INSTALLATION GUIDE
Woodburn
Models: KBF416C
KBF416MB
KBF416ORB
KBF416SS
Karran USA Tel: 866.452.7726 www.karran.com [email protected]
COMPONENT LIST QTY
1 - Faucet Body 1
2 - Rubber Washer 2
3 - Mounng Hardware 2
1
1
2
3
3
2
5-1/8”
10-3/8”
4”
6-1/8”
4-5/8”
4-1/16”
7-3/8”
2-3/16”
7/8” - 1”
7/8” - 1”
4”
5
4
7
6
9 - Handle
10 - O-Ring
11 - Nut
12 - Body Base
13 - Gasket
14 - Screw
15 - O-Ring
16 - Cartridge
17 - Cartridge Base
18 - Base Plate
19 - Washer
20 - Mounng Hardware
21 - Cartridge
22 - Water Lines
1 - Cover
2 - Screw
3 - Faucet Body
4 - Gasket
5 - Aerator
6 - Aerator Cover
7 - Color Buon
8 - Screw
