool or these instructions
to operate the power tool.
Power tools are dangerous in
the hands of untrained users.
e)Maintain power tools and
accessories. Check for
misalignment or binding
of moving parts, breakage
of parts and any other
condition that may affect
the power tool’s operation.
If damaged, have the power
tool repaired before use.
Many accidents are caused
by poorly maintained power
tools
.
f) Keep cutting tools sharp
and clean.
Properly
maintained cutting tools with
sharp cutting edges are less
likely to bind and are easier to
control.
g)Use the power tool,
accessories and tool bits
etc. in accordance with
these instructions, taking
into account the working
conditions and the work
to be performed.
Use of
the power tool for operations
different from those intended
could result in a hazardous
situation.
h)Keep handles and grasping
15
surfaces dry, clean and
free from oil and grease.
Slippery handles and grasping
surfaces do not allow for safe
handling and control of the
tool in unexpected situations.
5) BATTERY TOOL USE AND
CARE
a)Recharge only with the
charger specified by the
manufacturer.
A charger
that is suitable for one type of
battery pack may create a risk
of fire when used with another
battery pack.
b)Use power tools only with
specifically designated
battery packs.
Use of any
other battery packs may
create a risk of injury and fire.
c)When battery pack is not
in use, keep it away from
other metal objects, like
paper clips, coins, keys,
nails, screws or other small
metal objects, that can
make a connection from
one terminal to another.
Shorting the battery terminals
together may cause burns or
a fire.
d)Under abusive conditions,
liquid may be ejected from
the battery; avoid contact.
If contact accidentally
16
occurs, flush with water.
If liquid contacts eyes,
additionally seek medical
help. Liquid ejected from the
battery may cause irritation or
burns.
e)Do not use a battery pack
or tool that is damaged
or modified.
Damaged or
modified batteries may exhibit
unpredictable behaviour
resulting in fire, explosion or
risk of injury.
f) Do not expose a battery
pack or tool to fire or
excessive temperature.
Exposure to fire or
temperature above 130 °C may
cause explosion.
g)Follow all charging
instructions and do
not charge the battery
pack or tool outside
the temperature
range specified in the
instructions.
Charging
improperly or at temperatures
outside the specified range
may damage the battery and
increase the risk of fire.
6) SERVICE
a)Have your power tool
serviced by a qualified
repair person using only
identical replacement
17
parts.
This will ensure that
the safety of the power tool is
maintained.
b)Never service damaged
battery packs.
Service
of battery packs should
only be performed by the
manufacturer or authorized
service providers.
SCREW DRIVER SAFETY
WARNING
1. Hold power tool by
insulated gripping
surfaces, when performing
an operation where the
fastener may contact
hidden wiring. Fasteners
contacting a “live” wire may
make exposed metal parts
of the power tool “live” and
could give the operator an
electric shock.
DRILL SAFETY WARNINGS
1) Safety instructions for all
operations
a) Hold the power tool
by insulated gripping
surfaces, when performing
an operation where the
cutting accessory or
fasteners may contact
hidden wiring. Cutting
accessory or fasteners
18
contacting a “live” wire may
make exposed metal parts
of the power tool “live” and
could give the operator an
electric shock.
2) Safety instructions when
using long drill bits
a) Never operate at higher
speed than the maximum
speed rating of the drill
bit. At higher speeds, the
bit is likely to bend if allowed
to rotate freely without
contacting the workpiece,
resulting in personal injury.
b) Always start drilling at
low speed and with the
bit tip in contact with
the workpiece. At higher
speeds, the bit is likely to
bend if allowed to rotate
freely without contacting
the workpiece, resulting in
personal injury.
c) Apply pressure only in
direct line with the bit and
do not apply excessive
pressure. Bits can bend
causing breakage or loss of
control, resulting in personal
injury.
SAFETY WARNINGS FOR BAT-
TERY CELLS INSIDE THE TOOL
a) Do not dismantle, open or
shred cells.
19
b) Do not short-circuit
charging terminal. Do
not store power tool
haphazardly in a box or
drawer where charging
terminal may short-circuit
each other or be short-
circuited by conductive
materials. When power tool
is not in use, keep it away
from other metal objects,
like paper clips, coins, keys,
nails, screws or other small
metal objects, that can
make a connection from one
charging terminal to another.
c) Do not expose power
tool to heat or fire. Avoid
storage in direct sunlight.
d) Do not subject power tool
to mechanical shock.
e) In the event of battery
leaking, do not allow the
liquid to come into contact
with the skin or eyes. If
contact has been made,
wash the affected area
with copious amounts of
water and seek medical
advice.
f) Keep power tool clean and
dry.
g) Wipe the charging
terminals with a clean dry
cloth if they become dirty.
h) Power tool needs to be
20
charged before use.
Always refer to this
instruction and use
the correct charging
procedure.
i) Do not maintain power tool
on charge when not in use.
j) After extended periods
of storage, it may be
necessary to charge and
discharge the power tool
several times to obtain
maximum performance.
k) Recharge only with the
charger specified by Worx.
Do not use any charger
other than that specifically
provided for use with the
equipment. A charger that
is suitable for one type of
battery may create a risk of
fire when used with another
battery.
l) Keep power tool out of the
reach of children.
m)Retain the original
product literature for
future reference.
n) Dispose of properly.
o) Do not mix cells of
different manufacture,
capacity, size or type
within a device.
p) Do not use any cell which is
not designed for use with
the equipment.
21
q)Keep the battery away
from microwaves and high
pressure.
GENERAL SAFETY WARNINGS
FOR YOUR BATTERY CHARGER
WARNING Read all safety
warnings and all
instructions. Failure to follow
the warnings and instructions
may result in electric shock, fire
and/or serious injury.
Save all warnings and
instructions for future
reference.
This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved. Children
shall not play with the appliance.
Cleaning and user maintenance
shall not be made by children
without supervision.
If the supply cord is damaged,
it must be replaced by the
manufacturer, its service agent
or similarly qualified persons in
order to avoid a hazard.
22
ADDITIONAL SAFETY
INSTRUCTIONS FOR YOUR
BATTERY CHARGER
1. Before charging, read the
instructions.
2. Do not charge a leaking
battery.
3. Do not use chargers for works
other than those for which
they are designed.
4. Before charging, ensure your
charger is matching the local
AC supply.
5. For indoor use, or do not
expose to rain.
6. The charging device must be
protected from moisture.
7. Do not use the charging
device in the open.
8. Do not short out the contacts
of battery or charger.
9. Respect the polarity “+/-“
when charging.
10.Do not open the unit and keep
out of the reach of children.
11.Do not charge the batteries
of other manufactures or ill-
suited models.
12.Ensure that the connection
between the battery charger
and battery is correctly
positioned and is not
obstructed by foreign bodies.
13.Keep battery charger’s slots
are free of foreign objects
and protect against dirt and
23
humidity. Store in a dry and
frost-free place.
14.When charging batteries,
ensure that the battery
charger is in a well-
ventilated area and away
from inflammable materials.
Batteries can get hot during
charging. Do not overcharge
any batteries. Ensure that
batteries and chargers are
not left unsupervised during
charging.
15.Do not recharge non-
rechargeable batteries, as
they can overheat and break.
16.Longer life and better
performance can be obtained
if the battery pack is charged
when the air temperature is
between 18°C and 24°C. Do
not charge the battery pack
in air temperatures below
0°C, or above 40°C. This is
important as it can prevent
serious damage to the battery
pack.
17.Charge only battery pack of
the same model provided
by Worx and of models
recommended by Worx.
24
SYMBOLS
Do not stare directly into the tool
holder. When changing the tool insert, it
can be thrown out toward the front
To reduce the risk of injury, user must
read instruction manual
Warning
Wear eye protection
Wear ear protection
Wear dust mask
Wear protective gloves
Double insulation (for charger)
Do not burn
Do not expose to rain or water
For indoor use only (for charger)
Read the operator’s manual
Lock
The output plug is with positive center
pole and negative outer pole
T1A
Fuse
Waste electrical products must not be
disposed of with household waste. Please
recycle where facilities exist. Check
with your local authorities or retailer for
recycling advice.
Li-I on
Li-I on
Do not dispose of batteries, Return
exhausted batteries to your local
collection or recycling point
Li-I
on
25
RCM marking
ABN: Australian Business Number. By this number,
business information such as entity type, status,
business location etc. can be found at website http://
abr.business.gov.au.
ABN of Positec Australia Pty Limited is 14 101 682 357
COMPONENT LIST
1. SLIDE COVER
2. FORWARD/REVERSE ROTATION CONTROL
3. SOFT GRIP HANDLE
4. CHARGING INDICATOR
5. CHARGING SOCKET
6. ON/OFF SWITCH
7. LED LIGHT
8. SCREW HOLDER
9. CHUCK
10. BIT CARTRIDGE
11. EXTENDABLE FLEXIBLE SHAFT *
* Not all the accessories illustrated or described are
included in standard delivery.
TECHNICAL DATA
Type WX255 WX255.X (250~269-designation of machinery,
representative of Battery-powered Screwdriver)
WX255 WX255.X **
Charger voltage 100-240V~ 50/60Hz
Rated voltage 4V Max
***
Charger input power 3W
Battery capacity 1.5Ah Li-Ion
No-load speed 230/min
Maximum torque 3N.m
Machine weight 0.5kg
Charger Protection class /II
Charging time (Approx.) 5 hours (Approx.)
**
X=1-999, A-Z, M1-M9 there are only used for different
customers, there are no safe relevant changes between these
models.
***
Voltage measured without workload. Initial battery voltage
reaches maximum of 4 volts. Nominal voltage is 3.6 volts.
For the technical data of the types, the number of cells and the
rated capacity of the batteries that can be charged, please
26
refer the nameplate of the tool supplied by Worx.
We recommend that you purchase your accessories from
the same store that sold you the tool. Refer to the accessory
packaging for further details. Store personnel can assist you and
offer advice.
NOISE INFORMATION
A weighted sound pressure L
pA
: 65dB(A)
A weighted sound power L
wA
: 76dB(A)
K
pA
&K
wA
3.0dB(A)
Wear ear protection.
VIBRATION INFORMATION
The declared vibration total value and the declared noise
emission value have been measured in accordance with a
standard test method and may be used for comparing one tool
with another.
The declared vibration total value and the declared noise
emission value may also be used in a preliminary assessment
of exposure.
WARNING: The vibration and noise emissions during
actual use of the power tool can differ from the declared
value depending on the ways in which the tool is used
especially what kind of workpiece is processed dependant on
the following examples and other variations on how the tool is
used:
How the tool is used and the materials being cut or drilled.
The tool being in good condition and well maintained.
The use of the correct accessory for the tool and ensuring it is
sharp and in good condition.
The tightness of the grip on the handles and if any anti vibration
and noise accessories are used.
And the tool is being used as intended by its design and these
instructions.
This tool may cause hand-arm vibration syndrome if its
use is not adequately managed.
WARNING: To be accurate, an estimation of exposure
level in the actual conditions of use should also take
account of all parts of the operating cycle such as the times
when the tool is switched off and when it is running idle but not
actually doing the job. This may significantly reduce the
exposure level over the total working period.
Helping to minimise your vibration and noise exposure risk.
Always use sharp chisels, drills and blades.
Maintain this tool in accordance with these instructions and
keep well lubricated (where appropriate).
If the tool is to be used regularly then invest in anti vibration and
noise accessories.
Plan your work schedule to spread any high vibration tool use
across a number of days.
Vibration total values (triax vector sum) determined accord-
ing to EN 62841:
Vibration emission value: a
h
= 0.70m/s²
Uncertainty K = 1.5m/s²
27
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the instruction book
carefully.
INTENDED USE
The power tool is intended for driving in and loosening screws
as well as for drilling in wood, metal and plastic.
ACTION FIGURE
BEFORE OPERATION
Charging the Battery
NOTE:
1. Maximize Battery Performance
Prior to initial use, the battery must be
charged 5 hours to fully utilize the battery
capacity.
2. When the battery is full charged, the light
turns green.
See Fig. A
ASSEMBLY AND ADJUSTMENT
Inserting and Removing the Bit
Cartridge
See Fig. B,C
Assembling and Removing the Screw
Holder
See Fig. D1,D2
Installing and removing extendable flexible
shaft (optional)
See Fig. E1,E2
Forward/reverse/lock
WARNING: Never change the direction
of rotation when the chuck is rotating,
wait until it is stopped!
See Fig F1,F2,F3
OPERATION
Selecting a Bit See Fig G1,G2
Drilling a Pilot Hole See Fig H
Assembling screw See Fig I1,I2,I3
Tightening and Loosening Screw See Fig J1, J2
Operating the On/Off Switch
WARNING: Do not operate for long
periods at low speed because excess
heat will be produced internally.
See Fig K
LED Light Indicator See Fig K
Automatic Spindle Locking
NOTE: When the slide driver is out of
power, this function enables the customer
tightening or loosening screws manually.
MAINTENANCE
Your power tool requires no additional lubrication or mainte-
nance. There is no user serviceable parts in your power tool.
Never use water or chemical cleaners to clean your power
tool. Wipe clean with a dry cloth. Always store your power tool
in a dry place. Keep the motor ventilation slots clean. Keep all
28
working controls free of dust. If you see some sparks flashing
in the ventilation slots, this is normal and will not damage your
power tool.
ENVIRONMENTAL PROTECTION
Waste electrical products must not be disposed of with
household waste. Please recycle where facilities exist.
Check with your local authorities or retailer for recycling
advice.
FOR BATTERY TOOLS
The ambient temperature range for the use and storage of tool
and battery is 0
O
C-45
O
C.
The recommended ambient temperature range for the charg-
ing system during charging is 0
O
C-40
O
C.
PLUG REPLACEMENT
(ONLY FOR REWIRABLE PLUG OF UK & IRELAND)
If you need to replace the fitted plug then follow the
instructions below.
IMPORTANT
The wires in the mains lead are colored in accordance with the
following code:
Blue = Neutral
Brown = Live
As the colors of the wires in the mains lead of this appliance
may not correspond with the colored markings identifying
the terminals in your plug, proceed as follows. The wire which
is colored blue must be connected to the terminal which
is marked with N. The wire which is colored brown must be
connected to the terminal which is marked with L.
WARNING: Never connect live or neutral wires to the
earth terminal of the plug. Only fit an approved BS1363/A
plug and the correct rated current fuse which is used in the
plug.
NOTE: If a moulded plug is fitted and has to be removed take
great care in disposing of the plug and severed cable, it must
be destroyed to prevent engaging into a socket.
C
onnec t
Blue to
N
(
neutral)
Outer sleeve
firmly clamped
Cable grip
Brown L (live)
Fuse
29
TROUBLE SHOOTING
Problem Possible cause Solution
Battery will not charge 1. Charger not plugged into a
working outlet.
2. Surrounding air temperature is too
hot or too cold.
1. Plug charger into a working outlet.
Check current by plugging in a lamp.
2. Move charger to an appropriate place
which temperature is suitable for the
charger.
Switch cannot be pressed Forward/Reverse switch at middle
position
Make sure switch is on Forward or
Reverse rotation according to project
need.
Driver stops during driving screws Driver battery is out of power Make sure the driver is fully charged
before using it.
Bit Cartridge will not rotate when Cover
slides.
The cover is not fully open Make sure the Cover is fully open and
past the red line on the tool.
Positec Australia Pty Limited
10 Corporate Blvd Bayswater , VIC 3153, Australia
30
DECLARATION OF CONFORMITY
We,
Positec Germany GmbH
Postfach 32 02 16, 50796 Cologne, Germany
On behalf of Positec declare that the product,
Description Battery-powered Screwdriver
Type WX255 WX255.X (250~269 - designation of
machinery, representative of Battery-powered
Screwdriver)
Function Tightening and loosening screws, nuts
Complies with the following directives,
2006/42/EC 2011/65/EU&(EU)2015/863
2014/30/EU 2014/35/EU
Standards conform to:
EN 62841-1, EN 62841-2-2, EN 55014-1,
EN 55014-2, EN 60335-1, EN 60335-2-29,
EN 62233, EN IEC 61000-3-2, EN 61000-3-3
The person authorized to compile the technical file,
Name: Marcel Filz
Address: Positec Germany GmbH
Postfach 32 02 16, 50796 Cologne, Germany
2021/10/22
Allen Ding
Deputy Chief Engineer, Testing & Certification
Positec Technology (China) Co., Ltd
18, Dongwang Road, Suzhou Industrial
Park, Jiangsu 215123, P. R. China
31
DECLARATION OF CONFORMITY
We,
Positec (UK & Ireland) Ltd.,
PO Box 6242, Newbury, RG14 9LT, UK
On behalf of Positec declare that the product,
Description Battery-powered Screwdriver
Type WX255 WX255.X (250~269 - designation of
machinery, representative of Battery-powered
Screwdriver)
Function Tightening and loosening screws, nuts
Complies with the following regulations,
Supply of Machinery (Safety) Regulations 2008
Electromagnetic Compatibility Regulations 2016
The Restriction of the Use of Certain Hazardous
Substances in Electrical and Electronic Equipment
Regulations
Electrical Equipment (Safety) Regulations 2016
Standards conform to:
BS EN 62841-1, BS EN 62841-2-2,
BS EN 55014-1, BS EN 55014-2
BS EN 60335-1,BS EN 60335-2-29,
BS EN 62233, BS EN IEC 61000-3-2,
BS EN 61000-3-3
The person authorized to compile the technical file,
Name Jim Kirkwood
Address Positec (UK & Ireland) Ltd.,
PO Box 6242, Newbury, RG14 9LT, UK
2021/10/22
Allen Ding
Deputy Chief Engineer, Testing & Certification
Positec Technology (China) Co., Ltd
18, Dongwang Road, Suzhou Industrial
Park, Jiangsu 215123, P. R. China
32
Copyright © 2022, Positec. All Rights Reserved.
AR01233505
www.worx.com
After-sales Service and Application
At www.worx.com you can order spare parts or arrange the
collection of a product in need of servicing or repair.
Tel. Service: 0345 202 9679
E-Mail: customerservices@worxtools.com
