Projector A1362
User Manual
Read all instructions before you use this device. Do not make any changes
that are not described in this manual. If physical injury, loss of data, or
damage is caused by failure to follow instructions, the warranty does not
apply.
Setup
• To reduce the risk of fire and/or electric shock, do not expose the device
to rain or moisture, and objects filled with liquids, such as vases, should
not be placed on the device.
• Do not place the device on soft surfaces such as tablecloths or carpets
as doing so could be a fire-hazard.
• Do not place the device in areas susceptible to excessive dust and dirt or
near any appliance generating a strong magnetic field.
• To prevent overheating, do not block or clog the ventilation openings.
Never place the device in a confined space. Always leave enough space
around the device for ventilation.
• Protect the device against direct sunlight, heat, large temperature
fluctuations and moisture.
• When the device runs for a long period of time and the surface becomes
hot, shut it down and unplug the power cord. Resume operation only after
the device has cooled.
• Always handle the device with care. Avoid touching the lens.
• Never place heavy or sharp objects on the device or the power cord.To
avoid electric shock, do not disassemble.
• Only use attachments or accessories specified by the manufacturer.
Avoid extreme vibration. It may damage the internal components.. Do not
allow children to handle the device without supervision.
• Under the following conditions, a layer of moisture can appear inside the
device which can lead to malfunctions:
a) if the device is moved from a cold to a warm area;
b) after a cold room is heated;
c) when the device is placed in a damp room.
To avoid any moisture, seal the device in a plastic bag before moving it
to another room, and wait for one to two hours before you take it out of
the bag.
Safety Instructions
EN
01
Power Supply
Hearing Safety
Cleaning
Repairs
Caution
• Use only the provided power adapter.
• Power off the device before removing the power supply from the socket.
• Protect the power cord from being walked on or pinched, particularly at
plugs, convenience receptacles, and the point where they exit from this
device.
• Unplug this device if there are lightning storms or when unused for a
long period of time.
• Where the power plug or an appliance coupler is used as the disconnect
device, the disconnect device shall remain readily operable.
• Before you make or change any connections, ensure that all devices are
disconnected from the power outlet.
• Do not touch the power cable or the power connector with wet hands.
• Power off the device and remove it from the power supply before cleaning
the surface.
• Use a soft, lint-free cloth. Never use liquid, gaseous, or easily flammable
cleansers (like sprays, abrasives, polishes, and alcohol). Wipe over the
surfaces gently. Be careful that you do not scratch the surfaces.
• Do not use any liquid cleaning agents to clean the lens as they may
damage the protective coating on the lens. Use lens cleaning paper to
clean the lens of the projector.
• Do not make any repairs to the device by yourself. Only have your device
repaired by an authorized service center.
• Improper maintenance can result in injuries or damage to the device.
• Refer all servicing to qualified service personnel.
• Do not stare at operating beam, the bright light may hurt your eyes.
To avoid hearing damage, do not listen for extended periods at high volume.
Set the volume at a safe level.
EN
02
User manual x 1
Adapter x 1
Remote control x1
Projector x 1 Adapter AC cord x 1
Overview
Projector
Air ventilation(Outlet)
Tof (Auto focus)
Tripod screw hole
DC -in
Lens
USB port
HDMI Port
IR receiver
①
②
③
Handle
⑩
④
⑤
⑥
Aux Port
⑨
⑦
⑧
Front View Rear View
• Please do not look into the lens directly to avoid harm for your eyes.
• Please do not block the air ventilation(Outlet).
Attention:
User Manual
What’s Included
EN
03
F
F
OK
65 7 8
9
10
1
2
3
1
4
EN
04
• Press the button once: power on
• Press the button twice: power off
Signal source
Access more options during play
(available depend upon the source)
Activate Google assistant, Google's
voice-powered virtual assistant service
Projector setting
Press to confirm a selection or entry
Navigate menus or adjust the selected content
Return to the previous menu
Go to projector Homepage
Go to Android TV homepage
Volume down / up
Mutes the projector's audio
Adjust the focus
Preset Youtube button
Preset Netflix button
Preset Prime Video button
Preset Disney+ button
1
2
3
4
5
8
9
11
14
6
7
10
13
15
16
17
12
1
3
4
5
6
7
8
9
10
11
12
13
14
16
15
17
2
Get Started
Placement
① Place the projector right towards the projection surface to get a
rectangle picture.
② The distance between the projector and the projection surface
determines the picture size.
③ Check the projection distance and screen size on the specifications part.
Prepare the Remote Control
Install the remote control batteries (batteries not
included).
① Press and open the battery cover, as illustrated.
② Install two AAA batteries. Make sure that the
positive and negative ends are positioned
correctly, as illustrated.
③
④ The distance between the remote and the projector
should not exceed 10 m / 33 ft.
Place the battery cover back until it clicks into place.
• Press the power button once to power on.
• Press the power button twice to power off.
Power On
1.1m
4.1m
40"
150"
4
2
1
3
EN
05
Settings
Projection Settings
Projection Mode
Press the button on the remote control, go to projector homepage,
and select Settings.
You can also manually focus through the remote control. Press the /
button on the remote control, until the picture is clear.
When start the projector for the first time, you will be guided to a page to
select language, use remote control or to select your language. Then
press the right button and select "Complete" to enter the next page.
Focus
Place the projector towards a suitable projection surface or wall, the projector
will automatically focus the image.
Select Your Language
Auto Focus
Manual Focus
Note：The projection distance must between 1.1m to 4.1m.
EN
06
Zoom in/out
Use the remote control to resize the picture size from 50% to 100%
without moving the projector.
This Projector support Auto keystone correction, digital keystone
correction, and remote four-point keystone correction.
When fixing your projector in a place, use digital keystone correction.
Press the button to go to projector homepage, select [Settings]
-> [Projection Settings] -> [Vertical Correction] / [Horizontal Correction],
press left or right button on the remote control to adjust.
• Digital Keystone Correction
Vertical Correction
Keystone Correction
When the projector image is distorted, it will perform auto keystone
correction to restore the image to a rectangle. If you find the auto
keystone correction does not work as well as before, follow the
instructions below to optimize it.
① Press the button to go to projector homepage, into
[Settings] -> [Projection Settings] -> [Calibration Settings].
② Select [Keystone Benchmark Correction], and adjust the projector
for the correct image.
• Auto Keystone Correction
EN
07
OK
If the projected image is stretched or distorted along both axes due
to the angle of the projection, press the button to go to
projector homepage, and select [Settings] -> [Projection Settings]
-> [Four point Correction], choose the corner you want and press left
or right button on the remote control to adjust.
• Four Point Correction
Four Point Correction
To restore the default settings, select Keystone Correction Reset and
press “OK”.
• Keystone Correction Reset
Other settings
Screen Saver
Set the shutdown timer for the projector.
Screensaver Timeout Shutdown
Select an on-screen display language.
Language Settings
Reset your device and restore factory setting.
Restore Factory Settings
Select default screen saver video.
Screensaver Video
The screen saver automatically starts whenever your projector sits idle
for the default time. You could change the default time or turn it off.
Horizontal Correction
EN
08
OK
Wired Connections
1. Connect to an HDMI Playback Device
2. Connect to a Flash Drive
Method 1:
Method 2:
① Plug in the USB storage device.
② Press the button on remote control to go to projector homepage,
select
[USB], and press.
③ Select the file you plan to play from the file and folder menu.
① Install the
File Explorer app from the GOOGLE Play Store on the
projector.
② Install a media player app such as
VLC.
③ Plug in the USB drive into the projector to play your videos.
3. Connect to a Headphone via AUX Cable
You can connect a headphone or speaker to Projector via AUX cable as well.
① Plug in the 3.5mm AUX cable connector to projector AUX port.
② Plug the other connector of the 3.5mm AUX cable to your headphone or
speaker.
③ Play your media on projector.
This projector supports connections with various HDMI playback devices
such as PC, TV stick, TV box, DVD player, set-top box (STB), game console
or other devices.
① Connect this projector to an HDMI playback device with an HDMI cable
(not provided).
② Press the button on remote control to go to projector homepage,
select
[HDMI], and press[OK].
EN
09
Press the button to pop up the shortcut menu
• Press navigation button to select the option
• Press button to go to the next page
• Press or button to adjust parameter
• Press "OK" button to save
Shortcut Menu
Image Mode
Color Temp
Sound Mode
Projection Setting
Standard
Keeps natural looking colors with
a balance of warm and cool tones
Provides more picture details and
color sharpness
Provides warm colors with
lower light
Provides cold color temp
Provides normal temp
Provides warm temp
Provides standard tones
Provides more detailed tone
Provides home theater-style sound
Manually set the sound of each
frequency band
Zoom in or out of the
projection image
Perform keystone correction
Reset keystone correction
Manually set the Red,
Green and Blue
Manually set the Brightness,
contrast, Saturation, Sharpness
and Hue
Light
Soft
Personal
Cold
Normal
Warm
Personal
Standard
Music
Movie
Personal
Zoom In/Out
Vertical Correction
Horizontal
Correction
Four Point
Correction
Keystone
Correction Reset
EN
10
Specifications
Projection Distance and Screen Size
You may return your undamaged product within 30 days of the date of
purchase to receive a full refund for any reason.
For non-quality related warranty claims, the buyer is responsible for
shipping costs.
Every ETOE product comes with one year of quality-related issues coverage.
If you submit a claim to our support mail, ETOE will, at its option:
1. Replace the ETOE Product with a replacement product of the same
model and cover any return shipping costs.
2. Exchange the ETOE Product for a refund of your purchase price.
30-Day Money-Back Guarantee for Any Reason
12-Month Warranty for Quality-Related Issues
Warranty
CPU: ARM Quad 64-bit Cortex-A53
Native Resolution: 1920*1080
Throw Ratio: 1.22
Aspect Ratio: 16:9 / 4:3 Adaptive
Speaker: 10W*2 Stereo Speaker
Connection Port: HDMI*1; USB*1; AUX*1
Zoom: 50%-100%
Keystone Correction: ±40°, Auto keystone support
Recommended Ambient: 41°F to 95°F / 5°C to 35°C
Relative Humidity: 15% ~ 85% (non-condensing)
Specifications
Screen size
(inch)
3.5 108.049.819.688.634.940
5.3 162.174.729.4132.852.360
7.1 216.199.639.2177.169.780
8.9 270.1124.549.0221.487.2100
Width
(inch)
Width
(cm)
Height
(cm)
Distance
(cm)
Distance
(ft)
Height
(inch)
EN
11
