F77 V2 User Manual
1
Content
Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2
Product Specications . . . . . . . . . . . . . . . . . . . . .
3
Package Contents . . . . . . . . . . . . . . . . . . . . . . .
4
Appearance . . . . . . . . . . . . . . . . . . . . . . . . . . .
5
Buttons and Functions . . . . . . . . . . . . . . . . . . . .
6
Touch Screen Function . . . . . . . . . . . . . . . . . . . .
8
Voice Control Function . . . . . . . . . . . . . . . . . . .
11
User Inteace Oveiew . . . . . . . . . . . . . . . . . . .
12
Function Oveiew . . . . . . . . . . . . . . . . . . . . . .
15
App and Wi-Fi Function . . . . . . . . . . . . . . . . . . .
18
How to Play Video on Computer . . . . . . . . . . . . . .
20
Installation . . . . . . . . . . . . . . . . . . . . . . . . . .
24
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . .
28
Customer Seice Center . . . . . . . . . . . . . . . . . .
30
2
Notice
• Please read this manual carefully before operation and keep it
for future reference. It will be helpful should you encounter any
operational problems.
• Non-original pas or improper installation will void the
manufacturer's warranty. The installation instructions do not
apply to all types of vehicles and are written as guidelines to
assist in installing the system.
• Consult with an experienced technician if you are not
comfoable installing the device on your own.
• Please make sure to read and understand local laws and
regulations regarding cameras and their use in a vehicle. Laws
may va by state.
• Do not obscure the view of the road ahead or obstruct the
deployment of any airbags in the event of an accident.
• When not in use, please disconnect the car adapter from both
the 12/24V DC outlet in your vehicle and the device itself.
• Only clean the device with a soft d cloth, for tough di, apply
some neutral detergent diluted in 5 to 6 pas water on a soft
cloth.
• Note that alcohol, thinner, benzene, etc
.
could cause damage to
the paint or coatings on the device.
• Avoid making contact with the lens as this may cause damage.
• The video recordings made by this device are intended for
personal use only.
• While driving, do not adjust the controls of your device, as
it may draw your attention from your surroundings.
3
Product Specications
Item Name F77 V2 Dash Cam Video Format MP4
Screen Size 4" IPS Screen Photo Format JPG
Recording
Resolution
Front 4K@30fps+Rear 4K@30fps
Front 2.5K@60fps+Rear 4K@30fps
Front 2.5K@30fps+Rear 4K@30fps
Front 4K@30fps / Front 2.5K@60fps / Front 2.5K@30fps
Input DC 5V-2.5A
Lens
Front cam F1.8
Rear cam F1.8
Operating
Temperature
-4°F~158°F
eMMC Storage 256GB
Warranty
Period
18 months
Note:
If you have any problems during use, we will provide free device
replacement within 18 months of purchase, in addition to lifetime
technical suppo.
Extended Warranty Seice:
You may also receive an additional 6 months of extended
warranty seice by registering your device on our website.
URL: https://www.redtigercam.com/pages/warranty-form
4
Package Contents
• F77 V2 4K Dash Cam
• 4K Rear Camera
• User Manual • Tool
• Power Supply Cable
with Car Charger
• Electrostatic
Sticker
• Adhesive
• Rear Cam Cable
• USB Type-C Data
Cable
• Cable Clips*5
OK Button
•Adhesive Slipcover
5
Appearance
4
1
7
8
15
5
12
13
14
11
10
6
9
Adhesive
OK Button
Status Light
Screen
GPS
Left Button
Reset Button
Memo Card
Slot
Power Button
Power Po
Rear Cam
Slot
Front
Camera
Lens
Sliding Cover
Right Button
3
2
Mode Button
6
Buttons and Functions
Power Button
Recording Mode:
• Sho press-to Switch screen
• Long press-to Turn o the Camera
Setup Mode:
• Sho press-to Turn on/o screen
Playback Mode:
• Sho press-to Delete/Lock/Unlock the specic le
Menu Button
Recording Mode:
• Sho press to Enter main menu
Setup Mode:
• Sho press-to Return to the previous screen
Playback Mode:
• Sho press-to Return to the previous screen
Left Button
Recording Mode:
• Sho press-to Lock/Unlock the recording le
• Long press-to Turn on/o Wi-Fi
Setup Mode:
• Sho press-to Select the previous function
Playback Mode:
• Sho press-to Select the previous le
• Sho press-to Fast rewind while vidio is being
played
M
7
OK
Right Button
Recording Mode:
• Sho press-to Turn on/o audio recording
Setup Mode:
• Sho press-to Select the next function
Playback Mode:
• Sho press-to Select the next le
• Sho press-to Fast forward while video is being played
OK Button
Recording Mode:
• Sho press-to Take a snapshot
• Long press-to Turn on/o video
Setup Mode:
• Sho press-to Enter/Conrm specic settings
Playback Mode:
• Sho press-to Play the specic le
8
You can manually click the icon at the top of the screen to
choose whether to record audio during video recording.
You can manually click the icon at the top of the screen to
choose whether to turn on Wi-Fi.
You can manually click the icon at the top of the screen to
choose whether to turn on the key sound.
You can manually click the icon at the top of the screen to
choose whether to turn on the Voice control.
Touch Screen Function
• Video Mode
9
Swipe up and down on the playback inteace to turn
pages.
You can manually click the icon to choose whether to copy
the contents of the eMMC to the memo card.
You can manually click the icon to choose whether to
delete les.
You can manually click the icon to choose whether to lock
les.
You can manually click the icon to choose whether to select
multiple les.
• Playback Mode
10
Swipe up and down on the setting inteace to turn pages.
You can manually click the icon to enter the selected function
inteace.
• Setting Mode
11
Voice Control Function
Fast control through simple voice commands
If the icon is white , it means the function can be used
normally.
You have two ways to enable this feature.
Tap on the icon to turn the feature on or o.
Enter the setting mode-vioce control-on/o.
1
2
Note:
You can see the specic commands in setting-vioce control.
lock the voice
take picture
turn on audio turn o audio
turn on screen turn o screen
turn on wi turn o wi
turn on recording turn o recording
show front camera show rear camera
12
Icon Description
Fatigue driving function is on
G-Sensor sensitivity
Front camera resolution
Loop recording in 1 min/3 mins/5 mins per le
Whether to connect the hardwired kit and set up parking
monitoring
Voice control
User Inteace Oveiew
• Recording Mode
13
Icon Description
GPS status
Wi-Fi status
Camera system sound status
Voice recording status
Which camera is being displayed
Recording status and recording time
Emergency recording is on
Date and time of the camera
Settings
Emergency recording
Turn on or o recording
Photograph
14
• Playback Mode
Press the
M
button to enter Playback mode.
Press the Left or Right button to select the folder you want
to play, then press the
OK
button to enter.
Press the
OK
button to watch the recorded video.
Sho press the power button to edit your recorded videos.
1
3
2
4
15
Icon Function Option/Description
Resolution
Front 4K@30fps+Rear 4K@30fps /
Front 2.5K@60fps+Rear 4K@30fps/
Front 2.5K@30fps+Rear 4K@30fps/
Front 4K@30fps/Front 2.5K@60fps/
Front 2.5K@30fps
Audio ON/OFF
Recording Duration 1/3/5mins
G-sensor O/Low/Medium/High
Fatigue Reminder
A Reminder Will be Made During
1h/2h/3h/OFF
Wi-Fi OFF/2.4GHz/5.8GHz
Click Tone ON/OFF
Screen Saver
OFF/10s/30s/2mins,
Screen goes o after the set time
Voice Control ON/OFF/Voice Command
Mirror Flip
Horizontal Flip Your Rear View
*
Need to connect rear camera
Function Oveiew
Sho press M button to enter settings menu, where you can
adjust various functions and parameters of the entire machine.
16
Icon Function Option/Description
Rear Cam Flip
Veical Flip Your Rear View
*
Need to connect rear camera
Parking Monitor Please connect the ACC hardwire kit
GPS Display GPS signal strength
TimeWatermark ON/OFF
Speed Stamp ON/OFF
GPS Stamp ON/OFF
Speed Units KM/H / MPH
Language Choose Your Preferred Language
Clock Settings Update With GPS
Time Format 12h/24h
Time Zone Choose Your Time Zone
DST Daylight Saving Time ON/OFF
12
24
17
Icon Function Option/Description
Flicker 60Hz/50Hz
Format Reminder Reminder to Clear Data
Format
Format eMMC or memo card.All data
will be deleted
Card Speed Card Speed Detection
Default Setting Reset All Settings
APP A QR Code for redtiger app
Version Software Version
Help Center Scan the QR code to contact us
Note:
• In order to a Clean, Smooth, Comfoable using experience, we
suggest you format your eMMC storage once a month.
• When you turn o Click Tone, the staup and shutdown sounds
will also be turned o.
18
App and Wi-Fi Function
• How to connect Wi-Fi?
1. Download the app
You can download the app from:
-- Ocial Website: https://www.
redtigercam.com/pages/app
-- QR Code located on your dash cam
(may be located on the right side)
-- Search “Redtiger” in the Apple App
Store or Google Play Store
2. Turn on the Wi-Fi on the dash cam, the Wi-Fi and SSID and
password will appear on the display.
3. Open Redtiger App> jump to the Wi-Fi connection inteace
according to the steps> nd the Wi-Fi of the dash cam> enter
the password to connect.
(The default password is 12345678)
4. After successfully connecting to Wi-Fi, return to the App to
use it.
• View/Download/Delete/Share Video
1. Click the icon on the main inteace to view video and image
les.
2. Long press the video le to select it, then choose whether
you would like to download or delete it.
3. Return to the App home page and select the Album> Open
and watch/share it.
19
• App Home
1 2
Native Wi-Fi Name Function Icon
7 8
Rotate Video Screen Speed Info
3 4
GPS Singal Map
5 6
Playback Footage Dash Cam Settings
1
2
5
6
3
4
6
7
8
3
5
20
• Over-The-Air Updates
Note: Please update the Redtiger App to the latest version to use
this function.
1. To peorm an over-the-air update, disconnect your phone
from the dash cam’s Wi-Fi network. Connect your phone to
LAN (not the dash cam’s Wi-Fi) for 5 seconds, then
disconnect. Reconnect to the dash cam’s Wi-Fi network.
2. Once Wi-Fi connection is successful, open the Redtiger App
to sta using it. If new software is detected, the App page will
indicate the availability of an update.
3. To peorm the update, click on “Upgrade Now”. The Redtiger
app will prompt you to download the update package.
4. Connect the dash cam to send the update package. Do not
power o the dash cam during the upgrade process. Once
the upgrade is completed, the app will display the upgrade
success message, and the dash cam will automatically resta.
How to Play Video on Computer
We recommend using REDTIGER Player as the correct video player
to watch/play videos. It can also view Google Maps.
You can Download it for free on Mac or Windows from the
following link: https://www.redtigercam.com/pages/gps-player
You can choose dierent playback modes in Settings > Video
Playback Mode. You can set playback speed, language, map,
and various other functions.
21
Data can be output from the main unit to a personal
computer using a USB cable.Alternatively, you can inse
an memo card into the dash cam and copy data from the
eMMC, transfer data by using a card reader.
TIPS:
22
1 2
4 65
3
1 2
Video play window (Front) Video play window (Rear)
3 4
Map and track display Play control panel
5 6
Speed and driving state indication Play list
Note:
If the video les of front and rear road tracks are recorded
synchronously and loaded into the playing list at the same time,
they can be played separately in split left and right screens.
When you nd the desired video le, hold down the left mouse
button and drag the desired les to the video play window to
play it.
23
Installation
• eMMC Storage
The dash cam comes with built-in 256GB eMMC (Embedded Multi
Media Card) storage, eliminating the need for additional purchase
and installation of an memo card, allowing for immediate
recording upon staup.
Please make sure to connect all cameras
and wires before powering on the camera
screen,otherwise the camera will not work
properly.Please follow the instructions
below for the rst-time installation of the
Redtiger dash cam.
Scan the QR code on the right to view the
installation tutorial video.
WARNING
24
SD
• Inse Memo Card (Optional Operation)
F77 V2 also suppo using memo cards to copy the videos you
need. You can do this in the playback folder by clicking "Copy
Current" or "Copy Selected."
Tips: Video is not saved directly to the memo card.Inse the
memo card into the dash cam, ensuring that it is oriented
correctly so that the gold contacts are facing towards the screen
of the dash cam. Push the memo card until it clicks into the slot.
•
Front camera installation
Peel o the electrostatic sticker on the cellophane and transfer
it to where you want to stick it. Attach the front camera to the
electrostatic sticker and press to make it rmer.
25
•
Wire Layout In The Vehicle
The car charger is connected to the cigar socket.
Connect the other end of the car charger to the dash cam.
Use the crowbar to run the power cable along the front
windshield and the roof, and hide the cable down the A-pillar,
so as not to block the driver's sight and cause danger.
3
1
2
Pillar A
26
Connect the inteace of the rear cable with the inteace of the
rear cam cable.
Hide the rear cam cable along the gaps between the front
windshield and the ceiling, between the car body and the
ceiling on the side of the passenger seat, and between the rear
seats and the ceiling.
4
5
27
•
Rear camera installation
Peel o the electrostatic sticker on the rear camera and transfer
it to where you want to stick it. Attach the camera to the
electrostatic sticker and press to make it rmer.
28
Troubleshooting
・Why is the machine running normally but there are no les in
the memo card?
The eMMC (Embedded Multi Media Card) is built into the dash
cam for storage. The memo card does not automatically save
les, but you can manually copy les to the memo card.
・Why is there no GPS signal?
1. Disconnect and clean the cable and po of any dust that
may have accumulated around the dash cam. Check for any
inteerence in your car, like metal lm on the windshield, a
radio antenna, or radar detector.
2. Move your car to an open area. Obsee if the GPS icon on
the screen turns green and displays GPS information.
3. Once the GPS locks on to a signal, a satellite icon will appear
at the bottom left of the screen. Green indicates positioning,
while white indicates no positioning.
・How to turn o the on/o music of dash cam?
Please go to Settings > Click Tone > O.
When the click tone is turned o, the power on and o music
will also be turned o.
・Why does my dash cam prompt “Card Error” or “Please
Format Memo Card” occasionally?
Please follow the steps below to check:
1. Please go to Settings > Format Reminder to check whether
the regular format reminder is enabled.
2. Format the Memo Card.
3. Restore facto settings and resta the dash cam.
4. Update the rmware.
・Device restas repeatedly/no boot?
1. Ensure you’re using the included charger/cables.
29
2. Remove the memo card, camera cable, and car charger
and reinstall them. Check if an issue was caused by the
accessories.
3. Reset the device using the button at the bottom of the
camera.
4. If the issue persists, connect the dash cam to a computer
using a USB cable. If the device powers on, the issue may
be caused by the car charger cable. If it does not power on
while connected, there may be an issue with the dash cam
itself.
5. Please go to the ocial website to update the rmware.
6. If it is not resolved, please contact our dedicated customer
seice for a replacement.
・Why "Mass storage" appears on the screen?
"Mass storage" happens when you use a USB cable with data
transfer mode causing the dash cam to enter transfer mode.
In this mode, data can only be transferred; no other functions
work. For best results, use the original car charger or a USB
cable without data transfer mode.
・Why can't I connect to Wi-Fi?
1. Check the working distance of Wi-Fi, about 15ft.
2. Check the SSID and password of the Wi-Fi, or whether there
are other devices connected to the Wi-Fi.
3. Turn o mobile data, security software, and VPN on your
phone.
4. If the issue persists, please contact customer suppo for
assistance.
・Why is the time setting incorrect?
The dash cam features built-in GPS. It automatically adjusts
time based on your location and time zone, eliminating the
need for manual time changes. And you can adjust the time
through Settings > Time Zone/DST.
30
Help Center WhatsApp
Redtiger
For more information:
After sales: help@redtigercam.com
Business Cooperation: contact@redtigercam.com
Customer Phone Seice: +1 888 966 8028 (US)
Customer Seice Center
If you have any problems with the function or installation of your
dash cam, please feel free to reach out to us.
Check us out here.
Product and seice are the foundation of Redtiger.
www.redtigercam.com
Instagram: @redtiger_dashcam
Facebook: Redtiger Dash Cam
