PRECAUTIONS:
For the safety of children,please read the instruction manual
before use.
It is not allowed to drive on highways or slopes.
If you don't use an electric toy car for a long time,
please charge it at least once a month.
There is a lot of important information in the manual,please
keep it safe.
Please charge the battery promptly when it is low.
Please turn off the power when not in use.
The images in the manual are for reference only。
Charging must be operated by adults and children should not be allowed
to charge themselves.
This car must be used under adult supervision and guidance.
This product must be assembled by an adult.
It is strictly prohibited to drive and play in dangerous places such as
public roads,slopes,and swimming pools.
Please note that some parts may be damaged due to improper use.
Regularly check the wires,plugs,and other components of the battery
charger for damage.If any damage is found,stop using it until it is
repaired.The power terminal connection must not be short circuited.
This product is a battery-powered kids electric ride-on car,
designed for children aged 3 to 8 years old to ride on flat, hard
indoor and outdoor ground. It is equipped with forward, reverse,
left/right steering, lighting and multimedia functions, powered by
12V rechargeable battery. Only one child within the applicable age
range is allowed to ride at a time, maximum load capacity 70KG.
Before operation, check battery level, wheels, safety belt and
remote controller. Do not operate the vehicle on slopes, puddles,
gravel roads or motor vehicle lanes. Adult supervision is required
whenever children are using this product.
The car has Bluetooth for music play.
1. Turn on the car audio
2. Open Bluetooth on your phone
3. Search and connect the car devicePlay music after pairing succeeds.
Children's electric vehicles
Installation instruction
WARNING:
For safety reasons,please pay attention to the following warnings:
For adult assemble toys,stay away from the fire.
This prodarct contains small parts that not suitable under 12months!
Use it under the supervision of adults.
Charging must be done by an adult.
The maximum load capacity of a car is 25 kilograms.
This car is suitable for children aged 12 to 72 months.
Do not use this car while charging.
Do not treat chargers as toys.
For safety reasons,please read this instruction carefully before use.
Kids Electric Ride on Car
HW-1788
This product also supports 2.4G remote control operation. However, it is sold
without a remote control at the time of shipment. Consumers need to purchase
the remote control separately.
(Please read this manual carefully before use)
Steering wheel
Front windshield
Wheels and covers
rear bumper
seat
front bumper
Installation tools and screws
car body
Installation steps
1.shim
2.wheel
4.nut-wrench
3.nut
5.protecting cover
Install the front wheels:
1.First ,use a nut wrench to remove the nut and washer from the shaft.
2.Install the wheels and washers onto the axle in sequence as shown in the diagram,tighten
the nuts and secure them with a nut wrench.
3.Then buckle the protruding nut guard onto the corresponding wheel groove.
Install the rear wheels:
1.Use two wrenches to simultaneously clamp the nuts on both sides of the wheel,rotate the wrenches
in different directions,and remove the nuts and washers on both sides.
2.Install the left and right wheels and washers into the axle in sequence as shown in the figure,tighten
the nuts, and then use two wrenches to tighten and fix them in the opposite direction.
3.Simply fasten the nut covers on both sides to the corresponding wheel slots.
Connect the battery line and install the seat:
1.Remove the white insulation 2.Connect the red end corresponding
cap from the battery. to the red line to the battery cable
Install steering wheel,windshield,and bumper
2.Insert the steering wheel control 3. Remove the screws and install the
cable into the body power cord end.
steering wheel.Align the screw holes
and secure them tightly with screws
4.Align the front windshield buckle with
the body groove and insert it into the
screw holes on both sides,and then
fix and lock it with screws.
5.Align the rear bumper with the holes
on both sides behind the seat and insert
it firmly to ensure it is fully inserted.
5.protecting cover
4.nut-wrench
3.nut
1.wheel
2.shim
Accessories Display
3. Align the protrusion on the back of the
car with the groove on the body,buckle
it into the seat,align it with the screw
hole below,and tighten it with a
screwdriver to fix it
6. Align the front bumper with the four
recessed holes in the front as shown in
the picture and insert them,then tighten
and fix them one by one with screws.
3.Insert the front windshield power
cord into the body power cord end.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure statement
The device has been evaluated to meet general RF exposure requirement. The
device can be used in portable exposure condition without restriction.
